FM/MW/LW Cassette Car Stereo

3-858-436-11 (1)

Operating Instructions

XR-6859RDS

 1996 by Sony Corporation

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Welcome!

Thank you for purchasing the Sony Cassette Car Stereo. This unit lets you enjoy a variety of features by using a rotary remote.

In addition to the tape playback and the radio operations you can expand your system by connecting an optional CD changer.

This unit also incorporates a security system.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Table of contents

This Unit Only

Getting Started

Resetting the unit ................................................ 4

Detaching the front panel .................................. 4

Preparing the rotary remote .............................. 4

Setting the clock .................................................. 5

Cassette player

Listening to the tape ........................................... 5

Playing the tape in various modes ................... 6

Radio

Memorising stations automatically

— Best Tuning Memory (BTM) ................... 7

Memorising only the desired stations .............. 7

Receiving the memorised stations .................... 7

RDS

Overview of the RDS function .......................... 8

Displaying the station name .............................. 8

Re-tuning the same programme automatically

— Alternative Frequencies (AF) .................. 8

Listening to traffic announcements .................. 9

Presetting the RDS stations with the AF

and TA data ................................................. 10

Locating a station by programme type .......... 10

Setting the clock automatically ....................... 11

Other Functions

Using the rotary remote ................................... 11

Adjusting the sound characteristics ............... 12

Muting the sound.............................................. 12

Changing the sound settings ........................... 12

With Optional Equipment

CD changer

Playing a CD ...................................................... 13

Scanning the tracks

— Intro scan .................................................. 13

Playing tracks repeatedly

— Repeat play .............................................. 13

Playing tracks in random order

— Shuffle play .............................................. 14

Additional Information

Precautions ......................................................... 14

Maintenance ....................................................... 15

Location of controls .......................................... 16

Specifications ..................................................... 17

Troubleshooting guide ..................................... 18

Index .................................................... Back cover

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Getting Started

Depending on the car, the “Resetting the unit” and “Detaching the front panel” procedures may not work.

Attaching the front panel

Attach part A of the front panel to part B of the unit as illustrated and push until it clicks.

Resetting the unit

Before operating the unit for the first time or after replacing the car battery, you must reset the unit. Press the reset button with a pointed object, such as a ballpoint pen.

Reset button

Note

Pressing the reset button will erase all the memorised stations.

Detaching the front panel

The front panel of this unit can be detached in order to prevent the unit from being stolen.

1 Press (OFF).

2 Press (RELEASE) to open up the front

panel, and detach the panel by pulling it towards you.

(RELEASE)

Notes

• Make sure that the front panel is the right way up when

attaching it to the unit as it cannot be attached upside down.

• Do not press the front panel hard against the unit when

attaching it to the unit. It can easily be attached by pressing it lightly against the unit.

• When you carry the front panel with you, put it in the

supplied front panel case.

• Do not press hard or give excessive pressure to the

display windows of the front panel.

• Do not expose the front panel to direct sunlight, heat

sources such as hot air ducts or leave it in a humid place. Never leave it on the dashboard etc. of a car parked in direct sunlight where there may be a considerable rise in temperature inside the car.

Caution alarm (Detachable front panel only)

If you turn the ignition key to the OFF position without removing the front panel, the caution alarm will beep for a few seconds.

Preparing the rotary remote

When you mount the rotary remote, attach the label in the illustration below.

Notes

• Be sure not to drop the panel when detaching it from the unit.

• If you press (RELEASE) to detach the panel while the unit is still turned on, the power will be automatically turned off in order to protect the speakers from being damaged.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

SEL

DSPL

MODE

DSPL

SEL

Setting the clock

The clock has a 24-hour digital indication.

For example, setting it to 10:08

Cassette Player

1 Press (DSPL) during operation.

2 Press (DSPL) for more than two seconds.

100

The hour digit blinks.

1 Set the hour digits.

to go forward

to go back

1000

2 Press (SEL) momentarily.

1000

The minute digit blinks.

3 Set the minute digits.

to go forward

to go back

1008

3 Press (DSPL) momentarily.

1008

The clock activates.

Note (Audi only)

Turn the power on first, then set the clock.

Listening to the tape

Insert the cassette.

Playback will start automatically.

