Soundmax SM-CCR3703 User manual

SM-CCR3703

Мультимедийный ресивер 2 DIN с 7” сенсорным TFT-дисплеем и ТВ-тюнером

Руководство по эксплуатации

2 DIN Multimedia receiver with 7” TFT touch screen display and TV tuner

Instruction manual

Dear customer!

Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future.

Important safeguards ............................................................................................................................................. 3

Accessories ............................................................................................................................................................. 4

Installation/Connections ........................................................................................................................................ 5

Panel controls ....................................................................................................................................................... 10

General operations ............................................................................................................................................... 13

Radio operations ................................................................................................................................................... 16

TV tuner operations .............................................................................................................................................. 18

USB/SD operations ............................................................................................................................................... 19

Steering wheel control (SWC).............................................................................................................................. 21

Smartphone mirroring by HDMI........................................................................................................................... 22

Cleaning ................................................................................................................................................................. 23

Troubleshooting guide ......................................................................................................................................... 24

Specifications ........................................................................................................................................................ 25

Important safeguards

• Read carefully through the manual to familiarize yourself with this unit.

• Keep this manual handy as a reference for operating procedures and precautions. Do not allow persons who have not

read through this manual to use this unit.

• Do not allow this unit to come into contact with liquids. Electrical shock could result. Also, damage to this unit, smoke,

and overheating could result from contact with liquids or dust. Protect this unit from moisture.

• Make sure that foreign objects do not get inside the unit; they may cause malfunctions, or create safety hazards such

as electrical shock or laser beam exposure.

• The beginning of operation is the moment of the unit installation. Before use the device in winter it is recommended to

heat up the passenger compartment during 20 seconds or to the operation temperature.

• Using the unit with the temperature that goes beyond the operation temperature greatly decreases the operation

resource of the screen and other components of the unit and can result in an outage.

• Disconnect the vehicle’s negative battery terminal while mounting and connecting the unit.

• The unit is designed for negative terminal of the battery, which is connected to the vehicle metal. Please ensure it

before installation.

• When replacing the fuse, be sure to use one with an identical amperage rating. Using a fuse with a higher amperage

rating may cause serious damage to the unit.

• Do not allow the speaker wires to be shorted together when the unit is switched on. Otherwise it may overload or

burn out the power amplifier.

• Make sure you disconnect the power supply and aerial if you will not be using the system for a long period or during a

thunderstorm.

• Make sure you disconnect the power supply if the system appears to be working incorrectly, is making an unusual

sound, has a strange smell, has smoke emitting from it or liquids have got inside it. Let a qualified technician check the system.

• Always keep the volume low enough so that you can hear sounds from outside the vehicle.

• Should this product fail to operate properly, contact your dealer or nearest service center.

Accessories

1. Media player 1 pc

2. Remote controller 1 pc

3. ISO connector 1 pc

4. Mounting parts: Mounting bracket 2 pcs Steel bar 1 pc Screw B 5x20 1 pc Nut M5 1 pc Flat washer 2 pcs Spring washer 2 pcs Bolt M5 1 pc Screw B 5x12 4 pcs Screw B 5x6 4 pcs

5. Consumer information 1 pc

6. Warranty card 1 pc

7. Instruction manual 1 pc

Installation/Connections

Choose the mounting location where the unit will not interfere with the normal driving function of the

driver.

Before finally installing the unit, connect the wiring and make sure that the unit works properly. Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the

vehicle.

Install the unit where it does not get in the driver's way and cannot injure the passenger if there is a

sudden stop, like an emergency stop.

If installation angle exceeds 30° from horizontal, the unit may not perform properly. Avoid installing the unit where it would be subject to high temperature, such as from direct sunlight, or

from hot air, from the heater, or where it would be subject to dust, dirt or excessive vibration.

Mounting

• Connect the cable set and the antenna to the vehicle’s electronics corresponding to the connection table

(see farther).

• Attach the mounting racks to the sides and to the back of the unit, and fix them with the screws.

• Insert the unit into the slot until the stop. The unit then audibly snaps.

• Fasten the screws to fix the unit.

• The device is distinguished by a high degree of output. During operation, this results in a strong heat

generation. Therefore no cables or other parts may adjoin the device. If their insulation melts, there is the risk of a short circuit or fire.

• Removing: Turn off the device. Clamp off the negative pole of the vehicle battery for the duration of the disassembly. Unscrew the four screws. Remove carefully the unit from the slot and disconnect all wires. Make sure that no vehicle cable can cause a short circuit after the device has been unplugged.

Connection diagram

Using the ISO Connector

Location

FUNCTION

Connector A

Connector B

Rear right speaker (+)/Purple

Rear right speaker (-)/Purple-Black

Front right speaker (+)/Grey

Front right speaker (-)/Grey-Black

Battery 12V (+)/Yellow

Front left speaker (+)/White

Antenna power/Blue-White

Front left speaker (-)/White-Black

Panel light/Orange-White

Rear left speaker (+)/Green

ACC+/Red

Rear left speaker (-)/Green-Black

Ground/Black

1. If your car is equipped with the ISO connector, then connect the ISO connectors as illustrated.

2. For connections without the ISO connectors, check the wiring in the vehicle carefully before connecting, incorrect connection may cause serious damage to this unit.

Cut the connector, connect the colored leads of the power cord to the car battery as shown in the colour code table below for speaker and power cable connections.

