SpectraLink 84-series, 8450, 8452, 8453 Administration Manual

Spectralink 84-Series Wireless Telephone

Barcode Administration Guide

1725-86973-000 Rev: C
June 2014

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Copyright Notice

© 2012-2014 Spectralink Corporation All rights reserved. SpectralinkTM, the Spectralink logo and the
names and marks associated with Spectralink’s products are trademarks and/or service marks of
Spectralink Corporation and are common law marks in the United States and various other countries. All
other trademarks are property of their respective owners. No portion hereof may be reproduced or
transmitted in any form or by any means, for any purpose other than the recipient’s personal use, without
the express written permission of Spectralink.

All rights reserved under the International and pan-American Copyright Conventions. No part of this
manual, or the software described herein, may be reproduced or transmitted in any form or by any
means, or translated into another language or format, in whole or in part, without the express written
permission of Spectralink Corporation.

Do not remove (or allow any third party to remove) any product identification, copyright or other notices.

Notice

Spectralink Corporation has prepared this document for use by Spectralink personnel and customers.
The drawings and specifications contained herein are the property of Spectralink and shall be neither
reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any
license to make, use, or sell equipment manufactured in accordance herewith.

Spectralink reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult Spectralink to determine
whether any such changes have been made.

NO REPRESENTATION OR OTHER AFFIRMATION OF FACT CONTAINED IN THIS DOCUMENT
INCLUDING BUT NOT LIMITED TO STATEMENTS REGARDING CAPACITY, RESPONSE-TIME
PERFORMANCE, SUITABILITY FOR USE, OR PERFORMANCE OF PRODUCTS DESCRIBED
HEREIN SHALL BE DEEMED TO BE A WARRANTY BY SPECTRALINK FOR ANY PURPOSE, OR
GIVE RISE TO ANY LIABILITY OF SPECTRALINK WHATSOEVER.

Warranty

The Product Warranty and Software License and Warranty and other support documents are available at

http://support.spectralink.com.

Contact Information

US Location European Location
800-775-5330 [phone]

Spectralink Corporation Spectralink Europe ApS
2560 55th Street Langmarksvej 34
Boulder, CO 80301 8700 Horsens, Denmark

[e-mail] [e-mail]

1725-86973-000_C.docx
June 2014 2

Contents

Introduction ...................................................................... 5

Product Support ............................................................................................................... 5

Spectralink References .................................................................................................... 5

Barcode Reference ........................................................................................................... 5

Conventions Used In This Document .............................................................................. 6

Icons ............................................................................................................................... 6

Typography ..................................................................................................................... 7

Chapter 1: Understanding Barcode Technology ......................... 8

1D vs. 2D Formats............................................................................................................. 8

8450 and 1D Barcode Patterns ....................................................................................... 8

8452/8453 and 2D Barcode Patterns ............................................................................... 8

Chapter 2: Barcode Applications .......................................... 10

Using On-board Applications..........................................................................................10

Using the Quick Barcode Connector™ (QBC) ...............................................................10

Supported Symbologies ..................................................................................................10

Special Alerts for Barcode Applications ........................................................................11

Chapter 3: Barcode Implementation ....................................... 13

Conflicting Symbologies .................................................................................................15

Chapter 4: Barcode Parameters ............................................ 16

Administration Parameters .............................................................................................16

Symbology Parameters ...................................................................................................18

Aztec .............................................................................................................................. 18

Codabar ................................ ......................................................................................... 19

Code 11 .........................................................................................................................21

Code 39 .........................................................................................................................23

Code 93 .........................................................................................................................26

Code 128........................................................................................................................27

Datamatrix ......................................................................................................................31

EAN / UPC .....................................................................................................................31

GS1 Composite ..............................................................................................................34

GS1 Databar ..................................................................................................................34

Interleaved 2 of 5 ................................................................ ............................................35

Micro PDF 417 ...............................................................................................................37

MSI Code .......................................................................................................................38

1725-86973-000_C.docx
June 2014 3

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

PDF 417 .........................................................................................................................40

Plessey Code .................................................................................................................40

QR Code ........................................................................................................................42

Standard 2 of 5 ...............................................................................................................42

Telepen ..........................................................................................................................43

Appendix A: Open Source Information ................................... 46

OFFER for Source for GPL and LGPL Software ............................................................46

Contact Information for Requesting Source Code ...........................................................46

1725-86973-000_C.docx
June 2014 4

Introduction

This is your guide to understanding how barcode technology works in conjunction with the
Spectralink 8450/8452/8453 handsets and how to deploy it in your facility.

Refer to this document when you need to configure your handsets for a barcode application or
when you need to change a barcode configuration due to advances or changes in the
technology.

Be aware that this is a living document. Barcode technology changes rapidly and this document
makes every effort to keep up. If you have questions, please contact your Spectralink service
provider.

Product Support

Spectralink wants you to have a successful installation. If you have questions please contact the
Customer Support Hotline at 1-800-775-5330.

The hotline is open Monday through Friday, 6 a.m. to 6 p.m. Mountain time.
For Technical Support: mailto:[e-mail]
For Knowledge Base:

http://support.spectralink.com/SpectralinkService/support/us/support/voice/wi­fi/spectralink_8400_wireless.html

For Return Material Authorization: mailto:[e-mail]

Spectralink References

All Spectralink documents are available at http://support.spectralink.com. Use the Documents
and Downloads pane and select Voice as the Product Type and then select the Spectralink
84-Series Wireless Telephone from the page. For other documents, use the navigation pane on
the left to locate the product and open the page.

Specific Documents

The Spectralink 84-Series Wireless Telephone Administration Guide provides a comprehensive
list of every parameter available on Spectralink 84-Series Wireless Telephones.

Spectralink 84-Series Wireless Telephone Deployment Guide This document introduces
deployment concepts and the methods of provisioning the 84-Series handsets in any type of
facility. It is the fundamental text and a prerequisite to this Administration Guide, especially for
administrators who are new to the Spectralink 84-Series handsets or who may wish a refresher
course.

1725-86973-000_C.docx
June 2014 5

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Caution

The Caution icon highlights information you need to know to avoid a hazard that
could potentially impact device performance, application functionality, successful
feature configuration and/or affect handset or network performance.

Admin Tip

This tip advises the administrator of a smarter, more productive or alternative
method of performing an administrator-level task or procedure.

Settings

The Settings icon highlights information to help you zero in on settings you need to
choose for a specific behavior, to enable a specific feature, or access
customization options.

Quick Barcode Connector Administration Guide Provides instruction for implementation of the
barcode application. The Spectralink 84-Series User Guide contains information about using the
barcode feature.

The Spectralink 84-Series User Guide offers comprehensive instructions on using each of the
features deployed on the handsets.

Barcode Reference

The Bar Code Book: A Comprehensive Guide to Reading, Printing, Specifying, Evaluating, and
Using Bar Code and Other Machine-Readable Symbols by Roger C. Palmer, Fifth Edition

The book describes the many different forms of 1-D and 2-D bar code symbols, explains how
they work, compares their attributes, and provides detailed reference information. Equipment
used for printing, reading, and evaluating bar code symbols is reviewed, and extensive
information is provided about the applicable industry standards. The emerging fields of Direct
Part Marking and image-based scanning is reviewed, and the issue of patents is presented.
Many applications of the technology are described.

Conventions Used In This Document

Icons

Icons indicate extra information about nearby text.

1725-86973-000_C.docx
June 2014 6

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Convention

Description

Bold

Highlights interface items such as menus, soft keys, file names, and
directories. Also used to represent menu selections and text entry to the
handset.