If the cassette is already inserted, press (TAPE) to start playback.

FWD

The side facing up is being played.

REV

The side facing down is being played.

Tip

To change the tape transport direction, press (TAPE) during tape playback.

Stop playback

Eject the cassette

Fast-winding the tape

During playback, press either side of (PRESET/DISC).

PRESET

REW

To start playback during fast-forwarding or rewinding, press (TAPE).

DISC

Press

(OFF)

Fast-forwardRewind

Getting Started/Cassette Player

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Locating the beginning of the tracks

You can skip up to nine tracks at one time.

Note

The AMS function may not work when :

• the blanks between tracks are shorter than four seconds

• there are noises

• there are long sections of low volume or quiet sections.

— Automatic Music Sensor (AMS)

During playback, press either side of (SEEK/AMS) momentarily.

SEEK

AMS

To locate the previous tracks

To locate the succeeding the tracks

Changing the displayed items

Each time you press (DSPL) momentarilly during tape playback, the displayed item changes as follows:

z Tape playback z Clock z Frequency*

Switching to the radio during fastwinding the tape

— Automatic Tuner Activation (ATA)

Press (5) during playback.

“ATA” appears on the display.

When fast-forwarding or rewinding with (PRESET/DISC), the tuner will turn on automatically.

Skipping blanks during tape playback — Blank skip

Press (6) during playback.

“BL.SKIP” appears on the display.

Blanks longer than eight seconds will be automatically skipped during tape playback.

* While the ATA function is activated

Playing the tape in various modes

Searching the desired track

— Intro scan

Press (1) during playback.

“INTRO” appears on the display.

The first 10 seconds of all the tracks are played.

When you find the desired track, press again. The unit returns to the normal playback mode.

Playing tracks repeatedly

— Repeat play

Press (2) during playback.

“REP” appears on the display.

When the currently played track is over, it will be played again from the beginning.

To cancel this mode, press again.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Radio

Memorising stations automatically

— Best Tuning Memory (BTM)

This function selects from the currently received band the stations with the strongest signals and memorises them in order of their frequency.

PREVENTING ACCIDENTS!

When tuning in during driving, use the automatic tuning and the memory preset search function instead of the manual tuning.

1 Press (TUNER) repeatedly and select the

band.

Each time you press (TUNER), the band changes as follows:

FM1 n FM2 n FM3 n MW n LW

2 Press (SENS/BTM) for two seconds.

Notes

• The unit will not store stations with weak band frequencies on the preset number buttons. If there are only a few stations received, some preset number buttons will remain empty.

• When there is a preset number indicated on the display, the unit will store stations on all preset number buttons from the one currently displayed.

3 Press the desired preset number button

((1) to (6)) for three seconds.

The number of the pressed preset number button appears on the display.

Receiving the memorised stations

1 Press (TUNER) repeatedly, and select the

band.

2 Press the preset number button ((1) to

(6)) momentarily on which the desired station is stored.

Tip

Press either side of (PRESET/DISC) momentarily to receive in order the stations stored in the memory (Preset Search Function).

If FM stereo reception is poor

— Monaural mode

Press (SENS/BTM) momentarily until “MONO” lights up on the display.

The sound will improve, but it will become monaural. (The “ST” indication will disappear.)

Changing the displayed items

Each time you press (DSPL), the display item changes as follows:

Frequency ˜ Clock

Cassette Player/Radio

If you cannot tune in a preset station

Memorising only the desired stations

Up to 6 stations on each band (FM1, FM2, FM3, MW and LW) can be stored on the preset number buttons in order of your choice. Therefore, 18 stations can be memorised on FM. If you try to store another station on the same preset number button, the previously stored station will be erased.

1 Press (TUNER) repeatedly, and select the

band.

2 Press (SEEK/AMS) to search for the

station which you wish to store on the preset number button.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Press either side of (SEEK/AMS) momentarily to search for the station (automatic tuning).

The scanning stops when a station is received. Press either side of the button repeatedly until the desired station is received.

Note

If the automatic tuning stops too frequently, press (SENS/BTM) momentarily until “LCL” lights up on the display (local seek mode). Only the stations with relatively strong signals can be tuned in.

