S-1498-LH
Sentinel Mark II® Anti-Scald Balanced Pressure Exposed Shower
FEATURES:
• Brass body construction
• (2) 1/2” -14 NPTF inlets
• Pressure balancing & ceramic temperature regulating
cartridge with built-in check valves
• Brass lever handle
• Adjustable temperature limit stop to control maximum
temperature setting
• Supports back-to-back installation
• Vandal-resistant
• Shower head not included
• Polished stainless steel rain shower with 15-1/2” arm and
supporting strap
SHOWER ADD-ONS:
• S-2762: Neo Rain Shower Head
• S-2763: Kubos Rain Shower Head
STANDARDS:
• ASSE 1016 certified
• ASME A112.18.1/CSA B125.1 certified
WARRANTY:
Visit www.speakman.com for full product warranty information
• 5 Year Limited Warranty (commercial)
• 5 Year Limited Warranty (residential)
4
16
106mm
32
815mm
1
15
"
2
394mm
3
"
1
"
16
PIPE STRAP W/SCREWS
(LOCATION OPTIONAL)
4'-6"
[1.37 METERS]
TO FLOOR
All dimensions are in inches (millimeters) unless otherwise specified and are subject to change without notice.
Architect/Engineer Approval Space:
SPEAKMAN
400 ANCHOR MILL ROAD
NEW CASTLE, DE 19720
Management Systems Registered to ISO 9001
1in
25mm
146mm
3
5
"
4
P:
800-537-2107
F:
80 0 -97 7-2 747
W:
WWW.SPEAKMAN.COM
R:
01-JUNE 2018
