Stack-On PDS-500 9004-0708 User Manual [en, es, fr]

R

®

Installation Instructions

Home Security Safe

IMPORTANT

Record the serial number from the tag on the back of the safe or
from the tag on the inside of the lock cover plate on the front of
the safe. Record your combination number.

Keep keys in a secure place away from children.

For electronic safes - DO NOT STORE KEYS OR YOUR
COMBINATION INSIDE SAFE.

ELECTRONIC SAFES

When you first recieve your new electronic safe you will need to open the door with the key in order to install the
batteries. Batteries are included and are located inside the safe in the hardware bag.

To open the door with the key, first remove the small central panel from the front of the faceplate. Insert the key and turn
counterclockwise. Turn the knob to the right and open the door.
NOTE: This key has also been provided in case you lose or forget your security code or the batteries run low. If you lose
your key, you may purchase a replacement key by referencing the serial number located under the removable central panel.
See section at the bottom of this instruction regarding replacement keys.

Locate the batteries inside the safe. Open the battery compartment on the back of the door by pushing the tab in the
direction of the arrow and install the batteries.

Serial #:

Your Electronic Safe Combination

ENTERING YOUR SECURITY CODE

To enter your own security code you will need to follow the steps listed below:

1. After installing the batteries, locate the small red button on the inside of the door near the hinge.

2. Press the red button and then release it, you will hear a beep. DO NOT SHUT THE DOOR UNTIL YOU HAVE
CONFIRMED THAT YOUR NEW SECURITY CODE HAS BEEN ENTERED CORRECTLY.

3. With the door open, enter your own personal security code, which can be 3-8 digits long, and confirm your new code by
pressing the " # " key on the electronic touch pad. Before you close the door, try the new security code to make sure the lock
releases the knob so you can turn it and retract the live action locking bolts.

If the code fails, go through steps 1-3 again. If the code works successfully, then you should lock the safe.

When you open the safe in the future enter the security code you have set followed by the " " key and turn the knob.

If the incorrect security code is entered 3 times you will have an automatic lockout for 20 seconds before you can try your code
again.

If the incorrect security code is entered 3 additional times there will be a 5-minute lockout before the code can be tried again.

BATTERY REPLACEMENT

This safe uses 4 - AA batteries. Under normal use, batteries will last about 1 year.

When the battery is low, a red light will come on warning you that the battery is low.

To test the batteries, enter your security code. If the batteries are low the red light located in the middle of the top of the
keypad will start to flash.

To replace the batteries, open the battery compartment on the back of the door by pushing the tab in the direction of the
arrow and install all new batteries.

YOU MUST REPROGRAM YOUR SECURITY CODE AFTER YOU REPLACE THE BATTERIES. SEE STEPS 1-3 UNDER
"ENTERING YOUR SECURITY CODE".

9004-0708

1

12

TURNING THE KEYPAD SOUND OFF/ON

You can turn off the "Beep" sound of the keypad by entering the code 633.

To turn the "Beep" sound on, enter the code 66.

MAINTENANCE FOR KEY AND ELECTRONIC SAFES

If the door of the safe starts to rub on the door frame, open the door per the instructions above.

By the door hinges you will find a threaded stem. Use an Allen Wrench to tighten the threaded stem. This will help
realign the door and give you trouble free access to the contents of your safe.

DRAWER MOUNTING

For best results this safe should be mounted in a dry and secure area.

Select an appropriate sized drawer for your safe. Place the safe in the
drawer and try opening and closing both the safe and the drawer.

Before mounting the the safe to the bottom of the drawer, check to make
sure the bottom of the drawer is recessed so there will be enough
clearance for the bolts. There should not be any interference from the bolts
when opening or closing the drawer.

Drill holes in the drawer bottom and secure the safe with the bolts.

WALL MOUNTING (Model PDS-505 only)

For best results this safe should be mounted in a dry and secure area.

The hardware used may vary depending on the type of wall and spacing of wall supports.
The safe must be fastened to a solid and secure wall structure such as wall studs that
can support a minimum of 30 lbs. (approximate weight of the safe when empty). These
instructions provide a general guideline for hanging this unit. Please contact your local
hardware retailer for fastening hardware for your particular wall.

The safe must be mounted flush to the wall. It is important that the safe is securely
fastened to the wall. These units are heavy and could cause injury.

TIP: A securely fastened cleat (A) mounted level and at the appropriate height will aid in
mounting the safe.

