VAIO FS

VGN-FS25GP

®

Intel

Centrino™ Mobile Technology

Broaden your DVD creativity with style.

Specifications

Model

Platform

Operating System

Processor System Bus

Memory Bus

Cache Memory

Main Memory

Hard Disk

Optical Drive

Graphics Accelerator

Video Memory

Display

Interfaces

Wireless LAN

Modem

PC Card Slot

Audio

Keyboard / Input Device

Battery

Dimensions (W × H × D)

Weight

Software Applications

Supplied Accessories

Warranty

Features and specifications are subject to change without notice.

*1 CPU speed will be reduced under certain operating conditions. *2 By adding one 512MB memory module. *3 NVIDIA
video memory and dynamically available system memory for optimal system performance. *4 Includes necessary data for recovery (setting back to initial shipment settings) in the hard disk
drive consuming approximately 5GB in size. *5 This product is designed to playback discs that conform to the Compact Disc Digital Audio standard specifications (CD Standard). A DualDisc
is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. Please be aware that the audio side (non-DVD side) of a DualDisc
may not play on this product because it does not conform to the CD Standard. *6 High-speed/Full-speed/Low speed compatible. *7 Does not support MagicGate copyright protection
technology. Does not support Memory Stick with capacity of 2GB and over. Compatibility confirmed with Sony branded “Memory Stick” media only. *8 MagicGate copyright protection
technology cannot be applied to Memory Stick PRO. *9 Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network may reduce the communication speed due to
radio interference. Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication speed to ensure communication with IEEE 802.11b products. When
the communication speed is not as fast as expected, changing the wireless channel on the access point may increase the communication speed. *10 The communication speed varies
depending on the distance between communication devices, existence of obstacles between such devices, the device configuration, the radio conditions, and the software in use. In addition,
communication may be cut off depending on the radio conditions. *11 This product may only function with a genuine Sony battery designed for this model. *12 Estimated battery life (under
JEITA Battery Run Time Measurement Method (ver.1.0).) When the power-saving mode is on. Actual battery life may vary with different operating conditions and settings. For further details,
please visit vaio-online.sony.com *13 Warranty conditions may vary by region.

The trademarks, including but not limited to “SONY”, “VAIO”, “Memory Stick” and “SonicStage” are either trademarks or registered trademarks of Sony Corporation and/or its subsidiaries.
Adobe, Adobe Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other countries. Intel, Intel logo, Intel Inside, Intel
Inside logo, Intel Centrino, Intel Centrino logo, Intel SpeedStep, and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other
countries. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. All other product and brand names may be
trademarks or registered trademarks of their respective owners. Whilst information given is true at time of printing, small production changes in the course of our company’s policy of
improvement through research and design might not necessarily be included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.

VGN-FS25GP

®

Intel

Centrino™ Mobile Technology

• Intel® Pentium® M Processor 740 (1.73GHz)*1 • Intel® PRO/Wireless 2200BG Network Connection • Intel® 915PM Express Chipset

Microsoft® Windows® XP Professional with Service Pack 2 (English version) Multilanguage User Interface (pre-installed Traditional Chinese)

533MHz

333MHz

L1 Cache: 64KB L2 Cache: 2MB (on CPU)

512MB DDR SDRAM (upgradeable up to 1GB)*

2 SO-DIMM slots (The pre-installed memory module uses one)

60GB (C: 15GB, D: 45GB*

DVD±RW Drive (supporting DVD+R Double Layer disc)*

Maximum reading speed: DVD+R, DVD-R, DVD-ROM: 8× / DVD-RW, DVD+RW: 6× / DVD+R DL (Double Layer): 4× / CD-R, CD-RW, CD-ROM: 24×

Maximum writing speed: DVD+R, DVD-R: 8× / DVD+RW, DVD-RW: 4× / DVD+R DL (Double Layer): 2.4× / CD-RW: 10× / CD-R: 24×

• Dual display compatible • 3D graphics acceleration compatible • NVIDIA® GeForce™ Go 6200 with TurboCache™*

(PCI Express ×16 connection)

3

128MB*

15.4˝ Wide (WXGA: 1280 × 800) TFT colour display (Clear Bright LCD: Single Lamp)

• USB 2.0 × 3*6 • i.LINK (IEEE 1394) S400 (4pin) • Network (RJ-45) connector (100BASE-TX/10BASE-T) • Headphone jack (stereo mini)

• Microphone jack (stereo mini) • Monitor connector (VGA, D-SUB 15 pin) • Modular (RJ-11) connector • Port Replicator connector

• Memory Stick Slot*

• Integrated Wireless LAN IEEE 802.11b/802.11g*9 • Intel® PRO/Wireless 2200BG Network Connection

• Data rate: maximum 11Mbps (802.11b)/54Mbps (802.11g)*

V.92 and V.90 Compliant

Type I/II × 1, CardBus Support

• Intel® High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers

• ca 19mm Key pitch / 2.5mm Key stroke • 86 Keys • Intelligent Touchpad

VGP-BPS2A*

364 × 25.4-35.9 × 264.5mm

2.85kg (including the supplied battery)

