ST ST72623F2, ST72621K4, ST72622L2, ST72621L4, ST72621J4 User Manual

ST7262xxx
PDIP32 shrinkSO34 shrink
LQFP44 PDIP42 shrink
SO20 PDIP20
Low speed USB 8-bit MCU with 3 endpoints, Flash or
ROM memory, LVD, WDG, 10-bit ADC, 2 timers, SCI, SPI
Features
Memories
– 8 or 16 Kbyte Program memory
– In-Application and In-Circuit Programming for
FLASH versions
– 384 to 768 bytes RAM (128-byte stack)
Clock, Reset and Supply Management
– Enhanced Reset System (Power On Reset) – Low Voltage Detector (LVD) – Clock-out capability – 6 or 12 MHz Oscillator (8, 4, 2, 1 MHz internal
frequencies)
– 3 Power saving modes
USB (Universal Serial Bus) Interface
– DMA for low speed applications compliant
with USB specification (version 2.0):
– Integrated 3.3V voltage regulator and trans-
ceivers – Suspend and Resume operations – 3 Endpoints
Up to 31 I/O Ports
– Up to 31 multifunctional bidirectional I/O lines – Up to 12 External interrupts (3 vectors) – 13 alternate function lines – 8 high sink outputs
(8 mA@0.4 V/20 mA@1.3 V) – 2 true open drain pins (N buffer 8 mA@0.4 V)
3 Timers
– Configurable watchdog timer (8 to 500 ms
timeout) – 8-bit Auto Reload Timer (ART) with 2 Input
Captures, 2 PWM outputs and External Clock – 8-bit Time Base Unit (TBU) for generating pe-
riodic interrupts cascadable with ART
Device Summary
Features ST72623F2 ST72621K4 ST72622L2 ST72621L4 ST72621J4
Program memory - Kbytes 8 16 8 16 16 RAM (stack) - bytes 384 (128) 768 (128) 384 (128) 768 (128) 768 (128) Peripherals USB, Watchdog, Low Voltage Detector, 8-bit Auto-Reload timer, Timebase unit, A/D Converter Serial I/O - SPI + SCI SPI SPI + SCI I/Os 11212331 Operating Supply 4.0V to 5.5V (Low voltage 3.0V to 5.5V ROM versions available) Operating Temperature 0°C to +70°C Packages PDIP20/SO20 PDIP32 SO34 PDIP42/LQFP44
Analog Peripheral
– 10-bit A/D Converter with up to 8 input pins.
2 Communications Interfaces
– Asynchronous Serial Communication inter-
face
– Synchronous Serial Peripheral Interface
Instruction Set
– 8-bit data manipulation – 63 basic instructions – 17 main addressing modes – 8 x 8 unsigned multiply instruction – True bit manipulation
Nested interrupts
Development Tools
– Full hardware/software development package
June 2009 1/139
Doc ID 6996 Rev 5
1
Table of Contents
1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 PIN DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 PCB LAYOUT RECOMMENDATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 REGISTER & MEMORY MAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 FLASH PROGRAM MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 STRUCTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.4 ICC INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5 ICP (IN-CIRCUIT PROGRAMMING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.6 IAP (IN-APPLICATION PROGRAMMING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.7 RELATED DOCUMENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.8 REGISTER DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5 CENTRAL PROCESSING UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 CPU REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 CLOCKS AND RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.1 CLOCK SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.2 RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7 INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.2 MASKING AND PROCESSING FLOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7.3 INTERRUPTS AND LOW POWER MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.4 CONCURRENT & NESTED MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.5 INTERRUPT REGISTER DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
8 POWER SAVING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.2 WAIT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.3 HALT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
9 I/O PORTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9.2 FUNCTIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
9.3 MISCELLANEOUS REGISTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
10 ON-CHIP PERIPHERALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.1 WATCHDOG TIMER (WDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.2 PWM AUTO-RELOAD TIMER (ART) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
10.3 TIMEBASE UNIT (TBU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
10.4 SERIAL PERIPHERAL INTERFACE (SPI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
10.5 SERIAL COMMUNICATIONS INTERFACE (SCI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
10.6 USB INTERFACE (USB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
139
2/139
1
Doc ID 6996 Rev 5
Table of Contents
10.7 10-BIT A/D CONVERTER (ADC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
11 INSTRUCTION SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
11.1 CPU ADDRESSING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
11.2 INSTRUCTION GROUPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
12 ELECTRICAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
12.1 PARAMETER CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
12.2 ABSOLUTE MAXIMUM RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
12.3 OPERATING CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
12.4 SUPPLY CURRENT CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
12.5 CLOCK AND TIMING CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
12.6 MEMORY CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
12.7 EMC CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
12.8 I/O PORT PIN CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
12.9 CONTROL PIN CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
12.10TIMER PERIPHERAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
12.11COMMUNICATION INTERFACE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . 117
12.1210-BIT ADC CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
13 PACKAGE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
13.1 PACKAGE MECHANICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
14 DEVICE CONFIGURATION AND ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . 128
14.1 OPTION BYTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
14.2 DEVICE ORDERING INFORMATION AND TRANSFER OF CUSTOMER CODE . . . . . 128
14.3 DEVELOPMENT TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
14.4 ST7 APPLICATION NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
15 IMPORTANT NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
15.1 A/ D CONVERTER ACCURACY FOR FIRST CONVERSION . . . . . . . . . . . . . . . . . . . . 135
15.2 A/D CONVERTER CONVERSION SPEED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
15.3 SCI WRONG BREAK DURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
15.4 UNEXPECTED RESET FETCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
15.5 HALT MODE POWER CONSUMPTION WITH ADC ON . . . . . . . . . . . . . . . . . . . . . . . . . 136
16 REVISION HISTORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
3/139
139
Doc ID 6996 Rev 5
ST7262xxx
8-BIT CORE
ALU
ADDRESS AND DATA BUS
OSCIN
OSCOUT
RESET
PORT B
USB SIE
PORT A
SCI
PORT C
SPI
PB7:0
(8 bits)
PC7:0
(8 bits)
OSCILLATOR
Internal CLOCK
CONTROL
RAM
(384,
PA7:0
(8 bits)
V
SS
V
DD
POWER SUPPLY
PROGRAM
(8 or 16K Bytes)
LVD
10-BIT ADC
MEMORY
WATCHDOG
USBDP
USBDM
USBVCC
PWM ART
USB DMA
V
SSA
V
DDA
PORT D
PD6:0 (7 bits)
TIME BASE UNIT
V
PP
or 768 Bytes)

1 INTRODUCTION

The ST7262 and ST72F62 devices are members of the ST7 microcontroller family designed for USB applications.
All devices are based on a common industry­standard 8-bit core, featuring an enhanced instruc­tion set.
The ST7262 devices are ROM versions. The ST72F62 versions feature dual-voltage
FLASH memory with FLASH Programming capa­bility.
Under software control, all devices can be placed in WAIT, SLOW, or HALT mode, reducing power
Figure 1. General Block Diagram
consumption when the application is in idle or standby state.
The enhanced instruction set and addressing modes of the ST7 offer both power and flexibility to software developers, enabling the design of highly efficient and compact application code. In addition to standard 8-bit data management, all ST7 micro­controllers feature true bit manipulation, 8x8 un­signed multiplication and indirect addressing modes.
4/139
1
Doc ID 6996 Rev 5

2 PIN DESCRIPTION

44 43 42 41 40 39 38 37 36 35 34
33 32 31 30 29 28 27 26 25 24 23
12 13 14 15 16 17 18
19 20 21 22
1 2 3 4 5 6 7 8 9 10 11
38 37 36 35 34 33 32 31 30 29 28 27
16
15
1 2 3 4 5 6 7 8 9 10 11 12 13 14
39
40
41
42
PD6 PD5
OSCOUT
OSCIN
IT9 / PC2
IT10 / SCK / PC3
IT11 / SS
/ PC4
IT12 / MISO / PC5
MOSI / PC6
PD1
V
PP
PD2
PD3
PD4
PC7
PD0
V
DDA
USBVCC
PB1 (HS) / RDI
PB0 (HS) / MCO
PA7 / AIN7
PA6 / AIN6
PA5 / AIN5
PA4 / AIN4
PA3 / AIN3 / IT4
PA0 / AIN0 / IT1 / USBOE
RESET
V
SSA
USBDM
USBDP
PA1 / AIN1 / IT2 PA2 / AIN2 / IT3
21
20
17 18 19
IT8 / PWM1 / PB7 (HS)
PC0
PC1
V
DD
V
SS
26 25 24 23 22
PB6 (HS) / PWM0 / IT7 / ICCDATA
PB5 (HS) / ARTIC2 / IT6 / ICCCLK
PB4 (HS) / ARTIC1 / IT5
PB3 (HS) / ARTCLK
PB2 (HS) / TDO
OSCOUT
OSCIN
IT9 / PC2
IT10 / SCK / PC3
IT11 / SS
/ PC4
IT12 / MISO / PC5
MOSI / PC6
PD1
V
PP
PC7
PD0
IT8 / PWM1 / PB7
PC0
PC1
V
DD
V
SS
ARTCLK / PB3 (HS)
IT5 / ARTIC1 / PB4 (HS)
ICCCLK / IT6 / ARTIC2 / PB5 (HS)
ICCDATA /IT7 / PWM0 / PB6 (HS)
N.C.
TDO / PB2 (HS)
PB1 (HS) / RDI
PB0 (HS) / MCO
PA7 / AIN7
PA6 / AIN6
PA5 / AIN5
PA4 / AIN4
PA3 / AIN3 / IT4
PA0 / AIN0 / IT1 / USBOE
RESET
PA1 / AIN1 / IT2
PA2 / AIN2 / IT3
V
DDA
USBVCC
V
SSA
USBDM
USBDP
PD3
PD4
Reserved*
PD6
PD5
PD2
* Pin 39 of the LQFP44 package must be left unconnected.
Figure 2. 44-pin LQFP and 42-Pin SDIP Package Pinouts
ST7262xxx
Doc ID 6996 Rev 5
5/139
ST7262xxx
28 27 26 25 24 23 22 21 20 19 18
29
30
31
32
PC4 / SS / INT11 PC5 / MISO / IT12
PA4 / AIN4
PA3 / AIN3 / IT4
PA2 / AIN2 / IT3
PA1 / AIN1 / IT2
PA0 / AIN0 / IT1 / USBOE
V
SSA
USBDM
USBVCC
V
DDA
V
PP
RESET
PC6 / MOSI
USBDP
PC7
16
15
1 2 3 4 5 6 7 8
9 10 11 12 13 14
IT10 / SCK / PC3
IT9 / PC2
AIN7 / PA7
MCO / PB0 (HS)
RDI / PB1 (HS)
TDO / PB2 (HS)
ARTCLK / PB3 (HS)
IT5 / ARTIC1 / PB4 (HS)
ICCCLK / IT6 /ARTIC2 / PB5 (HS)
IT8 / PWM1 / PB7 (HS)
V
DD
V
SS
OSCOUT
OSCIN
ICCDATA / IT7 / PWM0 / PB6 (HS)
PA5 / AIN5
AIN6 / PA6
33
34
17
28 27 26 25 24 23 22 21 20 19 18 17
16
15
1 2 3 4 5 6 7 8 9 10 11 12 13 14
29
30
31
32
IT10 / SCK / PC3
IT9 / PC2
AIN7 / PA7
MCO / PB0 (HS)
RDI / PB1 (HS)
TDO / PB2 (HS)
ARTCLK / PB3 (HS)
IT5 / ARTIC1 / PB4 (HS)
ICCCLK / IT6 / ARTIC2 / PB5 (HS)
IT8 / PWM1 / PB7 (HS)
V
DD
V
SS
OSCOUT
OSCIN
ICCDATA / IT7 / PWM0 / PB6 (HS)
AIN6 / PA6
PC4 / SS
/ INT11
PC5 / MISO / IT12
PA4 / AIN4
PA3 / AIN3 / IT4
PA2 / AIN2 / IT3
PA1 / AIN1 / IT2
PA0 / AIN0 / IT1 / USBOE
V
SSA
USBDM
USBVCC
V
DDA
V
PP
RESET
PC6 / MOSI
USBDP
PA5 / AIN5
PC1
PIN DESCRIPTION (Cont’d)
Figure 3. 34-Pin SO and 32-Pin SDIP Package Pinouts
6/139
Doc ID 6996 Rev 5
Figure 4. 20-pin SO20 Package Pinout
14 13 12 11
15
16
17
18
OSCIN
OSCOUT
PB7 (HS) / PWM1 / IT8
PB6 (HS) / PWM0 / IT7/ ICCDATA
USBVCC
V
DD
V
PP
USBDP
1 2 3 4 5 6 7 8 9
10
IT3 / AIN2 / PA2
PB0 (HS) / MCO PB1 (HS) PB2 (HS) PB3 (HS) / ARTCLK PB4 (HS) / ARTIC1 / IT5
RESET
IT2 / AIN1 / PA1
19
20
USBOE/ IT1 / AIN0/ PA0
V
SS
USBDM
PB5 (HS) / ARTIC2 / IT6 / ICCCLK
14 13 12 11
15
16
17
18
OSCIN
OSCOUT
PB7 (HS) / PWM1 / IT8
PB6 (HS) / PWM0 / IT7/ICCDATA
USBVCC
V
DD
V
PP
USBDP
1 2 3 4 5 6 7 8 9
10
IT5 / ARTIC1 / PB4 (HS)
MCO / PB0 (HS)
PB1 (HS)
PB2 (HS)
RESET
IT2 / AIN1/ PA1
19
20
USBOE / IT1 / AIN0 / PA0
V
SS
USBDM
PB5 (HS) / ARTIC2 / IT6 / ICCCLK
IT3 / AIN2 / PA2
ARTCLK / PB3 (HS)
Figure 5. 20-pin DIP20 Package Pinout
ST7262xxx
Doc ID 6996 Rev 5
7/139
ST7262xxx
PIN DESCRIPTION (Cont’d)
Legend / Abbreviations:
Type: I = Input, O = Output, S = Supply Input level: A = Dedicated analog input Input level: C = CMOS 0.3V
= CMOS 0.3VDD/0.7VDD with input trigger
C
T
Output level: HS = High Sink (on N-buffer only) Port configuration capabilities:
– Input:float = floating, wpu = weak pull-up, int = interrupt (\ =falling edge, / =rising edge
ana = analog
– Output: OD = open drain, T = true open drain (N buffer 8mA@0.4 V), PP = push-pull
Table 1. Device Pin Description
/0.7VDD,
DD
),
Pin n°
DIP42
LQFP44
SO34
SO20
DIP32
Pin Name
DIP20
Level Port / Control
Input Output
Type
Input
Output
float
wpu
int
ana
OD
Main
Function
(after
reset)
PP
Alternate Function
FLASH programming voltage
1 6 29 28 9 14 V
PP
Sx
(12V), must be tied low in user mode.
27----PD1 I/OC
38----PD0 I/OC
4931---PC7 I/OC
5 103230 - - PC6/MOSI I/OC
T
T
T
T
xxPort D1
xxPort D0
xxPort C7
xxPort C6
SPI Master Out / Slave In
SPI Master In /
6 11 33 31 - - PC5/MISO/IT12 I/O C
T
xx xPort C5
Slave Out 1) / Interrupt 12 input
SPI Slave Select
7 123432 - - PC4/SS
/IT11 I/O C
T
xx xPort C4
(active low) 1)/ Interrupt 11 input
8 13 1 1 - - PC3/SCK/IT10 I/O C
9142 2 - -PC2/IT9 I/OC
10 15 3 3 11 16 OSCIN
T
T
xx xPort C3
xx xPort C2 Interrupt 9 input
These pins are used connect an
SPI Serial Clock Interrupt 10 input
external clock source to the on-
11 16 4 4 12 17 OSCOUT
12 17 5 5 4 9 V
13 18 6 6 8 13 V
SS
DD
14 19 7 - - - PC1 I/O C
1520----PC0 I/OC
S Digital Ground Voltage
S
T
T
PB7/PWM1/IT8/
16 21 8 7 13 18
RX_SEZ/DA-
I/O C
T
TAOUT/DA9
xTPort C1
xTPort C0
HS x \ x Port B7
chip main oscillator.
Digital Main Power Supply Volt­age
ART PWM output 1/ Interrupt 8 input
17 - - N.C. Not Connected
1)
1)
/
8/139
Doc ID 6996 Rev 5
ST7262xxx
Pin n°
DIP42
LQFP44
SO34
SO20
DIP32
Pin Name
DIP20
Level Port / Control
Input Output
Type
Input
Output
float
wpu
int
ana
OD
Main
Function
(after
reset)
PP
Alternate Function
ART PWM output 0/
18 22 9 8 14 19
PB6/PWM0/IT7/ ICCDATA
I/O C
HS x \ x Port B6
T
Interrupt 7 input/In­Circuit Communica­tion Data
ART Input Capture 2/
19 23 10 9 15 20
PB5/ARTIC2/IT6/ ICCCLK
I/O C
HS x / x Port B5
T
Interrupt 6 input/ In-Circuit Communi­cation Clock
20 24 11 10 16 1 PB4/ARTIC1/IT5 I/O C
21 25 12 11 17 2 PB3/ARTCLK I/O C
22 26 13 12 18 3 PB2/TDO I/O C
HS x / x Port B4
T
HS x x Port B3 ART Clock input
T
HS x x Port B2
T
23 27 14 13 19 4 PB1/RDI I/O CTHS x x Port B1
ART Input Capture 1/Interrupt 5 input
SCI Transmit Data
1)
Output SCI Receive Data
1)
Input
24 28 15 14 20 5 PB0/MCO I/O CTHS x x Port B0 CPU clock output
25 29 16 15 - - PA7/AIN7 I/O C
26 30 17 16 - - PA6/AIN6 I/O C
27 31 18 17 - - PA5/AIN5 I/O C
28 32 19 18 - - PA4/AIN4 I/O C
29 33 20 19 - - PA3/AIN3/IT4 I/O C
30 34 21 20 1 6 PA2/AIN2/IT3 I/O C
31 35 22 21 2 7 PA1/AIN1/IT2 I/O C
32 36 23 22 3 8
33 37 30 29 10 15 RESET
34 38 24 23 - - V
PA0/AIN0/IT1/ USBOE
SSA
I/O C
I/O C
S
T
T
T
T
T
T
T
T
xxxPort A7 ADC Analog Input 7
xxxPort A6 ADC Analog Input 6
xxxPort A5 ADC Analog Input 5
xxxPort A4 ADC Analog Input 4
x\xxPort A3
x\xxPort A2
x\xxPort A1
ADC Analog Input 3/ Interrupt 4 input
ADC Analog Input 2/ Interrupt 3 input
ADC Analog Input 1/ Interrupt 2 input
ADC Analog Input 0/
x\xxPort A0
Interrupt 1 input/ USB Output Enable
Top priority non maskable inter­rupt (active low)
Analog Ground Voltage, must be connected externally to V
SS
35 39 25 24 5 10 USBDM I/O USB bidirectional data (data -)
36 40 26 25 6 11 USBDP I/O USB bidirectional data (data +)
37 41 27 26 7 12 USBVCC S USB power supply 3.3V output
Analog Power Supply Voltage,
38 42 28 27 - - V
DDA
S
must be connected externally to
.
V
DD
39-----Reserved Must be left unconnected.
401----PD6 I/OC
412----PD5 I/OC
423----PD4 I/OC
T
T
T
xxPort D6
xxPort D5
xxPort D4
.
Doc ID 6996 Rev 5
9/139
ST7262xxx
14 13 12 11
15
16
17
18
USBVCC USBDP
1 2 3 4 5 6 7 8 9
10
19
20
USBDM
USB Connector
Ground
Ground
ST7262
1.5KOhm pull-up resistor
Pin n°
Pin Name
DIP42
LQFP44
SO34
SO20
DIP32
DIP20
434----PD3 I/OC
445----PD2 I/OC
Level Port / Control
Input Output
Type
Input
Output
T
T
wpu
float
xxPort D3
xxPort D2
int
ana
OD
Main
Function
(after
reset)
PP
Note 1: Peripheral not present on all devices. Refer to “Device Summary” on page 1.

2.1 PCB LAYOUT RECOMMENDATION

In the case of DIP20 devices the user should lay­out the PCB so that the DIP20 ST7262 device and the USB connector are centered on the same axis ensuring that the D- and D+ lines are of equal length. Refer to Figure 6
Figure 6. Recommended PCB Layout for USB Interface with DIP20 package
Alternate Function
10/139
Doc ID 6996 Rev 5

3 REGISTER & MEMORY MAP

0000h
Program Memory
Interrupt & Reset Vectors
HW Registers
BFFFh
0040h
003Fh
(see Table 2)
C000h
FFDFh FFE0h
FFFFh
(see Table 6)
0340h
Reserved
033Fh
Short Addressing RAM (zero page)
or Stack
017Fh
0040h
00FFh
768 Bytes RAM
E000h
8 KBytes
(128 Bytes)
16 KBytes
384 Bytes RAM
64 Bytes
01BFh
16-bit Addressing
RAM
Short Addressing RAM (zero page)
017Fh
0040h
00FFh
448 Bytes
033Fh
16-bit Addressing
RAM
16-bit Addressing
RAM
or Stack
(128 Bytes)
16-bit Addressing
RAM
192 Bytes
192 Bytes
ST7262xxx
As shown in the Figure 7, the MCU is capable of addressing 64K bytes of memories and I/O regis­ters.
The available memory locations consist of 64 bytes of register locations, 768 bytes of RAM and up to 16 Kbytes of user program memory. The RAM space includes up to 128 bytes for the stack from 0100h to 017Fh.
The highest address bytes contain the user reset and interrupt vectors.
Figure 7. Memory Map
IMPORTANT: Memory locations marked as “Re-
served” must never be accessed. Accessing a re­served area can have unpredictable effects on the device.
Doc ID 6996 Rev 5
11/139
ST7262xxx
Table 2. Hardware Register Map
Address Block
0000h 0001h
0002h 0003h
0004h 0005h
0006h 0007h
Port A
Port B
Port C
Port D
Register
Label
PADR PADDR
PBDR PBDDR
PCDR PCDDR
PDDR PDDDR
Register Name
Port A Data Register Port A Data Direction Register
Port B Data Register Port B Data Direction Register
Port C Data Register Port C Data Direction Register
Port D Data Register Port D Data Direction Register
Reset
Status
1)
00h
00h
1)
00h
00h
1)
00h
00h
1)
00h
00h
0008h ITRFRE1 Interrupt Register 1 00h R/W
0009h MISC Miscellaneous Register 00h R/W
000Ah 000Bh 000Ch
ADC
ADCDRMSB ADCDRLSB ADCCSR
ADC Data Register (bit 9:2) ADC Data Register (bit 1:0) ADC Control Status Register
00h 00h 00h
000Dh WDG WDGCR Watchdog Control Register 7Fh R/W
000Eh 0010h
0011h 0012h 0013h
SPI
SPIDR SPICR SPICSR
SPI Data I/O Register SPI Control Register SPI Control Status Register
Reserved Area (3 Bytes)
xxh 0xh 00h
Remarks
2)
R/W
2)
R/W
2)
R/W
2)
R/W
2)
R/W
2)
R/W
2)
R/W
2)
R/W
Read Only Read Only R/W
R/W R/W Read Only
0014h 0015h 0016h 0017h 0018h 0019h 001Ah 001Bh 001Ch
001Dh 001Eh 001Fh 0020h 0021h 0022h 0023h 0024h
PWM ART
SCI
PWMDCR1 PWMDCR0 PWMCR ARTCSR ARTCAR ARTARR ARTICCSR ARTICR1 ARTICR2
SCIERPR SCIETPR
SCISR SCIDR SCIBRR SCICR1 SCICR2
PWM AR Timer Duty Cycle Register 1 PWM AR Timer Duty Cycle Register 0 PWM AR Timer Control Register Auto-Reload Timer Control/Status Register Auto-Reload Timer Counter Access Register Auto-Reload Timer Auto-Reload Register ART Input Capture Control/Status Register ART Input Capture Register 1 ART Input Capture Register 2
SCI Extended Receive Prescaler register SCI Extended Transmit Prescaler Register Reserved Area SCI Status register SCI Data register SCI Baud Rate Register SCI Control Register 1 SCI Control Register 2
00h 00h 00h 00h 00h 00h 00h 00h 00h
00h 00h
--
C0h
xxh 00h
x000 0000b
00h
R/W R/W R/W R/W R/W R/W R/W Read Only Read Only
R/W R/W
Read Only R/W R/W R/W R/W
12/139
Doc ID 6996 Rev 5
ST7262xxx
Address Block
0025h 0026h 0027h 0028h 0029h 002Ah 002Bh 002Ch 002Dh 002Eh 002Fh 0030h 0031h
0032h
to
0035h
0036h 0037h
0038h FLASH FCSR Flash Control/Status Register 00h R/W
0039h ITRFRE2 Interrupt Register 2 00h R/W
003Ah
to
003Fh
USB
TBU
Register
Label
USBPIDR USBDMAR USBIDR USBISTR USBIMR USBCTLR USBDADDR USBEP0RA USBEP0RB USBEP1RA USBEP1RB USBEP2RA USBEP2RB
TBUCV TBUCSR
Register Name
USB PID Register USB DMA Address register USB Interrupt/DMA Register USB Interrupt Status Register USB Interrupt Mask Register USB Control Register USB Device Address Register USB Endpoint 0 Register A USB Endpoint 0 Register B USB Endpoint 1 Register A USB Endpoint 1 Register B USB Endpoint 2 Register A USB Endpoint 2 Register B
Reserved Area (4 Bytes)
TBU Counter Value Register TBU Control/Status Register
Reserved Area (6 Bytes)
Reset
Status
x0h xxh x0h 00h 00h 06h 00h
0000 xxxxb
80h 0000 xxxxb 0000 xxxxb 0000 xxxxb 0000 xxxxb
00h
00h
Remarks
Read Only R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
R/W R/W
Legend: x=undefined, R/W=read/write Notes:
1. The contents of the I/O port DR registers are readable only in output configuration. In input configura­tion, the values of the I/O pins are returned instead of the DR register contents.
2. The bits associated with unavailable pins must always be kept at their reset value.
Doc ID 6996 Rev 5
13/139
ST7262xxx
4 Kbytes
4 Kbytes
2Kbytes
SECTOR 1 SECTOR 0
16 Kbytes
SECTOR 2
8K 16K 32K 60K
FLASH
FFFFh
EFFFh
DFFFh
3FFFh
7FFFh
1000h
24 Kbytes
MEMORY SIZE
8 Kbytes 40 Kbytes
52 Kbytes
9FFFh
BFFFh
D7FFh
4K 10K 24K 48K

4 FLASH PROGRAM MEMORY

4.1 INTRODUCTION

The ST7 dual voltage High Density Flash (HDFlash) is a non-volatile memory that can be electrically erased as a single block or by individu­al sectors and programmed on a Byte-by-Byte ba­sis using an external V
supply.
PP
The HDFlash devices can be programmed and erased off-board (plugged in a programming tool) or on-board using ICP (In-Circuit Programming) or IAP (In-Application Programming).
The array matrix organisation allows each sector to be erased and reprogrammed without affecting other sectors.