Tip

If you know the frequency, press and hold either side of (SEEK/AMS) until the desired station is received (manual tuning).

RDS

Overview of the RDS function

Radio Data System (RDS) is a broadcasting service that allows FM stations to send additional digital information along with the regular radio programme signal. Your car stereo offers you a variety of services. Here are just a few: Re-tuning the same programme automatically, Listening to traffic announcements and Locating a station by programme type.

Re-tuning the same programme automatically

— Alternative Frequencies (AF)

The Alternative Frequencies (AF) function automatically selects and re-tunes the station with the strongest signal in a network. By using this function, you can continuously listen to the same programme during a longdistance drive without having to re-tune the station manually.

Frequencies change automatically.

96.0 MHz

98.5 MHz

Notes

• Depending on the country or region, not all of the RDS functions are available.

• RDS may not work properly if the signal strength is weak or if the station you are tuned in is not transmitting RDS data.

Displaying the station name

The name of the station currently received lights up on the display.

Select an FM station.

When you tune in an FM station that transmits RDS data, the station name lights up on the display.

FM1

BBC 1 FM

Note

The “*” indication means that an RDS station is being received.

Changing the displayed items

Each time you press (DSPL), the displayed item changes as follows:

z Frequency z Clock z Station Name

Note

“NO NAME” lights up if the station received does not transmit RDS data.

Station

102.5 MHz

1 Select an FM station.

2 Press (AF/TA) until “AF” lights up on the

display.

The unit starts searching for an alternative station with a stronger signal in the same network.

Note

When there is no alternative station in the area, and you don’t need to search for an alternative station, turn the AF function off by pressing (AF/TA) until “AF TA” disappears.

Changing the displayed items

Each time you press (AF/TA), the displayed items change as follows:

z AF z TA z AF TA*

Blank Z

* Select this to turn on both AF and TA functions.

Notes

• “NO AF” and the station name flashes alternately, if the unit cannot find an alternative station in the network.

• If the station service name starts flashing after you’ve made the preset selection, it means that no alternative frequency is available and the unit cannot receive the PI (Programme Identification) data of the memorised station. Press (SEEK/AMS) while the station service name is flashing (for about eight seconds) so the unit starts searching for a station with the same PI data, but with another frequency (“PI SEEK” lights up and no sound is heard). If the unit still cannot find an alternative station, “NO PI” lights up and the unit goes back to the original preset station.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Listening to a regional programme

The “REG” (regional on) function of this unit lets you stay tuned to a regional programme without being switched to another regional station. (Note that you must turn the AF function on.) The unit is factory preset to “REG“ but if you want to turn off the function, do the following.

Press (AF/TA) for more than two seconds until “REG” disappears.

Note that turning the “REG” function off might cause the unit to switch to another regional station within the same network.

Note

This function does not work in the United Kingdom and in some other areas.

Local link function (United Kingdom only)

The Local Link function lets you select other local stations in the area, even though they are not stored in your presets.

1 Press a preset number button that has

stored a local station.

2 Within five seconds, press again the

preset number button of the local station.

3 Repeat this procedure until the desired

local station is received.

Listening to traffic announcements

The Traffic Announcement (TA) and Traffic Programme (TP) data let you automatically tune in an FM station that is broadcasting traffic announcements even though you are listening to other programme sources.

Tip

When the traffic announcement starts while you are listening to another programme source, the unit automatically switches to the announcement and goes back to the original source when the announcement is over.

Notes

• “NO TP” flashes for five seconds if the received station doesn’t broadcast traffic announcements. Then, the unit starts searching for a station that does broadcast traffic announcements.

• When the “EON” indication appears with “TP” on the display, the current station makes use of broadcast traffic announcements of other stations in the same network.

To cancel the current traffic announcement

Press (AF/TA) momentarily.

To cancel all traffic announcements, turn off the function by pressing (AF/TA) until and “TA” disappears.

Presetting the volume of traffic announcements

You can preset the volume level of the traffic announcements beforehand, so you will not miss the announcement. When a traffic announcement starts, the volume will be automatically adjusted to the preset level.

1 Select the desired volume level.

2 Press (3) while holding down (SEL).

A beep sounds, and the setting is stored.