Italics

Used to emphasize text, to show example values or inputs, and to show
titles of reference documents available from the Spectralink Support Web
site and other reference sites.

Underlined blue

Used for URL links to external Web pages or documents. If you click on
text in this style, you will be linked to an external document or Web page.

Bright orange text

Used for cross references to other sections within this document. If you
click on text in this style, you will be taken to another part of this
document.

Fixed-width-font

Used for code fragments and parameter names.

Convention

Description

<MACaddress>

Indicates that you must enter information specific to your installation,
handset, or network. For example, when you see <MACaddress>, enter
your handset’s 12-digit MAC address. If you see <installed-directory>,
enter the path to your installation directory.

>

Indicates that you need to select an item from a menu. For example,

Settings > Basic indicates that you need to select Basic from the
Settings menu.

Typography

A few typographic conventions, listed next, are used in this guide to distinguish types of in-text
information.

This guide also uses a few writing conventions to distinguish conditional information.

1725-86973-000_C.docx

June 2014 7

Chapter 1: Understanding Barcode

Technology

Barcode technology enables you to encode and decode information stored in a variety of visual
patterns. Barcode patterns can store a variety of data. Currently, the Spectralink 8450 handset
supports a wide range of one-dimensional (1D) and stacked 1D barcode types, including the
Code 128 barcode symbology, which can contain up to 70 numerals and/or characters. The
Spectralink 8452/8453 handset supports a wide range of two-dimensional (2D) barcode types.
Two-dimensional barcode symbologies typically encode more data, which may be contained in
a smaller barcode label, as compared with 1D barcode symbologies. The Spectralink 8450 can
only decode 1D barcode symbologies, whereas the Spectralink 8452/8453 can decode both 1D
and 2D barcode label formats. The Spectralink 8452/8453 can also decode composite
barcodes that contain both a 1D and a 2D barcode component, such as the GS1 Composite
CC-A/B symbology often found on drug packaging.

1D vs. 2D Formats

8450 and 1D Barcode Patterns

Barcode patterns can store a variety of data. Currently, your Spectralink 8450 handset supports
a wide range of one-dimensional (1D) and stacked ID barcode types, including the Code 128
barcode symbology, which can contain up to 70 numerals and/or characters.

1D example (Code 128 symbology)

8452/8453 and 2D Barcode Patterns

Your Spectralink 8452/8453 handset supports a wide range of two-dimensional (2D) barcode
types. Two-dimensional barcode symbologies typically encode more data, which may be
contained in a smaller barcode label, as compared with 1D barcode symbologies. The
Spectralink 8452/8453 can decode both 1D and 2D barcode label formats, as well as composite
1D/2D barcodes.

1725-86973-000_C.docx
June 2014 8

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

2D example (QR Code symbology)

1725-86973-000_C.docx
June 2014 9

Chapter 2: Barcode Applications

Caution: Required settings for QBC

Several settings MUST be set to their default value to ensure correct
interoperability between the handset and QBC:

 barcode.preambleTransmissionValue (default Null)
 barcode.postambleTransmissionValue (default Null)
 barcode.symbologyIdTransmission (default 0)

See the explanation of these parameters in Administration Parameters.

Barcode information is typically entered into a field in an application that processes the data.
This application might be running:

 in the web browser on the handset
 on a computer that is linked to a Spectralink 845x handset via QBC.

Using On-board Applications

The first item is a web application running on the web browser on the handset. The scanned
information is used by the web application and either populates an input field on the page or is
used by code in the web page to continue a work flow.

Using the Quick Barcode Connector™ (QBC)

The second item is an application that is running on a computer accessible to the user that has
been loaded with the Quick Barcode Connector application. QBC enables you to capture
barcode data using a Spectralink 8450 or 8452/8453 handset and transfer the data to the
application running on the computer associated with the scanning handset. You can think of it
as a wireless barcode scanner connected to the computer.

For more information, see the Quick Barcode Connector (QBC) Administration Guide.

1725-86973-000_C.docx
June 2014 10

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Symbology

1D

2D

Aztec

X

Codabar

X X Code11

X X Code 39

X X Code 93

X X Code 128*†

X X DataMatrix

X X EAN / UPC†

X

X

GS1 Composite*†

X

X

GS1 DataBar

X

X

Interleaved 2 of 5*

X

X

Micro PDF 417

X MSI Code

X X PDF 417

X Plessey Code

X X QR Code

X Standard 2 of 5

X X Telepen

X

X

Note: Symbologies available by default on 84- and 87- Series handsets

All symbologies covered in this document (except for GS1 Composite) are available
on both the 84- and 87-Series handsets and are enabled by default. The 84 Series
can be additionally configured through the .cfg files. The 87-Series is not further
configurable for barcode symbologies and therefore only the default settings can be
deployed as of this writing.

Supported Symbologies

All of the symbologies listed here are enabled by default except GS1 Composite.

* Some parameters apply only to 1D or 2D.
† This symbology has conflicts with other symbologies or internally. Please see the section

Conflicting Symbologies for explanation.

1725-86973-000_C.docx
June 2014 11

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Special Alerts for Barcode Applications

You can assign special alerts, ringtones and vibrations for certain events. The Spectralink
84-Series User Guide contains instruction on how to set ring types for different conditions.

1725-86973-000_C.docx
June 2014 12

Chapter 3: Barcode Implementation

Admin Tip: Recommended configuration

Although barcode parameters can be included almost anywhere in the .cfg file
structure, the recommendations given here conform to the standard configurations
as given in the Spectralink 84-Series Deployment Guide. Following these
guidelines will make your installation easier to administer and support.

Implementation of barcode parameters requires that you include your symbology parameters in
the configuration (.cfg) files that you prepare for your facility. If you are using one of the
templates included with the software, common barcodes are enabled by default.

Configuration flexibility allows you to structure the files according to the most efficient method
for your facility. See the Spectralink 84-Series Deployment Guide for a full explanation of .cfg
files and how they are structured. Double check the site.cfg file to determine if the barcode you
want to deploy is enabled.

Parameters are assigned by:

 Site – parameters that apply to the entire deployment such as network, log-in, DHCP,

etc.

 Group – parameters that apply to a limited number of users such as nurses or sales

departments.

 User – parameters that apply to specific users such as extension and username.

The first essential factor in determining how to configure the parameters is whether all
8450/8452/8453 handsets will be using the same barcode symbology/symbologies or if specific
groups will need certain symbologies that conflict with the symbologies used by another group.
See the section below for information on conflicting symbologies.

One of these three types of configurations is recommended.

 If different and conflicting barcode symbologies are deployed, the conflicting parameters

should be assigned to a group or groups and included in each group’s .cfg file.

 If all barcode symbologies are the same for all handsets and no conflicting symbologies

are required, the parameters are best deployed site-wide in the site.cfg file or in a
separate barcode.cfg file that all handsets reference through the 00000000000.cfg file.

 In rare instances, parameters should be included in the user file. For instance if only one

user requires a certain symbology that conflicts with the symbologies used in the rest of
the facility, that specific handset can be configured with the unique symbology.

If conflicting symbologies are in use and group .cfg files cannot be used, you must include
the barcode parameters in each user profile .cfg file.

