KV-20WS1

SERVICE MANUAL

MODEL

RM-836

KV-20WS1A

RM-836

KV-20WS1B

RM-836

KV-20WS1D

RM-836

KV-20WS1E

DEST.COMMANDER CHASSIS NO.

Italian

French

AEP

Spanish

SCC-K31F-A

SCC-K36F-A

SCC-K32H-A

SCC-K30H-A

BE-5

MODEL

KV-20WS1K KV-20WS1R KV-20WS1U

COMMANDER

RM-836

CHASSIS

DEST.

OIRT

UK

CHASSIS NO.

SCC-K35M-A

SCC-K35L-A

SCC-K33D-A

MICROFILM

— 1 —

MENU

PROGR

RM-836

TRINITRON COLOR TV

R

5-4. SEMICONDUCTORS

KV-20WS1

L4941BV LM7808CT MC7808CT TEA7605 TL750L05CLPR

IN

GND

MC44002P

1

(TOP VIEW)

MC14538BCP MC44140P

16

OUT

PC123F2 PC123FY2

4

3

STV9379

DTA144ESA DTA144ESA-TP DTC114EK DTC114EKA-T146 DTC143TKA-T146

1

2

PST572D PST572D-T

1

3

2

4

5

6

7

DTC144EKA-T146 2SA1037K-T-146-R 2SA1162-G 2SC2412K-QR 2SC2412K-T-146-R

C

TDA2822M TEA2124

7

6

8

1 Ground

1

2140

2 Input

2

3 Output

3

1

SBX1981-51

20

2

3

( TOP VIEW )

5

DTA114ES DTC114ES-TP

4

E

B

TDA7264

E

C

9

B

SDA5250M-C9-GEG

1

(TOP VIEW)

8

64 41

65

M27C512-90C1-BE5-1

1724

25

32

1

(TOP VIEW)

16

9

8

80

124

( MARKING SIDE VIEW )

SE-135N SE135N-LF12

MSP3400C-PP-C6 MSP3410B-PP-F7

64

132

( TOP VIEW )

33

3

1 V OUT

2

1

2 V IN 3 GND

STR-S6707

NJM2233BL

40

ST24W04FM6TR

25

BF421-AMMO 2SA1091-O

BF871-127

1

1 ( TOP VIEW )

E

C

8

58

4

S2000N-16E305A

B

E

C

2SA1667 2SC3852A 2SD2394-EF

B

C

E

B

2SA933AS-QRT 2SA933AS-RT 2SC1740S-RT

LETTER SIDE

1

8

19

E

B

C

E

C

B

— 43 —

KV-20WS1

2SC2389STP-R

LETTER SIDE

E

C

2SC2785-HFE

E

C

2SC2808STP-R

BYD33G BYD33G-AMMO ERC06-15S

CATHODE

ERA81-004TP1 ERA83-006 MTZJ-T-77-5.6C MTZJ-T-77-6.8A MTZJ-T-77-6.8C MTZJ-T-77-33C MTZJ-T-77-3.9B MTZJ-T-77-7.5C

MTZJ-33C MTZJ-7.5B RD3.9ES-B2 RD5.6ESB2 RD6.8ES-B2 RD7.5ESB2 RD9.1ES-B3 1SS133T-77

HZT33-02RE UPC574J

MTZJ-T-77-9.1C

ANODE

B

DAN202K

CATHODE

ANODE

DAN202K-T-146

3

GBU4JL-6088

1

2

B

2

3

1

DAP202K DAP202K-T-146

3

LR5360HL

E

C

B

2SC3209LK-TP 2SD774-T-4 2SD774-34

E

C

2SC4793 2SD1763A

1

2

23

1

ANODE

DTZ5.1B DTZ9.1 RD5.6S-B

ANODE

B

EG-1Z-V1 EL1Z ERD28-06S ERD28-08S FMN-G12S

UDZ-TE-17-5.1B UDZ-TE-17-5.6B UDZ-TE-17-9.1B

CATHODE

RGP10GPKG23 RU3YX-LF-C4 RU-3YX-V1 RU4AM-T3 1SS292T-77

CATHODE

1N4531-AMMO

CATHODE

B

C

E

ANODE

— 44 —

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

SECTION 7

ELECTRICAL PARTS LIST

REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK

KV-20WS1

• Items marked " * " are not stocked since

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

they are seldom required for routine service. Some delay should be anticipated when ordering these items.

