L6234
Three phase motor driver
Features
■Supply voltage from 7 to 52 V
■5 A peak current
■RDSon 0.3 Ω typ. value at 25 °C
■Cross conduction protection
■TTL compatible driver
■Operating frequency up to 150 kHz
■Thermal shutdown
■Intrinsic fast free wheeling diodes
■Input and enable function for each half bridge
■10 V external reference available
Description
The L6234 is a triple half bridge to drive a brushless DC motor.
It is realized in BCDmultipower technology which combines isolated DMOS power transistors with CMOS and Bipolar circuits on the same chip.
By using mixed technology it has been possible to optimize the logic circuitry and the power stage to achieve the best possible performance.
32:(5 ',3
3RZHU62
The output DMOS transistors can sustain a very high current due to the fact that the DMOS structure is not affected by the second breakdown effect, the RMS maximum current is practically limited by the dissipation capability of the package.
All the logic inputs are TTL, CMOS and µP compatible. Each channel is controlled by two separate logic input.
L6234 is available in 20 pin PowerDIP package (16+2+2) and in PowerSO20.
Table 1. |
Device summary |
|
|
|
Order code |
Package |
Packing |
|
|
|
|
|
L6234 |
PowerDIP20 |
Tube |
|
|
|
|
|
L6234PD |
PowerSO20 |
Tube |
|
|
|
|
|
L6234PD013TR |
PowerSO20 |
Tape and reel |
|
|
|
|
November 2011 |
Doc ID 1107 Rev 10 |
1/16 |
www.st.com
Contents |
L6234 |
|
|
Contents
1 |
Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 3 |
|
2 |
Pin connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
. 4 |
|
3 |
Thermal data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
5 |
|
4 |
Maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
|
|
4.1 |
Recommended operating conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
6 |
5 |
Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
7 |
|
6 |
Circuit description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
8 |
|
7 |
Typical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
9 |
|
8 |
Mechanical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
12 |
|
9 |
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
15 |
2/16 |
Doc ID 1107 Rev 10 |
L6234 |
Block diagram |
|
|
|
|
|
Μ) |
|
Q) |
Μ) |
|
|
|
9&3 |
95() |
9%227 |
1 |
|
&+$5*( |
|
95() |
|
|
3803 |
|
9 |
|
|
|
|
9V |
|
Μ) |
,1 |
|
WR 9 |
||
|
7+ |
Μ) |
|
|
|
|
|
|
|
|
|
287 |
|
|
(1 |
|
7/ |
|
|
|
|
|
|
|
,1 |
|
7+ |
|
|
|
|
|
|
|
|
|
287 |
|
|
(1 |
|
7/ |
|
|
|
|
|
|
|
7+(50$/ |
|
6(16( |
|
|
|
|
|
|
|
3527(&7,21 |
|
|
|
|
,1 |
|
7+ |
|
|
|
|
|
|
|
|
|
287 |
|
|
(1 |
|
7/ |
|
|
|
|
|
|
|
|
|
6(16( |
|
|
|
|
*1' |
56(16( |
|
|
|
' ,1$ |
|
|
|
|
|
|
!-V |
Doc ID 1107 Rev 10 |
3/16 |
Pin connections |
L6234 |
|
|
287 |
|
|
287 |
*1' |
|
|
*1' |
|||
,1 |
|
|
,1 |
6(16( |
|
|
6(16( |
|||
(1 |
|
|
(1 |
(1 |
|
|
9%227 |
|||
96 |
|
|
6(16( |
,1 |
|
|
9&3 |
|||
*1' |
|
|
*1' |
287 |
|
|
95() |
|||
*1' |
|
|
*1' |
287 |
|
|
287 |
|||
|
|
|
|
|||||||
96 |
|
|
6(16( |
,1 |
|
|
,1 |
|||
(1 |
|
|
(1 |
|||||||
(1 |
|
|
9%227 |
|||||||
96 |
|
|
96 |
|||||||
,1 |
|
|
