Stack-On PS-512 9123-0708 User Manual [en, es, fr]

R

Installation Instructions

Home Security Safe

IMPORTANT

Record the serial number from the tag on the back of the safe or the
tag on the inside of the lock cover plate on the front of the safe.
Record your combination number.

Keep keys in a secure place away from children.

For electronic safes - DO NOT STORE KEYS OR YOUR
COMBINATION INSIDE SAFE

KEY SAFES

Insert key into slot and turn in a clockwise direction. Then pull the door open without removing the key.
If you lose your key please see the instructions at the end of this instruction sheet.

ELECTRONIC SAFES

When you first recieve your new electronic safe you will need to open the door with the key in order to
install the batteries. Batteries are included and are located inside the safe in the hardware bag.

Serial #:

Your Electronic Safe Combination

®

To open the door with the key, first remove the small central panel from the front of the faceplate. Insert the key
and turn counterclockwise. Turn the knob to the right and open the door.
NOTE: This key has also been provided in case you lose or forget your security code or the batteries run low. If
you lose your key, you may purchase a replacement key by referencing the serial number located under the
removable central panel. See section at the bottom of this instruction regarding replacement keys.

Locate the batteries inside the safe. Open the battery compartment on the back of the door by pushing the tab
in the direction of the arrow and install the batteries.

ENTERING YOUR SECURITY CODE

To enter your own security code you will need to follow the steps listed below:

1. After installing the batteries, locate the small red button on the inside of the door near the hinge.

2. Press the red button and then release it, you will hear a beep. DO NOT SHUT THE DOOR UNTIL YOU HAVE
CONFIRMED THAT YOUR NEW SECURITY CODE HAS BEEN ENTERED CORRECTLY.

3. With the door open, enter your own personal security code, which can be 3-8 digits long, and confirm your
new code by pressing the " # " key on the electronic touch pad. Before you close the door, try the new security
code to make sure the lock releases the knob so you can turn it and retract the live action locking bolts.

If the code fails, go through steps 1-3 again. If the code works successfully, then you should lock the safe.

When you open the safe in the future enter the security code you have set followed by the " " key and turn
the knob.

If the incorrect security code is entered 3 times you will have an automatic lockout for 20 seconds before you can
try your code again.

If the incorrect security code is entered 3 additional times there will be a 5-minute lockout before the code can be
tried again.

9123-0708

1

12

BATTERY REPLACEMENT

This safe uses 4 - AA batteries. Under normal use, batteries will last about 1 year.

When the battery is low, a red light will come on warning you that the battery is low.

To test the batteries, enter your security code. If the batteries are low the red light located in the middle of the top of the
keypad will start to flash.

To replace the batteries, open the battery compartment on the back of the door by pushing the tab in the direction of the
arrow and install all new batteries.

YOU MUST REPROGRAM YOUR SECURITY CODE AFTER YOU REPLACE THE BATTERIES. SEE STEPS 1-3
UNDER "ENTERING YOUR SECURITY CODE".

TURNING THE KEYPAD SOUND OFF/ON

You can turn off the "Beep" sound of the keypad by entering the code 633.

To turn the "Beep" sound on, enter the code 66.

MAINTENANCE FOR KEY AND ELECTRONIC SAFES

If the door of the safe starts to rub on the door frame, open the door per the instructions above.

By the door hinges you will find a threaded stem. Use an Allen Wrench to tighten the threaded stem. This will help
realign the door and give you trouble free access to the contents of your safe.

SELECTING A LOCATION

For best results this safe should be installed in an isolated, dry and secure area.

For greater security the safe should be fastened to solid surfaces. Ideally the
safe would be installed to both a wall and permanent shelf.

SECURING THE SAFE

Secure the safe to the wall and permanent shelf using the holes and hardware provided.
(see figure 1)

Mark the holes to be used. Drill the appropriate diameter and depth of pilot holes
depending on the type of hardware being used and the type of mounting surface.

Secure the safe with the fasteners.

NOTE: The safe needs to be upright and right side up or the locking mechanism will not
function properly.

IMPORTANT

Keep keys and your combination number in a secure
place, away from children. Keep this record of your serial
number and combination in a secure place separate from
your safe. To order a replacement key set, follow the
instructions on the attached form.