1725-86973-000_C.docx
June 2014 13

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Group

Deployment

Site.cfg

(may include barcode parameters)

<macaddress>.cfg

- site.cfg

- [Group].cfg

- <identity>. cfg

[Group]

(includes barcode parameters)

(one file for each phone)

[user].cfg

(may include barcode parameters)

Flat

Deployment

Site.cfg

(may include barcode parameters)

00000000000.cfg

- site.cfg

- barcode.cfg

- <macaddress>-ext.cfg

Barcode.cfg

(or)

(one file for each phone)

<macaddress>-ext.cfg

(may include barcode parameters)

User Profiles

Site.cfg

(may include barcode parameters)

00000000000.cfg

- site.cfg

(one file for each user)

[User Profile]

(may include barcode parameters)

Settings: The barcode.cfg file

All barcode parameters are included in the barcode.cfg template. You can use this
file to customize barcode parameters for your facility by either including it
wholesale as in Flat Deployment or by copying and pasting the symbologies you
want to deploy into another .cfg file.

These recommendations align with the three Scenarios described in the Deployment Guide:

As you can see from the above graphic, any .cfg file could contain the barcode parameters.
Your primary concerns should be accuracy of deployment and ease of maintenance. Therefore,
the general parameters should be included in the site.cfg file unless:

 you are using the barcode.cfg file as shown as an option in the Flat Deployment

 you must deploy conflicting parameters in which case you would put the symbologies in

scenario

a [Group] or [user] file.

1725-86973-000_C.docx
June 2014 14

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Caution

Certain symbologies are mutually exclusive. If you use the barcode.cfg file, ensure
that you disable the symbologies that you do not want to deploy. If you deploy
conflicting symbologies, ensure that they are segregated by [Group] or by [User].

Conflicting Symbologies

The GS1 Composite symbology and the EAN/UPC symbology can conflict with each
other.

This is due to the fact that some GS1 Composite variants (e.g. CC-A/B) contain a 2D barcode
and a UPC or EAN barcode. If you are trying to scan such a barcode and you have EAN/UPC
enabled, the barcode scanner may only return the EAN/UPC data and not the 2D portion of the
composite barcode.

ISBT 128 and Code 128 conflict with each other.

ISBT 128 consists of a Code 128 barcode with special data ID information prepended to the
barcode data. If read as an ISBT 128 barcode, the scanner can correctly interpret this special
data ID information. If read as a Code 128 barcode, the scanner will mistake the special data ID
information as just part of the barcode data. For this reason, the configuration parameters

enforce that they can’t both be activated. (See

barcode.symbology.symbology128Type.selection)

1725-86973-000_C.docx
June 2014 15

Chapter 4: Barcode Parameters

Parameter

Permitted Values

Default

Interpretation

barcode.

aimingBeamDuration

0 to 2550,
milliseconds

500 or

400

The aiming beam duration.

The default for the Spectralink 8450 is 500. The default
for the Spectralink 8452/8453 is 400.

barcode.

aimingBeamMode

0 to 2

0

The aiming beam mode. If the aiming beam is turned
on, the scanner will turn on the aiming beam for the
barcode.aimingBeamDuration before attempting to
decode a barcode. This allows a user to more
accurately aim the scanner, ensuring accurate
scanning of a particular barcode when many barcodes
are close together. Enabling this will cause the
minimum time to scan a barcode to increase by the
barcode.aimingBeamDuration. NOTE: Changing this

value from will significantly change the user’s barcode
scanning experience, so be sure to enlist your user’s

help in determining their preferred method.

The supported values are:

• 0 = typical aimer

• 1 = one button press aim and read

• 2 = first button press aim, second button press read

barcode.

centerDecodingActivation

0 or 1

0 or 1

A flag to determine if center decoding activation is
enabled. Center Decoding causes the scanner to only
attempt to decode barcodes at, or near the center of
the scan area.

If 0, center decoding activation is disabled

(default for the Spectralink 8450).

If 1, center decoding activation is enabled (default for
the Spectralink 8452/8453). The
barcode.centerDecodingTolerance parameter is used.

Barcode parameters must be set to correctly scan the symbologies encountered so that the
information passed to application programs (either internal web applications or to the PC via
QBC) contains the barcode data information the programs expected. For QBC, the barcode
parameters set in the provisioning server files must match the type of barcode input requested
by the application program for a successful implementation of barcoding.

Barcode parameter groups are listed here in alphabetical order. Most symbologies are enabled
by default.

Administration Parameters

1725-86973-000_C.docx
June 2014 16

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Parameter

Permitted Values

Default

Interpretation

barcode.

centerDecodingTolerance

0 to 100

00 or 10

The center decoding tolerance. The larger the value,
the further from the center the barcode can be and
still be decoded. A low value is useful when there is a
high density of barcodes. A high value allows the
scanner to more quickly acquire and read a barcode.

The default for the Spectralink 8450 is 00. The default
for the Spectralink 8452/8453 is 10.

barcode.

postambleTransmissionValue

Hex string

1-20 bytes of 00-FF

or Null

Null

The postamble transmission value.

If defined, this value is appended to the barcode data
scanned. (e.g. [barcode data][postamble])

If the QBC application is used, this parameter MUST be
set to Null. Note that the QBC application allows
configuration of a postamble that it will append to the
barcode data.

Note that all of the optional transmitted data is
inserted in the following order if configured:
[preamble][symbologyID][barcode data][postamble]

barcode.

preambleTransmissionValue

Hex string

1-20 bytes of 00-FF

or Null

Null

The preamble transmission value.

If defined, this value is prepended to the barcode data
scanned. ([preamble][barcode data])

If the Quick Barcode Connector (QBC) application is
used, this parameter MUST be set to Null. Note that
the QBC application allows configuration of a
preamble that it will prepend to the barcode data.

Note that all of the optional transmitted data is
inserted in the following order if configured:
[preamble][symbologyID][barcode data][postamble]

barcode.symbologyId
Transmission

0 to 2

0

Determines whether the AIM symbology ID is
transmitted. The symbology ID is a code that uniquely
identifies each barcode symbology type.

If non-zero, the Symbology ID is sent just before the
barcode data. ([symbologyID][barcode data])

If the QBC application is used, this parameter MUST be
set to Null.

The supported values are:

• 0 = disable transmission

• 2 = AIM Identifier

Note that all of the optional transmitted data is
inserted in the following order if configured:
[preamble][symbologyID][barcode data][postamble]

AIM identifiers are 3 characters, starting with a “]”.
The second character is the AIM symbology ID
character, and the third character is the Processing

1725-86973-000_C.docx
June 2014 17

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Parameter

Permitted Values

Default

Interpretation

option. Thus, for example, the AIM for an Aztec

barcode is “]z0”. The symbology ID and processing

option characters for all supported symbologies are:

Symbology

Symbology ID

Processing option

Aztec

z 0 Codabar

F

0,1,2 or 4

Code 11

H

0,1 or 3

Code 39

A

0,1,3,4,5 or 7

Code 93/93i

G

0,1-9,A-Z,or a-m

Datamatrix

d 1 EAN/UPC (standard lengths)

E

0,3 or 4

EAN/UPC (other lengths with no check digit)

X 0 EAN/UPC linear components

E

0,1,2,3 or 4

GS1 Composite

e

0,1,2 or 3

GS1 Databar

e

0

Interleaved 2 of 5

I

0,1 or 3

MSI Code

M

0 or 1

PDF417/MicroPDF

L

0,3,4 or 5

Plessey Code

P 0 QR Code

Q

0 or 1

Standard 2 of 5 (2 start/stop bars)

R

0,1 or 3

Standard 2 of 5 (3 start/stop bars)

S 0 Telepen

B

0 or 1

barcode.

illuminationLevel

(2D only)

0 to 100

50

The illumination level of the background rectangular
LED. 50% gives good overall performance. Higher
values might give better performance in very low light
environments but will have an impact on battery life in
heavy scanning situations.