4.2 MAIN FEATURES

3 Flash programming modes:
– Insertion in a programming tool. In this mode,
all sectors including option bytes can be pro­grammed or erased.
– ICP (In-Circuit Programming). In this mode, all
sectors including option bytes can be pro­grammed or erased without removing the de­vice from the application board.
– IAP (In-Application Programming) In this
mode, all sectors except Sector 0, can be pro­grammed or erased without removing the de­vice from the application board and while the application is running.
ICT (In-Circuit Testing) for downloading and
executing user application test patterns in RAM
Read-out protection
Register Access Security System (RASS) to
prevent accidental programming or erasing

4.3 STRUCTURE

The Flash memory is organised in sectors and can be used for both code and data storage.
Depending on the overall Flash memory size in the microcontroller device, there are up to three user sectors (see Table 3). Each of these sectors can be erased independently to avoid unnecessary erasing of the whole Flash memory when only a partial erasing is required.
The first two sectors have a fixed size of 4 Kbytes (see Figure 8). They are mapped in the upper part of the ST7 addressing space so the reset and in­terrupt vectors are located in Sector 0 (F000h­FFFFh).
Table 3. Sectors available in Flash devices
Flash Size (bytes) Available Sectors
4K Sector 0 8K Sectors 0,1
> 8K Sectors 0,1, 2
4.3.1 Read-out Protection
Read-out protection, when selected, provides a protection against Program Memory content ex­traction and against write access to Flash memo­ry. Even if no protection can be considered as to­tally unbreakable, the feature provides a very high level of protection for a general purpose microcon­troller.
In Flash devices, this protection is removed by re­programming the option. In this case, the entire program memory is first automatically erased and the device can be reprogrammed.
Read-out protection selection depends on the de­vice type:
– In Flash devices it is enabled and removed
through the FMP_R bit in the option byte.
– In ROM devices it is enabled by mask option
specified in the Option List.
Figure 8. Memory Map and Sector Address
14/139
Doc ID 6996 Rev 5
FLASH PROGRAM MEMORY (Cont’d)
ICC CONNECTOR
ICCDATA
ICCCLK
RESET
V
DD
HE10 CONNECTOR TYPE
APPLICATION POWER SUPPLY
1
246810
975 3
PROGRAMMING TOOL
ICC CONNECTOR
APPLICATION BOARD
ICC Cable
(See Note 3)
10kΩ
V
SS
ICCSEL/VPP
ST7
C
L2
C
L1
OSC1
OSC2
OPTIONAL
See Note 1
See Note 2
APPLICATION RESET SOURCE
APPLICATION
I/O
(See Note 4)
ST7262xxx

4.4 ICC INTERFACE

ICC (In-Circuit Communication) needs a minimum of four and up to six pins to be connected to the programming tool (see Figure 9). These pins are:
– RESET –V
: device reset
: device power supply ground
SS
Figure 9. Typical ICC Interface
– ICCCLK: ICC output serial clock pin – ICCDATA: ICC input/output serial data pin – ICCSEL/V
: programming voltage
PP
– OSC1(or OSCIN): main clock input for exter-
nal source (optional)
: application board power supply (see Fig-
–V
DD
ure 9, Note 3)
Notes:
1. If the ICCCLK or ICCDATA pins are only used as outputs in the application, no signal isolation is necessary. As soon as the Programming Tool is plugged to the board, even if an ICC session is not in progress, the ICCCLK and ICCDATA pins are not available for the application. If they are used as inputs by the application, isolation such as a serial resistor has to implemented in case another de­vice forces the signal. Refer to the Programming Tool documentation for recommended resistor val­ues.
2. During the ICC session, the programming tool must control the RESET flicts between the programming tool and the appli­cation reset circuit if it drives more than 5mA at high level (push pull output or pull-up resistor<1K). A schottky diode can be used to isolate the appli­cation RESET circuit in this case. When using a classical RC network with R > 1K or a reset man-
pin. This can lead to con-
Doc ID 6996 Rev 5
agement IC with open drain output and pull-up resistor > 1K, no additional components are need­ed. In all cases the user must ensure that no exter­nal reset is generated by the application during the ICC session.
3. The use of Pin 7 of the ICC connector depends on the Programming Tool architecture. This pin must be connected when using most ST Program­ming Tools (it is used to monitor the application power supply). Please refer to the Programming Tool manual.
4. Pin 9 has to be connected to the OSC1 or OS­CIN pin of the ST7 when the clock is not available in the application or if the selected clock option is not programmed in the option byte. ST7 devices with multioscillator capability need to have OSC2 grounded in this case.
15/139
ST7262xxx
FLASH PROGRAM MEMORY (Cont’d)

4.5 ICP (IN-CIRCUIT PROGRAMMING)

To perform ICP the microcontroller must be switched to ICC (In-Circuit Communication) mode by an external controller or programming tool.
Depending on the ICP code downloaded in RAM, Flash memory programming can be fully custom­ized (number of bytes to program, program loca­tions, or selection serial communication interface for downloading).
When using an STMicroelectronics or third-party programming tool that supports ICP and the spe­cific microcontroller device, the user needs only to implement the ICP hardware interface on the ap­plication board (see Figure 9). For more details on the pin locations, refer to the device pinout de­scription.

4.6 IAP (IN-APPLICATION PROGRAMMING)

This mode uses a BootLoader program previously stored in Sector 0 by the user (in ICP mode or by plugging the device in a programming tool).
This mode is fully controlled by user software. This allows it to be adapted to the user application, (us­er-defined strategy for entering programming mode, choice of communications protocol used to fetch the data to be stored, etc.). For example, it is possible to download code from the SPI, SCI or other type of serial interface and program it in the Flash. IAP mode can be used to program any of the Flash sectors except Sector 0, which is write/ erase protected to allow recovery in case errors occur during the programming operation.

4.7 RELATED DOCUMENTATION

For details on Flash programming and ICC proto­col, refer to the ST7 Flash Programming Refer-
ence Manual and to the ST7 ICC Protocol Refer­ence Manual
.

4.8 REGISTER DESCRIPTION

FLASH CONTROL/STATUS REGISTER (FCSR)
Read/Write Reset Value: 0000 0000 (00h)
70
00000000
This register is reserved for use by Programming Tool software. It controls the Flash programming and erasing operations.
16/139
Doc ID 6996 Rev 5

5 CENTRAL PROCESSING UNIT

ACCUMULATOR
X INDEX REGISTER
Y INDEX REGISTER
STACK POINTER
CONDITION CODE REGISTER
PROGRAM COUNTER
70
1C1I1HI0NZ
RESET VALUE = RESET VECTOR @ FFFEh-FFFFh
70
70
70
0
7
15 8
PCH
PCL
15
8
70
RESET VALUE = STACK HIGHER ADDRESS
RESET VALUE =
1X11X1XX
RESET VALUE = XXh
RESET VALUE = XXh
RESET VALUE = XXh
X = Undefined Value
ST7262xxx

5.1 INTRODUCTION

This CPU has a full 8-bit architecture and contains six internal registers allowing efficient 8-bit data manipulation.

5.2 MAIN FEATURES

Enable executing 63 basic instructions
Fast 8-bit by 8-bit multiply
17 main addressing modes (with indirect
addressing mode)
Two 8-bit index registers
16-bit stack pointer
Low power HALT and WAIT modes
Priority maskable hardware interrupts
Non-maskable software/hardware interrupts
Figure 10. CPU Registers

5.3 CPU REGISTERS

The 6 CPU registers shown in Figure 10 are not present in the memory mapping and are accessed by specific instructions.
Accumulator (A)
The Accumulator is an 8-bit general purpose reg­ister used to hold operands and the results of the arithmetic and logic calculations and to manipulate data.
Index Registers (X and Y)
These 8-bit registers are used to create effective addresses or as temporary storage areas for data manipulation. (The Cross-Assembler generates a precede instruction (PRE) to indicate that the fol­lowing instruction refers to the Y register.)
The Y register is not affected by the interrupt auto­matic procedures.
Program Counter (PC)
The program counter is a 16-bit register containing the address of the next instruction to be executed by the CPU. It is made of two 8-bit registers PCL (Program Counter Low which is the LSB) and PCH (Program Counter High which is the MSB).
Doc ID 6996 Rev 5
17/139
ST7262xxx
CENTRAL PROCESSING UNIT (Cont’d)
Condition Code Register (CC)
Read/Write Reset Value: 111x1xxx
70
11I1HI0NZ
C
The 8-bit Condition Code register contains the in­terrupt masks and four flags representative of the result of the instruction just executed. This register can also be handled by the PUSH and POP in­structions.
These bits can be individually tested and/or con­trolled by specific instructions.
Arithmetic Management Bits
Bit 4 = H Half carry. This bit is set by hardware when a carry occurs be-
tween bits 3 and 4 of the ALU during an ADD or ADC instructions. It is reset by hardware during the same instructions.
0: No half carry has occurred. 1: A half carry has occurred.
This bit is tested using the JRH or JRNH instruc­tion. The H bit is useful in BCD arithmetic subrou­tines.
Bit 2 = N Negative. This bit is set and cleared by hardware. It is repre-
sentative of the result sign of the last arithmetic, logical or data manipulation. It’s a copy of the re-
th
sult 7
bit. 0: The result of the last operation is positive or null. 1: The result of the last operation is negative
(i.e. the most significant bit is a logic 1).
This bit is accessed by the JRMI and JRPL instruc­tions.
Bit 1 = Z Zero.
This bit is set and cleared by hardware. This bit in­dicates that the result of the last arithmetic, logical or data manipulation is zero. 0: The result of the last operation is different from
zero.
1: The result of the last operation is zero. This bit is accessed by the JREQ and JRNE test
instructions. Bit 0 = C Carry/borrow.
This bit is set and cleared by hardware and soft­ware. It indicates an overflow or an underflow has occurred during the last arithmetic operation. 0: No overflow or underflow has occurred. 1: An overflow or underflow has occurred.
This bit is driven by the SCF and RCF instructions and tested by the JRC and JRNC instructions. It is also affected by the “bit test and branch”, shift and rotate instructions.
Interrupt Management Bits
Bit 5,3 = I1, I0 Interrupt The combination of the I1 and I0 bits gives the cur-
rent interrupt software priority.
Interrupt Software Priority I1 I0
Level 0 (main) 1 0 Level 1 0 1 Level 2 0 0 Level 3 (= interrupt disable) 1 1
These two bits are set/cleared by hardware when entering in interrupt. The loaded value is given by the corresponding bits in the interrupt software pri­ority registers (IxSPR). They can be also set/ cleared by software with the RIM, SIM, IRET, HALT, WFI and PUSH/POP instructions.
See the interrupt management chapter for more details.
18/139
Doc ID 6996 Rev 5
CPU REGISTERS (Cont’d)
PCH PCL
SP
PCH PCL
SP
PCL
PCH
X
A
CC
PCH PCL
SP
PCL
PCH
X
A
CC
PCH PCL
SP
PCL
PCH
X
A
CC
PCH PCL
SP
SP
Y
CALL
Subroutine
Interrupt
Event
PUSH Y POP Y IRET
RET
or RSP
@ 017Fh
@ 0100h
Stack Higher Address = 017Fh Stack Lower Address =
0100h
STACK POINTER (SP)
Read/Write Reset Value: 017Fh
15 8
00000001
Note: When the lower limit is exceeded, the Stack Pointer wraps around to the stack upper limit, with­out indicating the stack overflow. The previously stored information is then overwritten and there­fore lost. The stack also wraps in case of an under­flow.
The stack is used to save the return address dur­ing a subroutine call and the CPU context during
70
1 SP6 SP5 SP4 SP3 SP2 SP1 SP0
an interrupt. The user may also directly manipulate the stack by means of the PUSH and POP instruc­tions. In the case of an interrupt, the PCL is stored at the first location pointed to by the SP. Then the other registers are stored in the next locations as shown in Figure 11.
The Stack Pointer is a 16-bit register which is al­ways pointing to the next free location in the stack. It is then decremented after data has been pushed onto the stack and incremented before data is popped from the stack (see Figure 11).
Since the stack is 128 bytes deep, the 9 most sig­nificant bits are forced by hardware. Following an
– When an interrupt is received, the SP is decre-
mented and the context is pushed on the stack.
– On return from interrupt, the SP is incremented
and the context is popped from the stack.
A subroutine call occupies two locations and an in­terrupt five locations in the stack area.
MCU Reset, or after a Reset Stack Pointer instruc­tion (RSP), the Stack Pointer contains its reset val­ue (the SP6 to SP0 bits are set) which is the stack higher address.
The least significant byte of the Stack Pointer (called S) can be directly accessed by a LD in­struction.
ST7262xxx
Figure 11. Stack Manipulation Example
Doc ID 6996 Rev 5
19/139
ST7262xxx
OSCIN
OSCOUT
EXTERNAL
CLOCK
NC
OSCIN
OSCOUT
C
OSCIN
C
OSCOUT

6 CLOCKS AND RESET

6.1 CLOCK SYSTEM

6.1.1 General Description
The MCU accepts either a Crystal or Ceramic res­onator, or an external clock signal to drive the in­ternal oscillator. The internal clock (f
rived from the external oscillator frequency (f
CPU
) is de-
OSC
by dividing by 3 and multiplying by 2. By setting the OSC12/6 bit in the option byte, a 12 MHz external clock can be used giving an internal frequency of 8 MHz while maintaining a 6 MHz clock for USB (re­fer to Figure 14).
The internal clock signal (f
) consists of a
CPU
square wave with a duty cycle of 50%. It is further divided by 1, 2, 4 or 8 depending on the
Slow Mode Selection bits in the Miscellaneous register (SMS[1:0])
The internal oscillator is designed to operate with an AT-cut parallel resonant quartz or ceramic res­onator in the frequency range specified for f
osc
The circuit shown in Figure 13 is recommended when using a crystal, and Table 4 lists the recom­mended capacitors. The crystal and associated components should be mounted as close as pos­sible to the input pins in order to minimize output distortion and start-up stabilization time.
6.1.2 External Clock input
An external clock may be applied to the OSCIN in­put with the OSCOUT pin not connected, as shown on Figure 12. The t does not apply when using an external clock input.
),
specifications
OXOV
The equivalent specification of the external clock source should be used instead of t
OXOV
trical Characteristics).
6.1.3 Clock Output Pin (MCO)
The internal clock (f
) can be output on Port B0
CPU
by setting the MCO bit in the Miscellaneous regis­ter.
Figure 12. External Clock Source Connections
.
(see Elec-
Table 4. Recommended Values for 12 MHz Crystal Resonator
R
SMAX
C
OSCIN
C
OSCOUT
R
P
Note: R crystal (see crystal specification).
SMAX
20 Ω 25 Ω 70 Ω
56pF 47pF 22pF 56pF 47pF 22pF
1-10 MΩ 1-10 MΩ 1-10 MΩ
is the equivalent serial resistor of the
Note: When a crystal is used, and to not over­stress the crystal, ST recommends to add a serial resistor on the OSCOUT pin to limit the drive level in accordance with the crystal manufacturer’s specification. Please also refer to Section 12.5.4.
20/139
Figure 13. Crystal/Ceramic Resonator
Doc ID 6996 Rev 5
Figure 14. Clock block diagram
to CPU and
f
CPU
8/4/2/1 MHz
6 MHz (USB)
12 or
peripherals
%2
0
1
OSC12/6
6 MHz
Crystal
x2
Slow
Mode
%
SMS[1:0]
1/2/4/8
%3
(or 4/2/1/0.5 MHz)
MCO pin
LOW VOLTAGE
V
DD
FROM
WATCHDOG
RESET
RESET
INTERNAL
RESET
RESET

6.2 RESET

ST7262xxx
The Reset procedure is used to provide an orderly software start-up or to exit low power modes.
Three reset modes are provided: a low voltage re­set, a watchdog reset and an external reset at the RESET
pin.
A reset causes the reset vector to be fetched from addresses FFFEh and FFFFh in order to be loaded into the PC and with program execution starting from this point.
An internal circuitry provides a 514 CPU clock cy­cle delay from the time that the oscillator becomes active.
Caution: When the ST7 is unprogrammed or fully erased, the Flash is blank and the RESET vector is not programmed. For this reason, it is recom­mended to keep the RESET pin in low state until programming mode is entered, in order to avoid unwanted behaviour.
6.2.1 Low Voltage Reset
Low voltage reset circuitry generates a reset when
is:
V
DD
below V
below V
During low voltage reset, the RESET
when VDD is rising,
IT+
when VDD is falling.
IT-
pin is held low,
thus permitting the MCU to reset other devices.
Notes:
The Low Voltage Detector can be disabled by set­ting the LVD bit of the Option byte.
It is recommended to make sure that the V voltage rises monotonously when the device is ex­iting from Reset, to ensure the application functions properly.
6.2.2 Watchdog Reset
When a watchdog reset occurs, the RESET pulled low permitting the MCU to reset other devic­es as when low voltage reset (Figure 15).
6.2.3 External Reset
The external reset is an active low input signal ap­plied to the RESET
pin of the MCU. As shown in Figure 18, the RESET stay low for a minimum of one and a half CPU clock cycles.
An internal Schmitt trigger at the RESET vided to improve noise immunity.
Figure 15. Low Voltage Reset functional Diagram
Doc ID 6996 Rev 5
supply
DD
pin is
signal must
pin is pro-
21/139
ST7262xxx
RESET
V
DD
V
IT+
V
IT-
V
DD
Addresses
$FFFE
Temporization
V
IT+
(514 CPU clock cycles)
V
DD
OSCIN
f
CPU
FFFF
FFFE
PC
RESET
t
DDR
t
OXOV
514 CPU
CLOCK
CYCLES
DELAY
Figure 16. Low Voltage Reset Signal Output
Note: Typical hysteresis (V
IT+-VIT-
) of 250 mV is expected.
Figure 17. Temporization Timing Diagram after an internal Reset
Figure 18. Reset Timing Diagram
Note: Refer to Electrical Characteristics for values of t
22/139
Doc ID 6996 Rev 5
DDR
, t
OXOV
, V
IT+
and V
IT-.
ST7262xxx
RESET
R
ON
V
DD
WATCHDOG RESET
LVD RESET
INTERNAL RESET
PULSE
GENERATOR
200ns
Filter
t
w(RSTL)out
+ 128 f
OSC
delay
Figure 19. Reset Block Diagram
Note: The output of the external reset circuit must have an open-drain output to drive the ST7 reset pad.
Otherwise the device can be damaged when the ST7 generates an internal reset (LVD or watchdog).
Doc ID 6996 Rev 5
23/139
ST7262xxx
“IRET”
RESTORE PC, X, A, CC
STACK PC, X, A, CC
LOAD I1:0 FROM INTERRUPT SW REG.
FETCH NEXT
RESET
TLI
PENDING
INSTRUCTION
I1:0
FROM STACK
LOAD PC FROM INTERRUPT VECTOR
Y
N
Y
N
Y
N
Interrupt has the same or a
lower software priority
THE INTERRUPT
STAYS PENDING
than current one
Interrupt has a higher
software priority
than current one
EXECUTE
INSTRUCTION
INTERRUPT

7 INTERRUPTS

7.1 INTRODUCTION

The CPU enhanced interrupt management pro­vides the following features:
Hardware interrupts
Software interrupt (TRAP)
Nested or concurrent interrupt management
with flexible interrupt priority and level management:
– Up to 4 software programmable nesting levels – Up to 16 interrupt vectors fixed by hardware – 3 non maskable events: RESET, TRAP, TLI
This interrupt management is based on: – Bit 5 and bit 3 of the CPU CC register (I1:0), – Interrupt software priority registers (ISPRx), – Fixed interrupt vector addresses located at the
high addresses of the memory map (FFE0h to FFFFh) sorted by hardware priority order.
This enhanced interrupt controller guarantees full upward compatibility with the standard (not nest­ed) CPU interrupt controller.

7.2 MASKING AND PROCESSING FLOW

The interrupt masking is managed by the I1 and I0 bits of the CC register and the ISPRx registers which give the interrupt software priority level of each interrupt vector (see Table 5). The process­ing flow is shown in Figure 20.
When an interrupt request has to be serviced: – Normal processing is suspended at the end of
the current instruction execution.
– The PC, X, A and CC registers are saved onto
the stack.
– I1 and I0 bits of CC register are set according to
the corresponding values in the ISPRx registers of the serviced interrupt vector.
– The PC is then loaded with the interrupt vector of
the interrupt to service and the first instruction of the interrupt service routine is fetched (refer to “Interrupt Mapping” table for vector addresses).
The interrupt service routine should end with the IRET instruction which causes the contents of the saved registers to be recovered from the stack.
Note: As a consequence of the IRET instruction, the I1 and I0 bits will be restored from the stack and the program in the previous level will resume.
Table 5. Interrupt Software Priority Levels
Interrupt software priority Level I1 I0
Level 0 (main) Level 1 0 1 Level 2 0 0 Level 3 (= interrupt disable) 1 1
Low
High
10
Figure 20. Interrupt Processing Flowchart
24/139
Doc ID 6996 Rev 5
INTERRUPTS (Cont’d)
PENDING
SOFTWARE
Different
INTERRUPTS
Same
HIGHEST HARDWARE
PRIORITY SERVICED
PRIORITY
HIGHEST SOFTWARE
PRIORITY SERVICED
ST7262xxx
Servicing Pending Interrupts
As several interrupts can be pending at the same time, the interrupt to be taken into account is deter­mined by the following two-step process:
– the highest software priority interrupt is serviced, – if several interrupts have the same software pri-
ority then the interrupt with the highest hardware priority is serviced first.
Figure 21 describes this decision process.
Figure 21. Priority Decision Process
When an interrupt request is not serviced immedi­ately, it is latched and then processed when its software priority combined with the hardware pri­ority becomes the highest one.
Note 1: The hardware priority is exclusive while the software one is not. This allows the previous process to succeed with only one interrupt. Note 2: RESET, TRAP and TLI can be considered as having the highest software priority in the deci­sion process.
Different Interrupt Vector Sources
Two interrupt source types are managed by the CPU interrupt controller: the non-maskable type (RESET, TLI, TRAP) and the maskable type (ex­ternal or from internal peripherals).
Non-Maskable Sources
These sources are processed regardless of the state of the I1 and I0 bits of the CC register (see
Figure 20). After stacking the PC, X, A and CC
registers (except for RESET), the corresponding vector is loaded in the PC register and the I1 and I0 bits of the CC are set to disable interrupts (level
3). These sources allow the processor to exit HALT mode.
TLI (Top Level Hardware Interrupt)
This hardware interrupt occurs when a specific edge is detected on the dedicated TLI pin. Caution: A TRAP instruction must not be used in a TLI service routine.
TRAP (Non Maskable Software Interrupt)
This software interrupt is serviced when the TRAP instruction is executed. It will be serviced accord­ing to the flowchart in Figure 20 as a TLI. Caution: TRAP can be interrupted by a TLI.
RESET
The RESET source has the highest priority in the CPU. This means that the first current routine has the highest software priority (level 3) and the high­est hardware priority. See the RESET chapter for more details.
Maskable Sources
Maskable interrupt vector sources can be serviced if the corresponding interrupt is enabled and if its own interrupt software priority (in ISPRx registers) is higher than the one currently being serviced (I1 and I0 in CC register). If any of these two condi­tions is false, the interrupt is latched and thus re­mains pending.
External Interrupts
External interrupts allow the processor to exit from HALT low power mode. External interrupt sensitivity is software selectable through the ITRFRE2 register. External interrupt triggered on edge will be latched and the interrupt request automatically cleared upon entering the interrupt service routine. If several input pins of a group connected to the same interrupt line are selected simultaneously, these will be logically NANDed.
Peripheral Interrupts
Usually the peripheral interrupts cause the Device to exit from HALT mode except those mentioned in the “Interrupt Mapping” table. A peripheral interrupt occurs when a specific flag is set in the peripheral status registers and if the corresponding enable bit is set in the peripheral control register. The general sequence for clearing an interrupt is based on an access to the status register followed by a read or write to an associated register. Note: The clearing sequence resets the internal latch. A pending interrupt (i.e. waiting for being serviced) will therefore be lost if the clear se­quence is executed.
Doc ID 6996 Rev 5
25/139
ST7262xxx
MAIN
IT4
IT2
IT1
TLI
IT1
MAIN
IT0
I1
HARDWARE PRIORITY
SOFTWARE
3 3 3 3 3 3/0
3
11 11 11 11 11
11 / 10
11
RIM
IT2
IT1
IT4
TLI
IT3
IT0
IT3
I0
10
PRIORITY LEVEL
USED STACK = 10 BYTES
MAIN
IT2
TLI
MAIN
IT0
IT2
IT1
IT4
TLI
IT3
IT0
HARDWARE PRIORITY
3 2 1 3 3 3/0
3
11 00 01 11 11
11
RIM
IT1
IT4
IT4
IT1
IT2
IT3
I1 I0
11 / 10
10
SOFTWARE PRIORITY LEVEL
USED STACK = 20 BYTES
INTERRUPTS (Cont’d)

