SSANGYONG ACTYON, ACTYON SPORTS User Manual

Recommended Fluids and Lubricants

Descriptions SpecificationsCapacity

Engine Oil

Engine Coolant

Automatic Transmission Fluid

Manual Transmission Fluid

Transfer Case Fluid

Axle Oil

Brake / Clutch Fluid

Power Steering Fluid

Front

Automatic Transmission

Manual Transmission

Solid Axle

Rear

Suspension

ACTYON

SPORTS

D20DT

G23D

D20DT

G23D

4WD

2WD

2WD ALL, 4WD M/T

4WD A/T

2WD A/T

4WD ALL, 2WD M/T

7.5

10.5 ~ 11.0

9.5

3.6

3.4

1.4

1.9

2.0

1.9

2.0

As required

1.0

Quality class:

Ssangyong genuine engine oil

(Approved by MB Sheet 229.1 or 229.3)

Viscosity: MB sheet No. 224.1

Ssangyong genuine coolant

(Anti-freeze:SYC-310, Anti-freeze:water = 50:50)

Ssangyong genuine oil (CASTROL TQ 95)

Ssangyong genuine oil (ATF DEXRON II)

Ssangyong genuine oil (ATF DEXRON III)

Ssangyong genuine oil

(SAE 80W/90, API GL-5)

Ssangyong genuine oil

(SAE 80W/90, API GL-5)

Ssangyong genuine oil (DOT4)

Ssangyong genuine oil (ATF DEXRON II or III)

Q100_English_LHD.p65 2006-10-02, ¿ÀÈÄ 3:05Page 2 Adobe PageMaker 6.5K/Win

Q100-00_Foreword.p65 2006-10-02, ¿ÀÈÄ 3:05Page 1 Adobe PageMaker 6.5K/Win

Q100-00_Foreword.p65 2006-10-02, ¿ÀÈÄ 3:05Page 2 Adobe PageMaker 6.5K/Win

FOREWORD

This manual has been prepared to acquaint you with the operation and maintenance of your ACTYON/ACTYON SPORTS and to provide important safety information. We urge you to read it carefully and follow the recommendations to help assure the most enjoyable, safe, and trouble-free operation of your vehicle.

When it comes to service, remember that your dealer knows your vehicle best and is interested in your complete satisfaction.

We would like to take this opportunity to thank you for choosing ACTYON/ACTYON SPORTS and assure you of our continuing interest in your motoring pleasure and satisfaction.

This manual should be considered as a permanent part of your vehicle, and must remain with the vehicle at the time of resale.

PYUNGTAEK, KOREA

Q100-00_Foreword.p65 2006-10-02, ¿ÀÈÄ 3:05Page 3 Adobe PageMaker 6.5K/Win

IMPORTANT NOTICE

Please read this manual and follow the instructions carefully. Signal words such as “WARNING”, “CAUTION” and “NOTE”

have special meanings.

WARNING

WARNING indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not

avoided, may result in minor or moderate injury or property damage.

NOTE

All information, illustrations and specifications in this manual are based on the latest product information available at the time of publication.

Ssangyong reserves the right to change specifications or design at any time without notice and without incurring any obligation whatsoever.

This vehicle may not comply with the standards or regulations of other countries. Before attempting to register this vehicle in any other country, check all applicable regulations and make any necessary modifications.

This manual describes options and trim levels available at the time of printing, and therefore, some of the items covered may not apply to your vehicle. If any doubt exists about any of the options or trim levels, please do not hesitate to contact your Ssangyong Distributor for information on the latest specifications.

* : This asterisk in this manual signifies that an item of equip-

ment is not included in all vehicles (model variants, engine options, models specific to one country, optional equipment, etc.).

NOTE

NOTE indicates information to assist maintenance and instructions.

We would like to point out that non Ssangyong Genuine parts and accessories have not been examined and approved by Ssangyong, and in spite of continuous market product monitoring, we cannot certify the suitability nor the safety of

For product design changes

For a highest level of safety and quality, we are innovating our vehicles through our continual research and development efforts. As a result, the specifications are subject to change for the purpose of improvement without any notice and you may find material in this manual that does not apply to your specific vehicle.

Q100-00_Foreword.p65 2006-10-02, ¿ÀÈÄ 3:05Page 4 Adobe PageMaker 6.5K/Win

such products whether they are installed or intended for fitment in our vehicles. Ssangyong is not liable for any damage caused by the use of non Ssangyong Genuine parts and accessories.

TABLE OF CONTENTS

0. General ......................................................... Section 0

1. Safety Precautions ...................................... Section 1

0

1

2. Ignition Key, Remote Control Key ............. Section 2

3. Opening and Closing ................................... Section 3

4. Interior Switches .......................................... Section 4

5. Instrument Cluster ....................................... Section 5

6. Transmission and Brake System ................ Section 6

7. Seats ............................................................. Section 7

8. Seat Belt and Air Bag.................................. Section 8

9. Ventilation, Heating, and Air Conditioning .. Section 9

10. Turbocharger System .................................. Section 10

11. Convenience Devices .................................. Section 11

12. In Case of Emergency ................................. Section 12

13. Service and Maintenance ........................... Section 13

14. Lamps ........................................................... Section 14

15. Vehicle Care................................................. Section 15

16. Index ............................................................. Section 16

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-00_Foreword.p65 2006-10-02, ¿ÀÈÄ 3:05Page 5 Adobe PageMaker 6.5K/Win

Q100-00_Foreword.p65 2006-10-02, ¿ÀÈÄ 3:05Page 6 Adobe PageMaker 6.5K/Win

0

General

TABLE OF CONTENTS

Recommended Fluids and Lubricants ....... 0-2

Dimensions ................................................... 0-3

Specifications .............................................. 0-5

Vehicle Identification .................................. 0-8

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 1 Adobe PageMaker 6.5K/Win

16

RECOMMENDED FLUIDS AND LUBRICANTS

10

11

12

13

14

15

16

0

1

Engine Oil

Descriptions SpecificationsCapacity

D20DT

2

ACTYON

ACTYON SPORTS

G23D

D20DT G23D

4WD 2WD

2WD ALL, 4WD M/T 4WD A/T 2WD A/T 4WD ALL, 2WD M/T

3

Engine Coolant

4

5

Automatic Transmission Fluid Manual Transmission Fluid

6

7

Transfer Case Fluid

8

Axle Oil

Front

9

Rear

Brake / Clutch Fluid Power Steering Fluid

WARNING

• Use only Ssangyong recommended fluids and lubricants.

• Do not mix any different types or brands of oils or fluids. This may cause damages.

• Keep the specified levels when adding or replacing the fluids.

Automatic Transmission Manual Transmission Solid Axle Suspension

7.5

10.5 ~ 11.0

9.5

3.6

3.4

1.4

1.9

2.0

1.9

2.0

As required

1.0

Quality class: Ssangyong genuine engine oil (Approved by MB Sheet 229.1 or 229.3) Viscosity: MB sheet No. 224.1 Ssangyong genuine coolant (Anti-freeze:SYC-310, Anti-freeze:water = 50:50) Ssangyong genuine oil (CASTROL TQ 95) Ssangyong genuine oil (ATF DEXRON II)

Ssangyong genuine oil (ATF DEXRON III) Ssangyong genuine oil (SAE 80W/90, API GL-5) Ssangyong genuine oil (SAE 80W/90, API GL-5)

Ssangyong genuine oil (DOT4) Ssangyong genuine oil (ATF DEXRON II or III)

0-2

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 2 Adobe PageMaker 6.5K/Win

DIMENSIONS (ACTYON)

Unit: mm

Top View

Side View

1880

1735

Front View

1570

Rear View

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

2740

4455

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 3 Adobe PageMaker 6.5K/Win

1570

15

16

0-3

DIMENSIONS (ACTYON SPORTS)

Unit: mm

10

11

12

13

14

0

Top View

Front View

1

2

3

4

1900

5

6

1570

7

8

Side View

Rear View

9

1755

15

16

0-4

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 4 Adobe PageMaker 6.5K/Win

3060 4965

1570

SPECIFICATIONS (I)

* ( ) Optional, [ ] 2WD

General

Engine

Descriptions

Overall length (mm) Overall width (mm) Overall height (mm) Gross vehicle weight (kg) Curb vehicle weight (kg) Fuel Fuel tank capacity ( ) Min. turning radius (m) Numbers of cylinders/ Compression ratio Total displacement (cc) Camshaft arrangement Max. power Max. torque Idle speed Cooling system

Coolant capacity ( ) Lubrication type Max. oil capacity ( )

(when shipping)

Turbocharger and cooling type

D20DT D20DT

4,455 1,880

1,735 A/T M/T A/T M/T

310 Nm / 1,800 ~ 2,700 rpm

Gear pump, forced circulation

Turbocharger, air-cooled

2,520

1,974 [1,865] 1,952 [1,843]

Diesel

4 / 17.5:1

1,998

DOHC

141 PS / 4,000 rpm

780 ± 50 rpm

Water- cooled /

forced circulation

10.5 ~ 11.0

75

5.6

8.2

ACTYON

Gasoline

4 / 10.4 : 1

150 PS / 5,500 rpm

214 Nm / 3,500 ~ 4,600 rpm

750 ± 50 rpm

G23D

←

2,295

←

7.9

–

ACTYON SPORTS

4,965 1,900

1,755 2,740 [2,640] 2,740 [2,640] 1,986 [1,877] 1,963 [1,854]

Diesel

←

6.18

4 / 17.5:1

1,998

←

141 PS / 4,000 rpm

310 Nm / 1,800 ~ 2,700 rpm

780 ± 50 rpm

←

8.2

←

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 5 Adobe PageMaker 6.5K/Win

0-5

SPECIFICATIONS (II)

* ( ) Optional, [ ] 2WD

10

11

12

13

14

15

16

0

1

2

3

4

5

6

7

8

9

Manual

Transmission

Automatic

Transmission

Transfer Case

Clutch (M/T)

Power

Steering

Descriptions

Operating type

Gear ratio

Model Operating type Gear ratio

Model Type Gear ratio

Operating type Disc type Type Steering angle

1st 2nd 3rd 4th 5th Reverse

1st 2nd 3rd 4th Reverse

High (4H) Low (4L)

Inner Outer

ACTYON

D20DT D20DT

Semi- Remote control, floor

change type

4.315

2.475

1.536

1.000

0.807

3.919

Electronic, 4-speed

Floor change type

2.741

1.508

1.000

0.708

2.429

2WD, Part-time

Planetary gear type

1.000 : 1

2.483 : 1

Hydraulic type

Dry single diaphragm type

Rack and pinion

35.7°

32.1°

G23D

←

Part-time

←

ACTYON SPORTS

←

–

←

0-6

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 6 Adobe PageMaker 6.5K/Win

SPECIFICATIONS (III)

* ( ) Optional, [ ] 2WD

Front Axle

Rear Axle

Brake

Suspension

Air

Conditioner

Electrical

Descriptions

Drive shaft type Axle housing type Drive shaft type Axle housing type Master cylinder type Booster type

Brake type

Parking brake

Front suspension Rear suspension Refrigerant (capacity)

Battery type / Capacity (V-AH) Starter capacity (V-kW) Alternator capacity (V-A)

Solid axle suspension

Front wheels Rear wheels

Solid axle suspension

ACTYON

D20DT D20DT

Ball joint type Build-up type

Semi-floating type

Build-up type Tandem type

Vacuum assisted

booster type

Disc type

Drum (disc)

Cable type

(internal expansion)

Wishbone + coil spring

5-link + coil spring

R-134a (650 ± 30g)

MF / 12 - 90

12 - 2.2

12 - 115

G23D

←

12 - 1.2

←

ACTYON SPORTS

←

12 - 2.2

←

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 7 Adobe PageMaker 6.5K/Win

15

16

0-7

VEHICLE IDENTIFICATION

0

1. Engine Number

1

2

3

4

5

6

2. Chassis Number

7

Gasoline Engine: The engine num-

ber is stamped on the upper rear

8

left-hand side of the cylinder block.

The chassis number is stamped on the frame behind the front right tire.

9

10

3. Certification Label

11

12

13

14

15

16

Diesel Engine: The engine number is

stamped on the lower area of cylinder block behind the Intake manifold.

0-8

Q100-00-General.p65 2006-10-02, ¿ÀÈÄ 3:05Page 8 Adobe PageMaker 6.5K/Win

The certification label is located on the driver’s door sill.

0

Safety Precautions

TABLE OF CONTENTS

Checks before Starting a Journey.............. 1-2

Starting the Engine and Driving Off the

Vehicle ......................................................... 1-4

Safety Precautions ...................................... 1-6

Direct Injection Type Diesel Engine ..........1-11

Precautions Regarding Unauthorized

Modification & Alteration .......................... 1-13

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 1 Adobe PageMaker 6.5K/Win

16

CHECKS BEFORE STARTING A JOURNEY

CHECK THE VEHICLE OUTSIDE

0

1. Check the tire inflation and wear.

1

2. Check the engine oil and other fluid/oil levels in the en-

2

3

4

5

6

7

gine compartment.

3. Clean the windshield and rear glasses, side mirrors, and room mirrors.

4. Make sure that the engine hood and tailgate are properly closed.

5. Make sure that there are no obstacles in the danger area around the vehicle.

8

9

10

11

12

13

14

CHECK THE VEHICLE INSIDE

1. Make sure that all doors including the tailgate are properly closed.

2. Adjust the driver’s seat for comfortable driving.

3. Adjust the outside and inside rear view mirrors.

4. Fasten the seat belts and be sure that all other occupants have fastened theirs properly.

5. Check operation of the parking brake.

6. Check that all appropriate warning lights are operating when turning the ignition key to the “ON” position.

7. Check the operations of the clutch pedal, accelerator pedal, and brake pedal.

8. Make sure that there are no obstacles in the danger area around the vehicle.

15

16

1-2

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 2 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS

FUEL RECOMMENDATION

Commercially available high-quality fuels are suitable. Fuel quality has a decisive influence on the power output, driveability and life of the engine. The additives contained in the fuel play an important role in this connection. You should therefore use only high-quality fuels.

Diesel Engine

Use diesel fuel at 50 cetane rating or higher.

Gasoline Engine

Fuel with too low an octane number can cause pre-ignition (detonation). Ssangyong can not be held liable for resultant damage.

CAUTION

For correct octane rating setting and other use of gasoline (ex. Leaded), consult your Ssangyong Dealer.

CAUTION

Engine and exhaust system will be damaged.