Only available for 8452/8453.

Aztec
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
aztec.
enabled

0 or 1

1

A flag to determine whether or not Aztec symbology is
enabled.

Aztec is a two-dimensional matrix style symbology
which can encode around 3000 character using entire

Symbology Parameters

Aztec

(2D only)

1725-86973-000_C.docx
June 2014 18

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Aztec
Parameter

Permitted Values

Default

Interpretation

256-byte ASCII character set. This symbology is only
available on the Spectralink 8452/8453 handset.

barcode.symbology.
aztec.
structureAppendMode

0 or 1

0

A flag to determine whether or not structure append
mode is enabled.

If set to 1, the Aztec structured append header is used
instead of ECI.

barcode.symbology.
aztec.
GS1-128Emulation

0 or 1

0

A flag to determine whether or not GS1-128 Emulation
is enabled.

Codabar
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
codabar.
enabled

0 or 1

1

A flag to determine whether or not Codabar symbology
is enabled.

Codabar is a self-checking, discrete numerical
symbology. It has a 16 character set and is used in
blood banks, libraries and certain express parcel
applications.

barcode.symbology.
codabar.
checkDigitTransmission

0 or 1

0

A flag to determine whether or not the check digit is
transmitted for Codabar. The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
codabar.
checkDigitVerification

0 or 1

0

A flag to determine whether or not to enable check
digit verification for Codabar.

barcode.symbology.
codabar.
clsi

0 or 1

0

The CLSI library system. The CLSI library system for
Codabar inserts spaces after characters 1, 5, and 10 in
the 14-character label. Start/stop characters can be
transmitted or not transmitted as required. This system
is used by some libraries in the USA.

The support values are:

• 0 = not active

• 1 = active (insert spaces)

barcode.symbology.
codabar.
concatenation

0 to 2

0

Two adjacent Codabar codes scanned in a single sweep
can be concatenated and sent as a single message.

Codabar concatenation is applied according to the
concatenation mode selected in barcode. symbology.
codabar. concatenationMode.

Codabar

1725-86973-000_C.docx
June 2014 19

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Codabar
Parameter

Permitted Values

Default

Interpretation

The supported values are:

• 0 = not active

• 1 = transmitted concatenated code only

• 2 = transmit all codes (single and concatenated)

barcode.symbology.
codabar.
concatenationMode

0 to 2

0

Concatenation is applied differently depending on the
concatenation mode. There are 3 different modes:

• No restrictions

Concatenates all adjacent codes, intermediate
start/stop characters are not transmitted.

• First code stop character = second code start
character

Only concatenates adjacent codes if the first code stop
character is the same as the second code start
character (C123456A + A123456D = 123456123456 or
C123456123456D if start/stop characters are
transmitted).

• American Blood Commission (ABC)

Only concatenates adjacent codes if the stop character
of the first code = D and the start character of the
second code = D (C123456D + D123456A =
123456123456 or C123456123456A if start/stop
characters are transmitted).

The supported values are:

• 0 = no restrictions

• 1 = first code stop = second code start

• 2 American Blood Commission (ABC)

barcode.symbology.
codabar.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length

1725-86973-000_C.docx
June 2014 20

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Codabar
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
codabar.
lengthL1

0 to 255

6

The Codabar symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.codabar.lengthMode used.
Minimum length for Codabar is 3 characters.

Bar code length = <start> + <bar code data> + [check
digit] + <stop>

barcode.symbology.
codabar.
lengthL2

0 to 255

0

The Codabar symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.codabar.lengthMode used.
Minimum length for Codabar is 3 characters.

Bar code length = <start> + <bar code data> + [check
digit] + <stop>

barcode.symbology.
codabar.
lengthL3

0 to 255

0

The Codabar symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.codabar.lengthMode used.
Minimum length for Codabar is 3 characters.

Bar code length = <start> + <bar code data> + [check
digit] + <stop>

barcode.symbology.
codabar.
startStopTransmission

0 to 4

0

The start/stop tramission characters. The supported
values are:

• 0 = not transmitted

• 1 = “a, b,c, d” transmitted

• 2 = “A, B, C, D” transmitted

• 3 = “a,b,c,d / t,n, *, e” transmitted

• 4 = “DC1, DC2, DC3, DC4” transmitted

Code 11
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code11.
enabled

0 or 1

1

A flag to determine whether or not Code 11 symbology
is enabled.

Code 11 is a very high density, discrete numeric
symbology. It is most extensively used in labeling
telecommunications components and equipment.

Code 11

1725-86973-000_C.docx
June 2014 21

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 11
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code11.
checkDigitTransmission

0 or 1

1

A flag to determine whether or not the check digit is
transmitted for Code 11. The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
code11.
checkDigitVerification

1 or 2

1

The number of check digits for Code 11 check digit
verification.

The supported values are:

• 1 = 1 digit

• 2 = 2 digits

barcode.symbology.
code11.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode.

There are three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length

barcode.symbology.
code11.
lengthL1

0 to 255

0

The Code 11 symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code11.lengthMode used.
Minimum length for Code 11 is 2 characters.

Bar code length = <bar code data>

barcode.symbology.
code11.
lengthL2

0 to 255

0

The Code 11 symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code11.lengthMode used.
Minimum length for Code 11 is 2 characters.

Bar code length = <bar code data>

1725-86973-000_C.docx
June 2014 22

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 11
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code11.
lengthL3

0 to 255

0

The Code 11symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code11.lengthMode used
Minimum length for Code 11 is 2 characters.

Bar code length = <bar code data>

Code 39
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code39.
enabled

0 or 1

1

A flag to determine whether or not Code 39 symbology
is enabled.

Code 39 is a discrete, variable length, and self-checking
alphanumeric symbology. The character set is
uppercase A to Z, 0 to 9, dollar sign ($), period (. ), slash
(/), percent (%), space ( ), plus (+), and minus (-).
Standard Code 39 supports 43 characters while Code
39 Full ASCII (or Extended Code 39) supports 128
characters.

barcode.symbology.
code39.
acceptedCharacters

1 to 3

2

The Code 39 accepted start characters. The supported
values are:

• 1 = $ only

• 2 = * only

• 3 = * and $

barcode.symbology.
code39.
checkDigitTransmission

0 or 1

0

A flag to determine whether or not the check digit is
transmitted for Code39. The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
code39.
checkDigitVerification

0 to 3

1

There are 3 types of check digit verification for

Code 39:

• Modulo 43

Standard check digit for Code 39 that uses the Modulo
43 algorithm. It provides extra validation of data.

• French CIP

Check digit used for the French pharmaceutical
industry. It is only used for codes with 7 characters.

• Italian CPI

Code 39

1725-86973-000_C.docx
June 2014 23

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 39
Parameter

Permitted Values

Default

Interpretation

Check digit used by the Italian pharmaceutical industry,
also known as Code 32. If the checksum is not validated
the code is transmitted as standard Code 39.

Activating one type of check digit deactivates all other
check digits.

The supported values are:

• 0 = disable

• 1 = modulo 43

• 2 = French CIP

• 3 = Italian CPI

barcode.symbology.
code39.
format

0 or 1

0

The Code 39 format type. When Code 39 full ASCII
conversion is enabled Code 39 bar codes are
transmitted with an extended character set. The full
128 ASCII character set is encoded in Code 39 by
combining two regular Code 39 characters.