9&3 |
|||||||
|
|
|
|
|
|
*1' |
|
|
*1' |
|
287 |
|
|
|
|
95() |
|||||
|
|
|
|
|
32:(5 ',3 |
3RZHU62 |
|
!-V |
Table 2. |
Pin functions |
|
||
PowerDIP |
PowerSO20 |
Name |
Function |
|
|
|
|
|
|
1 |
6 |
OUT 1 |
|
|
20 |
5 |
OUT 2 |
Output of the channels 1/2/3. |
|
10 |
15 |
OUT 3 |
|
|
|
|
|
|
|
2 |
7 |
IN 1 |
Logic input of channels 1/2/3. A logic HIGH level (when the |
|
corresponding EN pin is HIGH) switches ON the upper DMOS |
||||
19 |
4 |
IN 2 |
||
Power Transistor, while a logic LOW switches ON the |
||||
9 |
14 |
IN 3 |
||
corresponding low side DMOS Power. |
||||
|
|
|
||
|
|
|
|
|
3 |
8 |
EN 1 |
Enable of the channels 1/2/3. A logic LOW level on this pin |
|
18 |
3 |
EN 2 |
||
switches off both power DMOS of the related channel. |
||||
8 |
13 |
EN 3 |
||
|
||||
|
|
|
|
|
4,7 |
9, 12 |
Vs |
Power supply voltage. |
|
|
|
|
|
|
14 |
19 |
SENSE2 |
A sense resistor connected to this pin provides feedback for |
|
|
|
|
motor current control for the bridge 3. |
|
|
|
|
|
|
17 |
2 |
SENSE1 |
A sense resistor connected to this pin provides feedback for |
|
|
|
|
motor current control for the bridges 1 and 2. |
|
|
|
|
|
|
|
|
|
Internal voltage reference. A capacitor connected from this pin |
|
11 |
16 |
VREF |
to GND increases the stability of the Power DMOS drive |
|
|
|
|
circuit. |
|
|
|
|
|
|
12 |
17 |
VCP |
Bootstrap oscillator. Oscillator output for the external charge |
|
pump. |
||||
|
|
|
||
|
|
|
|
|
13 |
18 |
VBOOT |
Overvoltage input to drive the upper DMOS |
|
|
|
|
|
|
5,6 |
1,10 |
GND |
Common ground terminal. In PowerDIP and SO packages |
|
15,16 |
11,20 |
these pins are used to dissipate the heat forward the PCB. |
||
|
||||
|
|
|
|
4/16 |
Doc ID 1107 Rev 10 |
L6234 |
Thermal data |
|
|
Table 3. |
Thermal data |
|
|
|
|
Symbol |
Parameter |
DIP16+2+2 |
PowerSO20 |
Unit |
|
|
|
|
|
|
|
R |
Thermal resistance, junction to pin |
12 (1) |
– |
°C/W |
|
th j-pin |
|
|
|
|
|
R |
Thermal resistance, junction to ambient |
40 (2) |
– |
°C/W |
|
th j-amb1 |
|
|
|
|
|
R |
Thermal resistance, junction characteristics) to |
50 (3) |
– |
°C/W |
|
ambient |
|||||
th j-amb2 |
|
|
|
||
|
|
|
|
|
|
Rth j-case |
Thermal resistance junction-case |
– |
1.5 |
°C/W |
1.The thermal resistance is referred to the thermal path from the dissipating region on the top surface of the silicon chip, to the points along the four central pins of the package, at a distance of 1.5 mm away from the stand-offs.
2.If a dissipating surface, thick at least 35 mm, and with a surface similar or bigger than the one shown in Figure 3, is created making use of the printed circuit. Such heatsinking surface is considered on the bottom side of an horizontal PCB (worst case).
3.If the power dissipating pins (the four central ones), as well as the others, have a minimum thermal connection with the external world (very thin strips only) so that the dissipation takes place through still air and through the PCB itself. It is the same situation of note 2, without any heatsinking surface created on purpose on the board.
!-V
Doc ID 1107 Rev 10 |
5/16 |