IMPORTANT

A

Keep keys and your combination number in a secure
place, away from children. Keep this record of your serial
number and combination in a secure place separate from
your safe. To order a replacement key set, follow the
instructions on the attached form.

STACK-ON PRODUCTS COMPANY

P.O. BOX 489

WAUCONDA, IL 60084

9004-0708

2

12

R

Security Cabinets and Safes Key or Combination Request

“This is not a Registration Form”

Verification of ownership is required in order to receive replacement key or confirm your combination
on your security product.

In order to receive a replacement key or obtain the combination to your security product:

1. Complete the following form and send to Stack-On Products.

2. Send a copy of your valid driver’s license along with the form.

3. Send a copy of the receipt showing the original purchase.

4. Security product owner must sign form.

5. Owner’s signature must be notarized.

6. Send $10.00 for replacement key or combination. Personal Check, MasterCard, or Visa

accepted.

7. Send completed information to: Stack-On Products Company
      1360 N. Old Rand Road

P.O. box 489
Wauconda, IL 60084

Serial Number______________________  Key Number (if applicable) _______

Unit Dimensions________________________________________

Unit Description___________________________________________________________

Owner’s Name ____________________________________ Date Purchased___/___/____

Owner’s Address ___________________________ Unit or Apt Number _________________

City ___________________________ State _______________ Zip Code________________

Telephone Number: (____)___________________ Fax Number: (____)___________________

Owner’s Email Address: ________________________________________________________

Owner’s Signature __________________________ Notary Signature________________

Notary Commission Expires: _____/_____/_____ Notary Stamp

SERVICE REQUESTED

Combination confirmation:  Yes  No
$10.00 charge for this service

Key Replacement:   Yes  No
$10.00 charge for this service

Credit Card Information (Please circle one) MasterCard  Visa

Expiration Date: ___/___/___ Card Number:______________________________________

Credit Card Identification Number (Located on back of card, last 3 digits on signature strip)_________

9/07

9004-0708

3

12

R

LIMITED THREE YEAR WARRANTY

SECURITY PLUS STEEL SAFES

Stack-On Products Co. (“Stack-On”) Security Plus Steel Safes are warranted to be free from
defects in material and workmanship for a period of three (3) years from the date of original
purchase by a consumer. This warranty extends to the initial consumer only.

If you believe there is a defect in material or workmanship in your Security Plus Steel Safe
during the three-year warranty period, please contact our customer service department, by
regular mail or email at the address listed below, and include with your correspondence proof of
purchase information and the model number of the safe.

Stack-On Products Company

1360 North Old Rand Road

Wauconda, IL 60084

[e-mail]

If Stack-On is properly notified during the three-year warranty period and, after inspection
confirms there is a defect, Stack-On will, at its sole option, provide repair parts or exchange the
product at no charge, or refund the purchase price of the product.

THIS WARRANTY DOES NOT COVER ANY PRODUCT, OR ANY PART OF ANY PRODUCT,
WHICH HAS BEEN SUBJECT TO EXCESSIVE USE, ACCIDENT, NEGLIGENCE, ABUSE OR
MISUSE, INCORRECT MAINTENANCE, ALTERATION OR REPAIR BY ANYONE OTHER
THAN STACK-ON. IN ADDITION, THIS WARRANTY DOES NOT COVER ANY
ACCESSORIES OR PARTS USED WITH OR IN THE PRODUCT WHICH ARE NOT
INCLUDED WITH THE ORIGINAL PURCHASE.

THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED INCLUDING THE WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY DISCLAIMED AND
EXCLUDED. STACK-ON SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR
LIABILITIES. STACK-ON NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON
TO ASSUME FOR IT, ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF STACK­ON’S SECURITY PLUS STEEL SAFES.

STACK-ON WILL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO THE INITIAL
CONSUMER FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, EXEMPLARY, OR
PUNITIVE DAMAGES ARISING OUT OF THE PURCHASE OR USE OF ANY STACK-ON
PRODUCTS, INCLUDING THE SECURITY PLUS STEEL SAFES.

STACK-ON’S LIABILITY FOR ANY BREACH OF THIS WARRANTY SHALL BE LIMITED
EXCLUSIVELY TO REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT, AS
DESCRIBED ABOVE, OR A REFUND OF THE PURCHASE PRICE OF THE PRODUCT.

IN NO EVENT SHALL STACK-ON’S OBLIGATION UNDER THIS WARRANTY EXCEED THE
PRICE OF THE PRODUCT.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