The support values are:

• 0 = standard 43 characters

• 1 = full ASCII (extended)

barcode.symbology.
code39.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length

barcode.symbology.
code39.
lengthL1

0 to 255

0

The Code 39 symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code39.lengthMode used.
Minimum length for Code 39 is 3 characters.

1725-86973-000_C.docx
June 2014 24

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 39
Parameter

Permitted Values

Default

Interpretation

Bar code length = <start> + <bar code data> + [check
digit] + <stop>

barcode.symbology.
code39.
lengthL2

0 to 255

0

The Code 39 symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code39.lengthMode used.
Minimum length for Code 39 is 3 characters.

Bar code length = <start> + <bar code data> + [check
digit] + <stop>

barcode.symbology.
code39.
lengthL3

0 to 255

0

The Code 39 symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code39.lengthMode used.
Minimum length for Code 39 is 3 characters.

Bar code length = <start> + <bar code data> + [check
digit] + <stop>

barcode.symbology.
code39.
readingTolerance

0 to 2

0

The Code 39 reading tolerance. The tolerance levels for
reading "hard to read" bar codes are:

• High

This is the most permissive mode. When enabled, the
scanner reads codes of variable quality.

The first margin of the quiet zone is expected to be four
times the width of the narrow element, and the second
margin twice the width.

Quiet zone is the white space before and after a bar
code to ensure correct decoding.

• Medium

This mode allows medium permissiveness.

• Low

This is the least permissive mode. When enabled, the
scanner reads only high quality codes that meet the
official Code 39 standards.

The first margin of the quiet zone is expected to be
seven times the width of the narrow element, the
second margin ten times.

The support values are:

• 0 = high

• 1 = medium

• 2 = low

1725-86973-000_C.docx
June 2014 25

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 39
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code39.
startStop

0 or 1

0

A flag to determine whether or not the Code 39
start/stop transmission is transmitted. The supported
values are:

• 0 = not transmitted

• 1 = transmitted

Code 93
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code93.
enabled

0 or 1

1

A flag to determine whether or not Code 93 symbology
is enabled.

Code 93 is an alphanumeric full ASCII symbology using
combinations of 2 characters. Unlike Code 39, Code 93
is a continuous symbology which produces denser
code. Code 93i encompasses and extends Code 93:
alphanumeric, full and extended ASCII, and all Unicode
characters.

barcode.symbology.
code93.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length

barcode.symbology.
code93.
lengthL1

0 to 255

0

The Code 93 symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code93.lengthMode used.
Minimum length for Code 93 is 1 character.

Bar code length = <bar code data>

Code 93

1725-86973-000_C.docx
June 2014 26

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 93
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
code93.
lengthL2

0 to 255

0

The Code 93 symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code93.lengthMode used.
Minimum length for Code 93 is 1 character.

Bar code length = <bar code data>

barcode.symbology.
code93.
lengthL3

0 to 255

0

The Code 93 symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the
barcode.symbology.code93.lengthMode used.
Minimum length for Code 93 is 1 character.

Bar code length = <bar code data>

Code 128
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
symbology128Type.
selection

0 to 4

3

The group of 128 Type symbologies that are enabled.
The supported values are:

• 0 = Code 128 disabled, GS1-128 disabled, ISBT 128
disabled.

• 1 = Code 128 enabled, GS1-128 disabled, ISBT 128
disabled.

• 2 = Code 128 disabled, GS1-128 enabled, ISBT 128
disabled

• 3 = (default) Code 128 enabled, GS1-128 enabled,
ISBT 128 disabled

• 4 = Code 128 disabled, GS1-128 disabled, ISBT 128
enabled

Code 128 is a very high-density alphanumeric
symbology that supports the extended ASCII character
set. It is a variable length, continuous code that uses
multiple element widths.

GS1-128 is a form of Code 128. It uses the normal Code
128 and adds the FNC1 character in the first position.

ISBT 128 is a variant of Code 128. It has been adapted
for use in Blood Transfusion Services worldwide by the
International Society of Blood Transfusion (ISBT).

Code 128

1725-86973-000_C.docx
June 2014 27

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 128
Parameter

Permitted Values

Default

Interpretation

Caution

ISBT 128 and Code 128 cannot be enabled at the same time.

barcode.symbology.
symbology128Type.
GS1-128Id

0 or 1

1

The GS1-128 identifier. According the GS1-128
norm, the AIM identifier "]C1" is added by default in
front of each GS1-128 bar code as follows:

]C1<data>

You can decide to keep this identifier or remove it.

The supported values are:

• 0 = remove AIM identifier from data

• 1 = include AIM identifier in data

barcode.symbology.
symbology128Type.
fnc1Separator

Hex string

One byte of 00 to FF

1d

The FNC1 separator character. This separator is
used when multiple identifiers and their fields are
concatenated. For example, this is useful for
separating fields when the <GS> character cannot
be transmitted. The value should be specified in
hexidecimal.

barcode.symbology.
symbology128Type.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are
used differently depending on the length mode.
There are three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1
and longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified
by L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length
specified by L1 and not longer than the maximum
length specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length

barcode.symbology.
symbology128Type.
lengthL1

0 to 255

0

The symbology 128 L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for Code 128/GS1-128 is 1
character.

Bar code length = <bar code data>

1725-86973-000_C.docx
June 2014 28

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 128
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
symbology128Type.
lengthL2

0 to 255

0

The symbology 128 L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for Code 128/GS1-128 is 1
character.

Bar code length = <bar code data>

barcode.symbology.
symbology128Type.
lengthL3

0 to 255

0

The symbology 128 L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for Code 128/GS1-128 is 1
character.

Bar code length = <bar code data>

barcode.symbology.
symbology128Type.
readingRange

(1D only)

0 or 1

0

The symbology 128 reading range. Use extended
reading range when long distance reading is
important for your application. When using this
mode a special algorithm is used and reading
distances are significantly increased.

The supported values are:

• 0 = normal

• 1 = extended

barcode.symbology.
symbology128Type.
readingTolerance

0 to 2

0

The symbology 128 reading tolerance. Set the
tolerance level for reading hard to read bar codes:

• High - most permissive (reads codes of variable
quality)

• Medium - medium permissiveness

• Low - least permissive (reads only high quality

codes including · quiet zone verification)

Quiet zone is the white space before and after a bar
code to ensure correct decoding.

The support values are:

• 0 = high

• 1 = medium

• 2 = low

barcode.symbology.
symbology128Type.
isbt128TransmitCodes

0 to 2

0

The transmission mode for concatenated ISBT

128 codes. The supported values are:

• 0 = Disable

Codes are always transmitted as single codes (no
concatenation).

• 1 = Concatenated codes only

1725-86973-000_C.docx
June 2014 29

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Code 128
Parameter

Permitted Values

Default

Interpretation

Only transmits concatenated codes, does not
transmit single codes.

• 2 = Single codes and concatenated codes

Single codes and concatenated codes are both
transmitted. If the product can only "see" one code
of a code pair it will send that code as a single code.
If the product "sees" both codes of a pair it will
concatenate the codes depending on the
concatenation mode setting.

barcode.symbology.
symbology128Type.
isbt128Concatenate Pairs

0 or 1

0

The ISBT 128 Concatenation pairs. Certain ISBT 128
codes are always concatenated in compliance with
Section 4. 1 of the "ISBT 128 Bar Code Symbology
and Application Specification for Labeling of Whole
Blood and Blood Components" (June 2000, Version

1. 2. 1). These include:

• Donation Identification Number + ABO/Rh

(D) Blood Groups

• Donation Identification Number + Donor

Identification Number

• Donation Identification Number + Confidential
Unit Exclusion Status

• Product Code + Expiration Date

All other code pairs are not concatenated unless the
scanner is set to concatenate all code pairs.