7.3 INTERRUPTS AND LOW POWER MODES

All interrupts allow the processor to exit the WAIT low power mode. On the contrary, only external and other specified interrupts allow the processor to exit from the HALT modes (see column “Exit from HALT” in “Interrupt Mapping” table). When several pending interrupts are present while exit­ing HALT mode, the first one serviced can only be an interrupt with exit from HALT mode capability and it is selected through the same decision proc­ess shown in Figure 21.
Note: If an interrupt, that is not able to Exit from HALT mode, is pending with the highest priority when exiting HALT mode, this interrupt is serviced after the first one serviced.
Figure 22. Concurrent Interrupt Management

7.4 CONCURRENT & NESTED MANAGEMENT

The following Figure 22 and Figure 23 show two different interrupt management modes. The first is called concurrent mode and does not allow an in­terrupt to be interrupted, unlike the nested mode in
Figure 23. The interrupt hardware priority is given
in this order from the lowest to the highest: MAIN, IT4, IT3, IT2, IT1, IT0, TLI. The software priority is given for each interrupt.
Warning: A stack overflow may occur without no­tifying the software of the failure.
Figure 23. Nested Interrupt Management
26/139
Doc ID 6996 Rev 5
INTERRUPTS (Cont’d)
ST7262xxx

7.5 INTERRUPT REGISTER DESCRIPTION

INTERRUPT SOFTWARE PRIORITY REGIS­TERS (ISPRX)
CPU CC REGISTER INTERRUPT BITS
Read/Write Reset Value: 111x 1010 (xAh)
70
11I1 H I0 NZC
Bit 5, 3 = I1, I0 Software Interrupt Priority These two bits indicate the current interrupt soft-
ware priority.
Interrupt Software Priority Level I1 I0
Level 0 (main) Level 1 0 1 Level 2 0 0 Level 3 (= interrupt disable*) 1 1
Low
High
10
These two bits are set/cleared by hardware when entering in interrupt. The loaded value is given by the corresponding bits in the interrupt software pri­ority registers (ISPRx).
They can be also set/cleared by software with the RIM, SIM, HALT, WFI, IRET and PUSH/POP in­structions (see “Interrupt Dedicated Instruction Set” table).
*Note: TLI, TRAP and RESET events can interrupt a level 3 program.
Read/Write (bit 7:4 of ISPR3 are read only) Reset Value: 1111 1111 (FFh)
70
ISPR0 I1_3 I0_3 I1_2 I0_2 I1_1 I0_1 I1_0 I0_0
ISPR1 I1_7 I0_7 I1_6 I0_6 I1_5 I0_5 I1_4 I0_4
ISPR2 I1_11 I0_11 I1_10 I0_10 I1_9 I0_9 I1_8 I0_8
ISPR3 1 1 1 1 I1_13 I0_13 I1_12 I0_12
These four registers contain the interrupt software priority of each interrupt vector.
– Each interrupt vector (except RESET and TRAP)
has corresponding bits in these registers where its own software priority is stored. This corre­spondence is shown in the following table.
Vector address ISPRx bits
FFFBh-FFFAh I1_0 and I0_0 bits*
FFF9h-FFF8h I1_1 and I0_1 bits
... ...
FFE1h-FFE0h I1_13 and I0_13 bits
– Each I1_x and I0_x bit value in the ISPRx regis-
ters has the same meaning as the I1 and I0 bits in the CC register.
– Level 0 can not be written (I1_x=1, I0_x=0). In
this case, the previously stored value is kept. (ex­ample: previous=CFh, write=64h, result=44h)
The RESET, TRAP and TLI vectors have no soft­ware priorities. When one is serviced, the I1 and I0 bits of the CC register are both set.
*Note: Bits in the ISPRx registers which corre­spond to the TLI can be read and written but they are not significant in the interrupt process man­agement.
Caution: If the I1_x and I0_x bits are modified while the interrupt x is executed the following be­haviour has to be considered: If the interrupt x is still pending (new interrupt or flag not cleared) and the new software priority is higher than the previ­ous one, the interrupt x is re-entered. Otherwise, the software priority stays unchanged up to the next interrupt request (after the IRET of the inter­rupt x).
Doc ID 6996 Rev 5
27/139
ST7262xxx
INTERRUPTS (Cont’d) INTERRUPT REGISTER 1 (ITRFRE1)
Address: 0008h - Read/Write Reset Value: 0000 0000 (00h)
70
IT8E IT7E IT6E IT5E IT4E IT3E IT2E IT1E
Bit 7:0 = ITiE Interrupt Enable 0: I/O pin free for general purpose I/O 1: ITi external interrupt enabled.
Note: The corresponding interrupt is generated when:
– a rising edge occurs on the IT5/IT6 pins – a falling edge occurs on the IT1, 2, 3, 4, 7 and 8
pins
INTERRUPT REGISTER 2 (ITRFRE2)
Address: 0039h - Read/Write Reset Value: 0000 0000 (00h)
Bit 5:4 = CTL[1:0] IT[10:9]1nterrupt Sensitivity These bits are set and cleared by software. They
are used to configure the edge and level sensitivity of the IT10 and IT9 external interrupt pins (this means that both must have the same sensitivity).
CTL1 CTL0 IT[10:9] Sensitivity
0 0 Falling edge and low level 0 1 Rising edge only 1 0 Falling edge only 1 1 Rising and falling edge
Bit 3:0 = ITiE Interrupt Enable 0: I/O pin free for general purpose I/O 1: ITi external interrupt enabled.
70
CTL3 CTL2 CTL1 CTL0 IT12E IT11E IT10E IT9E
Bit 7:6 = CTL[3:2] IT[12:11] Interrupt Sensitivity These bits are set and cleared by software. They
are used to configure the edge and level sensitivity of the IT12 and IT11 external interrupt pins (this means that both must have the same sensitivity).
CTL3 CTL2 IT[12:11] Sensitivity
0 0 Falling edge and low level 0 1 Rising edge only 1 0 Falling edge only 1 1 Rising and falling edge
28/139
Doc ID 6996 Rev 5
INTERRUPTS (Cont’d)
Table 6. Interrupt Mapping
ST7262xxx
0 ICP FLASH Start programming NMI interrupt Yes FFFAh-FFFBh 1 USB USB End Suspend interrupt USBISTR Yes FFF8h-FFF9h 2 3 Port B external interrupts IT[8:5] ITRFRE1 Yes FFF4h-FFF5h 4 Port C external interrupts IT[12:9] ITRFRE2 Yes FFF2h-FFF3h 5 TBU Timebase Unit interrupt TBUCSR No FFF0h-FFF1h 6 ART ART/PWM Timer interrupt ICCSR Yes FFEEh-FFEFh 7 SPI SPI interrupt vector SPISR Yes FFECh-FFEDh 8 SCI SCI interrupt vector SCISR No FFEAh-FFEBh 9 USB USB interrupt vector USBISTR No FFE8h-FFE9h
10 ADC A/D End of conversion interrupt ADCCSR No FFE6h-FFE7h
Source
Block
I/O Ports
Description
Reset TRAP software interrupt No FFFCh-FFFDh
Port A external interrupts IT[4:1] ITRFRE1 Yes FFF6h-FFF7h
Reserved area FFE0h-FFE5h
Register
Label
Priority
Order
Highest
Priority
Lowest Priority
Exit from
HALT
Yes FFFEh-FFFFh
Address
Vector
Table 7. Nested Interrupts Register Map and Reset Values
Address
(Hex.)
Register
Label
76543210
0032h
0033h
0034h
0035h
Ext. Interrupt Port B Ext. Interrupt Port A USB END SUSP Not Used
ISPR0
Reset Value
ISPR1
Reset Value
ISPR2
Reset Value
ISPR3
Reset Value1111
I1_3
1
I1_7
1
Not Used ADC USB SCI
I1_11
1
I0_3
1
SPI ART TBU Ext. Interrupt Port C
I0_7
1
I0_11
1
I1_2
1
I1_6
1
I1_10
1
I0_2
1
I0_6
1
I0_10
1
I1_13
I1_1
1
I1_5
1
I1_9
1
Not Used Not Used
1
I0_1
111
I0_5
1
I0_9
1
I0_13
1
I1_4
1
I1_8
1
I1_12
1
I0_4
1
I0_8
1
I0_12
1
Doc ID 6996 Rev 5
29/139
ST7262xxx
WFI INSTRUCTION
RESET
INTERRUPT
Y
N
N
Y
CPU CLOCK
OSCILLATOR PERIPH. CLOCK
I-BIT
ON
ON
CLEARED
OFF
CPU CLOCK
OSCILLATOR PERIPH. CLOCK
I-BIT
ON
ON
SET
ON
FETCH RESET VECTOR
OR SERVICE INTERRUPT
514 CPU CLOCK
CYCLES DELAY
IF RESET
Note: Before servicing an interrupt, the CC register is pushed on the stack. The I-Bit is set during the inter­rupt routine and cleared when the CC register is popped.

8 POWER SAVING MODES

8.1 INTRODUCTION

There are three Power Saving modes. Slow Mode is selected by setting the SMS bits in the Miscella­neous register. Wait and Halt modes may be en­tered using the WFI and HALT instructions.
After a RESET the normal operating mode is se­lected by default (RUN mode). This mode drives the device (CPU and embedded peripherals) by means of a master clock which is based on the main oscillator frequency divided by 3 and multi­plied by 2 (f
CPU
).
From Run mode, the different power saving modes may be selected by setting the relevant register bits or by calling the specific ST7 software instruction whose action depends on the oscillator status.
8.1.1 Slow Mode
In Slow mode, the oscillator frequency can be di­vided by a value defined in the Miscellaneous Register. The CPU and peripherals are clocked at this lower frequency. Slow mode is used to reduce power consumption, and enables the user to adapt clock frequency to available supply voltage.
Figure 24. WAIT Mode Flow Chart

8.2 WAIT MODE

WAIT mode places the MCU in a low power con­sumption mode by stopping the CPU. This power saving mode is selected by calling the “WFI” ST7 software instruction. All peripherals remain active. During WAIT mode, the I bit of the CC register is forced to 0, to enable all interrupts. All other registers and memory re­main unchanged. The MCU remains in WAIT mode until an interrupt or Reset occurs, whereup­on the Program Counter branches to the starting address of the interrupt or Reset service routine. The MCU will remain in WAIT mode until a Reset or an Interrupt occurs, causing it to wake up.
Refer to Figure 24.
30/139
Doc ID 6996 Rev 5
ST7262xxx
N
N
EXTERNAL
INTERRUPT*
RESET
HALT INSTRUCTION
514 CPU CLOCK
FETCH RESET VECTOR
OR SERVICE INTERRUPT
CYCLES DELAY
CPU CLOCK
OSCILLATOR PERIPH. CLOCK
I-BIT
ON
ON
SET
ON
CPU CLOCK
OSCILLATOR PERIPH. CLOCK
I-BIT
OFF
OFF
CLEARED
OFF
Y
Y
Note: Before servicing an interrupt, the CC register is pushed on the stack. The I-Bit is set during the inter­rupt routine and cleared when the CC register is popped.
POWER SAVING MODES (Cont’d)

8.3 HALT MODE

The HALT mode is the MCU lowest power con­sumption mode. The HALT mode is entered by ex­ecuting the HALT instruction. The internal oscilla­tor is then turned off, causing all internal process­ing to be stopped, including the operation of the on-chip peripherals.
When entering HALT mode, the I bit in the Condi­tion Code Register is cleared. Thus, any of the ex­ternal interrupts (ITi or USB end suspend mode), are allowed and if an interrupt occurs, the CPU clock becomes active.
The MCU can exit HALT mode on reception of ei­ther an external interrupt on ITi, an end suspend mode interrupt coming from USB peripheral, or a reset. The oscillator is then turned on and a stabi­lization time is provided before releasing CPU op­eration. The stabilization time is 514 CPU clock cy­cles. After the start up delay, the CPU continues opera­tion by servicing the interrupt which wakes it up or by fetching the reset vector if a reset wakes it up.
Figure 25. HALT Mode Flow Chart
Doc ID 6996 Rev 5
31/139
ST7262xxx

9 I/O PORTS

9.1 INTRODUCTION

The I/O ports offer different functional modes: transfer of data through digital inputs and outputs
and for specific pins: – Analog signal input (ADC) – Alternate signal input/output for the on-chip pe-
ripherals. – External interrupt generation An I/O port is composed of up to 8 pins. Each pin
can be programmed independently as digital input or digital output.

9.2 FUNCTIONAL DESCRIPTION

Each port is associated with 2 main registers: – Data Register (DR) – Data Direction Register (DDR) Each I/O pin may be programmed using the corre-
sponding register bits in DDR register: bit x corre­sponding to pin x of the port. The same corre­spondence is used for the DR register.
Table 8. I/O Pin Functions
DDR MODE
0 Input 1 Output
9.2.1 Input Modes
The input configuration is selected by clearing the corresponding DDR register bit.
In this case, reading the DR register returns the digital value applied to the external I/O pin.
Notes:
1. All the inputs are triggered by a Schmitt trigger.
2. When switching from input mode to output
mode, the DR register should be written first to output the correct value as soon as the port is configured as an output.
Interrupt function
When an external interrupt function of an I/O pin, is enabled using the ITFRE registers, an event on this I/O can generate an external Interrupt request to the CPU. The interrupt sensitivity is programma-
ble, the options are given in the description of the ITRFRE interrupt registers.
Each pin can independently generate an Interrupt request.
Each external interrupt vector is linked to a dedi­cated group of I/O port pins (see Interrupts sec­tion). If more than one input pin is selected simul­taneously as interrupt source, this is logically AN­Ded and inverted. For this reason, if an event oc­curs on one of the interrupt pins, it masks the other ones.
9.2.2 Output Mode
The pin is configured in output mode by setting the corresponding DDR register bit (see Table 7).
In this mode, writing “0” or “1” to the DR register applies this digital value to the I/O pin through the latch. Then reading the DR register returns the previously stored value.
Note: In this mode, the interrupt function is disa­bled.
9.2.3 Alternate Functions Digital Alternate Functions
When an on-chip peripheral is configured to use a pin, the alternate function is automatically select­ed. This alternate function takes priority over standard I/O programming. When the signal is coming from an on-chip peripheral, the I/O pin is automatically configured in output mode (push-pull or open drain according to the peripheral).
When the signal is going to an on-chip peripheral, the I/O pin has to be configured in input mode. In this case, the pin state is also digitally readable by addressing the DR register.
Notes:
1. Input pull-up configuration can cause an unex­pected value at the alternate peripheral input.
2. When the on-chip peripheral uses a pin as input and output, this pin must be configured as an input (DDR = 0).
Warning: Alternate functions of peripherals must must not be activated when the external interrupts are enabled on the same pin, in order to avoid generating spurious interrupts.
32/139
Doc ID 6996 Rev 5
I/O PORTS (Cont’d) Analog Alternate Functions
When the pin is used as an ADC input, the I/O must be configured as input. The analog multiplex­er (controlled by the ADC registers) switches the analog voltage present on the selected pin to the common analog rail which is connected to the ADC input.
It is recommended not to change the voltage level or loading on any port pin while conversion is in progress. Furthermore it is recommended not to
ST7262xxx
have clocking pins located close to a selected an­alog pin.
Warning: The analog input voltage level must be within the limits stated in the Absolute Maximum Ratings.
9.2.4 I/O Port Implementation
The hardware implementation on each I/O port de­pends on the settings in the DDR register and spe­cific features of the I/O port such as ADC Input or true open drain.
Doc ID 6996 Rev 5
33/139
ST7262xxx
DR
DDR
LATCH
LATCH
DR SEL
DDR SEL
V
DD
PA D
ANALOG SWITCH
ANALOG ENABLE
(ADC)
ALTERNATE ENABLE
ALTERNATE ENABLE
DIGITAL ENABLE
ALTERNATE ENABLE
ALTERNATE
ALTERNATE INPUT
OUTPUT
P-BUFFER
N-BUFFER
1
0
1
0
V
SS
DATA BUS
COMMON ANALOG RAIL
V
DD
DIODES
I/O PORTS (Cont’d)
9.2.5 Port A
Table 9. Port A Description
PORT A
Input* Output Signal Condition
I/O Alternate Function
USBOE USBOE = 1 (MISC)
PA0 floating push-pull
IT1 Schmitt triggered input IT1E = 1 (ITRFRE1) AIN0 (ADC) CS[2:0] = 000 (ADCCSR)
PA1 floating push-pull
PA2 floating push-pull
PA3 floating push-pull
IT2 Schmitt triggered input IT2E = 1 (ITRFRE1) AIN1 (ADC) CS[2:0] = 001 (ADCCSR) IT3 Schmitt triggered input IT3E = 1 (ITRFRE1) AIN2 (ADC) CS[2:0] = 010 (ADCCSR) IT4 Schmitt triggered input IT4E = 1 (ITRFRE1)
AIN3 (ADC) CS[2:0] = 011 (ADCCSR) PA4 floating push-pull AIN4 (ADC) CS[2:0] = 100 (ADCCSR) PA5 floating push-pull AIN5 (ADC) CS[2:0] = 101 (ADCCSR) PA6 floating push-pull AIN6 (ADC) CS[2:0] = 110 (ADCCSR) PA7 floating push-pull AIN7 (ADC) CS[2:0] = 111 (ADCCSR) *Reset State
Figure 26. PA[7:0] Configuration
34/139
Doc ID 6996 Rev 5
I/O PORTS (Cont’d)
DR
DDR
LATCH
LATCH
DR SEL
DDR SEL
V
DD
PA D
ALTERNATE ENABLE
ALTERNATE ENABLE
ALTERNATE ENABLE
ALTERNATE
ALTERNATE INPUT
OUTPUT
P-BUFFER
N-BUFFER
1
0
1
0
CMOS SCHMITT TRIGGER
V
SS
V
DD
DIODES
DATA BUS
PULL-UP*
* PULL-UP ON PORT C [7:2] ONLY
9.2.6 Port B
Table 10. Port B Description
ST7262xxx
PORT B
I/O Alternate Function
Input* Output Signal Condition
PB0 floating push-pull (high sink) MCO (Main Clock Output) MCO = 1 (MISCR)
PB1 floating push-pull (high sink) RDI SCI enabled
PB2 floating push-pull (high sink) TDO TE = 1 (SCICR2)
PB3 floating push-pull (high sink) ARTCLK EXCL = 1 (ARTCSR)
ARTIC1 ART Timer enabled
PB4 floating push-pull (high sink)
IT5 Schmitt triggered input IT5E = 1 (ITRFRE1)
ARTIC2 ART Timer enabled
PB5 floating push-pull (high sink)
IT6 Schmitt triggered input IT6E = 1 (ITRFRE1)
PWM1 OE0 = 1 (PWMCR)
PB6 floating push-pull (high sink)
IT7 Schmitt triggered input IT7E = 1 (ITRFRE1)
PWM2 OE1 = 1 (PWMCR)
PB7 floating push-pull (high sink)
IT8 Schmitt triggered input IT8E = 1 (ITRFRE1)
*Reset State
Figure 27. Port B and Port C [7:2] Configuration
Doc ID 6996 Rev 5
35/139
ST7262xxx
DR
DDR
LATCH
LATCH
DR SEL
DDR SEL
PA D
ALTERNATE ENABLE
ALTERNATE ENABLE
ALTERNATE OUTPUT
N-BUFFER
1
0
1
0
CMOS SCHMITT TRIGGER
V
SS
DIODES
DATA BUS
I/O PORTS (Cont’d)
9.2.7 Port C
Table 11. Port C Description
PORT C
I/O Alternate Function
Input* Output Signal Condition
PC0 floating true open drain
PC1 floating true open drain
PC2 with pull-up push-pull IT9 Schmitt triggered input IT9E = 1 (ITRFRE2)
SCK SPI enabled
PC3 with pull-up push-pull
IT10 Schmitt triggered input IT10E = 1 (ITRFRE2)
SPI enabled
SS
PC4 with pull-up push-pull
IT11 Schmitt triggered input IT11E = 1 (ITRFRE2)
MISO SPI enabled
PC5 with pull-up push-pull
IT12 Schmitt triggered input IT12E = 1 (ITRFRE2)
PC6 with pull-up push-pull MOSI SPI enabled
PC7 with pull-up push-pull
*Reset State
Figure 28. Port C[1:0] Configuration
36/139
Doc ID 6996 Rev 5
I/O PORTS (Cont’d)
DR
DDR
LATCH
LATCH
DR SEL
DDR SEL
V
DD
PA D
ALTERNATE ENABLE
ALTERNATE ENABLE
ALTERNATE ENABLE
ALTERNATE
ALTERNATE INPUT
PULL-UP
OUTPUT
P-BUFFER
N-BUFFER
1
0
1
0
CMOS SCHMITT TRIGGER
V
SS
V
DD
DATA BUS
DIODES
9.2.8 Port D
Table 12. Port D Description
ST7262xxx
PORT D
I/O Alternate Function
Input* Output Signal Condition
PD0 with pull-up push-pull
PD1 with pull-up push-pull
PD2 with pull-up push-pull
PD3 with pull-up push-pull
PD4 with pull-up push-pull
PD5 with pull-up push-pull
PD6 with pull-up push-pull
*Reset State
Figure 29. Port D Configuration
Doc ID 6996 Rev 5
37/139
ST7262xxx
I/O PORTS (Cont’d)
9.2.9 Register Description
DATA REGISTER (DR)
Port x Data Register PxDR with x = A, B, C or D.
Read/Write Reset Value: 0000 0000 (00h)
70
D7 D6 D5 D4 D3 D2 D1 D0
DATA DIRECTION REGISTER (DDR)
Port x Data Direction Register PxDDR with x = A, B, C or D.
Read/Write Reset Value: 0000 0000 (00h)
70
DD7 DD6 DD5 DD4 DD3 DD2 DD1 DD0
Bits 7:0 = DD[7:0] Data direction register 8 bits.
Bits 7:0 = D[7:0] Data register 8 bits. The DR register has a specific behaviour accord-
ing to the selected input/output configuration. Writ­ing the DR register is always taken into account even if the pin is configured as an input; this allows
The DDR register gives the input/output direction configuration of the pins. Each bit is set and cleared by software.
0: Input mode 1: Output mode
to always have the expected level on the pin when toggling to output mode. Reading the DR register returns either the DR register latch content (pin configured as output) or the digital value applied to the I/O pin (pin configured as input).
38/139
Doc ID 6996 Rev 5
I/O PORTS (Cont’d)
Table 13. I/O Port Register Map and Reset Values
ST7262xxx
Address
(Hex.)
Reset Value
of all I/O port registers
0000h PADR
0001h PADDR
0002h PBDR
0003h PBDDR
0004h PCDR
0005h PCDDR
0006h PDDR
0007h PDDDR
Register
Label
76543210
00000000
MSB LSB
MSB LSB
MSB LSB
MSB LSB
Doc ID 6996 Rev 5
39/139
ST7262xxx

9.3 MISCELLANEOUS REGISTER

MISCELLANEOUS REGISTER
Read Write Reset Value - 0000 0000 (00h)
Bit 1 = USBOE USB Output Enable 0: PA0 port free for general purpose I/O 1: USBOE alternate function enabled. The USB
output enable signal is output on the PA0 port
70
----SMS1SMS0
US-
BOE
MCO
(at “1” when the ST7 USB is transmitting data).
Bit 0 = MCO Main Clock Out 0: PB0 port free for general purpose I/O
Bits 7:4 = Reserved
1: MCO alternate function enabled (f
PB0 I/O port)
Bits 3:2 = SMS[1:0] Slow Mode Selection These bits select the Slow Mode frequency (de­pending on the oscillator frequency configured by option byte).
OSC12/6 SMS1 SMS0
00 4
f
OSC
f
OSC
= 6 MHz.
= 12 MHz.
01 2 10 1 11 0.5 00 8 01 4 10 2 11 1
Slow Mode Frequency (MHz.)
output on
CPU
40/139
Doc ID 6996 Rev 5

