MODEL : STm.57b
MOBILE PRINTER
Rev. 1.0
All specifications are subject to change without notice
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTION
Table of Contents
1.
Unpacking
2. Product overview 3
3. Installation & Usage 4
3-1. Control Panel Usage 4
3-2. Battery Installation 5
3-3. Battery removel 6
3-4. Battery Charging 7
3-5. Battery Charger Usage 8
3-6. Usage of Cigar Jack for charging 9
3-7. Belt clip usage 10
3-8. Roll Paper Installation 11
3-9. Leather case Usage 12
3-10. Shoulder Strap Usage 13
3-11. Self Test 14
4. Peripherals Connection 17
4-1. Bluetooth connectiontion 17
4-2. Interface Cable Connection 18
5. Printer Cleaning 19
6. Product Specification 20
6-1. Specification 20
7. CPCL Command Compatibilit
y
2
22
1
1. Unpacking
2. Product overview
Standard
Printer Battery
Recharger
Roll paper
Optional
USB Shelded Cable
CD
Front
Power switch
Belt Buckle
Serial Cable
Quick Manual
Paper feed
button
Side
Cover open
button
Charger
Connector
Battery
2
Battery Holder
(Cradle)
Cigar jack
Printer case
shoulder strap
USB
SERIAL
3
3. Setting Up the Product
3-1. Control Panel Usage
Button Name function
Power
button
Paper
Feed
Button
Battery
Status
Lamp
Error
Lamp
This button is used to turn the printer on and off.
When the printer is off, press this button for approximately
2 seconds and it will turn on the power. When you press this button
in a state that the printer is on, the printer will turn off.
Paper output can be done manually by pressing this button.
Additionally, self-testing and Hexadecimal Dumping can be processed..
1. Refer to “3-10” for self test information.
2. Refer to the service manual regarding Hexadecimal Dumping.
1. If the Batt, LED are Lit, the battery is fully charged.
2. If you can hear beeping sound and LED light is turned off, it means
that the battery is at the lowest level.
3. If the battery is not charged at all, the printer turns off automatically.
If the red light is turned on, it means that the paper cover is open.
3-2. Installing battery
Push the Open to the direction as
pointed by arrow in the image.
Insert the battery inside printer as
shown.
Open the battery cover and push up
the hook to the direction as above.
1 2
3
Close the battery cover once you
inserted the battery completely.
NOTE
As the battery is not charged at the time of your purchase, charge the battery
prior to using the product.
(Use the battery charger and/or the optional battery holder.)
4
5
3-3. Battery removel
3-4. Battery Charging
②
LED
①
Push the Open into the direction
indicated with the arrow in the image.
6
Push up the hook after opening the
battery cover.
1 2
3
Pull out the battery as shown above.
1. The battery can be charged only when the temperature is 0~40℃
2. Be sure that the printer is turn off and the battery to be charged is installed.
3. Connect the charger to the printer.
4. Recharging will now be started.
3-4-1 The status of lamp in charging
Status charging charging complete
Charging Lamp
NOTE
1. Unless the exclusive charger is used provided by the manufacturer, the printer
can be damaged, and the manufacturer is not liable for the consequential damage.
2. Before removing the battery, make sure that power is turned off.
3. Printer does not work in the status of being connected with charger only.
4. The battery should be installed to operate printer.
5. While charging, do not turn on the power.
6. Do not operate the print while charging the battery.
7. Do not connect the charger while the printer is operated.
Red
Green
7
3-5. Battery charger Usage
Optional
②
LED
①
1. Please press the battery into the holder until you can hear a snapping sound.
2. Insert DC JACK ① into the end completely as the direct shown above.
3. Plug the power code to electrical outlet.
4. While charging the battery, red light turns on.
Once the charge is completed, green light turns on.
Check the state of code connection when error occurs blinking on red light.
3-5-1 The status of lamp in charging
Status charging charging complete
Charging Lamp
NOTE
In the case the battery is not fixed properly in the holder, the red lamp will be blinking,
Then, extract and reinsert the battery.
Red
Green
3-6 Usage of Cigar Jack Charger for charging
Optional
Printer
Battery holder
Connect the car cigar JACK charger into the printer or battery holder.
Input
Output
NOTE
Use the Cigar Jack offered by the manufacturer
12 ~ 24V
8.4V 0.8 ~ 1.2A
.
8
9
3-7. Belt clip Usage
3-8. Roll Paper Installation
10
Insert the belt hook screw into the hole of the belt hook.
1
2
As shown above, fasten the screw with a screw driver.
Open the paper cover pressing the open
button. Insert a sharp tool into the paper
guide hole and push it in the direction of
arrow as shown above.
Pull out a short length of the paper and
shut the paper cover.
Put the paper in the right direction after
adjusting the paper guide matching the paper
width. (Remove the paper core when it is
used all)
1 2
3
4
Press the Feed Key once to arrange
the paper.
11
3-9. Leather Case Usage
Optional
3-10. Shoulder Strap Usage
Optional
12
Open the Velcro
Put the printer into the leather case
following the direction shown in the
image.
1 2
3
Close the Velcro
Insert the strap into the hook on
the printer.
After pulling out the end of strap
tightly, put it into the clip to be
fastened.
Place the end of strap into the hook of
shoulder strap.
1 2
3
4
Fasten the strap in the opposite
side with the sample way.
13
3-11. Self Test
The sample of self test printout
14
Turn off the power pressing the
power button for approximately
3 seconds.
The printout is produced.
