ST-7104
Advanced HD decoder for iDTV
Data brief
Features
■ Advanced high definition video decoding
(H264/VC-1/MPEG2)
■ Advanced standard definition video decoding
(H264/VC-1/MPEG2/AVS)
■ Advanced multi-channel audio decoding
(MPEG 1, 2, MP 3, DD/DD+, AAC/AAC+, and
WMA9/WMA9pro)
■ Linux, Windows CE, and OS21 compatible
ST40 applications CPU (450 MHz)
■ 32-bit DDR1/DDR2 compatible local memory
interface
■ Multi-stream, DVR capable transport stream
processing
JTAG
ST40-300 core 450 MHz
TMUs/INTC
UDI
32 K I cache
CPU/FPU core
MMU
32 K D cache
DDR2
SDRAM
16/32
LMI
6-channel
PCM out
2-ch
PCM in
Audio decoder
Audio L/R
out
Audio
DACs
players and
interfaces
ST231
core
S/PDIF
out
■ Extensive connectivity (dual USB hosts,
e-SATA, Ethernet MAC/MII/RMII, and PCI)
■ Separate digital video and graphics outputs
Description
The ST-7104 uses state of the art process
technology to provide a cost effective, fully
featured HD AVC decoder IC. It is a highly
integrated system-on-chip suitable for low-cost
add-on module for iDTV manufacturers.
The ST-7104 is targeted at the latest CE
manufacturer requirements for iDTVs which utilize
advanced HD decoding (H264/VC-1/MPEG2),
and which conform to DVB, SCTE, ATSC, ARIB,
CEA, ITU and OpenCable specifications.
Serial ATA
HDD, int/ext
eSAT A
interface
Dual
USB 2.0
hosts
USB
2.0
USB
2.0
Key
Scan
2x I/F
SmCard
GPIOs
Peripheral I/O
and external interrupts
Comms
IR Tx/Rx
UHF Rx
ILC
4x
UARTs
Serial
FLASH
SPI
4x
SSC/I2C
PWM
STBus
Capture
Ethernet,
MAC
MII/RMII
Delta Mu
advanced
video decoder
ST231
Output
stage
TXT
Sec
Dual
PTI
3
SWTS
2
TSmerger/router
TS TS TS
IN2IN0 IN1/OUT0
TS
IN3
PDES
2
Clock gen
and
system
services
Resets/
clocks/
modes
DUAL
FDMA
Bdisp
blitter
DENC
Main/aux display
compositor and
pass through
6DACs
Analog video
output
(HD/SD)
Main video
display
VTGs
DEI
Aux video
display
DVO0 DVO1
Digital
Digital
video
output 1
output 0
PCI
video
June 2009 Doc ID 15860 Rev 1 1/7
For further information contact your local STMicroelectronics sales office.
EMI
FLASH
NOR/NAND
SFLASH
www.st.com
7
Description ST-7104
1 Description
The ST-7104 offers current users of ST’s growing family of advanced decoding ICs
enhancements in performance and features, whilst reducing cost and time-to-market for the
next generation deployments.
2/7 Doc ID 15860 Rev 1
ST-7104 Main features
2 Main features
The ST-7104 has the following features:
● Integrates in a single IC, Multi-stream transport demux, CPU, A/V decode, Video
processing, Graphics and Display, peripherals, Audio/Video DACs, Digital A/V outputs,
e-SATA port, dual USB ports and Ethernet MAC/MII
● High performance CPUs for applications (ST40) and audio/video decoding (2 x ST231)
– ST40-300, dual-issue, appl ic at ion s CPU, 32K I, 32KD cach es :
Target speed > 450 MHz delivering > 800 DMIPs
● Single 32-bit DDR1/DDR2 Local Memory Interface (LMI), up to 400 MHz
● Latest generation “Delta” Video Decoder with ST231 programmable CPU core:
– MPEG2, H264, VC-1/WM9, HD or SD Advanced Video Decoding
– AVS SD decoding
– Provides flexibility to support other codecs (DivX, XviD, H263 encode/decode)
– HD and SD decoding or dual SD Decoding, PIP & Mosaic capable
– Real-time transcoding of MPEG2 SD to H264 SIF
● Advanced de-blocking of decoded MPEG2 SD sources based on ST’s DSE (Digital
Source Enhancer) Technology with 2D Analysis window and Texture Adaptive Filter
● ST231 CPU based Audio Decoder. MPEG1 I/II, MP3, Dolby Digital/DD+, MPEG4
AAC/AAC+ multi-channel audio decoding. Concurrent audio description decoding.
