Sony MBX-189 Schematics

5

4

3

2

1

Schematics Page Index (Title / Revision / Change Date)

Page

01
02
03

D D

04
05
06
07
08
09
10
11
12
13
14
15

C C

16
17
18
19
20
21
22
23
24
25
26
27
28

B B

29
30
31
32
33
34
35
36
37
38
39
40

A A

Title of Schematics Page
Schematics Page Index
Block Diagram
Penryn(HOST BUS) 1/3
Penryn(HOST BUS) 2/3
Penryn (Power/Gnd) 3/3
CLOCK GEN
Cantiga (HOST) 1/7
Cantiga (DMI) 2/7
Cantiga (GRAPHIC) 3/7
Cantiga (DDRII) 4/7
Cantiga (POWER,VCC) 5/7
Cantiga (VCC CORE) 6/7
Cantiga (VSS) 7/7
DDRII(SO-DIMM_0) 1/3
DDRII(SO-DIMM_1) 2/3
DDRII(Termination) 3/3
ICH9-M( PCI/USB ) 1/5
ICH9-M( LPC,IDE,SATA )2/5
ICH9-M( GPIO) 3/5
ICH9-M( POWER) 4/5 GMCH Power(Dummy Page)
ICH9-M( GND) 5/5
EC+KBC(WPC8763L)
Flash ROM/SPI
Debug Port
EXPRESS CARD
Mini-PCIE Card (WLAN)
Robson Connector
TV-Tuner Connector
LAN (88E8055) 1/2
LAN (Transformer) 2/2
SATA HDD
PATA CD-ROM
Media Key Connector
PCI (PCI BUS)
PCI ( i.LINK)
PCI (SD/MS-DUO)
Camera Connector
Felica Connector
USB&Audio Jack Connector
Bluetooth Connector

Rev.

SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD

Page

41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80

Title of Schematics Page
Modem Connector
KB Connector
USB 2.0 to PATA Bridge
Status LED
Touch Pad Connector
HW Thermal Protection
FAN
Thermal Sensor
Power Design Diagram
DCIN&Charger
Discharge Circuit
Identify IC
SYS Power (+3_3V/+5V)
SYS Power(+1_5V/+1_05V)
DDR2 Power(+1_8V/+0_9V)
CPU_Vcore---ISL6266A
Others power plane
OVP protection
VGA Power(ATI VDD)

LID Switch
Inverter
LVDS
HDMI
CRT
Audio (CODEC)
Audio (MUTE)
Audio (Power)
Audio (Speaker AMP)
Audio (Speaker Connector)
VGA (PCI-E) 1/6
VGA (STRAP) 2/6
VGA (I/O) 3/6
VGA (Memory BUS) 4/6
VGA (LVDS) 5/6
VGA (POWER) 6/6
VRAM (GDDR3) 1/3
VRAM (GDDR3) 2/3
VRAM (BYPASS) 3/3
HOLE

Rev.

SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD
SD

DVT2 BOM Control Table

VALUE
Head

UMA

Discrete
VGA with
M86

Discrete
VGA with
M82

CA_

Stuff

Un-stuff

Un-stuff

P. Leader

M82_M86_AT_

Un-stuff Un-stuffUn-stuffUn-stuff

Stuff Stuff

Stuff Stuff

Un-stuff

Un-stuff

Check by

NC_

Un-stuff

Un-stuff

Design by

TONY CHENGJERRY HSIAOJERRY HSIAO

Project Code & Schematics Subject:

5

M760 Main Board

4

PCB P/N:

3

FUBAI 1P-0083101-8010)
HANNSTAR (1P-0083500-8010)
IRIS (1P-0083J01-8010)

2

HON HAI Precision Ind. Co., Ltd.

HON HAI Precision Ind. Co., Ltd.

HON HAI Precision Ind. Co., Ltd.
CCPBG - R&D Division

CCPBG - R&D Division

FOXCONN

FOXCONN

FOXCONN

Title

Title

Title

Index Page

Index Page

Index Page

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

M760

M760

M760

Date: Sheet

Date: Sheet

Date: Sheet of

CCPBG - R&D Division

189Thursday, March 27, 2008

189Thursday, March 27, 2008

1

189Thursday, March 27, 2008

of

of

1.0

1.0

1.0

1

2

3

4

5

6

7

8

TI CHARGER

BQ24751

M760 (IRX-4370) Montevina + M86-LP/M82-XT

DC_IN

A A

PS8101QFN48G

HDMI

HDMI REPEATER

P.64

GDDR3 VRAM
16M X 32b X 4

---------------------­32M X 32b X 2

P.77-79

LVDS

WSXGA

P.63

CRT

P.65

B B

TMDS
LVDS

CRT

LVDS/CRT

ATI M86-ME LP

----------------­ATI M82-ME XT

Non-Macrovision GPU

P.71-76

TMDS

PCIE X16

CPU
Penryn/Celeron
Processor

Micro-FCPGA-478
(478 -pin socket P)