While you are pressing the FEED
button, press the power button
1 2
3
NOTE
1. To print ASCII pattern additionally,
press the Feed button once more
2. After printing ASCII pattern, the
self test will be finished automatically.
3. If the Feed button is not pressed
to print ASCII pattern, self test will be
finished automatically after 30 seconds.
15
4. Peripherals Connection
When the printer is installed initially or when you face a problem, you can run the
self test and check the information about
-Control Circuit, Mechanism, Print Quality, ROM Version
After checking with self-test and no issues are found, you can examine other
devices and software. This function is working independent of devices and software.
●
Motor protection from being overheated
The motor should be stopped and cooled about more than 30 seconds after
continuous printing 1.5 meter
This product can communicate with other devices via Bluetooth
communication and cable.
4-1. Bluetooth Connection
1. The Printer can be connected to devices equipped with Bluetooth communication
capacity (PDAs, PCs, etc.)
2. Use the Bluetooth connection function supported by the device to connect
to the printer.
NOTE
Refer to the
Bluetooth
Manual for more details on connection.
16
17
5. Printer cleaning
4-2. Interface Cable Connection
Serial
USB
1. Connect USB or Serial cable into the cable connector on the printer.
NOTE
Use the cable offered by the manufacturer (USB, Serial)
2. Connect the interface cable into the USB or Serial port of the device
(PDA, PC, etc.)
If the interior of the printer is dusty, printing quality can lowered.
In such a case, follow the instructions below to clean up the printer.
NOTE
1. Make sure to turn the printer power off prior to cleaning
2. Regarding print head cleaning, as the print head sets very hot during
printing, turn off the printer power and wait approximately 10 minute before
commencement.
3. When cleaning the print head, take care not to touch the heated portion of the
print head. The print head subject to be damaged by static electricity.
4. Take care not to allow the print head to become scratched and /or
damaged in any way.
1. Use an applicator swab moistened with an alcohol solution to clean the print
head and remove any dusts.
2. Once the cleaning is completed, insert paper roll into the printer few minutes
later and close the printer cover.
18
Preventing Overheating
To prevent the motor from overheating, continuous driving of the printer
should be 1.5 m or less in print length. Set the pause time for 30 seconds
or more after driving the printer.
19
6. Pritner Specification
6-1. Specication
Printing Method Direct Thermal
Printing Speed 80mm/sec
Resolution 203 DPI X 203 DPI
Character ALPHA NUMERIC Character, Extension Character
Barcode Code 39, Code 93, UCC/EAN-128, Code 128,
Emulation CPCL
Driver Window CE 4.2&5.0, Window Mobile 5.0
Sensor Black-mark, Gap, cover open
Paper paper type Thermal Paper
width 58mm
thickness 65㎕
External Diameter Max. Φ 56mm
Internal Diameter 12.5mm +/-0.5mm
Reliability TPH 100km
Battery Continuous Printing 54min
Communications standard Serial(RS-232C), USB, Bluetooth Class2
Battery Charger input AC100~240V, 50/6 Hz
output 8.4V , 800~1400mA
Battery Battery type Li-ion
output 7.4V, 2200mAh
Charging time 3hours 40min
Size WXDXH(mm) 104 X 74 X 154
WXDXH” 4.0 X 2.9 X 6.0
UPC-E, UPC-A, EAN-8, EAN-13, EAN-14, UPC and
EAN 2 or 5 digit extensions, Plessey, FIM, Postnet,
Interleaved 2-of-5, MSI, Codabar
Standby for 19hours
Printing length: 249.8M
Weight 500g
Environmental sealing IP42
Temperature operation 5~40℃
storage -20~60℃
Humidity operation 35 ~ 80%
storage 10 ~ 90%
20
21
7. CPCL Command Compatibility
NOTE
Compatible with only
Compatible
○
Printer Commands
PRINT
FORM
JOURNAL
UNITS
Comments
TEXT
TEXT
FONT-GROUP(FG)
TEXT CONCATENATION
MULTILINE(ML)
COUNT
SETMAG
SCALABLE TEXT
Linear Bar Codes
BARCODE
BARCODE-TEXT
Two-Dimensional Bar Codes
PDF417 (PORTABLE DATA FILE)
MAXICODE
QRCODE
DATAMATRIX
GS1(RSS)
commanders provided
by the manufacturer.
Graphics
Partially
Compatible
●
△
Not
Compatible
x
Compatibility
○
○
○
○
○
Compatibility
○
○
○
○
○
○
X
Compatibility
○
○
Compatibility
○
○
●
●
●
BOX
LINE
INVERSE-LINE
PATTERN
GRAPHICS
PCX
Advanced Commands
CONTRAST
TONE
JUSTIFICATION
PAGE-WIDTH
PACE
NO-PACE
WAIT
REWIND
TENSION
SPEED
SETSP
ON-OUT-OF-PAPER
ON-FEED
PREFEED
POSTFEED
PRESENT-AT
COUNTRY/CODE PAGE
FORMAT FILES
BEEP
CUT
PATIAL-CUT
MCR
Compatibility
○
○
○
○
○
○
Compatibility
○
○
○
○
○
○
○
X
X
○
○
X
○
○
○
X
○
○
○
X
X
●
22
23
Line Print Mode
SETLP
SETLF
Moving With X and Y Coordinates
LMARGIN
SETBOLD
SETSP
Special ASCII Characters
SETFF
SET-TOF
SETLP-TIMEOUT
Compatibility
○
○
○
○
○
○
○
○
○
○
24