• Do not use leaded fuel to the vehicle for unleaded fuel.

• Use the fuel with specified or higher Research Octane Number recommended for your country by Ssangyong.

It is not covered by warranty.

Do not Use Methanol

Fuels containing methanol (wood alcohol) should not be used in your vehicle. This type of fuel can reduce vehicle performance and damage components of the fuel system.

NOTE

The warranty policy will not cover damage of the fuel system and any performance problems that are caused by the use of methanol or fuel containing methanol.

Operation in Foreign Countries

If you are going to drive your vehicle in another country, be sure to:

• Observe all regulations regarding registration and insurance.

• Check that a suitable fuel is available.

Vehicle Fueling from Drums or Storage Containers

For safety reasons (particularly when using noncommercial fueling systems) fuel containers, pumps and hoses must be properly earthed.

Static electricity build up can occur under certain atmospheric and fuel flow conditions if unearthed hoses, particularly plastic, are fitted to the fuel dispensing pump.

It is therefore recommended that earthed pumps with integrally earthed hoses be used, and that storage containers be properly earthed during all noncommercial fueling operations.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 3 Adobe PageMaker 6.5K/Win

1-3

STARTING THE ENGINE AND DRIVING OFF THE VEHICLE

0

1

2

3

4

5

6

7

8

1. Apply the parking brake.

9

2. Make sure that there are no persons or obstacles in the

10

11

12

13

14

15

dangerous area around the vehicle.

CAUTION

The engine with an automatic transmission equipped vehicle can be started only when the selector lever is at the “P” or “N” position. The engine with a manual transmission equipped in ve-

hicle can be started only when the clutch pedal is fully depressed. Do not turn the ignition key to the “START” position while the

engine is running. It could result in serious start motor damage.

3. • Automatic transmission equipped vehicle Move the selector lever to the

the brake pedal.

• Manual transmission equipped vehicle

Move the gearshift lever to the Neutral position and fully depress the brake pedal and the clutch pedal.

WARNING

Depress the brake pedal when the selector lever is at the “P” position. Never depress the accelerator pedal.

“P” position and depress

16

1-4

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 4 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS

4. • Diesel engine equipped vehicle: Insert the ignition key into the key cylinder and turn it to

the

“ON” position without depressing the accelerator

pedal. As soon as the glow indicator ( the key to the

• Gasoline engine equipped vehicle:

Turn the ignition key to “ON” position and check the appropriate warning lights are operating.

5. Release the key when the engine starts. If your vehicle is equipped with a manual transmission and is engaged at neutral (N), it is ok to release the clutch pedal when the engine runs.

6. Warm up the engine in idling speed. Do not warm up the engine excessively.

“START” position to start the engine.

) goes out, turn

7. Make sure that there are no persons or obstacles in the danger area around the vehicle.

8. Release the parking brake.

9. • Automatic transmission equipped vehicle Keep the brake pedal depressed and shift into the

position. Make sure that the position indicators of “D” are coming on. Slowly release the brake pedal to begin moving.

• Manual transmission equipped vehicle

Keep the brake pedal and clutch pedal depressed and shift into the gradually depress the accelerator while slowly releasing

the clutch to begin moving.

“1” position. Release the brake pedal and

“D”

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 5 Adobe PageMaker 6.5K/Win

1-5

SAFETY PRECAUTIONS

10

11

12

13

14

15

16

0

1

Ignition Key/Remote Control Key

1. Never use any duplicated key not provided by

2

3

4

5

6

7

8

9

Ssangyong. It may cause a fire due to an overload in the electric circuit.

2. If you lose your keys, you have to replace the whole key set to prevent from theft.

3. Avoid shock to the transmitter in the remote control key and do not get it wet.

4. Only use the batteries with the same specifications to replace the discharged battery. Do not reverse the polarity.

Turbocharger System

If the oil supply for the bearing assembly of the fast rotating turbo charger stops, the stop will cause the turbocharger to seize. Therefore, the following cares are necessary to prevent the seizure.

1. After starting the engine, let it run for approx. 2 minutes at idle speed (Avoid acceleration or driving off the vehicle).

2. After changing the engine oil and oil filter, start the engine and let it run for approx. 2 minutes at idle speed (Avoid acceleration or driving off the vehicle).

3. Do not stop the engine immediately after coming back from high load driving (such as high speed driving or driving on long slope). Let the engine run for approx. 2 minutes at idle speed to cool it down.

SAFETY PRECAUTIONS (I)

Air Bag

1. Never impact the air bag installations by hands or tools.

2. The air bag system serves as a supplement to the seat belt. Make sure that you and your passengers always fasten the seat belts properly even if the air bags are installed in the vehicle.

3. Do not place any objects on the air bag inflation location. You may be injured by those objects during deployment.

4. The air bag system should be inspected 10 years after installation regardless of its appearance and other conditions.

5. Repairs to the air bag system should be done only by a Ssangyong Dealer or Ssangyong Authorized Service Center.

6. Do not diagnose the circuit with a circuit tester. Do not attempt to modify any air bag components including the steering wheel, air bag mounting area, and harness.

7. Never install a child restraint in the front seat. The children on the restraint could be seriously injured by the air bag in a collision.

8. The deployed air bag unit should be removed from the vehicle and replaced with a new one.

9. When the air bag is deployed, the relevant components will be very hot, so do not touch them until they have cooled down.

10. A person who is smaller than 140 cm should sit in the rear.

1-6

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 6 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS

SAFETY PRECAUTIONS (II)

0

Hazardous Materials

Do not store any flammable items or disposable lighters in the console box or other spaces. In hot weather, they can explode and cause a fire.

Genuine Parts

Always use only Ssangyong genuine parts for replacement. Ssangyong is not liable for any damage caused by the use of non-Ssangyong genuine parts and accessories.

Tire

1. Be sure to use the same size and type of tires from the same manufacturer on all wheels. Otherwise, damage can be caused to the powertrain.

2. Keep the specified tire inflation pressure.

3. Make sure that the spare tire is ready for use at any time. After installing the spare tire on a wheel, do not drive for a long distance. Instead, visit a nearby dealer or tire shop to replace the spare tire with a regular tire for driving.

4. Always check the tire surface for damage and uneven wear before driving and replace it if needed.

5. Using tires of different specifications may cause high fuel consumption, long stopping distance, vehicle body vibration, heavy steering operation, and poor ABS operation.

Power Window

1. When you operate the rear windows from the driver’s seat while a child sits in the rear, make sure that no body part of the child is between the window and the window frame.

2. When carrying children in the rear seat, press the rear door window lock switch to make the rear door switches inoperative.

3. Make sure that all passengers have their body parts such as hands inside the vehicle.

4. When closing the windows, be aware of safety conditions before operation.

Glass Care

1. Be careful not to damage the rear heated wire and diversity antenna when cleaning the rear glass.

2. Do not install any sunshield on the windshield glass and rear glass. It may adversely affect the rear heated wire and receiving sensitivity of the antenna.

3. The rain and automatic light sensors are installed on the upper middle front of the windshield (if equipped). If these sensors are contaminated or covered with various coating sprays, the automatic rain sensing wipers and lights may not work properly.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 7 Adobe PageMaker 6.5K/Win

1-7

0

1

Child Restraint

When transporting infants or small children, an appropri-

2

ate child restraint system should always be used. The child

3

restraint system should be appropriate for your child’s

SAFETY PRECAUTIONS (III)

weight and height and properly fit the car’s seat. Accident statistics indicate that children are safer when properly restrained in the rear seat rather than in the front seat.

10

11

12

13

14

15

16

4

5

6

7

8

9

1-8

WARNING

• Infants and small children should always be restrained in an infant or child restraint.

• NEVER INSTALL A REAR-FACING CHILD RESTRAINT IN THE FRONT SEAT WITH FRONT PASSENGER AIR BAG.

• A child in a rear-facing child restraint installed in the front seat can be seriously injured if the front passenger air bag inflates. Secure a rear-facing child restraint in the rear seat.

• A front-facing child restraint should be secured in the rear seat whenever possible. If installed in the front passenger seat, adjust the seat as far back as it will go.

• When installing a child restraint system, follow the instructions provided by the manufacturer.

• When not in use, keep your child restraint system secured with a seat belt or remove it from the vehicle.

• Do not hold a child while riding in a vehicle.

• Never let a child stand or kneel on any seat.

• Do not allow a child in the cargo areas while the vehicle is moving.

SAFETY PRECAUTIONS

WARNING

• Children who have outgrown child restraint systems should sit in the rear seat and be restrained with the seat belt. If child’s seating position has a shoulder belt which is on or very close to the face or neck, move the child close to the center of the vehicle, slightly inboard of the shoulder belt, or move the child to a position without a shoulder belt if possible.

• Please note that the three point seat belt is designed for a person who is taller than 140 cm.

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 8 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS (IV)

0

Starting the Engine

1. Turn the ignition key to the “ON” position and wait until the glow indicator goes out. After then, turn the ignition key to the the engine starts.

2. Even if the engine does not start, do not hold the ignition key at the seconds.

3. If the engine does not start, wait 10 seconds before trying again.

4. If the engine fails to start, turn the key back to the

“START” position and hold it until

“START” position for more than 10

“LOCK” position and wait for 10 seconds.

5. Do not turn the ignition key to the while the engine is running.

6. The engine in an automatic transmission equipped vehicle can be started only when the selector lever is at

the “P” or “N” position. The engine in a manual transmission equipped vehicle

can be started only when the clutch pedal is fully depressed.

7. Do not leave the ignition key at the “ON” or “ACC” position when the engine is not running. This could cause battery discharge.

“START” position

Warming Up the Engine

1. Do not drive without warming up the engine. Driving immediately after starting the engine may decrease the engine’s life expectancy. Warm up the engine before moving your vehicle.

2. Do not warm up the engine excessively. Warm up the engine just until the coolant temperature gauge begins to move.

3. Excessive engine warming increases the fuel consumption and air pollution. An optimized warming up time is approx. 2 minutes. Do not accelerate the engine during the warming up period.

Driving the Automatic Transmission Equipped Vehicle

1. Keep the brake pedal depressed and shift the gear selection lever into the “D” position. Make sure that the

“D” light is on the instrument cluster.

Drive off the vehicle by releasing the brake pedal slowly.

2. To avoid any possible damage to the automatic transmission, do not abruptly drive off or accelerate the vehicle after shifting the gear selection lever into

“D” position. Especially on a hill, move the lever

the to the and wait for a couple of seconds until the position indicator of

3. Your vehicle may move backward on a steep hill even if the shift lever is engaged into the “D” position. Therefore, always depress the brake pedal when you need to stop on such a hill.

“D” position with the brake pedal depressed

“D” is on the instrument cluster.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 9 Adobe PageMaker 6.5K/Win

1-9

10

11

12

13

14

15

16

0

1

Cautions While Driving

1. Do not turn off the engine while the vehicle is in motion.

2

3

4

5

6

7

8

9

The power steering function and the brake assist function will be deactivated.

2. Do not attempt to adjust the driver’s seat, rear view mirrors, or steering wheel while driving. Adjustments should be done before driving.

3. While driving, do not depress the brake pedal when the accelerator pedal is depressed. Otherwise, the response from the accelerator pedal may be delayed. This symptom is the safety function to protect the vehicle’s drive system. This symptom can be eliminated if you depress and release the accelerator pedal once when the brake pedal is not depressed.

4. Do not operate the steering wheel abruptly. This will cause unstable driving situations and can end with an unexpected accident.

SAFETY PRECAUTIONS (V)

Abrupt Start, Acceleration and Stop

1. Avoid abrupt starts, acceleration or stops. It may cause high fuel consumption or an accident.

2. Gently accelerate and decelerate the engine.

Fade

Reduction or loss in braking force due to loss of friction between the brake pads and disc, caused by heat buildup through repeated or prolonged brake application.

Engine Brake

When driving down a long slope, use the engine brake effect by downshifting the transmission in steps according to the driving conditions while using the service brake. An excessive operation of the service brake could result in a “Fade” or “Vapor Lock” effect.

Stopping and Parking the Vehicle

1. Never leave infants and children unattended in the vehicle with the doors locked. They can move the vehicle unexpectedly. They can be suffocated in especially hot weather.

2. When parking the vehicle on a hilly road, apply the parking brake and chock the blocks under the wheels. Place the gear selector lever to the “P” position (automatic transmission equipped vehicle).

3. If possible, do not stop and park the vehicle on the steep road.

Extinguisher

Keep it ready for use at any time. Be familiar with how to use it. For more information, read the label on the surface of the fire extinguisher.

Vapor Lock

When the brake is excessively applied on a downhill, some bubbles can be formed in the brake cylinder or in brake lines. Because of these bubbles, hydraulic braking pressure cannot be transferred to breaking units of the vehicle despite the fully depressed brake pedal.

1-10

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 10 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS

DIRECT INJECTION TYPE DIESEL ENGINE

CAUTIONS FOR DIRECT INJECTION TYPE DIESEL ENGINE (I)

Direct Injection (DI) Type Diesel Engine

Compared to Indirect Injection (IDI) Type Diesel Engine that uses a mechanical fuel injection system, a Direct Injection (DI) Type Diesel Engine controls the amount of injected fuel and the fuel injection timing electronically. This advanced engine enhances the output power and reduces the noxious exhaust

gas (CO, HC, NOx....). Because the Direct Injection Diesel En-

gine is operated by high pressure (1,600 bars), any removal, modification or service of the engine may contaminate the inside of the system and cause the system to malfunction. In that case, the malfunction and any related systems are not under warranty of this company.

Warning for Using Low Quality Fuel

The fuel system in a DI engine equipped vehicle has many precisely machined components. Using low quality fuel could result in serious damage to the engine due to the water or impurities in the fuel.

Never use the low quality fuel.

System Safety Mode

When the vehicle has a system error, the vehicle operates in safety mode to maintain minimum driving conditions and to prevent the system from being damaged. In this mode, the engine driving force may be decreased or the engine may stall. When this happens, have the system checked at a Ssangyong Dealer or Ssangyong Authorized Service Center.

Supplementary Heating Device

- FFH (Fuel Fired Heater)

This supplementary heater is a fuel burning type and improves the heating effect by increasing the engine coolant temperature.

- PTC (Positive Temperature Coefficient)

This supplementary heater is an electrical air heating type and installed on the heater outlet port. This device improves the heating effect by increasing the temperature of flowing air into the passenger room.

FFH Operation

The FFH system operates up to more than 2 minutes to burn the residual fuel inside the system when stopping the engine during its operation.

