Sony Smart Bluetooth Speaker BSP60 User Guide
User guide
Smart Bluetooth® Speaker
BSP60
Contents
Introduction.................................................................................... 3
Function overview..............................................................................3
Hardware overview............................................................................ 3
Basics.............................................................................................4
Charging.............................................................................................4
Turning on and off.............................................................................. 4
Resetting the device.......................................................................... 4
Getting started............................................................................... 5
Installing necessary applications on your Android™ device............. 5
Using your device...........................................................................7
Using voice controls.......................................................................... 7
Making phone calls............................................................................ 9
Playing music ....................................................................................9
Setting alarms.................................................................................. 10
Setting your device to move around................................................11
Guidelines for using the "Dance with music" action........................11
Troubleshooting............................................................................13
Why does my device show the host application icon on the
display?............................................................................................13
What is the function of the speaker covers? If they get
damaged, can they be removed and replaced?.............................. 13
The speaker covers pop open for no reason while I'm using my
Android™ device. Why is this?........................................................13
Legal information..........................................................................14
Declaration of Conformity ............................................................... 15
2
This is an Internet version of this publication. © Print only for private use.
Introduction
Function overview
The Smart Bluetooth® SpeakerBSP60 is designed to make your life easier. When
paired with an Android™ smartphone or tablet, it can vocalise basic information such
as weather forecasts or your daily schedule. Using voice commands, you can ask it
to perform simple tasks, such as setting alarms and checking your phone for new
messages. The built-in microphone accommodates conference calls. With NFC Onetouch technology, you just need to touch an NFC enabled Android™ calling device to
the Smart Bluetooth® Speaker and you’re ready to talk, hands free. You can also use
NFC One-touch to instantly play back music. And with a new, fun dance mode, the
Smart Bluetooth® Speaker can dance in time to your music.
Hardware overview
1. Speaker cover 9. Microphone
2. Control light 1 10. Reset button
3. NFC detection area 11. Power switch
4. Speaker cover 12. Off position
5. Control light 2 13. On position
6. Display 14. PAIRING position
7. Control light 3 15. Micro USB port
8. Control light 4
Compatibility information for your accessory is available at
This is an Internet version of this publication. © Print only for private use.
www.sonymobile.com/support
3
.
Basics
Charging
Before using your Smart Bluetooth® SpeakerBSP60 for the first time, you need to
charge it for approximately 2 hours. Sony chargers are recommended.
The battery status is indicated on the display as
Speaker device is turned on.
To charge your device
1
Slide the power switch to the off position.
2
Plug one end of the USB cable into the charger.
3
Plug the other end of the cable into the Micro USB port of your device.
when your Smart Bluetooth®
Turning on and off
To turn on your device
•
Slide the power switch to the on position.
To turn off your device
•
Slide the power switch to the off position.
When the battery runs out, the device turns off automatically. If this happens, you must slide
the power switch to the off position before your device can start charging.
Resetting the device
You can reset your device to restart it in situations where it behaves unexpectedly. No
settings or pairing information get deleted when you perform such a reset.
You can also reset your Smart Bluetooth® Speaker to its original factory settings. All
settings get deleted when you perform this kind of reset, which is sometimes
necessary if you want to reset the clock or alarm or delete pairing information in the
Smart Bluetooth® Speaker application.
To reset the device
•
Using the tip of an unfolded paper clip (or a similar object with a long fine tip),
press the reset button and then release it.
To perform a factory data reset
•
Slide the power switch to the PAIRING position for 12 seconds and then
release it.
4
This is an Internet version of this publication. © Print only for private use.
Getting started
Installing necessary applications on your Android™ device
For your Smart Bluetooth® Speaker to work properly, you must first install the latest
version of the Smart Bluetooth® Speaker application on the Android™ device that
you are using with the speaker, and then you need to pair and connect the two
devices. There are two ways to do this. You can use the NFC One-touch method,
which launches the procedure automatically, or you can use the manual Bluetooth®
setup method. Both methods require you to install the Voice Control application,
which is necessary if you want to use voice commands.
To set up using the NFC One-touch method
1
Speaker: Slide the power switch to the on position.
2
Slide the power switch to the PAIRING position until appears on the
display, indicating that the Smart Bluetooth® Speaker is in pairing mode.
3
Android™ device: Make sure that the NFC function is turned on and that the
screen is active and unlocked.
4
Place the Android™ device over the Smart Bluetooth® Speaker so that the
NFC detection area of each device touches the other. The installation page for
the Smart Bluetooth® Speaker application on Google Play™ opens
automatically on the Android™ device.
5
Follow the on-screen instructions to download and install the application.
6
After successful installation, launch the Smart Bluetooth® Speaker application
and follow the instructions to connect the Android™ device with the Smart
Bluetooth® Speaker.
7
Once the two devices are connected, the device software is automatically
updated, if necessary. This procedure can take a few minutes.
8
After the device software is updated, an installation page opens for the Voice
Control application. Follow the instructions on your Android™ device to install
the latest version of the Voice Control application for your Smart Bluetooth®
Speaker.
To pair and connect any previously connected Android™ device with your Smart Bluetooth®
Speaker at a later time, just touch the NFC detection area of the Android™ device to the NFC
area of the Smart Bluetooth® Speaker.
5
This is an Internet version of this publication. © Print only for private use.
