Spear & Jackson S1733EH, S1836EH, MEH1735AE User Manual

Hover Mower
ORIGINAL
INSTRUCTION
MANUAL
S1836EH S1733EH MEH1735AE
Important - Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from your mower, ensuring it is assembled correctly and safely. If you need help or have damaged or missing parts, call the Customer Helpline on 0345 605 2068
0345 605 2068
SPEAR & JACKSON SINCE 1760
For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools.
Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage.
Each product is carefully designed with performance,comfort and durability rmly in mind,which has earned Spear & Jackson an enviable reputation as a maker of tools to trust.
3 YEARS GUARANTEE
As a testament to the quality of our products, we offer a 3 year manufacturers warranty and a comprehensive after sales service.
The warranty covers manufacturing faults, however in the event that the item has been deliberately damaged, used in a commercial environment or disassembled then the warranty will be null and void.
Please retain proof of purchase.
7 DAYS A WEEK TECHNICAL SUPPORT
We want you to get the best out of your products. Our easy-to-read instruction manual guides you with best practice use and maintenance tips. Please call 0345 605 2068 for technical support, we can solve around 80% of questions directly over the phone.
We hope you enjoy your product and we look forward to any feedback, as this allows us to develop even better products for the future.
AFTER SALES HELPLINE 0345 605 20682
CONTENTS
Safety Information ..................................................................................................................... 4
Intended Purpose ............................................................................................................................. 4
Warning Symbols ............................................................................................................................... 4
Work Area Safety ............................................................................................................................... 5
Electrical Safety ................................................................................................................................. 6
Power Tool Use and Care .................................................................................................................. 7
Personal Safety .................................................................................................................................. 7
Operating Safety ................................................................................................................................ 9
Maintenance and Storage Safety .................................................................................................... 13
Intended Use .................................................................................................................................... 13
In the Box ........................................................................................................................................ 14
Parts ................................................................................................................................................. 14
Assemble ................................................................................................................................... 17
Prepare ...................................................................................................................................... 18
Operate ...................................................................................................................................... 19
Maintenance ............................................................................................................................. 22
Technical Data .......................................................................................................................... 24
Troubleshooting ........................................................................................................................ 25
Warranty .................................................................................................................................... 26
AFTER SALES HELPLINE 0345 605 2068 3
SAFETY INFORMATION
INTENDED PURPOSE
The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembly and operating the hover.
WARNING SYMBOLS
Before any use, refer to the corresponding paragraphin the present manual.
This symbol, before a safety comment, indicates a precaution, a warning or a danger. Ignoring this warning can lead to an accident for yourself or for others. To limit the risk of injury, fire, or electrocution always apply the recommendations indicated.
There is a risk that some objects could be thrown out by the shredder.
Keep bystanders away. before leaving the product unattended for any period.
Double insulation.
Keep supply flexible cord away form cutting means.
Guaranteed sound power level value in 96 dB.
Wear hearing protection
Wear eye protection
Wear protective gloves
Do not expose and operate the product to rain or wet conditions.
Remove the plug from the mains immediately if cable is damaged or cut.
AFTER SALES HELPLINE 0345 605 20684
The product complies with the applicable European directives and an evaluation method of conformity for these directives was done.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
SAFETY INFORMATION
GENERAL SAFETY
IMPORTANT!
• Keep this instruction manual in a safe place for future reference.
• Read the instructions carefully. Be familiar with the controls and the proper use of the equipment.
• Never allow children or people unfamiliar with these instructions to use this Hover. Local regulations can restrict the age of the operator.
• Never use the machine while
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
• Don’t use the appliance without reading the instruction sheet.
• Children should be supervised to ensure that they do not play with the appliance.
WORK AREA SAFETY
people, especially children, or pets are nearby. Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people or their property.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
• Inspect the area where the machine is to be used and remove all objects which can be thrown by the machine. If objects are hidden while operating stop the motor and remove them.
• Do not operate the machine in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
AFTER SALES HELPLINE 0345 605 2068 5
SAFETY INFORMATION
GENERAL SAFETY
ELECTRICAL SAFETY
• The plug must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power shall not play with the appliance. Cleaning and user maintenance tools. Unmodified plugs and matching outlets will reduce the risk of electric shock.
• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. The maximum operating current of the RCD must be less than 30mA.
