Multi-Housing
Coin Slide-Operated
Commercial Washers & Dryers
Coin
SWT910 1-Speed Topload Washer
SWT920/SWT921 2-Speed Topload Washer
SDE907/SDG909 Single Load Dryer
SSE907/SSG909 Stack Dryer - Solid Door
SSE917/SSG919 Stack Dryer - See-Through Door
Commercial Built to Last Longer
Heavy-Duty Commercial
Coin Slide-Operated
Today, multi-housing owners are continuously
confronted with issues such as energy conservation,
equipment breakdowns and vandalism. That's why when
it comes to coin-operated washers and dr yers, water and
energy efficient designs, quality internal components
and high security systems are among the most important
factors to consider when equipping a laundry room.
Speed Queen's coin washer, single load and stack dryer
also increase process speed and lower utility costs,
benefiting building management. Residents will have
increased flexibility of independent selections of hot,
warm and cold wash temperatures and two-speed
wash and spin actions.
Your authorized Speed Queen route operator can design
a laundry solution to meet the needs of your property.
High Efficiency Automatic Washer
• Department of Energy compliant to commercial
washer standards for energy and water savings.
• Exclusive stainless steel or porcelain washtub with
large capacity 2.8 cu. ft.
• Three energy saving cycles
~ Water saver cycle with wash and two rinses
~ 24.4 gals. per cycle
~ Automatic temperature control to reduce hot water
• Three regular cycles
~ Normal, Permanent Press or Delicate
~ True delicate cycle with gentle agitation and slow
spin action.
Superior Wash/Rinse Action
• Curved four-vane polypropylene agitator with 210°
wash stroke, the longest in the industry, produces
superb washing results.
High Speed Spin-Extract
• A higher extract speed of 710 RPM spins clothes out
drier. In fact, the high spin speed lowers moisture
retention by 3.4% over previous models. This means
faster drying, increased cycle turns and satisfied users.
Automatic Balance System
• Residents will appreciate the Automatic Balance
System (ABS) for smooth and quiet operation, even
on wood floors. The ABS provides the industry’s
best out-of-balance handling, completing wash
cycles without interruption.
Quality Washer Components
• Electronic Hybrid Timer for reliable operation.
• Durable stainless steel and porcelain enamel washtub.
• Long-lasting galvanized steel cabinet.
• StrongBox SecurityTMon meter case.
• Dependable, Eversmooth transmission.
• Heavy-duty, 1/2 HP, two-speed motor.
• Single-belt drive simplicity.
• Corrosion-resistant polypropylene pump.
• Pump clips for service convenience.
• Rear self-leveling legs.
• Unit is 100% front serviceable.
Dryer
Slide Operated
Control
Superior Drying Convenience
• Electric programmable timer in one-minute increments
1-64 minutes with cool down of 3-6 minutes.
• A wide door opening of 2.06 sq. ft. is the industry’s
largest, offering residents the convenience of easy
loading and unloading.
• Door is reversible for installation flexibility. The
up-front lint filter is easy to clean and secured.
• Extended safety tumble automatically tumbles
clothes 20 minutes after cycle completion for
two minutes to reduce clothes wrinkling.
Drying and Energy Dynamics
• Durable galvanized steel cylinder with extra-large
18 lb capacity. The gentle tumble action minimizes
wrinkles.
• Quiet, efficient blower system with superior
airflow of 220 cu. ft. per minute for fast drying
and lower operating costs.
• Efficient dryer heating with 25,000 Btu (gas
models) and 5,350 Watts (electric models).
Stack Dryer Features
• See-through door model optional.
• A space saver! Two dryers in the space of
one, both operating independently.
• 100% serviceable from the front.
• StrongBox Security™ center section module
to reduce vandalism.
Control Features
Washer
User selectable options for
Hot, Warm or Cold wash
temperatures. Two speeds
with normal/gentle wash and
slow/fast extract. Six cycles
with three “water saver”
cycles—Normal, Permanent
Press and Delicate selections
with LED indicators.
One-speed model offers
three wash temperatures
combined with selections for
six cycles including three
“water saver” cycles.
Dryer
Our dryer’s electronic
control offers four heat/cycle
options. Factory set with a
45-minute drying time, the
timer can be programmed
in one-minute increments.
A push-to-start button adds
convenience for residents
as does an in-use LED.
Activation Features
Speed Queen offers many
activation options to meet
your specific market needs.
Coin slides offer simple,
dependable operation.
Other equipment manufacturers’ card readers also
are available.
StrongBox Security™ system
on both washers and dryers
provides top-of-the-industry
security to deter vandalism
of tops and metercases.
