Sony XAV-70BT Users guide

AV Center

4-164-314-43 (1)

XAV-70BT

Operating Instructions

Be sure to install this unit in the dashboard of the car for safety. For installation and connections, see the supplied installation/ connections manual.

Warning

To prevent fire or shock hazard, do not expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this CD/DVD player is harmful to eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

This label is located on the bottom of the chassis.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment

and receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

This equipment complies with FCC and IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated with at least 20 cm and more between the radiator and person’s body (excluding extremities: hands, wrists, feet and ankles).

Note on the lithium battery

Do not expose the battery to excessive heat such as direct sunlight, fire or the like.

Warning if your car’s ignition has no ACC position

Be sure to set the Auto Off function (page 50). The unit will shut off completely and automatically in the set time after the unit is turned off, which prevents battery drain. If you do not set the Auto Off function, press and hold (SOURCE/OFF) until the display disappears each time you turn the ignition off.

To cancel the demonstration (Demo) display, see page 53.

Table of Contents

Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . 6

Notes on installation . . . . . . . . . . . . . . . . . . . . . 6

Copyrights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Notes on Bluetooth . . . . . . . . . . . . . . . . . . . . . . 8

Playable discs and symbols used in this

manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Location and function of controls . . . . . . . . . . 10

Main unit. . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Card remote commander RM-X170 . . . . . . 12

Getting Started

Resetting the unit. . . . . . . . . . . . . . . . . . 14

Performing initial settings. . . . . . . . . . . 14

Preparing the card remote

commander. . . . . . . . . . . . . . . . . . . . . . . 14

Basic Operations

Listening to the radio . . . . . . . . . . . . . . 15

Playing discs . . . . . . . . . . . . . . . . . . . . . 17

Advanced Operations — Radio

Storing and receiving stations . . . . . . . . . . . . . 21

Storing automatically — BTM . . . . . . . . . . 21

Storing manually. . . . . . . . . . . . . . . . . . . . . 21

Receiving stored stations . . . . . . . . . . . . . . 21

RDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Selecting PTY. . . . . . . . . . . . . . . . . . . . . . . 22

Setting CT. . . . . . . . . . . . . . . . . . . . . . . . . . 22

Advanced Operations — Discs

Using PBC functions — Playback control . . . 22

Configuring audio settings . . . . . . . . . . . . . . . 22

Changing the audio language/format . . . . . 23

Changing the audio channel. . . . . . . . . . . . 23

Adjusting the audio output level

— Dolby D level . . . . . . . . . . . . . . . . . . . . 23

Locking discs — Parental control. . . . . . . . . . 24

Activating parental control. . . . . . . . . . . . . 24

Changing the area and its movie rating

level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Repeat and shuffle play. . . . . . . . . . . . . . . . . . 24

Direct search play . . . . . . . . . . . . . . . . . . . . . . 25

USB Device Operations

Playing a USB device . . . . . . . . . . . . . . . . . . . 26

Repeat and shuffle play. . . . . . . . . . . . . . . . . . 26

Enjoying music according to your mood

— SensMe™. . . . . . . . . . . . . . . . . . . . . . . . . . 27

Before using the SensMe™ function . . . . . 27

Installing “SensMe™ Setup” and “Content

Transfer” in your computer . . . . . . . . . . . . 27

Registering a USB device using “SensMe™

Setup”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Transferring tracks to the USB device using

“Content Transfer”. . . . . . . . . . . . . . . . . . . 28

Playing tracks in the channel

— SensMe™ channels. . . . . . . . . . . . . . . . 28

Playing tracks in the mood map

— SensMe™ mood . . . . . . . . . . . . . . . . . . 30

iPod Operations

Playing an iPod . . . . . . . . . . . . . . . . . . . . . . . . 31

Setting the play mode . . . . . . . . . . . . . . . . . . . 31

Repeat and shuffle play. . . . . . . . . . . . . . . . . . 32

Operating an iPod directly

— Passenger control . . . . . . . . . . . . . . . . . . . . 32

continue to next page t

Useful Functions

Sound Adjustment

Listing up tracks/images/video files

— List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Selecting a track/image/video file . . . . . . . .33

Selecting a file type . . . . . . . . . . . . . . . . . . .33

Searching a track by listening to track passages

— ZAPPIN™. . . . . . . . . . . . . . . . . . . . . . . . . .33

Using Gesture Command . . . . . . . . . . . . . . . . .34

Handsfree Calling and Audio Streaming — Bluetooth

Before using the Bluetooth function . . . . . . . .34

Basic procedure of the Bluetooth

function . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Bluetooth status indication . . . . . . . . . . . . .35

Installing the external microphone

XA-MC10 . . . . . . . . . . . . . . . . . . . . . . . . . .35

Pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Searching from this unit . . . . . . . . . . . . . . .35

Searching from the Bluetooth device . . . . .36

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Handsfree calling . . . . . . . . . . . . . . . . . . . . . . .37

Making calls . . . . . . . . . . . . . . . . . . . . . . . .37

Receiving calls. . . . . . . . . . . . . . . . . . . . . . .39

Operations during a call. . . . . . . . . . . . . . . .39

Phonebook management . . . . . . . . . . . . . . . . .40

Storing phonebook data. . . . . . . . . . . . . . . .40

Browsing a phonebook in a cellular

phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Deleting phonebook data. . . . . . . . . . . . . . .41

Editing a contact . . . . . . . . . . . . . . . . . . . . .41

Call data management . . . . . . . . . . . . . . . . . . .42

Call history . . . . . . . . . . . . . . . . . . . . . . . . .42

Preset dial . . . . . . . . . . . . . . . . . . . . . . . . . .42

Locking the personal information . . . . . . . .43

Audio streaming. . . . . . . . . . . . . . . . . . . . . . . .43

Listening to a Bluetooth device through

this unit . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Operating the Bluetooth device with

this unit . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Bluetooth settings. . . . . . . . . . . . . . . . . . . . . . .43

Selecting the sound quality — EQ7 . . . . . . . . 44

Customizing the equalizer curve

— EQ7 Tune. . . . . . . . . . . . . . . . . . . . . . . . 44

Adjusting the sound characteristics . . . . . . . . . 45

Optimizing sound for the listening position

— Intelligent Time Alignment . . . . . . . . . . . . 45

Precisely calibrating the listening position

— Intelligent Time Alignment Tune . . . . . 46

Speaker configuration and volume setup . . . . 46

Creating a virtual center speaker

— CSO . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using rear speakers as subwoofer

— RBE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Adjusting the speaker volume. . . . . . . . . . . 47

Monitor Adjustment

Adjusting the monitor angle . . . . . . . . . . . . . . 47

Touch panel calibration . . . . . . . . . . . . . . . . . . 47

Setting the background screen. . . . . . . . . . . . . 48

Selecting the picture quality

— Picture EQ . . . . . . . . . . . . . . . . . . . . . . . . . 48

Customizing the picture quality . . . . . . . . . 48

Selecting the aspect ratio. . . . . . . . . . . . . . . . . 49

Settings

Basic setting operation . . . . . . . . . . . . . . . . . . 49

General settings . . . . . . . . . . . . . . . . . . . . . . . . 50

Sound settings . . . . . . . . . . . . . . . . . . . . . . . . . 52

Screen settings. . . . . . . . . . . . . . . . . . . . . . . . . 53

DVD and other playback settings . . . . . . . . . . 54

Setting the security code . . . . . . . . . . . . . . . . . 57

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . 57

Using Optional Equipment

Auxiliary audio/video equipment . . . . . . . . . . 57

Rear view camera . . . . . . . . . . . . . . . . . . . . . . 58

Rear view camera settings . . . . . . . . . . . . . 58

Additional Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Notes on LCD panel . . . . . . . . . . . . . . . . . . 59

Notes on discs . . . . . . . . . . . . . . . . . . . . . . . 59

Playback order of MP3/WMA/AAC/JPEG/

/MPEG-4 files . . . . . . . . . . . . . . . . . 60

DivX

About MP3 files . . . . . . . . . . . . . . . . . . . . . 60

About WMA files . . . . . . . . . . . . . . . . . . . . 60

About AAC files . . . . . . . . . . . . . . . . . . . . . 60

About JPEG files . . . . . . . . . . . . . . . . . . . . 60

About DivX video. . . . . . . . . . . . . . . . . . . . 60

About DivX Video-on-Demand . . . . . . . . . 61

About MPEG-4 files . . . . . . . . . . . . . . . . . . 61

About iPod . . . . . . . . . . . . . . . . . . . . . . . . . 61

About Bluetooth function . . . . . . . . . . . . . . 61

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Removing the unit . . . . . . . . . . . . . . . . . . . . . . 62

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 63

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . 64

Error displays/messages . . . . . . . . . . . . . . . 67

Language code/area code list. . . . . . . . . . . . . . 69

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Support site

If you have any questions or for the latest support information on this product, please visit the web site below:

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

Provides information on:

• Models and manufacturers of compatible digital audio players

• Models and manufacturers of compatible cellular phones and the FAQ about Bluetooth function

Notes on safety

Notes on installation

• Comply with your local traffic rules, laws and regulations.

• While driving – Do not watch or operate the unit, as it may lead

to distraction and cause an accident. Park your car in a safe place to watch or operate the unit.

– Do not use the setup feature or any other

function which could divert your attention from the road.

– When backing up your car, be sure to

look back and watch the surroundings carefully for your safety, even if the rear view camera is connected. Do not depend on the rear view camera exclusively.

• While operating – Do not insert your hands, fingers or foreign

object into the unit while functioning, as it may

cause injury or damage to the unit. – Keep small articles out of the reach of children. – Be sure to fasten seatbelts to avoid injury in the

event of a sudden movement of the car.

Preventing an accident

Pictures appear only after you park the car and set the parking brake. If the car starts moving during video playback, the picture is automatically switched to the background screen after displaying the caution below.

“Video blocked for your safety.”

The monitor connected to the REAR VIDEO OUT is active while the car is in motion. The picture on the display is switched to the background screen, but audio source can be heard.

Do not operate the unit or watch the monitor while driving.

• We recommend this unit should be installed by a qualified technician or service personnel. – If you try to install this unit by yourself, see the

supplied installation/connections manual and install the unit properly.

– Improper installation may cause battery drain or

a short circuit.

• If the unit does not work properly, check the connections first, referring to the supplied installation/connections manual. If everything is in order, check the fuse.

• Protect the unit surface from damage. – Do not expose the unit surface to chemicals,

such as insecticide, hair spray, insect repellent, etc.

– Do not leave rubber or plastic materials in

contact with the unit for a long time. Otherwise, the finish of the unit may be impaired, or deformation may occur.

• When installing, be sure to fix securely.

• When installing, be sure to turn the ignition off. Installing the unit with the ignition on may cause battery drain or a short circuit.

• When installing, be sure not to damage any car parts such as pipes, tubes, fuel tank or wiring by using a drill, as it may cause a fire or an accident.

Copyrights

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories.

symbol are trademarks of Dolby Laboratories.

United States and/or other countries.

“DVD VIDEO,” “DVD-R,” “DVD-RW,” “DVD+R,” and “DVD+RW” are trademarks.

The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners.

ZAPPIN is a trademark of Sony Corporation.

“Dolby” and the double-D

Microsoft, Windows, Windows Vista and Windows Media and logos are trademarks or registered trademarks of Microsoft Corporation in the

, DivX Certified® and

DivX associated logos are registered trademarks of DivX, Inc.

12 TONE ANALYSIS and its logo are trademarks of Sony Corporation.

“WALKMAN” and “WALKMAN” logo are registered trademarks of Sony Corporation.

SensMe and the SensMe logo are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB.

Music recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music recognition technology and related content delivery. For more information, please visit www.gracenote.com.

CD and music-related data from Gracenote, Inc., copyright © 2000-2010 Gracenote. Gracenote Software, copyright © 2000-2010 Gracenote. This product and service may practice one or more of the following U.S. Patents: #5,987,525; #6,061,680; #6,154,773, #6,161,132, #6,230,192, #6,230,207, #6,240,459, #6,330,593, and other patents issued or pending. Some services supplied under license from Open Globe, Inc. for U.S. Patent: #6,304,523.

Gracenote and CDDB are registered trademarks of Gracenote. The Gracenote logo and logotype, and the “Powered by Gracenote” logo are trademarks of Gracenote.

This product uses font data which is licensed to Sony by Monotype Imaging Inc. or its affiliates.

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPhone is a trademark of Apple Inc.

Apple, Macintosh and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER FOR DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, LLC. SEE HTTP://WWW.MPEGLA.COM

Notes on Bluetooth

Caution

IN NO EVENT SHALL SONY BE LIABLE FOR ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR OTHER DAMAGES INCLUDING, WITHOUT LIMITATION, LOSS OF PROFITS, LOSS OF REVENUE, LOSS OF DATA, LOSS OF USE OF THE PRODUCT OR ANY ASSOCIATED EQUIPMENT, DOWNTIME, AND PURCHASER’S TIME RELATED TO OR ARISING OUT OF THE USE OF THIS PRODUCT, ITS HARDWARE AND/OR ITS SOFTWARE.

IMPORTANT NOTICE!

Safe and efficient use

Changes or modifications to this unit not expressly approved by Sony may void the user’s authority to operate the equipment. Please check for exceptions, due to national requirement or limitations, in usage of Bluetooth equipment before using this product.

Driving

Check the laws and regulations on the use of cellular phones and handsfree equipment in the areas where you drive. Always give full attention to driving and pull off the road and park before making or answering a call if driving conditions so require.

Connecting to other devices

When connecting to any other device, please read its user guide for detailed safety instructions.

Radio frequency exposure

RF signals may affect improperly installed or inadequately shielded electronic systems in cars, such as electronic fuel injection systems, electronic antiskid (antilock) braking systems, electronic speed control systems or air bag systems. For installation or service of this device, please consult with the manufacturer or its representative of your car. Faulty installation or service may be dangerous and may invalidate any warranty that may apply to this device. Consult with the manufacturer of your car to ensure that the use of your cellular phone in the car will not affect its electronic system. Check regularly that all wireless device equipment in your car is mounted and operating properly.

Emergency calls

This Bluetooth car handsfree and the electronic device connected to the handsfree operate using radio signals, cellular, and landline networks as well as user-programmed function, which cannot guarantee connection under all conditions. Therefore do not rely solely upon any electronic device for essential communications (such as medical emergencies). Remember, in order to make or receive calls, the handsfree and the electronic device connected to the handsfree must be switched on in a service area with adequate cellular signal strength. Emergency calls may not be possible on all cellular phone networks or when certain network services and/or phone features are in use. Check with your local service provider.

Playable discs and symbols used in this manual

This unit can play various video/audio discs. The following chart helps you to check if a disc is supported by this unit, as well as what functions are available for a given disc type.

Disc symbol in manual Disc format

DVD VIDEO

DVD-R*

/ DVD-R DL*1 / DVD-RW*

(Video mode/VR mode)

VIDEO

DVD+R*

/ DVD+R DL*1 / DVD+RW*

Video CD

(Ver. 1.0/1.1/2.0)

Audio CD

AUDIO

*1 Audio files can also be stored. *2 Video/image files can also be stored.

Note

“DVD” may be used in this manual as a general term for DVD VIDEOs, DVD-Rs/DVD-RWs, and DVD+Rs/ DVD +RWs.

CD-ROM*

/ CD-R*2 / CD-RW*

The following chart shows the supported compression formats and their file types. Available functions differ depending on the format, regardless of disc type. The format symbols below appear next to the description of functions available for that format.

Format symbol in manual File type

MP3 audio file

WMA audio file

AAC audio file

JPEG image file

DivX

video file

MPEG-4

Tip

For details on compression formats, see page 60.

Note

Even compatible discs may not be playable on this unit, depending on their recorded condition.

MPEG-4 video file

Location and function of controls

6 7 8 9

Main unit

VOL

2 3 4 5

Refer to the pages listed for details.

A Disc slot (located behind the front panel)

page 17

B VOL (Volume) –/+* buttons

C Receptor for the card remote

commander

D Display window/touch panel

E Reset button page 14

F (Bluetooth) signal indicator

page 35

TOP

G TOP button

To open the top menu.

H SOURCE/OFF button

Press to turn on the power/change the source: “Tuner” (Radio), “Disc,” “AUX” (Auxiliary equipment), “USB/iPod,” “BT Audio” (Bluetooth Audio). Press for 1 second to turn off the power. Press for more than 2 seconds to shut off completely.

I Z (Open/Close) button page 17

* The VOL + button has a tactile dot.

OFFSOURCE

Screen displays

When no source is selected:

A “Source List” key

To open the source list.

B “Top” key

To open the top menu.

Source List

Top menu:

45 67

ATT

AV Source BT Phone

Source list:

Top

12:00

M.OFF

12:00

C Clock display page 53, 57

D (Close) key

To close the menu.

E “ATT” (Attenuate) key*

To attenuate the sound. To cancel, touch again.

F (Setting) key

To open the setting menu.

G “M.OFF” (Monitor off) key

To turn off the monitor and the button illumination. To turn back on, touch anywhere on the display.

H “AV Source” key

To open the source list.

I “BT Phone” key

To enter the Bluetooth Phone mode.

J Source select keys

To change the source: “Tuner” (Radio), “Disc,” “AUX” (Auxiliary equipment), “USB/iPod,” “SensMe™,” “BT Audio” (Bluetooth Audio).

* Appears only when a source is selected.

45 62

ATT

Tuner Disc

USB/iPod

SensMe™

AUX

BT Audio

Top

12:00

Card remote commander RM-X170

8 9 q;

3 4

• The card remote commander can be generally used to operate the audio controls simply. For menu operations, use the touch panel.

• Refer to the pages listed for details.

• Remove the insulation film before use (page 14).

A OFF button

Press to turn off/stop the source. Press and hold to shut off completely.

