ST AN2405 Application note

AN2405
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Application note
Migrating from RS232-only applications to
RS232/USB applications using Turbo Plus uPSD
Introduction
Most laptops and recent desktops do not have serial ports however many legacy applications still use RS232. The scope of this application note is to migrate such RS232 applications to RS232/USB applications using Turbo Plus uPSD. Since Turbo Plus uPSD has two UART ports, one of them is used for the USB-to-Serial Bridge connection. The scope is to implement an easy migration with minimal impact on legacy applications.
July 2007 Rev 1 1/13
www.st.com
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Contents AN2405
Contents
1 Migration description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Loading CDC class drivers for USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 .INF file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3.1 Usbser.inf (Windows 2000,XP only) file: . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 CDC Firmware Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 CDC Class Requests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6 USB_UART1 Bridge (HW Connection-User setup or Automatic USB Detect) 8
1.7 USB-to-Serial Bridge plug-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.8 Example of easy migration to RS232_USB application: . . . . . . . . . . . . . . 9
2 Conclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
AN2405 Migration description

1 Migration description

1.1 Architecture

USB Migrated PC Application
(Legacy Serial Port or Virtual
Serial Port over USB)
Legacy PC Application
UART drivers
UART H/W & DB9
Connector
RS232
UART0 H/W & DB9
Connector
UART0 firmware driver
UART0 only
microcontroller
Firmware Application
Transmitting and
Receiving over UART0
Easy
Migration
UARTdrivers + CDC class
device drivers for USB
(usbser.sys, usbser.inf)
UARTT H/W & DB9 Connector
+
USB H/W & USB Type A
Connector
RS232 or USB
UART0 H/W & DB9
Connector
+
USB H/W & USB Type B
Connector
UQRT0 firmware driver + USB
CDC class driver
MCU -> Turbo Plus uPSD
UART0 Tx and Rx connected
to UART1 Rx and Tx
(HW connection-User Setup or
Automatic USB Detect)
USB-to-UART1 Bridge Plug-in
Unchanged Firmware
Application Transmitting and
Receiving over UART0

1.2 Loading CDC class drivers for USB

Install the setup application provided with this example and the necessary CDC class drivers will be loaded on your PC. The driver installed will work with Windows 2000 & XP
3/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Migration description AN2405
only. The .inf file has to be modified to work with Windows 98/Me. When connected to a device that has CDC class implemented, Windows will see USB as a virtual COM port.
PC Application

1.3 .INF file

When a USB device is connected, windows checks the .inf file to load the appropriate driver for the device.
Microsoft does not provide an .inf file with the usbser.sys driver file. The .inf file usbser.inf provided via the setup application allows the user to load the usbser.sys driver file under Windows 2000 and Windows XP. The .inf file has to be modified to work with Windows 98/Me.
Application manufacturers can modify this file and the device descriptors in usb_desc.h for their own VID & PID.
To install the drivers from a directory instead of running the provided setup application, copy the usbser.inf file and usbser.sys file to a folder. When the dialog box displaying “Found New Hardware Wizard” opens up, choose Install from a specific location and point to the folder where the usbser.inf file is copied.
Usbser.sys
CDC Descriptors
Target Device
Usbser.inf
Note: Do not copy the .inf file into the windows\inf folder manually.

1.3.1 Usbser.inf (Windows 2000,XP only) file:

[Version] DriverVer=08/03/2004,5.1.2600.2180 Signature=$CHICAGO$ Class=Ports ClassGUID={4d36e978-e325-11ce-bfc1-08002be10318} Provider=%String0%
; Port Class Install [ClassInstall]
4/13
AddReg=USBClassInstall
[USBClassInstall] HKR,,,,%Enumerator% HKR,,Icon,,"-23"
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
AN2405 Migration description
HKR,,Installer32,,"MsPorts.Dll, PortsClassInstaller"
[Manufacturer] %String0%=STMicroelectronics
[ControlFlags] ExcludeFromSelect=USB\VID_0483&PID_3420 ExcludeFromSelect=USB\VID_0483&PID_3400
[STMicroelectronics] %String1%=STUSB, USB\VID_0483&PID_3401
; Win 2000 [STUSB] ;CopyFiles=WDM.Drvrs AddReg=STUSB.AddReg, DevMap.AddReg
;[WDM.Drvrs] ; usbser.sys,,,0x00000020
[STUSB.AddReg] HKR,,DevLoader,0,*ntkern HKR,,NTMPDriver,,"usbser.sys" HKR,,EnumPropPages32,,"MsPorts.dll, SerialPortPropPageProvider"
[DevMap.AddReg] ; HKLM, hardware\devicemap\serialcomm,COM5,,COM5
[STUSB.Services] AddService=usbser, 0x00000002, FuncDrv_Service_Inst
[FuncDrv_Service_Inst] DisplayName=%USBFilterString% ServiceType= 1 StartType = 3 ErrorControl = 0 ServiceBinary = %12%\usbser.sys
[Strings] String0="STMicroelectronics" String1="STMicroelectronics USB Serial Emulator" Enumerator = "USB Serial Emulator" %USBFilterString% = "USB Serial Service"