Power antenna wire is intended for power supply of the antenna and for remote control of an additional amplifier.

Parking wire connection

If Parking cable is connected to hand brake switch, the video display of the TFT monitor will be controlled by driving status, system setup and input video sources. When the car is moving ahead, if the video disc is played, the screen shows a warning message. The warning screen will prevent the driver from watching images.

Reverse driving cable connection

If the rear view video camera is connected, the unit automatically switches to camera picture during reverse driving. The unit returns to the original work mode after the reverse driving is done.

Panel controls

Front panel

1. IR-sensor

2. TFT/ON/OFF button

3. HOME button

4. VOL+ button

5. VOL- button

6. SD card slot

7. RESET button

8. USB drive

9. AUX-in

10. Display

Remote controller

1. Power On/off

2. Mode Switch Button

3. Stop Playback

4. Navigation Up

5. Navigation Left

6. Enter Button

7. Change The Audio Output Method

8. Navigation Down

9. Band/Select Type

10. Auto Preset Scan/Repeat Play

11. Tuning/Music Selection (numeric key)

12. Mute Sound Button

13. Time Clock Display/Statistical Disc

Information Display Button

14. VOL +

15. Play/Pause Function

16. Sound Select Button

17. Navigation Right

18. VOL -

19. Subtitle Language Switching Key

20. Next Track/Next Radio Station

21. Previous Track/Previous Radio Station

22. GO TO Button (track selection)

23. Aspect Ratio Button

Changing the battery

Pic. 1

Pic. 2

1. Press the catch and at the same time pull out the battery tray (pic. 1).

2. Insert the 1 lithium battery, type CR2025 (3V) battery with the stamped

(+) mark facing upward. Insert the battery tray into the remote controller (pic.2).

Warning:

Store the battery where children cannot reach. If a child accidentally swallows the battery, consult a

doctor immediately.

Do not recharge, short, disassemble or heat the battery or dispose it in a fire. Do not expose or bring into contact the battery with other metallic materials. Doing this may cause the

battery to give off heat, crack or start a fire.

When throwing away or saving the battery, wrap it in tape and insulate; otherwise, the battery may give

off heat, crack or start a fire.

Please direct the Remote controller to the IR sensor of the front panel.

General operations

Touch screen

Due to the touch screen, you can fulfill most functions not only by pressing buttons but also by touching the

options you need.

Turning the unit on/off

Press the POWER Button to turn the unit on. When the unit is on, press the POWER Button once to turn the TFT off. During TFT off, the video out signal will be available so that the connected monitor will show the screen of the unit. Press the POWER Button again to turn the TFT back on. Press and hold the POWER button again to turn the unit off.

Reset the unit

Operating the unit for the first time or after replacing the car battery, you must reset the unit. Press reset button on the unit with a pointed object (such as a ballpoint pen) to set the unit to initial state.

When some errors occur on the display, you can also press reset button to resume to normal, and it will erase the clock setting and some memorized functions.

Setting the sound characteristics

• Volume: Use the VOL +/- Button to adjust the volume level. Turn the button clockwise to increase the volume, and vice versa. The larger the number of volume, the higher the volume level. You can also adjust the volume by sliding the volume icon on top of the screen.

• Bass: Press the SEL Button on the RC until the display shows “BAS”. Use the VOL +/- Button to adjust. When EQ is ON, bass control is not available.

• Treble: Press SEL Button on the RC until the display shows “TRE”. Use the VOL +/- Button to adjust. When EQ is ON, treble control is not available.

• Balance: Press SEL Button on the RC until the display shows “BAL”, then use the VOL +/- Button to adjust the balance between the left & right speakers.

• Fader: Press SEL Button on the RC until the display shows “FAD”, then use the VOL +/- Button to adjust the balance between the front & rear speakers.

• Other Audio Settings: You can adjust other audio settings like preset equalizer, loudness or subwoofer ON/OFF by tapping the “EQ” icon on the main menu, or on the control menu of other audio/video play modes.

Mute function

Press MUTE button on the RC to turn off the sound. Press the button again or adjust volume to resume the

sound output.

Mode selection

Press the MODE Button to cycle the Play Modes between RADIO, USB, SD and AUX in.

RCA output

The RCA Output is on the back of the unit. (Refer to Wiring Diagram) This output is for connecting amplifier, equalizer, or other audio component that requires a pre-amp out connection. (Red=Right, White=Left) Follow the manufactures instructions for the audio component that you are connecting.

AV in jack

The Video Output Jack is on the back of the unit. (Refer to Wiring Diagram) This output (in yellow) is for connecting monitor(s). You must connect a monitor for car in order to play this unit in another monitor. Consult your dealer for any kinds of monitors that are suitable to use in car.

Subwoofer

The Subwoofer Output is on the wire harness. (Refer to Wiring Diagram) This output is designed for connecting up to 2 subwoofers to the unit. Follow the amplifier’s installation instructions. You can turn the subwoofer on/off by pressing the icon in the main menu.

Rear view camera function

The rear view camera input is on the back of the unit. (refer to wiring diagram). This input (in yellow) is for connecting backup camera for parking. You must connect the VCC wire (in purple-white color) to the reverse gear switch in order to activate this video input mode when you switch the reverse gear of your car. Please refer to the wiring diagram for more details.

+ 35 hidden pages