• All variable and adjustable resistors

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

*A-1632-654-A A BOARD, COMPLETE (KV-20WS1A) ***************** *A-1632-655-A A BOARD, COMPLETE (KV-20WS1B) ***************** *A-1632-653-A A BOARD, COMPLETE (KV-20WS1D) *A-1632-700-A A BOARD, COMPLETE (Greek Text) ***************** *A-1632-652-A A BOARD, COMPLETE (KV-20WS1E) ***************** *A-1632-658-A A BOARD, COMPLETE (KV-20WS1K) ***************** *A-1632-657-A A BOARD, COMPLETE (KV-20WS1R) ***************** *A-1632-656-A A BOARD, COMPLETE (KV-20WS1U) *****************

< CAPACITOR >

have characteristic curve B, unless otherwise noted.

RESISTORS

• All resistors are in ohms

• F : nonflammable

REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK

C034 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C035 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C036 1-126-965-11 ELECT 22MF 20% 50V C037 1-164-346-11 CERAMIC CHIP 1MF 16V C038 1-164-346-11 CERAMIC CHIP 1MF 16V

C039 1-163-205-00 CERAMIC CHIP 0.001MF 10% 50V C040 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V C041 1-126-965-11 ELECT 22MF 20% 50V C042 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C044 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V

C045 1-164-505-11 CERAMIC CHIP 2.2MF 16V C046 1-163-125-00 CERAMIC CHIP 220PF 5% 50V C099 1-165-320-11 CERAMIC CHIP 0.47MF 10% 16V C121 1-163-117-00 CERAMIC CHIP 100PF 5% 50V C122 1-163-249-11 CERAMIC CHIP 82PF 5% 50V

When indicating parts by reference number, please include the board name.

CAPACITORS COILS

MF : mF , PF : mmF MMH : mH , µH : mH

A

C001 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V C002 1-126-968-11 ELECT 100MF 20% 50V C003 1-164-492-11 CERAMIC CHIP 0.15MF 10% 16V C004 1-163-034-00 CERAMIC CHIP 0.033MF 50V C005 1-163-105-00 CERAMIC CHIP 33PF 5% 50V

C006 1-163-105-00 CERAMIC CHIP 33PF 5% 50V C007 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C008 1-126-965-11 ELECT 22MF 20% 50V C009 1-126-961-11 ELECT 2.2MF 20% 50V C010 1-163-033-91 CERAMIC CHIP 0.022MF 50V

C011 1-163-243-11 CERAMIC CHIP 47PF 5% 50V C012 1-163-113-00 CERAMIC CHIP 68PF 5% 50V C013 1-163-078-11 CERAMIC CHIP 0.033MF 10% 25V C014 1-164-346-11 CERAMIC CHIP 1MF 16V C015 1-163-121-00 CERAMIC CHIP 150PF 5% 50V

C016 1-164-222-11 CERAMIC CHIP 0.22MF 25V C017 1-162-638-11 CERAMIC CHIP 1MF 16V C018 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C019 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V C020 1-163-038-00 CERAMIC CHIP 0.1MF 25V

C021 1-164-005-11 CERAMIC CHIP 0.47MF 25V C022 1-126-960-11 ELECT 1MF 20% 50V C024 1-126-965-11 ELECT 22MF 20% 50V C025 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C026 1-126-965-11 ELECT 22MF 20% 50V

C027 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C028 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V C029 1-163-077-00 CERAMIC CHIP 0.1MF 50V C030 1-163-077-00 CERAMIC CHIP 0.1MF 50V C031 1-163-038-00 CERAMIC CHIP 0.1MF 25V

C123 1-163-139-00 CERAMIC CHIP 820PF 5% 50V C124 1-163-249-11 CERAMIC CHIP 82PF 5% 50V C131 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C135 1-126-934-11 ELECT 220MF 20% 16V C136 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V