• Adobe Reader 6 • Adobe Photoshop Elements 3.0 (Installer) • Adobe Premiere Standard • WinDVD 5 for VAIO • RecordNow! 7 • Click

to DVD 2.4 • DVgate Plus 2.1 • PictureGear Studio 2.0 • SonicStage 3.0 • SonicStage Mastering Studio 1.4 • SonicStage Mastering

Studio Audio Filter 1.4 • VAIO Control Center 1.1 • VAIO Edit Components 5.0 • VAIO Media 4.1 • VAIO Original Screen Saver • VAIO

Recovery Utility 2.4 • VAIO Update 2.1 • VAIO Zone 1.4 • Norton Internet Security 2005

• AC adapter (VGP-AC19V10) • Lithium-ion battery (VGP-BPS2A)

13

One year*

4

) Ultra ATA/100

7

(Standard/Duo Size compatible, Memory Stick PRO compatible, High-speed data transfer compatible*8)

11

Lithium-ion battery: up to 2 hours of use*

2

(partially shared with video memory)*

5

10

• Frequency: 2.4GHz

12

®

TurboCache™ technology combines the size and bandwidth of

3

3

Optional Accessories (availability depends on region)

VGP-PRFS1 Port Replicator

● Monitor connector

(VGA, D-SUB 15 pin)

● Printer connector

● Network connector

● USB 2.0 connector (×2)

VGP-BPL2

Lithium-ion Battery

● Rechargeable battery

VGP-AC19V10

AC Adapter

● Universal voltage compatible:

AC100 – 240V

PCGA-WMS5/S

Wireless Mouse

● Stylish, user-friendly design

● Highly sensitive receiver

● Sensor resolution:

800 dots per inch

Sony recommends Microsoft

®

Windows

12

11. Wireless LAN switch

12. Headphone jack (stereo mini)

13. Microphone jack (stereo mini)

14. Indicators

15. Network (RJ-45) connector (100BASE-TX/10BASE-T)

16. Modular (RJ-11) connector

17. DVD±RW drive (supporting DVD+R Double Layer disc)

18. Manual eject button

19. Disc eject button

10. Built-in stereo speakers

11. Power button

12. Shortcut buttons

13. PC Card eject button

14. PC Card slot (Type I/II ×1)

15. i.LINK (IEEE 1394) S400 (4 pin) connector

16. Memory Stick Slot

(Standard/Duo Size compatible, Memory Stick PRO compatible,
high-speed data transfer compatible)

17. USB 2.0 connector (×3)

18. Monitor connector (VGA, D-SUB 15 pin)

19. DC-IN connector

XP Professional.

VGN-FS25GP

1 23

4

56 7 98

10

1413 15 16 17 18 19

11

®

vaio-online.sony.com

VGN-FS25GP

Relish the visual pleasure and create DVDs.

From slender, stylish body to wide 15.4˝ WXGA Clear Bright LCD, the new VAIO FS25GP delivers visual

satisfaction. Its wide screen dimensions and Clear Bright technology bring DVD movies and digital photos to

life. And DVD recording capabilities expand your creative potential. Moreover, rigid magnesium body panels

support super body slimness while conveying a pleasing sense of refinement. Stylish and stunning, the user-

friendly VAIO FS25GP makes the ownership experience a joy.

Sony recommends Microsoft® Windows® XP Professional.

Powerful software for creative minds.

DVD CREATION

With Click to DVD, you’re only a
click away from creating your own
photo, movie + photo, or video DVD
on DVD±R/RW or DVD+R Double
Layer disc. You can also create 5.1
surround sound DVDs. Moreover,
RecordNow! 7 lets you back up AV
and data files on CDs and DVDs
with drag’n drop ease.

Click to DVD

RecordNow! 7

CONTENT BROWSER

VAIO Zone lets you seamlessly enjoy
CDs, DVDs, music, photos, videos
and other AV files through a single
interface. And VAIO Media software
enables AV files on your VAIO to be
accessed and played by other VAIO
Media-installed VAIO notebooks and
PCs on your home network.

VAIO Zone

VAIO Media

MOVIES

Import videos from a Handycam*, trim
and edit them, or export them to a
Handycam* with DVgate Plus. Use

®

Adobe

Premiere® Standard with VAIO
Edit Components to add transitions
and effects like sparkles. Multiple
channel (4ch DV-AVI capture,
4ch/5.1ch DV-AVI output, etc.)
surround sound is supported.