Concatenated codes are transmitted according to
the concatenation transmission mode selected.

The support values are:

• 0 = authorized ISBT 128 code pairs only

• 1 = all ISBT 128 code pairs

barcode.symbology.
symbology128Type.
gtinProcessing

0 or 1

0

A flag to determine whether or not GTIN processing
for GS1-128 is enabled. GTIN stands for "Global
Trade Item Number" and transmits GS1-128 as the
14 character GS1 Composite GTIN.

barcode.symbology.
symbology128Type.
unconventionalGS1-128

0 or 1

0

A flag to determine whether or not unconventional
GS1-128 barcodes are decoded. Unconventional
GS1-128 allows decoding of unconventional GS1­128 which is GS1-128 with two FNC1 characters at
the beginning.

1725-86973-000_C.docx
June 2014 30

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Datamatrix
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
datamatrix.
enabled

0 or 1

1

A flag to determine whether or not the DataMatrix
symbology is enabled. DataMatrix is a two­dimensional matrix symbology which can encode up
to 2000 characters. DataMatrix is only supported by
the Spectralink 8452/8453 handset.

EAN / UPC
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
upca.
enabled

0 or 1

1

A flag to determine whether or not the UPC-A
symbology is enabled.

Universal Product Code (UPC) symbology is the most
commonly used bar code on consumer products in the
USA and Canada. It is a fixed-length, numeric,
continuous symbology that uses four element widths.

barcode.symbology.
upce.
enabled

0 or 1

1

A flag to determine whether or not the UPC-E
symbology is enabled.

UPC-E is a compressed version of UPC-A. It cuts the
data length in half by compressing the extra zeros. As it
is more compact than UPC-A, it is especially used on
products with very small packaging where UPC-A bar
codes would not normally fit.

barcode.symbology.
ean8.
enabled

0 or 1

1

A flag to determine whether or not the EAN-8
symbology is enabled.

EAN-8 is a compressed version of EAN-13 (as UPC-A
and UPC-E). As it is more compact than EAN-13, it is
especially used on products with very small packaging
where EAN-13 bar codes would not normally fit.

barcode.symbology.
ean13.
enabled

0 or 1

1

A flag to determine whether or not the EAN-13
symbology is enabled.

The European Article Numbering (EAN) symbology is an
extension of the UPC-A symbology which includes the
country information. This symbology is used on most
consumer goods in Europe.

barcode.symbology.
upcean.
addondigit.
transmission

0 or 1

0

The requirements for add-on digits for UPC/EAN
symbologies.

The supported values are:

• 0 = add-on digits not required but transmitted if read

• 1 = add-on digits required and transmitted

Datamatrix

EAN / UPC

1725-86973-000_C.docx
June 2014 31

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

EAN / UPC
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
upcean.
addondigit.
addon2

0 or 1

0

A flag to determine whether or not add-on 2 for all
UPC/EAN symbologies is enabled.

barcode.symbology.
upcean.
addondigit.
addon5

0 or 1

0

A flag to determine whether or not add-on 5 for all
UPC/EAN symbologies is enabled.

barcode.symbology.
upcean.
addondigit.
securityLevel

0 to 100

10

The add-on digit security is used only when add-on
digits are not required but transmitted. A higher
security level results in more secure decoding however
this can slow the decode rate.

barcode.symbology.
upca.
checkDigit Transmission

0 or 1

1

A flag to determine whether or not the check digit is
transmitted for UPCA.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
upce.
checkDigit Transmission

0 or 1

1

A flag to determine whether or not the check digit is
transmitted for UPCE.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
ean8.
checkDigit Transmission

0 or 1

1

A flag to determine whether or not the check digit is
transmitted for EAN-8.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
ean13.
checkDigit Transmission

0 or 1

1

A flag to determine whether or not the check digit is
transmitted for EAN-13.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
upca.
upcNumber
SystemTransmission

0 or 1

1

A flag to determine whether or not number system
transmission for UPC-A is enabled. UPC-A has a
transmitted number system equal to 0. To transmit the
additional leading character (country code), select
"UPC-A transmitted as EAN-13" option. The number
system is transmitted as follows:

<leading character> <number system> <data>

1725-86973-000_C.docx
June 2014 32

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

EAN / UPC
Parameter

Permitted Values

Default

Interpretation

<check digit>

barcode.symbology.
upce.
upcNumber
SystemTransmission

0 or 1

1

A flag to determine whether or not number system
transmission for UPC-E is enabled. The number system
is transmitted as follows:

<leading character> <number system> <data>

<check digit>

barcode.symbology.
upca.
reencoding

0 or 1

1

The UPC-A re-encoding format. The support values are:

• 0 = UPC-A transmitted as UPC-A

• 1 = UPC-A converted and transmitted as

EAN-13

barcode.symbology.
upce.
reencoding

0 or 1

1

The UPC-E re-encoding format. The support values are:

• 0 = UPC-E transmitted as UPC-E

• 1 = UPC-E converted and transmitted as UPC-A

barcode.symbology.
ean8.
reencoding

0 or 1

0

The EAN-8 re-encoding format. The support values are:

• 0 = EAN-8 transmitted as EAN-8

• 1 = EAN-8 converted and transmitted as

EAN-13

barcode.symbology.
upcean.
isbn.
enabled

0 or 1

1

Converts all EAN-13 bar codes beginning with "978" or
"979" (except for "9790") by removing the first 3 digits,
calculating the checksum on the remaining characters,
and adding the ISBN (International Standard Book
Number) check digit.

The supported values are:

• 0 = EAN-13 conversion to ISBN disabled

• 1 = EAN-13 conversion to ISBN enabled

Note: No conversion is done if GTIN processing is
active.

barcode.symbology.
upcean.
gtinProcessing

0 or 1

0

A flag to determine whether or not GTIN processing for
all UPC/EAN symbologies is enabled. GTIN stands for
"Global Trade Item Number" and transmits UPC/EAN
symbologies as the 14 character EAN. UCC GTIN.

barcode.symbology.
upcean.
readingRange

(1D only)

0 or 1

1

The reading range can be set to standard or extended.
Use extended reading range when long distance
reading is important for your application. When using
this mode a special algorithm is used and reading
distances are significantly increased.

The supported values are:

• 0 = normal

1725-86973-000_C.docx
June 2014 33

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

EAN / UPC
Parameter

Permitted Values

Default

Interpretation

• 1 = extended

GS1 Composite
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
GS1Composite.
cc-abCombined.enabled

0 or 1

0

0 = Not active

1 = Active

barcode.symbology.
GS1Composite.
cc-c.enabled

0 or 1

0

0 = No active

1 = Active

barcode.symbology.
GS1Composite.
linearTransmissionOnly

(2D only)

0 or 1

0

0 = Note active

1 = Active

barcode.symbology.
GS1Composite.
unconventional

(2D only)

0 or 1

0

0 = Not active

1 = Active

barcode.symbology.
GS1Composite.
GS1-128Emulation

(1D only)

0 or 1

0

0 = Not active

1 = Active

barcode.symbology.
GS1CompositeType.
eanUpcCompositeMessage

0 to 2

2

0 = Never linked

1 = Always linked

2 = Auto-discriminate

GS1 Databar
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
databar.
expended.
enabled

0 or 1

1

A flag to determine whether or not the GS1 DataBar
expanded symbology is enabled. GS1 DataBar is a high
density 1D bar code designed to encode standard GS1
Composite/EAN item numbers - up to 14 digits - in a
very small footprint.

