Sony NEX-5TL-S Marketing Specifications

NEX-5TL/S

Compact Interchangeable Lens Digital Camera

Shoot and share DSLR-quality photos online, straight
from the camera. With built-in Wi-Fi®, it even lets you
download camera apps for endless creative possibilities.
And the 16.1MP APS-C size sensor delivers breathtaking
stills and it now focuses with incredible speed and DSLR­grade precision. All this and more in a camera that’s
about half the size of a DSLR.

Key Features

16.1 MP APS-C size HD image sensor

The same sensor format that Sony builds into the full-sized α DSLRs. With 13 times the area of the typical point-and-shoot
image sensor, APS-C sensor size makes the dierence between “snapshots” and “photographs,” delivering an exceptional
combination of high resolution, high sensitivity and gorgeous, blurred backgrounds.

Fast Hybrid AF

Sony’s advanced Fast Hybrid AF combines two technologies for outstanding performance: Phase detection auto focus
for quick response that is ideal when tracking fast-moving subjects and contrast-detection auto focus for added precision.
A perfect match that delivers optimal Auto Focus for fast, precise focusing in any scene

Full HD Movies1 at 60p/60i/24p

Capture HD Movies in your choice of super-smooth 60p, standard 60i or cinematic 24p, all at Full HD 1920x1080 resolution.1
AVCHD™ codec delivers stunning picture quality. MP4 codec oers smaller les for easier upload to the web.

Simple connectivity to smartphones via Wi-Fi® or NFC

Connectivity with smartphones for One-touch sharing/One-touch remote has been simplied with Wi-Fi®/NFC control.
In addition to Wi-Fi support for connecting to smartphones, the NEX-5T also supports NFC (near eld communication)
providing “touch connection” convenience when transferring images to Android™ smartphones and tablets. Users need
only touch devices to connect; no complex set-up is required. Moreover, when using Smart Remote Control — a feature
that allows shutter release to be controlled by a smartphone — connection between the NEX-5T and the smartphone can
be established by simply touching devices.

PlayMemories Camera Apps

Personalize your camera by adding new features of your choice with PlayMemories Camera Apps. Find apps to t your
shooting style from portraits, detailed close-ups, sports, time lapse, motion shot and much more. Use apps that shoot,
share and save photos using Wi-Fi that make it easy to control and view your camera from smartphone, and post photos
directly to Facebook or backup images to the cloud without connecting to a computer.11

180-degree tilt-able 3.0” Touch LCD

The NEX-5T is equipped with a tilt-able LCD screen that ips up 180-degrees without sacricing the compactness for which
the 5-series is renowned for. This makes taking great self-portraits incredibly easy since users can precisely compose shots,
choosing to include people or objects in the frame for more satisfying results.

Picture Eect mode

There are 11 types (15 variations) of Picture Eects to choose from: Posterization (Color, B/W), Pop Color, Retro Photo,
Partial Color (R,G,B,Y), High Contrast Mono, Toy Camera, So High-key, So Focus, HDR Painting, Rich-tone Mono,
Miniature. Each is unique and each give you a new and exciting way to make your images and videos pop.

Up to ISO 25600 sensitivity with advanced noise reduction

With a new Exmor® sensor that features the same adaptive noise reduction technology from Sony’s agship SLT-A99V, the
NEX-5T easily oers a wide range of sensitivity from ISO 100 to ISO 25600.

Accepts Sony® E-mount lenses

Compatible with Sony’s wide selection of E-mount series of smaller, lighter lenses designed specically for α NEX compact
interchangeable lens cameras. Open up a world of endless creative options.

Auto Object Framing

Give your photos a professional look with Auto Object Framing. Featuring advancements like exceptional two-person
portrait capability along with Face Detection and Tracking Focus, Auto Object Framing not only turns ordinary photos into
stunning compositions but does so automatically recognizing the scene then cropping accordingly.

Auto HDR mode

Captures more scene dynamic range than a single exposure can handle—and more range than photo lm. Combines
the best highlight detail from one shot, the best mid-tones from a second and the best shadow detail from a third for one
incredible shot (up to 6 EV stops). Captures in a split second. (Recommended for still subjects.)

