SERVICE MANUAL
MOBILE DVD SYSTEM
US Model
MV-900SDS
Ver 1.0 2004.06
9-877-871-01
2004F05-1
© 2004.06
Sony Corporation
e Vehicle Company
Published by Sony Engineering Corporation
SPECIFICATIONS
Copyrights
This product incorporates copyright protection
technology that is protected by method claims
of certain U.S. patents, other intellectual
property rights owned by Macrovision
Corporation, and other rights owners. Use of
this copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
• “Memory Stick,”
and “MagicGate
Memory Stick” are trademarks of Sony
Corporation.
• “Memory Stick Duo” and “
”
are trademarks of Sony Corporation.
• “MagicGate” and “
” are
trademarks of Sony Corporation.
• “Memory Stick PRO” and “
”
are trademarks of Sony Corporation.
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro Logic”, and the
double-D symbol are trademarks of Dolby
Laboratories.
“DTS,” “DTS Digital Surround” and “DTS
Digital Out” are trademarks of Digital Theater
Systems, Inc.
DVD player XVM-R90D
System
Laser Semiconductor laser
Signal format system NTSC/PAL
Audio characteristics
Frequency response 20 Hz to 20 kHz
Signal to noise ratio 90 dB (A)
Harmonic distortion 0.05 %
Dynamic range 90 dB
Wow and flutter below measurable limits
(±0.001% W PEAK)
General
Outputs FM output
Audio output
Video output
Optical output
Inputs Audio input
Video input
DC 12V input
Power requirements 12 V DC
Dimensions Approx. 285 × 73 × 455 mm
(11
1
/4 × 2 7/8 × 18 in)
(w/h/d)
Mass Approx. 3.5 kg
(7 lb 12 oz)
Operating temperature 0 °C to 45 °C
(32 °F to 113 °F)
Supplied accessories Card remote commander
RM-X137
Power supply cord (1)
RF modulator cable (1)
Mounting plate (1)
Screws (5)
Tapping screws (8)
Operating Instructions (1)
Monitor
System Liquid crystal color display
Display Manual flipdown panel
Drive system TFT-LCD active matrix
system
Picture size 9 inches wide screen (16:9)
Picture segment 336,960 (w 1,440 × h 234)
dots
Cordless Stereo Headphones
MDR-IF0140
General
Modulation system Frequency modulation
Carrier frequency Right 2.8 MHz
Left 2.3 MHz
Frequency response 18 − 22,000 Hz
Power source DC 1.5 V (size AAA) dry
battery
Mass Approx. 125 g (4.41 oz)
including battery
Operating temperature 5 °C to 35 °C
(41 °F to 95 °F)
Design and specifications are subject to change
without notice.
MODEL NUMBER LABEL PRINTED MODEL NAME
DVD PLAYER MV-900SDS XVM-R90D
CORDLESS STEREO HEADPHONE MDR-IF0140 MDR-IF0140
CARD REMOTE COMMANDER – RM-X137
COMPONENT MODEL NAME