• The voltage indicated on the rating plate must correspond to the voltage of the power source.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
• When operating a power
• Only use or replace power supply cables for this unit which correspond to the types indicated by the manufacturer. See the operating instructions for the order no. and types.
• Never touch the mains plug with wet hands.
• Do not run over, crush or pull the power supply cable or extension lead, otherwise it may be damaged. Protect the cable from heat, oil and sharp edges.
AFTER SALES HELPLINE 0345 605 20686
SAFETY INFORMATION
• The extension lead must have a cross section in accordance with the operating instructions and be protected against splashed water. The connection must not be in water.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and more safely when operated at the rate for which it was designed.
the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to
• Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
• Maintain power tools. Check
be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
for misalignment or binding of moving parts, breakage of parts and any other condition that may affect
AFTER SALES HELPLINE 0345 605 2068 7
SAFETY INFORMATION
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating the machine. Do not use the machine while you are tired or under the influence of drugs, alcohol or medication.
• Use personal protective equipment such as dusk masks and non-skid safety shoes. Always wear eye protection.
• Prevent unintentional starting. Ensure the switch is in the off -position before
gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
• Warning! Switch off, remove plug from mains before adjusting, cleaning or if cable is cut, damaged or
connecting to power source, picking up or carrying the tool.
• Do not carry the machine with your finger on the switch .
• Remove any adjusting key or wrench before turning the machine on. A wrench or a key left attached to a rotating part of the machine may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times.
entangled.
• The blades continue to rotate for a few seconds after the machine is switched off.
• The operating voltage is 220-240V~, 50Hz. If you want to use an extension cable should not be lighter than:
- if rubber insulated, or ordinary tough rubber sheathed flexible cord
-if polyvinyl chloride insulated, ordinar polyvinyl chloride sheathed flexible
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
AFTER SALES HELPLINE 0345 605 20688
cord (code designation H05 VVF) and the following cable dimensions should be used:
SAFETY INFORMATION
OPERATING SAFETY
• 1.0mm²: max. length 40m
• 1.5 mm²: max. length 60m
• 2.5 mm²: max. length 100m
Note: If an extension cable
is used it must be earthed and connected through the plug to the earth cable of your supply network in accordance with prescribed safety regulations.
• If in doubt contact a qualified electrician or call the after sales support.
• WARNING! Inadequate extension cables can be
TRAINING
• Read the instructions carefully. Be familiar with the controls and the proper use of the machine.
• Never allow people unfamiliar with these instructions or children to use the product. Local regulations can restrict the age of the operator.
• Never use the machine while people, especially children, or pets are nearby. Keep in mind that the operator
dangerous. Extension cable, plug and socket must be of watertight construction and intended for outdoor use.
• It is recommended for increased electrical safety to use a Residual Current Device (RCD) with a tripping current of not more than 30mA. Always check your RCD every time you use it.
or user is responsible for accidents or hazards occurring to other people or their property.
PREPARATION
• While operating the machine always wear substantial footwear and long trousers. Do not operate the machine when barefoot or wearing open sandals. Avoid wearing clothing that is loose fitting or that has hanging cords or ties.
• Thoroughly inspect the area
AFTER SALES HELPLINE 03456 052 068
where the machine is to be used and remove all objects which can be thrown by the machine.
AFTER SALES HELPLINE 0345 605 2068 9
SAFETY INFORMATION
• Before using, always visually inspect to see that the blade, blade bolt and the blade assembly are not worn or damaged. Replace worn or damaged components in sets to preserve balance. Replace damaged or unreadable labels.
• Before use check the supply and extension cord for signs of damage or aging. If the cord becomes damaged during use, disconnect the cord from the supply immediately.
OPERATION
• Before use check the controls and correct operation of the product.
• Before using the product or after any impact, check for signs of wear or damage and repair as necessary.
• Always disconnect the product from the power supply (i.e. remove the plug from the power supply)
– Whenever leaving the
product unattended;
– Before clearing a
blockage;
– Before checking, cleaning
or working on the product
• Operate the machine only in daylight or in good artificial light. Do not expose the product to rain or wet conditions. Avoid using the product in bad weather conditions especially when there is a risk of lightning.
• Never operate the machine with defective guards or shields, or without safety devices, for example deflectors and/or grass collector, in place.
• Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.
– After striking a foreign
object;
– Whenever the product
starts vibrating abnormally.
• Always ensure that the air vents are kept clear of debris.