10 ON-CHIP PERIPHERALS

RESET
WDGA
7-BIT DOWNCOUNTER
f
CPU
T6
T0
CLOCK DIVIDER
WATCHDOG CONTROL REGISTER (CR)
÷65536
T1
T2
T3
T4
T5

10.1 WATCHDOG TIMER (WDG)

ST7262xxx
10.1.1 Introduction
The Watchdog timer is used to detect the occur­rence of a software fault, usually generated by ex­ternal interference or by unforeseen logical condi­tions, which causes the application program to abandon its normal sequence. The Watchdog cir­cuit generates an MCU reset on expiry of a pro­grammed time period, unless the program refresh­es the counter’s contents before the T6 bit be­comes cleared.
10.1.2 Main Features
Programmable free-running downcounter (64
increments of 65536 CPU cycles)
Programmable reset
Reset (if watchdog activated) when the T6 bit
reaches zero
Hardware Watchdog selectable by option byte
10.1.3 Functional Description
The counter value stored in the CR register (bits T[6:0]), is decremented every 65,536 machine cy­cles, and the length of the timeout period can be programmed by the user in 64 increments.
Figure 30. Watchdog Block Diagram
If the watchdog is activated (the WDGA bit is set) and when the 7-bit timer (bits T[6:0]) rolls over from 40h to 3Fh (T6 becomes cleared), it initiates a reset cycle by driving low the reset pin for 30µs.
The application program must write in the CR reg­ister at regular intervals during normal operation to prevent an MCU reset. This downcounter is free­running: it counts down even if the watchdog is di­abled The value to be stored in the CR register must be between FFh and C0h (see Table 14):
– The WDGA bit is set (watchdog enabled) – The T6 bit is set to prevent generating an imme-
diate reset
– The T[5:0] bits contain the number of increments
which represents the time delay before the watchdog produces a reset.
Table 14.Watchdog Timing (f
CR Register
initial value
Max FFh 524.288
Min C0h 8.192
= 8 MHz)
CPU
WDG timeout period
(ms)
Doc ID 6996 Rev 5
41/139
ST7262xxx
WATCHDOG TIMER (Cont’d)
10.1.4 Software Watchdog Option
If Software Watchdog is selected by option byte, the watchdog is disabled following a reset. Once activated it cannot be disabled, except by a reset.
The T6 bit can be used to generate a software re­set (the WDGA bit is set and the T6 bit is cleared).
10.1.5 Hardware Watchdog Option
If Hardware Watchdog is selected by option byte, the watchdog is always active and the WDGA bit in the CR is not used.
– The opcode for the HALT instruction is 0x8E. To
avoid an unexpected HALT instruction due to a program counter failure, it is advised to clear all occurrences of the data value 0x8E from memo­ry. For example, avoid defining a constant in ROM with the value 0x8E.
– As the HALT instruction clears the I bit in the CC
register to allow interrupts, the user may choose to clear all pending interrupt bits before execut­ing the HALT instruction. This avoids entering other peripheral interrupt routines after executing the external interrupt routine corresponding to the wake-up event (reset or external interrupt).
10.1.6 Low Power Modes WAIT Instruction
No effect on Watchdog.
HALT Instruction
Halt mode can be used when the watchdog is en­abled. When the oscillator is stopped, the WDG stops counting and is no longer able to generate a reset until the microcontroller receives an external interrupt or a reset.
If an external interrupt is received, the WDG re­starts counting after 514 CPU clocks. In the case of the Software Watchdog option, if a reset is gen­erated, the WDG is disabled (reset state).
Recommendations
– Make sure that an external event is available to
wake up the microcontroller from Halt mode.
– Before executing the HALT instruction, refresh
the WDG counter, to avoid an unexpected WDG reset immediately after waking up the microcon­troller.
– When using an external interrupt to wake up the
microcontroller, reinitialize the corresponding I/O as Input before executing the HALT instruction. The main reason for this is that the I/O may be wrongly configured due to external interference or by an unforeseen logical condition.
10.1.7 Interrupts
None.
10.1.8 Register Desc4ription CONTROL REGISTER (CR)
Read/Write Reset Value: 0111 1111 (7Fh)
70
WDGA T6 T5 T4 T3 T2 T1 T0
Bit 7 = WDGA Activation bit. This bit is set by software and only cleared by hardware after a reset. When WDGA = 1, the watchdog can generate a reset. 0: Watchdog disabled 1: Watchdog enabled
Note: This bit is not used if the hardware watch­dog option is enabled by option byte.
Bits 6:0 = T[6:0] 7-bit timer (MSB to LSB). These bits contain the decremented value. A reset is produced when it rolls over from 40h to 3Fh (T6 becomes cleared).
Table 15. Watchdog Timer Register Map and Reset Values
Address
(Hex.)
0Dh
42/139
Register
Label
WDGCR
Reset Value
76543210
WDGA
0
T6
T5
1
1
Doc ID 6996 Rev 5
T4
1
T3
T2
1
1
T1
T0
1
1

10.2 PWM AUTO-RELOAD TIMER (ART)

OVF INTERRUPT
EXCL CC2 CC1 CC0 TCE FCRL OIE OVF
ARTCSR
f
INPUT
PWMx
PORT
FUNCTION
ALTERNATE
OCRx
COMPARE
REGISTER
PROGRAMMABLE
PRESCALER
8-BIT COUNTER
(ARTCAR REGISTER)
ARTARR
REGISTER
ARTICRx
REGISTER
LOAD
OPx
POLARITY CONTROL
OEx
PWMCR
MUX
f
CPU
PWMDCRx REGISTER
LOAD
f
COUNTER
ARTCLK
f
EXT
ARTICx
ICFxICSx
ARTICCSR
LOAD
ICx INTERRUPT
ICIEx
INPUT CAPTURE
CONTROL
10.2.1 Introduction
The Pulse Width Modulated Auto-Reload Timer on-chip peripheral consists of an 8-bit auto reload counter with compare/capture capabilities and of a 7-bit prescaler clock source.
These resources allow five possible operating modes:
– Generation of up to 2 independent PWM signals – Output compare and Time base interrupt
Figure 31. PWM Auto-Reload Timer Block Diagram
ST7262xxx
– Up to two input capture functions – External event detector – Up to two external interrupt sources The three first modes can be used together with a
single counter frequency. The timer can be used to wake up the MCU from
WAIT and HALT modes.
Doc ID 6996 Rev 5
43/139
ST7262xxx
COUNTER
FDh FEh FFh FDh FEh FFh FDh FEh
ARTARR=FDh
f
COUNTER
OCRx
PWMDCRx
FDh
FEh
FDh
FEh
FFh
PWMx
PWM AUTO-RELOAD TIMER (Cont’d)
10.2.2 Functional Description
Counter
The free running 8-bit counter is fed by the output of the prescaler, and is incremented on every ris­ing edge of the clock signal.
It is possible to read or write the contents of the counter on the fly by reading or writing the Counter Access register (ARTCAR).
When a counter overflow occurs, the counter is automatically reloaded with the contents of the ARTARR register (the prescaler is not affected).
Counter clock and prescaler
The counter clock frequency is given by:
f
COUNTER
= f
INPUT
The timer counter’s input clock (f
/ 2
CC[2:0]
INPUT
) feeds the 7-bit programmable prescaler, which selects one of the 8 available taps of the prescaler, as defined by CC[2:0] bits in the Control/Status Register (ARTCSR). Thus the division factor of the prescal­er can be set to 2
This f
INPUT
n
(where n = 0, 1,..7).
frequency source is selected through the EXCL bit of the ARTCSR register and can be either the f
or an external input frequency f
CPU
EXT
The clock input to the counter is enabled by the TCE (Timer Counter Enable) bit in the ARTCSR register. When TCE is reset, the counter is stopped and the prescaler and counter contents are frozen. When TCE is set, the counter runs at the rate of the selected clock source.
Counter and Prescaler Initialization
After RESET, the counter and the prescaler are cleared and f
INPUT
= f
CPU
. The counter can be initialized by: – Writing to the ARTARR register and then setting
the FCRL (Force Counter Re-Load) and the TCE (Timer Counter Enable) bits in the ARTCSR reg-
ister. – Writing to the ARTCAR counter access register, In both cases the 7-bit prescaler is also cleared,
whereupon counting will start from a known value. Direct access to the prescaler is not possible.
Output compare control
The timer compare function is based on four differ­ent comparisons with the counter (one for each PWMx output). Each comparison is made be­tween the counter value and an output compare register (OCRx) value. This OCRx register can not be accessed directly, it is loaded from the duty cy­cle register (PWMDCRx) at each overflow of the counter.
.
This double buffering method avoids glitch gener­ation when changing the duty cycle on the fly.
Figure 32. Output compare control
44/139
Doc ID 6996 Rev 5
PWM AUTO-RELOAD TIMER (Cont’d)
DUTY CYCLE
REGISTER
AUTO-RELOAD
REGISTER
PWMx OUTPUT
t
255
000
WITH OEx=1 AND OPx=0
(ARTARR)
(PWMDCRx)
WITH OEx=1 AND OPx=1
COUNTER
ST7262xxx
Independent PWM signal generation
This mode allows up to two Pulse Width Modulat­ed signals to be generated on the PWMx output pins with minimum core processing overhead. This function is stopped during HALT mode.
Each PWMx output signal can be selected inde­pendently using the corresponding OEx bit in the PWM Control register (PWMCR). When this bit is set, the corresponding I/O pin is configured as out­put push-pull alternate function.
The PWM signals all have the same frequency which is controlled by the counter period and the ARTARR register value.
f
PWM
= f
COUNTER
/ (256 - ARTARR)
When a counter overflow occurs, the PWMx pin level is changed depending on the corresponding OPx (output polarity) bit in the PWMCR register.
Figure 33. PWM Auto-reload Timer Function
When the counter reaches the value contained in one of the output compare register (OCRx) the corresponding PWMx pin level is restored.
It should be noted that the reload values will also affect the value and the resolution of the duty cycle of the PWM output signal. To obtain a signal on a PWMx pin, the contents of the OCRx register must be greater than the contents of the ARTARR reg­ister.
The maximum available resolution for the PWMx duty cycle is:
Resolution = 1 / (256 - ARTARR)
Note: To get the maximum resolution (1/256), the ARTARR register must be 0. With this maximum resolution, 0% and 100% can be obtained by changing the polarity.
Doc ID 6996 Rev 5
45/139
ST7262xxx
COUNTER
PWMx OUTPUT
t
WITH OEx=1
AND OPx=0
FDh FEh FFh FDh FEh FFh FDh FEh
OCRx=FCh
OCRx=FDh
OCRx=FEh
OCRx=FFh
ARTARR=FDh
f
COUNTER
Figure 34. PWM Signal from 0% to 100% Duty Cycle
46/139
Doc ID 6996 Rev 5
PWM AUTO-RELOAD TIMER (Cont’d)
COUNTER
t
FDh FEh FFh FDh
OVF
ARTCSR READ
INTERRUPT
ARTARR=FDh
f
EXT=fCOUNTER
FEh FFh FDh
IF OIE=1
INTERRUPT
IF OIE=1
ARTCSR READ
ST7262xxx
Output compare and Time base interrupt
On overflow, the OVF flag of the ARTCSR register is set and an overflow interrupt request is generat­ed if the overflow interrupt enable bit, OIE, in the ARTCSR register, is set. The OVF flag must be re­set by the user software. This interrupt can be
External clock and event detector mode
Using the f auto-reload timer can be used as an external clock event detector. In this mode, the ARTARR register is used to select the n be counted before setting the OVF flag.
used as a time base in the application.
When entering HALT mode while f all the timer control registers are frozen but the counter continues to increment. If the OIE bit is set, the next overflow of the counter will generate an interrupt which wakes up the MCU.
Caution: If HALT mode is used in the application, prior to executing the HALT instruction, the coun­ter must be disabled by clearing the TCE bit in the ARTCSR register to avoid spurious counter incre­ments.
Figure 35. External Event Detector Example (3 counts)
external prescaler input clock, the
EXT
number of events to
EVENT
n
= 256 - ARTARR
EVENT
is selected,
EXT
Doc ID 6996 Rev 5
47/139
ST7262xxx
ARTICx PIN
CFx FLAG
t
f
COUNTER
INTERRUPT
COUNTER
t
01h
f
COUNTER
xxh
02h
03h 04h 05h 06h 07h
04h
ARTICx PIN
CFx FLAG
ICRx REGISTER
INTERRUPT
PWM AUTO-RELOAD TIMER (Cont’d)
Input capture function
This mode allows the measurement of external signal pulse widths through ICRx registers.
Each input capture can generate an interrupt inde­pendently on a selected input signal transition. This event is flagged by a set of the corresponding CFx bits of the Input Capture Control/Status regis­ter (ICCSR).
These input capture interrupts are enabled through the CIEx bits of the ICCSR register.
The active transition (falling or rising edge) is soft­ware programmable through the CSx bits of the ICCSR register.
The read only input capture registers (ICRx) are used to latch the auto-reload counter value when a transition is detected on the ARTICx pin (CFx bit set in ICCSR register). After fetching the interrupt vector, the CFx flags can be read to identify the in­terrupt source.
Note: After a capture detection, data transfer in the ICRx register is inhibited until the ARTICCSR register is read (clearing the CFx bit). The timer interrupt remains pending while the CFx flag is set when the interrupt is enabled (CIEx bit set). This means, the ARTICCSR register has to be read at each capture event to clear the CFx flag.
During HALT mode, input capture is inhibited (the ICRx is never re-loaded) and only the external in­terrupt capability can be used.
External interrupt capability
This mode allows the Input capture capabilities to be used as external interrupt sources.
The edge sensitivity of the external interrupts is programmable (CSx bit of ICCSR register) and they are independently enabled through CIEx bits of the ICCSR register. After fetching the interrupt vector, the CFx flags can be read to identify the in­terrupt source.
The interrupts are synchronized on the counter clock rising edge (Figure 36).
During HALT mode, the external interrupts can still be used to wake up the micro (if CIEx bit is set).
Figure 36. ART External Interrupt
The timing resolution is given by auto-reload coun­ter cycle time (1/f
COUNTER
).
Figure 37. Input Capture Timing Diagram
48/139
Doc ID 6996 Rev 5
PWM AUTO-RELOAD TIMER (Cont’d)
10.2.3 Register Description
ST7262xxx
CONTROL / STATUS REGISTER (CSR)
Read/Write Reset Value: 0000 0000 (00h)
70
EXCL CC2 CC1 CC0 TCE FCRL OIE OVF
Bit 7 = EXCL
External Clock
This bit is set and cleared by software. It selects the input clock for the 7-bit prescaler. 0: CPU clock. 1: External clock.
COUNTER ACCESS REGISTER (CAR)
Read/Write Reset Value: 0000 0000 (00h)
70
CA7CA6CA5CA4CA3CA2CA1CA0
Bit 7:0 = CA[7:0] Counter Access Data These bits can be set and cleared either by hard-
ware or by software. The CAR register is used to read or write the auto-reload counter “on the fly” (while it is counting).
Bit 6:4 = CC[2:0] Counter Clock Control These bits are set and cleared by software. They determine the prescaler division ratio from f
f
COUNTER
f
INPUT
f
INPUT
f
INPUT
f
INPUT
f
INPUT
f
INPUT
f
INPUT
f
INPUT
/ 16 / 32 / 64
/ 128
/ 2 / 4 / 8
With f
=8 MHz CC2 CC1 CC0
INPUT
8 MHz 4 MHz 2 MHz
1 MHz 500 KHz 250 KHz 125 KHz
62.5 KHz
0 0 0 0 1 1 1 1
0 0 1 1 0 0 1 1
Bit 3 = TCE Timer Counter Enable This bit is set and cleared by software. It puts the timer in the lowest power consumption mode. 0: Counter stopped (prescaler and counter frozen). 1: Counter running.
Bit 2 = FCRL
Force Counter Re-Load
This bit is write-only and any attempt to read it will yield a logical zero. When set, it causes the contents of ARR register to be loaded into the counter, and the content of the prescaler register to be cleared in
INPUT
0 1 0 1 0 1 0 1
.
AUTO-RELOAD REGISTER (ARR)
Read/Write Reset Value: 0000 0000 (00h)
70
AR7AR6AR5AR4AR3AR2AR1AR0
Bit 7:0 = AR[7:0]
Counter Auto-Reload Data
These bits are set and cleared by software. They are used to hold the auto-reload value which is au­tomatically loaded in the counter when an overflow occurs. At the same time, the PWM output levels are changed according to the corresponding OPx bit in the PWMCR register.
This register has two PWM management func­tions:
– Adjusting the PWM frequency – Setting the PWM duty cycle resolution
order to initialize the timer before starting to count. Bit 1 = OIE
Overflow Interrupt Enable
PWM Frequency vs. Resolution:
This bit is set and cleared by software. It allows to enable/disable the interrupt which is generated when the OVF bit is set. 0: Overflow Interrupt disable. 1: Overflow Interrupt enable.
Bit 0 = OVF
Overflow Flag
This bit is set by hardware and cleared by software reading the CSR register. It indicates the transition of the counter from FFh to the ARR value
.
ARR value Resolution
0 8-bit ~0.244-KHz 31.25-KHz
[ 0..127 ] > 7-bit ~0.244-KHz 62.5-KHz [ 128..191 ] > 6-bit ~0.488-KHz 125-KHz [ 192..223 ] > 5-bit ~0.977-KHz 250-KHz [ 224..239 ] > 4-bit ~1.953-KHz 500-KHz
0: New transition not yet reached 1: Transition reached
f
PWM
Min Max
Doc ID 6996 Rev 5
49/139
ST7262xxx
PWM AUTO-RELOAD TIMER (Cont’d)
PWM CONTROL REGISTER (PWMCR)
Read/Write Reset Value: 0000 0000 (00h)
70
DUTY CYCLE REGISTERS (DCRx)
Read/Write Reset Value: 0000 0000 (00h)
00OE1OE000OP1OP0
Bit 7:6 = Reserved.
Bit 5:4 = OE[1:0] PWM Output Enable These bits are set and cleared by software. They enable or disable the PWM output channels inde­pendently acting on the corresponding I/O pin. 0: PWM output disabled. 1: PWM output enabled.
Bit 3:2 = Reserved.
Bit 1:0 = OP[1:0] PWM Output Polarity These bits are set and cleared by software. They independently select the polarity of the two PWM output signals.
PWMx output level
OPx
Counter <= OCRx Counter > OCRx
100 011
Notes: – When an OPx bit is modified, the PWMx output
signal polarity is immediately reversed. – If DCRx=FFh then the output level is always 0. – If DCRx=00h then the output level is always 1.
70
DC7 DC6 DC5 DC4 DC3 DC2 DC1 DC0
Bit 7:0 = DC[7:0] Duty Cycle Data These bits are set and cleared by software. A DCRx register is associated with the OCRx reg-
ister of each PWM channel to determine the sec­ond edge location of the PWM signal (the first edge location is common to all channels and given by the ARR register). These DCR registers allow the duty cycle to be set independently for each PWM channel.
50/139
Doc ID 6996 Rev 5
PWM AUTO-RELOAD TIMER (Cont’d)
ST7262xxx
INPUT CAPTURE CONTROL / STATUS REGISTER (ARTICCSR)
Read/Write (except bits 1:0 read and clear)
INPUT CAPTURE REGISTERS (ARTICRx)
Read only Reset Value: 0000 0000 (00h)
Reset Value: 0000 0000 (00h)
70
70
IC7 IC6 IC5 IC4 IC3 IC2 IC1 IC0
0 0 CS2 CS1 CIE2 CIE1 CF2 CF1
Bit 7:0 = IC[7:0] Input Capture Data
Bit 7:6 = Reserved, always read as 0.
These read only bits are set and cleared by hard-
ware. An ARTICRx register contains the 8-bit Bit 5:4 = CS[2:1] Capture Sensitivity These bits are set and cleared by software. They
auto-reload counter value transferred by the input
capture channel x event. determine the trigger event polarity on the corre­sponding input capture channel. 0: Falling edge triggers capture on channel x. 1: Rising edge triggers capture on channel x.
Bit 3:2 = CIE[2:1] Capture Interrupt Enable These bits are set and cleared by software. They enable or disable the Input capture channel inter­rupts independently. 0: Input capture channel x interrupt disabled. 1: Input capture channel x interrupt enabled.
Bit 1:0 = CF[2:1] Capture Flag These bits are set by hardware when a capture oc­curs and cleared by hardware when software reads the ARTICCSR register. Each CFx bit indi­cates that an input capture x has occurred. 0: No input capture on channel x. 1: An input capture has occurred on channel x.
Doc ID 6996 Rev 5
51/139
ST7262xxx
PWM AUTO-RELOAD TIMER (Cont’d)
Table 16. PWM Auto-Reload Timer Register Map and Reset Values
Address
(Hex.)
0014h
0015h
0016h
0017h
0018h
0019h
001Ah
001Bh
001Ch
Register
Label
PWMDCR1
Reset Value
PWMDCR0
Reset Value
PWMCR
Reset Value
ARTCSR
Reset Value
ARTCAR
Reset Value
ARTARR
Reset Value
ARTICCSR
Reset Value 0 0
ARTICR1
Reset Value
ARTICR2
Reset Value
7 65432 1 0
DC7
0
DC7
0 0
0
EXCL
0
CA7
0
AR7
0
IC7
0
IC7
0
DC60DC5
DC60DC5
CC20CC1
CA6
AR6
IC6
IC6
DC4
0
0
0 0
0
0
0
0
OE1
0
0
CA5
0
AR5
0
CS2
0
IC5
0
IC5
0
0
DC4
0
OE0
0
CC0
0
CA4
0
AR4
0
CS10CIE20CIE1
IC4
0
IC4
0
DC3
0
DC3
0 0
0
TCE0FCRL
CA3
0
AR3
0
IC3
0
IC3
0
DC2
0
DC2
0 0
0
0
CA2
0
AR2
0
0
IC2
0
IC2
0
DC1
0
DC1
0
OP1
0
OIE
0
CA1
0
AR1
0
CF2
0
IC1
0
IC1
0
DC0
0
DC0
0
OP0
0
OVF
0
CA0
0
AR0
0
CF1
0
IC0
0
IC0
0
52/139
Doc ID 6996 Rev 5

10.3 TIMEBASE UNIT (TBU)

TBU 8-BIT UPCOUNTER (TBUCV REGISTER)
INTERRUPT REQUEST
TBU PRESCALER
f
CPU
TBUCSR REGISTER
PR1 PR0PR2TCENITEOVF
MSB
LSB
ART PWM TIMER 8-BIT COUNTER
MSB
LSB
CAS
0
1
TBU
ART TIMER CARRY BIT
0
ST7262xxx
10.3.1 Introduction
The Timebase unit (TBU) can be used to generate periodic interrupts.
10.3.2 Main Features
8-bit upcounter
Programmable prescaler
Period between interrupts: max. 8.1ms (at 8
CPU
)
MHz f
Maskable interrupt
Cascadable with PWM/ART TImer
10.3.3 Functional Description
The TBU operates as a free-running upcounter. When the TCEN bit in the TBUCSR register is set
by software, counting starts at the current value of the TBUCV register. The TBUCV register is incre­mented at the clock rate output from the prescaler selected by programming the PR[2:0] bits in the TBUCSR register.
When the counter rolls over from FFh to 00h, the OVF bit is set and an interrupt request is generat­ed if ITE is set.
The user can write a value at any time in the TBUCV register.
If the cascading option is selected (CAS bit=1 in
the TBUCSR register), the TBU and the ART TIm-
er counters act together as a 16-bit counter. In this
case, the TBUCV register is the high order byte,
the ART counter (ARTCAR register) is the low or-
der byte. Counting is clocked by the ART timer
clock (Refer to the description of the ART Timer
ARTCSR register).
10.3.4 Programming Example
In this example, timer is required to generate an in-
terrupt after a delay of 1 ms.
Assuming that f
is 8 MHz and a prescaler divi-
CPU
sion factor of 256 will be programmed using the
PR[2:0] bits in the TBUCSR register, 1 ms = 32
TBU timer ticks.
In this case, the initial value to be loaded in the
TBUCV must be (256-32) = 224 (E0h).
ld A, E0h
ld TBUCV, A ; Initialize counter value
ld A 1Fh ;
ld TBUCSR, A ; Prescaler factor = 256,
; interrupt enable, ; TBU enable
Figure 38. TBU Block Diagram
Doc ID 6996 Rev 5
53/139
ST7262xxx
TIMEBASE UNIT (Cont’d)
10.3.5 Low Power Modes
Mode Description
WAIT No effect on TBU HALT TBU halted.
Bit 6 = CAS Cascading Enable
This bit is set and cleared by software. It is used to
cascade the TBU and the PWM/ART timers.
0: Cascading disabled
1: Cascading enabled
10.3.6 Interrupts
Interrupt
Event
Counter Over­flow Event
Event
Enable
Flag
OVF ITE Yes No
Control
Bit
Exit from Wait
Exit
from
Halt
Bit 5 = OVF Overflow Flag This bit is set only by hardware, when the counter
value rolls over from FFh to 00h. It is cleared by software reading the TBUCSR register. Writing to this bit does not change the bit value. 0: No overflow 1: Counter overflow
Note: The OVF interrupt event is connected to an interrupt vector (see Interrupts chapter). It generates an interrupt if the ITE bit is set in the TBUCSR register and the I-bit in the CC register is reset (RIM instruction).
Bit 4 = ITE Interrupt enabled. This bit is set and cleared by software.
0: Overflow interrupt disabled 1: Overflow interrupt enabled. An interrupt request
is generated when OVF=1.
10.3.7 Register Description TBU COUNTER VALUE REGISTER (TBUCV)
Read/Write Reset Value: 0000 0000 (00h)
Bit 3 = TCEN TBU Enable. This bit is set and cleared by software.
0: TBU counter is frozen and the prescaler is reset. 1: TBU counter and prescaler running.
70
Bit 2:0 = PR[2:0] Prescaler Selection
CV7CV6CV5CV4CV3CV2CV1CV0
These bits are set and cleared by software to se­lect the prescaling factor.
Bit 7:0 = CV[7:0] Counter Value This register contains the 8-bit counter value
which can be read and written anytime by soft­ware. It is continuously incremented by hardware if TCEN=1.
TBU CONTROL/STATUS REGISTER (TBUCSR)
Read/Write Reset Value: 0000 0000 (00h)
70
PR2 PR1 PR0 Prescaler Division Factor
000 2 001 4 010 8 011 16 100 32 101 64 110 128 111 256
0 CAS OVF ITE TCEN PR2 PR1 PR0
Bit 7 = Reserved. Forced by hardware to 0.
54/139
Doc ID 6996 Rev 5
TIMEBASE UNIT (Cont’d)
Table 17. TBU Register Map and Reset Values
ST7262xxx
Address
(Hex.)
0036h
0037h
Register
Label
TBUCV
Reset Value
TBUSR
Reset Value
76543210
CV7
0
-
0
CV6
0
CAS
0
CV5
0
OVF
0
CV4
0
ITE
0
CV3
0
TCEN
0
CV2
0
PR2
0
CV1
0
PR1
0
CV0
0
PR0
0
Doc ID 6996 Rev 5
55/139
ST7262xxx
SPIDR
Read Buffer
8-Bit Shift Register
Write
Read
Data/Address Bus
SPI
SPIE SPE
MSTR
CPHA
SPR0
SPR1
CPOL
SERIAL CLOCK
GENERATOR
MOSI
MISO
SS
SCK
CONTROL
STATE
SPICR
SPICSR
Interrupt
request
MASTER
CONTROL
SPR2
07
07
SPIF WCOL MODF
0
OVR SSISSMSOD
SOD
bit
SS
1
0