Therefore, a certain period of FFH operation after stopping the engine is not a malfunction.

In an initial operating stage, the fuel pump generates the operating sound and the FFH heater produces white smoke. These are normal states to fill the fuel into the FFH fuel line.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 11 Adobe PageMaker 6.5K/Win

1-11

10

11

12

13

14

15

16

0

CAUTIONS FOR DIRECT INJECTION TYPE DIESEL ENGINE (II)

1

Engine Check Indicator Priming Pump Operating

2

3

4

Water Separator Warning Light

Conditions

Can be performed when engine oil is changed

5

6

The Engine check indicator on the instrument cluster comes on when the

7

fuel or major electronic systems of the engine are not working properly. As a

8

result, the engine’s power output may decrease or the engine may stall. If this

9

happens, please visit the nearest Ssangyong dealer or authorized service operator.

WARNING

• When engine check warning light comes on, immediately stop driving and have the engine system checked at a Ssangyong Dealer or Ssangyong Authorized Service Center.

• Drain the water from fuel filter & water separator immediately after the water separator warning light comes on.

• The fuel system in the engine may get seriously damaged if you keep driving while the warning light is on.

When the water level inside of the water drain in the fuel filter exceeds a certain level, this warning light and an alarming sound are activated. In addition, the driving force of the vehicle decreases. If this happens, immediately drain the water from the fuel filter. Please refer to Chapter 5 “How to drain the water from the fuel filter” in this manual.

1. When completely consumed the fuel

2. After draining the water from the fuel filter

3. After replacing the fuel filter

- If this happens, pump fuel until the

priming pump is fully filled. Then, start the engine.

Priming Pump

1-12

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 12 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS

PRECAUTIONS REGARDING UNAUTHORIZED MODIFICATION & ALTERATION

PRECAUTIONS REGARDING UNAUTHORIZED MODIFICATION & ALTERATION (I)

Do not modify this vehicle.

If unauthorized modification is made on the vehicle, the company is not liable for repairing the modified parts even during the term of warranty. Other part problems caused by modification are also not covered.

The vehicle you bought is equipped with a large number of precision parts that have passed through countless experiments and tests. These parts are deeply and systematically interwoven. Therefore, if any part is modified or altered without authorization, said parts may be damaged from the decrease in performance or overloading, which can then cause critical damage to the vehicle and human life.

Do not modify without authorization the driving gear system, including the engine, just to upgrade the vehicle’s performance and beauty.

• Prohibition of using unauthorized modification of the engine or parts for the exhaust

Changing without authorization the preset value in the fuel supply system and inlet, exhaust and electric systems, and changing or adding unauthorized parts is illegal and may cause serious problem with the vehicle’s durability.

In particular, modifying your vehicle into the LPG vehicle might bring serious damage to the vehicle's performance and durability. Not only the engine but also the transmission and wheel alignment are excluded from the warranty.

If you install a wheel dust cover on the tires to enhance the beauty of tire parts, the heat caused by friction in braking might bring serious problems in performance, causing Vapor Lock and Fade phenomena.

Do not modify the car’s audio system and install other additional electronic devices such as wireless communication equipment, rear view camera, LCD TV, and remote starting device.

This vehicle’s electronic system contains electronic circuits and fuses for the installation of standard electric and electronic devices. If you add new devices or circuits using the several existing devices and circuits at a time, electric and electronic devices can be damaged from overloading and may ignite. In addition, when you do drilling work in installing devices such as an antenna may expose the vehicle to rusting.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 13 Adobe PageMaker 6.5K/Win

16

1-13

10

11

12

13

14

15

16

0

PRECAUTIONS REGARDING UNAUTHORIZED MODIFICATION & ALTERATION (II)

1

Do not use the nonstandard tires, wheels, and other re-

2

lated parts.

Installing nonstandard tires such as tires with greater

3

width than prescribed can wear out the power delivery system or friction-damage related parts. In addition, other

4

problems such as increase of fuel consumption and braking distance, vehicle's shudder, and decrease of steering

5

power can all degrade the vehicle’s performance. The

6

speedometer and odometer can also become inaccurate. The vehicle with automatic transmission may have the

7

shock in changing the speed.

8

Do not use duplicate key

A duplicate key might cause malfunction to the ignition key

9

cylinder and deter the ignition motor to return to the original state. If so, electronic circuitry can be damaged and may ignite from the ignition motor’s continuing rotation.

Do not equip the sunroof or color glasses at your discretion.

If you install a sunroof by cutting the vehicle’s roof, rust and leakage may occur in the cut part. Installing color glasses to block ultraviolet rays and better appearance may cause leakage and other many problems.

Do not equip the vehicle with bumper guards sold in the market.

Installing bumper guard or other guard bars that are being sold in the market may cause problems in parking and stopping due to the extended length of vehicle, and increase in fuel cost due to additional vehicle weight, and rusting may occur in the holes for equipping the guards. And because of the absence of shock absorber in the bumper guard, even accidents during low-speed driving will be much serious compared with the damage that unmodified cars might sustain.

Do not modify or replace the vehicle flooring or the seats at your discretion.

• When replacing the interior flooring of vehicle with laminated paper

To improve the comfort of cushion and to facilitate the cleaning of the vehicle, some drivers replace the flooring with laminated paper after removing the seats. However, this may cause damage to the various electronic system control units and wiring. This also may hinder the function of the seat rail that enables for the seat to move forward and backward. In this case, the locking system to fix the location of seats may malfunction, which might lead to a serious accident if the loose seats tilt forward or backward during an uphill climb or downhill descent.

1-14

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 14 Adobe PageMaker 6.5K/Win

SAFETY PRECAUTIONS

PRECAUTIONS REGARDING UNAUTHORIZED MODIFICATION & ALTERATION (III)

• When exchanging the seats with new ones or equipping separate seat covers.

There are several types of seat covers according to role and function although with the same vehicle type. Replacing the seats with new ones may alter the wiring system or over-use the wires because a seat has various electric connections and wiring diagram. As mentioned earlier, this may damage the wiring and related equipment or cause fire due to the overloading on the rated capacity.

In addition, replacing the seat cover may damage the electronic equipment caused by cut or pressured wire. Such a situation may also cause ventilation problems, fire, or noise.

Do not equip with a separate accessory or assistant device on the vehicle operational device.

Making the selection lever longer or equipping with an accelerator pedal and brake pedal pad may make the driver prone to make a mistake while driving.

Do not install products that may decrease the driving resistance such as sticker, molding, air dam, or windproofing products.

The sticker’s adhesives may damage the coated surface of the vehicle. If parts of the car are drilled to attach molding and other functional parts, the area near the holes will rust and other unfamiliar sound may occur while driving. Especially if the attached parts are not fixed well, it may damage the vehicle or even cause a fatal accident.

In using audio in the vehicle, do not use illegally copied CD and DVD, which violates relevant laws. Such discs can also cause malfunction of the audio head unit and changer. In addition, such discs may also not play properly.

When installing the vehicle with unauthorized parts or modifying it in ways including the cases mentioned previously, please keep in mind that the changed parts and related problems with changed auto parts shall not be covered by warranty.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

SAFETY PRECAUTIONS

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 15 Adobe PageMaker 6.5K/Win

15

16

1-15

MEMO

.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

Q100-01-Safety Precautions.p65 2006-10-02, ¿ÀÈÄ 3:05Page 16 Adobe PageMaker 6.5K/Win

0

Ignition Key, Remote Control Key

TABLE OF CONTENTS

Remote Control Key* and Ignition Key ...... 2-2

Remote Control Key Functions ................... 2-4

Key Functions .............................................. 2-8

Immobilizer System* ................................. 2-10

Opening and Closing the Doors and

Tailgate with Ignition Key ......................... 2-12

Theft Deterrent System ............................. 2-13

2

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 1 Adobe PageMaker 6.5K/Win

16

REMOTE CONTROL KEY* AND IGNITION KEY

UNLOCK BUTTON/PANIC BUTTON*

0

1. Unlock (Press and hold)

1

2

3

4

5

6

7

8

9

10

11

If you press and hold this button for a certain period of time, all doors and the tailgate are unlocked and the theft deterrent mode is deactivated.

CAUTION

• The doors cannot be locked by the remote control key if they are not closed.

• If you lose your keys, you have to replace the whole key set to prevent from theft.

2. Panic button (operative only when the ignition key is inserted)

Sounds intermittent buzzer for about 27 seconds

12

WHEN A REMOTE CONTROL KEY IS LOST

When one of remote control keys is lost and a new remote

13

control key is purchased, bring the duplicate of the old remote control key (dual REKES type) to the nearest

14

Ssangyong Dealer or Ssangyong Authorized Service Center

15

and have it recoded. Otherwise, the old key will not work.

DOOR LOCK

Lock (Briefly press)

If you press this button briefly, all doors and the tailgate are locked and the theft deterrent mode is activated.

16

2-2

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 2 Adobe PageMaker 6.5K/Win

IGNITION KEY, REMOTE CONTROL KEY

SIMULTANEOUS OPERATIONS OF ROOM LAMPS

The front and center room lamps come on for 30 seconds when the unlock button on the remote control is pressed and hold.

The lamps immediately go off when the remote lock button is pressed.

AUTOMATIC DOOR LOCKING

If a door is not opened within 30 seconds after unlocking the door with the remote control key, all the doors will be locked automatically.

FUNCTIONS OF IMMOBILIZER

Immobilizer Function

The immobilizer is designed to prevent the possibility of vehicle theft by allowing only authorized keys to start the engine. The same code is encrypted in the transponder inside of the key and in the Engine Control Unit (ECU). When the key is inserted and turned to the “ON” position, the ECU checks the code from the key and allows the engine to start only when the two codes are matched.

CAUTION

• The key and the immobilizer antenna coil should be avoided from any electronic or magnetic equipment which may interfere with the transponder. This may cause malfunctions of the immobilizer function of the key.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

NOTE

• Standard key does not have the remote control function.

• In case of the remote control key, some keys come with the immobilizer and battery as an optional package

IGNITION KEY, REMOTE CONTROL KEY

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 3 Adobe PageMaker 6.5K/Win

14

15

16

2-3

REMOTE CONTROL KEY FUNCTIONS (ACTYON)

PANIC BUTTON*

0

1

1. Panic Function

2

3

4

5

6

7

• If you are in your vehicle and feel threatened while the ignition key is inserted into the key switch, you may activate the alarm to call attention. If you press this button, the warning siren will sound for approx. 27 seconds.

• The siren will stop when any of the buttons on the remote control key is pressed.

NOTE

The alarm sounds only when the ignition key is inserted into the key switch hole.

8

9

10

11

CAUTION

• The doors cannot be locked by remote control if they are not closed.

• The electronic components inside the remote control are very sensitive to moisture or heat. Please do not expose them to moisture or heat.

12

13

14

DOOR LOCK/UNLOCK BUTTON

1. Lock (Briefly Press)

• If you press this button, all doors are locked and the theft deterrent mode is activated.

• When the theft deterrent mode is activated, the emergency hazard lights blink twice.

2. Unlock (Press and Hold)

• If you press and hold this button for about 1 seconds, it unlocks all doors and releases the theft deterrent mode.

• When the deterrent mode is deactivated, the emergency hazard lights blink once.

• The front and center room lamps come on for 30 seconds when the doors are unlocked with the remote control key.

15

16

2-4

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 4 Adobe PageMaker 6.5K/Win

IGNITION KEY, REMOTE CONTROL KEY

BATTERY REPLACEMENT

When the operational distance noticeably decreases or the remote control does not work occasionally, replace the battery with a new one.

Battery Replacement (With REKES)

1. Unscrew two screws from the rear cover.

0

1

2

Battery Specifications

Model

Amount

CAUTION

• Use only the specified battery.

• Make sure that the battery is installed in correct direction.

Battery Replacement (Without REKES)

To replace the battery in the key without REKES, open the cover.

CR 2032 (Rekes key type)

V 625U (without Rekes)

One

2. Pry off the cover by using a small flat screwdriver.

Model: CR2032

3. Remove the battery and insert a new one.

3

4

5

6

7

8

9

10

11

12

13

14

15

16

IGNITION KEY, REMOTE CONTROL KEY

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 5 Adobe PageMaker 6.5K/Win

2-5

REMOTE CONTROL KEY FUNCTIONS (ACTYON SPORTS)

UNLOCK/PANIC BUTTON

0

1. Unlock Door and Tailgate (Briefly Press)

1

• Pressing this button briefly unlocks all doors and the tail-

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

gate and deactivates the theft deterrent mode.

• When the theft deterrent mode is deactivated, the emergency hazard lights blink once.

2. Panic Function (Press and Hold)

• Pressing and holding this button for over 2 seconds in the theft deterrent mode makes the emergency hazard lights blink and sets off the acoustic warning for approximately 27 seconds.

• Pressing any of the buttons on the remote control key deactivates the function.

CAUTION

• With the doors (except for the tailgate) open, they cannot be locked by the remote control key.

• The panic functions operate in the theft deterrent mode.

• The electronic components inside the remote control are very sensitive to moisture or heat. Please do not expose them to moisture or heat.

• After locking the doors using the remote control key, check again if they are locked to make sure the vehicle itself or your personal belongings in the vehicle will not be stolen.

• All doors and the engine hood (except for the tailgate) should be closed to the theft deterrent mode.

DOOR LOCK BUTTON

1. Lock Door and Tailgate (Briefly Press)

• Pressing this button locks all doors and

the tailgate and theft deterrent mode.

• When the theft deterrent mode is

activated, the emergency hazard lights blink twice.

PANIC BUTTON*

(operative only when the ignition key is inserted)

Sounds intermittent buzzer for about 27 seconds

2-6

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 6 Adobe PageMaker 6.5K/Win

IGNITION KEY, REMOTE CONTROL KEY

BATTERY REPLACEMENT (WITH REKES)

These procedures are both for general remote control or rechargeable keys.

1. Undo the two screws on the rear cover.

BATTERY REPLACEMENT (WITHOUT REKES)

To replace the battery in the key without REKES, open the cover.

0

1

2

3

4

WHEN A REMOTE CONTROL KEY IS LOST

When one of remote control keys is lost and a new remote control key is purchased, bring the duplicate of the old remote control key (dual REKES type) to the nearest Ssangyong Dealer or Ssangyong Authorized Service Center and have it recoded. Otherwise, the old key will not work.

BATTERY REPLACEMENT

2. Pry off the cover using a small flat screwdriver. When the operational range noticeably decreases or the re-

mote control begins failing, replace the battery with a new one.