Receiving emergency announcements

If an emergency announcement comes in while you are listening to the radio, the programme will be automatically switched to the announcement. If you are listening to a source other than the radio, the emergency announcements will only be heard if you set AF or TA to on. The unit will then automatically switch to these announcements no matter what you are listening to at the time.

RDS

Press (AF/TA) until “TA” or “AF TA” lights up on the display.

The unit starts searching for traffic information stations. “TP” lights up on the display when the unit finds a station broadcasting traffic announcements. When the traffic announcement starts, “TA” flashes, then flashing stops when the traffic announcement is over.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

INFO

SPORT

Presetting the RDS stations with the AF and TA data

When you preset the RDS stations, the unit stores each station’s data as well as its frequency, so you don’t have to turn on the AF or TA function every time you tune in the preset station. You can select different setting (AF, TA, or both) for individual preset stations, or the same setting for all preset stations.

Presetting the same setting for all preset stations

1 Select an FM band.

2 Press (AF/TA) repeatedly and select

either “AF“, “TA” or “AF TA” (for both AF and TA functions).

Note that turning the “AF TA” function off stores RDS stations as well as non-RDS FM stations.

3 Press (SENS/BTM) for two seconds.

Presetting different settings for each preset station

1 Select an FM band, and tune in the

desired station.

2 Press (AF/TA) repeatedly and select

either “AF“, “TA” or “AF TA” (for both AF and TA functions).

Locating a station by programme type

You can locate the station you want by selecting one of the programme type shown below.

Note

In the countries or regions where EON data is not transmitted, you can use this function only for the stations you have tuned in once.

Programme types

News Current Affairs Information

Sports Education Drama Culture Science

Varied Popular Music Rock Music Middle of the Road Music Light Classical

Classical Other Music Type Not specified

Note

You cannot use this function in some countries where no PTY (Programme Type selection) data is available.

Display

NEWS AFFAIRS INFO

SPORT EDUCATE DRAMA CULTURE SCIENCE

VARIED POP M ROCK M M.O.R. M LIGHT M

CLASSICS OTHER M NONE

3 Press the desired preset number button

for three seconds. Repeat from step 1 for presetting other stations.

Tip

If you want to change the preset AF and/or TA setting after you tuned in the preset station, you can do so by turning on/off the AF or TA function.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

1 Press (PTY) during FM reception until

“PTY” lights up on the display.

The current programme type name appears if the station is transmitting the PTY data. “- - - - -” appears if the received station is not an RDS station or if the RDS data has not been received.

2 Press (PTY) repeatedly until the desired

programme type appears.

The programme types appear in the order as shown in the above table. Note that you cannot select “NONE” (Not specified) for searching.

3 Press either side of (SEEK/AMS).

The unit starts searching for a station broadcasting the selected programme type. When the unit finds the programme, the programme type appears again for five seconds. “NO” and the programme type appear alternately for five seconds if the unit cannot find the programme type and it returns to the previous station.

Other Functions

Using the rotary remote

The rotary remote works by pressing buttons and/or rotating controls. You can control the optional CD changer with the rotary remote.

Setting the clock automatically

By receiving CT (Clock Time) data, the clock of this unit can be set automatically.

During FM reception, press (2) while pressing (SEL).

“CT” will be displayed, and the clock will be set.

FM1

100

To cancel the CT function

Repeat the above procedure.

Notes

• The CT function may not work even though an RDS

station is being received.

• The time set by the CT function may not be exact.

By pressing the button (the SOURCE button)

(SOURCE)

(MODE)

Each time you press (SOURCE), the source changes as follows:

FM1 n FM2 n FM3 n MW n LW n CD1 n CD2 n TAPE

Tip

You can turn on this unit by pressing (SOURCE) on the rotary remote.

By rotating the control (the SEEK/AMS control)

RDS/Other Functions

Rotate the control momentarily and release it to:

•Locate the beginning of the tracks on the tape. Rotate and hold the control, and release it to fast-wind the tape. To playback, rotate and hold the control again, and release it.

•Locate a specific track on a disc. Rotate and hold the control to locate the specific point in a track, then release it to start playback.

•Tune in the stations automatically. Rotate and hold the control to tune in the specific station.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

By rotating the control while pushing (the PRESET/DISC control)

Rotate the control while pushing it to:

•Receive the stations memorised on the preset buttons.