• Never use replacement parts or accessories not provided or recommended by the manufacturer.
• Position the cord so that it will not be caught by the cutting attachment during operation.
• Disconnect from the power supply when the cord
AFTER SALES HELPLINE 0345 605 206810
SAFETY INFORMATION
becomes damaged or tangled.
• Do not use the product if the cord is damaged or worn.
• Warning! The cutting blade may continue to move after the product is switched off.
• Keep the extension cord away from the blades at all times.
• Always be sure of your footing on slopes.
• Walk, never run.
• Mow across the face of slopes, never up and down.
• Exercise extreme caution when changing direction on slopes.
• Do not mow excessively steep slopes.
devices, for example deflectors and/or grass collector, in place.
• Switch on the motor carefully according to instructions and with feet well away from the blade(s).
• Do not tilt the machine when switching on the motor, except if the machine has to be tilted for starting. In this case, do not tilt it more than absolutely necessary and lift only the part, which is away from the operator.
• Do not start the machine when standing in front of the discharge opening.
• Do not transport the machine while the cutting blade is running. Make sure that all moving parts have
• Use extreme caution when reversing or pulling the machine towards you.
• Stop the blade(s) if the machine has to be tilted for transportation when crossing surfaces other than grass, and when transporting the machine to and from the area to be used.
• Never operate the machine with defective guards or shields, or without safety
come to a complete stop.
• Whenever you leave the machine,
• Before clearing blockages or unclogging chute,
• Before checking, cleaning or working on the machine,
• After striking a foreign object. Inspect the machine for damage and make repairs before restarting and operating the machine.
AFTER SALES HELPLINE 0345 605 2068 11
SAFETY INFORMATION
• If the machine starts to vibrate abnormally (check immediately),
• inspect for damage,
• replace or repair any damaged parts,
• check for and tighten any loose parts.
EMERGENCY
• WARNING! Familiarize yourself with the use of this machine by means of this instruction manual. Memorise the safety directions and follow them to the letter. This will help to prevent risks and hazards.
safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this machine:
• Health defects resulting from vibration emission if the machine is being used over long periods of time or not adequately managed and properly maintained.
• Injuries and damage to property due to broken application tools or sudden impact of hidden objects during use.
• Always be alert when using the machine, so that you can recognize and handle risks early. Fast intervention can prevent serious injury and damage to property.
• Switch off and disconnect from the power supply if there is any malfunction. Have the machine checked by a qualified specialist and repaired, if necessary before you put it into operation again.
RESIDUAL RISKS
• WARNING! This machine produces an electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their doctor and medical implant manufacturer before operating this product!
• WARNING! Even if you are operating the machine in accordance with all
AFTER SALES HELPLINE 0345 605 206812
SAFETY INFORMATION
MAINTENANCE AND STORAGE SAFETY
• Keep all nuts, bolts and screws tight to be sure the machine is in safe working condition.
• Check the grass collector frequently for wear or deterioration.
• On machines with multi blades, take care as rotating one blade can cause other blades to rotate.
• Be careful during adjustment of the machine to prevent entrapment of the fingers between moving blades and fixed parts of the machine.
• Always allow the machine to cool down before storing.
• When servicing the blades be aware that, even though the power source is switched off, the blades can still be moved.
• Replace worn or damaged parts for safety. Use only genuine replacement parts and accessories.
relevant safety regulations. To avoid danger, equipment must only be repaired by qualified technicians.
• Only use parts and ccessories made for this machine by the manufacturer. Failure to do so can result in personal injury.
INTENDED USE
This Hover is designed for domestic use only:
• This electric Hover is intended for mowing lawns in domestic and hobby gardens.
• This product is not to be used in wet weather conditions and may not be used to mow wet or unusually high grass, e. g. pasture grass or for shredding leaves.
• This product is intended for private domestic use only, not for any commercial trade use. It must not be used for any purposes other than
SERVICE
Have your machine repaired by an authorized service agent. This
machine is manufactured in accordance with the
those described. Any use of the machine that deviates from its intended use and is not included in these.