B MONITOR OFF button

To turn off the monitor and the button illumination. To turn back on, press again.

qs qd

qf qg

E EQ (Equalizer) button

To select an equalizer curve from 7 music types (“Xplod”/“Vocal”/“Edge”/“Cruise”/ “Space”/“Gravity”/“Custom”/“OFF”).

F Number buttons page 25

Radio:

Press to receive stored stations. Press and hold to store stations.

Disc/USB:

To locate a title/chapter/track.

G CLEAR button

To delete an entered number.

C POSITION button

To switch the listening position (“Front L”/ “Front R”/“Front”/“All”/“Custom”/“OFF”).

D O (Return) button

To return to the previous display/return to the menu on a VCD*

H ATT (Attenuate) button

To attenuate the sound. To cancel, press again.

I u (Play/Pause) button

J .m/M> buttons

Radio:

Press to tune in stations automatically. Press and hold to find a station manually.

Disc*

/USB:

Press to skip a chapter/track/scene/file. Press and hold momentarily to reverse/fastforward the video. Press and hold to reverse/fast-forward track. Bluetooth Audio*

Press to skip a track. Press and hold to reverse/fast-forward track.

K DVD playback setting buttons

(AUDIO):

To change the audio language/format. (For VCD/CD/MP3/WMA/AAC/MPEG-4, to change the audio channel.)

(SUBTITLE):

To change the subtitle language.

(ANGLE):

To change the viewing angle.

(TOP MENU):

To open the top menu on a DVD.

(MENU):

To open the menu on a disc.

L ZAP button

To enter the ZAPPIN™ mode.

M </M/m/, (Cursor)/ENTER buttons

page 17

To control the menu on a DVD.

*1 When playing with PBC function. *2 Operation differs depending on the disc (page 19). *3 Operation differs depending on the connected

Bluetooth device.

*4 When two auxiliary devices are used.

Note

If the unit is turned off and the display disappears, it cannot be operated with the card remote commander unless (SOURCE/OFF) on the main unit is pressed, or a disc is inserted to activate the unit first.

N SRC (Source) button

To turn on/change the source: “Tuner” (Radio), “Disc,” “AUX” (Auxiliary equipment), “USB/iPod,” “BT Audio” (Bluetooth Audio).

O MODE button

Press to select the radio band (FM/AM)/ select an auxiliary device (AUX1/AUX2)*

P VOL (Volume) +/– buttons

Getting Started

Resetting the unit

Before operating the unit for the first time, or after replacing the car battery or changing the connections, you must reset the unit. Press the reset button (page 10) with a pointed object, such as a ball-point pen.

Note

Pressing the reset button will erase the clock setting and some stored contents.

Performing initial settings

After resetting, the display for the initial settings appears.

Initial Setting

Subwoofer

Listening Position

Language

1 Touch “Subwoofer” to set the

subwoofer connection status.

Set to “ON” if a subwoofer is connected, or “OFF” if not.

2 Touch “Listening Position” to set the

listening position.

Set to “Front L” if your listening position is front left, or “Front R” if front right.

3 Touch “Language” to set the display

language.

Touch repeatedly until the desired language (English/Spanish/Russian) appears.

4 Touch “OK.”

The setting is complete.

This setting can then be further configured in the setting menu.

• For details on setting the subwoofer connection status, see page 52.

• For details on setting the listening position, see “Optimizing sound for the listening position — Intelligent Time Alignment” on page 45.

• For details on setting the display language, see page 50.

OFF / ON

Front L / Front R

English

Preparing the card remote commander

Before using the card remote commander for the first time, remove the insulation film.

Basic Operations

Listening to the radio

Touch “Source List,” then “Tuner.”

From the top menu, touch “AV Source,” then “Tuner.” The radio reception display appears.

Touch “Band.”

The band list appears.

Source List

ATT

P1 P2 P3

P4 P5 P6

Band

ATT

Receive

Preset

List

BTM

Memory

Top

PTY List

12:0015

Top

FM2 FM3 AM2

FM1

Receive

Band

Touch the desired band (“FM1,” “FM2,” “FM3,” “AM1” or “AM2”).

Touch “Band” to close the band list.

Perform tuning.

To tune automatically

Touch

./>.

Scanning stops when the unit receives a station. Repeat this procedure until the desired station is received.

To tune manually

Touch

m/M repeatedly until the desired frequency is received.

To skip frequencies continuously, touch and hold

m/M.

continue to next page t

AM1

Preset

List

PTY List

12:0015

Reception controls

2 3

Touch the display if the reception controls are not shown.

Source List

456

ATT

Receive

Band

7 8 9

Preset

List

Top

PTY

List

12:0015

No. Item Touc h to

1 “Source List” open the source list. (page 11)

2 “ATT” attenuate the sound. To cancel, touch again.

3 “Top” open the top menu. (page 11)

4 m/M tune manually.

Touch and hold to skip frequencies continuously.

5 ./> tune automatically.

6 “Band” open the band list and change the band.

7 “Receive Menu” open the receive menu, which contains the following.

• “Mono”: Touch to activate the monaural mode if FM reception

is poor. To restore stereo reception, select “OFF.”

• “Local”: Touch to only tune into stations with stronger signal.

To tune normal stations, select “OFF.”

8 “Preset List” list up stored stations, or store stations. (page 21)

9 “PTY List” open the PTY list. (page 22)

Indications during reception

ATT

Receive

Band

Source List

Preset

List

A Current source icon* B Band number, Preset number*2, Frequency/status

Top

C Volume level* D Setting status (CSO, EQ7, RBE)

*1 Appears only when the controls are shown. *2 Appears only when the station stored in memory is

received.

*3 When ATT is activated, appears.

PTY List

12:0015

Playing discs

Depending on the disc, some operations may be different or restricted. Refer to the operating instructions supplied with your disc.

Press Z on the main unit.

The front panel opens automatically.

Insert the disc (label side up).

The front panel closes automatically, then playback starts.

If the DVD menu appears

Touch the item in the DVD menu directly. You can also use the menu control panel which can be shown by touching the display in a place other than menu item area. Touch b/v/V/B to move the cursor, then “Enter” to confirm. If the menu control panel does not appear by touching the display, use the card remote commander.

About the DVD menu

A DVD is divided into several sections, which make up a picture or music feature. These sections are called “titles.” When you play a DVD that contains several titles, you can select a desired title using the DVD’s top menu. For DVDs that allow you to select items such as subtitle/sound language(s), select these items using the DVD menu.

If the disc contains JPEG files

The slide show starts automatically.

To stop playback

Press (SOURCE/OFF) for 1 second.

Note

Discs in DTS format are not supported. The sound is not output if the DTS format is selected.

To eject the disc

1 Press Z on the main unit.

The front panel opens automatically, then the disc is ejected.

2 Press Z on the main unit to close the front panel.

Note

The front panel closes automatically after the caution alarm sounds.

continue to next page t

Playback controls

2 3

Touch the display if the playback controls are not shown.

Common to all discs/formats

Source List

ATT Top

Play Menu

DVD

SHUF

Control

ATT Top

PBC Panel

Play Menu

SHUF

ATT

Source List

12:0015

ATT Top

Play Menu

DVD

SHUF

Control

12:0015

MPEG-4

Source List

12:0015

ATT

Album

List

Top

Play Menu

SHUF

12:0015

Top

Album

ZAP

SHUF

12:0015

Play Menu

List

No. Item Touc h to

1 “Source List” open the source list. (page 11)

2 “ATT” attenuate the sound. To cancel, touch again.

3 “Top” open the top menu. (page 11)

No. Item Touch to

4 ./> skip a chapter/track/scene/image/file.

Touch and hold momentarily to reverse/fast-forward the video; and then repeatedly to switch the speed (× 2 t ×12 t ×120 t ×2…)*

. To cancel, touch u.

Touch and hold to reverse/fast-forward the audio track.

During pause, touch and hold down > to play the video in slow motion. To cancel, release the key.

5 u pause/resume play after pause.

6 “Play Menu” open the play menu, which contains the following.

• “Repeat”/“Shuffle” (page 24)

• “Dolby D Level” (DVD VIDEO playback only) (page 23)

• “Stereo” (VCD/CD/MP3/WMA/AAC playback only)

(page 23)

• “Image Turn” (JPEG playback only): Touch to rotate an

image left/right.

• “Audio” (DivX/MPEG-4 playback only) (page 23)

• “Subtitle” (DivX playback only): Touch repeatedly to turn off/

select the subtitle language.*2*

7 “DVD Control” open the DVD control menu, which contains the following.

• “Audio”: Touch repeatedly to select the audio language/

format. (page 23)*

• “Subtitle”: Touch repeatedly to turn off/select the subtitle

language.*

• “Angle”: Touch repeatedly to change the viewing angle.*

• “Top Menu”: Touch to open the top menu on the DVD.*

• “Menu”: Touch to open the menu on the disc.*

2*3

8 “PBC Panel” show the control panel for the PBC menu. (page 22)

9 “Album” –/+ skip an album (folder) of MP3/WMA/AAC/JPEG/DivX/

MPEG-4.

0 “List” list up tracks/images/video files. (page 33)

qa “ZAP” enter the ZAPPIN mode. (page 33)

*1 The speed depends on the format or the recording method. *2 Unavailable depending on the disc. *3 When the 4-digit input prompt appears, input the language code (page 69) for the desired language.

Note

If the disc contains multiple file types, only the selected file type (audio/video/image) can be played. For details on how to select the file type, see “Selecting a file type” on page 33.

Notes on JPEG playback

• If a large-sized image is rotated, it may take longer to display.

• Progressive JPEG files cannot be displayed.

continue to next page t

Indications during playback

D E F

Touch the display to show the indications. For audio discs, some indications are always shown during playback.

Source List

ATT

B C

ATT

Album

MPEG-4

Top

A Current source icon B Volume level* C Format, Playback status, Elapsed playback

time* number* (CSO, EQ7, RBE)

D Playback status, Elapsed playback time* E Track name, Album name, Artist name F Album artwork display*

, Chapter/title/album (folder)/track

3*4

, Audio Format*5, Setting status

G Format, Track number, Album number*7, Setting

DVD

Play Menu

Control

SHUF

12:0015

Top

Play Menu

List

ZAP

SHUF

12:0015

status (CSO, EQ7, RBE)

*1 When ATT is activated, appears. *2 During JPEG playback or VCD playback with the PBC

function, no indication appears.

*3 Indications differ depending on the disc/format. *4 When playing a VCD with the PBC function (page 22),

no indication appears.

*5 DVD/DivX only. *6 The recommended size is from 240 × 240 to 960 × 960

pixels.

*7 MP3/WMA/AAC only.

Advanced Operations — Radio

RDS

Storing and receiving stations

Caution

When tuning in stations while driving, use Best Tuning Memory (BTM) to prevent an accident.

Storing automatically — BTM

1 Touch “Source List,” then “Tuner.”

To change the band, touch “Band,” then select the desired band (“FM1,” “FM2,” “FM3,” “AM1” or “AM2”).

2 Touch “Preset List,” then “BTM.”

The unit stores stations in order of frequency in the preset list (“P1” to “P6”). A beep sounds when the setting is stored.

Storing manually

1 While receiving the station that you

want to store, touch “Preset List.”

2 Touch “Memory,” then touch the

number in the list (“P1” to “P6”).

The number and the confirmation display appear on the display.

3 Tou ch “ Yes.”

The station is stored.

Note

If you try to store another station on the same number, the previously stored station will be replaced.

Overview

FM stations with Radio Data System (RDS) service send inaudible digital information along with the regular radio program signal.

Display items

, RDS*

ATT

Receive

Band

Source List

A Band number, Preset number, Frequency B Stereo* C Program service name D Clock display

*1 During FM reception. *2 During RDS reception.

Preset

List

Top

PTY List

12:0015

RDS services

This unit automatically provides RDS services as follows:

Receiving stored stations

1 Select the band, then touch “Preset

List.”

2 Touch the desired number (“P1” to

“P6”).

PTY (Program Types)

Displays the currently received program type. Also searches your selected program type.

CT (Clock Time)

The CT data from the RDS transmission sets the clock.

Notes

• Depending on the country/region, not all RDS functions may be available.

• RDS will not work if the signal strength is too weak, or if the station you are tuned to is not transmitting RDS data.

Selecting PTY

1 During FM reception, touch “PTY List.”

The PTY list appears if the station is transmitting PTY data. To scroll the list, touch v/V.

2 Touch the desired program type.

The unit searches for a station broadcasting the selected program type.

To close the PTY list, touch “PTY List.”

Type of programs

“News” (News), “Current Affairs” (Current Affairs), “Information” (Information), “Sport” (Sports), “Education” (Education), “Drama” (Drama), “Cultures” (Culture), “Science” (Science), “Varied Speech” (Varied), “Pop Music” (Pop Music), “Rock Music” (Rock Music), “Easy Listening”

(M.O.R. Music), “Light Classics M” (Light classical), “Serious Classics” (Serious classical), “Other Music” (Other Music), “Weather & Metr” (Weather), “Finance” (Finance), “Children’s Progs” (Children’s program), “Social Affairs” (Social Affairs), “Religion” (Religion), “Phone In” (Phone In), “Travel & Touring” (Travel), “Leisure & Hobby” (Leisure), “Jazz Music” (Jazz Music), “Country Music” (Country Music),

“National Music” (National Music), “Oldies Music” (Oldies Music), “Folk Music” (Folk Music), “Documentary” (Documentary)

Notes

• You cannot use this function in countries/regions where no PTY data is available.

• You may receive a different radio program from the one you select.

Setting CT

1 Set “CT” to “ON” in setting (page 50).

Notes

• The CT function may not work even though an RDS station is being received.

• There might be a difference between the time set by the CT function and the actual time.

Advanced Operations — Discs

Using PBC functions — Playback control

The PBC menu interactively assists with operations while a PBC compatible VCD is played.

1 Start playing a PBC compatible VCD.

The PBC menu appears.

2 Touch “PBC Panel.”

The menu control panel appears.

3 Touch the number keys to select the

desired item, then “Enter.”

4 Follow the instructions in the menu for

interactive operations.

To return to the previous display, press O. To hide the controls, touch “Close.”

Playing without the PBC function

1 While the unit is off, touch “Source

List,” then .

2 Touch “Visual.”

The visual setting menu appears.

3 Touch v/V to scroll, then “Video CD

PBC” to set to “OFF.”

4 Start playing a VCD.

The PBC menu does not appear during playback.

Notes

• The items on the menu, and operation procedures differ depending on the disc.

• During PBC playback, the track number, playback item, etc., do not appear in the playback display.

• Resume playback is unavailable during playback without PBC.

Configuring audio settings

Note

Discs in DTS format are not supported. The sound is not output if the DTS format is selected.

Changing the audio language/ format

For DVD, the audio language can be changed if the disc is recorded with multilingual tracks. For DVD/DivX, you can change the audio format when playing a disc recorded in multiple audio formats (e.g., Dolby Digital).

For DVD

1 During playback, touch “DVD Control.” 2 Touch “Audio” repeatedly until the

desired audio language/format appears.

Audio language

Source List

Audio 1: English Dolby D 3/2.1

Audio Subtitle Angle MenuTop Menu

ATT

DVD

Control

Audio format/channel numbers*

Top

Play Menu

SHUF

12:0015

The audio language switches among the available languages. When the 4-digit input prompt appears, input the language code (page 69) for the desired language. When the same language is displayed two or more times, the disc is recorded in multiple audio formats.

* The format name and channel numbers appear as

follows. Example: Dolby Digital 5.1 ch

Rear component × 2

Dolby D 3 / 2 . 1

Front component × 2 + Center component × 1

To close the DVD control menu, touch “DVD Control.”

For DivX

1 During playback, touch “Play Menu,”

then “Audio” repeatedly until the desired audio format appears.

To close the play menu, touch “Play Menu.”

LFE component × 1

Changing the audio channel

MPEG-4

When playing VCD/CD/MP3/WMA/AAC/ MPEG-4, you can select the right or left channel sound to listen through both right and left speakers. The options are indicated below.

“2-Ch”: Standard stereo sound (default) “L-Ch”: Left channel sound (monaural) “R-Ch”: Right channel sound (monaural)

For VCD/CD/MP3/WMA/AAC

1 During playback, touch “Play Menu,”

then “Stereo” repeatedly until the desired audio channel appears.

For MPEG-4

1 During playback, touch “Play Menu,”

then “Audio” repeatedly until the desired audio channel appears.

To close the play menu, touch “Play Menu.”

Note

You may not be able to change the audio setting depending on the disc.

Tip

The operation by the card remote commander (pressing (AUDIO) repeatedly) is also available.

Adjusting the audio output level — Dolby D level

You can adjust the audio output level for a DVD recorded in Dolby Digital format, to reduce the volume level differences between disc and source.

1 During playback, touch “Play Menu.” 2 Touch the “Adjust” box to set to “ON.” 3 Touch –/+ repeatedly to adjust the

output level.

The output level is adjustable in single steps, between –10 and +10.

To close the play menu, touch “Play Menu.”

Locking discs — Parental control

* Excluding DVD-R/DVD-R DL/DVD-RW in VR mode.

You can lock a disc, or set playback restrictions according to a predetermined level such as viewer age. Restricted scenes can be blocked or replaced with different scenes when a parental control compatible DVD is played.

Activating parental control

1 While the unit is off, touch “Source

List,” then .

2 Touch “Visual.”

The visual setting menu appears.

3 Touch v/V to scroll, then “DVD

Parental Control.”

The password setting display appears.

4 Touch the number keys to enter your

password, then “OK.”

5 To confirm, touch the number keys to

reenter your password, then “OK.”

The setting is complete.

To delete an entered number, touch “Clear.” To return to the previous display, touch “Back.”

Deactivating parental control

1 Follow steps 1 to 3 above.

The parental unlock display appears.

2 Touch the number keys to enter your current

password. “Parental Unlocked” appears, and the parental control is deactivated.

Changing the password

Deactivate the parental control, then activate again using the new password.