Face Detection/ Registration technology

The camera can automatically detect and register up to eight individual faces and adjust focus, exposure, white balance
and ash to help deliver crisp, properly lit images of family and friends. Can prioritize children or adults

Sweep Panorama™ Technology

Capture expansive landscapes automatically. Press the shutter, sweep vertically or horizontally. The camera does the rest,
continuously shooting images and stitching them together. Up to 23 MP image size. Up to 202 degrees maximum sweep
angle (18mm focal length).

Dynamic Range Optimizer (DRO)

Improves results with backlit subjects and recovers details hidden in shadows. Settings include Auto, Level with a choice
of ve operating levels and O.

Six Creative Style settings

Control how the camera processes your images with six nishing styles: Standard, Vivid, Portrait, Landscape, Sunset and
B&W. You can even ne-tune contrast, saturation, and sharpness to your personal taste.

Photo Creativity Touch interface

The Photo Creativity touch interface enables you to easily enjoy the creative expression of SLR-quality digital imaging
without the complicated settings. Changes can be easily made using the control dial with results seen in real time on the
LCD. Settings include; Background Defocus, Brightness, Color, Vividness and most Picture Eects.

Clear Image Zoom

Utilizing Sony’s exclusive By Pixel Super Resolution Technology, Clear Image Zoom increases the eective focal length
of your lens up to 2x by digitally magnifying the center of your image with nearly imperceptible degradation. It virtually
doubles the eective focal length of whatever lens you’re using providing greater shooting exibility.

Convenient USB charging

Easily recharge the camera via USB charging. Simply connect the bundled USB cable and recharge the battery without
removing it from the camera, either via AC outlet or PC connection.

Multi-interface terminal

Multi-interface Smart Accessory2 terminal greatly expands the connectivity options such as external ash units

Stamina™ battery power for up to 330 shots

Take up to 330 shots on a single charge7 with Sony® lithium ion Stamina™ battery power. Sony’s InfoLITHIUM® battery
system enables you to see the percent of power remaining, so you can keep shooting in condence.

7

Specications

Camera

Lens Compatibility

Camera Type

Lens Mount Type Sony E-mount

Imaging Sensor

Imaging Sensor Exmor® APS HD CMOS sensor (23.5 X 15.6mm)

Processor BIONZ™ image processor

Anti Dust Charge protection coating on Optical Filter and ultrasonic vibration mechanism

Pixel Gross Approx. 16.1M pixels

Eective Picture Resolution Approx. 16.1 megapixels

Focal Length Conversion Factor 1.5x

Color Filter System RGB primary color lters

Recording

Sony E-mount, operation with Minolta / Konica Minolta Maxxum A-mount lenses
conrmed via optional LA-EA1/LA-EA2 adaptor

Interchangeable Lens
Digital SLR camera

Media Type

Color Space

Still Image Mode JPEG (Standard, Fine), RAW, RAW+JPEG

Still Image Max Eective Resolution 16.1 Megapixels

Still Image Size 16:9 L: 4912 x 2760 (7.1 MP), M:3568 x 2000 (7.1 MP), S: 2448 x 1376 (3.4 MP)

Still Image Size 3:2 L: 4912 x 3264 (16 MP), M: 3568 x 2368 (8.4 MP) , S: 2448 x 1624 (4 MP)

Panorama Still Image Size

Video Mode AVCHD / MP4 (MPEG-4 AVC (H.264))

Video Resolution

Video Signal NTSC color, EIA standards

Audio Format Dolby Digital (AC-3) / MPEG-4 AAC-LC

Microphone/Speaker

Still Image File Format

Optics/Lens

Lens Type Sony E-mount

Lens Mount Type Sony E-mount lenses

Lens Stabilization Optical SteadyShot

Aperture (Max.) f/3.5 - 5.6

Aperture (Min.) f/22 - F32

Optical Zoom Approx. 3x

Digital Zoom Approx. 4x

Focal Length (35mm equivalent) 24mm - 77mm

Filter Diameter 40.5mm

Lens Groups-Elements 8 groups, 9 elements (4 aspheric surfaces)

Minimum Focus Distance 9-13/16'' (.25m) (W) - 11-13/16'' (0.3m) (T)

AF for Movie Capture Contrast AF

Angle of View 83°-32°

Aperture Blade 7 Blades

Aspheric Elements 1 ED element, 3 aspheric elements

Dimensions (Max. Diameter x Length) 2-5/8" x 1-13/16 (64.7 x 29.9mm)

Direct Manual Focus Yes

Exterior Finish Silver (NEX-5T/S)

Lens Weight 4.1 oz (116 g.)

