Sophi
Products.
Page 2
2 PHACO DEVICE
Mobility, Simplicity,
Safety.
Sophi is the first wireless Phaco System, which offers the
surgical team high flexibility and mobility.
Phaco Device
Sophi Premium
1 Piece
Active IOP Control Pump
Peristaltic Pump
Clean Venturi Pump (Compressor Venturi)
Wireless Set (Battery & Compressor Vitrectomy)
Foot Pedal Sophi (1401-1300)
Tray Sophi (1401-0109)
Wi-Fi Video Transmitter Sophi (1401-0199-300)
REF. 1401-0100-ACW
Sophi Eco
1 Piece
Active IOP Control Pump
Peristaltic Pump
Compressor Vitrectomy
Battery-Ready
Foot Pedal Sophi (1401-1300)
Optional:
License Battery Sophi (1401-3000)
Tray Sophi (1401-0109)
Wi-Fi Video Transmitter Sophi (1401-0199-300)
REF. 1401-0100-A
Page 3
3
PHACO DEVICE
Sophi A
1 Piece
Active IOP Control Pump
Peristaltic Pump
Compressor Vitrectomy
Foot Pedal Sophi (1401-1300)
Charging Station USB Sophi (1801-1310)
Optional:
Wi-Fi Video Transmitter Sophi (1401-0199-300)
REF. 1801-0100
Page 4
4
PHACO DEVICE ACCESSORIES
Small details, big
advantages.
Sophi’s design is simple and straightforward. Complexity
lies inside the device and therefore facilitates a simple
user handling.
Phaco Device Accessories
Tray Sophi
1 Piece
Length 640 mm
Width 380 mm
Height 40 mm
REF. 1401-0109
Tray Sophi Compact
1 Piece
Length 400 mm
Extended Length 640 mm
Width 320 mm
Height 40 mm
REF. 1401-1400
Wi-Fi Video Transmitter Sophi
1 Set
1 Video Streaming Box
1 Wi-Fi Adapter
REF. 1401-0199-300
Page 5
5
PHACO HANDPIECE
Efcient
Sinus Phaco.
The less energy a Phaco handpiece requires, the less heat is
projected into the eye. That is why Sophi controls the
handpiece with a sinusoidal signal.
Phaco Handpiece
Phaco Handpiece Sophi
1 Piece
REF. 1401-2001
Phaco Handpiece Sophi Eco
1 Piece
REF. 1401-2010
Page 6
6
CASSETTE & TUBING
Triple Pump
Fluidics.
When it comes to the pumping system, Sophi is impressively innovative.
Sophi controls fluidics with three perfectly aligned pumping systems.
Peristaltic Pump, Clean Venturi Pump and active IOP Control Pump.
Cassette & Tubing
Cassette Peristaltic Sophi
Cassette Peristaltic Sophi Eco
Box of 10 Pieces
Box of 16 Pieces (Eco)
1 Cassette Peristaltic
1 Infusion Set
1 I/A Twin Tube
1 Waste Bag
1 Display Cover
REF. 1401-1200 Cassette Peristaltic Sophi
REF. 1401-1203 Cassette Peristaltic Sophi Eco
Cassette Peristaltic & Venturi Sophi
Box of 10 Pieces
1 Cassette Peristaltic & Venturi
1 Infusion Set
1 I/A Twin Tube
1 Waste Bag
1 Display Cover
REF. 1401-1210
Tubing Set for Day Cassette Sophi
Box of 10 Pieces
1 I/A Twin Tube
1 Waste Bag
1 Display Cover
REF. 1401-1290
Page 7
7
PHACO SET
Tip, sleeve, test
chamber and wrench.
Stable chamber even at high vacuum levels and efficient
emulsification to reduce effective phaco-time without
compromising safety.