Changing the area and its movie rating level

The restriction levels can be set depending on the area and its movie ratings.

1 While the unit is off, touch “Source

List,” then .

2 Touch “Visual.”

The visual setting menu appears.

3 Touch v/V to scroll, then “DVD

Parental Area.”

When parental control is already activated, the display to enter your password appears. To change the setting, enter your password. The options appear.

4 Touch the desired area to apply its

movie ratings.

When you select “Other,” enter the area code selecting from “Area code list” on page 69, using the number keys.

5 Touch “DVD Parental Rating.”

The options appear. The lower the number, the stricter the restriction level.

6 Touch the desired rating.

The setting is complete.

To return to the previous display, touch “Back.”

Repeat and shuffle play

1 During playback, touch “Play Menu,”

then the “Repeat” or “Shuffle” box repeatedly until the desired option appears.

Source List

ATT

MPEG-4

Top

Chapter OFF ON

Repeat Shuffle Adjust Dolby D Level 0

Repeat or shuffle play starts.

To close the play menu, touch “Play Menu.”

DVD

Control

Play Menu

SHUF

12:0015

The repeat options and switching order of each disc/format are indicated below.

Disc/format Options

“OFF”: Returns to normal play

mode. “Chapter”: Repeats the current chapter. “Title”: Repeats the current title.

“OFF”: Returns to normal play

mode. “Track”: Repeats the current track.

“OFF”: Returns to normal play mode. “Track”: Repeats the current track. “Album”: Repeats the current album (folder).

“OFF”: Returns to normal play mode. “Image”: Repeats the current image. “Album”: Repeats the current album.

“OFF”: Returns to normal play mode. “Movie”: Repeats the current

MPEG-4

video file. “Album”: Repeats the current album (folder).

The shuffle options and switching order of each disc/format are indicated below.

Disc/format Options

“OFF”: Returns to normal play

mode.

“Title”: Plays chapters in current title in random order.

“OFF”: Returns to normal play

mode. “Disc”: Plays tracks in current disc in random order.

“OFF”: Returns to normal play mode. “Album”: Plays tracks/images/ video files in current album (folder) in random order.

*1 Available only when playing version 1.0/1.1 VCD,

or version 2.0 VCD without PBC function.

*2 Excluding DVD-R/DVD-R DL/DVD-RW in VR

mode.

Direct search play

You can directly locate a desired point by specifying the title number, chapter number, etc.

1 During playback, press the number

buttons on the card remote commander to enter an item (track, title, etc.) number, then press (ENTER).

Playback starts from the beginning of the selected point.

The search items of disc/format are as follows.

DVD: Title or chapter* VCD*2/CD/MP3/WMA/AAC: Track JPEG: Image DivX/MPEG-4: File

*1 The search item depends on the setting. *2 Available only when playing a VCD without PBC

function.

Setting the search item (DVD only)

You can set the search item (title or chapter) for DVD playback.

1 Touch “Source List,” then . 2 Touch “Visual.”

The visual setting menu appears.

3 Touch v/V to scroll, then “DVD Direct

Search” to set to “Chapter” or “Title.”

The setting is complete.

To return to the previous display, touch “Back.”

MPEG-4

USB Device Operations

For details on the compatibility of your USB device, visit the support site.

Support site

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

• MSC (Mass Storage Class) and MTP (Media Transfer Protocol) type USB devices compliant with the USB standard can be used.

• Corresponding codec is MP3 (.mp3), WMA (.wma), AAC (.m4a), JPEG (.jpg), DivX (.avi) and MPEG-4 (.mp4).

• Backup of data in a USB device is recommended.

Notes

• Connect the USB device after starting the engine. Depending on the USB device, malfunction or damage may occur if it is connected before starting the engine.

• A large-sized file may take time to start playing back.

Playing a USB device

1 Remove the cap from the USB

connector, and connect the USB device to the USB connector.

Playback starts automatically. If a USB device is connected, to start playback, touch “Source List,” then “USB/ iPod.”

For details on the location of the USB connector, see the supplied installation/connections manual.

About the controls and indications during playback

You can control USB playback in the same way as disc playback. For details, see “Playback controls” on page 18. For details on indications during playback, see “Indications during playback” on page 20.

To stop playback

Press (SOURCE/OFF) for 1 second.

Notes on use

• Do not use USB devices so large or heavy that they may fall down due to vibration, or cause a loose connection.

• Do not leave a USB device in a parked car, as malfunction may result.

• This unit cannot recognize USB devices via a USB hub.

Notes on playback

• If a USB device contains multiple file types, only the selected file type (audio/video/image) can be played. For details on how to select the file type, see “Selecting a file type” on page 33.

• Displayed indications will differ, depending on the USB device, recorded format and settings. For details, visit the support site.

• The maximum number of displayable data is as follows. – folders (albums): 256 – files (tracks): 2,000

• It may take time for playback to begin, depending on the amount of recorded data.

• During playback or fast-forward/reverse of a VBR (Variable Bit Rate) MP3/WMA/AAC file, elapsed playing time may not display accurately.

• Playback of a lossless compression file is not supported.

Repeat and shuffle play

1 During playback, touch “Play Menu,”

then the “Repeat” or “Shuffle” box repeatedly until the desired option appears.

Repeat or shuffle play starts.

The repeat options are as follows.

“OFF”: Returns to normal play mode. “Track”/“Image”/“Movie”*

current track/image/video file.

“Album”: Repeats the current album (folder). “Drive”*

: Repeats the current drive.

The shuffle options are as follows.

“OFF”: Returns to normal play mode. “Album”: Plays tracks/images/video files in the

current album (folder) in random order.

*1 Options depend on the file type. *2 When two or more drives are created on the USB

device.

To close the play menu, touch “Play Menu.”

: Repeats the

To disconnect the USB device

Stop playback, then disconnect. Do not disconnect during playback, as data in the USB device may be damaged.

Enjoying music according to your mood — SensMe™

Sony’s unique “SensMe™ channels” and “SensMe™ mood” features automatically group tracks by channel or mood, and allow you to enjoy music intuitively.

Before using the SensMe™ function

The following is the basic procedure required to enjoy the SensMe™ function on the unit.

1 Installing “SensMe™ Setup” and

“Content Transfer” in your computer

First install “SensMe™ Setup” and “Content Transfer” from the supplied CD-ROM.

™

Content

SensMe

Transfer

Setup

2 Registering a USB device using

“SensMe™ Setup”

Connect a USB device to your computer, and perform registration using “SensMe™ Setup” to enable the SensMe™ function on this unit.

3 Transferring tracks to the USB device

using “Content Transfer”

In order to group tracks by channel or mood, track sound patterns need to be analyzed by 12 TONE ANALYSIS, which is loaded in “Content Transfer.” With the USB device connected to your computer, drag and drop tracks from Windows Explorer or iTunes, etc., to “Content Transfer.” Both analysis and transfer of tracks will be performed by “Content Transfer.”

Content Transfer

4 Connecting the USB device and

enjoying the SensMe™ function on the unit

Connect the set up USB device. You can then enjoy “SensMe™ channels” or “SensMe™ mood” on this unit.

SensMe™

™

SensMe

Setup

Tip

Registration can be performed either along with the installation procedure or after installation.

Installing “SensMe™ Setup” and “Content Transfer” in your computer

Use of the supplied software (“SensMe™ Setup” and “Content Transfer”) is required to enable the SensMe™ function on this unit. Install the software in your computer from the supplied CD-ROM.

1 Insert the supplied CD-ROM into your

computer.

The Installation Wizard runs automatically.

2 Follow the on-screen instructions to

complete the installation.

Registering a USB device using “SensMe™ Setup”

USB device registration is required to enable the SensMe™ function on the unit.

If registration is not performed along with the installation procedure, follow the steps below.

1 Start “SensMe™ Setup” on your

computer.

2 Connect a USB device to your

computer.

3 Complete registration following the

on-screen instructions.

Tip

If you connect a registered USB device containing analyzed tracks, the USB device can be unregistered again.

Playing tracks in the channel — SensMe™ channels

“SensMe™ channels” automatically group tracks into channels by their tunes. You can select and play a channel that fits your mood, activity, etc.

1 Connect a USB device set up for the

SensMe™ function.

2 Touch “Source List,” then “SensMe™.” 3 Touch “channels.”

The channel list appears.

Shuffle All

Energetic

Transferring tracks to the USB device using “Content Transfer”

To enable the SensMe™ function on this unit, tracks need to be analyzed and transferred to the registered USB device, using “Content Transfer.”

1 Connect the registered USB device to

your computer.

For “WALKMAN,” connect with the MTP mode. For USB devices other than “WALKMAN,” connect with the MSC mode. “Content Transfer” starts automatically. If a message appears, follow the on-screen instructions to proceed.

2 Drag and drop tracks from Windows

Explorer or iTunes, etc., to “Content Transfer.”

The analysis and transfer of tracks start.

For details on operations, see the Help of “Content Transfer.”

Note

The track analysis by 12 TONE ANALYSIS may take time, depending on the computer environment.

Tip

Not only audio files but also image or video files can be transferred using “Content Transfer.” For details, see the Help of “Content Transfer.”

Relax

ZAP

12:0015

4 Touch v/V to scroll the channel list.

Playback of the first track in the current channel starts from the track’s most melodic or rhythmical section*.

* May not be detected correctly.

5 Touch the desired channel.

Playback of tracks in the selected channel starts.

Notes

• Depending on the track, it may not be detected correctly or may be grouped in a channel not suited to the track’s mood.

• If the connected USB device contains many tracks, it may take time for “SensMe™ channels” to start, due to data reading.

Tip

Tracks are played in random order. The order will vary at each channel selection.

Channel list

A C D E

x Recommended, Shuffle All

“Morning” (5:00 AM – 9:59 AM) “Daytime” (10:00 AM – 3:59 PM) “Evening” (4:00 PM – 6:59 PM) “Night” (7:00 PM – 11:59 PM) “Midnight” (12:00 AM – 4:59 AM)

Tracks recommended for each time of day. Set the clock (page 57) for the channel to be displayed accurately.

“Shuffle All”: Plays all analyzed tracks in random order.

Controls and indications during “SensMe™ channels” playback

Shuffle All

Energetic

Relax

ZAP

12:0015

x Basic channels

Plays tracks according to the music type.

“Energetic”: High-spirit tracks.

“Relax”: Calm tracks.

“Mellow”: Mellow, melancholy tracks.

“Upbeat”: Happy tracks to improve your

mood.

“Emotional”: Ballad tracks.

“Lounge”: Lounge music.

“Dance”: Rhythm and rap, rhythm and blues

tracks.

“Extreme”: Intense rock tracks.

x In-car channels

Plays tracks that are suitable while driving.

“Freeway”: Speedy, high-spirit tracks.

“Chillout Drive”: Intoned, healing ballad

tracks.

“Weekend Trip”: Delightful, bright and happy tracks.

“Midnight Cruise”: Jazz or piano-featured tracks with mature mood.

“Party Ride”: Up-tempo and alive tracks.

“Morning Commute”: Bright and breezy

tracks.

“Goin’ Home”: Warm and relaxing tracks.

HGF

A To show the control keys: “Source List,”

“ATT,” “ Top.” (p age 1 8)

B To scroll the list and select another channel. C Indicates the current channel. D Indicates the album artwork display*

E Indicates the elapsed playback time, track

name, artist name.

F To pause/resume play after pause. G To skip a track. H To enter the ZAPPIN mode. (page 33)

During ZAPPIN playback of “SensMe™ channels,” the most melodic or rhythmical sections*

*1 The recommended size is from 240 × 240 to 960 ×

960 pixels.

*2 May not be detected correctly.

of the tracks are played.

Playing tracks in the mood map

A B C D E

— SensMe™ mood

“SensMe™ mood” distributes tracks as dots on a two-axis mood map, based on the characteristics of the individual tracks.

By touching the point on the map according to your mood, a circle appears around the touched point, and the tracks inside the circle are played.

1 Connect a USB device set up for the

SensMe™ function.

2 Touch “Source List,” then “SensMe™.” 3 Touch “mood.”

The two-axis mood map appears.

Circle

Mood

Type

Sad

Style

Time

Dots representing tracks

Fast

Happy

Slow

4 Touch the desired point on the map.

A circle appears around the touched point, and playback of tracks inside the circle starts. Playback of the first track starts from its most melodic or rhythmical section*.

* May not be detected correctly.

Notes

• Only the last 200 most recently transferred tracks using “Content Transfer” are mapped.

• Depending on the track, it may not be detected correctly or may be mapped in the position not suited to the track’s mood.

• If the connected USB device contains many tracks, it may take time for “SensMe™ mood” to start, due to data reading.

Tips

• In the mood map, the currently played track is indicated as a green dot.

• Tracks are played from the circle’s center outward.

Controls and indications during “SensMe™ mood” playback

Mood

Type

Sad

Style

Time

A To show the control keys: “Source List,”

“ATT,” “ Top.” (p age 1 8)

B To move the circle and regroup tracks. C To change the size of the circle: small,

medium or large.

D Indicates the album artwork display* E Indicates the elapsed playback time, track

name, artist name.

F To change parameters on the horizontal axis.

ZAP

12:0015

G To skip a track. H To pause/resume play after pause. I To enter the ZAPPIN mode. (page 33)

During ZAPPIN playback of “SensMe™ mood,” the most melodic or rhythmical sections*

*1 The recommended size is from 240 × 240 to 960 ×

960 pixels.

*2 May not be detected correctly.

Fast

Happy

Slow

of the tracks are played.

ZAP

12:0015

IFGH

Changing parameters on the horizontal axis

In the mood map, you can change parameters on the horizontal axis. Tracks are remapped according to the characteristics of the parameters.

Touch To change parameters to

“Mood” “Sad” – “Happy”

“Type” “Acoustic” – “Electronic”

“Style” “Soft” – “Hard”

“Time” “Morning” – “Midnight”

iPod Operations

For details on the compatibility of your iPod, see “About iPod” on page 61 or visit the support site.

Support site

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

In this manual, “iPod” is used as a general reference for the iPod functions on the iPod and iPhone, unless otherwise specified by the text or illustrations.

Playing an iPod

1 Reduce the volume on this unit. 2 Remove the cap from the USB

connector, and connect the iPod to the USB connector.

Use of the optional USB connection cable RC-200IPV is recommended.* For details, see the supplied installation/ connections manual.

The following display appears on the iPod

screen*

, then playback starts from the item last played. If an iPod is already connected, to start playback, touch “Source List,” then “USB/ iPod.”

*1 To play videos of iPod with video, use of the

RC-200IPV is required.

*2 May not appear in the case of an iPod touch or

iPhone being connected, or when the iPod was last played back using passenger control.

3 Adjust the volume on this unit.

To stop playback

Press (SOURCE/OFF) for 1 second.

To disconnect the iPod

Stop playback, then disconnect. Do not disconnect during playback, as data in the iPod may be damaged.

About the resuming mode

When the iPod currently playing is connected to the dock connector, the mode of this unit changes to resuming mode and playback starts in the mode set by the iPod. In the resuming mode, repeat/shuffle setting is not available.

Caution for iPhone

When you connect an iPhone via USB, telephone volume is controlled by iPhone itself. In order to avoid sudden loud sound after a call, do not increase the volume on the unit during a telephone call.

Note

This unit cannot recognize iPod via a USB hub.

Tips

• When the ignition key is turned to the ACC position with the unit on, the iPod will be recharged.

• If the iPod is disconnected during playback, “USB device is not connected.” appears in the display of the unit.

Setting the play mode

You can set one of the following play modes.

For audio playback

“Album,” “Track,” “Genre,” “Playlist,” “Artist,” “Podcast”*

For video playback

“Movie,” “Rental,” “TV Show,” “Music Video,” “Playlist,” “Podcast”*

* May not appear depending on iPod setting.

1 During playback, touch “List.” 2 Touch “MUSIC” or “VIDEO.” 3 Touch the desired play mode.

To start playback, touch the desired item(s) in the list. To scroll the list, touch v/V.

About the controls and indications during playback

You can control iPod playback in the same way as disc playback. For details, see “Playback controls” on page 18. For details on indications during playback, see “Indications during playback” on page 20.

To skip items of the selected play mode

During playback, touch –/+ of the selected play mode.

Repeat and shuffle play

1 During playback, touch “Play Menu,”

then the “Repeat” or “Shuffle” box repeatedly until the desired option appears.

Repeat or shuffle play starts.

To close the play menu, touch “Play Menu.”

The repeat options are as follows.

For audio playback

“OFF”: Returns to normal play mode. “Track”: Repeats the current track. “Album”/“Podcast”/“Artist”/“Playlist”/ “Genre”*: Repeats the current item of the

selected play mode.

For video playback

“OFF”: Returns to normal play mode. “Track”: Repeats the current video. “Rental”/“TV Show”/“Music Video”/ “Playlist”/“Podcast”*: Repeats the current

item of the selected play mode.

The shuffle options are as follows.

For audio playback

“OFF”: Returns to normal play mode. “Album”/“Podcast”/“Artist”/“Playlist”/ “Genre”*: Plays tracks of the selected play

mode in random order. “Device”: Plays all tracks in an iPod in random order.

Operating an iPod directly — Passenger control

You can directly operate an iPod connected to this unit.

1 During playback, touch “Play Menu,”

then the “Passenger Control” box to set to “ON.”

Deactivating the passenger control

Touch the “Passenger Control” box to set to “OFF.” The play mode changes to resuming mode.

To close the play menu, touch “Play Menu.”

Notes

• To output video to this unit, you need to activate the video output of iPod.

• The volume can be adjusted only by this unit.

• The repeat setting will be off if the passenger control

mode is canceled.

* Differs depending on the selected play mode.

Note

Displayed options may not conform to actual operation.

Useful Functions

Listing up tracks/images/video files — List

Selecting a track/image/video file

MPEG-4

You can list up albums/folders/tracks/images/ video files, and select a desired one to play. This function is convenient especially for the disc in MP3/WMA/AAC/JPEG/DivX/MPEG-4 format or USB device containing many albums/ tracks, etc.