DVgate Plus

Adobe® Premiere® Standard

DVD Creativity

All it takes is a single click to create your own DVD masterpiece! Simply load the DVD±RW drive
(supporting DVD+R Double Layer discs) with your choice of DVD media, import footage from your DV
or MICROMV Handycam* via i.LINK connector, and click the “Create DVD!” button of Sony’s excellent
Click to DVD software. Then share your DVD videos with friends and family. Or do basic editing of your
footage with DVgate Plus and semi-professional editing using Adobe® Premiere® Standard with VAIO
Edit Components, which lets you edit MPEG files and add effects such as sparkles and flames via 3D
Particle Maker and Motion Tracker. There’s no end to the creative possibilities!

* Availability depends on region.

Wide Screen Enjoyment

VAIO FS25GP’s wide 15.4˝ (16:10, WXGA, 1280 × 800) Clear Bright LCD brings out all the beauty of
your images through wide dimensions, exceptional brightness and striking image clarity. You’ll find it
perfect for editing videos and watching DVD movies that play smoothly and accurately courtesy of
NVIDIA® GeForce™ Go 6200 with TurboCache™* and 128MB* of video memory, as well as NVIDIA®
PureVideo™ technology. Support for Shader Model Ver. 3.0 also contributes to exciting 3D gameplay.
Moreover, SonicStage Mastering Studio Audio Filter headphone presets deliver superb sound quality
via special recommended headphones**, while VAIO Zone lets you quickly and seamlessly access all
your audio and visual files. Now total AV pleasure is yours with VAIO FS25GP.

* NVIDIA® TurboCache™ technology combines the size and bandwidth of video memory and dynamically available system memory for
optimal system performance. ** Availability depends on region.

✚ Main features

DVD video recording:

One-Click DVD
Video Creation

Comfortable typing:

Full-sized Keyboard

✚ Basic specifications

Intel® Pentium

Processor 740

(1.73GHz)

®

M

Beautiful viewing:

Clear Bright LCD /

Wide 16:10

Theatre sound quality:

Dolby Virtual Speaker /

Dolby Headphone

Microsoft

Windows® XP

Professional

* NVIDIA® TurboCache™ technology combines the size and bandwidth of video memory and dynamically available system memory for optimal system performance.

®

Network freedom:

Wireless LAN

802.11 b/g

Optional accessory:

Port Replicator

15.4˝ WXGA

1280 × 800 LCD

High quality:

2-sided

Magnesium Body

GeForce™ Go 6200
with TurboCache™

(128MB*)

Light for its size:

2.85kg

DVD±RW Drive

*

(supporting +R DL)

▲ Full-sized keyboard ▲ Slender and rigid ▲ VAIO mirror logo

Handy presentation:

Plug & Display

512MB

Main Memory

Content sharing:

Memory Stick Slot

n

d

a

ta

(S

Hard Disk Drive

/D

rd

60GB

p

tib

a

le

o

m

)

c

u

o

size

Performance Plus

VAIO FS25GP enhances your enjoyment with versatile features and the smooth response of
advanced system architecture — despite slender dimensions. This architecture includes
FSB 533MHz, new Intel® Centrino™ Mobile Technology with Intel® Pentium® M Processor
740 (1.73GHz), the latest advanced chipset (Intel® 915PM Express Chipset), and Intel® PRO/
Wireless 2200BG Network Connection. Two one-touch buttons provide quick access to your
choice of default or assigned functions, and the optional Port Replicator VGP-PRFS1* lets
you quickly connect and disconnect from AC power and peripherals. When connected to the
Net, VAIO Update alerts you to system updates and downloads them for you when desired.
Enjoy all this and more with VAIO FS25GP. *Availability depends on region.

Sony’s recommended headphones* for VAIO

Inner, Open-air MDR-E931LP

Inner, Closed MDR-EX51LP

VAIO provides an audio filter adjusted exclusively for the recommended headphones. Created at a professional music studio, this filter
ensures superlative quality sound reproduction.

* Availability depends on region.

Overhead, Open-air MDR-Q22LP

Overhead, Closed MDR-V700DJ

PHOTOS

Import images from your digital
camera via USB cable or Memory
Stick, then edit the files with Adobe
Photoshop
PictureGear Studio to place them in
chronological order with Calendar
View, create a slideshow, or create a
photo album and print it or attach it
to email.

®

Elements. Use

®

Adobe® Photoshop® Elements

PictureGear Studio

MUSIC

Import music from the Net or CDs
with SonicStage. Then transfer it to
MiniDisk (MD)** for playback on a Net
MD Walkman* or burn your own
original CDs. SonicStage Mastering
Studio lets you import analogue
music (Roland EDIROL AUDIO
capture UA-5* USB audio interface
device required) and edit it with high­quality effector modules before
recording on a CD. SonicStage
Mastering Studio Audio Filter can
enhance any sound played on
VAIO and provides excellent
headphone presets.

* Availability depends on region.
** SonicStage supports the new-generation Hi-MD as well as standard MD.

Note: Any copying or reproduction of copyrighted material may amount to copyright
infringement. Song titles, names of artists and other information shown in the
SonicStage screen capture are provided for illustrative purposes only.

SonicStage

SonicStage Mastering Studio

SonicStage Mastering Studio
Audio Filter
