Stanton S.25O, S-250 User Manual

S.25O

SINGLE TOP LOADING CD PLAYER

USER MANUAL

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions – All the safety and operating
instructions should be read before this product is
operated.

2. Retain Instructions － The safety and operating
instructions should be retained for future
reference.

3. Heed Warnings － All warnings on the appliance
and in the operating instructions should be
adhered to.

4. Follow Instructions － All operating and use
instructions should be followed.

5. Water and Moisture － The appliance should not
be used near water - for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, and the like.

6. Carts and Stands － The appliance should be
used only with a cart or stand that is
recommended by the manufacturer.
An appliance and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the appliance
and cart combination to overturn.

7. Wall or Ceiling Mounting － The product should
be mounted to a wall or ceiling only as
recommended by the manufacturer.

8. Heat － The appliance should be situated away
from heat sources such as radiators, heat
registers, stoves, or other appliances (including
amplifiers) that produce heat.

9. Power Sources – This product should be operated
only from the type of power source indicated on
the rating label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer the operating instructions.

10. Grounding or Polarization – This product may be
equipped with a polarized alternation-current line
plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized
plug.

11. Power-Cord Protection－Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to the
cord in correspondence of plugs, convenience
receptacles, and the point where they exit from
the appliance.

12. Cleaning - The appliance should be cleaned only
as recommended by the manufacturer.
Clean by wiping with a cloth slightly damp with
water. Avoid getting water inside the appliance.

13. For AC line powered units - Before returning
repaired unit to user, use an ohm-meter to
measure from both AC plug blades to all exposed
metallic parts. The resistance should be more
than 100,000 ohms.

14. Non-use Periods－The power cord of the

appliance should be unplugged from the outlet
when left unused for a long period of time.

15. Object and Liquid Entry－Care should be taken

so that objects do not fall and liquids are not
spilled into the enclosure through openings.

16. Damage Requiring Service－The appliance
should be serviced by qualified service personnel
when:

A. The power-supply cord or the plug has been

damaged; or

B. Objects have fallen, or liquid has been spilled

into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate

normally or exhibits a marked change in

performance; or
E. The appliance has been dropped, or the

enclosure damaged.

17. Servicing－The user should not attempt any
service to the appliance beyond that described in
the operating instructions. All other servicing
should be referred to qualified service personnel.

18. Ventilation – Slots and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never
be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should
not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is the
manufacturer’s instructions have been adhered to.

19. Attachments – do not use attachments not

recommended by the product manufacturer as
they may cause hazards.

IMPORTANT SAFETY INSTRUCTIONS

20. Accessories – Do not place this product on an
unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child
or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.

21. Lightning – For added protection for this product

during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent
damage to the product due to lightning and
power-line surges.

CAUTION

CAUTION

The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the use to
the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.

The exclamation point within the equilateral triangle is intended to alert the user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying this
appliance.

To prevent electric shock, do not use this polarized plug with an extension cord, receptacle or other outlet unless

the blades can be fully inserted to prevent blade exposure.

LINE VOLTAGE SELECTION

115 V

230V

1) The desired voltage may be set with the VOLTAGE SELECTOR switch on the rear panel of the
main unit, using a screwdriver.

2) Do not twist the VOLTAGE SELECTOR switch with excessive force as this may cause damage.

3) If the VOLTAGE SELECTOR switch does not move smoothly contact a qualified serviceman.

CAUTION: To reduce the risk of electric shock, do not remove
any cover. No user-serviceable parts inside. Refer servicing to
qualified service personnel only.

CAUTION

22. Replacement Parts – When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer
or have the same characteristics as the original
part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.

23. Safety Check – Upon completion of any service or
repairs to this product, ask the service technician
to perform safety checks to determine that the
product is in proper operating condition.

NOTE ON USE

• Allow for sufficient heat dispersion when installed on a rack.

• Handle the power cord carefully.

• Hold the plug when unplugging the cord.

• Keep the set free from moisture, water, and dust.

• Unplug the power cord when not using the set for long periods of time.

• Do not obstruct the ventilation holes. (For sets with ventilation holes.)

• Do not let foreign objects in the set.

• Do not let insecticides, benzene, and thinner come in contact with the set.

• Never disassemble or modify the set in any way.

FUNCTIONS

1) EJECT: Opens the CD door

2) STOP: Stops the CD.

3) SKIP: Skips through the tracks on the CD, forward or
back.

4) : Scans forward or back through the

current track. This unit features 3 scan speeds. Keep
the or button pressed for a few seconds

to change the scan speed.

5) PLAY/PAUSE: Plays or pauses the CD. Autocue func-
tion sets the cue point automatically when this button is
used.

6) CUE: Used to recall and preview the cue point.

7) TIME: LCD display reads the time remaining or time
elapsed, according to this button.

8) PITCH: Turns pitch fader ON and OFF.

9) PITCH SELECT: Pressing the PITCH and PITCH
BEND - (minus) buttons simultaneously changes the
pitch fader range between +/- 8, 12, and 16%.

10) PITCH BEND: Maximum pitch on this unit is 16%. If

the pitch fader is already physically set to 16%, this
function will not work.

: Switches between Single or Continuous

play modes.

11) SGL/CTN

12) LOOP: Press once to set starting loop point, press
again set ending point and enter loop. Press a third
time to exit loop.