GS1 DataBar Expanded encodes a GS1 Composite item
identification plus supplementary element strings such

GS1 Composite

GS1 Databar

1725-86973-000_C.docx
June 2014 34

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

GS1 Databar
Parameter

Permitted Values

Default

Interpretation

as weight and "best before" date in a linear symbol that
can be scanned omni-directionally by suitably
programmed point-of-sale scanners.

GS1 DataBar Expanded reads the following types of GS1
DataBar:

• GS1 DataBar Expanded

• GS1 DataBar Expanded Stacked

barcode.symbology.
databar.
limited.
enabled

0 or 1

1

A flag to determine whether or not the GS1 DataBar
limited symbology is enabled.

GS1 DataBar is a high density 1D bar code designed to
encode standard GS1 Composite/EAN item numbers ­up to 14 digits - in a very small footprint.

GS1 DataBar Limited encodes a 14-digit GS1 Composite
item identification with indicator digits of zero or one in
a linear symbol for use on small items that will not be
scanned at the point-of-sale.

GS1 DataBar Limited does not read stacked version.

barcode.symbology.
databar.
omni.
enabled

0 or 1

1

A flag to determine whether or not the GS1

DataBar omni-directional symbology is enabled. GS1
DataBar is a high density 1D bar code designed to
encode standard GS1 Composite/EAN item numbers ­up to 14 digits - in a very small footprint.

GS1 DataBar Omni-Directional encodes the full 14 digit
GS1 Composite item identification in a linear symbol
that can be scanned in any direction.

GS1 DataBar Omni-Directional reads the following
types of GS1 DataBar:

• GS1 DataBar Omni-Directional

• GS1 DataBar Truncated

• GS1 DataBar Stacked

• GS1 DataBar Stacked Omni-Directional

Interleaved 2 of 5
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
interleaved2of5.
enabled

0 or 1

1

A flag to determine whether or not the Interleaved 2 of
5 symbology is enabled. Interleaved 2 of 5 is a higher­density numerical symbology based upon the Standard
2 of 5 symbology. It is used primarily in the distribution
and warehouse industry. Unlike Standard 2 of 5, which
only encodes information in the width of the bars,

Interleaved 2 of 5

1725-86973-000_C.docx
June 2014 35

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Interleaved 2 of 5
Parameter

Permitted Values

Default

Interpretation

Interleaved 2 of 5 encodes data in the width of both
the bars and spaces.

barcode.symbology.
interleaved2of5.
checkDigit Transmission

0 or 1

0

A flag to determine whether or not the check digit is
transmitted for Interleaved 2 of 5.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
interleaved2of5.
checkDigitVerification

0 to 2

0

There are 2 types of check digit verification for

Interleaved 2 of 5:

• Modulo 10

Check digit usually used for Code Interleaved 2 of 5 that
applies the Modulo 10 algorithm.

• French CIP HR

Check digit used for the French pharmaceutical
industry. It is only used for codes with 7 characters.

Activating one type of check digit deactivates all other
check digits.

The supported values are:

• 0 = disable check digit verification

• 1 = enable Modulo 10 check digit verification

• 2 = enable French CIP HR check digit verification

barcode.symbology.
interleaved2of5.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length.

1725-86973-000_C.docx
June 2014 36

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Interleaved 2 of 5
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
interleaved2of5.
lengthL1

0 to 255

0

The Interleaved 2 of 5 symbology L1 length. Use L1, L2
and L3 to compose acceptable bar code lengths
depending on the length mode used. Minimum length
for Interleaved 2 of 5 is 4 characters.

Bar code length = <bar code data>

barcode.symbology.
interleaved2of5.
lengthL2

0 to 255

0

The Interleaved 2 of 5 symbology L2 length. Use L1, L2
and L3 to compose acceptable bar code lengths
depending on the length mode used. Minimum length
for Interleaved 2 of 5 is 4 characters.

Bar code length = <bar code data>

barcode.symbology.
interleaved2of5.
lengthL3

0 to 255

0

The Interleaved 2 of 5 symbology L3 length. Use L1, L2
and L3 to compose acceptable bar code lengths
depending on the length mode used. Minimum length
for Interleaved 2 of 5 is 4 characters.

Bar code length = <bar code data>

barcode.symbology.
interleaved2of5.
readingRange

(1D only)

0 or 1

1

The Interleaved 2 of 5 symbology reading range.
Reading range can be set to standard or extended. Use
extended reading range when long distance reading is
important for your application. When using this mode a
special algorithm is used and reading distances are
significantly increased.

The supported values are:

• 0 = normal

• 1 = extended

barcode.symbology.
interleaved2of5.
readingTolerance

0 to 2

0

The Interleaved 2 of 5 symbology reading tolerance. Set
the tolerance level for reading hard to read bar codes:

• High - most permissive (reads codes of variable
quality)

• Medium - medium permissiveness

• Low - least permissive (reads only high quality codes

including · quiet zone verification)

Quiet zone is the white space before and after a bar
code to ensure correct decoding.

The support values are:

• 0 = high

• 1 = medium

• 2 = low

Micro PDF 417

(2D only)

1725-86973-000_C.docx
June 2014 37

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Micro PDF 417
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
micropdf417.
enabled

0 or 1

1

A flag to determine whether or not the Micro PDF417
symbology is enabled.

Micro PDF417 is closely based on PDF417 but is more
space efficient. It is used for applications that do not
require the full data capacity of PDF417.

barcode.symbology.
micropdf417.
code128Emulation

0 or 1

0

When Micro PDF417 Code 128 Emulation is enabled
and reading a Micro PDF417 code containing a special
flag, the scanner transmits the Code 128 AIM
identifier instead of the Micro PDF417 identifier ( ]C
instead of ]L ).

The supported values are:

• 0 = disable emulation

• 1 = enable emulation

MSI Code
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
msi.
enabled

0 or 1

1

A flag to determine whether or not the MSI Code
symbology is enabled.

MSI Code is a bar code symbology and a modified
version of Plessey Code. This code is fixed, continuous,
and non-self-checking. It is often used to mark retail
shelves for inventory reordering. The character set is 0

- 9 plus additional symbols.

barcode.symbology.
msi.
checkDigitTransmission

0 or 1

1

A flag to determine whether or not the check digit is
transmitted for MSI code.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted.

barcode.symbology.
msi.
checkDigitVerification

1 to 2

1

There are two types of check digit verification for MSI
Code:

• Modulo 10

Check digit usually used for MSI Code that applies the
Modulo 10 algorithm.

• Double Modulo 10

The "Double Modulo 10" method essentially means
the MSI bar code has two Modulo 10 checksum digits.

The supported values are:

• 1 = modulo 10

MSI Code

1725-86973-000_C.docx
June 2014 38

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

MSI Code
Parameter

Permitted Values

Default

Interpretation

• 2 = double modulo 10

barcode.symbology.
msi.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length.

barcode.symbology.
msi.
lengthL1

0 to 255

6

The MSI Code symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for MSI Code is 3 characters.

Bar code length = <bar code data>

barcode.symbology.
msi.
lengthL2

0 to 255

0

The MSI Code symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for MSI Code is 3 characters.

Bar code length = <bar code data>

barcode.symbology.
msi.
lengthL3

0 to 255

0

The MSI Code symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for MSI Code is 3 characters.