C162 1-126-967-11 ELECT 47MF 20% 16V C201 1-126-965-11 ELECT 22MF 20% 50V C202 1-126-941-11 ELECT 470MF 20% 25V C205 1-126-963-11 ELECT 4.7MF 20% 50V C206 1-126-933-11 ELECT 100MF 20% 16V

C207 1-126-933-11 ELECT 100MF 20% 16V C208 1-126-963-11 ELECT 4.7MF 20% 50V C210 1-163-033-91 CERAMIC CHIP 0.022MF 50V C211 1-126-965-11 ELECT 22MF 20% 50V C213 1-164-005-11 CERAMIC CHIP 0.47MF 25V

C214 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C215 1-163-117-00 CERAMIC CHIP 100PF 5% 50V (KV-20WS1B) C216 1-163-109-00 CERAMIC CHIP 47PF 5% 50V C217 1-163-117-00 CERAMIC CHIP 100PF 5% 50V

C218 1-164-005-11 CERAMIC CHIP 0.47MF 25V C219 1-126-964-11 ELECT 10MF 20% 50V C220 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C221 1-163-117-00 CERAMIC CHIP 100PF 5% 50V (KV-20WS1B)

C222 1-126-934-11 ELECT 220MF 20% 16V C223 1-163-133-00 CERAMIC CHIP 470PF 5% 50V C224 1-163-133-00 CERAMIC CHIP 470PF 5% 50V C225 1-126-964-11 ELECT 10MF 20% 50V C226 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V

— 49 —

KV-20WS1

A

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARK

C227 1-163-084-00 CERAMIC CHIP 1.5PF 0.25PF 50V C228 1-163-084-00 CERAMIC CHIP 1.5PF 0.25PF 50V C229 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C230 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C231 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V

C232 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C233 1-163-003-11 CERAMIC CHIP 330PF 10% 50V C234 1-163-003-11 CERAMIC CHIP 330PF 10% 50V C235 1-126-964-11 ELECT 10MF 20% 50V C236 1-126-964-11 ELECT 10MF 20% 50V

C240 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V C242 1-164-346-11 CERAMIC CHIP 1MF 16V C243 1-164-346-11 CERAMIC CHIP 1MF 16V C244 1-164-346-11 CERAMIC CHIP 1MF 16V C245 1-164-346-11 CERAMIC CHIP 1MF 16V

C246 1-126-965-11 ELECT 22MF 20% 50V C247 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C300 1-126-942-61 ELECT 1000MF 20% 25V C301 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C302 1-163-038-00 CERAMIC CHIP 0.1MF 25V

C303 1-126-965-11 ELECT 22MF 20% 50V C304 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C305 1-124-257-00 ELECT 2.2MF 20% 50V C306 1-136-164-00 FILM 0.082MF 5% 50V C307 1-163-077-00 CERAMIC CHIP 0.1MF 10% 25V

C308 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C309 1-126-163-11 ELECT 4.7MF 20% 50V C310 1-163-077-00 CERAMIC CHIP 0.1MF 10% 25V C311 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C312 1-163-038-00 CERAMIC CHIP 0.1MF 25V

REF.NO. PART NO. DESCRIPTION REMARK

C404 1-164-346-11 CERAMIC CHIP 1MF 16V C405 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C406 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C408 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C409 1-163-135-00 CERAMIC CHIP 560PF 5% 50V

C410 1-126-967-11 ELECT 47MF 20% 16V C411 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C412 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C413 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C414 1-126-967-11 ELECT 47MF 20% 16V

C415 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C416 1-126-965-11 ELECT 22MF 20% 50V C417 1-126-965-11 ELECT 22MF 20% 50V C418 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C419 1-164-346-11 CERAMIC CHIP 1MF 16V

C420 1-164-346-11 CERAMIC CHIP 1MF 16V C421 1-164-337-11 CERAMIC CHIP 2.2MF 16V C422 1-164-337-11 CERAMIC CHIP 2.2MF 16V C423 1-164-337-11 CERAMIC CHIP 2.2MF 16V C424 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V

C425 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C500 1-137-374-11 FILM 0.047MF 5% 50V C501 1-126-963-11 ELECT 4.7MF 20% 50V C502 1-163-077-00 CERAMIC CHIP 0.1MF 50V C503 1-126-952-11 ELECT 1000MF 20% 35V

