TCM-230DV
Standard Cassette Voice Recorder
®
▲ Includes AC Charger Kit (2 NiMH Rechargeable Batteries,
Battery Charger and AC Adapter)
• Double Recording Time
• Voice Operated Recording (VOR)
• Long Battery Life—25 Hours
• Playback Speed Control
• LED Battery Level Indicator
• Built-In Microphone
• Earphone and Microphone Jacks
• Clear Voice™ Recording System
• One Touch Recording
• Cue and Review Function
• Sony-Matic
®
Automatic Recording Level Control
• DC-In Jack
• Hinged Battery Lid
• Includes Carrying Strap
▲ Step-up Feature ◗ New Feature
Charger
Page 2
features
▲Includes AC Charger Kit (2 NiMH Rechargeable Batteries, Battery
Charger and AC Adapter)
all you need to keep your recorder charged
• Double Recording Time gives you the option of recording on a
standard cassette at either normal speed or half the normal speed, for
extended recording or dictation sessions
• Voice Operated Recording activates the recorder only when audible
sound is present, conserving tape and eliminating soundless passages
• Long Battery Life—25 Hours is made possible by advanced
technology which extends battery power beyond previous limits
• Playback Speed Control lets you adjust playing speed as much as
+30% or -15% for easier review of recorded information
• LED Battery Level Indicator provides visible indication of battery
power remaining
• Built-In Microphone for extra convenience eliminates the need for an
external microphone in many situations
• Earphone and Microphone Jacks provide sound in both ears
when using an optional stereo headset and ability to record from an
optional microphone
• Clear Voice™ Recording System sound system enhances voice
quality during recording and playback for greater clarity
• One Touch Record from Playback for simplified quick
play/record operation
• Cue and Review Function provides sound during fast forward and
rewind modes to help find specific passages
• Sony-Matic®Automatic Recording Level Control uses advanced
circuitry to ensure correct recording level
• DC-In Jack permits two-way power operation, using available
replaceable batteries or supplied AC power adapter
• Hinged Battery Lid makes it easy to open and close the battery lid for
easy replacement of batteries, and prevents loss
• Includes Carrying Strap provides a secure, convenient band to hold
onto or carry the unit.
specifications
Recording System: 2 Track, 1 Channel, Standard Cassette
Frequency Response: 250-6,300Hz
Speaker: 2" (50mm) dia.
Speaker Output: 350mW
Inputs: DC-In jack 3V
External Microphone
Outputs: Earphone (mini jack)
Power Requirements: DC 3V, “AA” x 2
Battery Life (Approx.): Rec/Play: 25 Hours* Continuous Recording w/Sony
Alkaline Batteries (optional)
LED: w/Battery Indicator
Built-In Mic: Yes
Color: Silver
Dimensions (WHD): 33⁄8" x 41⁄2" x 13⁄8" (86.9 x 116.3 x 36.5mm)
Weight: 6 oz. (169g)
Supplied Accessories: Hand Strap, Battery Charger BCA-30E, AC-E30HG
AC Adapter, 2 “AA” NiMH Rechargeable Batteries
©2004 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited. All rights reserved. Sony,
Clear Voice and Sony-Matic are trademarks of Sony.
Features and specifications are subject to change without notice. Non-metric weights and measures
are approximate.
* Actual battery time may vary upon usage pattern.
TCM-230DV
Standard Cassette Voice Recorder
®
Sony Electronics Inc.
1 Sony Drive
Park Ridge, New Jersey 07656
www.sony.com
Printed in USA 2/2004