1.4 CDC Firmware Driver

The device enumerates as a CDC driver and talks to the PC over USB on Virtual COM port. To be considered as a COM port, the USB device declares two interfaces:
Abstract Control Model Communication class interface using interrupt endpoint 2(IN).
Data Class Interface using Bulk endpoint 1(IN & OUT)
Descriptors (Device, Configuration and Interface):
const device_descriptor code deviceDesc = { sizeof(device_descriptor), // Size of this Descriptor in Bytes DT_DEVICE, // Descriptor Type (=1) {USB_SPEC_REV_LSB, USB_SPEC_REV_MSB}, // USB Spec Release Number in BCD CDC_CLASS, // Device Class Code (CDC class code) 0, // Device Subclass Code (CDC Subclass Code) 0, // Device Protocol Code (CDC Device Protocol)
5/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Migration description AN2405
EP0_PKT_SIZE, // Maximum Packet Size for EP0 { VENDOR_ID_LSB, VENDOR_ID_MSB }, // Vendor ID {PRODUCT_ID_LSB, PRODUCT_ID_MSB}, // Product ID { 0x01, 0x02}, 0, // Index of String Desc for Manufacturer 0, // Index of String Desc for Product 0, // Index of String Desc for SerNo 1 // Number of possible Configurations };
const uchar code configDesc[] = { 9, // Configuration descriptor length 2, // Descriptor type (configuration) 0x43, // Total length of this descriptor 2EP+Control 0x00, NO_OF_INTERFACES, // Number of interfaces 0x01, // Configuration value (OnSetConfiguration) 0x00, // Index of string descriptor (none) BM_ATTRIBUTES, 0x32, // 100 mA max power consumption
//Communication class Interface Descriptor Requirement 0x09, // Descriptor length 0x04, // Descriptor type (interface) 0x00, // Number of interface 0x00, // Alternate setting 0x01, // Number of endpoints (except EP0) CDC_CLASS, // Class code - CDC class code ACM_VIRTUALCOM, // Subclass - Abstract Control Model(for virtual COM) INTERFACE_PROTOCOL, // Protocol - 0(interface protocol) 0x00, // iInterface String
//Header functional descriptor 0x05, //bFunctionLength 0x24, //bDescriptor type - CS_INTERFACE 0x00, //bDescriptor Subtype - Header Func Desc 0x10, //bcd CDC spec release number 0x01, //Call Management functional descriptor 0x05, //bFunctionLength CS_INTERFACE, //bDescriptor type - CS_INTERFACE CALL_MANAGEMENT_FN, //bDescriptor subtype - Call Management Func Desc 0x00, //bmCapabilities D0+D1 0x01, //bDataInterface: 1 //ACM Functional descriptor 0x04, //bFunction Length CS_INTERFACE, //bDescriptor type - CS_INTERFACE ACM_VIRTUALCOM, //bDescriptor subtype: ACM func desc 0x02, //bmCapabilities
//Union Functional descriptor 0x05, //bFunctionalLength CS_INTERFACE, //bDescriptor type - CS_INTERFACE UNION_MANAGEMENT_FN, //bDescriptor subtype: Union func desc 0x00, //bMasterInterface: Communication class interface 0x01, //bSlaveInterface0: Data Class Interface
//Endpoint 2 descriptor /* EP2 */ 0x07, // Descriptor length (7 bytes) 0x05, // Descriptor type (endpoint)
6/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
AN2405 Migration description
0x82, // Address (IN3) EP_ATTR_INTERRUPT, // Attributes-Interrupt transfer 0x08, 0, // Maximum packet size 0xFF, // Polling interval-Maximum
//Data class interface descriptor requirement 0x09, //bLength, 0x04, //bDescriptorType 0x01, //bInterface Number 0x00, //bAlternate setting 0x02, //bNumEndpoints DATA_CLASS_INTERFACE, //bInterfaceClass-Data class interface 0x00, //bInterfaceSubclass 0x00, //bInterfaceProtocol 0x00, //iInterface
//Endpoint 1 Descriptor /* EP1-OUT */ 0x07, // Descriptor length (7 bytes) 0x05, // Descriptor type (endpoint) 0x01, // Address (OUT1) EP_ATTR_BULK, // Attributes -bulk transfer EP1_PKT_SIZE, 0, // Maximum packet size 0, // Polling interval not used
/* EP1-IN*/ 0x07, // Descriptor length (7 bytes) 0x05, // Descriptor type (endpoint) 0x81, // Address (OUT1) EP_ATTR_BULK, // Attributes -bulk transfer EP1_PKT_SIZE, 0, // Maximum packet size 0 // Polling interval not used };