C504 1-126-968-11 ELECT 100MF 20% 50V C505 1-126-941-11 ELECT 470MF 20% 25V C506 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C507 1-126-965-11 ELECT 22MF 20% 50V C508 1-130-785-11 MYLAR 0.47MF 10% 100V

C313 1-163-137-00 CERAMIC CHIP 680PF 5% 50V C314 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C315 1-163-038-00 CERAMIC CHIP 0.1MF 25V C316 1-163-038-00 CERAMIC CHIP 0.1MF 25V C317 1-163-038-00 CERAMIC CHIP 0.1MF 25V

C319 1-163-038-00 CERAMIC CHIP 0.1MF 25V C320 1-163-038-00 CERAMIC CHIP 0.1MF 25V C321 1-126-963-11 ELECT 4.7MF 20% 50V C322 1-163-101-00 CERAMIC CHIP 22PF 5% 50V C323 1-163-099-00 CERAMIC CHIP 18PF 5% 50V

C324 1-163-119-00 CERAMIC CHIP 120PF 5% 50V C325 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C326 1-164-489-91 CERAMIC CHIP 0.22MF 16V C327 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C328 1-163-038-00 CERAMIC CHIP 0.1MF 25V

C329 1-163-016-00 CERAMIC CHIP 0.0039MF 10% 50V C330 1-163-038-00 CERAMIC CHIP 0.1MF 25V C331 1-104-665-11 ELECT 100MF 20% 25V C332 1-126-965-11 ELECT 22MF 20% 50V C333 1-107-715-11 ELECT 22MF 20% 16V

C341 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C345 1-163-139-00 CERAMIC CHIP 820PF 5% 50V C347 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C353 1-163-117-00 CERAMIC CHIP 100PF 5% 50V C355 1-163-059-91 CERAMIC CHIP 0.01MF 10% 50V

C359 1-126-965-11 ELECT 22MF 20% 50V C360 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C401 1-126-967-11 ELECT 47MF 20% 16V C402 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C403 1-164-346-11 CERAMIC CHIP 1MF 16V

C510 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C511 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C601 1-136-516-12 FILM 0.1MF 20% 300V C602 1-136-516-12 FILM 0.1MF 20% 300V C603 1-117-700-61 CERAMIC 0.0022MF 20% 250V

C604 1-117-700-11 CERAMIC 0.0022MF 20% 250V C605 1-162-964-91 CERAMIC 0.0047MF 250V C606 1-162 964-91 CERAMIC 0.0047MF 250V C610 1-104-665-11 ELECT 100MF 20% 25V C611 1-136-538-11 FILM 0.001MF 3% 2KV

C612 1-107-929-11 ELECT 10MF 20% 100V C613 1-162-318-11 CERAMIC 0.001MF 10% 500V C614 1-104-666-11 ELECT 220MF 20% 25V C615 1-124-347-00 ELECT 100MF 20% 160V C616 1-162-116-00 CERAMIC 680PF 10% 2KV

C617 1-107-929-11 ELECT 10MF 20% 100V C618 1-102-228-00 CERAMIC 470PF 10% 500V C619 1-126-942-61 ELECT 1000MF 20% 25V C621 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C622 1-126-965-11 ELECT 22MF 20% 50V

C623 1-111-055-91 ELECT 56MF 20% 25V C624 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V C625 1-126-967-11 ELECT 47MF 20% 50V C626 1-102-228-00 CERAMIC 470PF 10% 500V C627 1-111-097-11 ELECT 0.0022F 20% 35V

C628 1-126-964-11 ELECT 10MF 20% 50V C629 1-126-933-11 ELECT 100MF 20% 16V C630 1-113-473-11 ELECT(BLOCK) 180MF 20% 400V C631 1-124-910-11 ELECT 47MF 20% 50V C632 1-106-228-00 MYLAR 0.22MF 10% 100V

— 50 —

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK

KV-20WS1

A

C633 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V

< DIODE > C634 1-104-665-11 ELECT 100MF 20% 25V C635 1-111-097-11 ELECT 0.0022F 20% 35V C636 1-102-228-00 CERAMIC 470PF 10% 500V C638 1-163-205-00 CERAMIC CHIP 0.001MF 10% 50V