Phaco Set
Phaco Set Sophi - 20G
Box of 10 Pieces
Incision Size 2.5 – 2.75mm
1 Flared 20G/30° Phaco Tip, ASP Port 0.6mm
1 20G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2020 Single Use
REF. 1401-2620 Multi Use
Phaco Set Sophi - 21G
Box of 10 Pieces
Incision Size 2.2 – 2.4mm
1 Flared 21G/30° Phaco Tip, ASP Port 0.5mm
1 21G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2021 Single Use
REF. 1401-2621 Multi Use
Phaco Set Sophi - 23G
Box of 10 Pieces
Incision Size 1.8 – 2.0mm
1 Flared 23G/30° Phaco Tip, ASP Port 0.4mm
1 23G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2023 Single Use
REF. 1401-2623 Multi Use
Page 8
8
PHACO SET
Phaco Set Sophi - 20G Curved
Box of 10 Pieces
Incision Size 2.5 – 2.75mm
1 Flared 20G/30°, Curved Phaco Tip
ASP Port 0.6mm
1 20G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2720 Single Use
REF. 1401-3220 Multi Use
Phaco Set Sophi - 21G Curved
Box of 10 Pieces
Incision Size 2.2 – 2.4mm
1 Flared 21G/30°, Curved Phaco Tip
ASP Port 0.5mm
1 21G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2721 Single Use
REF. 1401-3221 Multi Use
Phaco Set Sophi - 23G Curved
Box of 10 Pieces
Incision Size 1.8 – 2.0mm
1 Flared 23G/30°, Curved Phaco Tip
ASP Port 0.4mm
1 23G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2723 Single Use
REF. 1401-3223 Multi Use
Page 9
9
PHACO SET
Dynamic Phaco Set Sophi - 20G
Box of 10 Pieces
Incision Size 2.5 – 2.75mm
1 Flared 20G/30° Phaco Tip, ASP Port 0.5mm
1 20G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-3020 Single Use
REF. 1401-3120 Multi Use
HighVac Phaco Set Sophi - 21G
Box of 10 Pieces
Incision Size 2.2 – 2.4mm
1 Flared 21G/30° Phaco Tip, ASP Port 0.45mm
1 21G Sleeve
1 Test Chamber
2 Tip Wrench (Single Use)
1 Tip Wrench (Multi Use)
10 Times Sterilizable (Multi Use)
REF. 1401-2821 Single Use
REF. 1401-2921 Multi Use
Page 10
10
IRRIGATION & ASPIRATION BIMANUAL
Cortex removal,
polish...
The latest series of bimanual and coaxial I/A-handles ensure
enhanced grip during I/A.
Irrigation & Aspiration Bimanual
I/A Bimanual Handpiece Set Sophi – 21G
Aeroplane
Box of 10 Pieces
Incision Size 1.1mm - Single Use
1 Aspiration Handpiece Green 21G
Curved Cannula Aeroplane Shape
ASP Port 0.35mm, Textured Head
Easy Incisions Entry
Incision Size 1.1mm - Single Use
1 Irrigation Handpiece Transparent 21G
Curved Cannula Aeroplane Shape
2× IRR Port 0.45mm
Easy Incisions Entry
REF. 1401-2130
21 G
Page 11
11
IRRIGATION & ASPIRATION COAXIAL
... visco removal
and so on.
Irrigation & Aspiration Coaxial
I/A Coaxial Handpiece Set Sophi - 20G/45°
Box of 10 Pieces
Single Use
Incision Size 2.5mm
1 I/A Handpiece Yellow
Aspiration Cannula Angled 20G/45°,
ASP Port 0.35mm, Polished Head
REF. 1401-2220
I/A Coaxial Handpiece Set Sophi - 20G/65°
Box of 10 Pieces
Single Use
Incision Size 2.5mm
1 I/A Handpiece Yellow
Aspiration Cannula Angled 20G/65°,
ASP Port 0.35mm, Polished Head
REF. 1401-2230
I/A Coaxial Handpiece Set Sophi - 21G/45°
Box of 10 Pieces
20 G
20 G
21 G
Single Use
Incision Size 2.2mm
1 I/A Handpiece Green
Aspiration Cannula Angled 21G/45°,
ASP Port 0.35mm, Polished Head
REF. 1401-2221
Page 12
12
IRRIGATION & ASPIRATION COAXIAL
I/A Coaxial Handpiece Set Sophi - 21G/45°
Soft Tip
Box of 10 Pieces
Single Use
Incision Size 2.2mm
1 I/A Handpiece Green Soft-Tip
Aspiration Cannula Angled 21G/45°,
ASP Port 0.40mm, Silicone Tip Head
REF. 1401-2243
I/A Coaxial Handpiece Set Sophi - 23G/45°
Box of 10 Pieces
Single Use
Incision Size 1.8mm
1 I/A Handpiece Blue
Aspiration Cannula Angled 23G/45°,
ASP Port 0.30mm, Polished Head
REF. 1401-2223
21 G
23 G
Page 13
13
DIATHERMY
Bipolar pencils and
forceps.
