VAIO® Computer
Quick Start
PCG-GRT200Z Series
Short Cut Menu
+F1 Displays the VAIO Help and Support Center window.
+Tab Switches the selected button on the taskbar.
+D Displays the desktop.
+E Displays the My Computer window.
+F Displays the Search Results window, where you can find a
file or folder. This is the equivalent of selecting Search from
the Start menu.
+Ctrl+F Displays the Search Results - Computers window, where
you can locate other computers. This is the equivalent of
selecting Search, and then Computer from the Start menu.
+M Minimizes all displayed windows.
Shift+ +M Returns all minimized windows to their previous size.
+R Displays the Run window. This is the equivalent of selecting
Run from the Start menu.
Fn+ +Insert Displays the System Properties window. This is the
equivalent of selecting Control Panel, and then System from
the Start menu.
Fn+F3 Toggles the built-in speakers off and on.
Fn+F4 Together with the or keys, it increases volume.
Together with the or keys, it decreases volume.
Fn+F5 Together with the or keys, it increases brightness.
Together with the or keys, it decreases brightness.
Fn+F7 Toggles the display between the computer screen (LCD), a
connected external display, and both the LCD and an
external display.
Fn+F12 Puts the system into Hibernate mode, a power management
state. To return the system to normal operating mode, press
the power button.
Fn+Esc Puts the system into Standby mode, a power management
state. To return the system to the active state, press any key
or the power button.
Contents
