Stack-On PSF-709 4616-0708 User Manual [en, es, fr]

HOME SECURITY SAFE

INSTRUCTIONS

IMPORTANT

Record your key number. Record your serial number located on the lower right corner of the door. Keep keys and combination in a secure place away from children.

Do not store spare keys or this document in the safe.

Key No.

Serial No.

COMBINATION NUMBER

HOW TO OPEN

All numbers must be dialed exactly. If you pass a number, you can not back up. You must start over. All numbers are to be dialed to the Top Notch located on the top of the dial ring. (the 12 o'clock position)

1. Turn the Dial clockwise passing the first combination number three times landing on the number the fourth time.

2. Now turn the Dial counterclockwise, passing the second combination number twice landing on the number on the third time around.

3. Now turn the Dial clockwise, passing the third combination number once - landing on the number on the second time around.

4. Turn the Dial counterclockwise until you reach the fourth combination number.

5. Place the key in the key slot and turn clockwise until it stops.

6. Pull the door open using the key.

Example: If the dial combination numbers were 70 - 50 - 30 - 10

1st

2nd 3rd 4th

1st

4 times (R)

2nd

3 times (L)

2 time (R)

3rd

4th

1 time (L)

4 times 3 times twice once

To lock the safe, close the door, turn the key counterclockwise until it stops and turn the dial several times.

SELECTING A LOCATION

Your Security Safe should be installed in an isolated, dry and secure area. For greater security the safe must be fastened to a solid surface.

SECURING THE SAFE

Locate the (2) mounting hole locations on the inside bottom of the safe under the paper stickers. It will be necessary to make a clearance hole through the safe insulation using a drill. Drill holes through the insulation using the same diameter drill as the diameter of the mounting hardware you are using. IMPORTANT: The fasteners you use must completely fill the hole you drilled in the insulation. (figure 1) You must use the fasteners after you drill the holes. Failure to do so will void the fire rating.

Through the clearance holes, mark the hole locations on the mounting surface. Drill the appropriate diameter and depth of pilot holes depending on the type of hardware being used and the type of mounting surface. Secure the safe with the fasteners. (figure 2)

NOTE: The safe needs to be upright and right side up or the locking mechanism won't work.

IMPORTANT

Keep your combination number and keys in a secure place, away from children. Keep this record of your serial number, combination number and key number in a secure place separate from your safe. You will need the serial number as a reference for obtaining a copy of your combination number or replacement keys.

To obtain a copy of your combination number and/or to order a replacement key set, follow the instructions on the attached form.

STACK-ON PRODUCTS CO., P.O. BOX 489, WAUCONDA, IL 60084

4616-0708

Security Cabinets and Safes Key or Combination Request

“This is not a Registration Form”

Verification of ownership is required in order to receive replacement key or confirm your combination on your security product.

In order to receive a replacement key or obtain the combination to your security product:

1. Complete the following form and send to Stack-On Products.

2. Send a copy of your valid driver’s license along with the form.

3. Send a copy of the receipt showing the original purchase.

4. Security product owner must sign form.

5. Owner’s signature must be notarized.

6. Send $10.00 for replacement key or combination. Personal Check, MasterCard, or Visa

accepted.

7. Send completed information to: Stack-On Products Company       1360 N. Old Rand Road

P.O. box 489 Wauconda, IL 60084

Serial Number______________________  Key Number (if applicable) _______

Unit Dimensions________________________________________

Unit Description___________________________________________________________

Owner’s Name ____________________________________ Date Purchased___/___/____

Owner’s Address ___________________________ Unit or Apt Number _________________

City ___________________________ State _______________ Zip Code________________

Telephone Number: (____)___________________ Fax Number: (____)___________________

Owner’s Email Address: ________________________________________________________

Owner’s Signature __________________________ Notary Signature________________

Notary Commission Expires: _____/_____/_____ Notary Stamp

SERVICE REQUESTED

Combination confirmation:  Yes  No $10.00 charge for this service

Key Replacement:   Yes  No $10.00 charge for this service

Credit Card Information (Please circle one) MasterCard  Visa

Expiration Date: ___/___/___ Card Number:______________________________________

Credit Card Identification Number (Located on back of card, last 3 digits on signature strip)_________

9/07

4616-0708

STACK-ON FIRE RESISTANT SAFE

LIMITED LIFETIME GUARANTEE AND LIMITED FIVE YEAR WARRANTY

(Valid Only for Purchases in North America)

If your Stack-On Fire Resistant Steel Safe suffers damage due to theft or fire at any time while still owned by the original owner, Stack-On will either repair or replace (at Stack-On’s discretion) your safe free of charge. If Stack-On chooses to repair the safe, such repair work may be performed by a local technician approved by Stack-On. Depending on the extent of the damage, Stack-On may require the safe be returned to the factory for repair. If the safe is so returned, Stack-On will pay the freight to the factory as well as the return freight. If the safe is replaced, Stack-On will pay the freight. This guarantee does not cover labor costs for removal or installation of the safe and its contents. Any repair, dismantling, or tampering undertaken without the prior written approval or direction of Stack-On will nullify this guarantee. Personal property in the safe is not covered under this guarantee.

In addition, Stack-On Fire Resistant Steel Safes are warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original purchase by a consumer. This warranty extends to the initial consumer only. If you believe there is a defect in material or workmanship in your Stack-On Fire Resistant Steel Safe during the 5year warranty period, please contact our customer service department at the address and in the manner set forth below. If Stack-On is properly notified during the 5-year warranty period and, after inspection confirms there is a defect, Stack-On will, at its sole option, provide repair parts or exchange the product at no charge, or refund the purchase price of the product.

THIS WARRANTY DOES NOT COVER ANY PRODUCT, OR ANY PART OF ANY PRODUCT, WHICH HAS BEEN SUBJECT TO EXCESSIVE USE, ACCIDENT, NEGLIGENCE, INCORRECT MAINTENANCE, ALTERATION OR REPAIR BY ANYONE OTHER THAN STACK-ON, ABUSE, OR MISUSE.

THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY DISCLAIMED AND EXCLUDED. STACK-ON SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES. STACK-ON NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT, ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF STACK-ON'S FIRE RESISTANT STEEL SAFES.

STACK-ON WILL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO THE INITIAL CONSUMER FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, EXEMPLARY, OR PUNITIVE DAMAGES ARISING OUT OF THE PURCHASE OR USE OF ANY STACK-ON PRODUCTS, INCLUDING THE FIRE RESISTANT STEEL SAFES. STACK-ON'S LIABILITY FOR ANY BREACH OF THIS WARRANTY SHALL BE LIMITED EXCLUSIVELY TO REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT, AS DESCRIBED ABOVE, OR A REFUND OF THE PURCHASE PRICE OF THE PRODUCT. IN NO EVENT SHALL STACK-ON'S OBLIGATION UNDER THIS WARRANTY EXCEED THE PRICE OF THE PRODUCT.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Please send your claim pursuant to the above guarantee or warranty in writing by regular mail or email to:

Stack-On Products Co. Attn.: Customer Service Department 1360 North Old Rand Road Wauconda, IL 60084 customerservice@stack-on.com

Be sure to include:

Your name and address

A description of the warranty claim, fire or theft

The model number and photographs of the safe

The serial number off the front or back of the safe

A copy of the report from the fire department, police or insurance company within 30 days of damage (applies to units damaged by theft or fire)

Proof of purchase information of the safe

This product is not designed for the storage of computer disks, CDs, DVDs, audio-visual materials or photographs/negatives.

08/07

4616-0708