•Change the disc.

Other operations

Rotate the VOL control to adjust the volume.

Press (MUTE) to mute the sound.

Press (SEL) two seconds while pushing the VOL control.

Tip

You can control the operative direction of controls with the unit.

Adjusting the sound characteristics

OFF

Press (OFF) to turn off the unit.

Press (SEL) to adjust and select.

Press (DSPL) to change the displayed items.

Changing the operative direction

The operative direction of controls is factory preset as in the illustration below.

To increase

To decrease

If you need to mount the rotary remote on the right of the steering column, you can reverse the operative direction of the controls.

1 Select the item you want to adjust by

pressing (SEL) repeatedly.

VOL (volume) n BAS (bass) n TRE (treble) n BAL (balance) n FAD (fader)

2 Adjust the selected item by pressing

either (+) or (–).

Adjust within three seconds after selecting. (After three seconds the button will again serve as volume control button.)

Muting the sound

Press (MUTE).

The “MUTE” indication flashes.

To restore the previous volume level, press again.

Changing the sound settings

Enjoying bass and treble even at Low Volume — Loudness

Bass and treble will be reinforced.

Press (LOUD).

“LOUD” will appear on the display.

To cancel, press again.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

With the Optional Equipment

CD Changer

You can control two CD changers.

Playing a CD

Press (CD) and select the changer.

CD playback starts.

When a CD changer is connected, all the tracks play from the beginning.

Each time you press (DSPL) momentarily during CD playback, the displayed item changes as follows:

Elapsed playback time ˜ Clock

Locating a specific track

— Automatic Music Sensor (AMS)

During playback, press either side of (SEEK/AMS) the number of times you wish to skip the tracks.

SEEK

AMS

To locate the previous tracks

Locating a specific point in a track

— Manual Search

During playback, press and hold either side of (SEEK/AMS). Release the button when you have found the desired part.

To reverse

Switching to other discs

During playback, press either side of (PRESET/DISC).

REW

To return to the previous disc

To locate the succeeding tracks

SEEK

AMS

To forward

PRESET

DISC

To advance to the next disc

Scanning the tracks

— Intro scan

The first 10 seconds of all the tracks on the currently selected disc are played in order. After the first disc is over, the next disc is played.

Press (1) during playback.

“INTRO” appears on the display.

When you find the desired track, press again. The unit returns to the normal CD playback mode.

Playing tracks repeatedly

— Repeat play

To repeat a track

Press (2) repeatedly during CD playback until “REP 1” is displayed.

To repeat a disc

Press (2) repeatedly during CD playback until “REP 2” is displayed.

To repeat all the discs in the current changers

Press (2) repeatedly during CD playback until “REP 3” is displayed.

Each time you press (2) the display changes as follows:

REP 1 (Track repeat)

Cancel (Normal CD playback mode)

REP 2 (Disc repeat)

REP 3 (Changer repeat)

Other Functions/CD Changer

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Playing tracks in random order

To play the tracks on the current disc in a random order

To play the tracks in the current changer in a random order

To play all the tracks in a random order

Each time you press (3) the display changes as follows:

SHUF 1 (Disc shuffle)

Cancel (Normal CD playback mode)

If you press (1) during shuffle play, the first 10 seconds of all tracks will be played in random order.

— Shuffle play

Press (3) repeatedly during CD playback until “SHUF 1” is displayed.

Press (3) repeatedly during CD playback until “SHUF 2” is displayed.

Press (3) repeatedly during CD playback until “SHUF 3” is displayed.

SHUF 2 (Changer shuffle)

SHUF 3 (All shuffle)

Additional Information

Precautions

• If your car was parked in direct sunlight

resulting in a considerable rise in temperature inside the car, allow the unit to cool off before switching on.

• If no power is being supplied to the unit,

check the connections first. If everything is in order, check the fuse.

• If no sound comes from the speakers of

2-speaker systems, set the fader control to the centre position.

If you have any questions or problems concerning your unit that are not covered in this manual, please consult your nearest VAG dealer.

Notes on Cassettes

Cassette care

• Do not touch the tape surface of a cassette, as

any dirt or dust will contaminate the heads.