10.4 SERIAL PERIPHERAL INTERFACE (SPI)

10.4.1 Introduction
The Serial Peripheral Interface (SPI) allows full­duplex, synchronous, serial communication with external devices. An SPI system may consist of a master and one or more slaves however the SPI interface can not be a master in a multimaster sys­tem.
10.4.2 Main Features
Full duplex synchronous transfers (on 3 lines)
Simplex synchronous transfers (on 2 lines)
Master or slave operation
Six master mode frequencies (f
f
SS Management by software or hardware
Programmable clock polarity and phase
End of transfer interrupt flag
Write collision, Master Mode Fault and Overrun
/2 max. slave mode frequency (see note)
CPU
CPU
/4 max.)
flags
Note: In slave mode, continuous transmission is not possible at maximum frequency due to the
Figure 39. Serial Peripheral Interface Block Diagram
software overhead for clearing status flags and to initiate the next transmission sequence.
10.4.3 General Description
Figure 39 shows the serial peripheral interface
(SPI) block diagram. There are 3 registers:
– SPI Control Register (SPICR) – SPI Control/Status Register (SPICSR) – SPI Data Register (SPIDR)
The SPI is connected to external devices through 3 pins:
– MISO: Master In / Slave Out data – MOSI: Master Out / Slave In data – SCK: Serial Clock out by SPI masters and in-
put by SPI slaves
: Slave select:
–SS
This input signal acts as a ‘chip select’ to let the SPI master communicate with slaves indi­vidually and to avoid contention on the data lines. Slave SS
inputs can be driven by stand-
ard I/O ports on the master MCU.
56/139
Doc ID 6996 Rev 5
SERIAL PERIPHERAL INTERFACE (Cont’d)
8-BIT SHIFT REGISTER
SPI
CLOCK
GENERATOR
8-BIT SHIFT REGISTER
MISO
MOSI
MOSI
MISO
SCK
SCK
SLAVE
MASTER
SS
SS
+5V
MSBit LSBit MSBit LSBit
Not used if SS is managed by software
10.4.3.1 Functional Description
A basic example of interconnections between a single master and a single slave is illustrated in
Figure 40.
The MOSI pins are connected together and the MISO pins are connected together. In this way data is transferred serially between master and slave (most significant bit first).
The communication is always initiated by the mas­ter. When the master device transmits data to a slave device via MOSI pin, the slave device re-
Figure 40. Single Master/ Single Slave Application
ST7262xxx
sponds by sending data to the master device via the MISO pin. This implies full duplex communica­tion with both data out and data in synchronized with the same clock signal (which is provided by the master device via the SCK pin).
To use a single data line, the MISO and MOSI pins must be connected at each node (in this case only simplex communication is possible).
Four possible data/clock timing relationships may be chosen (see Figure 43) but master and slave must be programmed with the same timing mode.
Doc ID 6996 Rev 5
57/139
ST7262xxx
MOSI/MISO
Master SS
Slave SS
(if CPHA=0)
Slave SS
(if CPHA=1)
Byte 1 Byte 2
Byte 3
1
0
SS internal
SSM bit
SSI bit
SS
external pin
SERIAL PERIPHERAL INTERFACE (Cont’d)
10.4.3.2 Slave Select Management
As an alternative to using the SS Slave Select signal, the application can choose to manage the Slave Select signal by software. This is configured by the SSM bit in the SPICSR regis­ter (see Figure 42)
In software management, the external SS free for other application uses and the internal SS signal level is driven by writing to the SSI bit in the SPICSR register.
In Master mode:
–SS
internal must be held high continuously
pin to control the
pin is
In Slave Mode:
There are two cases depending on the data/clock timing relationship (see Figure 41):
If CPHA=1 (data latched on 2nd clock edge):
–SS
internal must be held low during the entire transmission. This implies that in single slave applications the SS V
, or made free for standard I/O by manag-
SS
ing the SS
function by software (SSM= 1 and
pin either can be tied to
SSI=0 in the in the SPICSR register)
If CPHA=0 (data latched on 1st clock edge):
–SS
internal must be held low during byte transmission and pulled high between each byte to allow the slave to write to the shift reg­ister. If SS
is not pulled high, a Write Collision error will occur when the slave writes to the shift register (see Section 10.4.5.3).
Figure 41. Generic SS
Timing Diagram
Figure 42. Hardware/Software Slave Select Management
58/139
Doc ID 6996 Rev 5
SERIAL PERIPHERAL INTERFACE (Cont’d)
10.4.3.3 Master Mode Operation
In master mode, the serial clock is output on the SCK pin. The clock frequency, polarity and phase are configured by software (refer to the description of the SPICSR register).
Note: The idle state of SCK must correspond to the polarity selected in the SPICSR register (by pulling up SCK if CPOL=1 or pulling down SCK if CPOL=0).
To operate the SPI in master mode, perform the following two steps in order (if the SPICSR register is not written first, the SPICR register setting (MSTR bit) may be not taken into ac­count):
1. Write to the SPICR register: – Select the clock frequency by configuring the
SPR[2:0] bits.
– Select the clock polarity and clock phase by
configuring the CPOL and CPHA bits. Figure
43 shows the four possible configurations.
Note: The slave must have the same CPOL and CPHA settings as the master.
2. Write to the SPICSR register: – Either set the SSM bit and set the SSI bit or
clear the SSM bit and tie the SS
pin high for
the complete byte transmit sequence.
3. Write to the SPICR register: – Set the MSTR and SPE bits
Note: MSTR and SPE bits remain set only if SS
is high).
The transmit sequence begins when software writes a byte in the SPIDR register.
10.4.3.4 Master Mode Transmit Sequence
When software writes to the SPIDR register, the data byte is loaded into the 8-bit shift register and then shifted out serially to the MOSI pin most sig­nificant bit first.
When data transfer is complete:
– The SPIF bit is set by hardware – An interrupt request is generated if the SPIE
bit is set and the interrupt mask in the CC reg­ister is cleared.
Clearing the SPIF bit is performed by the following software sequence:
1. An access to the SPICSR register while the SPIF bit is set
2. A read to the SPIDR register.
ST7262xxx
Note: While the SPIF bit is set, all writes to the
SPIDR register are inhibited until the SPICSR reg­ister is read.
10.4.3.5 Slave Mode Operation
In slave mode, the serial clock is received on the SCK pin from the master device.
To operate the SPI in slave mode:
1. Write to the SPICSR register to perform the fol­lowing actions:
– Select the clock polarity and clock phase by
configuring the CPOL and CPHA bits (see
Figure 43).
Note: The slave must have the same CPOL and CPHA settings as the master.
– Manage the SS
10.4.3.2 and Figure 41. If CPHA=1 SS
be held low continuously. If CPHA=0 SS be held low during byte transmission and pulled up between each byte to let the slave write in the shift register.
2. Write to the SPICR register to clear the MSTR bit and set the SPE bit to enable the SPI I/O functions.
10.4.3.6 Slave Mode Transmit Sequence
When software writes to the SPIDR register, the data byte is loaded into the 8-bit shift register and then shifted out serially to the MISO pin most sig­nificant bit first.
The transmit sequence begins when the slave de­vice receives the clock signal and the most signifi­cant bit of the data on its MOSI pin.
When data transfer is complete:
– The SPIF bit is set by hardware – An interrupt request is generated if SPIE bit is
set and interrupt mask in the CC register is cleared.
Clearing the SPIF bit is performed by the following software sequence:
1. An access to the SPICSR register while the SPIF bit is set.
2. A write or a read to the SPIDR register.
Notes: While the SPIF bit is set, all writes to the SPIDR register are inhibited until the SPICSR reg­ister is read.
The SPIF bit can be cleared during a second transmission; however, it must be cleared before the second SPIF bit in order to prevent an Overrun condition (see Section 10.4.5.2).
pin as described in Section
must
must
Doc ID 6996 Rev 5
59/139
ST7262xxx
SCK
MSBit Bit 6 Bit 5
Bit 4 Bit3 Bit 2 Bit 1 LSBit
MSBit Bit 6 Bit 5
Bit 4 Bit3 Bit 2 Bit 1 LSBit
MISO
(from master)
MOSI
(from slave)
SS
(to slave)
CAPTURE STROBE
CPHA =1
MSBit Bit 6 Bit 5
Bit 4 Bit3 Bit 2 Bit 1 LSBit
MSBit Bit 6 Bit 5
Bit 4 Bit3 Bit 2 Bit 1 LSBit
MISO
(from master)
MOSI
SS
(to slave)
CAPTURE STROBE
CPHA =0
Note: This figure should not be used as a replacement for parametric information.
Refer to the Electrical Characteristics chapter.
(from slave)
(CPOL = 1)
SCK (CPOL = 0)
SCK (CPOL = 1)
SCK (CPOL = 0)
SERIAL PERIPHERAL INTERFACE (Cont’d)
10.4.4 Clock Phase and Clock Polarity
Four possible timing relationships may be chosen by software, using the CPOL and CPHA bits (See
Figure 43).
Note: The idle state of SCK must correspond to the polarity selected in the SPICSR register (by pulling up SCK if CPOL=1 or pulling down SCK if CPOL=0).
The combination of the CPOL clock polarity and CPHA (clock phase) bits selects the data capture clock edge
Figure 43. Data Clock Timing Diagram
Figure 43, shows an SPI transfer with the four
combinations of the CPHA and CPOL bits. The di­agram may be interpreted as a master or slave timing diagram where the SCK pin, the MISO pin, the MOSI pin are directly connected between the master and the slave device.
Note: If CPOL is changed at the communication byte boundaries, the SPI must be disabled by re­setting the SPE bit.
60/139
Doc ID 6996 Rev 5
SERIAL PERIPHERAL INTERFACE (Cont’d)
Clearing sequence after SPIF = 1 (end of a data byte transfer)
1st Step
Read SPICSR
Read SPIDR
2nd Step
SPIF =0 WCOL=0
Clearing sequence before SPIF = 1 (during a data byte transfer)
1st Step
2nd Step
WCOL=0
Read SPICSR
Read SPIDR
Note: Writing to the SPIDR regis­ter instead of reading it does not reset the WCOL bit
RESULT
RESULT
10.4.5 Error Flags
10.4.5.1 Master Mode Fault (MODF)
Master mode fault occurs when the master device has its SS
pin pulled low.
When a Master mode fault occurs:
– The MODF bit is set and an SPI interrupt re-
quest is generated if the SPIE bit is set.
– The SPE bit is reset. This blocks all output
from the device and disables the SPI periph­eral.
– The MSTR bit is reset, thus forcing the device
into slave mode.
Clearing the MODF bit is done through a software sequence:
1. A read access to the SPICSR register while the MODF bit is set.
2. A write to the SPICR register.
Notes: To avoid any conflicts in an application with multiple slaves, the SS
pin must be pulled high during the MODF bit clearing sequence. The SPE and MSTR bits may be restored to their orig­inal state during or after this clearing sequence.
Hardware does not allow the user to set the SPE and MSTR bits while the MODF bit is set except in the MODF bit clearing sequence.
In a slave device, the MODF bit can not be set, but in a multimaster configuration the device can be in slave mode with the MODF bit set.
The MODF bit indicates that there might have been a multimaster conflict and allows software to handle this using an interrupt routine and either perform to a reset or return to an application de­fault state.
ST7262xxx
10.4.5.2 Overrun Condition (OVR)
An overrun condition occurs, when the master de­vice has sent a data byte and the slave device has not cleared the SPIF bit issued from the previously transmitted byte.
When an Overrun occurs: – The OVR bit is set and an interrupt request is
generated if the SPIE bit is set.
In this case, the receiver buffer contains the byte sent after the SPIF bit was last cleared. A read to the SPIDR register returns this byte. All other bytes are lost.
The OVR bit is cleared by reading the SPICSR register.
10.4.5.3 Write Collision Error (WCOL)
A write collision occurs when the software tries to write to the SPIDR register while a data transfer is taking place with an external device. When this happens, the transfer continues uninterrupted; and the software write will be unsuccessful.
Write collisions can occur both in master and slave mode. See also Section 10.4.3.2 Slave Select
Management.
Note: a "read collision" will never occur since the received data byte is placed in a buffer in which access is always synchronous with the MCU oper­ation.
The WCOL bit in the SPICSR register is set if a write collision occurs.
No SPI interrupt is generated when the WCOL bit is set (the WCOL bit is a status flag only).
Clearing the WCOL bit is done through a software sequence (see Figure 44).
Figure 44. Clearing the WCOL bit (Write Collision Flag) Software Sequence
Doc ID 6996 Rev 5
61/139
ST7262xxx
MISO
MOSI
MOSI
MOSI MOSI MOSIMISO MISO MISOMISO
SS
SS SS
SS
SS
SCK SCK
SCK
SCK
SCK
5V
Ports
Slave MCU
Slave MCU
Slave
MCU
Slave MCU
Master
MCU
SERIAL PERIPHERAL INTERFACE (Cont’d)
10.4.5.4 Single Master System
A typical single master system may be configured, using an MCU as the master and four MCUs as slaves (see Figure 45).
The master device selects the individual slave de­vices by using four pins of a parallel port to control the four SS
The SS
pins of the slave devices.
pins are pulled high during reset since the master device ports will be forced to be inputs at that time, thus disabling the slave devices.
Figure 45. Single Master / Multiple Slave Configuration
Note: To prevent a bus conflict on the MISO line
the master allows only one active slave device during a transmission.
For more security, the slave device may respond to the master with the received data byte. Then the master will receive the previous byte back from the slave device if all MISO and MOSI pins are con­nected and the slave has not written to its SPIDR register.
Other transmission security methods can use ports for handshake lines or data bytes with com­mand fields.
62/139
Doc ID 6996 Rev 5
SERIAL PERIPHERAL INTERFACE (Cont’d)
10.4.6 Low Power Modes
Mode Description
WAIT
HALT
No effect on SPI. SPI interrupt events cause the device to exit from WAIT mode.
SPI registers are frozen. In HALT mode, the SPI is inactive. SPI oper­ation resumes when the MCU is woken up by an interrupt with “exit from HALT mode” ca­pability. The data received is subsequently read from the SPIDR register when the soft­ware is running (interrupt vector fetching). If several data are received before the wake­up event, then an overrun error is generated. This error can be detected after the fetch of the interrupt routine that woke up the device.
10.4.6.1 Using the SPI to wakeup the MCU from Halt mode
In slave configuration, the SPI is able to wakeup the ST7 device from HALT mode through a SPIF interrupt. The data received is subsequently read from the SPIDR register when the software is run­ning (interrupt vector fetch). If multiple data trans­fers have been performed before software clears the SPIF bit, then the OVR bit is set by hardware.
ST7262xxx
Note: When waking up from Halt mode, if the SPI
remains in Slave mode, it is recommended to per­form an extra communications cycle to bring the SPI from Halt mode state to normal state. If the SPI exits from Slave mode, it returns to normal state immediately.
Caution: The SPI can wake up the ST7 from Halt mode only if the Slave Select signal (external SS pin or the SSI bit in the SPICSR register) is low when the ST7 enters Halt mode. So if Slave selec­tion is configured as external (see Section
10.4.3.2), make sure the master drives a low level
on the SS
10.4.7 Interrupts
Interrupt Event
SPI End of Transfer Event
Master Mode Fault Event
Overrun Error OVR Yes No
Note: The SPI interrupt events are connected to the same interrupt vector (see Interrupts chapter). They generate an interrupt if the corresponding Enable Control Bit is set and the interrupt mask in
pin when the slave enters Halt mode.
Event
Flag
SPIF
MODF Yes No
Enable
Control
Bit
SPIE
Exit from Wait
Yes Yes
Exit
from
Halt
Doc ID 6996 Rev 5
63/139
ST7262xxx
SERIAL PERIPHERAL INTERFACE (Cont’d)
10.4.8 Register Description CONTROL REGISTER (SPICR)
Read/Write Reset Value: 0000 xxxx (0xh)
70
SPIE SPE SPR2 MSTR CPOL CPHA SPR1 SPR0
Bit 4 = MSTR Master Mode. This bit is set and cleared by software. It is also cleared by hardware when, in master mode, SS (see Section 10.4.5.1 Master Mode Fault
(MODF)).
0: Slave mode 1: Master mode. The function of the SCK pin
changes from an input to an output and the func­tions of the MISO and MOSI pins are reversed.
=0
Bit 7 = SPIE Serial Peripheral Interrupt Enable. This bit is set and cleared by software. 0: Interrupt is inhibited 1: An SPI interrupt is generated whenever
SPIF=1, MODF=1 or OVR=1 in the SPICSR register
Bit 6 = SPE Serial Peripheral Output Enable. This bit is set and cleared by software. It is also cleared by hardware when, in master mode, SS
=0 (see Section 10.4.5.1 Master Mode Fault
(MODF)). The SPE bit is cleared by reset, so the
SPI peripheral is not initially connected to the ex­ternal pins. 0: I/O pins free for general purpose I/O 1: SPI I/O pin alternate functions enabled
Bit 5 = SPR2 Divider Enable. This bit is set and cleared by software and is cleared by reset. It is used with the SPR[1:0] bits to set the baud rate. Refer to Table 18 SPI Master
mode SCK Frequency.
0: Divider by 2 enabled 1: Divider by 2 disabled
Note: This bit has no effect in slave mode.
Bit 3 = CPOL Clock Polarity. This bit is set and cleared by software. This bit de­termines the idle state of the serial Clock. The CPOL bit affects both the master and slave modes. 0: SCK pin has a low level idle state 1: SCK pin has a high level idle state
Note: If CPOL is changed at the communication byte boundaries, the SPI must be disabled by re­setting the SPE bit.
Bit 2 = CPHA Clock Phase. This bit is set and cleared by software. 0: The first clock transition is the first data capture
edge.
1: The second clock transition is the first capture
edge.
Note: The slave must have the same CPOL and CPHA settings as the master.
Bits 1:0 = SPR[1:0] Serial Clock Frequency. These bits are set and cleared by software. Used with the SPR2 bit, they select the baud rate of the SPI serial clock SCK output by the SPI in master mode.
Note: These 2 bits have no effect in slave mode.
Table 18. SPI Master mode SCK Frequency
SPR2 SPR1 SPR0
100 f 000 f 001 f 110 f 010 f 011 f
64/139
Serial Clock
(f
= 8MHz)
CPU
/4 f
CPU
/8 f
CPU
/16 f
CPU
/32 f
CPU
/64 f
CPU
/128 f
CPU
Serial Clock
(f
CPU
CPU
CPU
CPU
CPU
CPU
CPU
Doc ID 6996 Rev 5
= 4MHz)
SCK
/2 2 MHz /4 1 MHz
/8 0.5 MHz /16 0.25 MHz /32 125 kHz /64 62.5 kHz
SERIAL PERIPHERAL INTERFACE (Cont’d) CONTROL/STATUS REGISTER (SPICSR)
Read/Write (some bits Read Only) Reset Value: 0000 0000 (00h)
70
Bit 2 = SOD SPI Output Disable. This bit is set and cleared by software. When set, it disables the alternate function of the SPI output (MOSI in master mode / MISO in slave mode)
SPIF WCOL OVR MODF - SOD SSM SSI
0: SPI output enabled (if SPE=1) 1: SPI output disabled
ST7262xxx
Bit 7 = SPIF Serial Peripheral Data Transfer Flag
(Read only).
This bit is set by hardware when a transfer has been completed. An interrupt is generated if SPIE=1 in the SPICR register. It is cleared by a software sequence (an access to the SPICSR register followed by a write or a read to the SPIDR register).
0: Data transfer is in progress or the flag has been
cleared.
1: Data transfer between the device and an exter-
nal device has been completed.
Note: While the SPIF bit is set, all writes to the SPIDR register are inhibited until the SPICSR reg­ister is read.
Bit 6 = WCOL Write Collision status (Read only). This bit is set by hardware when a write to the SPIDR register is done during a transmit se­quence. It is cleared by a software sequence (see
Figure 44).
0: No write collision occurred 1: A write collision has been detected
Bit 5 = OVR SPI Overrun error (Read only). This bit is set by hardware when the byte currently being received in the shift register is ready to be transferred into the SPIDR register while SPIF = 1 (See Section 10.4.5.2). An interrupt is generated if SPIE = 1 in SPICR register. The OVR bit is cleared by software reading the SPICSR register. 0: No overrun error 1: Overrun error detected
Bit 4 = MODF Mode Fault flag (Read only). This bit is set by hardware when the SS
pin is pulled low in master mode (see Section 10.4.5.1
Master Mode Fault (MODF)). An SPI interrupt can
be generated if SPIE=1 in the SPICR register. This bit is cleared by a software sequence (An access to the SPICSR register while MODF=1 followed by a write to the SPICR register). 0: No master mode fault detected 1: A fault in master mode has been detected
Bit 3 = Reserved, must be kept cleared.
Bit 1 = SSM SS
Management.
This bit is set and cleared by software. When set, it disables the alternate function of the SPI SS
pin
and uses the SSI bit value instead. See Section
10.4.3.2 Slave Select Management.
0: Hardware management (SS
managed by exter-
nal pin)
1: Software management (internal SS
trolled by SSI bit. External SS
signal con-
pin free for gener-
al-purpose I/O)
Bit 0 = SSI SS
Internal Mode.
This bit is set and cleared by software. It acts as a ‘chip select’ by controlling the level of the SS
slave select signal when the SSM bit is set. 0 : Slave selected 1 : Slave deselected
DATA I/O REGISTER (SPIDR)
Read/Write Reset Value: Undefined
70
D7 D6 D5 D4 D3 D2 D1 D0
The SPIDR register is used to transmit and receive data on the serial bus. In a master device, a write to this register will initiate transmission/reception of another byte.
Notes: During the last clock cycle the SPIF bit is set, a copy of the received data byte in the shift register is moved to a buffer. When the user reads the serial peripheral data I/O register, the buffer is actually being read.
While the SPIF bit is set, all writes to the SPIDR register are inhibited until the SPICSR register is read.
Warning: A write to the SPIDR register places data directly into the shift register for transmission.
A read to the SPIDR register returns the value lo­cated in the buffer and not the content of the shift register (see Figure 39).
Doc ID 6996 Rev 5
65/139
ST7262xxx
Table 19. SPI Register Map and Reset Values
Address
(Hex.)
0011h
0012h
0013h
Register
Label
SPIDR
Reset Value
SPICR
Reset Value
SPICSR
Reset Value
76543210
MSB
xxxxxxx
SPIE
0
SPIF
0
SPE
0
WCOL
0
SPR20MSTR
0
OVR
0
MODF
00
CPOL
x
CPHA
x
SOD
0
SPR1
x
SSM
0
LSB
x
SPR0
x
SSI
0
66/139
Doc ID 6996 Rev 5