Durable porcelain enamel
tops and lids resist corrosion
and scratching, assuring
long-lasting appearance.
Coin Slide
One-Speed Washer
Slide Operated
Control
Two-Speed Washer
Slide Operated
Control
www.speedqueen.com
AM08-201
Washer & Dryer Specications
SWT910 Electric: SDE907 Electric: SSE907, SSE917
SWT920, SWT921 Gas: SDG909 Gas: SSG909, SSG919
Basket/Cylinder Volume -cu. ft. (liters) 2.8 (79) 7.0 (198) 7.0 (198)
Width - in (mm) 25 5/8" (651) 26 7/8" (683) 26 7/8" (683)
Depth - in (mm) 28" (711) 28" (711) 28" (711)
Height* - in (mm) 43" (1092) 43" (1092) 76 5/8" (1946)
Work Surface Height - in (mm) 36" (914) 36" (914) N/A
Weight - lb (kg) 190 (86) Electric: 135 (61) Electric: 265 (120)
Gas: 140 (64) Gas: 275 (125)
Shipping Weight - lb (kg) 210 (95) Electric: 145 (66) Electric: 280 (127)
Gas: 150 (68) Gas: 290 (132)
Cycle Time - minutes 28-31 45 45
Motor HP (Capacitor Start 1-speed, 1/2 HP 1/3 HP, 5.5 amps 1/3 HP, 5.5 amps
and Thermal Protected) 2-speed, 1/2 HP
Water Consumption - gal. per cycle 26.1 N/A N/A
Water Factor - gal. per cu. ft. 9.5 N/A N/A
Modified Energy Factor 1.26 N/A N/A
Hot Water Usage - gal. per cycle 4.48 N/A N/A
Water Pressure - psi (bar) Pressure fill – 20 to 120 N/A N/A
(1.4/8.3)
Spin Speed - RPM 2-spd, High 710, Low 473 N/A N/A
1-spd, 710
Cycle/Temperature Hot High High
Warm Medium Medium
Cold Low Low
Delicate Delicate
Electrical Specifications and 120/60/1-15 amp Electric: 120/240/60/1-30 amp Electric: 120/240/60/1-30 amp
Circuit Requirements 120/208/60/1-30 amp 120/208/60/1-30 amp
Gas: 120/60/1-15 amp Gas: 120/60/1-15 amp
Motor - RPM 60 Hz: 1725 or 1140 60 Hz: 1725 60 Hz: 1725
Btu Per Hour N/A 25,000 (6,300 kcal) 25,000 (6,300 kcal)
Heating Element N/A 5350 W, 240 V 5350 W, 240 V
4750 W, 208 V 4750 W, 208 V
Type of Gas (Gas models only) N/A Factory-equipped natural/ Factor y-equipped natural/
mixed gas. Convertible mixed gas. Convertible
to LP gas.** to LP gas.**
Utility Connections - in (mm) N/A Gas: 3/8" NPT (9.5) Gas: 3/8" NPT (9.5)
Air Outlet Diameter - in (mm) N/A 4" (102) 4" (102)
Exhaust Airflow
*** - cfm (liters/sec.) N/A 220 (105) 220 (105)
Maximum Exhaust N/A 0.6" W.C. 0.6" W.C.
Static Back Pressure
Agency Approval UL Electric: UL Electric: UL
Gas: CSA Star Gas: CSA Star
Activation Coin-Operated Coin-Operated Coin-Operated
Self-Adjusting Rear Legs Ye s N o N o
Top and Lid Finish Porcelain Porcelain N/A
Colors White, Bisque White, Bisque White, Bisque
Door Type Solid Solid Solid, Window
* Heights may vary slightly depending on leveling adjustments.
** IMPORTANT: Any product revisions or conversions must be made by the Manufacturer’s Authorized Dealers, Distributors, or local service personnel.
*** Measured at point of exit from dryer. Also available in 50 Hz. Features and certifications may vary by model.
At Speed Queen, we’re so confident our heavy-duty commercial washers and dryers are Commercial Built to Last Longer, that we’re offering the following
limited warranty to prove it: Through three years† — Any part of the washer, dryer or stack dryer. Through five years† — The washer transmission
assembly, base and cabinet assembly including top, lid and door, against rust from inside out. Lifetime† — The stainless steel washtub.
† Parts only. Labor not included. See Speed Queen Warranty Bond for specifics.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,
design and specifications subject to change without notice. The quality management systems of Alliance Laundry Systems’ Ripon facility has been
registered to ISO 9001:2000.
©Copyright 2008 Alliance Laundry Systems LLC
Printed in the U.S.A.