• Keep cassettes away from equipment with

built-in magnets such as speakers and amplifiers, as erasure or distortion on the recorded tape could occur.

• Do not expose cassettes to direct sunlight,

extremely cold temperatures or moisture.

• When the tape is played back for a long

period, the cassette shell may become warm because of the built-in power amplifier. However, this is not a sign of a malfunction.

Cassettes longer than 90 minutes

The use of cassettes longer than 90 minutes is not recommended except for long continuous play. The tapes used for these cassettes are very thin and tend to be stretched easily. Frequent playing and stopping of these tapes may cause them to be pulled into the cassette deck mechanism.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Maintenance

Depending on the car, the front panel will be fixed to the unit, and you cannot detach the front panel.

Cleaning the Connectors

The unit may not function properly if the connectors between the unit and the front panel are not clean. In order to prevent this, open the front panel by pressing (RELEASE), then detach it and clean with a cotton swab dipped in alcohol. Do not apply too much force. Otherwise, the connector may get damaged.

Main unit

Back of the front panel

CD Changer/Additional Information

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Location of controls

SENS/BTM

REP

SEL

SHUFINTRO

DSPL

BL.

ATA

SKIP

123 456

LOUD

MUTE

RELEASE

Refer to the pages for further details.

1 LOUD (loudness) button 12 2 During radio reception:

Preset number buttons 7

During tape/CD playback:

(1) INTRO button 6, 13 (2) REPEAT button 6, 13 (3) SHUF button 14 (5) ATA (Automatic Tuner

Activation) button 6

(6) BL.SKIP button 6

3 SENS/BTM (sensitivity adjust/best

tuning memory function) button 7, 10

4 DSPL (display mode change/time set)

button 5, 6, 7, 8, 13

5 6 (eject) button 5 6 SEEK/AMS button 6, 7, 11, 13 7 PRESET/DISC button 5, 6, 13 8 PTY (programme type) button 10 9 MUTE button 12 0 RELEASE (front panel release) button

4, 15

!¡ SEL (control mode select) button

5, 9, 11, 12

SEEK

AMS

PRESET

DISC

TAPE

PTY

AF/TA

OFF

REW

TUNER

!™ Reset button (located on the front side

of the unit hidden by the front panel)

Press this button when you use this unit for the first time, when you have changed the car battery, or when the buttons of this unit do not function properly.

!£ (+)(–) (volume/bass/treble/balance/

fader control) buttons 5, 12

!¢ Display window !∞ Caution alarm switch (located on the

bottom of the unit)

!§ TUNER (radio on/band select) button 7 !¶ CD (disc play/CD changer select) button

!• TAPE/* (playback/transport direction

change) button 5

!ª OFF button 4, 5 @º AF/TA (alternative frequency/traffic

announcement) button 8, 9, 10

Depending on the car, you cannot use RELEASE !º and Reset !™ buttons.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Specifications

Cassette player section

Tape track 4-track 2-channel stereo Wow and flutter 0.08 % (WRMS) Frequency response 30 – 18,000 Hz Signal-to-noise ratio 58 dB

Tuner section

Tuning range 87.5 – 108.0 MHz Aerial terminal External aerial connector Intermediate frequency 10.7 MHz Usable sensitivity 8 dBf Selectivity 75 dB at 400 kHz Signal-to-noise ratio 65 dB (stereo),

68 dB (mono)

Harmonic distortion at 1 kHz

0.5 % (stereo),

0.3 % (mono) Separation 35 dB at 1 kHz Frequency response 30 – 15,000 Hz Capture ratio 2 dB

MW/LW

Tuning range MW: 531 – 1,602 kHz

LW: 153 – 281 kHz Aerial terminal External aerial connector Intermediate frequency 10.71 MHz/450 kHz Sensitivity MW: 30 µV

LW: 50 µV

Power amplifier section

Outputs Speaker outputs

(sure seal connectors) Speaker impedance 4 – 8 ohms Maximum power output 20 W × 4 (at 4 ohms)

General

Tone controls Bass ±8 dB at 100 Hz

Power requirements 12 V DC car battery Dimensions Approx. 188 × 58 × 177 mm Mounting dimension Approx. 182 × 53 × 155 mm

Mass Approx. 1.2 kg Supplied accessories Front panel case (1)

Optional accessories Bus cable (supplied with

Optional equipment Source selector XA-C30

Design and specifications are subject to change without notice.