10.5 SERIAL COMMUNICATIONS INTERFACE (SCI)

ST7262xxx
10.5.1 Introduction
The Serial Communications Interface (SCI) offers a flexible means of full-duplex data exchange with external equipment requiring an industry standard NRZ asynchronous serial data format. The SCI of­fers a very wide range of baud rates using two baud rate generator systems.
10.5.2 Main Features
Full duplex, asynchronous communications
NRZ standard format (Mark/Space)
Dual baud rate generator systems
Independently programmable transmit and
receive baud rates up to 500K baud
Programmable data word length (8 or 9 bits)
Receive buffer full, Transmit buffer empty and
End of Transmission flags
Two receiver wake-up modes:
– Address bit (MSB) – Idle line
Muting function for multiprocessor configurations
Separate enable bits for Transmitter and
Receiver
Four error detection flags:
– Overrun error – Noise error – Frame error – Parity error
Five interrupt sources with flags:
– Transmit data register empty – Transmission complete – Receive data register full – Idle line received – Overrun error detected
Parity control:
– Transmits parity bit – Checks parity of received data byte
Reduced power consumption mode
10.5.3 General Description
The interface is externally connected to another device by two pins (see Figure 47):
– TDO: Transmit Data Output. When the transmit-
ter and the receiver are disabled, the output pin returns to its I/O port configuration. When the transmitter and/or the receiver are enabled and nothing is to be transmitted, the TDO pin is at high level.
– RDI: Receive Data Input is the serial data input.
Oversampling techniques are used for data re­covery by discriminating between valid incoming data and noise.
Through these pins, serial data is transmitted and received as frames comprising:
– An Idle Line prior to transmission or reception – A start bit – A data word (8 or 9 bits) least significant bit first – A Stop bit indicating that the frame is complete This interface uses two types of baud rate generator: – A conventional type for commonly-used baud
rates
– An extended type with a prescaler offering a very
wide range of baud rates even with non-standard oscillator frequencies
Doc ID 6996 Rev 5
67/139
ST7262xxx
WAKE
UP
UNIT
RECEIVER
CONTROL
SR
TRANSMIT
CONTROL
TDRE TC RDRF IDLE OR NF FE PE
SCI
CONTROL
INTERRUPT
CR1
R8 T8 SCID M WAKE PCE PS PIE
Received Data Register (RDR)
Received Shift Register
Read
Transmit Data Register (TDR)
Transmit Shift Register
Write
RDI
TDO
(DATA REGISTER) DR
TRANSMITTER
CLOCK
RECEIVER
CLOCK
RECEIVER RATE
TRANSMITTER RATE
BRR
SCP1
f
CPU
CONTROL
CONTROL
SCP0
SCT2
SCT1 SCT0 SCR2
SCR1SCR0
/PR
/16
CONVENTIONAL BAUD RATE GENERATOR
SBKRWURETEILIERIETCIETIE
CR2
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
Figure 46. SCI Block Diagram
68/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
Bit0
Bit1
Bit2
Bit3
Bit4
Bit5
Bit6
Bit7
Bit8
Start
Bit
Stop
Bit
Next
Start
Bit
Idle Frame
Bit0
Bit1
Bit2
Bit3
Bit4
Bit5
Bit6
Bit7
Start
Bit
Stop
Bit
Next Start
Bit
Start
Bit
Idle Frame
Start
Bit
9-bit Word length (M bit is set)
8-bit Word length (M bit is reset)
Possible
Parity
Bit
Possible
Parity
Bit
Break Frame
Start
Bit
Extra
‘1’
Data Frame
Break Frame
Start
Bit
Extra
‘1’
Data Frame
Next Data Frame
Next Data Frame
10.5.4 Functional Description
The block diagram of the Serial Control Interface, is shown in Figure 46 It contains six dedicated reg­isters:
– Two control registers (SCICR1 & SCICR2) – A status register (SCISR) – A baud rate register (SCIBRR) – An extended prescaler receiver register (SCIER-
PR)
– An extended prescaler transmitter register (SCI-
ETPR)
Refer to the register descriptions in Section
10.5.7for the definitions of each bit.
Figure 47. Word Length Programming
ST7262xxx
10.5.4.1 Serial Data Format
Word length may be selected as being either 8 or 9 bits by programming the M bit in the SCICR1 reg­ister (see Figure 46).
The TDO pin is in low state during the start bit. The TDO pin is in high state during the stop bit. An Idle character is interpreted as an entire frame
of “1”s followed by the start bit of the next frame which contains data.
A Break character is interpreted on receiving “0”s for some multiple of the frame period. At the end of the last break frame the transmitter inserts an ex­tra “1” bit to acknowledge the start bit.
Transmission and reception are driven by their own baud rate generator.
Doc ID 6996 Rev 5
69/139
ST7262xxx
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
10.5.4.2 Transmitter
The transmitter can send data words of either 8 or 9 bits depending on the M bit status. When the M bit is set, word length is 9 bits and the 9th bit (the MSB) has to be stored in the T8 bit in the SCICR1 register.
Character Transmission
During an SCI transmission, data shifts out least significant bit first on the TDO pin. In this mode, the SCIDR register consists of a buffer (TDR) be­tween the internal bus and the transmit shift regis­ter (see Figure 46).
Procedure
– Select the M bit to define the word length. – Select the desired baud rate using the SCIBRR
and the SCIETPR registers.
– Set the TE bit to assign the TDO pin to the alter-
nate function and to send a idle frame as first transmission.
– Access the SCISR register and write the data to
send in the SCIDR register (this sequence clears the TDRE bit). Repeat this sequence for each data to be transmitted.
Clearing the TDRE bit is always performed by the following software sequence:
1. An access to the SCISR register
2. A write to the SCIDR register The TDRE bit is set by hardware and it indicates: – The TDR register is empty. – The data transfer is beginning. – The next data can be written in the SCIDR regis-
ter without overwriting the previous data.
This flag generates an interrupt if the TIE bit is set and the I bit is cleared in the CC register.
When a transmission is taking place, a write in­struction to the SCIDR register stores the data in the TDR register and which is copied in the shift register at the end of the current transmission.
When no transmission is taking place, a write in­struction to the SCIDR register places the data di­rectly in the shift register, the data transmission starts, and the TDRE bit is immediately set.
When a frame transmission is complete (after the stop bit) the TC bit is set and an interrupt is gener­ated if the TCIE is set and the I bit is cleared in the CC register.
Clearing the TC bit is performed by the following software sequence:
1. An access to the SCISR register
2. A write to the SCIDR register Note: The TDRE and TC bits are cleared by the
same software sequence.
Break Characters
Setting the SBK bit loads the shift register with a break character. The break frame length depends on the M bit (see Figure 47).
As long as the SBK bit is set, the SCI send break frames to the TDO pin. After clearing this bit by software the SCI insert a logic 1 bit at the end of the last break frame to guarantee the recognition of the start bit of the next frame.
Idle Characters
Setting the TE bit drives the SCI to send an idle frame before the first data frame.
Clearing and then setting the TE bit during a trans­mission sends an idle frame after the current word.
Note: Resetting and setting the TE bit causes the data in the TDR register to be lost. Therefore the best time to toggle the TE bit is when the TDRE bit is set, that is, before writing the next byte in the SCIDR.
70/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
10.5.4.3 Receiver
The SCI can receive data words of either 8 or 9 bits. When the M bit is set, word length is 9 bits and the MSB is stored in the R8 bit in the SCICR1 register.
Character reception
During a SCI reception, data shifts in least signifi­cant bit first through the RDI pin. In this mode, the SCIDR register consists or a buffer (RDR) be­tween the internal bus and the received shift regis­ter (see Figure 46).
Procedure
– Select the M bit to define the word length. – Select the desired baud rate using the SCIBRR
and the SCIERPR registers.
– Set the RE bit, this enables the receiver which
begins searching for a start bit. When a character is received: – The RDRF bit is set. It indicates that the content
of the shift register is transferred to the RDR. – An interrupt is generated if the RIE bit is set and
the I bit is cleared in the CC register. – The error flags can be set if a frame error, noise
or an overrun error has been detected during re-
ception. Clearing the RDRF bit is performed by the following
software sequence done by:
1. An access to the SCISR register
2. A read to the SCIDR register. The RDRF bit must be cleared before the end of the
reception of the next character to avoid an overrun error.
Break Character
When a break character is received, the SCI han­dles it as a framing error.
Idle Character
When a idle frame is detected, there is the same procedure as a data received character plus an in­terrupt if the ILIE bit is set and the I bit is cleared in the CC register.
Overrun Error
An overrun error occurs when a character is re­ceived when RDRF has not been reset. Data can not be transferred from the shift register to the
ST7262xxx
RDR register as long as the RDRF bit is not cleared.
When an overrun error occurs: – The OR bit is set. – The RDR content is not lost. – The shift register is overwritten. – An interrupt is generated if the RIE bit is set and
the I bit is cleared in the CC register.
The OR bit is reset by an access to the SCISR reg­ister followed by a SCIDR register read operation.
Noise Error
Oversampling techniques are used for data recov­ery by discriminating between valid incoming data and noise. Normal data bits are considered valid if three consecutive samples (8th, 9th, 10th) have the same bit value, otherwise the NF flag is set. In the case of start bit detection, the NF flag is set on the basis of an algorithm combining both valid edge detection and three samples (8th, 9th, 10th). Therefore, to prevent the NF flag getting set during start bit reception, there should be a valid edge de­tection as well as three valid samples.
When noise is detected in a frame: – The NF flag is set at the rising edge of the RDRF
bit.
– Data is transferred from the Shift register to the
SCIDR register.
– No interrupt is generated. However this bit rises
at the same time as the RDRF bit which itself generates an interrupt.
The NF flag is reset by a SCISR register read op­eration followed by a SCIDR register read opera­tion.
During reception, if a false start bit is detected (e.g. 8th, 9th, 10th samples are 011,101,110), the frame is discarded and the receiving sequence is not started for this frame. There is no RDRF bit set for this frame and the NF flag is set internally (not accessible to the user). This NF flag is accessible along with the RDRF bit when a next valid frame is received.
Note: If the application Start Bit is not long enough to match the above requirements, then the NF Flag may get set due to the short Start Bit. In this case, the NF flag may be ignored by the applica­tion software when the first valid byte is received.
See also Section 10.5.4.10.
Doc ID 6996 Rev 5
71/139
ST7262xxx
TRANSMITTER
RECEIVER
SCIETPR
SCIERPR
EXTENDED PRESCALER RECEIVER RATE CONTROL
EXTENDED PRESCALER TRANSMITTER RATE CONTROL
EXTENDED PRESCALER
CLOCK
CLOCK
RECEIVER RATE
TRANSMITTER RATE
SCIBRR
SCP1
f
CPU
CONTROL
CONTROL
SCP0
SCT2
SCT1 SCT0 SCR2 SCR1SCR0
/PR
/16
CONVENTIONAL BAUD RATE GENERATOR
EXTENDED RECEIVER PRESCALER REGISTER
EXTENDED TRANSMITTER PRESCALER REGISTER
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
Figure 48. SCI Baud Rate and Extended Prescaler Block Diagram
72/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
Tx =
(16
*
PR)*TR
f
CPU
Rx =
(16
*
PR)*RR
f
CPU
Tx =
16
*
ETPR*(PR*TR)
f
CPU
Rx =
16
*
ERPR*(PR*RR)
f
CPU
Framing Error
A framing error is detected when: – The stop bit is not recognized on reception at the
expected time, following either a de-synchroni-
zation or excessive noise. – A break is received. When the framing error is detected: – the FE bit is set by hardware – Data is transferred from the Shift register to the
SCIDR register. – No interrupt is generated. However this bit rises
at the same time as the RDRF bit which itself
generates an interrupt. The FE bit is reset by a SCISR register read oper-
ation followed by a SCIDR register read operation.
10.5.4.4 Conventional Baud Rate Generation
The baud rate for the receiver and transmitter (Rx and Tx) are set independently and calculated as follows:
with: PR = 1, 3, 4 or 13 (see SCP[1:0] bits) TR = 1, 2, 4, 8, 16, 32, 64,128 (see SCT[2:0] bits) RR = 1, 2, 4, 8, 16, 32, 64,128 (see SCR[2:0] bits) All these bits are in the SCIBRR register. Example: If f
is 8 MHz (normal mode) and if
CPU
PR = 13 and TR = RR = 1, the transmit and re­ceive baud rates are 38400 baud.
Note: The baud rate registers MUST NOT be changed while the transmitter or the receiver is en­abled.
10.5.4.5 Extended Baud Rate Generation
The extended prescaler option gives a very fine tuning on the baud rate, using a 255 value prescal­er, whereas the conventional Baud Rate Genera­tor retains industry standard software compatibili­ty.
The extended baud rate generator block diagram is described in the Figure 48
The output clock rate sent to the transmitter or to the receiver is the output from the 16 divider divid­ed by a factor ranging from 1 to 255 set in the SCI­ERPR or the SCIETPR register.
ST7262xxx
Note: the extended prescaler is activated by set-
ting the SCIETPR or SCIERPR register to a value other than zero. The baud rates are calculated as follows:
with: ETPR = 1,..,255 (see SCIETPR register) ERPR = 1,.. 255 (see SCIERPR register)
10.5.4.6 Receiver Muting and Wake-up Feature
In multiprocessor configurations it is often desira­ble that only the intended message recipient should actively receive the full message contents, thus reducing redundant SCI service overhead for all non addressed receivers.
The non addressed devices may be placed in sleep mode by means of the muting function.
Setting the RWU bit by software puts the SCI in sleep mode:
All the reception status bits can not be set. All the receive interrupts are inhibited. A muted receiver may be awakened by one of the
following two ways: – by Idle Line detection if the WAKE bit is reset, – by Address Mark detection if the WAKE bit is set. Receiver wakes-up by Idle Line detection when
the Receive line has recognized an Idle Frame. Then the RWU bit is reset by hardware but the IDLE bit is not set.
Receiver wakes-up by Address Mark detection when it received a “1” as the most significant bit of a word, thus indicating that the message is an ad­dress. The reception of this particular word wakes up the receiver, resets the RWU bit and sets the RDRF bit, which allows the receiver to receive this word normally and to use it as an address word.
CAUTION: In Mute mode, do not write to the SCICR2 register. If the SCI is in Mute mode during the read operation (RWU = 1) and a address mark wake up event occurs (RWU is reset) before the write operation, the RWU bit is set again by this write operation. Consequently the address byte is lost and the SCI is not woken up from Mute mode.
Doc ID 6996 Rev 5
73/139
ST7262xxx
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
10.5.4.7 Parity Control
Parity control (generation of parity bit in transmis­sion and parity checking in reception) can be ena­bled by setting the PCE bit in the SCICR1 register. Depending on the frame length defined by the M bit, the possible SCI frame formats are as listed in
Table 20.
Table 20. Frame Formats
M bit PCE bit SCI frame
0 0 | SB | 8 bit data | STB | 0 1 | SB | 7-bit data | PB | STB | 1 0 | SB | 9-bit data | STB | 1 1 | SB | 8-bit data PB | STB |
Legend: SB = Start Bit, STB = Stop Bit, PB = Parity Bit
Note: In case of wake up by an address mark, the MSB bit of the data is taken into account and not the parity bit
Even parity: the parity bit is calculated to obtain an even number of “1s” inside the frame made of the 7 or 8 LSB bits (depending on whether M is equal to 0 or 1) and the parity bit.
Example: data = 00110101; 4 bits set => parity bit is 0 if even parity is selected (PS bit = 0).
Odd parity: the parity bit is calculated to obtain an odd number of “1s” inside the frame made of the 7 or 8 LSB bits (depending on whether M is equal to 0 or 1) and the parity bit.
Example: data = 00110101; 4 bits set => parity bit is 1 if odd parity is selected (PS bit = 1).
Transmission mode: If the PCE bit is set then the MSB bit of the data written in the data register is not transmitted but is changed by the parity bit.
Reception mode: If the PCE bit is set then the in­terface checks if the received data byte has an
even number of “1s” if even parity is selected (PS = 0) or an odd number of “1s” if odd parity is selected (PS = 1). If the parity check fails, the PE flag is set in the SCISR register and an interrupt is generated if PIE is set in the SCICR1 register.
10.5.4.8 SCI Clock Tolerance
During reception, each bit is sampled 16 times. The majority of the 8th, 9th and 10th samples is considered as the bit value. For a valid bit detec- tion, all the three samples should have the same value otherwise the noise flag (NF) is set. For ex­ample: If the 8th, 9th and 10th samples are 0, 1 and 1 respectively, then the bit value is “1”, but the Noise Flag bit is set because the three samples values are not the same.
Consequently, the bit length must be long enough so that the 8th, 9th and 10th samples have the de­sired bit value. This means the clock frequency should not vary more than 6/16 (37.5%) within one bit. The sampling clock is resynchronized at each start bit, so that when receiving 10 bits (one start bit, 1 data byte, 1 stop bit), the clock deviation must not exceed 3.75%.
Note: The internal sampling clock of the microcon­troller samples the pin value on every falling edge. Therefore, the internal sampling clock and the time the application expects the sampling to take place may be out of sync. For example: If the baud rate is 15.625 Kbaud (bit length is 64µs), then the 8th, 9th and 10th samples are at 28µs, 32µs and 36µs respectively (the first sample starting ideally at 0µs). But if the falling edge of the internal clock oc­curs just before the pin value changes, the sam­ples would then be out of sync by ~4us. This means the entire bit length must be at least 40µs (36µs for the 10th sample + 4µs for synchroniza­tion with the internal sampling clock).
74/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
RDI LINE
Sample clock
12345678910111213 14 15 16
sampled values
One bit time
6/16
7/16
7/16
10.5.4.9 Clock Deviation Causes
The causes which contribute to the total deviation are:
–D
: Deviation due to transmitter error (Local
TRA
oscillator error of the transmitter or the trans­mitter is transmitting at a different baud rate).
–D
tion of the receiver.
–D
: Error due to the baud rate quantiza-
QUANT
: Deviation of the local oscillator of the
REC
receiver: This deviation can occur during the reception of one complete SCI message as­suming that the deviation has been compen­sated at the beginning of the message.
–D
: Deviation due to the transmission line
TCL
(generally due to the transceivers)
All the deviations of the system should be added and compared to the SCI clock tolerance:
D
TRA
+ D
QUANT
+ D
REC
+ D
< 3.75%
TCL
ST7262xxx
10.5.4.10 Noise Error Causes
See also description of Noise error in Section
10.5.4.3.
Start bit
The noise flag (NF) is set during start bit reception if one of the following conditions occurs:
1. A valid falling edge is not detected. A falling edge is considered to be valid if the 3 consecu­tive samples before the falling edge occurs are detected as '1' and, after the falling edge occurs, during the sampling of the 16 samples, if one of the samples numbered 3, 5 or 7 is detected as a “1”.
2. During sampling of the 16 samples, if one of the samples numbered 8, 9 or 10 is detected as a “1”.
Therefore, a valid Start Bit must satisfy both the above conditions to prevent the Noise Flag getting set.
Data Bits
The noise flag (NF) is set during normal data bit re­ception if the following condition occurs:
– During the sampling of 16 samples, if all three
samples numbered 8, 9 and10 are not the same. The majority of the 8th, 9th and 10th samples is considered as the bit value.
Therefore, a valid Data Bit must have samples 8, 9 and 10 at the same value to prevent the Noise Flag getting set.
Figure 49. Bit Sampling in Reception Mode
Doc ID 6996 Rev 5
75/139
ST7262xxx
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
10.5.5 Low Power Modes 10.5.6 Interrupts
Mode Description
No effect on SCI.
WAIT
HALT
SCI interrupts cause the device to exit from Wait mode.
SCI registers are frozen. In Halt mode, the SCI stops transmitting/re-
ceiving until Halt mode is exited.
The SCI interrupt events are connected to the same interrupt vector.
These events generate an interrupt if the corre­sponding Enable Control Bit is set and the inter­rupt mask in the CC register is reset (RIM instruc­tion).
Interrupt Event
Transmit Data Register Empty
Transmission Com­plete
Received Data Ready to be Read
Overrun Error Detect­ed
Idle Line Detected IDLE ILIE Yes No Parity Error PE PIE Yes No
Enable
Event
Control
Flag
TDRE TIE Yes No
TC TCIE Yes No
RDRF
OR Yes No
Bit
RIE
Exit
from
Wait
Yes No
Exit
from
Halt
76/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
10.5.7 Register Description STATUS REGISTER (SCISR)
Read Only
Note: The IDLE bit is not set again until the RDRF bit has been set itself (that is, a new idle line oc­curs).
Reset Value: 1100 0000 (C0h)
70
TDRE TC RDRF IDLE OR NF FE PE
Bit 3 = OR Overrun error. This bit is set by hardware when the word currently being received in the shift register is ready to be transferred into the RDR register while RDRF = 1.
An interrupt is generated if RIE = 1 in the SCICR2 Bit 7 = TDRE Transmit data register empty. This bit is set by hardware when the content of the TDR register has been transferred into the shift register. An interrupt is generated if the TIE bit = 1 in the SCICR2 register. It is cleared by a software sequence (an access to the SCISR register fol­lowed by a write to the SCIDR register). 0: Data is not transferred to the shift register
register. It is cleared by a software sequence (an
access to the SCISR register followed by a read to
the SCIDR register).
0: No Overrun error
1: Overrun error is detected
Note: When this bit is set RDR register content is
not lost but the shift register is overwritten. 1: Data is transferred to the shift register
Note: Data is not transferred to the shift register unless the TDRE bit is cleared.
Bit 2 = NF Noise flag.
This bit is set by hardware when noise is detected
on a received frame. It is cleared by a software se-
quence (an access to the SCISR register followed Bit 6 = TC Transmission complete. This bit is set by hardware when transmission of a frame containing Data is complete. An interrupt is generated if TCIE = 1 in the SCICR2 register. It is cleared by a software sequence (an access to the SCISR register followed by a write to the SCIDR register).
by a read to the SCIDR register).
0: No noise is detected
1: Noise is detected
Note: This bit does not generate interrupt as it ap-
pears at the same time as the RDRF bit which it-
self generates an interrupt. 0: Transmission is not complete
1: Transmission is complete Note: TC is not set after the transmission of a Pre-
amble or a Break.
Bit 5 = RDRF Received data ready flag. This bit is set by hardware when the content of the RDR register has been transferred to the SCIDR register. An interrupt is generated if RIE = 1 in the SCICR2 register. It is cleared by a software se­quence (an access to the SCISR register followed by a read to the SCIDR register). 0: Data is not received 1: Received data is ready to be read
Bit 1 = FE Framing error.
This bit is set by hardware when a de-synchroniza-
tion, excessive noise or a break character is de-
tected. It is cleared by a software sequence (an
access to the SCISR register followed by a read to
the SCIDR register).
0: No Framing error is detected
1: Framing error or break character is detected
Note: This bit does not generate interrupt as it ap-
pears at the same time as the RDRF bit which it-
self generates an interrupt. If the word currently
being transferred causes both frame error and
overrun error, it will be transferred and only the OR
bit will be set.
ST7262xxx
Bit 4 = IDLE Idle line detect. This bit is set by hardware when a Idle Line is de­tected. An interrupt is generated if the ILIE = 1 in the SCICR2 register. It is cleared by a software se­quence (an access to the SCISR register followed by a read to the SCIDR register). 0: No Idle Line is detected 1: Idle Line is detected
Bit 0 = PE Parity error.
This bit is set by hardware when a parity error oc-
curs in receiver mode. It is cleared by a software
sequence (a read to the status register followed by
an access to the SCIDR data register). An inter-
rupt is generated if PIE = 1 in the SCICR1 register.
0: No parity error
1: Parity error
Doc ID 6996 Rev 5
77/139
ST7262xxx
SERIAL COMMUNICATIONS INTERFACE (Cont’d) CONTROL REGISTER 1 (SCICR1)
Read/Write Reset Value: x000 0000 (x0h)
70
R8 T8 SCID M WAKE PCE PS PIE
Bit 7 = R8 Receive data bit 8. This bit is used to store the 9th bit of the received word when M = 1.
Bit 6 = T8 Transmit data bit 8. This bit is used to store the 9th bit of the transmit­ted word when M = 1.
Bit 5 = SCID Disabled for low power consumption When this bit is set the SCI prescalers and outputs are stopped and the end of the current byte trans­fer in order to reduce power consumption.This bit is set and cleared by software. 0: SCI enabled 1: SCI prescaler and outputs disabled
Bit 4 = M Word length. This bit determines the word length. It is set or cleared by software. 0: 1 Start bit, 8 Data bits, 1 Stop bit 1: 1 Start bit, 9 Data bits, 1 Stop bit
Note: The M bit must not be modified during a data transfer (both transmission and reception).
Bit 3 = WAKE Wake-Up method.
This bit determines the SCI Wake-Up method, it is
set or cleared by software.
0: Idle Line
1: Address Mark
Bit 2 = PCE Parity control enable.
This bit selects the hardware parity control (gener-
ation and detection). When the parity control is en-
abled, the computed parity is inserted at the MSB
position (9th bit if M = 1; 8th bit if M = 0) and parity
is checked on the received data. This bit is set and
cleared by software. Once it is set, PCE is active
after the current byte (in reception and in transmis-
sion).
0: Parity control disabled
1: Parity control enabled
Bit 1 = PS Parity selection.
This bit selects the odd or even parity when the
parity generation/detection is enabled (PCE bit
set). It is set and cleared by software. The parity is
selected after the current byte.
0: Even parity
1: Odd parity
Bit 0 = PIE Parity interrupt enable.
This bit enables the interrupt capability of the hard-
ware parity control when a parity error is detected
(PE bit set). It is set and cleared by software.
0: Parity error interrupt disabled
1: Parity error interrupt enabled.
78/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d) CONTROL REGISTER 2 (SCICR2)
Read/Write Reset Value: 0000 0000 (00h)
70
Notes:
– During transmission, a “0” pulse on the TE bit
(“0” followed by “1”) sends a preamble (idle line) after the current word.
– When TE is set there is a 1 bit-time delay before
the transmission starts.
TIE TCIE RIE ILIE TE RE RWU
SBK
CAUTION: The TDO pin is free for general pur-
pose I/O only when the TE and RE bits are both Bit 7 = TIE Transmitter interrupt enable.
cleared (or if TE is never set). This bit is set and cleared by software. 0: Interrupt is inhibited 1: An SCI interrupt is generated whenever
TDRE=1 in the SCISR register
Bit 6 = TCIE Transmission complete interrupt ena-
ble
This bit is set and cleared by software. 0: Interrupt is inhibited 1: An SCI interrupt is generated whenever TC=1 in
the SCISR register
Bit 5 = RIE Receiver interrupt enable. This bit is set and cleared by software. 0: Interrupt is inhibited 1: An SCI interrupt is generated whenever OR=1
or RDRF=1 in the SCISR register
Bit 2 = RE Receiver enable.
This bit enables the receiver. It is set and cleared
by software.
0: Receiver is disabled
1: Receiver is enabled and begins searching for a
start bit
Bit 1 = RWU Receiver wake-up.
This bit determines if the SCI is in mute mode or
not. It is set and cleared by software and can be
cleared by hardware when a wake-up sequence is
recognized.
0: Receiver in Active mode
1: Receiver in Mute mode
Note: Before selecting Mute mode (setting the
RWU bit), the SCI must receive some data first,
otherwise it cannot function in Mute mode with Bit 4 = ILIE Idle line interrupt enable.
wake-up by idle line detection. This bit is set and cleared by software.
0: Interrupt is inhibited 1: An SCI interrupt is generated whenever IDLE=1
in the SCISR register.
Bit 0 = SBK Send break.
This bit set is used to send break characters. It is
set and cleared by software.
0: No break character is transmitted Bit 3 = TE Transmitter enable. This bit enables the transmitter. It is set and cleared by software.
0: Transmitter is disabled 1: Transmitter is enabled
1: Break characters are transmitted
Note: If the SBK bit is set to “1” and then to “0”, the
transmitter sends a BREAK word at the end of the
current word.
ST7262xxx
Doc ID 6996 Rev 5
79/139
ST7262xxx
SERIAL COMMUNICATIONS INTERFACE (Cont’d) DATA REGISTER (SCIDR)
Read/Write Reset Value: Undefined Contains the Received or Transmitted data char-
acter, depending on whether it is read from or writ­ten to.
70
DR7 DR6 DR5 DR4 DR3 DR2 DR1 DR0
The Data register performs a double function (read and write) since it is composed of two registers, one for transmission (TDR) and one for reception (RDR). The TDR register provides the parallel interface between the internal bus and the output shift reg­ister (see Figure 46). The RDR register provides the parallel interface between the input shift register and the internal bus (see Figure 46).
Bits 5:3 = SCT[2:0] SCI Transmitter rate divisor
These 3 bits, in conjunction with the SCP1 & SCP0
bits define the total division applied to the bus
clock to yield the transmit rate clock in convention-
al Baud Rate Generator mode.
TR dividing factor SCT2 SCT1 SCT0
1000 2001 4010
8011 16 1 0 0 32 1 0 1 64 1 1 0
128 1 1 1
Bits 2:0 = SCR[2:0] SCI Receiver rate divisor. These 3 bits, in conjunction with the SCP[1:0] bits define the total division applied to the bus clock to yield the receive rate clock in conventional Baud Rate Generator mode.
BAUD RATE REGISTER (SCIBRR)
Read/Write Reset Value: 0000 0000 (00h)
70
SCP1 SCP0 SCT2 SCT1 SCT0 SCR2 SCR1 SCR0
Bits 7:6 = SCP[1:0] First SCI Prescaler These 2 prescaling bits allow several standard
RR Dividing factor SCR2 SCR1 SCR0
1000
2001
4010
8011 16 1 0 0 32 1 0 1 64 1 1 0
128 1 1 1
clock division ranges:
PR Prescaling factor SCP1 SCP0
100 301 410
13 1 1
80/139
Doc ID 6996 Rev 5
SERIAL COMMUNICATIONS INTERFACE (Cont’d) EXTENDED RECEIVE PRESCALER DIVISION
REGISTER (SCIERPR)
Read/Write Reset Value: 0000 0000 (00h) Allows setting of the Extended Prescaler rate divi-
sion factor for the receive circuit.
ST7262xxx
EXTENDED TRANSMIT PRESCALER DIVISION REGISTER (SCIETPR)
Read/Write Reset Value:0000 0000 (00h) Allows setting of the External Prescaler rate divi-
sion factor for the transmit circuit.
70
ERPR7ERPR6ERPR5ERPR4ERPR3ERPR2ERPR1ERPR
0
Bits 7:0 = ERPR[7:0] 8-bit Extended Receive
Prescaler Register.
The extended Baud Rate Generator is activated when a value different from 00h is stored in this register. Therefore the clock frequency issued from the 16 divider (see Figure 48) is divided by the binary factor set in the SCIERPR register (in the range 1 to 255).
The extended baud rate generator is not used af­ter a reset.
70
ETPR7ETPR6ETPR5ETPR4ETPR3ETPR2ETPR1ETPR
Bits 7:0 = ETPR[7:0] 8-bit Extended Transmit
Prescaler Register.
The extended Baud Rate Generator is activated when a value different from 00h is stored in this register. Therefore the clock frequency issued from the 16 divider (see Figure 48) is divided by the binary factor set in the SCIETPR register (in the range 1 to 255).
The extended baud rate generator is not used af­ter a reset.
Table 21. Baudrate Selection
Conditions
Symbol Parameter
f
Tx
Communication frequency 8 MHz
f
Rx
f
CPU
Accuracy vs
Standard
~0.16%
~0.79%
Prescaler
Conventional Mode TR (or RR)=128, PR=13 TR (or RR)= 32, PR=13 TR (or RR)= 16, PR=13 TR (or RR)= 8, PR=13 TR (or RR)= 4, PR=13 TR (or RR)= 16, PR= 3 TR (or RR)= 2, PR=13 TR (or RR)= 1, PR=13
Extended Mode ETPR (or ERPR) = 35, TR (or RR)= 1, PR=1
Standard
1200 2400 4800
9600 10400 19200 38400
14400 ~14285.71
300
Baud
Rate
~300.48 ~1201.92 ~2403.84 ~4807.69 ~9615.38
~10416.67 ~19230.77 ~38461.54
0
Unit
Hz
Doc ID 6996 Rev 5
81/139
ST7262xxx
SERIAL COMMUNICATIONS INTERFACE (Cont’d)
Table 22. SCI Register Map and Reset Values
Address
(Hex.)
1D
1E
20
21
22
23
24
Register
Name
SCIERPR
Reset Value
SCIETPR
Reset Value
SCISR
Reset Value
SCIDR
Reset Value
SCIBRR
Reset Value
SCICR1
Reset Value
SCICR2
Reset Value
76543210
ERPR70ERPR60ERPR50ERPR40ERPR30ERPR20ERPR10ERPR0
0
ETPR70ETPR60ETPR50ETPR40ETPR30ETPR20ETPR10ETPR0
0
TDRE
1
DR7
x
SCP1
0
R8
x
TIE
0
TC
1
DR6
x
SCP00SCT20SCT1
T8
0
TCIE
0
RDRF0IDLE
0
DR5
x
SCID
0
RIE
0
DR4
x
0
M
0
ILIE
0
OR
0
DR3
x
SCT00SCR2
WAKE
0
TE
0
NF
0
DR2
x
0
PCE
0
RE
0
FE
0
DR1
x
SCR10SCR0
PS
0
RWU
0
PE
0
DR0
x
0
PIE
0
SBK
0
82/139
Doc ID 6996 Rev 5