Bar code length = <bar code data>

1725-86973-000_C.docx
June 2014 39

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

PDF 417
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
pdf417.
enabled

0 or 1

1

A flag to determine whether or not the PDF417
symbology is enabled.

Macro PDF417, a feature of PDF417, extends the
capability of PDF417 by allowing up to 99,999 PDF417
symbols to be used to store data. This requires the use
of more than one PDF417 bar code.

barcode.symbology.
pdf417.
addresseeTransmission

0 or 1

0

A flag to determine whether or not the PDF417
addressee is transmitted.

barcode.symbology.
pdf417.
checksumTransmission

0 or 1

0

A flag to determine whether or not the PDF417
checksum is transmitted.

barcode.symbology.
pdf417.
fileNameTransmission

0 or 1

0

A flag to determine whether or not the PDF417
filename is transmitted.

barcode.symbology.
pdf417.
fileSizeTransmission

0 or 1

0

A flag to determine whether or not the PDF417 file
size is transmitted.

barcode.symbology.
pdf417.
segmentCount Transmission

0 or 1

0

A flag to determine whether or not the PDF417
segment count is transmitted.

barcode.symbology.
pdf417.
senderTransmission

0 or 1

0

A flag to determine whether or not the PDF417 sender
is transmitted.

barcode.symbology.
pdf417.
timestampTransmission

0 or 1

0

A flag to determine whether or not the PDF417 time
stamp is transmitted.

Plessey Code
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
plessey.
enabled

0 or 1

1

A flag to determine whether or not the Plessey Code
symbology is enabled.

Plessey Code is a variable length, numerical symbology
based on a four bit binary number scheme. This pulse-

PDF 417

(2D only)

Plessey Code

1725-86973-000_C.docx
June 2014 40

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Plessey Code
Parameter

Permitted Values

Default

Interpretation

width modulated bar code is commonly used for shelf
marking in grocery stores.

barcode.symbology.
plessey.
checkDigitTransmission

0 or 1

0

A flag to determine whether or not the check digit is
transmitted for Plessey code.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted.

barcode.symbology.
plessey.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length.

barcode.symbology.
plessey.
lengthL1

0 to 255

0

The Plessey Code symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for Plessey Code is 3 characters.

Bar code length = <bar code data>

barcode.symbology.
plessey.
lengthL2

0 to 255

0

The PlesseyCode symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for Plessey Code is 3 characters.

Bar code length = <bar code data>

barcode.symbology.
plessey.
lengthL3

0 to 255

0

The Plessey Code symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used.
Minimum length for Plessey Code is 3 characters.

Bar code length = <bar code data>

1725-86973-000_C.docx
June 2014 41

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

QR Code
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
qr2.
enabled

0 or 1

1

A flag to determine whether or not the QR Code
symbology is enabled.

QR Code is a matrix symbology consisting of a square
array of modules with a finder pattern located at three
corners. A wide range of symbol sizes is supported
along with four levels of error correction, and the
symbology is noted for its high data density.

QR code decoding is only supported on the Spectralink
8452/8453 wireless handset.

Standard 2 of 5
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
standard2of5.
enabled

0 or 1

1

A flag to determine whether or not the Standard 2 or 5
symbology is enabled.

Standard 2 of 5 is a low-density numerical symbology
encoding all information in the width of the bars. This
symbology is also referred to as "Straight 2 of 5" and
"Industrial 2 of 5".

barcode.symbology.
standard2of5.
checkDigit Transmission

0 or 1

0

A flag to determine whether or not the check digit is
transmitted.

The supported values are:

• 0 = check digit not transmitted

• 1 = check digit transmitted

barcode.symbology.
standard2of5.
checkDigitVerification

0 or 1

0

A flag to select whether to verify it using a Modulo 10
algorithm or not to verify it. The supported values are:

• 0 = disable

• 1 = modulo 10

barcode.symbology.
standard2of5.
format

0 or 1

0

The Standard 2 of 5 format. The supported formats are:

• 0 = Identicon (6 start/stop bars)

• 1 = Computer Identics (4 start/stop bars)

Note: If setting the format to Computer Identics
format, Spectralink recommends disabling Interleaved
2 of 5 symbology (risks of misreading between both
symbologies).

QR Code

(2D only)

Standard 2 of 5

1725-86973-000_C.docx
June 2014 42

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Standard 2 of 5
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
standard2of5.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length.

barcode.symbology.
standard2of5.
lengthL1

0 to 255

0

The Standard 2 of 5 symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used. The
minimum length for Standard 2 of 5 is 3 characters.

Bar code length = <bar code data>

barcode.symbology.
standard2of5.
lengthL2

0 to 255

0

The Standard 2 of 5 symbology L2 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used. The
minimum length for Standard 2 of 5 is 3 characters.

Bar code length = <bar code data>

barcode.symbology.
standard2of5.
lengthL3

0 to 255

0

The Standard 2 of 5 symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used. The
minimum length for Standard 2 of 5 is 3 characters.

Bar code length = <bar code data>

Telepen
Parameter

Permitted Values

Default

Interpretation

barcode.symbology.
telepen.
enabled

0 or 1

1

A flag to determine whether or not the Telepen
symbology is enabled. Telepen is an alphanumeric full

Telepen

1725-86973-000_C.docx
June 2014 43

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Telepen
Parameter

Permitted Values

Default

Interpretation

ASCII symbology with a defined letter case. It supports
both ASCII and numeric formats.

barcode.symbology.
telepen.
format

0 or 1

0

Telepen supports two formats, ASCII and numeric.

The Telepen numeric format is used for data
compression and is encoded as follows:

• start, stop and check digit remain unchanged

• ASCII characters between 0 and 16 remain unchanged

• characters from 17 to 26 take values from

'0X' to '9X'

• values over 26 are obtained by subtracting

27 from their ASCII value

The supported values are:

• 0 = ASCII

• 1 = numeric

barcode.symbology.
telepen.
lengthMode

0 to 2

0

Length 1 (L1), Length 2 (L2) and Length 3 (L3) are used
differently depending on the length mode. There are
three length modes:

• L1 as minimum length

Codes with as many characters as specified by L1 and
longer are read. L2 and L3 are not used.

• L1, L2, and L3 as three fixed lengths

Only codes that comply with the lengths specified by
L1, L2 and L3 will be read.

• L1 as minimum length, L2 as maximum length

Codes that are at least the minimum length specified
by L1 and not longer than the maximum length
specified by L2 are read. L3 is not used.

The supported values are:

• 0 = L1 as minimum length

• 1 = L1, L2, L3 as fixed lengths

• 2 = L1 as minimum length, L2 as maximum length.

barcode.symbology.
telepen.
lengthL1

0 to 255

0

The Telepen symbology L1 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used. Minimum
length for MSI Code is 3 characters.

Bar code length = <bar code data> + [check digit]

barcode.symbology.
telepen.
lengthL2

0 to 255

0

The Telepen symbology L2 length.

1725-86973-000_C.docx
June 2014 44

Spectralink 84-Series Wireless Telephones Barcode Administration Guide

Telepen
Parameter

Permitted Values

Default

Interpretation

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used. Minimum
length for MSI Code is 3 characters.

Bar code length = <bar code data> + [check digit]

barcode.symbology.
telepen.
lengthL3

0 to 255

0

The Telepen symbology L3 length.

Use L1, L2 and L3 to compose acceptable bar code
lengths depending on the length mode used. Minimum
length for MSI Code is 3 characters.

Bar code length = <bar code data> + [check digit]

1725-86973-000_C.docx
June 2014 45
