Sony PS3 CECH-ZED1E Instruction Manual

CECH-ZED1E

3D Display

Instruction Manual

WARNING

ˎ To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
ˎ This equipment has been tested and found to comply with the limits set out in the EMC

Directive using a connection cable shorter than 3 meters.

ˎ A molded plug complying with BS1363 is fitted to this equipment for your safety and

convenience. Should the fuse in the plug supplied need to be replaced, a 5AMP fuse approved
by ASTA or BSI to BS1362, (i.e., marked with
with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you

or mark) must be used. If the plug supplied

change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover,
please contact your nearest Sony service station.

ˎ Some people may experience discomfort (such as eye strain, eye fatigue, or nausea) while

watching 3D video images or playing stereoscopic 3D games on 3D displays. If you experience
such discomfort you should immediately discontinue use of your display until the discomfort
subsides. Generally we recommend that you avoid prolonged use of your PlayStation
and take 15 minutes breaks during each hour of play. However, when playing stereoscopic 3D

3 system

®

games or watching 3D video, the length and frequency of necessary breaks may vary from
person to person – please take breaks that are long enough to allow any feelings of discomfort
to subside. If symptoms persist, consult your doctor. The vision of young children (especially
those under six years old) is still under development. Consult with your child’s doctor or
optometrist before allowing young children to watch 3D video images or play stereoscopic 3D
games. Adults should supervise young children to ensure they follow the recommendations
listed above.

Precautions

Before using this product, carefully read this manual and retain it for future reference. Read also
the instructions for the PlayStation

Safety

ˎ Do not use a power cord other than the supplied AC power cord. Do not modify the cord.
ˎ Do not allow liquid or small particles to get into the product. If this happens, stop use and

disconnect it from the electrical outlet immediately.

ˎ Never disassemble or modify the product.
ˎ Do not expose the product to dust, smoke or steam.
ˎ Do not expose the product to high temperatures, high humidity or direct sunlight.
ˎ Do not touch the product with wet hands.
ˎ Unplug the AC power cord from the electrical outlet before cleaning or when you do not

intend to use the system for an extended period of time.

ˎ Do not connect the AC power cord to a voltage transformer or inverter. Connecting the AC

power cord to a voltage transformer for overseas travel or an inverter for use in an automobile
may cause heat to build up in the system and may cause burns or a malfunction.

ˎ Keep this product out of the reach of small children. Small children may swallow small parts

ormay wrap the cables around themselves, which may inflict injury or cause an accident or
amalfunction.

3 system.

®

Use and handling

ˎ The LCD screen is made of glass and may crack if subjected to excessive force.
ˎ Pixels that are not lit or are continuously lit may appear in certain locations on the LCD screen.

The appearance of such spots is a normal occurrence associated with LCD screens and is not a
sign of a system malfunction. LCD screens are made using highly precise technology. However,
a very small number of dark pixels or continuously lit pixels exist on each screen. Also, a
distorted image may remain on the screen for several seconds after the system has been
turnedoff.

ˎ Direct exposure to sunlight may damage the system’s LCD screen. Be careful when using the

system outdoors or near a window.

ˎ When using the system in a cold environment, you may notice shadows on the graphics or the

screen may appear darker than usual. This is not a malfunction, and the screen will return to
normal when the temperature goes up.

ˎ Do not leave still images displayed on the screen for an extended period of time, as doing so

may cause a faint image to be left permanently on the screen.

ˎ Be careful when carrying the product. If you do not have a good grip, the product may drop

causing potential damage or injury.

ˎ Do not place the product on surfaces that are unstable, tilted or subject to vibration.
ˎ Do not place any objects on top of the product. Do not stand on the product.
ˎ Do not throw or drop the product, or otherwise expose it to strong physical impact.
ˎ Do not allow the product to come into contact with liquids.
ˎ Follow the instructions below to help prevent the product exterior from deteriorating or

becoming discoloured.

ˋ Wipe with a soft, dry cloth.
ˋ Do not place any rubber or vinyl materials on the product exterior for an extended period

of time.

ˋ Do not use solvents or other chemicals. Do not wipe with a chemically-treated cleaning cloth.

Checking the version of the PS3™ system software

To use the 3D display, the PS3™ system software must be version 3.70 or later. You
can check the system software version by selecting (Settings) (System
Settings) [System Information] on the XMB™ (XrossMediaBar) menu of the
PS3™system.

Unpacking

ˎ 3D display (1) ˎ Stand (1) ˎ Neck (1)
ˎ AC power cord (1) ˎ HDMI cable (1) ˎ 3D glasses (2 sets) (pouch, USB cable)
ˎ Instruction manual (1)

Assembly

1 Insert the neck into the stand until you hear a click.

Check that the neck and stand face in the same direction, as shown in the
illustration.

2 Securely anchor the neck in place by tightening the mounting screw on the

bottom of the stand.

3 Insert the display into the neck until you hear a click.

Hints

ˎ Be careful not to pinch your hands or fingers when you assemble

the stand anddisplay.

ˎ You can adjust the tilt angle of the display by up to 10° from the

vertical (Figure ). Hold the stand down with one hand and move
the upper part of the display with your other hand. Do not try to tilt
the display any further than 10° from the vertical, since this may
damage it.

ˎ At least two people must perform the steps for removing the display

from the neck and stand. One person must hold the neck and stand
securely on a flat surface and press the button on the hinge. At the
same time, another person can lift the display upwards.

Rear

Press to detach display from neck
andstand.

Using the 3D display

Front

Status indicator

Red: power off (standby mode)
Blue: starting up
Green: running
Orange: no input signal

3D sync transmitter

Infrared receiver

Infrared receiver for the remote control
(sold separately).


