Sony VGN-FS500 Marketing, VGN-FS500B, VAIO VGN-FS500P CTO Specifications

Model

VGN-FS500/FS500P CTO

HARDWARE

Processor (Configurable)

Intel

®

Pentium®M Processor 770

(2.13GHz1, 2MB L2 Cache)

Intel®Pentium®M Processor 760

(2GHz1, 2MB L2 Cache)

Intel®Pentium®M Processor 750

(1.86GHz1, 2MB L2 Cache)

Intel®Pentium®M Processor 740

(1.73GHz1, 2MB L2 Cache)

Intel®Pentium®M Processor 730

(1.60GHz1, 2MB L2 Cache)

Intel®Celeron®Processor 360

(1.40GHz1, 2MB L2 Cache)

Front Side Bus Speed

533MHz

Chipset (Configurable)

Intel

®

915PM or

Intel

®

915GM

(Depending on Graphics)

Integrated Wireless LAN
(Configurable)

Intel®PRO/Wireless 2915ABG Network
Connection(802.11a/b/g)

3

,

Intel®PRO/Wireless 2200BG Network
Connection(802.11b/g)

3

, or none

LCD

15.4” WXGA (1280x800) with
XBRITE™ technology

Hard Drive (Configurable)

100GB

2

4200rpm Ultra ATA,

80GB

2

4200rpm Ultra ATA,

60GB

2

4200rpm Ultra ATA,

40GB

2

4200rpm Ultra ATA,

30GB

2

4200rpm Ultra ATA

Memory (Configurable)

1GB (512MB x 2)
512MB (512MB x 1)
512MB (256MB x 1)
256MB (256MB x 1)
PC-2700 333MHz DDR
(Expandable up to 1GB)

Graphics (Configurable)

NVIDIA

®

GeForce™ Go 6200 128MB
TurboCache™ (32MB Discrete Video
Memory, 96MB Dynamic Video
Memory) or

Intel

®

Graphics Media Accelerator 900

128MB Dynamic Video Memory

Graphics Interface

VGA out w/ Smart Display Sensor

Optical Drive (Configurable)

DDVVDD++RR DDoouubbllee LLaayyeerr// DDVVDD±±RRWW DDrriivvee

44

Double Layer +R

DVD+R Write (2.4x MAX)

DVD±RW

4

-RW

DVD-R Write (8x MAX); DVD-RW Write (4x MAX)

+RW

DVD+R Write (8x MAX); DVD+RW Write (4xMAX)

CD-RW

CD-R Write (24x MAX); CD-RW Write (10x MAX)

CCDD--RRWW// DDVVDD--RROOMM DDrriivvee

CD-RW

CD-R Write (24x MAX); CD-RW Write (10x MAX)

DVD-ROM

DVD Read (8.3x MAX); CD Read (25.8x MAX)

DDVVDD--RROOMM DDrriivvee

DVD-ROM

DVD Read (8.3x MAX); CD Read (25.8x MAX)

Modem

Integrated V.90 Modem with RJ-11 interface

Ethernet

10BASE-T/100BASE-TX Ethernet
with RJ-45 interface

Audio

Windows

®

sound system compatible,

Built-in stereo speakers

Audio Interface

Monaural mini microphone jack,
Headphone jack

Optional Port Replicator
Interfaces

Two USB62.0 ports, Monitor (VGA) port,
Printer port, DC in, RJ-45 Ethernet

Memory Stick®Media Slot

Supports optional Memory Stick,
Memory Stick PRO™ and Memory
Stick DUO™ media

5

PC Card Slots

One PCMCIA - Type II/Type I card slot
with CardBus support

Other Interfaces

i.LINK

®

connector(IEEE 1394)7, 3 USB

2.0 ports, port replicator connector

Pointing Device

Electro-Static touch pad

Keyboard

QWERTY, 86 keys with 2.5mm stroke
and 19.05mm pitch

Action Buttons

S1, S2 (programmable), Wireless
LAN on/off

Power Requirements

110W+10%

Optional Software

Sony®SonicStage®Mastering Studio
Adobe®Photoshop®Elements
Adobe®Photoshop®Album Starter Edition
Adobe®Premiere®Standard or Professional