D001 8-719-057-56 DIODE LS5360HL

*4-203-258-01 HOLDER, LED; D001

D002 8-719-982-27 DIODE MTZJ-33C

D003 8-719-914-43 DIODE DAN202K C639 1-102-228-00 CERAMIC 470PF 10% 500V

D004 8-719-991-33 DIODE 1SS133T C640 1-102-110-00 CERAMIC 220PF 10% 50V C641 1-106-228-00 MYLAR 0.22MF 10% 100V C644 1-106-383-00 MYLAR 0.047MF 10% 100V C645 1-104-666-11 ELECT 220MF 20% 25V

D005 8-719-914-43 DIODE DAN202K

D006 8-719-914-43 DIODE DAN202K

D007 8-719-914-43 DIODE DAN202K

D008 8-719-056-80 DIODE DTZ5.1B C646 1-163-038-00 CERAMIC CHIP 0.1MF 25V

D009 8-719-056-80 DIODE DTZ5.1B C647 1-163-038-00 CERAMIC CHIP 0.1MF 25V C800 1-126-772-11 ELECT 1MF 20% 250V C801 1-129-719-00 FILM 0.027MF 10% 630V C802 1-136-085-00 FILM 0.016MF 3% 2KV

D010 8-719-991-33 DIODE 1SS133T

D011 8-719-056-80 DIODE DTZ5.1B

D012 8-719-992-02 DIODE RB705D

D013 8-719-991-33 DIODE 1SS133T C803 1-136-540-11 FILM 0.82MF 5% 200V

D017 8-719-991-33 DIODE 1SS133T C804 1-126-959-11 ELECT 0.47MF 20% 50V C806 1-102-244-00 CERAMIC 220PF 10% 500V C807 1-107-651-11 ELECT 4.7MF 20% 250V C809 1-162-134-11 CERAMIC 470PF 10% 2KV

D301 8-719-991-33 DIODE 1SS133T

D302 8-719-991-33 DIODE 1SS133T

D303 8-719-991-33 DIODE 1SS133T

D304 8-719-914-44 DIODE DAP202K C810 1-129-702-00 FILM 0.001MF 10% 400V

D305 8-719-914-44 DIODE DAP202K C811 1-102-228-00 CERAMIC 470PF 10% 500V C812 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C813 1-162-116-00 CERAMIC 680PF 10% 2KV C815 1-162-134-11 CERAMIC 470PF 10% 2KV

D306 8-719-056-80 DIODE DTZ5.1B

D309 8-719-056-80 DIODE DTZ5.1B

D314 8-719-914-43 DIODE DAN202K

D315 8-719-914-43 DIODE DAN202K C817 1-136-559-11 MYLAR 0.0047MF 10% 400V

D338 8-719-914-43 DIODE DAN202K C818 1-136-540-11 FILM 0.82MF 5% 200V C819 1-162-318-11 CERAMIC 0.001MF 10% 500V C820 1-126-951-11 ELECT 470MF 20% 35V C823 1-106-375-12 MYLAR 0.022MF 10% 250V

D401 8-719-109-97 DIODE RD6.8ES-B2

D402 8-719-109-97 DIODE RD6.8ES-B2

D403 8-719-109-97 DIODE RD6.8ES-B2

D404 8-719-109-97 DIODE RD6.8ES-B2 C824 1-106-367-00 MYLAR 0.01MF 10% 400V

D405 8-719-109-97 DIODE RD6.8ES-B2 C828 1-104-709-11 ELECT 4.7MF 0 160V C833 1-106-220-00 MYLAR 0.1MF 10% 100V C839 1-136-200-11 FILM 0.15MF 5% 400V C1200 1-136-165-00 FILM 0.1MF 5% 50V