1 During playback, touch “List.”

The list of categories or files in the currently played item appears.

Contents List

File 01

File 02

File 03

File 04

File 05

File 06

Page p osition bar

To move to the upper level, touch . To scroll the list, touch v/V. To jump pages, touch the page position bar.

2 Touch the desired item.

Playback starts.

Selecting a file type

MPEG-4

If the disc/USB device contains multiple file types, only the selected file type (audio/video/ image) can be played. The playback priority order of file type is initially set to audio, video, then image (e.g., if the disc contains video files and image files, only video files are played). You can select the file type to list up, then select the desired file to play.

1 During playback, touch “List.” 2 Touch , then “Audio,” “Image” or

“Video” to select the file type.

To close the option menu, touch “Close.”

1/5

12:0015

3 Touch the desired file.

Playback of the selected file starts.

Searching a track by listening to track passages — ZAPPIN™

While playing back short track passages in a disc or USB device in sequence, you can search for a track you want to listen to. This function is convenient, for example, when searching for a track in shuffle or shuffle repeat mode.

1 During audio playback, touch “ZAP.”

Playback starts from a passage of the next track. The passage is played for the set time, and a beep sounds before the next passage starts.

“ZAP” touched.

2 Touch “ZAP” when a track you want to

listen to is played back.

The track that you select returns to normal play mode from the beginning. To search a track by ZAPPIN mode again, repeat steps 1 and 2.

In the case of “SensMe™ channels” or “SensMe™ mood” playback

If you enter the ZAPPIN mode during “SensMe™ channels” or “SensMe™ mood” playback, the most melodic or rhythmical sections* of tracks are played. For details on the SensMe™ function, see “Enjoying music according to your mood — SensMe™” on page 27.

* May not be detected correctly.

Tips

• You can change the playback time (page 55), but

cannot select the track passage to play back.

• You can deactivate the beep sound between track

passages (page 55).

The playback section of each track in ZAPPIN mode.

Using Gesture Command

You can perform frequently-used operations by drawing the following command stroke in the reception/playback display.

Draw To

Radio reception:

seek forward stations.

a horizontal

line

(left to right)

a horizontal

line

(right to left)

a vertical line

(upwards)

a vertical line

(downwards)

(The same as >.)

DVD/VCD playback:

skip forward a chapter/track. (The same as >.)

JPEG/DivX/MPEG-4/audio playback:

skip forward a file/track. (The same as >.)

Radio reception: seek backward stations. (The same as ..)

DVD/VCD playback:

skip backward a chapter/track. (The same as ..)

JPEG/DivX/MPEG-4/audio playback:

skip backward a file/track. (The same as ..)

Radio reception: receive stored stations (go forward).

DVD/VCD/DivX/MPEG-4 playback:

fast-forward the video.

JPEG/audio playback: skip forward an album (folder). (The same as “Album” +.)

Radio reception: receive stored stations (go backward).

DVD/VCD/DivX/MPEG-4 playback:

reverse the video.

JPEG/audio playback: skip backward an album (folder). (The same as “Album” –.)

Handsfree Calling and Audio Streaming — Bluetooth

Before using the Bluetooth function

Basic procedure of the Bluetooth function

1 Pairing

When connecting Bluetooth devices for the first time, mutual registration is required. This is called “pairing.” This registration (pairing) is required only for the first time, as this unit and the other devices will recognize each other automatically from the next time.

Note

If you delete the device registration from this unit, you need to perform pairing again.

2 Connection

After pairing is made, connect this unit and the Bluetooth device. Depending on the device, connection is automatically made along with the pairing.

3 Handsfree calling/Audio streaming

You can make/receive a handsfree call, or listen to audio through this unit.

To view the instructions on Gesture Command

Touch when it is shown in the top right corner of the display.

For details on compatibility of your device, visit the support site.

Support site

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

Bluetooth status indication

Bluetooth signal indicator: Lights up when the Bluetooth signal is on.

Calling...

ATT

Name

0123456789

Calling...

12:0015

Bluetooth status indications

None: No device is connected for

audio streaming purpose.

Flashing: Connection is in progress. Lit: Connected to a device.

None: No cellular phone is connected

for handsfree calling purpose.

Flashing: Connection is in progress. Lit: Connected to a cellular phone.

Signal strength status of connected cellular phone.

Remaining battery status of connected cellular phone.

Installing the external microphone XA-MC10

To capture your voice during handsfree calling, you need to install the external microphone XAMC10 (supplied).

For details on how to connect the microphone, see the supplied installation/connections manual.

Pairing

Pairing is required only the first time you connect to a Bluetooth device (cellular phone, etc.).*

To pair this unit to a Bluetooth device, you need to enter the same passkey*

on this unit and on the Bluetooth device. The passkey can be either your own selected number or the number determined by the Bluetooth device. For details, see the manual of the Bluetooth device.

*1 If you delete the device registration from this unit,

you need to perform pairing again.

*2 Passkey may be called “passcode,” “PIN code,”

“PIN number,” “password,” etc., depending on the Bluetooth device.

Tip

You can pair up to 9 devices.

Searching from this unit

Check that the other Bluetooth device is set to allow for searching (discoverable) beforehand.

1 Select the Bluetooth source.

To select Bluetooth Phone, press (TOP), then touch “BT Phone” in the top menu. To select Bluetooth Audio, touch “Source List,” then “BT Audio.”

2 Touch “BT Menu.”

In the case of Bluetooth Audio, touch “Play Menu,” then “BT Menu.” The Bluetooth setting menu appears.

BT Menu

Signal

Discoverable

Device Name

Device List

ATTBack Top

OFF / ON

Hide / Show

1/2

12:00

continue to next page t

3 Touch “Search.”

Search of connectable Bluetooth devices

1*2

starts.* After search is complete, the list of detected

devices*

*1 If the Bluetooth signal of this unit is off, it

*2 Search time varies depending on the number of

*3 The name or address (if name is unavailable) of

appears.

activates automatically when searching starts.

connectable devices.

detected devices are displayed.

4 Touch the device to connect. 5 Select the connection type.

Touch “Handsfree Connect” to use for handsfree calling. Touch “Audio Connect” to use for audio streaming. Pairing start and the passkey input display appears.

6 Touch the number keys to enter the

passkey, then “OK.”

Perform the required operation also on the other Bluetooth device. Pairing is complete and this unit is connected to the other Bluetooth device. When connection is made successfully, or

appears at the bottom of the display.

Searching from the Bluetooth device

The procedure to search for this unit from the other Bluetooth device is explained below.

1 Select the Bluetooth source.

To select Bluetooth Phone, press (TOP), then touch “BT Phone” in the top menu. To select Bluetooth Audio, touch “Source List,” then “BT Audio.”

2 Touch “BT Menu.”

In the case of Bluetooth Audio, touch “Play Menu,” then “BT Menu.” The Bluetooth setting menu appears.

3 Touch “Signal,” then “Yes” to set

“Signal” to “ON.”

The Bluetooth signal of this unit is activated.

4 Touch “Discoverable” to set to

“Show.”

The unit is ready to be detected by the other Bluetooth device.

5 Start searching for this unit from the

other Bluetooth device.

After search is complete, this unit appears as “Sony Automotive”* in the list of the other Bluetooth device.

* Can be changed in the Bluetooth setting

(page 44).

DR-BT30Q

Sony

Automotive XXXXXXX

After you perform the required operation on the other Bluetooth device, the passkey input display appears on this unit.

6 Touch the number keys to enter the

passkey, then “OK.”

Pairing is complete and this unit is connected to the other Bluetooth device. When connection is made successfully, or

appears at the bottom of the display.

Notes

• While connecting to a Bluetooth device, this unit cannot be detected from another device. To enable detection, disconnect the current connection and search for this unit from another device.

• Depending on the device, searching from this unit may not be possible. In this case, search for this unit from the other device.

• If you search for this unit and the other device mutually at the same time, this unit will not recognize the other device.

• It may take time to search or connect.

• Depending on the device, the connection

confirmation display appears before inputting the passkey.

• The time limit for inputting the passkey differs depending on the device.

• This unit cannot be connected to a device that supports only HSP (Head Set Profile).

Connecting

When the ignition is switched to on with the Bluetooth signal activated, this unit searches for the last-connected Bluetooth device, and connection is made automatically if possible.

This chapter explains how to connect manually to registered Bluetooth devices.

Before starting, be sure to activate the Bluetooth signal both on this unit (page 44) and the other Bluetooth device.

1 Select the Bluetooth source.

To select Bluetooth Phone, press (TOP), then touch “BT Phone” in the top menu. To select Bluetooth Audio, touch “Source List,” then “BT Audio.”

2 Touch “BT Menu.”

In the case of Bluetooth Audio, touch “Play Menu,” then “BT Menu.” The Bluetooth setting menu appears.

3 Touch “Device List.”

The list of registered Bluetooth devices appears. To scroll the list, touch v/V.

4 Touch the device to connect. 5 Select the connection type.

Touch “Handsfree Connect” to use for handsfree calling. Touch “Audio Connect” to use for audio streaming. Connection is complete. When connection is made successfully, or

appears at the bottom of the display. In the device list, the currently connected device is indicated by the icon at the head of its name.

To connect from the other Bluetooth device

Operate the other Bluetooth device to connect to this unit. When connection is made successfully, or appears at the bottom of the display.

To disconnect

1 Follow steps 1 to 3 above. 2 Touch the currently connected device, then

“Handsfree Disconnect” or “Audio Disconnect.”

To delete all registrations

1 Follow steps 1 to 3 above. 2 Touch “Delete All,” then “Yes” in the

confirmation display.

To connect to the last-connected device from this unit (Bluetooth Audio only)

Touch “Source List,” “BT Audio,” then “Connect.”

Note

If connection is made during audio streaming, noise may occur over playback sound.

Tip

You can connect a cellular phone for audio streaming purpose if it supports A2DP (Advanced Audio Distribution Profile).

Handsfree calling

Once the unit is connected to the cellular phone, you can make/receive handsfree calls by operating this unit.

Making calls

By dialing a phone number

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

Back

ATT

Preset Dial

BT phone

BT Menu

Call Menu PB Access

2 Touch “Call Menu,” then “Dial.”

The number input display appears.

ATT

Back

Dial

Please input phone number.

Top

Voice Dial

12:00

Top

To delete an individual registration

1 Follow steps 1 to 3 above. 2 Touch the device to delete, then “Delete this

device from List.”

3 Touch “Yes” in the confirmation display.

1 2 3 4 5

6 7 8 9 0

continue to next page t

12:00

3 Touch the number keys to enter the

phone number, then .

To delete an entered number, touch . The call is made and the calling display appears until the other party answers.

Calling...

ATT

Name

0123456789

Calling...

By the phonebook

For details on how to manage the phonebook data, see “Phonebook management” on page 40.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Phonebook.”

The phonebook appears.

3 Select the desired contact.

1 In the initial list, touch the initial of the

contact.

2 In the name list, touch the name of the

contact.

3 In the number list, touch the phone

number.

The contact confirmation display appears.

4 Touch “Call.”

The call is made and the calling display appears until the other party answers.

Tip

You can also browse the phonebook of the connected cellular phone on this unit and make a call (page 41).

By the call history

The unit stores the last 20 calls, allowing you to select one quickly from the list.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Recent Call.”

The list of call history appears. To scroll the list, touch v/V.

3 Touch the desired item in the list.

The contact confirmation display appears.

4 Touch “Call.”

The call is made and the calling display appears until the other party answers.

By the preset dial

You can store up to 6 contacts in the preset dial. For details on how to store, see “Preset dial” on page 42.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch the number in the list (“P1” to

“P6”).

The contact confirmation display appears.

3 Touch “Yes.”

The call is made and the calling display appears until the other party answers.

12:0015

By the voice dial function

You can make a call using the voice tag stored on the connected cellular phone.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Voice Dial.” 3 Say the voice tag stored on the cellular

phone.

Your voice is recognized, then the call is made. The calling display appears until the other party answers.

Notes

• Say the voice tag in the same way as you stored it on the cellular phone.

• If the voice dial function is activated on the connected cellular phone, it may not work by this unit.

• Do not use the voice dial function on the cellular phone while it is connected to this unit.

• Noises such as the engine running may interfere with sound recognition. In order to improve recognition, operate under conditions where noise is minimized.

• Voice dial may not work depending on the recognition specification of the cellular phone. For details, visit the support site.

To adjust the talker’s voice volume

Press (VOL) +/– while making a call. The level of talker’s voice volume will be stored into memory, independently from the regular volume level.

Receiving calls

With the unit connected to the cellular phone, you can receive a call in any status. The following display indicates an incoming call, along with the ring tone.

Incoming call...

ATT

Name

0123456789

Incoming call...

Operations during a call

The following display appears during a call.

ATT

On the Line.

BT Menu

Name

0123456789

Open KeypadHandsfree OFF

10:59

Top

12:0015

To answer the call

Touch .

To adjust the ring tone volume

Press (VOL) +/– while receiving a call. The level of ring tone volume will be stored into memory, independently from the regular volume level.

To reject a call

Touch .

Note

The ring tone and talker’s voice are output only from front speakers.

Tips

• You can set to answer a call automatically (page 44).

• You can set to use the ring tone of the cellular phone

or this unit (page 44).

To adjust the talker’s voice volume

Press (VOL) +/– during a call. The level of talker’s voice volume will be stored into memory, independently from the regular volume level.

To send DTMF (Dual Tone Multiple Frequency) tones

Touch “Open Keypad,” then the required number keys.

To transfer the current call to the cellular phone

Touch “Handsfree OFF.” To transfer back to the handsfree call, touch “Handsfree ON.”

Note

Depending on the cellular phone, connection may be cut off when call transfer is attempted.

To adjust the volume for the other party

1 Touch “BT Menu.” 2 Touch v/V to scroll, then “MIC Gain.” 3 Touch –/+ to adjust the level.

The level is adjustable in single steps, between –2 and +2.

4 Touch “Back” repeatedly to return to

the previous displays.

To end a call

Touch .

Phonebook management

You can store up to 300 contacts in the phonebook and up to 5 phone numbers can be registered to each contact.

Notes

• Downloaded phonebook data from a cellular phone cannot be overwritten by subsequent data. However, some data (name, etc.,) may be duplicated as a result.

• Phonebook data may be lost if this unit is damaged.

• When disposing of this unit, delete the phonebook

data by initializing (page 44).

Storing phonebook data

To download from a cellular phone

If the connected cellular phone supports PBAP (Phone Book Access Profile), you can download phonebook data and store on this unit.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “PB Access.”

The phonebook access menu appears.

3 Touch “Access” to select the memory

where phonebook data is stored.

To download the data in a cellular phone’s internal memory, set to “Memory.” To download the data on SIM, set to “SIM.”

4 Touch “Phonebook Download.”

When downloading is complete, “Complete” appears and the phonebook data is stored on this unit.

To receive from a cellular phone

You can send phonebook data from the connected cellular phone and receive it on this unit.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Receive

Phonebook.”

This unit is ready for receiving phonebook data.

3 Send the phonebook data by

operating the connected cellular phone.

When receiving is complete, “Complete” appears and the phonebook data is stored on this unit.

To add a contact by entering the name and number

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Phonebook.”

The phonebook appears.

3 Touch “Add Contact.”

The contact registration display appears.

Add Contact

Empty

ATTBack

Add to Phonebook?

Top

1/1

12:00

4 Touch “Empty” on the first line.

The name input display appears.

5 Touch the character keys to enter the

name, then “OK.”

For details on how to use the keyboard, see “About the keyboard to edit the name” on page 42. The contact registration display reappears.

6 Touch “Empty.”

The number input display appears.

7 Touch the number keys to enter the

phone number, then “OK.”

The phone number type selection display appears.

8 Touch the desired phone number type.

The contact registration display reappears. To enter other phone numbers, repeat steps 6 to 8.

9 Touch “Add to Phonebook?”

The contact is added to the phonebook.

To add a contact from the call history

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Recent Call.”

The list of call history appears. To scroll the list, touch v/V.

3 Touch the item to add to the

phonebook.

The contact confirmation display appears.

4 Touch “Save to Phonebook.”

The name input display appears.

5 Touch the character keys to enter the

name, then “OK.”

For details on how to use the keyboard, see “About the keyboard to edit the name” on page 42. The contact is added to the phonebook.

Browsing a phonebook in a cellular phone

If the connected cellular phone supports PBAP (Phone Book Access Profile), you can browse its phonebook data on this unit. You can also make a call to a contact or add the contact to this unit’s phonebook.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “PB Access.”

The phonebook access menu appears.

3 Touch “Access” to select the memory

where phonebook data is stored.

To browse the data in a cellular phone’s internal memory, set to “Memory.” To browse the data on SIM, set to “SIM.”

4 Touch “Phonebook Browsing.”

The phonebook of the connected cellular phone appears.

5 Select the desired contact.

1 In the initial list, touch the initial of the

contact.

2 In the name list, touch the name of the

contact.

3 In the number list, touch the phone

number.

The contact confirmation display appears.

To call the contact

Touch the phone number to call, then “Yes” in the confirmation display.

To add the contact to this unit’s phonebook

Touch “Save to Phonebook,” then “Yes” in the confirmation display.

Deleting phonebook data

To delete all phonebook data on this unit

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Phonebook.”

The phonebook appears.

3 Touch “Delete All.”

The confirmation display appears.

4 Touch “Yes.”

All phonebook data is deleted.

To delete an individual contact from the phonebook

1 Follow steps 1 to 2 above. 2 Select the contact to delete.

1 In the initial list, touch the initial of the

contact.

2 In the name list, touch the name of the

contact.

3 Touch “Delete Contact.”

The confirmation display appears.

4 Touch “Yes.”

The contact is deleted from the phonebook.

Editing a contact

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Phonebook.”