9

Microsoft®Office®2003 60-Day Trial

(Student/Teacher Edition for XP Home)

Microsoft®Office®2003 60-Day Trial

(Small Business Edition only for XP

Professional)

Microsoft®Office®2003 Basic, Small

Business or Professional Edition

Anti-Virus & Recovery Software

Norton

®

Internet Security™ 90-Day

Subscription
Intermute™ SpySubtract™ 30-Day Trial
VAIO®Update software
VAIO®Recovery Wizard software
VAIO®Help and Support software

Internet Services

AOL Online™ 90-Day Trial - New
Users Only

SERVICE AND WARRANTY
INFORMATION

Limited Warranty

1 Year Limited Warranty with Onsite
Service

10

Telephone Support

1 year toll-free technical telephone
assistance, available 24/7

11

.

On-line and Email Support

Support available from
http://www.sony.com/pcsupport

1. GHz denotes microprocessor internal clock speed; other
factors may affect application performance. CPU
speed will be reduced under certain operating conditions.

2. GB means one billion bytes when referring to hard drive
capacity. Accessible capacity may vary. A portion of hard
disk space is reserved as a recovery partition.

3. Requires compatible wireless LAN access point, sold
separately. Internet connection may require fees.

4. DVD Media/Formats are not universally compatible.

5. Supports Memory Stick PRO™ high-capacity media test­ed up to 1GB. Does not support MagicGate™ functionality.

6. i.LINK is a trademark of Sony used only to designate that
a product contains an IEEE 1394 connector. All
products with an i.LINK connector may not communicate
with each other.

7. Estimated battery life. Actual battery life may vary on
usage.

8. Does not support MemoryStick® media and Memory
Stick PRO™ media using the MagicGate™ function or
high-speed data transfer. Supports memory cards with

capacities up to 1GB. Does not support 5.0V SmartMedia
media or the ID function of SmartMedia media with IDs.
Does not support the SD Memory Card media copyright
protection function.

9. Not all features supported.

10. When available, Sony will provide Onsite Service in
fulfillment of its limited warranty obligations. Any such
services are subject to the terms and conditions of the
limited warranty. See actual Limited Warranty for details.
Onsite Service will be provided via third-party technician
to be dispatched as needed following phone-based trou­bleshooting. Some repairs may be accomplished with self
repair kits. Onsite Service may not be available in all loca­tions.

11. For certain third party software applications, Sony
provides first level Phone Support. Additional telephone
support may be available from the applicable 3rd party
vendor. Availability and schedule for any such support is
determined by the applicable software vendor.

Computer Interface: The computer industry lacks stan­dards, and therefore, there are a multitude of varying
software packages and add-on hardware options. This
personal computer is not manufactured to operate any
specific software, and Sony does not and cannot make
any warranty or representation with respect to the per­formance of this product with any particular software
packages and/or non-Sony add-on hardware options
except those mentioned in this document. Sony hereby
disclaims any representations or warranty that this prod­uct is compatible with any combination of products you
may choose to connect. While Sony representatives or
Sony authorized dealers may be able to assist you and
may make recommendations, they are NOT authorized to
vary or waive this disclaimer. Purchasers must deter­mine for themselves the suitability and compatibility of
the hardware and software in each and every particular
instance. Software titles pre-installed on the Sony
Notebook Computer are subject to change without
notice. Simulated graphic shown on display.
Preinstalled software may not be identical to retail ver­sions or have all documentation. This product meets the
standards of the International Energy Star Program for
energy efficiency. Features and specifications are sub­ject to change without notice. Non-metric weights and
measurements are approximate.

©2004 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permis­sion is prohibited. Sony, i.LINK, Memory Stick,
SonicStage, Giga Pocket, VAIO, VAIO Zone, XBRITE,
ErgoBright, Memory Stick PRO, Memory Stick PRO Duo,
MagicGate, Click to DVD, S-Master, DVgate Plus, VAIO
Media, PictureGear Studio and Like No Other are trade­marks of Sony. Intel and Pentium are registered trade­marks, and Centrino is a trademark of Intel Corporation.
Microsoft and Windows are registered trademarks of
Microsoft Corporation. All other trademarks are trade­marks of their respective owners.