Treble ±8 dB at 10 kHz

(negative ground)

(w/h/d)

Rotary remote (1) Interface box (1) Bus cable 5.5 m (1) RCA pin cord 5.5 m (1)

an RCA pin cord) RC-61 (1 m), RC-62 (2 m)

CD changer CDX-51, CDX-45, CDX-65

Additional Information

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Troubleshooting guide

The following check will assist in the correction of most problems which you may encounter with your unit. Before going through the check list below, refer to the operating procedures.

General

Problem

No sound

Indications do not appear on the display window.

Tape playback

Problem

Playback sound is distorted.

The AMS does not operate correctly.

Cause/Solution

• Adjust the volume with (+).

• Set the fader control to the centre position on the 2-speaker

system.

Remove the front panel and clean the connectors. See “Cleaning the Connectors” of “Maintenance” for details. If the front panel is fixed to the unit, consult your nearest VAG dealer.

Cause/Solution

Contamination of the tape head. n Clean the head.

• There is a noise in the space between tracks.

• A blank space is too short (less than four seconds).

• + on (SEEK/AMS) is pressed immediately before the

following track.

• = on (SEEK/AMS) is pressed immediately after the track

starts.

• A long pause, or a passage of low frequencies or very low

sound level is treated as a blank space.

Radio reception

Problem

Preset tuning is not possible.

Automatic tuning is not possible.

The “ST” indication flashes.

RDS functions

Problem

A SEEK starts after a few seconds of listening.

No traffic announcements

PTY displays “NONE”.

Cause/Solution

• Memorise the correct frequency.

• The broadcast is too weak.

The broadcast is too weak. n Use the manual tuning.

• Tune in precisely.

• The broadcast is too weak. n Press (SENS/BTM) to enter the

MONO mode.

Cause/Solution

The station is non-TP or weaken signal.

n Press (AF/TA) until “AF TA” disappears.

• Activate “TA”.

• The station does not broadcast any traffic announcements

despite being TP. n Tune in another station.

The station does not specify the programme type.

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Disc play

Problem

Playback sound skips.

Error displays (with the optional CD changer(s) connected)

The following indications will flash for about five seconds.

Cause/Solution

A dusty or defective disc.

Display Cause

NO MAG

NO DISC

ERROR

RESET

HI TEMP

If the above-mentioned solutions do not help to improve the situation, consult your nearest VAG dealer.

A disc magazine is not inserted in the CD changer.

No disc is inserted in the disc magazine.

The disc is dirty.

The disc is inserted upside down.

The CD changer cannot be operated because of some problem.

The ambient temperature is more than

50°C.

Solution

Insert a disc magazine with discs into the CD changer.

Take out the magazine and insert the discs.

Clean the disc.

Insert the disc correctly.

Press the reset button on the unit. If the front panel is fixed to the unit, consult your nearest VAG dealer.

Wait until the temperature goes down

below 50°C.

Additional Information

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Index

Alternative Frequencies (AF) 8 Automatic Music Sensor (AMS) 6, 13 Automatic tuning 7 Automatic Tuner Activation (ATA) 6

Balance 12 Bass 12 Best Tuning Memory (BTM) 7 Blank skip 6

Caution alarm 4 CD playback 13 Clock 5

D, E

Display 6, 7, 8, 13, 14

F, G, H

Fader 12 Fast-forward 5 Front panel 4

I, J, K

Intro scan 6, 13

Radio 7 Radio Data System (RDS) 8, 9, 10, 11 Repeat play 6, 13 Reset 4 Rewind 5 Rotary remote 4, 11, 12

Shuffle play 14

T, U, V, W, X, Y, Z

Tape playback 5 Traffic Announcement (TA) 9 Traffic Programme (TP) 9 Treble 12

Local seek mode (LCL) 7 Loudness 12

M, N, O

Manual search 13 Manual tuning 7 Mute 12

P, Q

Programme Type (PTY) 10

Sony Corporation Printed in France

Actual total number: Sony XR-6859RDS (E) 3-858-436-11 (1)

Sony XR-6859RDS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