The phonebook appears.

3 Select the contact to edit.

1 In the initial list, touch the initial of the

contact.

2 In the name list, touch the name of the

contact.

4 Touch the desired edit option.

Tou ch To

“Edit Name” edit the name of the

“Add Number” add the phone number

the phone number in the list

contact. Enter the new name, then touch “OK.”

to the contact. Enter the phone number, then touch “OK.”

delete the selected phone number. Touch “Delete Number,” then “Yes.”

continue to next page t

About the keyboard to edit the name

Contact Name

Please Input Name

Q W E R T Y U I O P

abc 123 OKSpace

Tou ch To

“ABC” or “abc” change the case.

the desired character key

“123” switch to the numeric

the desired number/symbol key

“Space” enter a space.

“OK” complete the name edit.

ATTBack

NAME

A S D F G H J K

Z X C V B N M

enter the character.

keyboard.

enter the number/ symbol.

delete a character.

Top

12:00

Call data management

4 Touch “Yes.”

The selected item is deleted from the call history.

Preset dial

You can store contacts in the phonebook or call history into the preset dials.

To store from the phonebook

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Phonebook.”

The phonebook appears.

3 Select the contact to store in the

preset dial.

1In the initial list, touch the initial of the

contact.

2In the name list, touch the name of the

contact.

3In the number list, touch the phone

number.

The contact confirmation display appears.

4 Touch “Preset Memory,” then the

desired preset number (“P1” to “P6”).

The contact is stored in the selected preset number.

Call history

You can delete the items in the call history.

To delete all items in the call history

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Recent Call.”

The list of call history appears.

3 Touch “Delete All.”

The confirmation display appears.

4 Touch “Yes.”

All items in the call history are deleted.

To delete an individual item in the call history

1 Follow steps 1 to 2 above. 2 In the list, touch the item to delete.

The contact confirmation display appears.

3 Touch “Delete Number.”

The confirmation display appears.

To store from the call history

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “Recent Call.”

The list of call history appears. To scroll the list, touch v/V.

3 Touch the desired item in the list.

The contact confirmation display appears.

4 Touch “Preset Memory,” then the

desired preset number (“P1” to “P6”).

The contact is stored in the selected preset number.

To change the registration of the preset dial

Follow the procedure above and overwrite a registered preset dial.

Locking the personal information

To prevent unauthorized access to personal information, you can lock call data by setting a 4digit code. Once locked, you need to enter the code to access the items in the call menu.

1 Press (TOP), then touch “BT Phone”

in the top menu.

The Bluetooth Phone display appears.

2 Touch “Call Menu,” then “PIM

Security.”

The confirmation display appears.

3 Tou ch “ Yes.”

The code setting display appears.

4 Touch the number keys to enter your

code, then “OK.”

5 To confirm, touch the number keys to

reenter your code, then “OK.”

The setting is complete.

To delete an entered number, touch “Clear.” To return to the previous display, touch “Back.”

Unlocking the call data

1 Follow steps 1 to 2 above.

The confirmation display appears.

2 Touch “Yes.”

The unlock display appears.

3 Touch the number keys to enter your code.

“Complete” appears, and the call data is unlocked.

Audio streaming

Listening to a Bluetooth device through this unit

If the other device supports A2DP (Advanced Audio Distribution Profile) of Bluetooth technology, you can listen to the playback sound through this unit.

1 Connect this unit and the Bluetooth

device (page 36).

2 Reduce the volume on this unit. 3 Touch “Source List,” then “BT Audio.”

The Bluetooth Audio display appears.

4 Operate the other Bluetooth device to

start playback.

5 Adjust the volume on this unit.

Operating the Bluetooth device with this unit

If the other device supports AVRCP (Audio Video Remote Control Profile) of Bluetooth technology, you can control the playback on this unit.

Operations can be performed in the same way as disc playback (page 18), except for the following.

Touch To

“Play Menu” c “BT Menu”

–/+ in the “Level” box

“Connect” connect to the last-

Notes

• The available operation differs depending on the Bluetooth device. Perform unavailable operations on the Bluetooth device.

• Depending on the Bluetooth device, it may be necessary to touch u twice to start/pause the playback.

• During audio streaming, some indications such as track name, etc., may not appear on this unit.

open the Bluetooth setting menu (page 43).

reduce the volume level differences between this unit and the other Bluetooth device. The level is adjustable in single steps, between –8 and +18.

connected device from this unit.

Bluetooth settings

The Bluetooth settings can be configured in “BT Menu.”

1 Select the Bluetooth source.

To select Bluetooth Phone, press (TOP), then touch “BT Phone” in the top menu. To select Bluetooth Audio, touch “Source List,” then “BT Audio.”

2 Touch “BT Menu.”

In the case of Bluetooth Audio, touch “Play Menu,” then “BT Menu.” The Bluetooth setting menu appears.

3 Touch the desired item in the list and

configure the setting.

continue to next page t

The items in the Bluetooth setting menu are as follows.

“Signal”*

Activates the Bluetooth signal: “ON,” “OFF.”

“Discoverable”*

(page 36) Allows the other Bluetooth device to search for this unit: “Show,” “Hide.”

“Device Name”*

Changes the name of this unit displayed on the connected device. (Default setting: “Sony Automotive”) For details on basic operation of keyboard, see “About the keyboard to edit the name” on page 42.

“Search”*

(page 35)

Searches for connectable Bluetooth devices.

“Device List”*1 (page 36)

Shows the list of registered devices; connects to a registered device; deletes all registrations.

“Auto Answer”*

Answers an incoming call automatically. – “Short”: to answer automatically after 3

seconds.

– “Long”: to answer automatically after 10

seconds.

– “OFF”: to not answer automatically.

“Ringtone”*

1*2

Uses the ring tone of this unit or the connected cellular phone: “Default,” “Cellular.”

“EC/NC Mode” (Echo Canceller/Noise Canceller Mode)

Reduces echo and noise in phone call conversations. Set to “Mode 1” normally. If the outgoing sound quality is unsatisfactory, set to “Mode 2” or “OFF.”

“MIC Gain” (page 39)

Adjust the volume for the other party: –2 ~ +2.

“Initialize”*

Initializes all Bluetooth-related settings. Touch “Yes” in the confirmation display.

*1 Cannot be configured during a handsfree call. *2 Depending on the cellular phone, this unit’s ring

tone may be output even if set to “Cellular.”

Note

For details on the setting of other Bluetooth devices, see their respective manuals.

Sound Adjustment

Selecting the sound quality — EQ7

You can select an equalizer curve from 7 music types (“Xplod,” “Vocal,” “Edge,” “Cruise,” “Space,” “Gravity,” “Custom” or “OFF”).

1 During reception/playback, touch

“Source List,” then .

2 Touch “Sound.”

The sound setting menu appears.

3 Touch “EQ7.”

The options appear.

4 Touch the desired equalizer curve.

The setting is complete.

To cancel the equalizer curve, select “OFF.” To return to the previous display, touch “Back.”

Customizing the equalizer curve — EQ7 Tune

“Custom” of EQ7 allows you to make your own equalizer settings. You can adjust the level of 7 different bands: 62 Hz, 157 Hz, 396 Hz, 1 kHz,

2.5 kHz, 6.3 kHz, and 16 kHz.

1 During reception/playback, touch

“Source List,” then .

2 Touch “Sound,” then “EQ7.” 3 Touch “Custom,” then “Tune.”

The tuning display appears.

Back

EQ7 Tune : Custom

62 Hz0157 Hz0396 Hz01 kHz02.5 kHz06.3 kHz016 kHz

ATT

Reset OK

4 Touch +/– of each frequency to adjust

their levels.

The level is adjustable in single steps, between –8 and +8. To restore the factory-set equalizer curve, touch “Reset.”

5 Touch “OK.”

The setting is complete.

To return to the previous display, touch “Back.”

Top

12:0015

Tip

Other equalizer types are also adjustable.

Adjusting the sound characteristics

The sound balance between left and right speakers (“Balance”) and front and rear speakers (“Fader”) can be adjusted to your preference. You can also adjust the volume level of subwoofer if it is connected.

1 During reception/playback, touch

“Source List,” then .

2 Touch “Sound.”

The sound setting menu appears.

3 Touch “Balance/Fader.”

The setting display appears.

Balance/Fader/Subwoofer Level Adjust

ATTBack

Fader : 0

Balance : 0

4 Tou ch B/V/v/b to adjust the balance/

fader.

The level is adjustable in single steps between –15 and +15 (Balance)/–15 and +15 (Fader).

5 Touch +/– to adjust the volume level of

subwoofer.

This setting is adjustable only when subwoofer is connected and “Subwoofer” is set to “ON” (page 52). The level is adjustable in single steps, between –6 and +6.

To return to the previous display, touch “Back.”

Top

Subwoofer : 0

12:0015

Optimizing sound for the listening position — Intelligent Time Alignment

The unit can change the localization of sound by delaying the sound output from each speaker to suit your position, and simulate a natural sound field with the feeling of being in the center of it wherever you sit in the car. The options for “Listening Position” are indicated below.

“Front L” (1): Front left “Front R” (2): Front right “Front” (3): Center front “All” (4): In the center of

your car “Custom”: Precisely

calibrated position (page 46) “OFF”: No position set

You can also set the approximate subwoofer position from your listening position if: – the subwoofer is connected and “Subwoofer” is

set to “ON” (page 52).

– the listening position is set to “Front L,” “Front

R,” “Front” or “All.”

1 During reception/playback, touch

“Source List,” then .

2 Touch “Sound.”

The sound setting menu appears.

3 Touch “Listening Position.”

The setting display appears.

4 Set the listening position.

Touch “Front L,” “Front R,” “Front,” “All” or “Custom.”

5 Set the subwoofer position.

If you select “Front L,” “Front R,” “Front” or “All” in step 4 above, you can set the subwoofer position. Touch “Near,” “Normal” or “Far.” The setting is complete.

To cancel Intelligent Time Alignment, select “OFF.” To return to the previous display, touch “Back.”

Precisely calibrating the listening position — Intelligent Time Alignment Tune

You can precisely calibrate your listening position from each speaker so that the sound delay reaches the listener more correctly.

Before starting, measure the distance between your listening position and each speaker.

1 During reception/playback, touch

“Source List,” then .

2 Touch “Sound,” then “Listening

Position.”

3 Touch “Custom,” then “Custom Tune.”

The setting display appears.

Back

Position Tune

100 100 100 100 100

(cm)

ATT

Reset OK

Top

12:0015

4 Touch +/– of each speaker to set the

distance between your listening position and the speakers.

The distance is adjustable in 2 cm ( steps, between 0 and 400 cm (0 and 13 To restore the default setting, touch “Reset.”

/16 in)

/10 ft).

5 Touch “OK.”

The setting is complete.

To return to the previous display, touch “Back.”

Note

The setting is applied only after “OK” is touched.

Speaker configuration and volume setup

Creating a virtual center speaker — CSO

To fully enjoy surround sound, it is adequate to have 5 speakers (front left/right, rear left/right, center) and 1 subwoofer. CSO (Center Speaker Organizer) allows you to create a virtual center speaker even though a real center speaker is not connected.

1 During disc/USB playback, touch

“Source List,” then .

2 Touch “Sound.”

The sound setting menu appears.

3 Touch “CSO.”

The options appear.

4 Touch “CSO1,” “CSO2” or “CSO3.”

The setting is complete.

To return to the previous display, touch “Back.”

Note

“CSO” is effective only when “Multi Ch Output” is set to “Multi” (page 54), as it is effective only for playback of multi-channel sources.

Using rear speakers as subwoofer — RBE

RBE (Rear Bass Enhancer) enhances the bass sound by applying the low pass filter setting (page 53) to rear speakers. This function allows rear speakers to work as a subwoofer even if it is not connected.

1 During reception/playback, touch

“Source List,” then .

2 Touch “Sound.”

The sound setting menu appears.

3 Touch v/V to scroll, then “RBE.”

The options appear.

4 Touch “RBE1,” “RBE2” or “RBE3.”

The setting is complete.

To return to the previous display, touch “Back.”

Adjusting the speaker volume

You can adjust the volume level of each connected speaker. The adjustable speakers are “Front R” (Front Right), “Front L” (Front Left), “Surround L” (Rear Left), “Surround R” (Rear Right) and “Subwoofer*.”

* Adjustable only when a subwoofer is connected and

“Subwoofer” is set to “ON” (page 52).

1 While the unit is off, touch “Source

List,” then .

2 Touch “Sound.”

The sound setting menu appears.

3 Tou ch v/V to scroll, then “4.1ch

Speaker Level.”

The setting display appears.

Back

4.1ch Speaker Level

Front L

Surround L

Subwoofer

Reset

ATT

Front R

Surround R

Top

12:00

4 Touch the speaker, then +/– to adjust

the level.

Repeat this step to adjust all speaker volume. To restore the default setting, touch “Reset.”

To return to the previous display, touch “Back.”

Monitor Adjustment

Adjusting the monitor angle

You can adjust the monitor angle for best viewing.

1 Touch “Source List,” then . 2 Touch “General.”

The general setting menu appears.

3 Touch v/V to scroll, then “Monitor

Angle.”

The setting display appears.

4 Touch –/+ to adjust the angle.

The adjustment is stored. The monitor retains the angle even after the front panel is opened and closed.

To return to the previous display, touch “Back.”

Touch panel calibration

Touch panel calibration is required if the touching position does not correspond with the proper item.

1 Touch “Source List,” then . 2 Touch “General.”

The general setting menu appears.

3 Touch v/V to scroll, then “Touch Panel

Adjust.”

The setting display appears.

4 Touch the targets in sequence.

The calibration is complete.

To cancel calibration, touch “Cancel.”

Setting the background screen

You can select the screen theme, visualizer and picture brightness for the background screen according to your preference.

1 Touch “Source List,” then . 2 Touch “Screen.”

The screen setting menu appears.

3 Touch “Screen Select.”

The options appear.

4 Select the screen theme.

Touch “Screen Theme,” then the desired type.

5 Select the visualizer.

Touch “Visualizer,” then the desired type.

6 Select the picture brightness.

Touch “Day / Night mode,” then one of the following options.

“Auto”: Switches the brightness automatically when you turn the lights on. (Available only when the illumination control lead is connected.) “Always Day”: Fixes the brightness suitable for day time use. “Always Night”: Fixes the brightness suitable for night time use.

To return to the previous display, touch “Back.”

Selecting the picture quality — Picture EQ

Customizing the picture quality

The options “Custom 1” and “Custom 2” of Picture EQ allow you to make your own picture quality setting by adjusting the picture tones.

1 During video/image playback, touch

“Source List,” then .

2 Touch “Screen,” then “Picture EQ.” 3 Touch “Custom 1” or “Custom 2,” then

“Custom Tune.”

The setting display appears.

Picture EQ : Custom Tune

Color Tone Brightness0Color

ATTBack

Warm

Normal

Cool

Top

12:0015

4 Touch “Warm,” “Normal,” or “Cool” to

select “Color Tone.”

5 Touch +/– of “Brightness” and “Color”

to adjust their levels.

To return to the previous display, touch “Back.”

Note

The picture quality of the rear view camera cannot be adjusted.

You can select a picture quality suitable for the interior brightness of the car. The options are indicated below.

“Dynamic”: Vivid picture with bright, clear colors.

“Standard”: Standard picture quality. “Theater”: Brightens the monitor; suitable for

darkly-lit movies.

“Sepia”: Applies a sepia tone to the picture. “Custom 1,” “Custom 2”: User-adjustable

settings (page 48).

1 During video/image playback, touch

“Source List,” then .

2 Touch “Screen.”

The screen setting menu appears.

3 Touch “Picture EQ.”

The options appear.

4 Touch the desired option.

To return to the previous display, touch “Back.”

Selecting the aspect ratio

You can change the screen aspect ratio. The options are indicated below.

“Normal”: Picture with 4:3 aspect ratio (regular picture).

“Wide”: Picture with 4:3 aspect ratio enlarged to the left and right edges of the screen, with overflowing parts of top and bottom cut off to fill the screen.

“Full”: Picture with 16:9 aspect ratio.

“Zoom”: Picture with 4:3 aspect ratio enlarged to the left and right edges of the screen.

1 During video/image playback, touch

“Source List,” then .

2 Touch “Screen.”

The screen setting menu appears.

3 Tou ch “ Asp e ct.”

The options appear.

4 Touch the desired option.

To return to the previous display, touch “Back.”

Note

The screen aspect ratio of the rear view camera cannot be changed.

Settings

The setting menu includes the following categories.

• “General”: General settings (page 50)

• “Sound”: Sound settings (page 52)

• “Screen”: Screen settings (page 53)

• “Visual”: DVD and other playback settings

(page 54)

Basic setting operation

You can set items in the menu by the following procedure.

E.g., when setting the demonstration

1 While the unit is off, touch “Source

List,” then .

From the top menu, touch . The setting menu appears.

ATT

Back Top

Security Control

Clock Adjust

Auto OFF

Output Color System

General Sound Screen Visual

2 Touch “Screen.”

The screen setting display appears.

Back Top

Screen Select

Picture EQ

Aspect

Clock

Demo

General Sound Screen Visual

Locked

OFF / ON

NTSC / PAL

ATT

Dynamic

Full

OFF / ON

1/4

12:0015

3 Touch “Demo” to set to “ON” or “OFF.”

The setting is complete.

To scroll the options (only when required), touch v/V. To return to the previous display, touch “Back.”

General settings

Touch c “General” c the desired item c the desired option. For details on this procedure, see “Basic setting operation” on page 49.

Follow the page reference for details. “z” indicates the default setting.

Item Option Purpose Unit status

Security Control (page 57)

Clock Adjust (page 57)

Auto OFF

Shuts off automatically after a desired time when the unit is off.

CT (Clock Time) (page 21, 22)

Output Color System

Changes the color system according to the connected monitor. (SECAM is not supported.)

Dimmer

Changes the display brightness.