10.6 USB INTERFACE (USB)

CPU
MEMORY
Transceiver
3.3V Voltage Regulator
SIE
ENDPOINT
DMA
INTERRUPT
Address,
and interrupts
USBDM
USBDP
USBVCC
6 MHz
REGISTERS
REGISTERS
data buses
USBGND
ST7262xxx
10.6.1 Introduction
The USB Interface implements a low-speed func­tion interface between the USB and the ST7 mi­crocontroller. It is a highly integrated circuit which includes the transceiver, 3.3 voltage regulator, SIE and DMA. No external components are needed apart from the external pull-up on USBDM for low speed recognition by the USB host. The use of DMA architecture allows the endpoint definition to be completely flexible. Endpoints can be config­ured by software as in or out.
10.6.2 Main Features
USB Specification Version 1.1 Compliant
Supports Low-Speed USB Protocol
Two or Three Endpoints (including default one)
depending on the device (see device feature list and register map)
CRC generation/checking, NRZI encoding/
decoding and bit-stuffing
USB Suspend/Resume operations
DMA Data transfers
On-Chip 3.3V Regulator
On-Chip USB Transceiver
10.6.3 Functional Description
The block diagram in Figure 50, gives an overview of the USB interface hardware.
For general information on the USB, refer to the “Universal Serial Bus Specifications” document available at http//:www.usb.org.
Serial Interface Engine
The SIE (Serial Interface Engine) interfaces with the USB, via the transceiver.
The SIE processes tokens, handles data transmis­sion/reception, and handshaking as required by the USB standard. It also performs frame format­ting, including CRC generation and checking.
Endpoints
The Endpoint registers indicate if the microcon­troller is ready to transmit/receive, and how many bytes need to be transmitted.
DMA
When a token for a valid Endpoint is recognized by the USB interface, the related data transfer takes place, using DMA. At the end of the transaction, an interrupt is generated.
Interrupts
By reading the Interrupt Status register, applica­tion software can know which USB event has oc­curred.
Figure 50. USB Block Diagram
Doc ID 6996 Rev 5
83/139
ST7262xxx
Endpoint 0 RX
Endpoint 0 TX
Endpoint 2 RX
Endpoint 1 TX
000000
000111
001000
001111
010000
010111
011000
011111
DA15-6,000000
Endpoint 1 RX
Endpoint 2 TX
100000
100111
101000
101111
USB INTERFACE (Cont’d)
10.6.4 Register Description DMA ADDRESS REGISTER (DMAR)
Read / Write Reset Value: Undefined
70
DA15 DA14 DA13 DA12 DA11 DA10 DA9 DA8
Bits 7:0=DA[15:8] DMA address bits 15-8. Software must write the start address of the DMA memory area whose most significant bits are given by DA15-DA6. The remaining 6 address bits are set by hardware. See the description of the IDR register and Figure 51.
INTERRUPT/DMA REGISTER (IDR)
Read / Write Reset Value: xxxx 0000 (x0h)
70
DA7 DA6 EP1 EP0 CNT3 CNT2 CNT1 CNT0
Bits 7:6 = DA[7:6] DMA address bits 7-6. Software must reset these bits. See the descrip­tion of the DMAR register and Figure 51.
Bits 5:4 = EP[1:0] Endpoint number (read-only). These bits identify the endpoint which required at­tention. 00: Endpoint 0 01: Endpoint 1 10: Endpoint 2
When a CTR interrupt occurs (see register ISTR) the software should read the EP bits to identify the endpoint which has sent or received a packet.
Figure 51. DMA Buffers
84/139
Bits 3:0 = CNT[3:0] Byte count (read only). This field shows how many data bytes have been received during the last data reception.
Note: Not valid for data transmission.
Doc ID 6996 Rev 5
USB INTERFACE (Cont’d) PID REGISTER (PIDR)
Read only Reset Value: xx00 0000 (x0h)
ST7262xxx
INTERRUPT STATUS REGISTER (ISTR)
Read / Write Reset Value: 0000 0000 (00h)
70
TP3 TP2 0 0 0
RX_ SEZ
RXD 0
70
SUSP DOVR CTR ERR IOVR ESUSP RESET SOF
When an interrupt occurs these bits are set by
Bits 7:6 = TP[3:2] Token PID bits 3 & 2. USB token PIDs are encoded in four bits. TP[3:2] correspond to the variable token PID bits 3 & 2.
hardware. Software must read them to determine the interrupt type and clear them after servicing.
Note: These bits cannot be set by software.
Note: PID bits 1 & 0 have a fixed value of 01.
When a CTR interrupt occurs (see register ISTR) the software should read the TP3 and TP2 bits to retrieve the PID name of the token received. The USB standard defines TP bits as:
TP3 TP2 PID Name
00 OUT 10 IN 11 SETUP
Bit 7 = SUSP Suspend mode request. This bit is set by hardware when a constant idle state is present on the bus line for more than 3 ms, indicating a suspend mode request from the USB bus. The suspend request check is active immedi­ately after each USB reset event and its disabled by hardware when suspend mode is forced (FSUSP bit of CTLR register) until the end of resume sequence.
Bits 5:3 Reserved. Forced by hardware to 0.
Bit 6 = DOVR DMA over/underrun.
Bit 2 = RX_SEZ Received single-ended zero This bit indicates the status of the RX_SEZ trans­ceiver output. 0: No SE0 (single-ended zero) state
This bit is set by hardware if the ST7 processor can’t answer a DMA request in time. 0: No over/underrun detected 1: Over/underrun detected
1: USB lines are in SE0 (single-ended zero) state
Bit 5 = CTR Correct Transfer. This bit is set by
Bit 1 = RXD Received data 0: No K-state 1: USB lines are in K-state
This bit indicates the status of the RXD transceiver output (differential receiver output).
Note: If the environment is noisy, the RX_SEZ and RXD bits can be used to secure the application. By interpreting the status, software can distinguish a valid End Suspend event from a spurious wake-up due to noise on the external USB line. A valid End Suspend is followed by a Resume or Reset se­quence. A Resume is indicated by RXD=1, a Re­set is indicated by RX_SEZ=1.
hardware when a correct transfer operation is per­formed. The type of transfer can be determined by looking at bits TP3-TP2 in register PIDR. The End­point on which the transfer was made is identified by bits EP1-EP0 in register IDR. 0: No Correct Transfer detected 1: Correct Transfer detected
Note: A transfer where the device sent a NAK or STALL handshake is considered not correct (the host only sends ACK handshakes). A transfer is considered correct if there are no errors in the PID and CRC fields, if the DATA0/DATA1 PID is sent as expected, if there were no data overruns, bit stuffing or framing errors.
Bit 0 = Reserved. Forced by hardware to 0.
Bit 4 = ERR Error. This bit is set by hardware whenever one of the er­rors listed below has occurred: 0: No error detected 1: Timeout, CRC, bit stuffing or nonstandard
framing error detected
Doc ID 6996 Rev 5
85/139
ST7262xxx
USB INTERFACE (Cont’d)
Bit 3 = IOVR Interrupt overrun. This bit is set when hardware tries to set ERR, or SOF before they have been cleared by software. 0: No overrun detected 1: Overrun detected
Bit 2 = ESUSP End suspend mode. This bit is set by hardware when, during suspend mode, activity is detected that wakes the USB in­terface up from suspend mode.
This interrupt is serviced by a specific vector, in or­der to wake up the ST7 from HALT mode. 0: No End Suspend detected 1: End Suspend detected
of each bit, please refer to the corresponding bit description in ISTR.
CONTROL REGISTER (CTLR)
Read / Write Reset Value: 0000 0110 (06h)
70
0 0 0 0 RESUME PDWN FSUSP FRES
Bits 7:4 = Reserved. Forced by hardware to 0.
Bit 1 = RESET USB reset. This bit is set by hardware when the USB reset se­quence is detected on the bus. 0: No USB reset signal detected 1: USB reset signal detected
Note: The DADDR, EP0RA, EP0RB, EP1RA, EP1RB, EP2RA and EP2RB registers are reset by a USB reset.
Bit 0 = SOF Start of frame. This bit is set by hardware when a low-speed SOF indication (keep-alive strobe) is seen on the USB bus. It is also issued at the end of a resume se­quence. 0: No SOF signal detected 1: SOF signal detected
Note: To avoid spurious clearing of some bits, it is recommended to clear them using a load instruc­tion where all bits which must not be altered are set, and all bits to be cleared are reset. Avoid read­modify-write instructions like AND, XOR..
INTERRUPT MASK REGISTER (IMR)
Read / Write Reset Value: 0000 0000 (00h)
Bit 3 = RESUME Resume. This bit is set by software to wake-up the Host when the ST7 is in suspend mode. 0: Resume signal not forced 1: Resume signal forced on the USB bus.
Software should clear this bit after the appropriate delay.
Bit 2 = PDWN Power down. This bit is set by software to turn off the 3.3V on­chip voltage regulator that supplies the external pull-up resistor and the transceiver. 0: Voltage regulator on 1: Voltage regulator off
Note: After turning on the voltage regulator, soft­ware should allow at least 3 µs for stabilisation of the power supply before using the USB interface.
Bit 1 = FSUSP Force suspend mode. This bit is set by software to enter Suspend mode. The ST7 should also be halted allowing at least 600 ns before issuing the HALT instruction. 0: Suspend mode inactive 1: Suspend mode active
When the hardware detects USB activity, it resets this bit (it can also be reset by software).
70
SUSPMDOVRMCTRMERRMIOVRMESU
SPM
RES ETM
SOF
M
Bit 0 = FRES Force reset. This bit is set by software to force a reset of the USB interface, just as if a RESET sequence came from the USB. 0: Reset not forced
Bits 7:0 = These bits are mask bits for all interrupt condition bits included in the ISTR. Whenever one of the IMR bits is set, if the corresponding ISTR bit is set, and the I bit in the CC register is cleared, an
1: USB interface reset forced. The USB is held in RESET state until software
clears this bit, at which point a “USB-RESET” in­terrupt will be generated if enabled.
interrupt request is generated. For an explanation
86/139
Doc ID 6996 Rev 5
USB INTERFACE (Cont’d) DEVICE ADDRESS REGISTER (DADDR)
Read / Write Reset Value: 0000 0000 (00h)
Bit 6 = DTOG_TX Data Toggle, for transmission transfers. It contains the required value of the toggle bit (0=DATA0, 1=DATA1) for the next transmitted data packet. This bit is set by hardware at the re-
70
ception of a SETUP PID. DTOG_TX toggles only when the transmitter has received the ACK signal
0 ADD6 ADD5 ADD4 ADD3 ADD2 ADD1 ADD0
from the USB host. DTOG_TX and also DTOG_RX (see EPnRB) are normally updated by
Bit 7 = Reserved. Forced by hardware to 0.
hardware, at the receipt of a relevant PID. They can be also written by software.
ST7262xxx
Bits 6:0 = ADD[6:0] Device address, 7 bits. Software must write into this register the address
sent by the host during enumeration. Note: This register is also reset when a USB reset
is received from the USB bus or forced through bit FRES in the CTLR register.
ENDPOINT n REGISTER A (EPnRA)
Read / Write Reset Value: 0000 xxxx (0xh)
70
ST_
DTOG
OUT
_TX
STAT _TX1
STAT
TBC3TBC2TBC1TBC
_TX0
0
Bits 5:4 = STAT_TX[1:0] Status bits, for transmis-
sion transfers.
These bits contain the information about the end­point status, which are listed below:
STAT_TX1 STAT_TX0 Meaning
00
01
10
11
DISABLED: transmission transfers cannot be executed.
STALL: the endpoint is stalled and all transmission requests result in a STALL handshake.
NAK: the endpoint is naked and all transmission requests result in a NAK handshake.
VALID: this endpoint is ena­bled for transmission.
These bits are written by software. Hardware sets
These registers (EP0RA, EP1RA and EP2RA) are used for controlling data transmission. They are also reset by the USB bus reset.
Note: Endpoint 2 and the EP2RA register are not
the STAT_TX bits to NAK when a correct transfer has occurred (CTR=1) related to a IN or SETUP transaction addressed to this endpoint; this allows the software to prepare the next set of data to be transmitted.
available on some devices (see device feature list and register map).
Bits 3:0 = TBC[3:0] Transmit byte count for End- point n.
Bit 7 = ST_OUT Status out. This bit is set by software to indicate that a status out packet is expected: in this case, all nonzero OUT data transfers on the endpoint are STALLed instead of being ACKed. When ST_OUT is reset, OUT transactions can have any number of bytes, as needed.
Before transmission, after filling the transmit buff­er, software must write in the TBC field the trans­mit packet size expressed in bytes (in the range 0-
8). Warning: Any value outside the range 0-8 will in-
duce undesired effects (such as continuous data transmission).
Doc ID 6996 Rev 5
87/139
ST7262xxx
USB INTERFACE (Cont’d) ENDPOINT n REGISTER B (EPnRB)
Read / Write Reset Value: 0000 xxxx (0xh)
70
CTRL
DTOG
_RX
STAT
_RX1
STAT
EA3 EA2 EA1 EA0
_RX0
These registers (EP1RB and EP2RB) are used for controlling data reception on Endpoints 1 and 2. They are also reset by the USB bus reset.
Note: Endpoint 2 and the EP2RB register are not available on some devices (see device feature list and register map).
Bit 7 = CTRL Control. This bit should be 0.
Note: If this bit is 1, the Endpoint is a control end­point. (Endpoint 0 is always a control Endpoint, but it is possible to have more than one control End­point).
Bit 6 = DTOG_RX Data toggle, for reception trans- fers. It contains the expected value of the toggle bit (0=DATA0, 1=DATA1) for the next data packet. This bit is cleared by hardware in the first stage (Setup Stage) of a control transfer (SETUP trans­actions start always with DATA0 PID). The receiv­er toggles DTOG_RX only if it receives a correct data packet and the packet’s data PID matches the receiver sequence bit.
STAT_RX1 STAT_RX0 Meaning
NAK: the endpoint is na-
10
ked and all reception re­quests result in a NAK handshake.
11
VALID: this endpoint is enabled for reception.
These bits are written by software. Hardware sets the STAT_RX bits to NAK when a correct transfer has occurred (CTR=1) related to an OUT or SET­UP transaction addressed to this endpoint, so the software has the time to elaborate the received data before acknowledging a new transaction.
Bits 3:0 = EA[3:0] Endpoint address. Software must write in this field the 4-bit address used to identify the transactions directed to this endpoint. Usually EP1RB contains “0001” and EP2RB contains “0010”.
ENDPOINT 0 REGISTER B (EP0RB)
Read / Write Reset Value: 1000 0000 (80h)
70
DTOGRXSTAT
1
RX1
STAT
RX0
0000
This register is used for controlling data reception on Endpoint 0. It is also reset by the USB bus re­set.
Bits 5:4 = STAT_RX [1:0] Status bits, for reception
transfers.
These bits contain the information about the end­point status, which are listed below:
STAT_RX1 STAT_RX0 Meaning
DISABLED: reception
00
transfers cannot be exe­cuted.
STALL: the endpoint is
01
stalled and all reception requests result in a STALL handshake.
88/139
Bit 7 = Forced by hardware to 1.
Bits 6:4 = Refer to the EPnRB register for a de­scription of these bits.
Bits 3:0 = Forced by hardware to 0.
Doc ID 6996 Rev 5
USB INTERFACE (Cont’d)
10.6.5 Programming Considerations
The interaction between the USB interface and the application program is described below. Apart from system reset, action is always initiated by the USB interface, driven by one of the USB events associated with the Interrupt Status Register (IS­TR) bits.
10.6.5.1 Initializing the Registers
At system reset, the software must initialize all reg­isters to enable the USB interface to properly gen­erate interrupts and DMA requests.
1. Initialize the DMAR, IDR, and IMR registers (choice of enabled interrupts, address of DMA buffers). Refer the paragraph titled initializing the DMA Buffers.
2. Initialize the EP0RA and EP0RB registers to enable accesses to address 0 and endpoint 0 to support USB enumeration. Refer to the para­graph titled Endpoint Initialization.
3. When addresses are received through this channel, update the content of the DADDR.
4. If needed, write the endpoint numbers in the EA fields in the EP1RB and EP2RB register.
10.6.5.2 Initializing DMA buffers
The DMA buffers are a contiguous zone of memo­ry whose maximum size is 48 bytes. They can be placed anywhere in the memory space to enable the reception of messages. The 10 most signifi­cant bits of the start of this memory area are spec­ified by bits DA15-DA6 in registers DMAR and IDR, the remaining bits are 0. The memory map is shown in Figure 51.
Each buffer is filled starting from the bottom (last 3 address bits=000) up.
10.6.5.3 Endpoint Initialization
To be ready to receive: Set STAT_RX to VALID (11b) in EP0RB to enable
reception. To be ready to transmit:
1. Write the data in the DMA transmit buffer.
2. In register EPnRA, specify the number of bytes to be transmitted in the TBC field
3. Enable the endpoint by setting the STAT_TX bits to VALID (11b) in EPnRA.
Note: Once transmission and/or reception are en­abled, registers EPnRA and/or EPnRB (respec­tively) must not be modified by software, as the hardware can change their value on the fly.
When the operation is completed, they can be ac­cessed again to enable a new operation.
10.6.5.4 Interrupt Handling Start of Frame (SOF)
The interrupt service routine may monitor the SOF events for a 1 ms synchronization event to the USB bus. This interrupt is generated at the end of a resume sequence and can also be used to de­tect this event.
USB Reset (RESET)
When this event occurs, the DADDR register is re­set, and communication is disabled in all endpoint registers (the USB interface will not respond to any packet). Software is responsible for reenabling endpoint 0 within 10 ms of the end of reset. To do this, set the STAT_RX bits in the EP0RB register to VALID.
Suspend (SUSP)
The CPU is warned about the lack of bus activity for more than 3 ms, which is a suspend request. The software should set the USB interface to sus­pend mode and execute an ST7 HALT instruction to meet the USB-specified power constraints.
End Suspend (ESUSP)
The CPU is alerted by activity on the USB, which causes an ESUSP interrupt. The ST7 automatical­ly terminates HALT mode.
Correct Transfer (CTR)
1. When this event occurs, the hardware automat­ically sets the STAT_TX or STAT_RX to NAK. Note: Every valid endpoint is NAKed until soft­ware clears the CTR bit in the ISTR register, independently of the endpoint number addressed by the transfer which generated the CTR interrupt. Note: If the event triggering the CTR interrupt is a SETUP transaction, both STAT_TX and STAT_RX are set to NAK.
2. Read the PIDR to obtain the token and the IDR to get the endpoint number related to the last transfer. Note: When a CTR interrupt occurs, the TP3­TP2 bits in the PIDR register and EP1-EP0 bits in the IDR register stay unchanged until the CTR bit in the ISTR register is cleared.
3. Clear the CTR bit in the ISTR register.
Doc ID 6996 Rev 5
89/139
USB INTERFACE (Cont’d)
Table 23. USB Register Map and Reset Values
Address
(Hex.)
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
Register
Name
PIDR Reset Value
DMAR Reset Value
IDR Reset Value
ISTR Reset Value
IMR Reset Value
CTLR Reset Value
DADDR Reset Value
EP0RA Reset Value
EP0RB Reset Value
EP1RA Reset Value
EP1RB Reset Value
EP2RA Reset Value
EP2RB Reset Value
7 6 5 4 3210
TP3
x
DA15
x
DA7
x
SUSP
0
SUSPM0DOVRM
0 0
0 0
ST_OUT0DTOG_TX0STAT_TX10STAT_TX00TBC3
1 1
ST_OUT0DTOG_TX0STAT_TX10STAT_TX00TBC3
CTRL0DTOG_RX
ST_OUT0DTOG_TX0STAT_TX10STAT_TX00TBC3
CTRL0DTOG_RX0STAT_RX10STAT_RX00EA3
TP2
x
DA14
x
DA6
x
DOVR
0
0
0 0
ADD6
0
DTOG_RX0STAT_RX10STAT_RX0
0
0 0
DA13
x
EP1
x
CTR
0
CTRM
0
0 0
ADD5
0
STAT_RX10STAT_RX00EA3
0
0
DA12
x
EP0
x
ERR
0
ERRM
0
0
0
ADD4
0
0
0 0
DA11
x
CNT3
0
IOVR0ESUSP0RESET
IOVRM0ESUSPM0RESETM0SOFM
RESUME0PDWN1FSUSP1FRES
ADD3
0
x
0
x
x
x
x
RX_SEZ0RXD
0
DA10
x
CNT2
0
ADD2
0
TBC2
x
0
0
TBC2
x
EA2
x
TBC2
x
EA2
x
0
DA9
x
CNT1
0
0
ADD1
0
TBC1
x
0
0
TBC1
x
EA1
x
TBC1
x
EA1
x
0
0
DA8
x
CNT0
0
SOF
0
0
0
ADD0
0
TBC0
x
0
0
TBC0
x
EA0
x
TBC0
x
EA0
x
90/139
Doc ID 6996 Rev 5