Low Noise During Movie Capture Yes

Memory Stick PRO Duo™ / Pro-HG Duo™ media; SD, SDHC and SDXC memory
card

Stills:
sRGB, AdobeRGB
Movie:
xvYCC standard (x.v.Color™ when connected via HDMI cable) compatible with

TRILUMINOS™ color

Horizontal Wide: 12,416 x 1,856 (23M),
Horizontal Std.: 8,192 x 1,856 (15M),
Vertical Wide: 2,160 x 5,536 (12M),
Vertical Std.: 2,160 x 3,872 (8.4M),
3D Sweep Panorama: N/A

AVCHD:
PS - 1920 x 1080/60p @ 28Mbps
FX - 1920 x 1080/60i @ 24Mbps
FH - 1920 x 1080/60i @ 17Mbps
FX - 1920 x 1080/24p @ 24Mbps
FH - 1920 x 1080/24p @ 17Mbps

MP4:
HD - 1440 x 1080/30p @ 12Mbps
VGA - 640 x 480/30p @ 3Mbps

Built-in Stereo Microphone / Built-in monaural speaker; volume settings in 8 steps
between 0 and 7

JPEG (DCF Ver. 2.0, Exif Ver.2.3, MPF Baseline compliant), RAW (Sony ARW

2.3format)

Maximum Magnication 0.215x

Mount Material Metal

EV Compensation

Macro Mode Yes

Magnication 0.215x

LCD Display

LCD Type 3.0” (7.5cm) Touchscreen TFT LCD (921,600 dots)

Angle Adjustment Tilt angle: Up: 180 degrees; Down: Approx. 50 degrees

Brightness Control Auto, Manual (5 steps between -2 to +2)

Coverage 100%

Live View Continuous Live View

Real-time image adjustment display On / O

Histogram Yes (On / o)

Peaking Yes (Level setting: High / Mid / Low / O, Color: White / Red / Yellow)

Grid Display Yes (Rule of Thirds, 4x6 Square, Diagonal & 4x6 Square Grids, O)

Customization

Touch Panel Yes

Focus Control

Focus System Fast Hybrid AF (phase-detection AF / contrast-detection AF)

Focus Points 99 points (phase-detection AF), 25 points (contrast-detection AF)

AF Modes

Focus Area

Focus Sensitivity EV 0 to 20 EV (at ISO100 equivalent, with F2.8 lens attached)

Manual Focus Assist MF Assist (4.8x, 9.6x)

Focus Features Predictive control (AF-A, AF-C), Focus Lock

AF Illuminator Yes (with built-in LED type)

Exposure System

Picture Eect(s)

Auto Exposure Lock Yes (AE Lock button). Can be disabled from menu

Color Temperature

Creative Style

D-Range Optimizer Yes: (Auto, Level, O)

Exposure Bracketing 3 continuous or single shots in 1/3 or 2/3 EV steps

Exposure Compensation

Exposure Settings

ISO

Metering Advanced 1200-zone evaluative metering

Metering Modes Multi-segment, Center-weighted, Spot

Metering Sensitivity EV 0 to 20 EV (at ISO100 equivalent, with F2.8 lens attached)

Noise Reduction Long exposure NR: available of shutter speeds longer than 1 sec

Scene Mode(s)

Still images: +/-3.0 EV (1/3EV steps selectable)
Movies: +/-2.0 EV (1/3EV steps selectable)

Grid, Histogram display, Digital Level Gauge, Grid Line, Magnied display for
playback

Single-shot AF (AF-S), Continuous AF (AF-C), Auto Focus, Direct Manual Focus
(DMF), Manual Focus

Multi Point AF (99 points for phase-detection AF, 25 points for contrast-detection
AF), Center-weighted, Flexible, Spot

11 modes (15 eects): Posterization (Color, B/W), Pop Color, Retro Photo, Partial
Color (R,G,B,Y), High Contrast, Mono, Toy Camera, So High-key, So Focus, HDR
Painting, Rich-tone Mono, Miniature

2500 – 9900K with 15-step each Magenta/Green compensation (G7 to M7),
Amber/Blue (A7 to B7), Custom

Standard, Vivid, Portrait , Landscape, Sunset, Black & White (Contrast (-3 to
+3steps), Saturation (-3 to +3steps), Sharpness (-3 to +3steps)