AFTER SALES HELPLINE 0345 605 2068 13
IN THE BOX
PARTS 7367416 (S1836EH )
1 Switch box
2
on/off switch lever
3
Upper handle
4
Quick release lever
5
Lower handle
9
6
Grass box
7
Safety lock-off
button
8
Cable strain relief
hook
9
Cable clamp
10
Spanner
11
Grassbox lid
14
Mulch mode
selection switch(on the box)
12
Deck
13
Screw*2
15
Spacer*3 (one piece is pre-assembled)
16
Wheel
8
7
1
2
3
10
11
16
4
5
6
13
12
14
15
AFTER SALES HELPLINE 0345 605 206814
IN THE BOX
PARTS 7454154 (S1733EH)
1 Switch box
2
On/off switch lever
3
Upper handle
4
Quick release lever
5
Lower handle
9
6
Grass box
7
Safety lock-off
button
8
Cable strain relief
hook
9
Cable clamp
10
Spanner
14
Spacer*3 (one
piece is pre­assembled)
11
Grassbox lid
12
Deck
13
Screw*2
8
7
1
15
Mulch plug
16
Wheel
2
3
10
11
4
5
6
13
12
16
15
14
AFTER SALES HELPLINE 0345 605 2068 15
IN THE BOX
PARTS 7498103 (MEH1735AE)
1
Switch box
2
on/off switch lever
3
Upper handle
4
Quick release lever
5
Lower handle
9
6
Grass box
7
Safety lock-off
button
8
Cable strain relief
hook
9
Cable clamp
16
10
Spanner
11
Grassbox lid
12
Deck
13
Screw*2
14
mulch mode
switch(on the box)
15
switchSpacer*3
(one piece is pre­assembled)
16
Detachable cable
17
Wheel
exchange
8
7
1
2
3
10
11
17
4
5
6
13
12
14
15
AFTER SALES HELPLINE 0345 605 206816
ASSEMBLY
Unpacking
1
i. Unpack all parts and lay them on a flat, stable surface.
ii. Remove all packing materials and shipping devices if
applicable.
iii. Make sure the delivery contents are complete and free of
any damage. If you find that parts are missing or show damage do not use the product but contact the aftersales helpline within 28 days of purchase. Using an incomplete or damaged product represents a hazard to people and property.
iv. Ensure that you have all the accessories and tools needed
for assembly and operation. This also includes suitable personal protective equipment.
Fix the Lower handle
2
Fully insert the lower handle into the slot on the deck.
Fasten in position with the 2 screws provided.
Fix the upper handle
3
Attach the upper handle to the lower handle tubes using bolts and wingknobs.
Once fitted correctly the upper handles should still move up and down. this freedom of movement allows the hover mower to float correctly on the uneven surfaces of a lawn. Do not over tighten these wingknobs.
The spanner could be easily fixed on the machine like below way
Fix the cable
4
Ensure that the cables clied are used to fix the cable to the handle.
AFTER SALES HELPLINE 0345 605 2068 17
PREPARE
Connection to the power supply
5
i. Hook the mains cable through the cable strain-release to
reduce the strain on the cable fitting as you mow.
ii. Connect the plug to the main socket.
Setting the cutting height
Remove the blade bolt, add the spacer to your suitable cut­ting height.
Cutting position Cutting height
1 (Non-spacer) 33mm 2 (1 spacer, pre-assemble) 26mm 3 (2 Spacers) 19mm 4 (3 spacers) 12mm
AFTER SALES HELPLINE 0345 605 206818
OPERATE
Mowing tips
i. Verify that the lawn is free of stones, sticks, wires ,and other
objects that could damage the hover.
ii. When cutting thick grass, reduce walking speed in order to
allow for a more effective cut and a proper discharge of the clippings.
iii. Never cut off more than one-third of the total length of the
grass for a healthy lawn. If it is roughly 6cm long, the grass should not be shorter than 4cm once mowed. If the grass is higher, you should gradually cut it down to the desired length so as not to damage the grass.
iv. Do not cut wet grass because it tends to stick to the un-
derbody of the hover, preventing the proper discharge of grass clippings.
33 mm
26 mm
19 mm
12 mm
Blade Maintenance
Always switch the product off, disconnect it from power sup-
ply and let the product cool
down before performing inspection, maintenance and clean-
ing work!
Removing the blade and fan. USE GLOVES.
• To remove the blade bolt with the spanner
10
• Remove the blade bolt
21
impeller
.
18
, hold the blade 19 firmly and
provided loosen the blade bolt 18 .
18
, blade 19 , spacer 20 and
Inspect for damage and clean as necessary.
