HAXL-PNI-15
GENUINE SPICER® MEDIUM DUTY POPULAR
PARTS LISTING S110, S111, S130, S132, AND
S135/S150
PART NUMBER INFORMATION
DATE: September 2, 2011
TO: All Dana Spicer® Service Parts Heavy Axle Customers
Models: S110, S111, S130, S132, and S135/S150
This bulletin contains comprehensive part listings of the most popular repair parts and
service kits available for the medium duty models listed above. The reference chart
below is a quick reference showing the Dana illustrated parts catalog number for each
of these models.
Any of these current catalog’s can be downloaded from www.spicerparts.com. Click
on the Literature button or The EXPERT icon, and navigate to the literature needed.
Dana Axle IPL Reference Chart
Catalog Item
Number
AXIP-0054 X
AXIP-0065 X
AXIP-0055 X X
AXIP-8941 X
S110 S111 S130 S132 S135,
S150
The charts on page 2 list the most popular Dana parts used by fleets and rebuilders
when doing maintenance or carrier rebuilds on medium duty carriers. Pages 3 & 4 show
the bill of materials of the kits referenced in the charts. The Individual service carriers,
gear/pinion kits and axle shafts are not shown in this bulletin but are listed in the
individual axle catalogs referenced above.
Spicer Service Parts Dana Holding Corporation www.spicerparts.com www.dana.com
Bearing and Overhaul Kits
S110 S111 S130 S132 S135, S150
Basic Overhaul Kit
Bearing Kit
Basic Overhaul Kits – Includes All Bearings, Shims, Washers, Snap Rings, Seals & RTV
Bearing Kits – Includes All Bearings, Seals & RTV
511859 511859 511859 511859 n/a
513279 513279 513279 513279 360KS100-X
Pinion Nuts, Pinion Seals and Seal Drivers
S110 S111 S130 S132 S135, S150
Pinion Nut
Pinion Seal
Oil Seal Driver Installation Tool
130542 130542 130542 130542 HN130
127591 127591 127591 127591 029HH100
126917 126917 126917 126917 n/a
Internal Carrier Repair Kits
S110 S111 S130 S132 S135, S150
Wheel Diff Side Gear Kit
Side Gear
Pinion Bearing Spacer Kit
Ring Gear Bolt or Ring Gear
Bolt Kit*
511861 504003 514374 504040 360KS101-X
130522
(34inv)
504039 504039 504039 504039 360KV100-X
130595
(qty-12)
130522
(34inv)
132820
(qty-10)
132807
(36inv)
132820
(qty-10)
132807
(36inv)
132820
(qty-10)
029GD104
360KY100-X*
(36inv)
Axle Housing Hardware, Breather and Sealant Parts
S110 S111 S130 S132 S135, S150
Carrier to Housing Hardware Kit
ABS Sensor
U-Tube Breather Kit
RTV Sealant – 3oz
Thread Adhesive Loctite 271 .5ml
514120 514120 514120 514120 HM101 (10),
2011750 130771 2001750 n/a 50311
507162 507162 507162* 507162 507162
107276S 107276S 107276S 107276S 107276S
129293 129293 129293 129293 129293
*All except Ford Applications
Dana Truetrac Limited Slip and No Spin Diff Assemblies
S110
Truetrac Kit – All Ratios
Truetrac Kit 3.91-4.44
Truetrac Kit 4.78-5.38
No Spin Assy
34inv
504038 504004 513305 513305
512772
512773
n/a n/a n/a n/a 360GN100
S111
34inv
S130
36inv
S132
36inv
HM102 (4)
S135, S150