BATTERY SPECIFICATIONS

CR 2032 (Rekes key type) V 625U (without Rekes) One

3. Replace the used battery with a new one.

Model

Amount

CAUTION

• Use only the specified battery. Install the battery with the correct polarity.

IGNITION KEY, REMOTE CONTROL KEY

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 7 Adobe PageMaker 6.5K/Win

5

6

7

8

9

10

11

12

13

14

15

16

2-7

KEY FUNCTIONS

10

11

12

13

14

15

16

0

1

2

3

4

5

6

LOCK Position

• The ignition key can only be inserted or withdrawn.

• The steering wheel can be locked.

7

Unlocking the Steering Wheel

8

To unlock the steering wheel, insert the

9

key and gently turn it to the ACC or ON position while slightly moving the steering wheel right and left.

Key Hole Illumination*

The illumination lamp comes on when opening the door. This lamp goes out about 10 seconds after closing the door.

Key Reminder

The buzzer will sound if the driver’s door is opened while the key is left in the ignition switch on the condition that the ignition key is in the ACC or ON position.

ACC Position

• Allows operation of some electrical accessories with the engine off.

• Unlock the steering wheel.

• The ignition key cannot be removed.

From ACC to LOCK Position:

Turn the key to LOCK position from ACC position while pressing the key.

ON Position

• The engine runs and all electrical accessories can be used.

• The steering wheel is unlocked.

START Position

• Engages the starter. After the engine starts, release the key and it will automatically return to the “ON” position.

Key Hole Illumination

2-8

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 8 Adobe PageMaker 6.5K/Win

IGNITION KEY, REMOTE CONTROL KEY

CAUTIONS WHEN STARTING THE ENGINE

• To unlock the steering wheel, insert the key and gently turn it to the steering wheel right and left.

• The engine in a manual transmission equipped vehicle can only be started when the clutch pedal is fully depressed.

• Diesel engine equipped vehicle: Turn the ignition key to the goes out. After then, turn the ignition key to the

“START” position and hold it until the engine starts.

But do not hold the ignition key at the tion for more than 10 seconds.

• The engine in an automatic transmission equipped vehicle can be started only when the selector lever is at

“P” or “N” position.

the

• Keep the brake pedal depressed when starting the engine.

• If the engine fails to start, even if the engine does not start, turn the key back to the “LOCK” position and wait for 10 seconds. Then try again, before any attempt

to start the engine.

• After starting the engine, let it run for approx. 2 minutes at idle speed. Do not accelerate the engine during the warming up period.

“ACC” position while slightly moving the

“ON” position and wait until the glow indicator

“START” posi-

• A warning buzzer sounds when opening the driver’s door with the key positioned at the position.

• Do not leave the key at the “ACC” or “ON” position when engine is not running. Otherwise, the battery could run down.

• Never press down the accelerator pedal while starting.

• Do not operate the starter for more than 10 seconds at a time. (The starter motor may be damaged.)

• To prevent any damage to the starter, restart the engine from the 10 seconds.

• Never turn the key to the draw the ignition key from the ignition switch while driving. The steering wheel will be locked and you may end up with serious injuries.

• Never use any duplicated key not provided from Ssangyong.

The duplicated key might not turn back to the position. It may cause a fire due to an overload in the electric circuit. In addition, the engine with the immobilizer system cannot be started with the duplicated key.

“LOCK” position after waiting at least

“ACC” or “LOCK”

“LOCK” position or with-

“ON”

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

IGNITION KEY, REMOTE CONTROL KEY

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:05Page 9 Adobe PageMaker 6.5K/Win

2-9

IMMOBILIZER SYSTEM*

The Immobilizer System provides an additional theft deterrent to the vehicle in which it is installed and prevents it from being

0

started by unauthorized persons. The transponder integrated in the key and the engine control unit have the same code. When the ignition key with the integrated transponder is turned to the ON position, the ECU (Engine Control Unit) checks the

1

crypto code of the key and, if correct, allows your vehicle to start the engine.

10

11

12

13

14

15

16

2

3

4

5

6

7

8

9

Immobilizer Key

When the ignition key with the integrated transponder is turned to the ON position, the ECU (Engine Control Unit) checks the crypto code of the key and, if correct, allows your vehicle to start the engine.

Immobilizer Indicator

This indicator comes on when the ignition key is communicating with the engine control unit (during engine starting) and goes out after starting the engine. If this indicator blinks, it may indicate that there is something wrong in the immobilizer system. Have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center.

NOTE

The time needed for communication between the immobilizer key and ECU can vary. When the time is very short, the immobilizer indicator does not come on.

Transponder (Diesel)

Transponder (Gasoline)

Battery

Key plate

2-10

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 10 Adobe PageMaker 6.5K/Win

IGNITION KEY, REMOTE CONTROL KEY

• When the Transponder is Damaged

When the transponder is damaged, you must replace it with a new one and register a new code on the engine control unit at a Ssangyong Dealer or Ssangyong Authorized Service Center. Otherwise, the engine cannot be started.

• When Your Key is Lost

When your key is lost, the encrypted code should be removed from the Engine Control Unit to avoid any vehicle theft. Please contact a Ssangyong Dealer or Ssangyong Authorized Service Center.

WARNING

• In any case, the immobilizer system cannot be removed from the vehicle. If you attempt to remove and damage the system, it is impossible to start the engine. So never attempt to remove, damage or modify it.

• In addition, any remote engine starter cannot be installed to the vehicle equipped with the immobilizer system. So never install any remote engine starter.

CAUTION

• When you modify your vehicle and install a remote engine starter, you may have some problems starting the engine or some fatal accidents.

In the following cases, you may be unable to start the vehicle with the immobilizer.

X When two or more immobilizer keys come into con-

tact with (each) other(s).

X When the key is close to any device sending or re-

ceiving electromagnetic fields or waves.

X When the key is close to any electronic or electric

devices such as lighting equipment, security keys or security cards.

X When the key is close to a magnetic or metal ob-

ject or a battery.

CAUTION

• If the indicator remains blinking, have the immobilizer system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center.

• Avoid impact to the transponder inside of the key. The transponder can be damaged.

• With a damaged transponder, the engine cannot be started.

• The immobilizer system should be inspected, replaced, serviced, or coded by only qualified service personnel in a Ssangyong Dealer or Ssangyong Authorized Service Center.

• When an old code should be replaced or another key is added, please observe the process personally.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

IGNITION KEY, REMOTE CONTROL KEY

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 11 Adobe PageMaker 6.5K/Win

2-11

OPENING AND CLOSING THE DOORS AND TAILGATE WITH IGNITION KEY

0

1

2

3

4

Locking the door and the tailgate

5

Unlocking the door and the tailgate

6

To Lock the Door:

7

Turn the key to the lock position (toward front of the vehicle) from driver’s

8

door or passenger’s door. All doors and the tailgate will be locked.

To Unlock the Door:

9

Turn the key to the unlock position (toward rear of the vehicle) from

10

driver’s door or passenger’s door. All doors and the tailgate will be unlocked.

11

Automatic Door Unlocking:

12

All doors will be automatically unlocked when the engine is switched off.

13

14

15

16

CAUTION

• When you unlock the door with the ignition key after the door is locked with the remote control (the theft deterrent mode), a warning buzzer sounds. Stop the buzzer by pressing any button on the remote control.

• The tailgate for ACTYON SPORTS cannot be locked or unlocked using the starter key. Also, the theft deterrent mode operates regardless of opening and closing the tailgate. (By using only the remote control key, not the ignition key, it is possible to go into the theft deterrent mode. )

ACTYON ACTYON SPORTS

If the starting key is turned to the arrow pointed direction, the tailgate will be opened.

NOTE

ACTYON SPORTS has no key hole on the tailgate to lock or unlock it.

Pulling the lever opens the tailgate.

2-12

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 12 Adobe PageMaker 6.5K/Win

IGNITION KEY, REMOTE CONTROL KEY

THEFT DETERRENT SYSTEM

ARMING THE THEFT DETERRENT SYSTEM

The theft deterrent system will be armed under the following conditions:

• When all doors are locked with the remote control key, the anti-theft mode will be activated. If the

“UNLOCK” button on the remote control key is pressed and no door is opened within approxi-

mately 30 seconds, all doors are automatically locked again and the anti-theft mode will be activated.

• When the theft deterrent system is armed, the emergency hazard lights blink twice.

CAUTION

• To arm the theft deterrent system, the ignition key should be removed from the ignition switch, all doors including the tailgate and the hood should be closed completely.

• Activation of the theft deterrent system is confirmed by the emergency hazard lights blinking twice.

ACTIVATING THE THEFT DETERRENT SYSTEM

If somebody tries to open the door, the tailgate or the hood without using the remote control key, the alarm will be activated.

• When one of the doors or the tailgate is opened with the ignition key while the deterrent system is armed, the alarm will sound.

• The engine hood or the tailgate is opened from the outside while the deterrent system is armed, the alarm will be activated.

• When the alarm is activated, warning sound and the emergency hazard lights will be on and off every second for 27 seconds.

DISARMING THE THEFT DETERRENT SYSTEM

• Unlock the door by using the remote control key.

• To deactivate the theft deterrent mode at the alarming stage, unlock the door by using the remote control key.

• When the deterrent system is disarmed, the emergency hazard lights blink once.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

IGNITION KEY, REMOTE CONTROL KEY

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 13 Adobe PageMaker 6.5K/Win

2-13

MEMO

.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 14 Adobe PageMaker 6.5K/Win

MEMO

.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 15 Adobe PageMaker 6.5K/Win

MEMO

.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

Q100-02-Ignition Key, Remote Control Key.p65 2006-10-02, ¿ÀÈÄ 3:06Page 16 Adobe PageMaker 6.5K/Win

0

Opening and Closing

TABLE OF CONTENTS

Opening and Closing Devices .................... 3-2

Doors ............................................................ 3-3

Windows ....................................................... 3-5

Sunroof* ....................................................... 3-7

Tailgate ........................................................ 3-9

Loading Goods (ACTYON SPORTS) ......... 3-10

Engine Hood .............................................. 3-12

Fuel Filler Door.......................................... 3-13

3

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 1 Adobe PageMaker 6.5K/Win

16

OPENING AND CLOSING DEVICES

Sunroof Controller Fuel Filler Door

0

Tailgate Opening Switch

Tailgate Opening Key Hole

1

2

3

4

5

Engine Hood Safety

6

Latch Lever

Child Safety Door Lock

7

8

Lock

9

10

11

Fuel Filler Door Release Lever,

12

Engine Hood Opening Lever

13

14

Fuel filler door release lever

Driver’s Door Windows Switch

Door Opening Lever

Unlock

15

16

3-2

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 2 Adobe PageMaker 6.5K/Win

Engine hood opening lever

OPENING AND CLOSING

DOORS

Unlock

Door Lock/Unlock Knob Door Opening Lever

Central Door Lock/ Unlock Switch

Lock

Driver’s door

Door Lock/Unlock Knob

All doors will be locked/unlocked when moving the knob to the respective lock/ unlock direction (only available at driver’s and front passenger’s door).

Door Opening Lever

Pull the door opening lever to open the door.

Lock

WARNING

Children in rear seats can open rear doors. Move the child-safe lever to the “LOCK” position.

NOTE

• The passenger’s door lock/unlock knob and lever have the same functions with those of the driver’s door.

• The door lock/unlock knob on the rear right or rear left door can only lock or unlock its respective door.

• Even though the driver’s door is locked, the door can be opened when the opening lever on the door is pulled.

Child Safety Door Lock

Unlock

Child safety door lock helps prevent from an accidental door open, especially when children are in the vehicle. When the child-safe lever is

in the “LOCK” position, the rear door can be opened only from the outside.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

OPENING AND CLOSING

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 3 Adobe PageMaker 6.5K/Win

3-3

CENTRAL DOOR LOCK/UNLOCK SWITCH

0

1

Driver’s side Passenger’s side

2

3

4

5

6

7

When the door lock/unlock switch is pressed while all doors including the tailgate are locked, all doors will be unlocked. When the switch is pressed again, all doors will be locked.

This switch is not available when any of doors are not fully closed and the vehicle is in theft deterrent mode.

8

Automatic Door Unlocking

9

When the airbag deploys while all doors are automatically locked by the Automatic Door Locking System, the doors

10

will automatically be unlocked.

11

12

WARNING

When damage is done on a door or the body frame by an impact from an accident, the automatic door unlocking system may not work.

Automatic Door Locking

All doors will be automatically locked when you drive over 30 km/h while the doors are unlocked.

CAUTION

When you drive at 30 km/h or a higher speed and try to unlock all doors with the door lock/unlock knob or switch, all doors are automatically locked again.

13

14

15

16

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 4 Adobe PageMaker 6.5K/Win

NOTE

• When any door is open, all doors can not be locked by using the door lock knob, the central door lock/unlock switch, or the remote control.

• When the engine is turned off, all doors become unlocked.

3-4

OPENING AND CLOSING

Room Lamp Coupled Operation

The center room lamp is on or off depending on opening/ closing of doors. When any door is open, the front and center room lamps come on. (However, the main switch of the front room lamp should be pressed.) When any door is closed, the lamp will go out.

WINDOWS

Driver’s Door Window Switch

• When the front of the switch is lightly pressed, the window will be lowered while the switch is pressed.

• When pressed to its end, the window will open automatically until it is fully open. If you want to stop the window while automatic lowering, lightly press the switch again or pull the switch up.

XX

X When closing the window

XX

• When you lightly pull the switch up, the window will move up only while the switch is being operated.

• When pulling the switch up to its end, the window will be fully closed (auto-up operation*). If you want to stop the autoup function, pull up or gently press the switch again.

Rear Left Window Switch

Rear Right Window Switch

Passenger’s Door Window Switch

Window Lock Switch

If the window lock switch is pressed down, passenger’s and rear windows cannot be operated by their switches.

WARNING

When carrying children in the rear seat, press the window lock switch to make the rear window switches inoperative. Do not allow children to play with the power window switch and rear door window switches.

CAUTION

When closing the passenger’s and rear windows from driver’s seat, be aware of safety conditions before operation. Parts of the body can be trapped by the window.

Central Door Lock/ Unlock Switch

Time Lag of Window Operation

The power window can be operated for 30 seconds even after the ignition key is turned to another position from the “ON” position. However, the function immediately stops when one of the front doors is opened.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

OPENING AND CLOSING

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 5 Adobe PageMaker 6.5K/Win

3-5

Anti-Trap System for Driver’s Window*

0

The anti-trap system enables the driver’s window to auto-

1

matically reverse when something is caught in the window as it is closing. When the sensor detects an obstacle, the

2

window will be lowered immediately.