STACK-ON PRODUCTS COMPANY

P.O. BOX 489

WAUCONDA, IL 60084

FIGURE 1

9123-0708

2

12

R

Security Cabinets and Safes Key or Combination Request

“This is not a Registration Form”

Verification of ownership is required in order to receive replacement key or confirm your combination
on your security product.

In order to receive a replacement key or obtain the combination to your security product:

1. Complete the following form and send to Stack-On Products.

2. Send a copy of your valid driver’s license along with the form.

3. Send a copy of the receipt showing the original purchase.

4. Security product owner must sign form.

5. Owner’s signature must be notarized.

6. Send $10.00 for replacement key or combination. Personal Check, MasterCard, or Visa

accepted.

7. Send completed information to: Stack-On Products Company
      1360 N. Old Rand Road

P.O. box 489
Wauconda, IL 60084

Serial Number______________________  Key Number (if applicable) _______

Unit Dimensions________________________________________

Unit Description___________________________________________________________

Owner’s Name ____________________________________ Date Purchased___/___/____

Owner’s Address ___________________________ Unit or Apt Number _________________

City ___________________________ State _______________ Zip Code________________

Telephone Number: (____)___________________ Fax Number: (____)___________________

Owner’s Email Address: ________________________________________________________

Owner’s Signature __________________________ Notary Signature________________

Notary Commission Expires: _____/_____/_____ Notary Stamp

SERVICE REQUESTED

Combination confirmation:  Yes  No
$10.00 charge for this service

Key Replacement:   Yes  No
$10.00 charge for this service

Credit Card Information (Please circle one) MasterCard  Visa

Expiration Date: ___/___/___ Card Number:______________________________________

Credit Card Identification Number (Located on back of card, last 3 digits on signature strip)_________

9/07

9123-0708

3

12

R

LIMITED THREE YEAR WARRANTY

SECURITY PLUS STEEL SAFES

Stack-On Products Co. (“Stack-On”) Security Plus Steel Safes are warranted to be free from
defects in material and workmanship for a period of three (3) years from the date of original
purchase by a consumer. This warranty extends to the initial consumer only.

If you believe there is a defect in material or workmanship in your Security Plus Steel Safe
during the three-year warranty period, please contact our customer service department, by
regular mail or email at the address listed below, and include with your correspondence proof of
purchase information and the model number of the safe.

Stack-On Products Company

1360 North Old Rand Road

Wauconda, IL 60084

[e-mail]

If Stack-On is properly notified during the three-year warranty period and, after inspection
confirms there is a defect, Stack-On will, at its sole option, provide repair parts or exchange the
product at no charge, or refund the purchase price of the product.

THIS WARRANTY DOES NOT COVER ANY PRODUCT, OR ANY PART OF ANY PRODUCT,
WHICH HAS BEEN SUBJECT TO EXCESSIVE USE, ACCIDENT, NEGLIGENCE, ABUSE OR
MISUSE, INCORRECT MAINTENANCE, ALTERATION OR REPAIR BY ANYONE OTHER
THAN STACK-ON. IN ADDITION, THIS WARRANTY DOES NOT COVER ANY
ACCESSORIES OR PARTS USED WITH OR IN THE PRODUCT WHICH ARE NOT
INCLUDED WITH THE ORIGINAL PURCHASE.

THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED INCLUDING THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY DISCLAIMED AND
EXCLUDED. STACK-ON SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR
LIABILITIES. STACK-ON NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON
TO ASSUME FOR IT, ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF STACK­ON’S SECURITY PLUS STEEL SAFES.

STACK-ON WILL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO THE INITIAL
CONSUMER FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, EXEMPLARY, OR
PUNITIVE DAMAGES ARISING OUT OF THE PURCHASE OR USE OF ANY STACK-ON
PRODUCTS, INCLUDING THE SECURITY PLUS STEEL SAFES.

STACK-ON’S LIABILITY FOR ANY BREACH OF THIS WARRANTY SHALL BE LIMITED
EXCLUSIVELY TO REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT, AS
DESCRIBED ABOVE, OR A REFUND OF THE PURCHASE PRICE OF THE PRODUCT.

IN NO EVENT SHALL STACK-ON’S OBLIGATION UNDER THIS WARRANTY EXCEED THE
PRICE OF THE PRODUCT.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.

9123-0708

4

12