1.5 CDC Class Requests

The firmware is required to handle the following CDC class requests:
Request Code Description Req’d/Opt
SEND_ENCAPSULATED_COMMAND 00h
GET_ENCAPSULATED_RESPONSE 01h
SET_COMM_FEATURE 02h
GET_COMM_FEATURE 03h
CLEAR_COMM_FEATURE 04h
SET_LINE_CODING 20h
GET_LINE_CODING 21h
Issues a command in the format of the supported control protocol
Requests a response in the format of the supported control protocol
Controls the settings for a particular communication feature
Returns the current settings for the communication feature
Clears the settings for a particular communication feature
Configures DTE rate, stop-bits, parity, and number-of-character bits
Requests current DTE rate, stop-bits, parity, and number-of-character bits
Required
Required
Optional
Optional
Optional
Optional
Optional
1)
1)
7/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Migration description AN2405
Request Code Description Req’d/Opt
SET_CONTROL_LINE_STATE 22h
SEND_BREAK 23h
Note: 1 These requests can be used to configure the UARTs in USB-to Serial bridge
implementations.
RS-232 signal used to tell the DCE device the DTE device is now present
Sends special carrier modulation used to specify RS-232 style break

1.6 USB_UART1 Bridge (HW Connection-User setup or Automatic USB Detect)

The target MCU for the migrated application is the Turbo Plus uPSD. The Turbo Plus uPSD has two UARTs - UART0 and UART1 and a USB communication interface. The UARTs can be configured using Timer2 to operate at one of the following Kbps baud rates:
f
MHz
OSC
40.0 115200 FF F5 113636 -1.36%
40.0 57600 FF EA 56818 -1.36%
40.0 28800 FF D5 29070 0.94%
40.0 19200 FF BF 19231 0.16%
40.0 9600 FF 7E 9615 0.16%
Desired
Baud Rate
RCAP2H (hex) RCAP2L(hex)
Timer 2 SFRs
Resulting
Baud Rate
Optional
Optional
Baud Rate
Deviation
The Tx and Rx lines of UART0 must be connected to the Tx and Rx lines of UART1 when using Virtual COM port. This will enable the data transferred over UART0 by the application program to be transferred over USB by the USB-to Serial Bridge Plug-in program.
Target Device
RS232
or
USB
Rx
Tx
Host PC
This connection can be done by the user or can be done through automatic USB detection.
U A R T 0
Turbo Plus uPSD
UART1
Rx
Tx
USB-to-Serial Bridge Plug-in
H/W connection (User Setup/USB Auto Detect)
8/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
AN2405 Migration description

1.7 USB-to-Serial Bridge plug-in

The USB-to-Serial Bridge Plug-in is provided as a library file (upsd3400_USB-to_Serial.lib . Features of this library are:
Small code footprint of approximately 3.5K
Xdata memory space of 800 bytes including intermediate FIFO buffers used for transfer
Data space of 50 bytes

1.8 Example of easy migration to RS232_USB application:

The scope is to provide an easy migration. The example application echoes back character typed and sent to Turbo Plus uPSD. All received and transmitted characters are stored in an intermediate FIFO buffer to avoid data being lost when UART is not able to handle them.
Transmit over
UART1
Intermediate Tx
FIFO
H/W Connection
Receive over
UART0
Received Bytes
Receive_length=0
over USB
Transmit Bytes
over USB
Intermediate Rx
FIFO
Intermediate Rx
FIFO
Migrated RS232_USB Firmware Application
Echo Back on
UART0 (main.c)
H/W Connection
Receive over
UART1
9/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Conclusion AN2405

2 Conclusion

The example application is aimed at easy migration from RS232 only applications to RS232/USB applications. There is a overhead of one UART port and the firmware is not efficient in RS232 transfers. Once the reader has familiarized himself with the concepts of USB and CDC Class implementation it is recommended that he moves to implement a USB­to Serial bridge.
10/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
AN2405 References

3 References

1. Universal Serial Bus definitions for Communication devices, Version 1.1
2. uPSD34xx-Turbo Plus Series Fast Turbo 8032 MCU with USB and Programmable
Logic
3. DK3400_USB_To_Serial_Bridge_Using_UART1 firmware.
11/13
Obsolete Product(s) - Obsolete Product(s) Obsolete Product(s) - Obsolete Product(s)
Revision history AN2405

4 Revision history

Table 1. Document revision history
Date Revision Changes
02-Jul-2007 1 Initial release.
