Source Technologies ETC 405, ETC 426, ETC 470, ETC 436, ETC 414 User Manual

CE User Manual

Production Dates: September 2004 - Present

Copyright © 2007 Electronic Theatre Controls, Inc. All Rights reserved.

Product information and specifications subject to change. Part Number: 7060M1210-06.01 Rev A Released: August 2007

T a b l e o f C o n t e n t s

Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Source Four CE guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Basic luminaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Luminaire information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Colour frame holder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Replacing the HPL lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Centering lamp and adjusting the field . . . . . . . . . . . . . . . . . . . .7

Focusing the beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Shaping the beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Rotating the barrel assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Adjusting the yoke position . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Cleaning lens and reflector . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Portable appliance test (PAT) guidelines. . . . . . . . . . . . . . . . . .12

E TC ®, Emphasis®, Expression®, Insight™, Imagine™, Focus™, Express™, Unison ®, Obsession® II, ETCNet2™, EDMX™, Source Four®, Revolution®, Sensor®, and WYSILink™ are either registered trademarks or trademarks of Electronic Theatre Controls, Inc. in the United States and other countries .

All other trademarks, both marked and not marked, are the property of their respective owners.

i

English

Declaration of conformity

We, Electronic Theatre Controls, Europe Ltd. declare under sole responsibility that the product:

Product name:	Source Four CE
Product type/model:	Source Four CE series (405, 410, 414, 419, 426, 436,
	450, 470, 490)
Lot:	n/a
Batch/Serial number:	n/a
Item numbers:	one of each model

to which this declaration relates in conformity with the following standards:

EN60598-1:2000	Luminaires, General requirements and tests
EN60598-2-17:1990	Specification for luminaires for stage lighting, television, film, and
	photographic studios (outside and indoor) - equiv. BS 4533-
	102.17:1990
following the provisions of EU LV Directive(s) 73/23/EEC
London, United Kingdom	Mr. Adam Bennette
(Place of issue)	(Name of authorised person)

(Date of issue)	(signature of authorised person)
Electronic Theatre Controls, Ltd.	Registered office:
Unit 26-28 Victoria Industrial Estate,	Grant Thornton House
Victoria Road, London W3 6UU U.K.	Melton St., London NW1 28W, England
Telephone (+44) (0)20 8896 1000	Registered in England No. 3057796
Fax (+44) (0)20 8896 2000	VAT No. 6629487 90

1

English

Source Four CE guidelines

The Source Four CE is intended for professional use only. Read the entire User Guide before using equipment.

W A R N I N G : Please note the following safety precautions.

•Do not mount the Source Four CE on or near a flammable surface.

•Use the Source Four CE in dry locations only, where humidity does not exceed 90 percent.

•The luminaire is for indoor use only and is not intended for outdoor use.

•For temporary installations, mount and support the Source Four CE only by the primary suspension yoke holes. Suspend the luminaire from a hook clamp or a stand mount, using a securely tightened steel bolt (up to Ø 12 mm), flat washer and locking washer.

•In addition to primary suspension, attach a safety cable (ETC part #7060A1022) or chain to the secondary suspension point on the Source Four CE.

•If the external cable is damaged, it shall be replaced by ETC or our service agents.

•Always hang the Source Four CE with the colour frame held securely behind the retaining clip.

•Always replace the lamp if it becomes damaged or thermally deformed.

•Disconnect the unit from power before all cleaning and maintenance.

•The Source Four CE is suitable for indoor use with a maximum ambient temperature: Ta=45 C

•Maximum exterior surface temperature: Tmax=217ºC

•A multilingual label sheet is included with this manual. Affix the label of the appropriate language over the existing warning label on the extension yoke. Do not cover ETC trademark or CE mark.

•The Source Four CE is equipped with a safety screen that covers the lens to prevent injury from broken glass due to lamp failure. Do not remove this safety screen.

•Keep the luminaire at least 0.8 meters away from any lit surface. Lighted objects at this distance or greater will not exceed 90ºC temperature from projected light.

0.8m

2	Source Four CE User Manual

English

Basic luminaire

			Earth continuity cable
	Secondary suspension point
Primary suspension yoke mounting holes			Lamp socket assembly
	Retainer bolt
	Drop-in iris slot
Colour frame	Retainer bolt
	Lens tube		Reflector housing
			Yoke locking knob
Gel retainer			Reflector
clip			Barrel rotation knob
	Barrel		Shutters
		Gobo holder slot
	assembly
	Beam focus knob
Colour frame holder	Safety screen
	(19°, 26°, 36° and 50° only)		Figure 1

W A R N I N G :	Please note the following safety warnings before use:
	Do not mount the luminaire on or near combustible surfaces.
	Do not operate the luminaire without a lens installed.
	Always hang the luminaire with the colour frame retaining clip in the locked
	position.
