SF-2000
LEAD FREE
X
Square Wall-Mount AC Sensor Faucet
MODELS:
• SF-2000: Square Wall-Mount AC Sensor Faucet
• SF-2000-TMV: Square Wall-Mount AC Sensor Faucet
w/ Thermostatic Mixing Valve
FEATURES:
• Brass construction with polished chrome finish
• Sensor eye near outlet of faucet
• Plug-in AC powered (plug included)
• Wall mount spout
• 60 second flow time out feature
• 9/16”-24 UNF supply connection
• Vandal-resistant 0.5 GPM (1.89 L/min) flow control
OPTION:
• TMV: Thermostatic Mixing Valve (A-TMV)
STANDARDS:
• ASME A112.18.1/CSA B125.1 certified
• NSF/ANSI 61 certified
• NSF/ANSI 372 certified
WARRANTY:
Visit www.speakman.com for full product warranty information
• Limited Lifetime Warranty (residential)
• 5 Year Limited Warranty (commercial)
11
7
"
120.00°
16
195.39mm
9.87mm
FINISHED WALL
FOR PLUMBING ROUGH-IN
PLEASE REFER TO
INSTALATION MANUAL
3
"
8
36"
MA
3
2
"
8
60mm
3"
76.20mm
5
3
4
"
2
"
5"
16
8
127mm
110mm
60mm
All dimensions are in inches (millimeters) unless otherwise specified and are subject to change without notice.
Architect/Engineer Approval Space:
1
1
"
4
32mm
P:
800-537-2107
F:
80 0-97 7-2747
W:
WWW.SPEAKMAN.COM
R:
02-NOVEMBER 2019