Renew your metal blade after 50 hours mowing or 2 years whichever is the sooner-regardless of condition. If the blade is cracked or damaged replace it with a new one. Never use a blade bolt if the insulated head is damaged cracked or missing.
Fitting the blade and impeller. USE GLOVES.
18
19
20
21
• Ensure the impeller 21 is located correctly.
• Place the spacers 20 onto the fan ensuring the pegs have located into the holes
• Ensure the pegs have located into the holes on the blade and that the blade is positioned as illustrated in figure 6.
• Place the blade bolt 18 through the centre hole of the blade.
• Tighten down clockwise by hand.
• Hold the blade 19 firmly and tighten the blade bolt with the spanner provided.
AFTER SALES HELPLINE 0345 605 2068 19
OPERATE
IMPORTANT! Ensure the power cord is disconnected
from the mains supply and wait until the cutting head has stopped rotating before adjusting the cutting height.
18
• There are 4 different cutting heights. Figure 7 shows the lowest cutting height, 3 spacers. Figure 8 shows the highest cutting height, no spacers. Adding spacers reduces the cutting height, removing spacers increases cutting height
• Disconnect from the main electricity supply and wait
21
until impeller
and the blade bolt 18 have stopped
rotating.
• Turn your product upside down.
• To remove the blade
20
ers spacers
, use the spanner 10 to remove blade bolt 18. The
20
and blade 19 can now be removed and the
19
and adjust the number of spac-
number of spacers adjusted.
• Spacers that are not being used can be stored on the spanner to prevent loss.
• Refit the blade as described in Blade Maintenance.
19
19
20
21
18
20
21
When removing a spacer from its storage location on the spanner, gently twist it as you remove it. When you replace a spacer back to this location just push it firmly into position.
AFTER SALES HELPLINE 0345 605 206820
OPERATE
Switching on
i. Press the button (1).
ii. Pull the switch bar (2) towards the handle and hold in posi-
tion.
Switching off
2
I
1
Release the switch bar.
Mowing direction
To avoid cutting the mains cable and to collect grass clippings correctly please mow away from the plug socket following the arrows and avoid twisting the power cord.
O
AFTER SALES HELPLINE 0345 605 2068 21
OPERATE
1
3
2
2
7
6
Mulching operation S1836EH MEH1735AE
Rotate the Mulch Mode Switch,anti-clockwise to select mulch mode and clockwise to return to collect mode.
Mulch mode
Mulching operationS1733EH
Lift up the grass box lid
1
and fit the mulch plug 2
over the grass inlet chute, then put grass lid back in
3
place
.
Emptying the GrassboxS1733EH
• Stop the product and wait until the blade has stopped
rotating before emptying the grassbox
• Lift up the grassbox lid
7
.
• Lift the grassbox 6 off the product and empty.
Failure to fit the grassbox and lid correctly will cause poor collectiong of grass cilppings.
Standard collection mode
AFTER SALES HELPLINE 0345 605 206822
MAINTENANCE
WARNING!
Always switch the product off, disconnect it from the power supply and let the product cool down before performing inspection, maintenance and cleaning work!
i. Keep the underbody and cutting blade clean and free of
debris. Remove clippings from the discharge chute.
ii. Check all nuts and bolts periodically for tightness before
operation. After prolonged use, especially in sandy soil conditions, the cutting blade will become worn and lose some of its original shape. The cutting efficiency will be reduced and the cutting blade should be replaced.
iii. Lubricate the cutting blade after each use to prolong the life
span of the cutting blade and product. Apply light machine oil along the edge of the cutting blade.
Repair
This product does not contain any parts that can be repaired by the consumer. Contact an authorised service centre or a similarly qualified person to have it checked and repaired.
Storage
Switch the product off and disconnect from power supply.
Clean the product as described above.
To reduce storage space, the upper handle can be folded down, unscrew the wing nuts by approximately 6 revolutions.
AFTER SALES HELPLINE 0345 605 2068 23
MAINTENANCE
Transportation
i. Switch the product off and disconnect from power supply.
ii. Protect the product from any heavy impact or strong
vibrations which may occur during transportation in vehicles.
iii. Secure the product to prevent it from slipping or falling over.
Recycling and disposal
• The product comes in a package that protects it against damage during shipping. Keep the packaging until you are sure that all parts have been delivered and the product is functioning properly. Recycle the packaging afterwards.
• Old products are potentially recyclable and do not, therefore, belong in your household rubbish. You are requested to assist us and our contribution to saving resources and protecting the environment by handing in this product at an equipped collection centre (if there is one available).