3

4

5

CAUTION

• The anti-trap safety system is available only for the driver’s window equipped with the automatic rolling up (Auto-up) function.

• The anti-trap safety system does not operate when the window is about to touch its window frame.

6

Passenger’s and Rear Window Switch

Passenger’s seat

Door lock/Unlock switch

7

Window switch

8

9

Rear seat

10

11

To move windows up or down, pull up or press the corresponding switch for the window.

12

13

14

15

16

3-6

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 6 Adobe PageMaker 6.5K/Win

OPENING AND CLOSING

WARNING

• Before operating the power windows, make sure that nothing can be trapped (such as heads, hands, or fingers) in the window.

• Make sure that passengers do not stick out their hands or heads from the vehicle while driving.

• Do not allow children to play with any switch, door lever or the gear shift lever.

SUNROOF*

* For your safety, never operate the sunroof when the vehicle is moving.

SUNROOF SLIDING OPERATION

XX

X Open: 2-Step Opening

XX

When the sunroof is closed, two thirds of the sunroof automatically opens if the sunroof open/close switch is turned to the “OPEN” direction (Clockwise). When the switch is turned again to the “OPEN” direction, the sunroof completely opens. When the switch is operated while the sunroof is moving, the sunroof stops sliding.

XX

X Close

XX

When the sunroof is open, turn the switch to the “CLOSE” direction (counterclockwise) to close it completely. To stop the closing sunroof, operate the switch to either direction.

SUNROOF TILTING OPERATION

XX

X Tilt Up

XX

When the sunroof is closed, turn the switch to the “CLOSE” direction (counterclockwise) to tilt up the rear of the sunroof.

XX

X Tilt Down

XX

When the rear of the sunroof is tilted up, turn the switch to the “OPEN” position (clockwise) to close the sunroof.

WIND BUFFETING

When you drive this vehicle with the window or sunroof open at a certain position, you may feel some pressure upon your ears or hear some noises similar to those from a helicopter. This happens because of an influx in air through the window or sunroof and its resonance effect. If this happens, adjust by opening the window or sunroof.

SUNROOF OPEN WARNING BUZZER

If the driver’s door is opened after the ignition key is removed with the sunroof opened, the buzzer will sound to alert you that the sunroof is opened. The buzzer will automatically turn off when the door is closed. After this, the buzzer will not sound even though the door is opened again.

Anti-Pinch Function

To prevent any body parts from being trapped by the sliding sunroof, an Anti-Pinch Function automatically opens the sunroof when an object is trapped.

CAUTION

• This safety function is available for the sliding sunroof close.

• The anti-Pinch function is deactivated just before the sunroof closes.

• If the anti-pinch is operated 3 times in series, the system is changed to manual mode.

WARNING

• When operating the sunroof, be aware of safety conditions before operation. Parts of the body can be trapped.

OPENING AND CLOSING

3-7

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 7 Adobe PageMaker 6.5K/Win

10

11

12

13

14

15

16

0

1

2

3

4

5

6

7

8

9

CAUTION

• Even though the sunroof can be operated when the ignition key is in the ON position (the engine is not running), operating the sunroof repeatedly with the engine turned off will run down the battery. Operate the sunroof while the engine is running.

• When a desired sunroof operation is completed, release the switch. If you keep pressing the switch, it could cause a malfunction.

Especially in the winter, never operate the sunroof if moving areas are iced. Wait until the areas are deiced.

• When leaving the vehicle unattended, be sure to completely close the sunroof. Otherwise, there is a great risk of vehicle theft. Or, the interior of the vehicle will be wet when it rains or snows.

• When the sunroof is slid to its complete open position, the wind buffet phenomenon can increase. If this happens, adjust by opening the sunroof or only open two thirds of the sunroof by using only the first step of the opening system.

Battery Discharge or Power Failure while Operating Sunroof

If the sunroof is stopped midway due to a discharged battery or power failure, you need to re-calibrate the starting point of the sunroof. In addition, the following cases need the re-calibration.

• The sunroof does not completely close or open by operating the switch once.

• The sunroof slides back to close. But the operation does not stop even after a complete close and tilts up the sunroof.

• The opening gap remarkably decreases for the sliding open or tilt up.

• Operation of the sunroof switch does not do anything or work properly.

Re-calibrating the Sunroof Starting Point

• Turn the sunroof switch to the “CLOSE” direction to completely close the sunroof (sliding close).

• When the sunroof stops while the rear of the sunroof is a little open, turn the sunroof switch to the “CLOSE” direction to tilt it completely.

NOTE

When the sunroof is completely opened with the sunroof switch and the switch is turned to the “OPEN” direction for more than 5 seconds, the sunroof cannot completely be either closed or opened by operating the switch once. The sunroof will be moving only when the switch is being turned. When this happens, re-calibrate the beginning point of the sunroof to reactivate the one touch button.

3-8

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 8 Adobe PageMaker 6.5K/Win

OPENING AND CLOSING

TAILGATE

Tailgate Open Switch

When the tailgate is unlocked and your vehicle completely stops, press the tailgate open switch for a while to open the tailgate. When the door lock/unlock switch is engaged in the “LOCK” position, the tailgate will not be opened.

Opening the Tailgate with Ignition Key

When opening the tailgate

Turn the ignition key to the open position on the tailgate.

Tailgate Open/Close

After unlocking the tailgate with the tailgate open switch or the ignition key, lift up the tailgate to open the tailgate completely. To close the tailgate, pull down the tailgate handle to lower the gate. Then, push the tailgate to close it completely.

WARNING

Before closing the tailgate, ensure that none of your body parts are trapped. Also, because the tailgate is heavy, it might unexpectedly fall down and close. To prevent any injury, close the tailgate with caution.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

OPENING AND CLOSING

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 9 Adobe PageMaker 6.5K/Win

3-9

LOADING GOODS (ACTYON SPORTS)

TAILGATE OPENING/CLOSING

0

1

2

3

4

5

6

7

8

9

To open the tailgate, pull the lever to unlock the tailgate and

10

lower it slowly with both hands. After loading, raise and close the tailgate.

11

ACTYON SPORTS has no key hole on the tailgate to lock or

12

unlock it. Locking or unlocking doors using the driver's or passenger’s

13

door opening knob or switch also locks or unlock the tailgate.

14

15

16

NOTE

The door ajar warning light does not come on when the tailgate is open. Make sure that the tailgate is closed before driving.

Opening Tailgate Closing Tailgate

CAUTION

• To open the tailgate, hold the tailgate with both hands, and then lower it slowly. Failing to hold the tailgate with both hands makes it risky of being dropped, which may damage it or cause personal injury.

• To close the tailgate, hold the lever with one hand and raise the tailgate slowly with the other hand as illustrated.

• Before closing the tailgate, ensure that your body parts are completely out of its way. To prevent any injury, close the tailgate with caution.

• Do not let children or senior citizens open the tailgate. The heavy tailgate might unexpectedly fall down and cause injury.

3-10

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 10 Adobe PageMaker 6.5K/Win

OPENING AND CLOSING

LOADING GOODS ON THE DECK

0

Holding hooks

431kg (2WD: 440kg)

Maximum loading capacity

After loading the goods on the deck, ensure they are firmly secured using the hooks on the side panels.

CAUTION

• Keep the deck away from direct sunlight, rain or snow when parking. Water or snow on the deck should be removed before driving.

• Tailgate, deck floor and tailgate hinges can be damaged or broken if you throw the goods or jump on the tailgate while the tailgate is open.

• When holding or tying down the goods using ropes or wires, never use the opening on the upper part of the deck cover. The cover and its painted surface can be damaged.

A/T

453kg (2WD: 462kg)

M/T

WARNING

• Never allow people to get on the deck. It should be used only for loading goods.

• To prevent your goods on the deck from being stolen, unload and store them in a safe place upon arriving at the destination.

• After loading, close and lock the tailgate. Make sure that the tailgate is locked securely by swaying it back and forth.

• Do not drive with the tailgate open.

• Never exceed the tailgate’s loading capacity. Overloading may damage the tailgate, power train, suspension or relevant components, and may also impair the driving safety and place you at risk for an accident.

• Do not alter the cargo area by using canvas or other materials as roofing, or modify installed components. Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety, decrease the vehicle’s fuel economy and cause the panels to rust. Moreover, alterations may increase the total weight of the vehicle and impair the driver’s rearview, which may lead to an accident.

• Avoid loading goods taller than the side panels.

• Do not load metal bars, other sharp-edged materials or particularly voluminous goods that may block the rearview.

During a hard braking, collision or accident, metal bars or other sharp-edged materials that exceed the deck’s loading width or height may get through the rear window and may result in serious, sometimes fatal injury.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

OPENING AND CLOSING

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 11 Adobe PageMaker 6.5K/Win

3-11

ENGINE HOOD

10

11

12

13

14

15

16

0

1

2

3

4

5

6

7

8

9

WARNING

• When you open the hood while the engine is running, extra caution is needed to avoid any injuries by the moving parts in the engine compartment.

• Before driving, try to pull up the front edge of the hood to check that the hood is securely latched.

• When it is windy, extra caution is needed to prevent personal injury. Wind might be able to lift up the hood and the prop rod may be disengaged from its slot. This may result in an unexpected closing of the hood.

1. To open the engine hood, pull the release knob located on the lower left side of the steering wheel to unlatch the engine hood.

2. Slightly lift up the engine hood and raise up the safety latch lever with your fingers. Then, completely lift up the engine hood.

3. After lifting up the hood, secure it with the prop rod. Insert the rod's free end into its slot on the hood to prevent the hood from suddenly closing.

3-12

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 12 Adobe PageMaker 6.5K/Win

OPENING AND CLOSING

FUEL FILLER DOOR

1. Open the fuel filler door ( ) by pulling the release lever located on the lower left side

of the steering wheel.

WARNING

• Always stop the engine when refueling. Use only the designated fuel and low sulfur diesel.

• When refueling, • No smoking.

• No naked flame. • No sparking material.

• If you use inappropriate grade fuel or put improper fuel additives into the fuel tank, the engine and catalytic converter may seriously be damaged.

• Check the type of fuel before fueling your vehicle. If gasoline is fueled into a diesel-engine vehicle, this may have negative effects upon its fuel system and other vehicle systems and bring serious damage to your vehicle.

CAUTION

• Fuel damages paintwork. If fuel spills onto paintwork, immediately wash the affected area with cold water.

• The fuel filler door may not open in cold weather. Gently tap the fuel filler door to open.

OPEN

CLOSE

2. Open the fuel filler cap ( ) by turning it counterclockwise.

3. After refueling, tighten the fuel filler cap by turning it clockwise until you hear clicking sounds.

Then close the fuel filler lid ( properly until it latches.

0

1

2

3

4

5

6

)

7

8

9

10

11

12

13

14

15

16

OPENING AND CLOSING

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 13 Adobe PageMaker 6.5K/Win

3-13

Gasoline Engine

0

Fuel with too low octane number can cause pre-ignition

1

(detonation). Ssangyong can not be held liable for resultant damage.

2

3

4

5

6

7

WARNING

Gasoline vapor is highly flammable. It burns violently and that can cause very bad injuries. When refueling,

• Switch off engine.

• No smoking.

• No naked flame.

• No sparking material.

8

9

10

CAUTIONS WHEN OPENING / CLOSING DOORS

CAUTION

For correct octane rating setting and other use of gasoline (ex. Leaded), consult your Ssangyong Dealer.

CAUTION

Gasoline damages paintwork. If gasoline spills onto paintwork, wash with cold water immediately.

CAUTION

Engine and exhaust system will be damaged.

• Do not use leaded fuel to the vehicle for unleaded fuel.

• Use the fuel with specified or higher Research Octane Number recommended for your country by Ssangyong. Otherwise, it is not covered by warranty.

11

12

• Do not allow children to play with any switch, door lever and the gear shift.

• Before operating the power windows, doors, sunroof, tailgate and fuel filler door, make sure that nothing can be trapped (such as heads, hands, or fingers).

13

• Make sure that the doors, sunroof, tailgate and fuel filler door are completely closed before driving.

14

15

16

Q100-03-Opening and Closing.p65 2006-10-02, ¿ÀÈÄ 3:06Page 14 Adobe PageMaker 6.5K/Win

• When a child is on board, use the child safety functions to avoid any unwanted and dangerous opening of doors or windows.

• Parts of the human body can be trapped in the window or sunroof and can be struck by passing objects. Do not stick hands, heads or anything else out of the openings.

3-14

OPENING AND CLOSING

0

Interior Switches

TABLE OF CONTENTS

Interior Switches ......................................... 4-2

Light Switch ................................................. 4-4

Wiper and Washer Switch .......................... 4-8

Rain Sensing Wiper* ................................. 4-10

Cruise Control Switch (For Auto T/M*) ...... 4-11

Outside Rearview Mirror Control Switch* and

Rear Fog Light Switch* ............................. 4-15

ESP

and ESP System* ....................................... 4-16

Center Switch Panel ................................. 4-18

HDC (Hill Descent Control) Switch* .......... 4-20

Heated Glass Switch ................................. 4-22

(Electronic Stability Program) Switch

OFF

4

Audio Remote Control Switches on

Steering Wheel .......................................... 4-23

4-Wheel Drive System and Switch* ......... 4-24

Cautions When Using 4-Wheel Drive

Mode ........................................................... 4-26

Limited Slip Differential (LSD)* ................ 4-27

Switches in Overhead Console ................ 4-28

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 1 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

0

1

2

3

10

11

12

13

14

15

16

4

5

6

Light switch

Audio remote control switch

Sunroof switch

7

8

Wiper and washer switch

9

Door lock/

unlock switch

Window control switches

Door lock/unlock switch

4-2

INTERIOR SWITCHES

Auto cruise*

4-wheel drive switch Driver seat heating switch

Passenger seat heating switch Headlight leveling switch

Winter/Power mode switch

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 2 Adobe PageMaker 6.5K/Win

0

ESP OFF switch*

Hazard warning flasher switch

Outside rearview mirror* folding switch

Outside rearview mirror control switch

Rear fog light switch*

Outside rearview mirror selection switch

HDC switch*

Tailgate and outside rearview mirror heated glass switch

Windshield heated glass switch

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

TRIP/RESET switch

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 3 Adobe PageMaker 6.5K/Win

16

4-3

LIGHT SWITCH

Light Switch

0

1

Front fog light switch

2

3

4

5

6

You can turn the lights on and off (headlamps, tail lights, position

7

lamps, license plate lamp, turn signal lamps, fog lights) with this

8

switch.