D406 8-719-109-97 DIODE RD6.8ES-B2

D407 8-719-109-97 DIODE RD6.8ES-B2

D408 8-719-110-14 DIODE RD9.1ES-B2

D409 8-719-110-14 DIODE RD9.1ES-B2 C1201 1-136-157-00 FILM 0.022MF 5% 50V

D410 8-719-110-14 DIODE RD9.1ES-B2 C1202 1-136-157-00 FILM 0.022MF 5% 50V C1203 1-136-169-00 FILM 0.22MF 5% 50V C1204 1-136-169-00 FILM 0.22MF 5% 50V C1205 1-101-004-00 CERAMIC 0.01MF 50V

D411 8-719-991-33 DIODE 1SS133T

D412 8-719-109-97 DIODE RD6.8ES-B2

D413 8-719-991-33 DIODE 1SS133T

D415 8-719-110-14 DIODE RD9.1ES-B2 C1206 1-101-004-00 CERAMIC 0.01MF 50V

D416 8-719-056-84 DIODE UDZ-TE-17-7.5B C1215 1-136-173-00 FILM 0.47MF 5% 50V C1216 1-137-366-11 FILM 0.0022MF 5% 50V C1217 1-137-366-11 FILM 0.0022MF 5% 50V

D417 8-719-056-84 DIODE UDZ-TE-17-7.5B

D418 8-719-056-84 DIODE UDZ-TE-17-7.5B

D419 8-719-056-84 DIODE UDZ-TE-17-7.5B < FILTER >

D421 8-719-109-97 DIODE RD6.8ES-B2

D501 8-719-302-43 DIODE EL1Z CF001 1-767-120-21 VIBRATOR, CERAMIC CF200 1-409-327-00 TRAP, CERAMIC (6.5MHZ) (KV-20WS1B)

D602 8-719-991-33 DIODE 1SS133T

D603 8-719-109-97 DIODE RD6.8ES-B2 < CONNECTOR >

D604 8-719-302-43 DIODE EL1Z

D605 8-719-302-43 DIODE EL1Z CN001 *1-564-508-11 PLUG, CONNECTOR 5P

D606 8-719-028-89 DIODE EK04-V1 CN081 *1-568-881-51 PIN, CONNECTOR 6P CN082 *1-568-880-51 PIN, CONNECTOR 5P CN201 *1-568-879-11 PIN, CONNECTOR 4P CN402 *1-564-512-11 PLUG, CONNECTOR 9P

D607 8-719-046-78 DIODE EG-1Z-V1

D608 8-719-302-43 DIODE EL1Z

D609 8-719-312-10 DIODE RU4AM-T3

D610 8-719-025-88 DIODE GBU4JL-6088 CN405 *1-766-955-11 CONNECTOR, BOARD TO BOARD 11P

D612 8-719-046-76 DIODE RU3YX-LF-C4 CN601 *1-580-844-11 PIN, CONNECTOR (POWER) CN603 1-508-765-00 PIN, CONNECTOR (5MM PITCH) 3P CN604 1-695-915-11 TAB (CONTACT) CN801 *1-580-798-11 CONNECTOR PIN (DY) 6P

D613 8-719-058-38 DIODE FMN-G12S

D614 8-719-109-97 DIODE RD6.8ES-B2

D615 8-719-302-43 DIODE EL1Z

D616 8-719-110-03 DIODE RD7.5ES-B2 CN1202 *1-568-882-51 PIN, CONNECTOR 7P

D617 8-719-991-33 DIODE 1SS133T

— 51 —

KV-20WS1

A

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARK

D619 8-719-046-78 DIODE EG-1Z-V1 D620 8-719-110-14 DIODE RD9.1ES-B3 D621 8-719-058-38 DIODE FMN-G12S D622 8-719-991-33 DIODE 1SS133T D623 8-719-924-16 DIODE MTZJ-T-77-24

D625 8-719-991-33 DIODE 1SS133T

REF.NO. PART NO. DESCRIPTION REMARK

IC605 8-759-510-52 IC L4941BV 4-202-373-01 SPRING, IC; IC605 IC1200 8-759-473-02 IC TDA7269 4-202-373-01 SPRING, IC; IC1200 4-202-710-11 SPACER, INSULATING; IC1200