13) LCD DISPLAY: Shows time (minutes, seconds,
frame), and pitch information.

14) PITCH FADER: Used to speed up or slow down cur­rent track.

15) AUDIO OUT: This stereo line output connects to the
line input on any DJ mixer.

16) DIGITAL OUTPUT: This coaxial (S/P DIF) digital out­put connects to any RCA S/P DIF input, as found on
most standard computer sound cards or CD burners.

17) FADER START: Connects to any DJ mixer equipped
with a fader start input. This enables the user to start
the CD from the cue point, using the mixer’s cross or
line fader, depending on the mixer.

18)

VOLTAGE SELECTOR: Used to select the unit’s volt­age according to the local setting.

Note: The voltage
should preset correctly from the factory, however,
make sure to check it before powering the unit.

19) AC IN: This is the connection for the supplied power
cable.

20) POWER: This button is used to power the unit ON and
OFF.

21) PHONES: Use this stereo jack to connect a pair
of headphones.

*Just for Dual Voltage model only.

FUNCTIONS

1

EL A P S E D
RE M A IN

2

SI N G L E

CO N T I NU

14

13

3

12

11

4

10

5 6 7 8 9

15 162117 18 19

20

SPECIFICATION

POWER SOURCE Dual Voltage:

AC 115/230V, 50/60Hz

Single Voltage:
AC 100V, 50/60Hz (For Japan)

0V, 60Hz (For Taiwan)

AC 11
AC 120V, 60Hz (For U.S.A.,Canada,Mexico)
AC 220V, 50Hz (For United Arab Emirates,Chile,Aegentina)
AC 220V, 60Hz (For Philippines)
AC 230V, 50Hz (For Europe,New Zealand,South Africa,Singapore,Israel)

0V, 50Hz (For Australia,U.K.)

AC 24

DIMENSIONS 216(W) x 275(H) x 88(D) mm
WEIGHT 2.3Kgs

Stanton Magnetics, Inc. – Warranty Provision – Returns for Repairs or Replacement

WARRANTY

Through Stanton’s authorized dealers around the World, Stanton, or one of Stanton’s authorized distributors outside the U.S.,
will, without charge, repair or replace, at the sole discretion of the entity responsible for making the repair or providing the

replacement, any Stanton merchandise proved defective in material or workmanship for a period of one (1) year following the

date of original purchase. Exceptions to this warranty are as noted below:

The warranty for mechanical parts which are subject to wear and tear are limited to the earlier to occur of thirty (30) days
following the date of original purchase or the following number of cycles: Faders - 15,000; Rotary potentiometers - 10,000; and
Switches - 10,000.

Stanton will warrant all replacement parts and repairs for ninety (90) days from the date of original shipment. Repairs made
necessary by reason of misuse, alteration, normal wear, or accident are not covered under this warranty.

RETURNS

Authorized Stanton dealers are only authorized to sell and distribute merchandise within a specific country. All goods requiring
warranty repair or replacement must be returned (freight prepaid if not hand-delivered) to the authorized Stanton dealer from
whom the merchandise was purchased and in the same country where the merchandise was purchased. For purposes of
purchases made via the Internet, the merchandise must be returned to the authorized Stanton dealer in the country where the
authorized Stanton dealer which sold the merchandise to purchaser is located and not the authorized Stanton dealer in the
country where the purchaser is located or the country in which the merchandise was received. Any returns to a non-authorized
dealer or to an authorized Stanton dealer not in the same country as the merchandise was intended to be sold or as set forth
above will void this warranty.

To initiate a warranty repair, you must contact the authorized Stanton dealer from whom you purchased the merchandise, and
follow such authorized Stanton dealer’s return policy.

Stanton assumes no risk and shall be subject to no liability for damages or loss resulting from the specific use or application
made of the merchandise. Stanton's liability for any claim, whether based on breach of contract, negligence, infringement of any
rights of any party, or product liability, and relating to the merchandise shall not exceed the price received by Stanton from your
purchase of such merchandise. In no event will Stanton be liable for any special, incidental or consequential damages (including
loss of use, loss of profit and claims of third parties) however caused, whether by the negligence of Stanton or otherwise. To the
extent permitted by law and except as otherwise provided above, Stanton disclaims any express or implied warranties of
merchantability or fitness for a particular purpose.

The above warranty provides you with specific legal rights. You may also have additional rights, which are subject to variation
from state to state and country to country.

If there is a dispute regarding the warranty of merchandise that does not fall under the warranty conditions stated above, please
include a written explanation with the merchandise when returned pursuant to the terms and conditions set forth herein.

Please register your product online at www.stantondj.com or mail your completed warranty card to:

Stanton Magnetics, Inc, 3000 SW 42 St. Hollywood, Florida 33312.

STANTON WARRANTY REGISTRATION CARD

out in order to validate your warranty.

If you have internet access, please register your product at

www.stantondj.com. Otherwise, return this card completely filled

PERSONAL INFO

Name

Address

City State Zip

cut along dotted line

Country

Telephone

PRODUCT INFO

Model Number

Serial Number

Date of Purchase

Where did you buy this product?

Stanton Magnetics, Inc.
3000 SW 42nd Street
Hollywood, FL 33312
U.S.A.

PLACE
STAMP

HERE