10.7 10-BIT A/D CONVERTER (ADC)

10.7.1 Introduction
The on-chip Analog to Digital Converter (ADC) pe­ripheral is a 10-bit, successive approximation con­verter with internal sample and hold circuitry. This peripheral has up to 8 multiplexed analog input channels (refer to device pin out description) that allow the peripheral to convert the analog voltage levels from up to 8 different sources.
The result of the conversion is stored in a 10-bit Data Register. The A/D converter is controlled through a Control/Status Register.
10.7.2 Main Features
10-bit conversion
Up to 8 channels with multiplexed input
Linear successive approximation
Data register (DR) which contains the results
Conversion complete status flag
Continuous or One-Shot mode
On/off bit (to reduce consumption)
The block diagram is shown in Figure 52.
10.7.3 Functional Description
10.7.3.1 Analog Power Supply
Depending on the MCU pin count, the package may feature separate V
DDA
and V
analog pow-
SSA
er supply pins. These pins supply power to the A/D converter cell and function as the high and low ref­erence voltages for the conversion. In smaller packages V
DDA
and V and the analog supply and reference pads are ternally
bonded to the VDD and VSS pins.
pins are not available
SSA
in-
Separation of the digital and analog power pins al­low board designers to improve A/D performance. Conversion accuracy can be impacted by voltage drops and noise in the event of heavily loaded or badly decoupled power supply lines.
10.7.3.2 PCB Design Guidelines
To obtain best results, some general design and layout rules should be followed when designing the application PCB to shield the noise-sensitive, analog physical interface from noise-generating CMOS logic signals.
– Use separate digital and analog planes. The an-
alog ground plane should be connected to the
digital ground plane via a single point on the PCB. The analog power plane should be con­nected to the digital power plane via an RC net­work.
– Filter power to the analog power planes. The
best solution is to connect a 0.1µF capacitor, with good high frequency characteristics, between
and V
V
DDA
to the V
DDA
and place it as close as possible
SSA
and V
pins and connect the ana-
SSA
log and digital power supplies in a star network. Do not use a resistor, as V
used as a refer-
DDA is
ence voltage by the A/D converter and resist­ance would cause a voltage drop and a loss of accuracy.
– Properly place components and route the signal
traces on the PCB to shield the analog inputs. Analog signals paths should run over the analog ground plane and be as short as possible. Isolate analog signal from digital signals that may switch while the analog inputs are being sampled by the A/D converter. Do not toggle digital outputs on the same I/O port as the A/D input being convert­ed.
10.7.3.3 Digital A/D Conversion Result
The conversion is monotonic, meaning that the re­sult never decreases if the analog input does not and never increases if the analog input does not.
If the input voltage (V
) is greater than V
AIN
DDA
(high-level voltage reference) then the conversion result is FFh in the ADCDRMSB register and 03h in the ADCDRLSB register (without overflow indi­cation).
If the input voltage (V
) is lower than V
AIN
SSA
(low­level voltage reference) then the conversion result in the ADCDRMSB and ADCDRLSB registers is 00 00h.
The A/D converter is linear and the digital result of the conversion is stored in the ADCDRMSB and ADCDRLSB registers. The accuracy of the con­version is described in the Electrical Characteris­tics Section.
is the maximum recommended impedance
R
AIN
for an analog input signal. If the impedance is too high, this will result in a loss of accuracy due to leakage and sampling not being completed in the allotted time.
Doc ID 6996 Rev 5
91/139
10-BIT A/D CONVERTER (ADC) (Cont’d)
CS2 CS1EOC SPEED ADON ITE CS0
ADCCSR
AIN0
AIN1
ANALOG TO DIGITAL
CONVERTER
AINx
ANALOG
MUX
D4 D3D5D9 D8 D7 D6 D2
ADCDRMSB
3
DIV 2
f
ADC
f
CPU
D1 D0
ADCDRLSB
DIV 4
0
1
EOC Interrupt
00 0 0 00
ONE
SHOT
10.7.3.4 A/D Conversion
Conversion can be performed in One-Shot or Con­tinuous mode. Continuous mode is typically used for monitoring a single channel. One-shot mode should be used when the application requires in­puts from several channels.
ADC Configuration
The analog input ports must be configured as in­put, no pull-up, no interrupt. Refer to the «I/O ports» chapter. Using these pins as analog inputs does not affect the ability of the port to be read as a logic input.
In the ADCCSR register:
– Select the CS[2:0] bits to assign the analog
channel to convert.
ADC One-Shot Conversion mode
In the ADCCSR register:
1.Set the ONE SHOT bit to put the A/D converter in one shot mode.
Figure 52. ADC Block Diagram
2.Set the ADON bit to enable the A/D converter and to start the conversion. The EOC bit is kept low by hardware during the conversion.
Note: Changing the A/D channel during conver­sion will stop the current conversion and start con­version of the newly selected channel.
When a conversion is complete:
– The EOC bit is set by hardware. – An interrupt request is generated if the ITE bit
is set. – The ADON bit is reset by hardware. – The result is in the ADCDR registers.
To read the 10 bits, perform the following steps:
1. Wait for interrupt or poll the EOC bit
2. Read ADCDRLSB
3. Read ADCDRMSB The EOC bit is reset by hardware once the AD-
CDRMSB is read.
92/139
Doc ID 6996 Rev 5
10-BIT A/D CONVERTER (ADC) (Cont’d) To read only 8 bits, perform the following steps:
1. Wait for interrupt or poll the EOC bit
2. Read ADCDRMSB The EOC bit is reset by hardware once the AD-
CDRMSB is read. To start another conversion, user should set the
ADON bit once again.
ADC Continuous Conversion mode
In the ADCCSR register:
1.Reset the ONE SHOT bit to put the A/D con­verter in continuous mode.
2.Set the ADON bit to enable the A/D converter and to start the first conversion. From this time on, the ADC performs a continuous conversion of the selected channel.
Note: Changing the A/D channel during conver­sion will stop the current conversion and start con­version of the newly selected channel.
When a conversion is complete:
– The EOC bit is set by hardware. – An interrupt request is generated if the ITE bit
is set.
– The result is in the ADCDR registers and re-
mains valid until the next conversion has end­ed.
To read the 10 bits, perform the following steps:
1. Wait for interrupt or poll the EOC bit
2. Read ADCDRLSB
3. Read ADCDRMSB
The EOC bit is reset by hardware once the AD­CDRMSB is read.
To read only 8 bits, perform the following steps:
1. Wait for interrupt
2. Read ADCDRMSB
The EOC bit is reset by hardware once the AD­CDRMSB is read.
Changing the conversion channel
The application can change channels during con­version. In this case the current conversion is stopped and the A/D converter starts converting the newly selected channel.
ADCCR consistency
If an End Of Conversion event occurs after soft­ware has read the ADCDRLSB but before it has read the ADCDRMSB, there would be a risk that the two values read would belong to different sam­ples.
To guarantee consistency:
– The ADCDRMSB and the ADCDRLSB are
locked when the ADCCRLSB is read
– The ADCDRMSB and the ADCDRLSB are un-
locked when the MSB is read or when ADON is reset.
Thus, it is mandatory to read the ADCDRMSB just after reading the ADCDRLSB. This is especially important in continuous mode, as the ADCDR reg­ister will not be updated until the ADCDRMSB is read.
10.7.4 Low Power Modes Note: The A/D converter may be disabled by re-
setting the ADON bit. This feature allows reduced power consumption when no conversion is need­ed and between single shot conversions.
Mode Description
WAIT No effect on A/D Converter
A/D Converter disabled. After wakeup from Halt mode, the A/D
HALT
Converter requires a stabilisation time
(see Electrical Characteristics)
t
STAB
before accurate conversions can be performed.
10.7.5 Interrupts
Exit
from
Wait
Flag
Enable
Control
Bit
Interrupt Event
End of Conversion EOC ITE Yes No
Event
Exit
from
Halt
Note: The EOC interrupt event is connected to an
interrupt vector (see Interrupts chapter). It generates an interrupt if the ITE bit is set in the ADCCSR register and the interrupt mask in the CC register is reset (RIM instruction).
Doc ID 6996 Rev 5
93/139
10-BIT A/D CONVERTER (ADC) (Cont’d)
10.7.6 Register Description
CONTROL/STATUS REGISTER (ADCCSR)
Read/Write (Except bit 7 read only) Reset Value: 0000 0000 (00h)
70
EOC SPEED ADON ITE
ONE
SHOT
CS2 CS1 CS0
Bit 7 = EOC End of Conversion This bit is set by hardware. It is cleared by soft­ware reading the ADCDRMSB register. 0: Conversion is not complete 1: Conversion complete
Bit 2:0 = CS[2:0] Channel Selection These bits are set and cleared by software. They select the analog input to convert.
Channel* CS2 CS1 CS0
0000 1001 2010 3011 4100 5101 6110 7111
*The number of channels is device dependent. Refer to the device pinout description.
Bit 6 = SPEED ADC clock selection This bit is set and cleared by software. 0: f 1: f
ADC ADC
= f = f
CPU CPU
/2 /4
DATA REGISTER (ADCDRMSB)
Read Only
Reset Value: 0000 0000 (00h) Bit 5 = ADON A/D Converter on This bit is set and cleared by software or by hard-
70
ware after the end of a one shot conversion. 0: Disable ADC and stop conversion 1: Enable ADC and start conversion
D9 D8 D7 D6 D5 D4 D3 D2
Bit 4 = ITE Interrupt Enable This bit is set and cleared by software.
0: EOC Interrupt disabled 1: EOC Interrupt enabled
Bit 3 = ONESHOT One Shot Conversion Selection This bit is set and cleared by software. 0: Continuous conversion mode 1: One Shot conversion mode
Bit 7:0 = D[9:2] MSB of Analog Converted Value
This register contains the MSB of the converted
analog value.
DATA REGISTER (ADCDRLSB)
Read Only
Reset Value: 0000 0000 (00h)
70
000000D1D0
Bit 7:2 = Reserved. Forced by hardware to 0.
Bit 1:0 = D[1:0] LSB of Analog Converted Value
This register contains the LSB of the converted an-
alog value.
Note: please refer to Section 15 IMPORTANT
NOTES
94/139
Doc ID 6996 Rev 5

11 INSTRUCTION SET

11.1 CPU ADDRESSING MODES

The CPU features 17 different addressing modes which can be classified in seven main groups:
Addressing Mode Example
Inherent nop Immediate ld A,#$55 Direct ld A,$55 Indexed ld A,($55,X) Indirect ld A,([$55],X) Relative jrne loop Bit operation bset byte,#5
so, most of the addressing modes may be subdi-
vided in two submodes called long and short:
– Long addressing mode is more powerful be-
cause it can use the full 64 Kbyte address space, however it uses more bytes and more CPU cy­cles.
– Short addressing mode is less powerful because
it can generally only access page zero (0000h ­00FFh range), but the instruction size is more compact, and faster. All memory to memory in­structions use short addressing modes only (CLR, CPL, NEG, BSET, BRES, BTJT, BTJF, INC, DEC, RLC, RRC, SLL, SRL, SRA, SWAP)
The ST7 Assembler optimizes the use of long and
short addressing modes. The CPU Instruction set is designed to minimize
the number of bytes required per instruction: To do
Table 24. CPU Addressing Mode Overview
Mode Syntax Destination
Inherent nop + 0
Immediate ld A,#$55 + 1
Short Direct ld A,$10 00..FF + 1
Pointer
Address
(Hex.)
Pointer Size
(Hex.)
Length
(Bytes)
Long Direct ld A,$1000 0000..FFFF + 2
No Offset Direct Indexed ld A,(X) 00..FF + 0
Short Direct Indexed ld A,($10,X) 00..1FE + 1
Long Direct Indexed ld A,($1000,X) 0000..FFFF + 2
Short Indirect ld A,[$10] 00..FF 00..FF byte + 2
Long Indirect ld A,[$10.w] 0000..FFFF 00..FF word + 2
Short Indirect Indexed ld A,([$10],X) 00..1FE 00..FF byte + 2
Long Indirect Indexed ld A,([$10.w],X) 0000..FFFF 00..FF word + 2
Relative Direct jrne loop PC+/-127 + 1
Relative Indirect jrne [$10] PC+/-127 00..FF byte + 2
Bit Direct bset $10,#7 00..FF + 1
Bit Indirect bset [$10],#7 00..FF 00..FF byte + 2
Bit Direct Relative btjt $10,#7,skip 00..FF + 2
Bit Indirect Relative btjt [$10],#7,skip 00..FF 00..FF byte + 3
Doc ID 6996 Rev 5
95/139
INSTRUCTION SET OVERVIEW (Cont’d)
11.1.1 Inherent
All Inherent instructions consist of a single byte. The opcode fully specifies all the required informa­tion for the CPU to process the operation.
Inherent Instruction Function
NOP No operation TRAP S/W Interrupt
WFI
HALT
RET Sub-routine Return IRET Interrupt Sub-routine Return SIM Set Interrupt Mask (level 3) RIM Reset Interrupt Mask (level 0) SCF Set Carry Flag RCF Reset Carry Flag RSP Reset Stack Pointer LD Load CLR Clear PUSH/POP Push/Pop to/from the stack INC/DEC Increment/Decrement TNZ Test Negative or Zero CPL, NEG 1 or 2 Complement MUL Byte Multiplication SLL, SRL, SRA, RLC,
RRC SWAP Swap Nibbles
Wait For Interrupt (Low Pow­er Mode)
Halt Oscillator (Lowest Power Mode)
Shift and Rotate Operations
11.1.2 Immediate
Immediate instructions have 2 bytes, the first byte contains the opcode, the second byte contains the operand value.
Immediate Instruction Function
LD Load CP Compare BCP Bit Compare AND, OR, XOR Logical Operations ADC, ADD, SUB, SBC Arithmetic Operations
11.1.3 Direct
In Direct instructions, the operands are referenced
by their memory address.
The direct addressing mode consists of two sub-
modes:
Direct (short)
The address is a byte, thus requires only one byte
after the opcode, but only allows 00 - FF address-
ing space.
Direct (long)
The address is a word, thus allowing 64 Kbyte ad-
dressing space, but requires 2 bytes after the op-
code.
11.1.4 Indexed (No Offset, Short, Long)
In this mode, the operand is referenced by its
memory address, which is defined by the unsigned
addition of an index register (X or Y) with an offset.
The indirect addressing mode consists of three
submodes:
Indexed (No Offset)
There is no offset, (no extra byte after the opcode),
and allows 00 - FF addressing space.
Indexed (Short)
The offset is a byte, thus requires only one byte af-
ter the opcode and allows 00 - 1FE addressing
space.
Indexed (long)
The offset is a word, thus allowing 64 Kbyte ad-
dressing space and requires 2 bytes after the op-
code.
11.1.5 Indirect (Short, Long)
The required data byte to do the operation is found
by its memory address, located in memory (point-
er).
The pointer address follows the opcode. The indi-
rect addressing mode consists of two submodes:
Indirect (short)
The pointer address is a byte, the pointer size is a
byte, thus allowing 00 - FF addressing space, and
requires 1 byte after the opcode.
Indirect (long)
The pointer address is a byte, the pointer size is a
word, thus allowing 64 Kbyte addressing space,
and requires 1 byte after the opcode.
96/139
Doc ID 6996 Rev 5
INSTRUCTION SET OVERVIEW (Cont’d)
11.1.6 Indirect Indexed (Short, Long)
This is a combination of indirect and short indexed addressing modes. The operand is referenced by its memory address, which is defined by the un­signed addition of an index register value (X or Y) with a pointer value located in memory. The point­er address follows the opcode.
The indirect indexed addressing mode consists of two submodes:
Indirect Indexed (Short)
The pointer address is a byte, the pointer size is a byte, thus allowing 00 - 1FE addressing space, and requires 1 byte after the opcode.
Indirect Indexed (Long)
The pointer address is a byte, the pointer size is a word, thus allowing 64 Kbyte addressing space, and requires 1 byte after the opcode.
Table 25. Instructions Supporting Direct, Indexed, Indirect and Indirect Indexed Addressing Modes
11.1.7 Relative mode (Direct, Indirect)
This addressing mode is used to modify the PC
register value, by adding an 8-bit signed offset to
it.
Available Relative
Direct/Indirect
Instructions
JRxx Conditional Jump CALLR Call Relative
Function
The relative addressing mode consists of two sub-
modes:
Relative (Direct)
The offset is following the opcode.
Relative (Indirect)
The offset is defined in memory, which address
follows the opcode.
Long and Short
Instructions
LD Load CP Compare AND, OR, XOR Logical Operations
ADC, ADD, SUB, SBC
BCP Bit Compare
Short Instructions Only Function
CLR Clear INC, DEC Increment/Decrement TNZ Test Negative or Zero CPL, NEG 1 or 2 Complement BSET, BRES Bit Operations
BTJT, BTJF
SLL, SRL, SRA, RLC, RRC
SWAP Swap Nibbles CALL, JP Call or Jump subroutine
Arithmetic Additions/Sub­stractions operations
Bit Test and Jump Opera­tions
Shift and Rotate Operations
Function
Doc ID 6996 Rev 5
97/139
INSTRUCTION SET OVERVIEW (Cont’d)

11.2 INSTRUCTION GROUPS

The ST7 family devices use an Instruction Set consisting of 63 instructions. The instructions may
Load and Transfer LD CLR Stack operation PUSH POP RSP Increment/Decrement INC DEC Compare and Tests CP TNZ BCP Logical operations AND OR XOR CPL NEG Bit Operation BSET BRES Conditional Bit Test and Branch BTJT BTJF Arithmetic operations ADC ADD SUB SBC MUL Shift and Rotates SLL SRL SRA RLC RRC SWAP SLA Unconditional Jump or Call JRA JRT JRF JP CALL CALLR NOP RET Conditional Branch JRxx Interruption management TRAP WFI HALT IRET Condition Code Flag modification SIM RIM SCF RCF
be subdivided into 13 main groups as illustrated in
the following table:
Using a prebyte
The instructions are described with one to four op­codes.
In order to extend the number of available op­codes for an 8-bit CPU (256 opcodes), three differ­ent prebyte opcodes are defined. These prebytes modify the meaning of the instruction they pre­cede.
The whole instruction becomes:
PC-2 End of previous instruction PC-1 Prebyte PC Opcode
PC+1 Additional word (0 to 2) according to the number of bytes required to compute the ef­fective address
These prebytes enable instruction in Y as well as indirect addressing modes to be implemented. They precede the opcode of the instruction in X or the instruction using direct addressing mode. The prebytes are:
PDY 90 Replace an X based instruction using immediate, direct, indexed, or inherent ad­dressing mode by a Y one.
PIX 92 Replace an instruction using di­rect, direct bit, or direct relative addressing mode to an instruction using the corresponding indirect addressing mode. It also changes an instruction using X indexed ad­dressing mode to an instruction using indirect X in­dexed addressing mode.
PIY 91 Replace an instruction using X in­direct indexed addressing mode by a Y one.
98/139
Doc ID 6996 Rev 5
INSTRUCTION SET OVERVIEW (Cont’d)
Mnemo Description Function/Example Dst Src I1 H I0 N Z C
ADC Add with Carry A = A + M + C A M H N Z C ADD Addition A = A + M A M H N Z C AND Logical And A = A . M A M N Z BCP Bit compare A, Memory tst (A . M) A M N Z BRES Bit Reset bres Byte, #3 M BSET Bit Set bset Byte, #3 M BTJF Jump if bit is false (0) btjf Byte, #3, Jmp1 M C BTJT Jump if bit is true (1) btjt Byte, #3, Jmp1 M C CALL Call subroutine CALLR Call subroutine relative CLR Clear reg, M 0 1 CP Arithmetic Compare tst(Reg - M) reg M N Z C CPL One Complement A = FFH-A reg, M N Z 1 DEC Decrement dec Y reg, M N Z HALT Halt 1 0 IRET Interrupt routine return Pop CC, A, X, PC I1 H I0 N Z C INC Increment inc X reg, M N Z JP Absolute Jump jp [TBL.w] JRA Jump relative always JRT Jump relative JRF Never jump jrf * JRIH Jump if ext. INT pin = 1 (ext. INT pin high) JRIL Jump if ext. INT pin = 0 (ext. INT pin low) JRH Jump if H = 1 H = 1 ? JRNH Jump if H = 0 H = 0 ? JRM Jump if I1:0 = 11 I1:0 = 11 ? JRNM Jump if I1:0 <> 11 I1:0 <> 11 ? JRMI Jump if N = 1 (minus) N = 1 ? JRPL Jump if N = 0 (plus) N = 0 ? JREQ Jump if Z = 1 (equal) Z = 1 ? JRNE Jump if Z = 0 (not equal) Z = 0 ? JRC Jump if C = 1 C = 1 ? JRNC Jump if C = 0 C = 0 ? JRULT Jump if C = 1 Unsigned < JRUGE Jump if C = 0 Jmp if unsigned >= JRUGT Jump if (C + Z = 0) Unsigned >
Doc ID 6996 Rev 5
99/139
INSTRUCTION SET OVERVIEW (Cont’d)
Mnemo Description Function/Example Dst Src I1 H I0 N Z C
JRULE Jump if (C + Z = 1) Unsigned <= LD Load dst <= src reg, M M, reg N Z MUL Multiply X,A = X * A A, X, Y X, Y, A 0 0 NEG Negate (2's compl) neg $10 reg, M N Z C NOP No Operation OR OR operation A = A + M A M N Z
POP Pop from the Stack
PUSH Push onto the Stack push Y M reg, CC RCF Reset carry flag C = 0 0 RET Subroutine Return RIM Enable Interrupts I1:0 = 10 (level 0) 1 0 RLC Rotate left true C C <= A <= C reg, M N Z C RRC Rotate right true C C => A => C reg, M N Z C RSP Reset Stack Pointer S = Max allowed SBC Substract with Carry A = A - M - C A M N Z C SCF Set carry flag C = 1 1 SIM Disable Interrupts I1:0 = 11 (level 3) 1 1 SLA Shift left Arithmetic C <= A <= 0 reg, M N Z C SLL Shift left Logic C <= A <= 0 reg, M N Z C SRL Shift right Logic 0 => A => C reg, M 0 Z C SRA Shift right Arithmetic A7 => A => C reg, M N Z C SUB Substraction A = A - M A M N Z C SWAP SWAP nibbles A7-A4 <=> A3-A0 reg, M N Z TNZ Test for Neg & Zero tnz lbl1 N Z TRAP S/W trap S/W interrupt 1 1 WFI Wait for Interrupt 1 0 XOR Exclusive OR A = A XOR M A M N Z
pop reg reg M pop CC CC M I1 H I0 N Z C
100/139
Doc ID 6996 Rev 5
Loading...