Still images: +/-3.0 EV (1/3EV steps selectable)
Movies: +/-2.0 EV (1/3EV steps selectable)

iAUTO, Superior Auto, Programmed AE (P), Aperture priority (A), Shutter-speed
priority (S), Manual (M), Sweep Panorama, Scene Selection

Stills: ISO 100-25600 selectable in 1 EV steps, Auto (100-3200)
Movies: ISO 100-6400 selectable in 1 EV steps, Auto (100-3200)

Portrait, Landscape, Macro, Sports Action, Sunset, Night Portrait, Night View, Hand­held Twilight, Anti Motion Blur

White Balance Mode

Drive System

Burst Buer

Continuous Shooting Speed Speed Priority Continuous mode: 10 fps

Drive Mode

Self-timer 2-sec. or 10-sec. delay

Shutter Speeds

Shutter Type Electronically-controlled, vertical-traverse, focal-plane shutter

Flash

Flash Bracketing ±2.0 EV

Flash Compensation ±2.0 EV (switchable between 1/3 EV steps)

Flash Coverage 16 mm (focal length printed on lens body)

Flash Metering System Pre-ash TTL

Flash Modes

Flash Type External ash (supplied) attachable to Smart Accessory Terminal2

Guide Number 7 (in meters at ISO100)

Recycling Time Approx. 4 sec.

Convenience Features

Self Timer Yes

Red-Eye Reduction Yes

Erase/Protect Ye s

Media/Battery Indicator Yes

Power Save Mode Yes

Still Image Playback Options Slideshow, Panorama scrolling, Folder selection (Still)

Video Playback Options Forward / Rewind (movie)

Multiple Language Display Yes

View & Index

Advanced Features

Face Detection On, O, Face Registration, Face Selection; maximum eight faces detected

Smile Shutter™ technology Smile shutter (selectable from 3 steps)

Image Stabilization Lens-based (where applicable)

Intelligent Auto Ye s

Wi-Fi Yes

x.v.Color™ x.v.Color™ when connected via HDMI cable

Superior Auto Ye s

Tracking Focus Ye s

Anti Motion Blur Yes

Auto High Dynamic Range

Auto, Daylight, Shade, Cloudy, Incandescent, Fluorescent, Flash, Color
temperature range 2500 to 9900K, Custom

JPEG Standard (11 shots)
JPEG Fine (11 shots)
RAW (10 shots)
RAW+JPEG (9 shots)

Single-shot, Continuous, Speed Priority Continuous, Self-timer (10/2 sec. delay),
Self-timer (Cont.) (with 10 sec. delay; 3/5 exposures), Bracketing

Still images:
1/4000 to 30 sec, Bulb

Movies:
1/4000 to 1/4 (1/3 steps)
Up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode)

Flash o, Auto ash, Fill-ash, Slow Sync., Rear Sync., Red-eye reduction (on/o
selectable)

Single (with or without shooting information), RGB histogram and highlight/shadow
warning, 4/9-frame index view, Enlarged display mode (L: 13.6x, M: 9.9x, S: 6.8x),
Auto Review (10/5/2sec, O), Image orientation (On/O), Slideshow, Panorama
scrolling, Folder selection (still), Forward/Rewind (movie), Delete, Protect

Yes, (Auto Exposure Dierence, Exposure dierence Level (1-6 EV at 1.0 EV step),
o)

Photo Creativity Yes

Priority Setting (for Face Detection) Yes (eight faces max)

Shooting Tips Yes

Sweep Panorama Horizontal (Wide / Standard), Vertical (Wide / Standard)

Accessories

Flash and ash case
NP-FW50 rechargeable battery
AC-UB10 AC adaptor

Supplied Accessories

Shoulder strap
Body cap
Micro USB cable
CD-ROM

1. Records in up to 29 minutes segments.

5. Attaching Sony A-mount lens requires LA-EA1 (note: Autofocus available with SSM and SAM series lenses when using LA-EA1) or LA-EA2 adaptors (sold separately).

6. Compatible with BRAVIA® Sync or Theatre Sync™ HDTVs connected via HDMI®.

7. Actual performance varies based on settings, environmental conditions, and usage. Battery capacity decreases over time and use.

8. Requires compatible BRAVIA® HDTV and cable sold separately

9. Auto Focus function available with Sony E-Mount lenses and Sony A-mount SSM and SAM series lenses when using LA-EA1.