36inv
Spicer Service Parts Dana Holding Corporation www.spicerparts.com www.dana.com
Bearing/Overhaul and Hardware Kit – Bill of Material
Item Description Qty
511859
Basic
Overhaul Kit
513279
Bearing Kit
360KS100-X
Bearing Kit
514120
Carrier To Housing
Hardware Kit
507162
U-Tube
Breather Kit
504039
Pinion Bearing
Spacer Kit
360KS100-X
Pinion Bearing
Spacer Kit
HB105 BEARING CONE 3984 2
12495 55437 - BEARING CUP 1
360HA100 INNER PINION BEARING CUP 1
12496 55200 - BEARING CONE 1
127591 OILSEAL 1
HA102 DIFF BEARING CUP 2
129305 THRUST WASHER 4
127386 THRUST WASHER 1
129562 BEARING CONE 1
12496 55200 - BEARING CONE 1
HA102 DIFF BEARING CUP 2
12495 55437 - BEARING CUP 1
129561 BEARING CUP 1
129562 BEARING CONE 1
HB105 BEARING CONE 3984 2
107276S SEALANT RTV 1
127591 OILSEAL 1
029HH100 PINION OIL SEAL 1
INNER PINION BEARING CONE
360HB100
72225CPW3VW8 1
360HA100 INNER PINION BEARING CUP 1
12495 55437 - BEARING CUP 1
HB104 OUTER PINION BEARING CONE 1
HA102 DIFF BEARING CUP 2
HB105 BEARING CONE 3984 2
128415 WASHER 12
107276S SEALANT RTV 1
210115 CAPSCREW 8
210091 CAPSCREW 4
129293 THREAD ADHESIVE 1
302706 BREATHER ASSY 1
129340 HOSE & CLAMP ASSY 1
129341 BREATHER INSTAL.INST 1
130553 PIN BRG SPACER 27.490 1
130563 PIN BRG SPACER 27.664 1
130565 PIN BRG SPACER 27.690 1
130567 PIN BRG SPACER 27.715 1
130573 PIN BRG SPACER 27.791 1
130575 PIN BRG SPACER 27.817 1
130577 PIN BRG SPACER 27.842 1
130583 PIN BRG SPACER 27.918 1
360HS100 15 SPACER PB .300 1
360HS100 16 SPACER PB .301 1
360HS100 17 SPACER PB .302 1
360HS100 18 SPACER PB .303 1
360HS100 19 SPACER PB .304 1
360HS100 20 SPACER PB .305 1
360HS100 21 SPACER PB .306 1
Spicer Service Parts Dana Holding Corporation www.spicerparts.com www.dana.com
Wheel Diff Side Gear Kit - Bill of Materials:
Item Description Qty
511861
model: S110
504003
model: S111
514374
model: S130
504040
model: S132
360KS101-X
model: S135, S150
127386 THRUST WASHER 1
129305 THRUST WASHER 2
133761 PINION - SIDE 2
133771 SHAFT - DIFFERENTIAL (PIN) 1
130605 PIN-DOWEL 1
130522 SIDE GEAR 2
133772 SHAFT - DIFFERENTIAL 1
130605 PIN-DOWEL 1
132821 PIN - DOWEL 2
130522 SIDE GEAR 2
133761 PINION - SIDE 2
127386 THRUST WASHER 1
129305 THRUST WASHER 2
127386 THRUST WASHER 1
129305 THRUST WASHER 4
133761 PINION - SIDE 4
130767 SHAFT - DIFFERENTIAL (PIN) 1
130768 SHAFT - DIFFERENTIAL (PIN) 2
132807 GEAR - SIDE (WHEEL DIFF) 2
130605 PIN-DOWEL 2
132821 PIN - DOWEL 2
127386 THRUST WASHER 1
129305 THRUST WASHER 4
133761 PINION - SIDE 4
130763 PIN - DOWEL 2
130605 PIN-DOWEL 2
132807 GEAR - SIDE (WHEEL DIFF) 2
130764 RING - DIFF SHAFT 1
130762 SHAFT - DIFFERENTIAL (PIN) 4
18346 THRUST WASHER 2
360DP100 DIFF CROSS (SPIDER) 1
HS109 SIDE PINION THRUST WASHER 4
029GD104 GEAR-SIDE 2
472GC102 PINION MATE 4
As always, we appreciate your continued business and support of genuine Spicer
products!
Bernie Powers
Product Manager
Spicer® Heavy Axle Products