9

10

11

12

13

Turn signal lamp

14

15

Front fog light

16

Headlamp

Rear Fog Light Switch

When the front fog light switch is “ON” press the rear fog light switch to turn the lights on.

Automatic Light (Rain Sensor*)

This senses the ambient illumination intensity to determine the timing for turning the headlamps and tail lights on or off automatically when the light

switch is set to “AUTO”.

High-mounted stop lamp

License plate lamp Tail light/Stop lamp

Turn signal lamp Back-up lamp

Rear fog light*

4-4

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 4 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

AUTOMATIC LIGHT*

0

AUTO

The auto light and rain sensor senses the ambient illumination intensity to determine the timing for turning the headlamps and tail lights on or off automatically when the

light switch is set to

CAUTION

• Do not clean the sensor with detergent or wax.

• On a foggy, snowy, rainy, or cloudy day, be sure to use manual mode. The turning on or off time of the lamps varies depending on the climate, season, or circumstances.

• Any aftermarket tanning film or spray may cause the lighting system to malfunction.

• Ssangyong recommends you to use this device restrictively around only a sunrise or sunset.

• Usually turn the head or tail lights on or off manually.

• Turn on the headlamps when passing through a dark area such as a tunnel.

• On a gloomy day, do not rely on this automatic function. But turn the head or tail lights on or off manually.

• When the switch is turned to the “AUTO” position, room, tail, and head lights might blink for a very short time. It is a normal phenomenon recognizing the automatic setting.

“AUTO”.

Rain Sensor*

This senses the amount of rain to operate the windshield wiper automatically (For detailed information of wiper operation, refer to wiper and washer switch section).

CAUTION

Do not shake and impact the sensor. It may not work properly.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 5 Adobe PageMaker 6.5K/Win

4-5

Battery Saver (Automatically turns off the lights)

0

• To avoid discharging the battery, if the tail lamps are on after the ignition key is removed, a buzzer will sound to alert the driver when the driver’s door is opened.

1

The tail lamps will automatically turn off when the door is closed.(With the light switch on, if the ignition key is removed and all doors are closed, the tail lamps

2

are off due to the battery saver function. However, if you open a door and turn the light switch to the “OFF” position and then to the “ON” position, the tail lamps

3

will stay on after the door is closed.)

4

• To turn the tail lamps on again, insert the ignition key into the ignition switch. Or, turn the light switch to the “OFF” position and then to the “ON” position.

5

6

7

8

9

Headlight Leveling Switch

With the low beam switched on, adjust the aiming angle of headlights to suit the vehicle load.

• To lower the aiming angle, rotate the switch counter-clockwise.

• To raise the aiming angle, rotate the switch clockwise.

10

LIGHT SWITCH

11

12

13

Head-, side-marker, tail, license plate, fog, and instrument cluster lamps

14

come on.

(Headlamps ON)

AUTO

Head- and tail lights automatically turn on or off based upon the intensity of the sunlight analyzed by the automatic light sensor.

(Automatic light ON)

NOTE

According to load condition, adjust the aiming angle of headlights.

15

(Tail lights ON)

16

Side-marker, tail, license plate, fog, and instrument cluster lamps come on.

4-6

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 6 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

OFF

All lights are off.

(Lights OFF)

Headlamp High Beam

To turn on the headlamp high beam, push the lever towards the instrument cluster with the headlamp low beam on. The headlamp high beam indicator

) in the instrument cluster

( comes on when the headlamp high beam is turned on.

Right Turn Signal Switch

NOTE

While the turn signal lamp is turned on, the turn signal indicator in the instrument cluster blinks.

Front Fog Light Switch

To turn on the fog lights, turn this switch while the tail lights or headlamps are turned on.

0

1

2

3

4

DAYTIME RUNNING LIGHT (DRL): DRL Regulation Region Only

For vehicles equipped with the DRL, the tail lights automatically turn on when turning the starter key from ACC to ON.

The headlights turn on as the engine starts.

Passing

Regardless of the position of the light switch, if you hold the lever toward the steering wheel, the headlights are on high beam during the hold. The high beam indicator also illuminates on the instrument cluster during the hold.

WARNING

Driving with high beam headlamps disturbs the approaching vehicle’s visibility for safe driving. Use the high beam headlamp only during very dark situations when it is very hard to see the road.

Left Turn Signal Switch

REAR FOG LIGHT SWITCH*

To turn on the rear fog light, push the rear fog light switch while the front fog light switch is turned on. To turn it off, push the switch again. The rear fog lights are automatically turned off when turning off the light switch or the front fog light switch. Therefore, to turn on the rear fog lights, push the rear fog light switch again after turning on the light switch and the front fog light switch.

With the headlights automatically ON, turning the light switch from OFF to ON turns off the headlights but keeps the tail lights on. (Turning the light switch immediately deactivates the DRL function.)

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 7 Adobe PageMaker 6.5K/Win

5

6

7

8

9

10

11

12

13

14

15

16

4-7

WIPER AND WASHER SWITCH

0

FRONT WIPER SWITCH

1

2

3

4

5

6

7

MIST

The windshield wipers can be operated only when you hold the switch to the “MIST” position. The lever will return to the “OFF” position when released.

OFF

Stop the operation.

8

9

10

AUTO

Operates automatically according to the vehicle speed or amount of rain.

11

12

13

LO

Continuous wipe, slow operation

14

15

16

HI

Continuous wipe, fast operation

FRONT AUTOMATIC WIPING SPEED CONTROL SWITCH

The interval of wiper swings can be adjusted by twisting the control knob upward or downward when the windshield wiper switch is in the AUTO position.

Fast: Fast interval Slow: Slow interval

4-8

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 8 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

REAR WIPER SWITCH (ACTYON ONLY)

There is no rear wiper switch in ACTYON SPORTS.

When the switch is fully turned, washer fluid will be sprayed onto the rear window glass and the wiper will also operate. When the switch is released, it will stop in the Rear Wiper Operation mode and only the wiper will keep operating.

Rear wiper operation

FRONT AUTO WASHER SWITCH

When the front wiper switch is off and this switch is pressed, washer fluid will be sprayed and the wiper will automatically operate 4 times. Then, the fluid will be sprayed again and the wiper will automatically operate 3 times.

0

1

2

3

4

5

6

7

8

9

10

OFF

Rear wiper stops

Wiper and Washer Coupled Operation

Pull the lever briefly (for less than 0.6 seconds):

When the switch is fully turned, washer fluid will be sprayed onto the rear window glass and the wiper will also operate. When the switch is released, it will return to the “OFF” position and turn off the wiper and washer.

One wiping cycle with washer spray Pull and hold the lever for more than 0.6 seconds:

Three wiping cycles with washer spray While being held down, the wiper and washer will

keep working.

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 9 Adobe PageMaker 6.5K/Win

11

12

13

14

15

16

4-9

RAIN SENSING WIPER*

When the wiper switch is in the “AUTO” position, this sensor detects the

0

amount of rain, turns on the wiper, and controls the intermittent wiper intervals.

1

Rain and Auto Light Sensor

2

3

4

5

6

It controls the wiping speed by de-

7

tecting the amount of rain drops.

8

9

10

11

12

13

14

15

16

CAUTION

• When the wiper switch is in the “AUTO” position, the wiper will operate once if the initial engine start is made. This may wear the wiper blades prematurely (especially in winter). Therefore, other than rainy days, set the switch to the “OFF” position. In winter, ensure that the wiper blades are not frozen and are not stuck to the windshield. Otherwise, this may cause some damage to the wiper motor.

• If you use only the wipers when the glass is dry, this could scratch the glass and wear the wiper blades prematurely. Use the wiper with the washer when the glass is dry.

• Turn the wiper switch to the “OFF” position before any car wash to avoid unwanted operation of the wipers.

• When it does not rain, turn the wiper switch into the “OFF” position.

WARNING

When you clean the windshield over the sensor with damp clothes, the wiper may operate suddenly. It could cause serious injury. Make sure to place the wiper switch and ignition switch to the “OFF” position when not in use.

Wiper AUTO Position

AUTO

NOTE

• When the light and wiper switches are in the “AUTO” position, head lights come on if the rain sensor detects any rain. The head lights stay on for 3 minutes after the rain stops.

• The speed of the wipers becomes a little faster when it is dark enough to turn on the automatic lights.

• When the ignition key is in the “ON” position, the wiper will automatically operate once if the wiper switch is turned from the “OFF” to the “AUTO” position. But the wiper will not operate again to prevent any damage to the window even though the wiper switch is turned from the “OFF” position to the “AUTO” position.

4-10

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 10 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

CRUISE CONTROL SWITCH (FOR AUTO T/M*)

CRUISE CONTROL

TYPE A

TYPE B

The cruise control is an automatic speed control system that maintains a desired driving speed without using the accelerator pedal.

The vehicle speed must be greater than 40 km/h to engage the cruise control. This feature is especially useful for motorway driving.

CAUTION

Improper use of the cruise control could be dangerous.

• Do not use on winding roads.

• Do not use in heavy traffic.

• Do not use on slippery, wet roads. This could result in a loss of control, collision, and/or personal injuries.

NOTE

The described speed value may vary slightly depending on the road conditions.

Setting a Desired Speed

TYPE A

TYPE B

1. To operate the cruise control, accelerate to your desired speed using the accelerator pedal over 40 km/h.

2. When the desired speed is reached, push up the ACCEL switch of the cruise control lever or push down the DECEL switch for 1 second per one switching and then release the accelerator pedal slowly.

3. Now, the vehicle is cruised by this system with the set speed.

4. And you can set to other vehicle speeds again with above steps after an accelerator pedal intervention during the cruise control running.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 11 Adobe PageMaker 6.5K/Win

4-11

Accelerating with the Cruise Control System

0

• While the cruise control system is running

1

1. Push up the ACCEL switch of the cruise control lever and

2

3

4

5

6

7

8

9

10

11

12

13

14

hold it until the desired speed is reached without an accelerator pedal intervention.

2. When the desired speed is reached, release the lever.

• While the cruise control system is not running

1. Accelerate using the accelerator pedal over 40 km/h.

2. Push up the ACCEL switch of the cruise control lever and hold it.

3. And then release the accelerator pedal slowly.

4. When the desired speed is reached, release the lever.

• Tap-up while the cruise control system is running

1. Push up the ACCEL switch of the cruise control lever less than 0.5 second per one switching while the cruise control system is running. This is a tap-up switching.

2. When you operate a tap-up switching, the vehicle is accelerated for 1 km/h over the previous set speed.

3. If you want to accelerate for 13 km/h, operate the tap-up switching 13 times without accelerating with the cruise control system.

15

Decelerating with the Cruise Control System

• While the cruise control system is running

1. Push down the DECEL switch of the cruise control lever and hold it until the desired speed is reached without a brake pedal intervention. But the cruise control system cannot maintain the cruise function at less than 35 km/h.

2. When the desired speed is reached, release the lever.

• When the cruise control system is not running

1. Push down the DECEL switch of the cruise control lever and hold it.

2. And then release the accelerator pedal slowly.

3. When the desired speed is reached, release the lever. But the cruise control system cannot maintain the cruise function at less than 35 km/h.

• Tap-down while the cruise control system is running

1. Push down the DECEL switch of the cruise control lever less than 0.5 second per one switching while the cruise control system is running. This is a tap-down switching.

2. When you operate a tap-down switching, the vehicle is decelerated for 1 km/h below the previous set speed.

3. If you want to decelerate for 10 km/h, operate the tap-down switching ten times without the brake pedal intervention.

16

4-12

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 12 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

Recovery of Set Speed

Normal Cancellation of the Cruise Control

0

TYPE A

TYPE B

Even if the cruise control is cancelled, the previous set cruise speed can be recovered by pushing (Type A) or pulling (Type B) toward the cruise control lever when the current vehicle speed is over 60 km/h (Diesel D20DT only) or 40 km/h (Gasoline G23D only) without an acceleration intervention. But if you turn off the ignition switch, the memorized set speed is cleared and you cannot recover the previous set speed.

CAUTION

The resume position should only be used if the driver is fully aware of this speed and wishes to resume this particular speed.

TYPE A

TYPE B

The cruise control system will be canceled when one or more items of the following conditions are applied;

1. When the brake pedal is depressed.

2. When the cruising speed is downed less than 35 km/h.

3. When the OFF switch is operated by pulling the cruise control lever (Type A) or by pushing the ON-OFF switch of the cruise control lever (Type B).

4. When ABD is activated.

And the cruise control system can be operated again in driving state.

CAUTION

Keep the main cruise control switch in the neutral position when not using the cruise control.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 13 Adobe PageMaker 6.5K/Win

4-13

Abnormal Cancellation of the Cruise Control

0

1. When the rapid deceleration is applied without braking.

1

2. When the rapid acceleration is applied without accelera-

2

3

4

5

6

7

8

tion pedal intervention.

3. When the cruise control lever is failed.

4. When the brake switch and the brake light switch input signal are implausible.

And the cruise control system cannot be operated again in driving state. In this case, you should stop the vehicle, and turn off the ignition switch and then turn it on again. After you do that, you can use the cruise control system again. But if the cruise control system isn’t recovered, you should contact a Ssangyong Dealer for diagnosis of the cruise control system.

Using the Cruise Control on Hills

How well the cruise control works on hills depends on the speed, load, and the steepness of the hill.

When going up steep hills, you may have to depress the accelerator pedal to maintain your speed. When going downhill, you may have to brake or shift to a lower gear to keep your speed down.

Applying the brake takes you out of the cruise control.

9

10

11

12

13

14

15

16

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 14 Adobe PageMaker 6.5K/Win

CAUTION

Abnormal changes of the selector lever can damage the engine. Do not move the shift lever to Neural while driving at the set speed. Automatic transmission damage may result.

CAUTION

• The speed that has been set may not be maintained on uphill or downhill slopes.

• The speed may drop to less than the set speed on a steep uphill grade. The accelerator must be used if you want to maintain that speed.

• The speed may increase to more than the set speed on a steep downhill grade. When the speed increases too much, turn off the cruise control.

4-14

INTERIOR SWITCHES

OUTSIDE REARVIEW MIRROR CONTROL SWITCH* AND REAR FOG LIGHT SWITCH*

Outside Rearview Mirror Folding Switch*

To fold the outside rearview mirrors, press the switch. To unfold the mirrors, press again.

