Sony Walkman BCR-NWU7 Specifications

BCR-NWU7

WM-Port connection

Easy connection to Sony Walkman® Digtal Players with the WM-Port

Cradle function

Recharge your battery, AC power supply, PC connection

Supplied adaptor

Supplied AC power adaptor

Data synchronization

Synchronize your data with a PC

Playback

Playback audio tracks using external speakers (not included)

Specications

Cradle for Walkman® with WM-PORT

Inputs and Outputs

Input(s)

Output(s)

WM-PORT connector (22 pin) (For “WALKMAN”)

Stereo mini, 10k Ohms

Power

AC Power

AC-S508U DC 5V (AC 100V - 240V)

Weights and Measurements

Diameter (Approx.)

Weight (Approx.)

Diameter approx. 3 1/4 in. Height approx. 1 in.

2.9 oz.

Accessories

AC Adaptor x 1

Supplied Accessories

©2009 Sony Electronics Inc. All rights reserved.

Sony and Walkman are trademarks of Sony. All other trademarks are property of their

respective owners.

AC Cord
Warranty card

Features and specications are subject to change without notice. Non-metric weights and

measures are approximate and may vary. /Updated: December 16, 2011