< SOCKET > D626 8-719-302-43 DIODE EL1Z D627 8-719-991-33 DIODE 1SS133T

J401 1-695-551-11 SOCKET 21P D802 8-719-302-43 DIODE EL1Z D803 8-719-945-80 DIODE ERC06-15S

D805 8-719-928-08 DIODE ERD28-08S D806 8-719-302-43 DIODE EL1Z D807 8-719-991-33 DIODE 1SS133T D809 1-535-143-31 LEAD JUMPER (15MM) D1200 8-719-109-72 DIODE RD3.9ES-B2

< FUSE >

< COIL >

L001 1-414-181-11 INDUCTOR 4.7UH

L003 1-408-405-00 INDUCTOR 4.7UH

L108 1-414-740-21 INDUCTOR 4.7UH

L111 1-408-408-00 INDUCTOR 8.2UH

L112 1-408-397-00 INDUCTOR 1UH

L113 1-408-408-00 INDUCTOR 8.2UH

L200 1-408-406-00 INDUCTOR 5.6UH (KV-20WS1B) F601 1-576-231-11 FUSE (4A 250V) *1-533-725-11 HOLDER, FUSE; F601

L201 1-535-303-00 LEAD, JUMPER (5.0MM)

L203 1-410-385-11 INDUCTOR CHIP 22UH

L204 1-410-385-11 INDUCTOR CHIP 22UH < FERRITE BEAD >

L301 1-410-989-11 INDUCTOR CHIP 0.47UH FB001 1-412-911-11 INDUCTOR, FERRITE BEAD FB002 1-412-911-11 INDUCTOR, FERRITE BEAD FB003 1-412-911-11 INDUCTOR, FERRITE BEAD FB600 1-410-397-21 FERRITE BEAD INDUCTOR 1.1UH

L302 1-410-396-41 FERRITE BEAD INDUCTOR 0.45UH

L401 1-408-409-00 INDUCTOR 10UH

L402 1-408-409-00 INDUCTOR 10UH

L403 1-535-303-00 LEAD, JUMPER (5.0MM) FB601 1-410-397-21 FERRITE BEAD INDUCTOR 1.1UH

L404 1-535-303-00 LEAD, JUMPER (5.0MM) FB602 1-412-911-11 INDUCTOR, FERRITE BEAD FB604 1-535-303-00 LEAD, JUMPER (5.0MM) FB605 1-412-911-11 INDUCTOR, FERRITE BEAD FB606 1-412-911-11 INDUCTOR, FERRITE BEAD

L405 1-408-409-00 INDUCTOR 10UH

L406 1-408-409-00 INDUCTOR 10UH

L407 1-408-409-00 INDUCTOR 10UH

L408 1-408-409-00 INDUCTOR 10UH FB607 1-412-911-11 INDUCTOR, FERRITE BEAD

L409 1-410-985-11 INDUCTOR CHIP 0.22UH < ENCAPSULATED FILTER >

L410 1-408-409-00 INDUCTOR 10UH

L411 1-408-409-00 INDUCTOR 10UH FL201 1-239-803-11 FILTER, EMI

L412 1-410-985-11 INDUCTOR CHIP 0.22UH

L501 1-412-525-31 INDUCTOR 10UH < IC >

L609 1-414-743-21 INDUCTOR 47UH IC001 8-759-495-43 IC SDA5255-A031 (KV-20WS1A/20WS1B/20WS1D/ 20WS1E/20WS1K/20WS1U) 8-759-495-42 IC SDA5255-A032 (KV-20WS1R)

L611 1-414-743-21 INDUCTOR 47UH

L612 1-412-522-41 INDUCTOR 5.6UH

L613 1-412-522-41 INDUCTOR 5.6UH

L800 1-412-553-11 INDUCTOR 3.3MMH 8-759-486-29 IC SDA5255A026 (Greek Text)

L801 1-535-303-00 LEAD, JUMPER (5.0MM) IC002 8-759-437-34 IC ST24W04FB6 IC003 8-742-014-10 HYB IC SBX1981-51 IC004 8-759-073-00 IC TEA2114 IC005 8-759-510-54 IC PST572D