Printed in U.S.A. 1/05.

Get Creative When
On-The-Go

The VAIO®FS Notebook
comes loaded with the tools
you need to create, manage
and share your digital pho­tos, home videos, movies
and music. Powerful per­formance, extended battery
life

8

and optional integrated
wireless LAN3make it easy
to enjoy your multimedia
entertainment while you're
away from home.

Sony's Professional
Tools Are At Your
Fingertips

With Click to DVD™ software
and the optional DVD+R Double
Layer/DVD±RW drive, creating
high-quality DVDs is just one
click away

4

. Create or record up
to 8.5GB of home videos,
movies, TV shows, music or dig­ital photos - or up to 4 hours of
MPEG2 video - on one Double
Layer DVD disc.

Superior Display
Technology

The VAIO®FS Notebook
comes with a 15.4”
widescreen LCD with Sony
XBRITE™ display technolo­gy. It delivers brilliant colors,
sharp contrasts and crisp
images. With glare filter and
anti-reflective coating to min­imize reflection, you're
assured a beautifully clear
image from any viewing
angle. Your movies and
home videos will come alive.

Delivering Powerful
Performance

With optional tools like inte­grated wireless LAN3, Intel

®

Pentium®M processor,
enhanced battery life8and
Sony's original multimedia
software, you have the
robust tools you need when
you're on the road. And,
with its slim, lightweight
design, it's your ideal mobile
companion.

The VAIO®FS Notebook
delivers powerful perform­ance for your every­day essential computing
needs and growing multi­media entertainment de­mands. Easily manage,
and enjoy your digital pho­tos, home videos, and
music on-the-go. Slim and
lightweight, it's your ideal
mobile companion.

The Perfect Blend of Performance and Mobility.

Sony®VAIO®Notebook

VGN-FS500/
FS500P CTO

Battery (Configurable)

Standard Lithium-ion Battery (VGP-BPS2A)
or (VGP-BPL2)

Estimated Battery Life

Standard Battery: 2.0-3.5 hours

7

Weight

6.28 lbs. with standard battery
(weight is approximate and may vary)

Size (W x H x D)

14.33” x 1”-1.41” x 10.41”

Supplied Accessories

Standard Lithium-ion battery, Power
cord & AC adapter (VGP-AC19V11)

Optional Accessories

Additional Standard Battery (VGP-BPS2)
Large Capacity Battery (VGP-BPL2)
AC Adapter (VGP-AC19V10)
Port Replicator (VGP-PRFS1)
Visual Communication Camera

(PCGA-UVC11A)
Wireless optical mouse (PCGA-WMS5/S)
USB Mobile Mouse- Black/Silver

(PCGA-UMS3/B/S)
Wireless Keyboard and Mouse

(VGP-WKB1)
Memory Card Adapter (VGP-MCA10)

8

Universal Carrying Case (VGP-AMB1)
Notebook Backpack (PCGA-CCP3 Series)
Sport Backpack (VGP-AMB2)
Neoprene Notebook & AC Adapter

(VGP-AMC3)
60GB External Hard Drive (PCGA-HDM06)

2

External Floppy Disk Drive (VGP-UFD1)

SOFTWARE

Operating System (Configurable)

Microsoft®Windows®XP Home with

Service Pack 2 or Microsoft®Windows

®

XP Professional with Service Pack 2

Sony Original Software

VAIO Zone™ with WinDVD™
Click to DVD™ - DVD Creation (only avail

able on models with DVD±RW drive)
DVGate Plus™ - Digital Video
SonicStage®- Digital Music
PictureGear Studio™ - Digital Photo
VAIO Media™ - Network File Sharing

VAIO®FS Series Software Bundle

Intuit®Quicken®2005 New User Edition

(previous Quicken users may require

additional upgrade)

InterVideo®WinDVD

®

Microsoft®Works 8.0
Sonic RecordNow!®7 (only available on

models with DVD±RW drive)

Featuring One Year Onsite Service

10

and 24/7 Telephone Support

11