P.3-5

FSB
667/800/1067 MHz

North Bridge
Cantiga

-GM47/PM45

FCBGA-1329

P.7-13

667/800 MHZ

667/800 MHZ

CK505
SL28648BLC

SO-DIMM 0
667/800 MHZ
DDR(II)

SO-DIMM 1
667/800 MHZ
DDR(II)

P.6

200 pin

P.14-16

200 pin

X,TAL

14.318MHZ

P.14-16

Pre-AMP

MDC 1.5
Modem

P.41

Realtek
ALC262 VD

-----------------

P.66-70

Ricoh R5C833
CardReader

GHK 216

i.LINK

P.34-36

USB2.0

PCI BUS

HDA

C-Link0

South Bridge
ICH9-M

4

676 mBGA

DMI X4

(USB x 12)
(PCIE x 6)
(SATA x 2)

P.17-21

LPC

5

PCIE

6

USB2.0

SATA 3Gb/s

SPI

SATA
HDD

P.31

HDMI
SPI ROM

P.17

Winbond
WPCE775L

LQFP-128

P.22

PS/2

Touch PAD

P.45

Keyboard

P.42

RJ11

Int. Speaker

1.0 Walt x 2

G1431F2U
Amplifier

Digital Mic

CAM(1.3M)

P.37

Ext. Mic In Jack

C C

Headphone Jack

USB 2.0
CONN.X3

P.39

MS Pro/DUO
SD Card

P.36

i.Link

P.35

PWM/TACH

GPIO

SPI

35001 Bus

D D

FAN

Lid Switch

P.47 P.48 P.46

1

P.61

2

Flash BIOS
16M bit

BATT ID

GPIO Expander

P.52

3

SMBus 2

BATT CONN

P.22

4

P.50

SMBus 1

Thermal Sensor
EMC1402-2-ACZL
(CPU/DDR)

MSOP-8

Thermal Sensor
G781P8f
(VGA/NB)

MSOP-8

5

P.48P40

Thermal Sensor
G709T1UF
(H/W Thermal shutdown)

SOT-23-5

88E8055

QFN-56

Gigabit

P.29-30

ROBOSON 1.6

P.27

Express
Card 34

P.25

Mini-Card(WLAN)
PCIE

P.26

Mini-Card (TV)
PCIE

P.28

Bluetooth

P.40

Felica

P.38

USB to PATA Bridge
CY7C68300C

6

Netswap
NS682403P

P.43

RJ45

BCAS

CIR

PATA
ODD

P.32

FOXCONN

FOXCONN

FOXCONN

Title

Title

Title

Block Diagram

Block Diagram

Block Diagram

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

M760

M760

M760

Date: Sheet

Date: Sheet

Date: Sheet

7

SYSTEM DC/DC

TPS51125RGER

INPUTS

DCBATOUT

SYSTEM DC/DC

SC411

INPUTS OUTPUTS

DCBATOUT

SYSTEM DC/DC

TPS51116RGER

DCBATOUT

CPU DC/DC

ISL6266A

INPUTS

DCBATOUT

SYSTEM DC/DC

APL5912

+1_5VRUN PEX_VDD

SYSTEM DC/DC

SC411

DCBATOUT

SYSTEM DC/DC

MAX8776

DCBATOUT

HON HAI Precision Ind. Co., Ltd.

HON HAI Precision Ind. Co., Ltd.

HON HAI Precision Ind. Co., Ltd.
CCPBG - R&D Division

CCPBG - R&D Division

CCPBG - R&D Division

8

P.63

OUTPUTSINPUTS

BT+
DCBATOUT

P.64

OUTPUTS

+5VALW

+5VALW_LDO

+3VALW

+ECVCC

+15V_ALW

P.65

+1_5VRUN
+1_05VRUN

P.66

OUTPUTSINPUTS

+1_8VSUS
+0_9VSUS

P.67

OUTPUTS

VHCORE

P.70

OUTPUTSINPUTS

P.70

OUTPUTSINPUTS
NV_VDD

P.71

OUTPUTSINPUTS

+VGFX_CORE

1.0

1.0