Dimmer Level

Sets the brightness level when the dimmer is activated.

Touch Panel Adjust (page 47)

Beep

Language

–

No (z)

30sec, 30min, 60min

OFF (z)

PAL (z: Asian model)

NTSC (z: Latin American model)

Auto (z)

(–5 ~ +5) z: 0

–

ON (z)

OFF

English

Asian model), Español (z: Latin American model),

Русский

(z:

– Any status.

To deactivate the Auto Off function.

Any status.

To select the desired time.

To activate the CT function.

To deactivate the CT

Any status.

function.

To set to PAL.

To set to NTSC.

Unit off.

To dim the display automatically when you turn lights on. (Available only when the illumination

Any status.

control lead is connected.)

To dim the display.

To select the level.

Any status.

–

Any status.

To activate the operation sound.

Any status. To deactivate the operation sound.

To select the display language.

Unit off.

Item Option Purpose Unit status

Key Illumination

ON (z)

To turn on the button illumination.

OFF

To turn off the button

Any status.

illumination.

Rotary Commander

Changes the operative direction of rotary commander controls.

AUX1 Input (page 57)

Sets the type of device connected to the AUX1 IN terminals to switch the background screen accordingly.

Default (z)

Reverse

Video (z)

Audio

OFF

To use in the factory-set position.

To use on the right side of the steering column.

To show the picture from the connected device.

To show this unit’s background screen.

To deactivate the AUX

Any status.

Unit off.

input.

AUX2 Input (page 57)

Sets the type of device connected to the AUX2 IN terminals to switch the background screen accordingly.

Video (z)

Audio

OFF

To show the picture from the connected device.

To show this unit’s background screen.

To deactivate the AUX

Unit off.

input.

No Signal

Changes the screen automatically when no external video signal is detected.

Camera Input

Activates the video input from the connected rear view camera.

Through

Blank (z)

OFF

ON (z)

To show the no signal screen.

To show the audio playback screen with no signal notification.

To deactivate the input.

To show the picture from the rear view camera when the back lamp lights up (or

Unit off.

Any status.

the shift lever is set to the R (reverse) position).

Rear View Camera Setting (page 58)

Monitor Angle (page 47)

–

Any status.

– Any status.

Sound settings

Touch c “Sound” c the desired item c the desired option. For details on this procedure, see “Basic setting operation” on page 49.

Follow the page reference for details. “z” indicates the default setting.

Item Option Purpose Unit status

EQ7 (page 44)

OFF (z)

To cancel the equalizer curve.

During reception/

playback.

During reception/

playback.

Balance/Fader (page 45)

Xplod, Vocal, Edge, Cruise, Space, Gravity, Custom

Balance: (–15 ~ +15) Fader: (–15 ~ +15) z: 0

Subwoofer: (–6 ~ +6) z: 0

To select the equalizer curve; customize the equalizer curve.

To adjust the level.

To adjust the volume level of subwoofer. (Available only when “Subwoofer” is set to “ON.”)

Listening Position (page 45)

Sets the listening position and subwoofer position.

OFF (z)

Front L

Front R

Front

All

Custom

To not set the listening position.

To set to front left.

To set to front right.

To set to center front.

To set to the center of your car.

To precisely calibrate the

During reception/

playback. listening position

(page 46).

Subwoofer: Near, Normal (z), Far

To select the subwoofer position. (Available only when “Subwoofer” is set to “ON,” and the listening position is set to “Front L,” “Front R,” “Front” or “All.”)

CSO (Center Speaker Organizer) (page 46)

Sets the virtual center speaker

OFF (z), CSO1, CSO2, CSO3

To select the mode.

During disc/USB

playback.

mode.

Subwoofer

Sets the subwoofer connection status.

ON (z)

OFF

To set the connection status to on.

Unit off. To set the connection status to off.

Item Option Purpose Unit status

RBE (Rear Bass Enhancer)

(page 46)

Uses rear speakers as a

OFF (z), RBE1, RBE2, RBE3

To select the mode.

During reception/ playback.

subwoofer.

Crossover Filter

Selects the cut-off frequency of the front/rear speakers (HPF) and subwoofer (LPF).

4.1ch Speaker Level (page 47)

LPF: 50 Hz, 60 Hz, 80 Hz, 100 Hz (z), 120 Hz

HPF: OFF (z)

HPF: 50 Hz, 60 Hz, 80 Hz, 100 Hz, 120 Hz

Subwoofer Phase: Normal (z), Reverse

–

To select the cut-off frequency. (Available only when “Subwoofer” is set to “ON.”)

To not cut out the frequency.

To select the cut-off frequency.

To select the subwoofer phase. (Available only when “Subwoofer” is set to “ON.”)

–

During reception/ playback.

Unit off.

Screen settings

Touch c “Screen” c the desired item c the desired option. For details on this procedure, see “Basic setting operation” on page 49.

Follow the page reference for details. “z” indicates the default setting.

Item Option Purpose Unit status

Screen Select (page 48)

Picture EQ (page 48)

Aspect (page 49)

Clock

Shows/hides the clock display in the bottom right corner of

–

Dynamic (z), Standard, Theater, Sepia

Custom 1, Custom 2

Full (z), Normal, Wide, Zoom

ON (z)

OFF

– Any status.

To select the picture quality.

To customize the picture

During video/ image playback.

quality.

To select the screen aspect ratio.

During video/ image playback.

To show the clock display.

To hide the clock display.

Any status.

the display.

Demo

ON (z)

To activate the demonstration.

OFF

To deactivate the

Unit off.

demonstration.

DVD and other playback settings

Touch c “Visual” c the desired item c the desired option. For details on this procedure, see “Basic setting operation” on page 49.

Follow the page reference for details. “z” indicates the default setting.

Item Option Purpose Unit status

DVD Menu Language

DVD Audio Language

DVD Subtitle Language

Audio DRC

Makes the sound clear when the volume is low. Only for a DVD* conforming to Audio DRC (Dynamic Range Control).

* Excluding DVD-R/DVD-R DL/

DVD-RW in VR mode.

Multi Ch Output

Switches the method of outputting multi channel sources.

DVD Parental Control

(page 24)

DVD Parental Rating (page 24)

DVD Parental Area (page 24)

DVD Playlist Play

(For DVD-R/DVD-R DL/ DVD-RW in VR mode only)

DVD Direct Search

(page 25)

Sets the search item of DVD direct search play.

–

Standard (z)

Wide

Multi (z)

Stereo

–

Original (z)

Playlist

Chapter (z)

Title

To change the disc’s menu language.

To change the soundtrack language.

To change the subtitle language recorded on the disc.

To select the standard setting.

To obtain the feeling of being at a live performance.

To output in 4.1 channels.

To downmix to 2 channels.

To lock/unlock a disc.

To set the restriction level according to the selected area.

To set the restriction standard by area.

To play originally recorded titles.

To play an edited playlist.

To search for a chapter.

To search for a title.

Unit off.

Any status.

Item Option Purpose Unit status

Monitor Type

Selects an aspect ratio suitable for the connected monitor. (The screen aspect ratio of this unit also changes.)

Depending on the disc, “4:3 Letter Box” may be selected automatically instead of “4:3 Pan Scan,” and vice versa.

16:9 (z)

4:3 Letter Box

To display the wide picture. Suitable when connecting to a wide-screen monitor or a monitor with a wide mode function.

To display a wide picture with bands on the upper and lower positions of the screen.

Unit off.

Suitable when connecting to a 4:3 screen monitor.

4:3 Pan Scan

To display a wide picture on the entire screen and automatically cut off the portions that do not fit.

ZAPPIN Time (page 33)

ZAPPIN Tone (page 33)

Multi Disc Resume

USB Resume

JPEG Slide Show

Video CD PBC (page 22)

6sec, 15sec (z), 30sec

ON (z)

OFF

ON (z)

OFF

ON (z)

OFF

5sec (z), 20sec, 60sec, Fixed

ON (z)

OFF

To select the playback time for the ZAPPIN function.

To have the beep sound between track passages.

To deactivate the beep sound.

To store the resume settings in memory for up to 5 video* discs.

* DVD VIDEO/VCD/DivX/

MPEG-4 only.

To not store the resume settings in memory. Resume playback is available only for the current disc in the unit.

To store resume settings in memory for DivX/MPEG-4 files in the USB device.

To not store the resume settings in memory.

To select the slide show interval.

To play VCD with the PBC function.

To play VCD without the PBC function.

During audio playback.

Unit off.

continue to next page t

Item Option Purpose Unit status

DivX VOD Registration

Done

To close the display.

Code

Displays the registration code

Unit off.

for this unit. For details, see page 61.

DivX VOD Deactivate Code

Deactivates this unit’s registration for DivX VOD

Done

To close the display.

Unit off.

playback.

Note

If parental control is applied, resume playback will not work. In this case, playback starts from the beginning of the disc when it is inserted.

Setting the security code

Using Optional Equipment

This unit has a security function to discourage theft. Enter a 4-digit number as your security code. Once the security function is activated, you need to enter the security code to turn on the unit after re-installing the unit in another car or charging the battery.

Activating the security function

1 Touch “Source List,” then .

The general setting menu appears. If not, touch “General.”

2 Touch “Security Control.”

The security code setting display appears.

3 Touch the number keys to enter your

security code, then “OK.”

4 To confirm, touch the number keys to

reenter your security code, then “OK.”

The setting is complete.

To delete an entered number, touch “Clear.” To return to the previous display, touch “Back.”

The 4-digit input prompt appears when you turn on the unit after re-installing in another car or charging the battery. Touch the number keys to enter your security code.

Deactivating the security function

1 Follow steps 1 to 2 above.

The security unlock display appears.

2 Touch the number keys to enter your security

code. “Unlocked” appears, and the security function is deactivated.

Setting the clock

The clock uses a 12-hour indication.

1 Touch “Source List,” then .

The general setting menu appears. If not, touch “General.”

2 Touch “Clock Adjust.”

The setting display appears.

3 Touch “AM” or “PM.” 4 Set the hour and minute.

For example, to set to 8:30, touch “0830.”

5 Tou ch “ OK.”

The setting is complete.

To delete an entered number, touch “Clear.” To return to the previous display, touch “Back.”

Auxiliary audio/video equipment

You can connect up to 2 optional devices, such as portable media player, game, etc., to the AUX1 IN and AUX2 IN terminals on the unit.

Selecting auxiliary device

1 Touch “Source List,” then “AUX.”

The AUX playback display appears.

Source List

AUX1 AUX2

ATT

2 Touch “AUX1” or “AUX2” to select the

device.

Operate by the portable device itself.

Adjusting the volume level

Be sure to adjust the volume for each connected device before playback. The volume level is common to “AUX1” and “AUX2.”

1 Reduce the volume on the unit. 2 Touch “Source List,” then “AUX.”

The AUX playback display appears.

3 Start playback of the portable device

at a moderate volume.

4 Set your usual listening volume on the

unit.

5 Touch –/+ in the “Level” box

repeatedly to adjust the level.

The level is adjustable in single steps, between –8 and +18.

continue to next page t

Top

Level 0

12:0015

Setting the type of device

By setting the type (video or audio) of each connected device, the background screen can be switched accordingly.

1 While the unit is off, touch “Source

List,” then .

The general setting menu appears. If not, touch “General.”

2 Touch v/V to scroll, then “AUX1 Input”

or “AUX2 Input.”

3 Touch “Audio” or “Video.”

The setting is complete.

To deactivate the AUX input, select “OFF.” To return to the previous display, touch “Back.”

Rear view camera

By connecting the optional rear view camera to the CAMERA IN terminal, you can display the picture from the rear view camera.

The picture from rear view camera appears when the back lamp lights up (or the shift lever is set to the R (reverse) position).

Notes

• When backing up your car, watch the surroundings carefully for safety. Do not depend on the rear view camera exclusively.

• The picture from a rear view camera does not appear in the rear monitor.

Tip

Even if a rear view camera is connected, you can set to not display the picture from a rear view camera by deactivating the camera input (page 51).

Rear view camera settings

You can display setting items on the picture from the rear view camera to assist operation.

This setting is available only when: – “Camera Input” is set to “ON” (page 51). – the parking brake is applied.

1 Touch “Source List,” then .

The general setting menu appears. If not, touch “General.”

2 Touch v/V to scroll, then “Rear View

Camera Setting.”

The setting items appear.

Back

Turn off engine but keep the key in the “IGN” position.

Displaying marker lines

Touch “Marker.” Touch “Marker” again to hide the marker lines.

Reversing the picture

Touch “Mirror.” A mirror reversed picture appears.

Editing lines

1 Touch “Line Edit.”

Marker

Mirror

Line Edit

Back

1 Edit

2 Edit

3 Edit

Turn off engine but keep the key in the “IGN” position.

Reset

2 Select the line to edit.

Touch “1 Edit,” “2 Edit” or “3 Edit” corresponding to the line to edit.

3 Edit the line.

To increase the length, touch B b. To reduce the length, touch bB. To adjust the position, touch V or v. To restore the default setting, touch “Reset.”

To return to the previous display, touch “Back.”

Additional Information

Precautions

• Cool off the unit beforehand if your car has been

parked in direct sunlight.

• Power antenna (aerial) extends automatically.

Moisture condensation

Should moisture condensation occur inside the unit, remove the disc and wait for about an hour for it to dry out; otherwise the unit will not operate properly.

To maintain high sound quality

Do not splash liquid onto the unit or discs.

Notes on LCD panel

• Do not press on the LCD panel as doing so can

distort the picture or cause a malfunction (i.e., the picture may become unclear, or the LCD panel may be damaged).

• Do not touch other than with the finger, as it may

damage or break the LCD panel.

• Clean the LCD panel with a dry soft cloth. Do not

use solvents such as benzine, thinner, commercially available cleaners, or antistatic spray.

• Do not use this unit outside the temperature range

5 – 45 ºC (41 – 113 ºF).

• If your car was parked in a cold or hot place, the

picture may not be clear. However, the monitor is not damaged, and the picture will become clear after the temperature in your car becomes normal.

• Some stationary blue, red or green dots may

appear on the monitor. These are called “bright spots,” and can happen with any LCD. The LCD panel is precision-manufactured with more than

99.99 % of its segments functional. However, it is possible that a small percentage (typically 0.01 %) of the segments may not light up properly. This will not, however, interfere with your viewing.

Notes on discs

• Do not expose discs to direct sunlight or heat

sources such as hot air ducts, nor leave it in a car parked in direct sunlight.

• Before playing, wipe the discs

with a cleaning cloth from the center out. Do not use solvents such as benzine, thinner, commercially available cleaners.

• This unit is designed to play back discs that conform to the Compact Disc (CD) standard. DualDiscs and some of the music discs encoded with copyright protection technologies do not conform to the Compact Disc (CD) standard, therefore, these discs may not be playable by this unit.

• Discs that this unit CANNOT play – Discs with labels, stickers, or sticky tape or

paper attached. Doing so may cause a malfunction, or may ruin the disc.

– Discs with non-standard shapes (e.g., heart,

square, star). Attempting to do so may damage the unit.

–8 cm (3

/4 in) discs.

Note on playback operations of DVDs and VCDs

Some playback operations of DVDs and VCDs may be intentionally set by software producers. Since this unit plays DVDs and VCDs according to the disc contents the software producers designed, some playback features may not be available. Also, refer to the instructions supplied with the DVDs or VCDs.

Notes on DATA CDs and DATA DVDs

• Some DATA CDs/DATA DVDs (depending on the equipment used for its recording, or the disc condition) may not play on this unit.

• Finalization is required for some discs (page 60).

• The unit is compatible with the following standards. For DATA CDs – ISO 9660 level 1/level 2 format, Joliet/Romeo in

the expansion format – Multi Session For DATA DVDs – UDF Bridge format (combined UDF and ISO

9660)

–Multi Border

• The maximum number of: – folders (albums): 256 (including root and empty

folders).

– files (tracks/images/videos) and folders

contained in a disc: 2,000 (if a folder/file names contain many characters, this number may become less than 2,000).

– displayable characters for a folder/file name: 64

(Joliet/Romeo).

continue to next page t

Notes on finalizing discs

The following discs are required to be finalized to play on this unit.

• DVD-R/DVD-R DL (in video mode/VR mode)

• DVD-RW in video mode

• DVD+R/DVD+R DL

•CD-R

•CD-RW

The following discs can be played without finalization.

• DVD+RW – automatically finalized.

• DVD-RW in VR mode – finalization not required.

For details, see the manual supplied with the disc.

Notes on Multi Session CDs/Multi Border DVDs

This unit can play Multi Session CDs/Multi Border DVDs under the following conditions. Note that the session must be closed and the disc must be finalized.

• When CD-DA (Compact Disc Digital Audio) is recorded in the first session: The unit recognizes the disc as CD-DA and only CD-DA of the first session is played, even if an other format (e.g., MP3) is recorded in other sessions.

• When CD-DA is recorded other than in the first session: The unit recognizes the disc as a DATA CD or DATA DVD, and all CD-DA sessions are skipped.

• When an MP3/WMA/AAC/JPEG/DivX/MPEG-4 is recorded: Only the sessions containing the selected file type (audio/video/image)* are played (if CD-DA or other data exists in other sessions, they are skipped).

* For details on how to select the file type, see

page 33.

Playback order of MP3/WMA/AAC/ JPEG/DivX

/MPEG-4 files

MP3/WMA/AAC/ JPEG/DivX/ MPEG-4

Folder (album)

MP3/WMA/AAC/ JPEG/DivX/ MPEG-4 file (track/image/ video)

About MP3 files

• MP3, which stands for MPEG-1 Audio Layer-3, is a music file compression format standard. It compresses audio CD data to approximately 1/10 of its original size.

• ID3 tag versions 1.0, 1.1, 2.2, 2.3 and 2.4 apply to MP3 only. ID3 tag is 15/30 characters (1.0 and

1.1), or 63/126 characters (2.2, 2.3 and 2.4).