Mirror Selection Switch

“L”: Driver side mirror “R”: Passenger side mirror

WARNING

Do not put any tinting film on the door glasses of the front seats. Otherwise, your visibility will decrease.

Outside Rearview Mirror Control

1. Select the driver side mirror (L) or the passenger side mirror (R) with the mirror selection switch.

2. Adjust the outside rearview mirror by pushing the appropriate edge of the switch.

Aiming Switch

Adjust the selected mirror up, down, left, or right by pressing the corresponding edges of the switch to get a desired view.

Rear Fog Light Switch*

When the rear fog light switch is pressed with the front fog light switch on, the rear fog light indicator and the fog lights will be on. If you press the switch again, the rear fog light indicator and the fog lights will be off.

CAUTION

• You can fold and unfold the mirrors within 30 seconds after the ignition is turned to OFF. (However, this function is overridden when the driver’s door is opened with the ignition switch OFF.)

• Do not fold or unfold the outside rearview mirrors manually. It may cause a malfunction of the mirror folding system.

• If you directly spray high-pressured water to the electric remotecontrolled outside mirrors, this may cause some malfunctions in the mirror system.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 15 Adobe PageMaker 6.5K/Win

4-15

ESP

(ELECTRONIC STABILITY PROGRAM) SWITCH AND ESP SYSTEM*

OFF

10

11

12

13

14

15

16

0

ESP Warning Lamp

1

2

3

4

5

6

7

8

9

ESP

If you press the ESP the ESP function stops and the indicator lamp in the instrument cluster comes on.

Press this switch again to resume the ESP function. At this time, the indicator lamp goes out.

Switch

OFF

switch,

OFF

Blinking: When ESP is activated. On: When ESP is deactivated (by pressing the ESP

switch). When ESP system is defective.

When ESP is activated, the indicator light is blinking and a warning buzzer sounds. If this indicator illuminates in spite of an activated ESP, this means a malfunction of the ESP system.

Stopping ESP Function With ESP

If the driving wheels are slipping on snowy or icy roads, the engine rpm may not increase even when you depress the accelerator pedal, and accordingly, you may not be able to move your vehicle. In this case, stop the ESP function by pressing the ESP ESP

switch is pressed, the ESP function stops and

OFF

the vehicle is driven independently from the sensor outputs.

switch. When the

OFF

Resuming ESP Function With ESP

If you push the ESP tion is deactivated (the ESP warning lamp is turned on), the system will be resumed and the ESP warning lamp on the instrument cluster goes out by resuming the ESP system.

switch again when the ESP func-

OFF

Switch

OFF

Switch

4-16

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 16 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

ESP (ELECTRONIC STABILITY PROGRAM) SYSTEM

The Electronic Vehicle Stability Control Program (ESP) is a supplementary driving safety system when your vehicle is unstably moving in a certain situation, such as during a sharp corner. The ESP applies brakes on a certain wheel (s) or controls the engine torque to compensate vehicle stability. These actions help your vehicle avoid dangerous situations. The ESP functions automatically, working only in very unstable conditions; it does not operate under normal driving conditions. If the ESP is engaged, the ESP warning light will flicker on the instrument cluster and a warning alarm will sound.

BAS (Brake Assist System) Function

A certain driver such as a female driver, aged driver, or a driver with a disability is unable to depress the brake pedal as hard as necessary. When the ESP system recognizes any emergency situations requiring hard braking, it automatically delivers an extra high braking pressure to the wheels.

ARP (Active Rollover Protection) Function

This function is a part of the ESP system. When your vehicle moves in an extremely unstable manner, this function helps the vehicle maintain normal stability.

CAUTION

The ARP system more powerfully controls the engine and each wheel than the ESP function. When the ARP is applied, a sudden decrease of vehicle speed or powerful braking force can make steering your vehicle difficult.

CAUTION

• If the ESP warning light comes on, the ESP related system is defective. Make sure to check the vehicle at the nearest Ssangyong Dealer or Ssangyong Authorized Service Center.

• The ESP system does not operate during reverse driving.

• The ESP system activates when the vehicle is unstable to correct the vehicle stability. When the ESP warning lamp and the warning alarm turn on, reduce the speed and pay extra attention to the road.

• The ESP system is only a supplementary device for the vehicle. When the vehicle exceeds its physical limits, it cannot be controlled. Do not rely on the system. Keep driving safely.

• When ESP is applied, you may feel some noise or vibration from the brake pedal or other relevant systems. They are caused by pressure changes in the relevant systems.

Driving Impression when ESP is Working

When ESP is applied in a certain situation (the indicator blinks and a warning buzzer sounds), such as during a sharp turn, you may feel that ESP controls each wheel and different levels of needed braking force are applied to wheels. You may hear some noise or feel some vibrations from the brake pedal or other systems. They are caused by pressure changes in relevant system. You may also notice the engine output decreases even when the accelerator pedal is being depressed.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 17 Adobe PageMaker 6.5K/Win

4-17

CENTER SWITCH PANEL

0

10

11

12

13

14

15

16

1

2

3

4

5

6

7

8

9

HDC (Hill Descent Control) Switch*

The green HDC indicator in the instrument cluster comes on when pressing this switch.

Tailgate and Outside Rearview Mirror* Heated Glass Switch*

Press this switch to turn on the tailgate and outside rearview mirror heated glasses. The heated glass indicator in the switch comes on.

Windshield Heated Glass Switch

Press this switch to turn on the windshield heated glass. The heated glass indicator in the switch comes on.

TRIP Switch

Conversion between the trip meter and ODO meter

Reset the trip meter

Hazard Warning Flasher Switch

To turn on the hazard warning flashers, push this switch. All turn signal lamps will flash simultaneously with the hazard warning indicators.

4-18

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 18 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

TRIP AND RESET SWITCH

TRIP/RESET Switch

TRIP/RESET switch is used for different displays: TRIP A, TRIP B and ODO (the total driving distance)

0

1

2

3

4

5

Total driving

1. Changing the Driving Distance Display Mode

To choose a desired driving distance display mode, press the switch: Changing sequence: ODO - TRIP A - TRIP B - ODO

2. TRIP A and TRIP B Resetting Procedure

TRIP A/B display will be initialized to 0 km when the distance of an individual trip exceeds 999.9 km. If you press and hold the reset button for more than one second in TRIP A or TRIP B mode, trip meter resets to zero.

distance

Trip A

Trip B

* If the meter cluster with “mile” unit is installed,

trip/odo distance is displayed in “mile”.

Unit: 0~999999 km

Unit: 0.0~999.9 km

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 19 Adobe PageMaker 6.5K/Win

6

7

8

9

10

11

12

13

14

15

16

4-19

HDC (HILL DESCENT CONTROL) SWITCH*

0

HDC?

1

HDC stands for Hill Descent Control. When traveling down steep grades, this function allows you to travel at a low speed without any depression of the brake pedal. This convenient function is for only driving down steep grades. Therefore do not use this function for anything other than driving down steep hills.

2

HDC Switch

3

When this button is pressed

4

once, HDC is ready for use. The green HDC indicator on the in-

5

strument cluster comes on. When the button is pressed again, HDC

6

is deactivated and the indicator goes off.

7

8

The HDC Indicator

Green light on: HDC is ready for

9

use (by pressing the HDC switch).

10

Green light blinking: HDC is be-

ing applied.

11

Red light on: the HDC system is overheated

or malfunctioning.

12

When HDC is applied, the green HDC indicator blinks.

13

When the red HDC indicator is on, the HDC system is over-

14

heated or malfunctioning. When the red HDC indicator is on, the HDC function does

15

not work.

16

Depressing the Accelerator or Brake Pedal while HDC is being applied

If you depress the accelerator or brake pedal, the HDC function immediately stops and there will be more driving or braking force accordingly.

WARNING

• When driving down an extremely dangerous steep grade, HDC will

still work even if the brake or accelerator pedal is depressed.

4-20

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 20 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

HDC Operational Conditions

1. The HDC switch should be on (The green indicator on the instrument cluster comes on).

2. A certain steep grade.

3. Driving for about 7 ~ 50 km/h in the 2 wheel (2H) or 4 wheel high (4H) speed position. Or driving for about 3 ~ 25 km/h in the 4 wheel low position.

4. The automatic gear shift lever is in the “D” or “R” or “N” position. In case of the manual transmission, the gear shift is in the forwarding “1” or “Reverse” or “Neutral” position.

5. The accelerator or brake pedal is not depressed.

6. ESP (Electronic Stability Program, including BAS) is not activated.

Deactivation Conditions of HDC

1. The HDC switch is off (The green indicator on the instrument cluster is off too).

2. Less than required steep grade.

3. Vehicle’s speed is out of the operational ranges.

4. The accelerator or brake pedal is depressed.

5. ESP (including BAS) is applied.

6. Because of extended operation of HDC, the system is overheated (The red HDC indicator illuminates).

Operation of HDC

When all operational conditions are met, HDC is applied and the green HDC indicator blinks. HDC automatically decreases the vehicle speed to 7 km/h in the 2 wheel (2H) or 4 wheel high speed mode (4H) position. HDC automatically stops at speeds less than 7 km/h or when the slope descends slowly. It is normal to have strong vibrations and noise from the brake system when HDC is applied.

WARNING

• HDC is designed for driving on off-road steep grades.

• Unnecessary usage of HDC can cause malfunctions in the brake system or ESP. Do not use HDC when driving on normal roads.

• If driving on a level road with HDC on and ready for use, HDC may be applied during sharp cornering or passing over a speed bump. Therefore, do not activate HDC while driving on normal roads.

• If the red HDC indicator illuminates, HDC is overheated or malfunctioning. If the indicator is on even after the system has cooled down enough, have the nearest authorized dealer or service center check the system.

• It is normal to have strong vibrations and noise from the brake system when HDC is applied.

• In case of a manual transmission vehicle, the gear shift is in the forwarding “1” or “Reverse” position. If HDC is attempted in the “2” position, the engine may turn off.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 21 Adobe PageMaker 6.5K/Win

16

4-21

HEATED GLASS SWITCH

0

1

Tailgate and outside rearview mirror heated glass switch

2

• Press this switch to turn on the tailgate and outside rearview mirror heated glasses. It will

3

operate for about 12 minutes.

4

• Press the switch again to stop the operation.

• This switch is designed to defrost or defog the

5

tailgate glass and outside rearview mirrors.

6

• The heated glass will operate for about 6 minutes when the switch is pressed again within

7

10 minutes after completion of its first operation cycle.

8

• The indicator in the switch comes on when in use.

9

10

11

Outside

12

rearview mirror heated glass

13

14

15

16

Tailgate heated glass

Windshield heated glass

Windshield heated glass switch

• Press this switch to turn on the windshield heated glass. It will operate for about 12 minutes.

• Press the switch again to stop the operation.

• Use this to prevent the windshield wiper blades from being frozen.

• It will operate for approximately another 6 minutes if the switch is pressed again within 10 minutes after completing its 12-minute operation.

• The indicator in the switch comes on when in use.

Tailgate heated glass

Outside rearview mirror heated glass

4-22

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 22 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

AUDIO REMOTE CONTROL SWITCHES ON STEERING WHEEL

* The audio system equipped in the vehicle can be controlled by the remote control switches on the steering wheel.

POWER

Audio power on/off when the button is pressed.

MODE

Audio mode changes when the button is pressed.

XX

X

SEEK

• In radio mode

- Press briefly: Manual searching for a station. Move to a stored station.

- Press and hold: Automatic searching for a station.

• In CD (DVD) player/Cassette tape mode

- Press briefly: Replay the next/previous track.

- Press and hold: Move forward/backward in the current tract.

SEEK

X

XX

Stops audio output from the audio system. To resume the audio output, press the button again.

Increases/decreases volume

VOL

MUTE

XX

X

VOL

X

XX

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 23 Adobe PageMaker 6.5K/Win

4-23

4-WHEEL DRIVE SYSTEM AND SWITCH*

0

1

2

3

4-WHEEL DRIVE SYSTEM

The 4-wheel drive system automatically distributes torque to all four wheels using sophisticated electronic controls and ensures a more enhanced vehicle stability compared with that of the 2-wheel drive system.

The 4-wheel drive system is mainly used for unpaved, snowy, and slippery roads where extra traction is needed and for having a little fun in the mud. For maximum traction, "4L" mode is available.

4

5

6

7

DRIVING MODE

8

9

10

11

12

13

14

2H: 2-Wheel Drive, High

Rear-wheel drive mode. This is used

15

under normal or high-speed driving conditions on public roads or highways.

16

4H: 4-Wheel Drive, High

This is used under sandy, muddy or snow-covered road conditions.

4L: 4-Wheel Drive, Low

This is used for maximum traction.

4-24

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 24 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

4-WHEEL DRIVE SWITCH

Driving Mode Change

0

1

Only for part time TC, not equpped with 2-wheel drive vehicle Select a proper driving mode according to the road conditions.

CAUTION

• Do not drive your vehicle over 80 km/h in 4H mode.

2H : 2-Wheel Drive, High

Rear-wheel drive mode. This is used under normal or highspeed driving conditions on public roads or highways.

4H : 4-Wheel Drive, High

This is used under sandy, muddy or snow-covered road conditions.

4L : 4-Wheel Drive, Low

Use this position for maximun traction.

2H ⇔ 4H

Shifting is possible while driving at the speed of 70 km/h or less.

• When shifting the driving mode to “4H”, this indicate comes on.

• When shifting the driving mode from “4L” to “4H”, the light blinks during shifting and comes on after completely shifting.

2H, 4H ⇔ 4L

• For vehicles equipped with automatic transmission, stop the vehicle on level ground and move the gear selector lever into the “N” position. Turn the switch to the desired position.

• For vehicle equipped with manual transmission, stop the vehicle on level ground and move the gear selector lever into the “N” position. Then turn the switch to the desired position while depressing the clutch pedal.

Completely shifting to “4L” turns on the light. Light blinks during shifting to “4L”.

INTERIOR SWITCHES

4-25

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 25 Adobe PageMaker 6.5K/Win

4WD HIGH Indicator

0

1

• When shifting the driving mode from “2H” to “4H”, this indicator comes on.

2

3

4

4WD LOW Indicator*

5

6

7

• When shifting the driving mode to “4L”, the light blinks during shifting and it will come on after completely shifting.

• The blinking indicator indicates that the mode is shifting to “4L”.