AFTER SALES HELPLINE 0345 605 206824
TECHNICAL DATA
Model 7367416(S1836EH) 7454154(S1733EH) 7498103(MEH1735AE)
Voltage
Power Input
Cutting Speed
Cutting Width
220-240V~ 50Hz 240V~50Hz
1800W 1700W
4200/min
36cm 33cm
220-240V~ 50Hz
1700W
35cm
Cutting height adjustment 12,19,26,33mm 4 Levels
Volume of Grass collector
Sound emssion level 76dB(A) K=3dB(A)
L
PA
Sound Power level 96dB(A)
L
WA
Vibration
Protection Class
26L 20L
≤2,5m/s2 ≤2,5m/s2
II
26L
≤2,5m/s2
PARTS 7498103 (MEH1735AE)
Part numbe: 7367416 (SJ1836EH) ACCESSORIES
111019107 Blade
111229110 Wing knobs
111019106 Blade Spacer
Part numbe: 7454154 (S1733EH) ACCESSORIES
111049104 Blade
111229110 Wing knobs
111019106 Blade Spacer
Part numbe: 7498103 (MEH1735AE) ACCESSORIES
111019107 Blade
111229110 Wing knobs
111019106 Blade Spacer
AFTER SALES HELPLINE 0345 605 2068 25
TECHNICAL DATA
The sound values have been determined according to noise test code given in EN 60335-2-77, using the basic standards EN ISO 11201 and EN ISO 3744. The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are necessary.
The declared vibration value has been measured in accordance with a standard test method (according to EN 60335-2-77) and may be used for comparing one product with another. The declared vibration value may also be used in a preliminary assessment of exposure.
WARNING! Depending on the actual use of the product the vibration values can differ from the declared total! Adopt proper measures to protect yourself against vibration exposures! Take the whole work process including times the product is running under no load or switched off into consideration!
Proper measures include among others regular maintenance and care of the product and cutting attachments, keeping hands warm, periodical breaks and proper planning
of work processes!
AFTER SALES HELPLINE 0345 605 206826
TROUBLESHOOTING
Suspected malfunctions are often due to causes that the user can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly.
WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself!
Gloves and appropriate protective clothing must be worn when performing these instructions.
Fault Possible Cause Solution
Hover does not start No power at mains socket Check the fuse, switch,
socket, cable, wire and have any repairs carried out by a
qualified electrician. Defective on/off switch Repair by a qualified technician Defective motor
Poor floatation Impeller is blocked by grass Disconnect from mains
Poor collection
Excessive vibration Blade damaged Replace blade.
Cut height too low Raise the cutting height. Grassbox fitted incorrectly Fit the grassbox correctly. Mowing in side to side
movements
Blade fitted incorrectly Fit the blade correctly.
required.
and clean the deck and the
impeller
The Hover collects at the rear
as users walk forward in straight
lines.
AFTER SALES HELPLINE 0345 605 2068 27
WARRANTY
If your device develops a fault, please don’t hesitate to contact our customer service department on 0345 605 2068, the majority of problems can be solved directly on the phone.
1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights. This product is covered by a 3 year manufacturer warranty.
2. Claims must be accompanied by proof of purchase. This must be in the form of a Sales receipt or bank statement and must show that the product has been purchased within the warranty period as described under point 1, from the retailer that it was originally bought from. Please keep your receipt safe or staple it to the back of this manual for future reference.
3. Our devices have not been designed for commercial, trade or industrial applications, any signs of use of the equipment in these application or equivalent activities, invalidates the warranty.
4. The following are also excluded from our warranty:
A. Faults due to accidents, customer misuse or unauthorized repairs
B. Consumable Parts such as blades, wheels, and other accessories that are compatible with the
product.
C. Failure due to lack of routine maintenance.
D. Failure as a result of not using the equipment in accordance with the manual and safety
instructions.
Warranty claims should be submitted before the end of the warranty period, see point 1. The original warranty period remains applicable to the device even if repairs are carried out or parts are replaced. In such cases, the work performed or parts fitted will not result in an extension of the warranty period, and no new warranty will become active for the work performed or parts fitted.
If you have any problems or questions concerning your garden power tool, please contact our after sales service at 0345 605 2068.
AFTER SALES HELPLINE 0345 605 206828
Loading...
