StarLight GLF1-1000-4.5 Data sheet [EN]

Fiber Optical Light Guide

GLF -1000-4.5

100-011335

For halogen and LED cold light sources

■

Low head generation on object

■

Versions with several flexible arms

■

Best transmission

■

High flexibility and luminous eiciency

■

Spot illumination

■

Adaptable to cold light sources from all manufacturers

■

Adaptable to customer needs

■

Technical Data

Number of arms 1

Diameter active light guide 4,5 mm

Length 1000 mm

Light guide access Standard 15 mm

Diameter light output 13 mm

Diameter light input 15 mm

Outer tube diameter 10 mm

Illumination point-like

Beam angle 70°

Temperature input (light source) max. 240°C

Ambient temperature max. 80°C

Material tube Steel spiral, PVC

Accessories

Focusing optics for light guides

Mounting systems

Adapter

© 2017 StarLight Opto-Electronics GmbH & Co. KG. Technical specifi cations are subject to change without notice.
Flachslander Str. 8 • D-90431 Nuremberg • Phone: [phone] • Fax: [phone] • [e-mail] • starlight-sl.com