DD+ and AAC+ transcodi ng
● Main and Aux Video display pipelines:
– Main: high quality H & V reformatting/resizing with sample rate
conversion/filtering. Motion adaptive spatial and temporal de-interlacing for
480p/576p and 1080p60 progressive output
– Aux: high quality H & V reformatting/resizing with sample rate conversion/filtering
● Three independent graphics planes with H&V resize, CLUT and anti-flicker filtering
● Link list based 2D graphics blitter. Up to 200 Mpixels/sec with destination alpha
blending. Capable of 3D user interface effects.
● Independent Main and Aux display compositions (Video/Graphics mixing)
● Pass-through display for graphics, main video or aux video output concurrently with
main and aux compositions
● HD display capture and down-conversion for concurrent HD and SD output of the main
composition
● 16-bit Digital Video Output for main display composition (HD/ED/SD formats up to
1080p60)
● Second 32-bit (ARGB) Digital Video Output for pass through display or main/aux
display compositions (HD/ED/SD formats up to 1080p60)
● Macrovision copy protection support
● PAL/NTSC/SECAM Digital encoder
● Six 10-bit DACs for component/composite analog video output (HD/ED/SD formats up
to 1080i)
● Integrated Stereo Audio DAC
● Six-channel Audio PCM Output Interface
Doc ID 15860 Rev 1 3/7
Main features ST-7104
● Stereo Audio PCM Input Interface
● Independent SPDIF output
● Quadruple external TS inputs, triple internal TS from memory
● Dual DVB-CI+ (HD/SD profiles) modules supported
● Multi-stream transpor t strea m de- mul tip lexi ng, 333 Mbi ts/se c, Qu adrup le tune r DVR
capable
● DVB/DES/AES/Multi-2/ICAM descrambling
● Dual USB 2.0 host interfaces both with PHY
● Integrated 10/100 Ethernet MAC/MII/RMII, Wake on LAN, 75 MHz (300 Mbits/sec)
capable
● 16-bit External Memory and Peripheral Interface (EMI) - up to five banks
● Interfacing to, and boot from, NOR or NAND FLASH
● Interfacing to, and boot from, serial FLASH
● 32-bit, 66 MHz, PCI Interface, shared on EMI with access interleaving possible
● DVR supported, with HDD attachment through e-SATA, EIDE (PIO mode) or USB
● Dual Multi-channel Flexible DMA Controllers
● Peripherals
– Two Smartcard interfaces
– four UARTs
– four SSC/I2C
– GPIO banks with alternate functions
–IR Tx/Rx
– UHF Rx/SCD
–PWM
–ILC
– 4 x 4 key matrix scanner
● Package
– FPBGA 27 x 27mm
– 620 balls
– 7R32x32
–Pitch 0.8 mm
– Ball 0.5 mm.
4/7 Doc ID 15860 Rev 1
ST-7104 Applications overview
3 Applications overview
The ST-7104 includes in a single IC, multi-stream transport de-multiplexing and
descrambling, an ST40 applications CPU, advanced audio/video decoding, video
processing, graphics and display composition, peripherals, audio/video DACs, Digital
audio/video outputs, two Host USB ports, an e-SATA HDD port, and Ethernet MAC
MII/RMII.
Figure 1. iDTV add-on module
DTV/ATV
Hybrid tuner
Analog
Digital
STV0362
demodulator
PIF/SIF
EXT3
(CVBS/S)
EXT4
(RGB, PbPr)
EXT1
(SCART)
EXT2
(SCART)
USB 2.0
MPEG TS
SIF
CVBS
CVBS/S
CVBS, RGB
CVBS, RGB
PC-RGB
DDR2
H.264/MPEG
16-bit VID
and
32-bit (ARGB) GFX
Video
processor
1080p/120Hz
ST-7104
decoder
2
I
S
L/R
NAND
FLASH
PCI
UART
Backlight
inverter
LVDS 10bit x 4ch
DVR (optional)
Wifi i/f
CI
Class D amp
Doc ID 15860 Rev 1 5/7
Revision history ST-7104
4 Revision history
Table 1. Document revision history
Date Revision Changes
10-Jun-2009 1 Initial release.