These superior bipolar products come with a non-slip grip
exterior surface. The instruments are available as reusable
and single use.
Diathermy
DIA Disposable Pencil Straight
Box of 10 Pieces
Disposable Bipolar Pencil Non-Stick
18G Straight
Length 11.1cm (4 3/8 in.)
REF. 14-5000
Order No. 1401-2502
DIA Disposable Forceps Straight
Box of 10 Pieces
Disposable Bipolar Forceps Non-Stick
Straight 0.4mm tip Jewelers/Iris
Length 10.2cm (4in.)
REF. 14-3000
Order No. 1401-2503
DIA Disposable Forceps Curved
Box of 10 Pieces
Disposable Bipolar Forceps Non-Stick
Curved 0.4mm tip Jewelers/iris
Length 10.2cm (4 in.)
REF. 14-1080
Order No. 1401-2504
DIA Disposable Bipolar Cable Sterile
Box of 10 Pieces
Disposable Bipolar Cord (28.6mm)
Length 3.6m (12ft.)
REF. 10-4001V
Order No. 1401-2501
Page 14
14
DIATHERMY
DIA Reusable Pencil Straight
1 Piece
Non-sterile
Reusable Thermoplastic Rubber
Bipolar Pencil Non-Stick
18G Straight
Length 11.1cm (4 3/8 in.)
REF. 14-7000
Order No. 1401-2506
DIA Reusable Forceps Straight
1 Piece
Non-sterile
Bipolar Coagulation Forceps
Straight 0.4mm tip Jewelers
Length: 10.2cm (4 in.)
REF. 10-3000
Order No. 1401-2507
DIA Reusable Forceps Curved
1 Piece
Non-sterile
Bipolar Coagulation Forceps
Curved 0.4mm tip Jewelers
Length 10.2cm (4 in.)
REF. 10-3001
Order No. 1401-2508
DIA Reusable Bipolar Cable
1 Piece
Non-sterile
Reusable Bipolar Cord (28.6mm)
Length 3.6m (12 ft) Silicone
REF. 10-6000V
Order No. 1401-2505
Page 15
15
VITRECTOMY
Pneumatic anterior
vitrectomy.
The compressor for vitrectomy is integrated into the device.
Therefore, the usual tube to the external pneumatic supply
becomes superfluous.
Vitrectomy
Vitrectomy Cutter Sophi – 23G
Box of 6 Pieces
Single Use
Guillotine Cutter
REF. 1401-2323
23 G
Page 16
16
MISCELLANEOUS
Other useful
accessories.
Miscellaneous
Cover Sophi
1 Piece
Polyester
White
REF. 1401-0170-005
Transport Box Sophi
1 Piece
Wooden Packaging
Treated According to ISPM 15 - CH-90240, HT
REF. 1401-0170-001
Page 17
17 MISCELLANEOUS
Transport Case Sophi A
1 Piece
REF. 1801-0170-001
Cover Sophi A
1 Piece
Polyester
White
REF. 1801-0170-006
Page 18
18 MISCELLANEOUS
Lithium-Ion Battery (BMS)
2 Pieces
REF. 1401-0107-002
Foot Pedal Sophi
1 Piece
Wireless/Bluetooth Low Energy
Easy Move Function
Inductive Charging
Dual Linear
4 Rocker Switches
Foot Pedal Cable Sophi (1401-0199-801)
REF. 1401-1300
Foot Pedal Cable Sophi
1 Piece
Length 4m
REF. 1401-0199-801
Earth Cable Sophi
1 Piece
Length 3m
REF. 1401-0199-101
Page 19
19 MISCELLANEOUS
Charging Station USB Sophi
1 Piece
REF. 1801-1310
Charging Station CAN Sophi
1 Piece
REF. 1801-1320
Insole Foot Pedal Sophi
1 Piece
REF. 1401-9928-004
License Battery Sophi
1 Piece
REF. 1401-3000
Page 20
“A clever design is not only pleasing to
the eye. A clever design integrates well
into your workow and seamlessly
becomes a part of your system. Think
about mobility, simplicity and safety to
signicantly increase eciency.”
Thomas Köppel
CEO This AG
Page 21
Page 22
www.sophi.info
Rev.: 1401-8300-006-04