8

9

4WD CHECK Warning Indicator

10

11

12

13

14

This warning indicator comes on when the ignition switch is turned to “ON” and should go out if the system is normal. If the “4WD CHECK” warning indicator stays on, have the 4WD system checked by the nearest Ssangyong Authorized Service Center.

15

16

Tight Cornering

Some mechanical shocks and resistances in the vehicle’s drive train may occur when cornering in 4-wheel drive mode. This is just normal and is due to the internal resistance in the drive train when the 4-wheel drive is properly working. To avoid damaging the drive train, do not drive your vehicle at an excessively high speed on a sharply curved road.

CAUTIONS WHEN USING 4-WHEEL DRIVE MODE

• There could be mechanical noises and shocks during mode changes. However, these are normal conditions due to the mode changing operations.

• Use only the 2H mode on a normal paved surface. Do not drive your vehicle in the “4H” position on paved road surfaces. Doing so will result in damages to the drive train.

• Driving in a 4 wheel mode on a normal paved surface will cause unwanted noises, premature wear of tires, or increased fuel consumption.

• If the “4WD CHECK” warning light stays on, have the 4WD system checked by the nearest Ssangyong Dealer or Ssangyong Authorized Service Center.

• When cornering a curved road in a 4-wheel drive mode, there could be some mechanical shocks and resistances in vehicle’s drive train. These are normal conditions due to internal resistance in the drive train when the 4-wheel drive mode is properly working. To avoid damages to the drive train, do not drive your vehicle at an excessively high speed on a sharply curved road.

4-26

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 26 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

LIMITED SLIP DIFFERENTIAL (LSD)*

LSD is a differential limiting of wheel which is spinned when one wheel is on a slipping surface like ice, snow or mud to help easy escaping from them. LSD is integrated in the rear axle and please keep eyes on following precautions.

NOTE

There is no switch or device to control the LSD in the vehicle. It is integrated in the rear axle and works when one wheel is spinning.

CAUTION

If you run the wheels with high speed while escaping mud or puddle, the limited slip differential (LSD) may badly be affected. Use other devices such as wood block while escaping depending on the situations.

WARNING

Limited slip differential (LSD) is integrated in the rear axle and operates when there are slippage differences between the left wheel and right wheel. So, in any cases, never start the engine if any wheel is jacked up.

Particularly, if you start the engine while one of rear wheels is jacked up, the wheel on the ground will run due to operation of the LSD, due to operation of the LSD, and make the vehicle move abruptly, so that you can be seriously injured. You can be seriously injured.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

INTERIOR SWITCHES

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 27 Adobe PageMaker 6.5K/Win

14

15

16

4-27

SWITCHES IN OVERHEAD CONSOLE

0

1

Spot Lamp Switch (Driver’s)

The front room lamp (driver’s) turns

2

on when pressing in this switch.

3

4

5

6

7

Sunroof Switch (ACTYON)

8

By turning this switch to either the clockwise or counterclockwise direction, the sunroof can be open

9

or closed. For more information, refer to Chapter 2.

10

11

CENTER ROOM LAMP

12

13

14

15

16

Door coupled operation

ON

Switching to ON lights up the center room lamp. If the switch is placed to the door coupled position, the lamp goes out. If any door is opened when the door coupled position is selected, the center room lamp comes on (However, the lamp is coupled with the doors only when the main switch of the front room lamp is pressed). However, if the door is closed, the lamp will go out.

Main Room Lamp Switch

When this switch is pressed, the front and center room lamps are coupled with doors. (The center room lamp is coupled only if the center room lamp switch is in the door coupled operation.) When pressed again, the lamps go out.

If switches of the spots and center room lamps are turned on, the lamps do not go out in spite of repressing the switch. To turn them off, check the switches.

* When a door is opened, the front and center room lamps

are turned on. In this case, you cannot turn off the lamps with the main room lamp switch. However, if the door is closed, the lamp will go out.

Spot Lamp Switch (passenger’s)

The front room lamp (passenger’s) turns on when pressing in this switch.

CAUTION

If your vehicle is left unattended while the front main, spot, or center room switch is turned on, the battery may be discharged.

LUGGAGE ROOM LAMP (ACTYON)

If the ON position is

Luggage Room Lamp

OFF

ON

pressed, the lamp will come on; if the OFF position is pressed, it will go out.

4-28

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 28 Adobe PageMaker 6.5K/Win

INTERIOR SWITCHES

MEMO

.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 29 Adobe PageMaker 6.5K/Win

MEMO

.....................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

Q100-04-Interior Switches.p65 2006-10-02, ¿ÀÈÄ 3:06Page 30 Adobe PageMaker 6.5K/Win

0

Instrument Cluster

TABLE OF CONTENTS

Instrument Cluster ....................................... 5-2

Tachometer, Speedometer ......................... 5-3

Coolant Temperature Gauge / Fuel Gauge .. 5-4

Display .......................................................... 5-5

Battery Charge Warning Light, Air Bag

Warning Light, ESP Warning Light, HDC

Indicator ....................................................... 5-6

Water Separator Warning Light ................. 5-7

How to Drain the Water from the Fuel Filter

(Without Additional Water Separator) ....... 5-8

How to Drain the Water from the Fuel Filter

(With Additional Water Separator) ............ 5-9

5

Immobilizer Indicator, Seat Belt Reminder,

4WD Indicators ............................................5-11

Engine Overheat Warning Light, Front Fog

Light Indicator, High Beam Indicator, Door

Ajar Warning Light .................................... 5-12

Brake Warning Light, Winter Mode Indicator,

Low Fuel Level Warning Light, Power Mode

Indicator ..................................................... 5-13

Glow Indicator (Diesel only), EBD Warning

Light, ABS Warning Light ......................... 5-14

Engine Hood Open Warning Light, Engine Oil

Pressure Warning Light, Engine Check

Warning Light, Cruise Control Indicator .. 5-15

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 1 Adobe PageMaker 6.5K/Win

INSTRUMENT CLUSTER

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 2 Adobe PageMaker 6.5K/Win

1. Tachometer

2. Speedometer

3. Left turn signal indicator

4. Right turn signal indicator

5. Engine coolant temperature gauge

6. Fuel gauge

7. Engine overheat warning light

8. Fog light indicator

9. High beam indicator

10. Door ajar warning light

11. Brake warning light

12. Low fuel level warning light

5-2

INSTRUMENT CLUSTER

13. Power mode indicator

14. ESP warning light

15. 4WD HIGH indicator

16. Battery charge warning light

17. Air bag warning light

18. HDC indicator

19. Immobilizer indicator

20. Water separator warning light

21. Seat belt reminder (driver’s seat)

22. 4WD CHECK warning light

23. Auto shift indicator (for automatic transmission)

24. ODOmeter/ Trip odometer

25. Winter mode indicator

26. ABS warning light

27. EBD warning light

28. Glow indicator

29. Engine hood open warning light

30. Engine check warning light

31. Engine oil pressure warning light

32. Auto cruise indicator

33. Seat belt reminder (passenger’s seat)

34. Hazard warning light (Eastern Europe only)

35. 4WD LOW indicator

TACHOMETER

Diesel Gasoline

SPEEDOMETER

RED ZONE (GCC ONLY)

0

1

2

3

4

5

6

The tachometer indicates engine speed in revolutions per minute. Multiply 1,000 to the current number, then it will be the current number of engine revolutions.

Specified idle rpm

Diesel

Gasoline

WARNING

Do not let engine reach excessive speed, indicated by the pointer being in the red zone.

780 ± 50 rpm 750 ± 50 rpm

The speedometer indicates the vehicle speed in kilometers per hour (km/h).

NOTE

Speedometer-KPH (MPH) Speedometer-MPH (KPH)

INSTRUMENT CLUSTER

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 3 Adobe PageMaker 6.5K/Win

7

8

9

10

11

12

13

14

15

16

5-3

COOLANT TEMPERATURE GAUGE

0

1

2

3

4

5

6

7

8

9

The temperature gauge indicates the temperature of the en-

10

gine coolant.

11

CAUTION

12

13

14

The engine can overheat.

• If the pointer reaches the red zone, stop the vehicle.

• Allow engine to cool. If the engine is overheated, continued operation of the vehicle

may seriously damage the engine.

15

FUEL GAUGE

This gauge indicates the level of fuel remaining in the fuel tank. Fill up the fuel tank before the needle reaches “E”.

16

5-4

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 4 Adobe PageMaker 6.5K/Win

INSTRUMENT CLUSTER

DISPLAY

Odometer and Trip Odometer Display

Each time the TRIP/RESET switch on the center panel is pressed lightly, the indicators are changed. To reset the trip meter, press and hold the switch.

0

1

2

3

4

Total driving distance

Unit: 0~999999 km

Auto Shift Indicator (for automatic transmission)

This indicator shows the automatic transmission selector lever position as below.

Trip A

Unit: 0.0~999.9 km

Gear Shifting

When the shift lever is engaged in the “D” position, the actual gear number is displayed in a small font next to the “D” letter.

NOTE

When a lower gear is needed to secure stabilized driving conditions, sometimes the “D3” can directly be shifted into the “D1” position, without lowering into the “D2” position.

Trip B

* If the meter cluster with “mile” unit is

installed, trip/odo distance is displayed in “mile”.

Unit: 0.0~999.9 km

INSTRUMENT CLUSTER

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 5 Adobe PageMaker 6.5K/Win

5

6

7

8

9

10

11

12

13

14

15

16

5-5

BATTERY CHARGE WARNING LIGHT

0

1

2

3

4

system. Have the charging system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center.

5

This warning light comes on when the ignition switch is turned on and it goes off when the engine is started.

If this light doesn’t go off after engine starting or comes on while driving, it means there is a malfunction in the

6

7

ESP WARNING LIGHT

If you press the ESP ESP function stops and the indicator lamp in the instrument cluster comes on. If the ESP function operates, the indicator lamp flickers.

If the ESP warning light is on without any deactivation of the system, there are some malfunctions in the system. Take the vehicle to an authorized dealer or service operation.

For more information about ESP (Electronic Stability Program), refer to Chapter 4.

switch, the

OFF

AIR BAG WARNING LIGHT

8

9

10

11

12

nates continuously while driving, it means that there is a malfunction in the system. Have the air bag system checked

13

without delay by a Ssangyong Dealer or Ssangyong Authorized Service Center.

14

15

16

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 6 Adobe PageMaker 6.5K/Win

NOTE

For more detailed information, refer to the “Seat Belt and Air Bag” section.

5-6

INSTRUMENT CLUSTER

When the ignition is switched on, this warning light illuminates and then should go off, to confirm that the air bag is operational.

If it does not come on, or if it does not go off, or if it flashes or illumi-

HDC INDICATOR

When the HDC switch is pressed

once, HDC is ready for use. The

green HDC indicator in the instru-

ment cluster comes on. When the

button is pressed again, HDC is de-

activated and the indicator goes off. When HDC is applied, the green HDC indicator blinks. When the red HDC indicator is on, the HDC system is over-

heated or malfunctioning. For more information, refer to Chapter 4, HDC Switch.

CAUTION

If the red HDC indicator illuminates, HDC is overheated or malfunctioning. If the indicator is on even after the system has cooled down enough, have the nearest authorized dealer or service center check the system.

WATER SEPARATOR WARNING LIGHT

Water Separator Warning Light (Without Additional Water Separator)

When the water level inside the water separator in the fuel filter exceeds a certain level, this warning light comes on and a buzzer sounds. Also, the driving force of the vehicle decreases. If these conditions occur, immediately drain the water from the fuel filter.

For the draining procedures, please refer to “How to drain the water from the fuel filter (without additional water separator)” on the next page.

This warning light goes off when the draining is completed.

0

1

2

3

4

5

6

7

Water Separator Warning Light (With Additional Water Separator)

CAUTIONS

• The fuel system in the engine may get serious damage if you keep driving while the warning light is on. Prompt correction should be necessary.

• Using low quality fuel could result in serious damage to the engine due to the water or impurities in fuel. Never use low quality fuel.

• After removing any water in the fuel filter, pump fuel until the priming pump is fully filled before starting the engine.

• When the water level inside the water separator in the fuel filter exceeds a certain level, this warning light comes on and a buzzer sounds. Also, the driving force of the vehicle decreases. If these conditions occur, immediately drain the water from fuel filter. If the above conditions still exist after draining the water, have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center.

When the water level inside the water separator exceeds a certain level, this warning light comes on and a buzzer sounds. Also, the driving force of the vehicle decreases. If these conditions occur, immediately drain the water from the fuel filter & water separator.

For the draining procedures, refer to “How to drain the water from the fuel filter (with additional water separator)” on page 5-10.

This warning light goes off when the draining is completed.

INSTRUMENT CLUSTER

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 7 Adobe PageMaker 6.5K/Win

8

9

10

11

12

13

14

15

16

5-7

HOW TO DRAIN THE WATER FROM THE FUEL FILTER (Without Additional Water Separator)

0

1. Locate the fuel filter in the engine compartment and place

1

2

3

4

a water container under it.

2. Disconnect the connector under the drain plug of the water separator.

3. Turn the drain plug to the opening direction to drain the water.

4. Wait until a certain amount of fuel gets out from the port, then turn the drain plug to the closing direction to tighten it.

5. Engage the connector under the drain plug and press the priming pump until it becomes rigid.

6. Close the engine hood and start the engine.

5

6

7

Priming pump

8

9

10

Fuel filter

11

12

13

14

15

Opening

Drain plug

Connector

Closing

16

5-8

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 8 Adobe PageMaker 6.5K/Win

INSTRUMENT CLUSTER

WARNING

If the priming pump is not properly operated, air may get into the fuel line. It may cause a starting problem or fuel system problem. Make sure to perform the job in step 5.

CAUTION

Be careful not to be injured by surrounding equipment during the working procedures.

HOW TO DRAIN THE WATER FROM THE FUEL FILTER (With Additional Water Separator)

Fuel filter

CAUTION

Drain the water from the fuel filter & water separator immediately after the warning light comes on. If you cannot do that by yourself, visit the nearest Ssangyong Dealer or Ssangyong Authorized Service Center.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

WARNING

The fuel system in the engine may get serious damage if you keep driving while the warning light is on. Prompt correction should be necessary.

Priming pump

Water separator

INSTRUMENT CLUSTER

Q100-05-Instrument Panel.p65 2006-10-02, ¿ÀÈÄ 3:06Page 9 Adobe PageMaker 6.5K/Win

15

16

5-9

SSANGYONG ACTYON, ACTYON SPORTS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