• When naming an MP3 file, be sure to add the file extension “.mp3” to the file name.

• During playback or fast-forward/reverse of a VBR (Variable Bit Rate) MP3 file, elapsed playback time may not display accurately.

Note on MP3

If you play a high-bit-rate MP3, such as 192 kbps, sound may be intermittent.

About WMA files

• WMA, which stands for Windows Media Audio, is a music file compression format standard. It compresses audio CD data to approximately 1/22* of its original size.

• WMA tag is 63 characters.

• When naming a WMA file, be sure to add the file extension “.wma” to the file name.

• During playback or fast-forward/reverse of a VBR (Variable Bit Rate) WMA file, elapsed playback time may not display accurately.

* only for 64 kbps

Note on WMA

Playback of the following WMA files is not supported. – lossless compression – copyright-protected

About AAC files

• AAC tag is 126 characters.

• When naming an AAC file, be sure to add the file extension “.m4a” to the file name.

About JPEG files

• JPEG, which stands for Joint Photographic Experts Group, is an image file compression format standard. It compresses still images approximately 1/10 to 1/100 of original size.

• When naming a JPEG file, be sure to add the file extension “.jpg” to the file name.

Note on JPEG

Playback of progressive JPEG files is not supported.

About DivX video

DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert files into DivX video.

About DivX Video-on-Demand

This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the visual setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD.

About MPEG-4 files

MPEG-4 files meeting the following requirements can be played. Playback is not be guaranteed for all MPEG-4 files meeting the requirements.

• Profile: MPEG-4 Simple profile

• Bit rate: Max. 7 Mbps on USB FS, 10 Mbps on DVD, 7 Mbps on CD

• Frame rate: Max. 30 fps

• Image size: Max. 720 × 480 pixels

• Audio: Max. 320 kbps (AAC-LC)

• File extension: .mp4

About iPod

• You can connect to the following iPod models. Update your iPod devices to the latest software before use.

Made for – iPod touch – iPod touch (2nd generation) – iPod classic – iPod classic (120GB) – iPod with video* – iPod nano (4th generation) – iPod nano (3rd generation) – iPod nano (2nd generation) – iPod nano (1st generation)*

Wor ks wit h – iPhone – iPhone 3G – iPhone 3GS

* Passenger control is not available for iPod nano (1st

generation) or iPod with video.

• “Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards.

• “Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone and has been certified by the developer to meet Apple performance standards.

• Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

About Bluetooth function

What is Bluetooth technology?

• Bluetooth wireless technology is a short-range wireless technology that enables wireless data communication between digital devices, such as a cellular phone and a headset. Bluetooth wireless technology operates within a range of about 10 m (about 33 feet). Connecting two devices is common, but some devices can be connected to multiple devices at the same time.

• You do not need to use a cable for connection since Bluetooth technology is a wireless technology, neither is it necessary for the devices to face one another, such is the case with infrared technology. For example, you can use such a device in a bag or pocket.

• Bluetooth technology is an international standard supported by millions of companies all over the world, and employed by various companies worldwide.

On Bluetooth communication

• Bluetooth wireless technology operates within a range of about 10 m. Maximum communication range may vary depending on obstacles (person, metal, wall, etc.) or electromagnetic environment.

• The following conditions may affect the sensitivity of Bluetooth communication. – There is an obstacle such as a person, metal, or

wall between this unit and Bluetooth device.

– A device using 2.4 GHz frequency, such as a

wireless LAN device, cordless telephone, or microwave oven, is in use near this unit.

• Because Bluetooth devices and wireless LAN (IEEE802.11b/g) use the same frequency, microwave interference may occur and result in communication speed deterioration, noise, or invalid connection if this unit is used near a wireless LAN device. In such as case, perform the following. – Use this unit at least 10 m away from the

wireless LAN device.

– If this unit is used within 10 m of a wireless

LAN device, turn off the wireless LAN device.

– Install this unit and Bluetooth device as near to

each other as possible.

• Microwaves emitting from a Bluetooth device may affect the operation of electronic medical devices. Turn off this unit and other Bluetooth devices in the following locations, as it may cause an accident. – where inflammable gas is present, in a hospital,

train, airplane, or petrol station

– near automatic doors or a fire alarm

• This unit supports security capabilities that comply with the Bluetooth standard to provide a secure connection when the Bluetooth wireless technology is used, but security may not be enough depending on the setting. Be careful when communicating using Bluetooth wireless technology.

continue to next page t

• We do not take any responsibility for the leakage of information during Bluetooth communication.

• Connection with all Bluetooth devices cannot be guaranteed. – A device featuring Bluetooth function is

required to conform to the Bluetooth standard specified by Bluetooth SIG, and be authenticated.

– Even if the connected device conforms to the

above mentioned Bluetooth standard, some devices may not be connected or work correctly, depending on the features or specifications of the device.

– While talking on the phone handsfree, noise may

occur, depending on the device or communication environment.

• Depending on the device to be connected, it may require some time to start communication.

Others

• Using the Bluetooth device may not function on cellular phones, depending on radio wave conditions and location where the equipment is being used.

• If you experience discomfort after using the Bluetooth device, stop using the Bluetooth device immediately. Should any problem persist, consult your nearest Sony dealer.

If you have any questions or problems concerning your unit that are not covered in this manual, consult your nearest Sony dealer.

WARNING

Battery may explode if mistreated. Do not recharge, disassemble, or dispose of in fire.

Fuse replacement

When replacing the fuse, be sure to use one matching the amperage rating stated on the original fuse. If the fuse blows, check the power connection and replace the fuse. If the fuse blows again after replacement, there may be an internal malfunction. In such a case, consult your nearest Sony dealer.

Fuse (10A)

Removing the unit

1 Insert both release keys

simultaneously until they click.

Maintenance

Replacing the lithium battery of the card remote commander

Under normal conditions, the battery will last approximately 1 year. (The service life may be shorter, depending on the conditions of use.) When the battery becomes weak, the range of the card remote commander becomes shorter. Replace the battery with a new CR2025 lithium battery. Use of any other battery may present a risk of fire or explosion.

+ side up

Notes on the lithium battery

• Keep the lithium battery out of the reach of children. Should the battery be swallowed, immediately consult a doctor.

• Wipe the battery with a dr y cloth to assure a good contact.

• Be sure to observe the correct polarity when installing the battery.

• Do not hold the battery with metallic tweezers, otherwise a short-circuit may occur.

Hook facing inwards.

2 Pull the release keys to unseat the

unit.

3 Slide the unit out of the mounting.

Specifications

Monitor section

Display type: Wide LCD color monitor Dimensions: 7.0 in System: TFT active matrix Number of pixels: 1,152,000 pixels Color system:

PAL/NTSC/SECAM/PAL-M automatic select

Tuner section

Tuning range:

Asian model:

87.5 – 108.0 MHz (at 50 kHz step) Latin American model:

87.5 – 107.9 MHz (at 200 kHz step)

Antenna (aerial) terminal:

External antenna (aerial) connector

Intermediate frequency: 150 kHz Usable sensitivity: 10 dBf Selectivity: 75 dB at 400 kHz Signal-to-noise ratio: 70 dB (mono) Separation: 40 dB at 1 kHz Frequency response: 20 – 15,000 Hz

Tuning range:

Asian model: 531 – 1,602 kHz (at 9 kHz step) Latin American model: 530 – 1,710 kHz (at 10 kHz step)

Antenna (aerial) terminal:

External antenna (aerial) connector

Intermediate frequency: 25 kHz Sensitivity: 26 µV

DVD/CD Player section

Signal-to-noise ratio: 120 dB Frequency response: 10 – 20,000 Hz Wow and flutter: Below measurable limit Harmonic distortion: 0.01 % Region code: Labeled on the bottom of the unit

USB Player section

Interface: USB (Full-speed) Maximum current: 500 mA

Wireless Communication

Communication System:

Bluetooth Standard version 2.0 + EDR

Output:

Bluetooth Standard Power Class 2 (Max. +4 dBm)

Maximum communication range:

Line of sight approx. 10 m (33 ft)*

Frequency band:

2.4 GHz band (2.4000 – 2.4835 GHz)

Modulation method: FHSS Compatible Bluetooth Profiles*

A2DP (Advanced Audio Distribution Profile) AVRCP (Audio Video Remote Control Profile) 1.3 HFP (Handsfree Profile) 1.5 PBAP (Phone Book Access Profile) OPP (Object Push Profile)

*1 The actual range will vary depending on factors

such as obstacles between devices, magnetic fields around a microwave oven, static electricity, reception sensitivity, antenna’s performance, operating system, software application, etc.

*2 Bluetooth standard profiles indicate the purpose of

Bluetooth communication between devices.

Power amplifier section

Outputs: Speaker outputs Speaker impedance: 4 – 8 ohms Maximum power output: 52 W × 4 (at 4 ohms)

General

Outputs:

Video output terminal (rear) Audio output terminals (front/rear) Subwoofer output terminal Power antenna (aerial) relay control terminal Power amplifier control terminal

Inputs:

Telephone ATT control terminal Illumination control terminal Remote controller input terminal Antenna (aerial) input terminal Parking break control terminal Microphone input terminal Reverse input terminal Camera input terminal AUX audio input terminals AUX video input terminals USB signal input connector External input terminal (Asian model only)

Power requirements: 12 V DC car battery

(negative ground (earth))

Dimensions: Approx. 178 × 100 × 189 mm

/8 × 4 × 71/2 in) (w/h/d)

Mounting dimensions: Approx. 182 × 111 × 164 mm

/4 × 43/8 × 61/2 in) (w/h/d)

Mass: Approx. 2.5 kg (5 lb 9 oz) Supplied accessories:

Card remote commander: RM-X170 Parts for installation and connections (1 set) Extension cord for AUX audio/video input terminals Microphone: XA-MC10 CD-ROM (Application disc)

Optional accessories/equipment:

Mobile monitor: XVM-B62 (For Asian model) USB connection cable for iPod: RC-200IPV Rear View Camera: XA-R800C

Your dealer may not handle some of the above listed accessories. Please ask the dealer for detailed information.

US and foreign patents licensed from Dolby Laboratories.

MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson.

continue to next page t

This product is protected by certain intellectual property rights of Microsoft Corporation. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft or an authorized Microsoft subsidiary.

Design and specifications are subject to change without notice.

• Halogenated flame retardants are not used in the certain printed wiring boards.

• Halogenated flame retardants are not used in cabinets.

• Packaging cushions are made from paper.

Region code

The region system is used to protect software copyrights. The region code is located on the bottom of the unit, and only DVDs labeled with an identical region code can be played on this unit.

DVDs labeled can also be played.

If you try to play any other DVD, the message “Playback prohibited by region code.” will appear on the monitor screen. Depending on the DVD, no region code may be labeled even though playing the DVD is prohibited by area restrictions.

ALL

System requirements for the software in the supplied CD-ROM

Computer

•CPU/RAM – IBM PC/AT compatible machine – CPU: Intel Pentium III Processor 450 MHz or

higher

– RAM: 256 MB or more (For Windows XP), 512

MB or more (For Windows Vista or later)

• CD-ROM drive

• USB port

Windows XP, Windows Vista, Windows 7 For details on compatible editions or Service Pack, visit

the following support site:

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

Monitor

High color (16-bit) or more, 800 × 600 dots or more

Other

Internet connection

Notes

• The following system environments are not supported. – Non IBM PC type computers, such as Macintosh,

etc. – Homemade computers – OS upgraded computers – Multi-display environment – Multi-boot environment – Virtual machine environment

• Depending on the computer condition, operation may not be possible even with the recommended environment.

Troubleshooting

The following checklist will help you remedy problems you may encounter with your unit. Before going through the checklist below, check the connection and operating procedures.

If the problem is not solved, visit the following support site.

Support site

Customers in Latin America:

http://esupport.sony.com/ES/LA/

Customers in Pan Asia:

http://www.sony-asia.com/section/support http://www.sony-asia.com/caraudio/

General

No power is being supplied to the unit.

• Check the connection or fuse.

• If the unit is turned off and the display disappears, it cannot be operated with the remote commander.

t Turn on the unit.

The power antenna (aerial) does not extend.

The power antenna (aerial) does not have a relay box.

No beep sound.

• The beep sound is canceled (page 50).

• An optional power amplifier is connected and you are not using the built-in amplifier.

The contents of the memory have been erased.

• The reset button has been pressed.

t Store again into the memory.

• The power supply lead or battery has been disconnected or it is not connected properly.

Stored stations and correct time are erased. The fuse has blown. Makes noise when the position of the ignition is switched.

The leads are not matched correctly with the car’s accessory power connector.

The display disappears from/does not appear on the monitor.

• The dimmer is set to “ON” (page 50).

• The display disappears if you press and hold

(SOURCE/OFF).

t Press (SOURCE/OFF) on the unit until the

display appears.

“M.OFF” is touched and the Monitor Off function

• is activated (page 11).

t Touch anywhere on the display to turn back on.

The display does not respond to your touch correctly.

• Touch one part of the display at a time. If two or more parts are touched simultaneously, the display will not operate correctly.

• Adjust the touch point of the display (page 47).

The Auto Off function does not operate.

The unit is turned on. The Auto Off function activates after turning off the unit. tTurn off the unit.

Card remote commander operation is not possible.

If the Monitor Off function is activated (no lighting), card remote commander operation is not possible (page 11).

The menu items cannot be selected.

Unavailable menu items are shown in grey.

AUX cannot be selected as the source.

All AUX input settings are set to “OFF.”

t Set “AUX1 Input”/“AUX2 Input” to “Video” or

“Audio” (page 58).

Radio reception

The stations cannot be received. The sound is hampered by noises.

• The connection is not correct.

t Connect a power antenna (aerial) control lead

(blue) or accessory power supply lead (red) to the power supply lead of a car’s antenna (aerial) booster (only when your car has built-in FM/AM antenna (aerial) in the rear/side glass).

t Check the connection of the car antenna (aerial). t If the auto antenna (aerial) will not go up, check

the connection of the power antenna (aerial) control lead.

Preset tuning is not possible.

• Store the correct frequency in the memory.

• The broadcast signal is too weak.

Automatic tuning is not possible.

• Setting of the local seek mode is not correct.

t Tuning stops too frequently:

Set “Local” to “ON” (page 16).

t Tuning does not stop at a station:

Set “Mono” to “ON” (page 16).

• The broadcast signal is too weak.

t Perform manual tuning.

During FM reception, the “Stereo” indication flashes.

• Tune in the frequency accurately.

• The broadcast signal is too weak.

t Set “Mono” to “ON” (page 16).

An FM program broadcast in stereo is heard in monaural.

The unit is in monaural reception mode. t Set “Mono” to “OFF” (page 16).

RDS

PTY displays “None.”

• The current station is not an RDS station.

• RDS data has not been received.

• The station does not specify the program type.


There is no picture/picture noise occurs.

• A connection has not been made correctly.

• Check the connection to the connected equipment, and set the input selector of the equipment to the source corresponding to this unit.

• Defective or dirty disc.

• Installation is not correct.

t Install the unit at an angle of less than 45° in a

sturdy part of the car.

• The parking cord (light green) is not connected to the parking brake switch cord, or the parking brake is not applied.

Picture does not fit in the screen.

The aspect ratio is fixed on the DVD.

There is no picture/picture noise occurs in the rear monitor.

• The source/mode which is not connected is selected. If there is no input, no picture appears in the rear monitor.

• The color system setting is incorrect.

t Set the color system to “PAL” or “NTSC”

according to the connected monitor (page 50).

• The picture of the rear view camera is displayed on this unit.

t No picture appears in the rear monitor if the

picture of the rear view camera is displayed on this unit.

continue to next page t

Sound

There is no sound/sound skips/sound cracks.

• A connection has not been made correctly.

• Check the connection to the connected equipment, and set the input selector of the equipment to the source corresponding to this unit.

• Defective or dirty disc.

• Installation is not correct.

tInstall the unit at an angle of less than 45° in a

sturdy part of the car.

• The MP3 file sampling rate is not 32, 44.1 or 48 kHz.

• The WMA file sampling rate is not 32, 44.1 or 48 kHz.

• The AAC file sampling rate is not 44.1 or 48 kHz.

• The MP3 file bit rate is not 48 to 192 kbps.

• The WMA file bit rate is not 64 to 192 kbps.

• The AAC file bit rate is not 40 to 320 kbps.

• The unit is in pause/reverse/fast-forward mode.

• The settings for the outputs are not made correctly.

• The DVD output level is too low (page 23).

• The volume is too low.

• The ATT function is activated, or the Telephone ATT function (when the interface cable of a car telephone is connected to the ATT lead) is activated.

• The position of the fader control “Fader” is not set for a 2-speaker system.

• Unsupported format (such as DTS).

tCheck if the format is supported by this unit

(page 9).

Sound is noisy.

Keep cords and cables away from each other.

Disc operation

The disc cannot be loaded.

• Another disc is already loaded.

• The disc has been forcibly inserted upside down or in the wrong way.

The disc does not play back.

• Defective or dirty disc.

• The disc is not applicable.

• The DVD is not applicable due to the region code.

• The disc is not finalized (page 60).

• The disc format and file version are incompatible with this unit (page 9, 59).

• Press Z to remove the disc.

MP3/WMA/AAC/JPEG/DivX/MPEG-4 files do not play back.

• Recording was not performed according to the ISO 9660 level 1 or level 2, the Joliet or Romeo in the expansion format (DATA CD), or the UDF Bridge format (DATA DVD) (page 59).

• The file extension is incorrect (page 60).

• Files are not stored in MP3/WMA/AAC/JPEG/DivX/ MPEG-4 format.

• If the disc contains multiple file types, only the selected file type (audio/video/image) can be played.

tSelect the appropriate file type using the list

(page 33).

MP3/WMA/AAC/JPEG/DivX/MPEG-4 files take longer to play back than others.

The following discs take a longer time to start playback. – a disc recorded with a complicated tree structure. – a disc recorded in Multi Session/Multi Border. – a disc to which data can be added.

