Part # Description
Unit of
Measurement
43200
Patient Connecting
Tubing 9/32" x 6'
Case of 50
48041
1200cc Canister Disposable
Case of 48
50159
Vacuum Tubing 3/8"
I.D. Silicon
Inch
50175
Bracket - Tubing Strap
Anchor
Each
50176
Tubing Strap Each
2314-10
Tubing Strap Hook Each
Common Spare Parts List
2300 Series (new-Duet®, Sentinel, VX-2®, EVX)
820.500 L3 1 of 9
Rev A
Part # Description
Unit of
Measurement
80024-115
On/Off Switch Control Panel
(Membrane) for VX2 2310 Series
Each
80023-115
On/Off Switch Control Panel
(Membrane) for
new-Duet 2314
Series
Each
80006
On/Off Switch for EVX
2309
Each
80009
Illuminated On/Off
Switch for EVX
2309BV
Each
80540
PC Board for VX2 (2310 Series) and
new-Duet (2314
Series)
Each
80516
Power Supply 2314 Each
80635
Battery 12V for
VX-2 (2310 Series)
and new-Duet (2314
Series)
3 pin Molex
Each
820.500 L3 2 of 9
Rev A
Part # Description
Unit of
Measurement
80638
Battery 12V for
2309 Series & 2315
2 pin Molex
Each
90157
Barb Union Each
22015-3
Regulator Knob Each
60000-144
Set Screw, Variable
Regulator
Each
2310-2
Chassis - Rear
Bracket Setup
Each
2314-2
Chassis - Rear No
Bracket Setup
Each
2310-3
Receptacle Plate Each
820.500 L3 3 of 9
Rev A
Part # Description
Unit of
Measurement
2315-3
Receptacle Plate for
2315
Each
2314-1
Chassis - Front Each
90160
Muffler Door Filter Each
2314-3
Chassis, Muffler Door Each
2314-400
Canister Holder
Assembly
Each
2314-401
Canister Holder Each
2500-400
Canister Holder
Assembly for 2315
Each
820.500 L3 4 of 9
Rev A
Part # Description
Unit of
Measurement
44241C
HI-D® "Big Stick"®
Large Bore Suction Tip
with Thumb Control
Case of 50
50007-6
Label, Control Panel
for 2315
Each
50007-16
Label, Regulator for
2310V
Each
50007-1
Label, Regulator for
2314
Each
50007-4
Label, Regulator for
2315
Each
80525
AC Charger for 2315 Each
80529 DC Charger 220V Each
820.500 L3 5 of 9
Rev A
Part # Description
Unit of
Measurement
80521-100
Converter AC/DC for
2310 and 2400 110V
Each
80533
AC Charger Fixed Volt
110V
Each
8310
Bracket Retention/Charging for
2310B, 2310BV and
2309BV
Each
8314
Bracket Retention/Charging for
2314B
Each
8323
BracketRetention/Charging for
2314BV-230
Each
80973
Wiring Harness for
8310 Bracket
Each
8314-8
Bracket, Right
Retention
Each
820.500 L3 6 of 9
Rev A
Part # Description
Unit of
Measurement
8314-9
Bracket, Left Retention Each
8310-2
Spring, Contact Each
80971
Electrical Input
Receptacle for 2314
Each
80104
Wiring Harness for
2310
Each
80952
Wiring Harness for
2309
Each
80972
Wiring Harness for
2309BV
Each
80962
Wiring Harness for
2315
Each
820.500 L3 7 of 9
Rev A
Part # Description
Unit of
Measurement
80515-01
LED holder set to be
used with 80952
Each
90201-TQ
Pump for VX-2 (2310
Series), EVX (2309
Series) and 2315
Each
90204
Pump for new-Duet
(2314 Series)
Each
22012-100
Regulator Assembly Each
10064-700
Shoulder Strap with
Pouch
Each
10064-600
Shoulder Strap Each
Fax: +1 818-504-6032
Email: marketing@sscor.com
Prices subject to change without notice
Freight Terms:
F.O.B. Sun Valley, CA
11064 Randall Street, Sun Valley, CA 91352
Phone 800-434-5211 Domestic +1 818-504-4054 International
820.500 L3 8 of 9
Rev A
Part # Description
Unit of
Measurement
www.sscor.com
S-SCORT, S-SCORT…JR.,new-Duet, VX-2, Quickdraw, HI-D, and "Big Stick" are registered trademarks of SSCOR, Inc.
820.500 L3 9 of 9
