Product data sheet
LP2K0910BD
TeSys K reversing contactor - 3P(3 NO) - AC-3
- <= 440 V 9 A - 24 V DC coil
Aug 8, 2016
1
Main
Range TeSys
Product name TeSys K
Product or component type
Device short name LP2K
Contactor application Motor control
Utilisation category AC-1
Device presentation Preassembled with reversing power busbar
Poles description 3P
Power pole contact composition
[Ue] rated operational voltage
[Ie] rated operational current
Motor power kW 4 kW at 660...690 V AC 50/60 Hz
Control circuit type DC standard
Control circuit voltage 24 V DC
Auxiliary contact com­position
[Uimp] rated impulse withstand voltage
Overvoltage category III
[Ith] conventional free air thermal current
Irms rated making ca­pacity
Rated breaking capac­ity
[Icw] rated short-time withstand current
Associated fuse rating 10 A gG for signalling circuit conforming to VDE
Average impedance 3 mOhm at 50 Hz - Ith 20 A for power circuit
Reversing contactor
Resistive load
AC-3 AC-4
3 NO
<= 690 V AC 50/60 Hz for signalling circuit 690 V AC 50/60 Hz for power circuit
16 A (<= 70 °C) at 690 V AC AC-1 for power circuit 20 A (<= 50 °C) at <= 440 V AC AC-1 for power cir­cuit 9 A at <= 440 V AC AC-3 for power circuit
4 kW at 500...600 V AC 50/60 Hz 4 kW at 480 V AC 50/60 Hz 4 kW at 440 V AC 50/60 Hz 4 kW at 380...415 V AC 50/60 Hz
2.2 kW at 220...230 V AC 50/60 Hz
1 NO
8 kV
10 A at <= 50 °C for signalling circuit 20 A at <= 50 °C for power circuit
110 A AC for signalling circuit conforming to IEC 60947 110 A AC for power circuit conforming to IEC 60947 110 A AC for power circuit conforming to NF C 63-110
70 A at 660...690 V conforming to IEC 60947 110 A at 380...400 V conforming to IEC 60947 110 A at 220...230 V conforming to IEC 60947 80 A at 500 V conforming to IEC 60947 110 A at 440 V conforming to IEC 60947 110 A at 415 V conforming to IEC 60947
20 A <= 50 °C >= 15 s power circuit 110 A 100 ms signalling circuit 90 A 500 ms signalling circuit 80 A 1 s signalling circuit 40 A <= 50 °C 3 min power circuit 45 A <= 50 °C 1 min power circuit 60 A <= 50 °C 30 s power circuit 80 A <= 50 °C 10 s power circuit 85 A <= 50 °C 5 s power circuit 90 A <= 50 °C 1 s power circuit
0660 10 A gG for signalling circuit conforming to IEC 60947 25 A aM for power circuit 25 A gG at <= 440 V for power circuit
2
[Ui] rated insulation voltage
Electrical durability 1.3 Mcycles 9 A AC-3 at Ue <= 440 V
Interlocking type Mechanical
Mounting support Plate
Standards BS 5424
Product certifications CSA
Connections - terminals Screw clamp terminals 2 cable(s) 0.34...1.5 mm² -
Tightening torque 1.3 N.m - on screw clamp terminals - with screwdriv-
Operating time 10 ms coil de-energisation and NO opening
Safety reliability level B10d = 20000000 cycles contactor with mechanical
Mechanical durability 5 Mcycles
Operating rate 3600 cyc/h
600 V for signalling circuit conforming to CSA C22.2 No 14 600 V for power circuit conforming to CSA C22.2 No 14 600 V for signalling circuit conforming to UL 508 690 V for signalling circuit conforming to IEC 60947-5-1 690 V for signalling circuit conforming to IEC 60947-4-1 690 V for power circuit conforming to IEC 60947-4-1 600 V for power circuit conforming to UL 508
0.18 Mcycles 20 A AC-1 at Ue <= 440 V
Rail
IEC 60947 NF C 63-110 VDE 0660
UL
cable stiffness: flexible - with cable end Screw clamp terminals 2 cable(s) 0.75...4 mm² - ca­ble stiffness: flexible - without cable end Screw clamp terminals 2 cable(s) 1.5...4 mm² - ca­ble stiffness: solid Screw clamp terminals 1 cable(s) 0.34...2.5 mm² ­cable stiffness: flexible - with cable end Screw clamp terminals 1 cable(s) 0.75...4 mm² - ca­ble stiffness: flexible - without cable end Screw clamp terminals 1 cable(s) 1.5...4 mm² - ca­ble stiffness: solid
er flat Ø 6 mm
1.3 N.m - on screw clamp terminals - with screwdriv­er Philips No 2
30...40 ms coil energisation and NO closing
load conforming to EN/ISO 13849-1 B10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1
Complementary
Control circuit voltage limits 0.1...0.75 Uc at <= 50 °C drop-out
0.8...1.15 Uc at <= 50 °C operational
Inrush power in W 3 W at 20 °C
Hold-in power consumption in W 3 W at 20 °C
Heat dissipation 3 W
Auxiliary contacts type Type instantaneous 1 NO
Minimum switching current 5 mA for signalling circuit
Minimum switching voltage 17 V for signalling circuit
Non overlap distance 0.5 mm
Insulation resistance > 10 MOhm for signalling circuit
Environment
IP degree of protection IP2x conforming to VDE 0106
Protective treatment TC conforming to DIN 50016
TC conforming to IEC 60068
Ambient air temperature for operation -25...50 °C
Ambient air temperature for storage -50...80 °C
Operating altitude 2000 m without derating in temperature
3
Flame retardance Requirement 2 conforming to NF F 16-102
Mechanical robustness Shocks contactor closed, on Y axis 10 Gn for 11 ms IEC 60068-2-27
Height 58 mm
Width 90 mm
Depth 57 mm
Product weight 0.48 kg
Requirement 2 conforming to NF F 16-101 V1 conforming to UL 94
Shocks contactor closed, on X axis 15 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Y axis 6 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on X axis 10 Gn for 11 ms IEC 60068-2-27 Vibrations contactor opened 2 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor closed 4 Gn, 5...300 Hz IEC 60068-2-6 Shocks contactor opened, on Z axis 10 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Z axis 15 Gn for 11 ms IEC 60068-2-27
Offer Sustainability
Sustainable offer status Green Premium product
RoHS
Product environmental profile
Product end of life instructions Need no specific recycling operations
Compliant - since 0706 - Schneider Electric declaration of conformity
Available Download Product Environmental