The disc does not start playing from the beginning.

Resume playback or multi-disc resume playback (page 55) has taken effect.

Certain functions cannot be performed.

Depending on the disc, you may not be able to perform operations such as stop, search, or repeat/shuffle play. For details, see the manual supplied with the disc.

The soundtrack/subtitle language or angle cannot be changed.

• Use the DVD menu instead of the direct selection button on the card remote commander (page 17).

• Multilingual tracks, multilingual subtitles, or multiangles are not recorded on the DVD.

• The DVD prohibits changing.

The operation buttons do not function. The disc will not eject.

Press the reset button (page 14).

You forgot the password for parental control.

Enter “5776” in the password input display to unlock (page 24).

USB playback

Cannot play back items via a USB hub.

This unit cannot recognize USB devices via a USB hub.

Cannot play back items.

Reconnect the USB device.

The USB device takes longer to play back.

The USB device contains large-sized files or files with a complicated tree structure.

A beep sounds.

During playback, the USB device has been disconnected. t Before disconnecting a USB device, make sure to

stop playback first for data protection.

The sound is intermittent.

The sound may be intermittent at a high-bit-rate of more than 320 kbps.

Bluetooth function

The other Bluetooth device cannot detect this unit.

• Set “Signal” to “ON” (page 44).

• Set “Discoverable” to “Show” (page 44).

• While connecting to the other Bluetooth device, this unit cannot be detected from another device. Disconnect the current connection and search for this unit from another device. The disconnected device can be reconnected by selecting from the list of registered devices.

This unit cannot detect the other Bluetooth device.

Check the Bluetooth setting of the other device.

Connection is not possible.

• Depending on the other device, searching from this unit may not be possible.

t Search for this unit from the other device.

• Depending on the status of the other device, searching from this unit may not be possible.

t Search for this unit from the other device.

• Check the pairing and connection procedures in the manual of the other device, etc., and perform the operation again.

The name of the detected device does not appear.

Depending on the status of the other device, it may not be possible to obtain the name.

No ring tone.

• Raise the volume while receiving a call.

• Depending on the connecting device, the ring tone may not be sent properly.

t Set “Ringtone” to “Default” (page 44).

The talker’s voice volume is low.

Raise the volume during a call.

The other party says that the volume is too low or high.

Adjust the “MIC Gain” level (page 39).

Echo or noise occurs in phone call conversations.

• Reduce the volume.

• “EC/NC Mode” is set to “OFF.”

t Set “EC/NC Mode” to “Mode 1” or “Mode 2”

(page 44).

• If ambient noise other than the phone call sound is loud, try reducing this noise. E.g.: If a window is open and road noise, etc., is loud, shut the window. If the air conditioner is loud, lower the air conditioner.

The phone sound quality is poor.

Phone sound quality depends on reception conditions of cellular phone. tMove your car to a place where you can enhance

the cellular phone’s signal if the reception is poor.

The volume of the connected Bluetooth device is low or high.

Volume level will differ depending on the Bluetooth device. tReduce the volume level differences between this

unit and the Bluetooth device (page 43).

No sound is output during audio streaming.

The connected Bluetooth device is paused. tCancel pause of the Bluetooth device.

The sound skips during audio streaming.

• Reduce the distance between the unit and the Bluetooth device.

• If the Bluetooth device is stored in a case which interrupts the signal, remove the case while using.

• Several Bluetooth devices or other devices which emit radio waves are used nearby.

t Turn off the other devices. t Increase the distance from the other devices.

• The playback sound stops momentarily when this unit is connecting to a cellular phone. This is not a malfunction.

You cannot control the connected Bluetooth device during audio streaming.

Check that the connected Bluetooth device supports AV R C P.

Some functions do not work.

Check that the connecting device supports the functions in question.

The name of the other party does not appear when a call is received.

• The other party is not stored in the phonebook.

t Store in the phonebook (page 40).

• The calling phone is not set to send the phone number.

A call is answered unintentionally.

• The connecting phone is set to start a call automatically.

• “Auto Answer” of this unit is set to “Short” or “Long” (page 44).

Pairing failed due to time out.

Depending on the connecting device, the time limit for pairing may be short. Try completing the pairing within the time by setting a single digit passkey.

Bluetooth function cannot be operated.

Turn off the unit by pressing (SOURCE/OFF) for 1 second, then turn on the unit.

No sound is output from the car speakers during handsfree call.

If the sound is output from the cellular phone, set the cellular phone to output the sound from the car speakers.

Error displays/messages

Bluetooth device is not found.

The unit cannot detect a connectable Bluetooth device. t Check the Bluetooth setting of the connecting

device.

Busy now… Please try again.

The unit is busy. t Wait for a moment and try again.

Cannot read.

• The unit cannot read the data due to some problem.

• The data is damaged or corrupted.

continue to next page t

Cannot read disc. Disc may be corrupted.

• The disc is corrupted.

• The disc is incompatible with this unit.

• The disc is not finalized.

Disc Error

• The disc is dirty or inserted upside down.

tClean or insert the disc correctly.

• A blank disc has been inserted.

• The disc cannot play due to a problem.

tInsert another disc.

• The disc is not compatible with this unit.

tInsert a compatible disc.

• Press Z to remove the disc.

Disc Reading...

The unit is reading all file/album (folder) information on the disc. t Wait until reading is complete and playback starts

automatically. Depending on the disc structure, it may take more than a minute.

Error

• USB device was not automatically recognized.

tReconnect it again.

• Phonebook content is changed during cellular phone access.

tAccess the phonebook again.

• Phonebook access is disconnected by the cellular phone.

tAccess the phonebook again.

• Phonebook download of the cellular phone failed due to a problem.

tDownload the phonebook again (page 40).

• Phonebook browsing of the cellular phone failed due to a problem.

tRetry browsing (page 41).

• Phonebook listing of the cellular phone failed due to a problem.

tRetry listing (page 41).

Error - Please select ‘initialize’ from the Bluetooth settings menu.

A memory error has occurred. t Initialize the Bluetooth setting (page 44).

Handsfree device is not available.

A cellular phone is not connected. t Connect a cellular phone (page 36).

Hubs not supported.

USB hub is not supported on this unit.

Local Seek +/Local Seek –

The local seek mode is on during automatic tuning.

No device found.

No device is in the list of registered Bluetooth device. t Perform pairing with a Bluetooth device (page 35).

No playable data.

The disc does not contain playable data.

No SensMe™ data on device.

The connected USB device does not contain data for the SensMe™ function, or the data has been moved to an improper location in the USB device.

Offset

There may be an internal malfunction. t Check the connection. If the error indication

remains on in the display, consult your nearest Sony dealer.

Output connection failure.

The connection of speakers/amplifiers is incorrect. t See the supplied installation/connections manual to

check the connection.

Overcurrent Caution on USB

The USB device is overloaded. t Disconnect the USB device, then change the source

by pressing (SOURCE/OFF).

t Indicates that the USB device is out of order, or an

unsupported device is connected.

Playback prohibited by region code.

The DVD playback is prohibited due to the different region code.

Please push reset.

This unit or USB device cannot be operated due to a problem. t Press the reset button (page 14).

SensMe™ data Reading...

The unit is reading all data for the SensMe™ function in the connected USB device. t Wait until reading is complete. Depending on the

amount of data, etc., it may take time.

The connected USB device is not supported.

For details on the compatibility of your USB device, visit the support site.

The SensMe™ data is corrupted.

The data for the SensMe™ function has a problem, such as altered file name, information, etc.

USB device is not connected.

USB is selected as source without a USB device connected. A USB device or a USB cable has been disconnected during playback. t Be sure to connect a USB device and USB cable.

USB Reading...

The unit is reading all file/album (folder) information in the connected USB device. t Wait until reading is complete and playback starts

automatically. Depending on the structure, it may take time.

“” or “”

During reverse or fast-forward, you have reached the beginning or the end of the disc and you cannot go any further.

“”

The character cannot be displayed with the unit.

If these solutions do not help improve the situation, consult your nearest Sony dealer. If you take the unit to be repaired because of disc playback trouble, bring the disc that was used at the time the problem began.

Language code/area code list

Language code list

The language spellings conform to the ISO 639: 1988 (E/F) standard.

Code Language Code Language Code Language Code Language

1027 Afar 1028 Abkhazian 1032 Afrikaans 1039 Amharic 1044 Arabic 1045 Assamese 1051 Aymara 1052 Azerbaijani 1053 Bashkir 1057 Byelorussian 1059 Bulgarian 1060 Bihari 1061 Bislama 1066 Bengali;

Bangla 1067 Tibetan 1070 Breton 1079 Catalan 1093 Corsican 1097 Czech 1103 Welsh 1105 Danish 1109 German 1130 Bhutani 1142 Greek 1144 English 1145 Esperanto 1149 Spanish 1150 Estonian 1151 Basque 1157 Persian 1165 Finnish 1166 Fiji 1171 Faroese 1174 French 1181 Frisian

1183 Irish 1186 Scots Gaelic 1194 Galician 1196 Guarani 1203 Gujarati 1209 Hausa 1217 Hindi 1226 Croatian 1229 Hungarian 1233 Armenian 1235 Interlingua 1239 Interlingue 1245 Inupiak 1248 Indonesian 1253 Icelandic 1254 Italian 1257 Hebrew 1261 Japanese 1269 Yiddish 1283 Javanese 1287 Georgian 1297 Kazakh 1298 Greenlandic 1299 Cambodian 1300 Kannada 1301 Korean 1305 Kashmiri 1307 Kurdish 1311 Kirghiz 1313 Latin 1326 Lingala 1327 Laothian 1332 Lithuanian 1334 Latvian;

Lettish

1345 Malagasy

1347 Maori 1349 Macedonian 1350 Malayalam 1352 Mongolian 1353 Moldavian 1356 Marathi 1357 Malay 1358 Maltese 1363 Burmese 1365 Nauru 1369 Nepali 1376 Dutch 1379 Norwegian 1393 Occitan 1403 (Afan)Oromo 1408 Oriya 1417 Punjabi 1428 Polish 1435 Pashto;

Pushto 1436 Portuguese 1463 Quechua 1481 Rhaeto-

Romance 1482 Kirundi 1483 Romanian 1489 Russian 1491 Kinyarwanda 1495 Sanskrit 1498 Sindhi 1501 Sangho 1502 Serbo-

Croatian 1503 Singhalese 1505 Slovak 1506 Slovenian

1507 Samoan 1508 Shona 1509 Somali 1511 Albanian 1512 Serbian 1513 Siswati 1514 Sesotho 1515 Sundanese 1516 Swedish 1517 Swahili 1521 Tamil 1525 Telugu 1527 Tajik 1528 Thai 1529 Tigrinya 1531 Turkmen 1532 Tagalog 1534 Setswana 1535 Tonga 1538 Turkish 1539 Tsonga 1540 Tatar 1543 Twi 1557 Ukrainian 1564 Urdu 1572 Uzbek 1581 Vietnamese 1587 Volapük 1613 Wolof 1632 Xhosa 1665 Yoruba 1684 Chinese 1697 Zulu

1703 Not specified

Area code list

Code Area Code Area Code Area Code Area

2044 Argentina 2047 Australia 2046 Austria 2057 Belgium 2070 Brazil 2079 Canada 2090 Chile 2092 China 2115 Denmark

2165 Finland 2174 France 2109 Germany 2248 India 2238 Indonesia 2254 Italy 2276 Japan 2304 Korea 2363 Malaysia

2362 Mexico 2376 Netherlands 2390 New Zealand 2379 Norway 2427 Pakistan 2424 Philippines 2436 Portugal 2489 Russia 2501 Singapore

2149 Spain 2499 Sweden 2086 Switzerland 2528 Thailand 2184 United

Kingdom

Index

AAC 9, 60 Angle (Angle) 19 Area code 69 Audio channel (Stereo) 23 Audio DRC (Audio DRC) 54 Audio format (Audio) 23 Audio streaming 43 Auto Off (Auto OFF) 50 Automatic answer (Auto Answer) 44 Auxiliary equipment 57 Auxiliary level (Level) 57 Auxiliary settings (AUX1 Input, AUX2 Input) 51, 58

Background screen (Screen Select) 48 Balance (Balance/Fader) 45, 52 Best Tuning Memory (BTM) 21 Bluetooth 34 Bluetooth setting initialization (Initialize) 44 Bluetooth settings 43 Bluetooth signal (Signal) 36, 44 Button illumination (Key Illumination) 51

Card remote commander 12, 14, 62 Center Speaker Organizer (CSO) 46, 52 Clock display (Clock) 11, 53 Clock setting (Clock Adjust) 57 Clock Time (CT) 21, 22, 50 Crossover filter (Crossover Filter) 53

Demonstration (Demo) 53 Dimmer level (Dimmer Level) 50 Dimmer setting (Dimmer) 50 Discs 9 Display language (Language) 14, 50 DivX Video-on-Demand 56, 61 DivX® 9, 60 Dolby D level (Dolby D Level) 23 Dolby Digital 23 DVD audio language (Audio, DVD Audio Language) 23, 54 DVD control menu (DVD Control) 19 DVD direct search play (DVD Direct Search) 25, 54 DVD menu 17 DVD menu language (DVD Menu Language) 54 DVD playlist play (DVD Playlist Play) 54 DVD’s top menu (Top Menu) 17, 19 Dynamic Range Control (DRC) 54

Echo Canceller/Noise Canceller Mode (EC/NC Mode) 44 EQ7 44, 52

Fader (Balance/Fader) 45, 52 Formats 9 Fuse 62

General settings (General) 50 Gesture Command 34

Handsfree calling 37 High Pass Filter (HPF) 53

Image rotate (Image Turn) 19 Initial settings (Initial Setting) 14 Intelligent Time Alignment 45, 46 iPod 31, 61

JPEG 9, 60

Language code 69 List up (List) 33 Listening position (Listening Position) 45, 52 Local seek mode (Local) 16 Low Pass Filter (LPF) 53

Microphone gain (MIC Gain) 39, 44 Monaural mode (Mono) 16 Monitor angle (Monitor Angle) 47 Monitor type (Monitor Type) 55 MP3 9, 60 MPEG-4 9, 61 Multi Border DVD 60 Multi channel output (Multi Ch Output) 54 Multi Session CD 60 Multi-disc resume playback (Multi Disc Resume) 55

No signal (No Signal) 51 NTSC 50

Operation sound (Beep) 50 Output color system (Output Color System) 50

PAL 50 Parental control settings (DVD Parental Control) 24, 54 Passenger control (Passenger Control) 32 Picture EQ 48, 53 Play menu (Play Menu) 19 Playable discs 9 Playback control (Video CD PBC) 22, 55 Playback settings (Visual) 54 Program Types (PTY) 21, 22

Radio Data System (RDS) 21 Rear Bass Enhancer (RBE) 46, 53 Rear view camera 58 Rear view camera input (Camera Input) 51 Rear view camera settings (Rear View Camera Setting) 58 Receive menu (Receive Menu) 16 Repeat play (Repeat) 24, 26, 32 Reset 14 Resume play 19 Ring tone (Ringtone) 44 Rotary commander (Rotary Commander) 51

Screen aspect ratio (Aspect) 49, 53 Screen settings (Screen) 53 Security function (Security Control) 57 SensMe™ 27 Shuffle play (Shuffle) 24, 26, 32 Slide show interval (JPEG Slide Show) 55 Slow-motion play 19 Sound settings (Sound) 52 Speaker volume (4.1ch Speaker Level) 47 Subtitle language (Subtitle, DVD Subtitle Language) 19, 54 Subwoofer position 45 Subwoofer setting (Subwoofer) 14, 52 Subwoofer volume (Balance/Fader) 45, 52

Touch panel calibration (Touch Panel Adjust) 47

USB device 26 USB resume playback (USB Resume) 55

Vol u me 1 0

WMA 9, 60

ZAPPIN beep sound (ZAPPIN Tone) 55 ZAPPIN playback time (ZAPPIN Time) 55 ZAPPIN™ 33

http://www.sony.net/

Sony Corporation

Printed in Thailand

Sony XAV-70BT Users guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Notes on safety

Notes on installation

Copyrights

Notes on Bluetooth

Playable discs and symbols used in this manual

Location and function of controls

Main unit

Card remote commander RM-X170

Getting Started

Resetting the unit

Performing initial settings

Preparing the card remote commander

Basic Operations

Listening to the radio

Playing discs

Storing and receiving stations

Storing manually

Overview

Receiving stored stations

Selecting PTY

Setting CT

Configuring audio settings

Changing the audio language/ format

Changing the audio channel

Activating parental control

Changing the area and its movie rating level

Repeat and shuffle play

Direct search play

USB Device Operations

Playing a USB device

Repeat and shuffle play

Before using the SensMe™ function

Installing “SensMe™ Setup” and “Content Transfer” in your computer

Registering a USB device using “SensMe™ Setup”

Transferring tracks to the USB device using “Content Transfer”

iPod Operations

Playing an iPod

Setting the play mode

Repeat and shuffle play

Useful Functions

Selecting a track/image/video file

Selecting a file type

Using Gesture Command

Before using the Bluetooth function

Basic procedure of the Bluetooth function

Bluetooth status indication

Installing the external microphone XA-MC10

Pairing

Searching from this unit

Searching from the Bluetooth device

Connecting

Handsfree calling

Making calls

Receiving calls

Operations during a call

Phonebook management

Storing phonebook data

Browsing a phonebook in a cellular phone

Deleting phonebook data

Editing a contact

Call data management

Preset dial

Call history

Locking the personal information

Audio streaming

Listening to a Bluetooth device through this unit

Operating the Bluetooth device with this unit

Bluetooth settings

Sound Adjustment

Adjusting the sound characteristics

Speaker configuration and volume setup

Adjusting the speaker volume

Monitor Adjustment

Adjusting the monitor angle

Touch panel calibration

Setting the background screen