L802 1-411-635-11 COIL, AIR-CORE

L803 1-411-816-11 COIL, CHOKE 680UH

L804 1-459-075-00 COIL,DYNAMIC CONVERSION CHOKE

L805 1-535-303-00 LEAD, JUMPER (5.0MM) IC200 8-759-429-97 IC MSP3400C-PP-C6 (KV-20WS1A/20WS1D/20WS1K/20WS1R) 8-759-481-43 IC MSP3410D-PP-B3 (KV-20WS1B/20WS1E/20WS1U)

L806 0-552-675-00 HLC

L807 1-535-303-00 LEAD, JUMPER (5.0MM)

L808 1-406-974-41 COIL, CHOKE 33UH

L810 1-408-947-00 INDUCTOR 2.2MMH IC201 8-759-502-21 IC TDA2822M

L811 1-412-525-31 INDUCTOR 10UH IC301 8-759-333-45 IC MC44002P IC302 8-759-333-46 IC MC44140P

< IC LINK > IC401 8-759-064-91 IC NJM2233BL IC501 8-759-192-71 IC STV9379 4-202-373-01 SPRING, IC; IC501

PS600 1-532-686-21 LINK, IC 2.7A (ICP-N75)

PS601 1-532-686-21 LINK, IC 2.7A (ICP-N75)

PS603 1-532-686-21 LINK, IC 2.7A (ICP-N75) IC600 8-749-924-99 IC STR-S6707 4-202-373-01 SPRING, IC; IC600

< TRANSISTOR > IC601 8-749-010-64 PHOTO COUPLER PC123F2 IC602 8-749-012-79 IC SE117N IC603 8-759-507-29 IC LM7808CT

Q002 8-729-620-06 TRANSISTOR 2SC3052-EF

Q006 8-729-216-22 TRANSISTOR 2SA1162-G

Q007 8-729-620-06 TRANSISTOR 2SC3052-EF IC604 8-759-457-41 IC KA76L05Z

Q008 8-729-620-06 TRANSISTOR 2SC3052-EF

— 52 —

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK

KV-20WS1

A

Q009 8-729-620-06 TRANSISTOR 2SC3052-EF Q011 1-801-806-11 TRANSISTOR DTC144EKA

Q012 8-729-620-06 TRANSISTOR 2SC3052-EF Q013 8-729-620-06 TRANSISTOR 2SC3052-EF Q014 8-729-620-06 TRANSISTOR 2SC3052-EF Q107 8-729-119-78 TRANSISTOR 2SC2785-HFE

Q110 8-729-620-06 TRANSISTOR 2SC3052-EF Q118 8-729-620-06 TRANSISTOR 2SC3052-EF Q200 8-729-900-53 TRANSISTOR DTC114EKA Q201 8-729-027-56 TRANSISTOR DTC143TKA-T146 Q202 8-729-027-56 TRANSISTOR DTC143TKA-T146

Q204 8-729-620-06 TRANSISTOR 2SC3052-EF Q205 8-729-620-06 TRANSISTOR 2SC3052-EF Q207 8-729-620-06 TRANSISTOR 2SC3052-EF (KV-20WS1B) Q208 8-729-216-22 TRANSISTOR 2SA1162-G (KV-20WS1B) Q209 8-729-620-06 TRANSISTOR 2SC3052-EF (KV-20WS1B)

Q210 8-729-620-06 TRANSISTOR 2SC3052-EF Q300 8-729-620-06 TRANSISTOR 2SC3052-EF Q304 8-729-900-53 TRANSISTOR DTC114EK Q305 8-729-900-53 TRANSISTOR DTC114EK Q306 8-729-900-53 TRANSISTOR DTC114EK

Q309 8-729-216-22 TRANSISTOR 2SA1162-G Q310 8-729-620-06 TRANSISTOR 2SC3052-EF Q311 8-729-620-06 TRANSISTOR 2SC3052-EF Q312 8-729-620-06 TRANSISTOR 2SC3052-EF Q402 8-729-620-06 TRANSISTOR 2SC3052-EF

Q403 8-729-620-06 TRANSISTOR 2SC3052-EF Q404 8-729-620-06 TRANSISTOR 2SC3052-EF Q405 8-729-620-06 TRANSISTOR 2SC3052-EF Q406 8-729-620-06 TRANSISTOR 2SC3052-EF Q407 8-729-620-06 TRANSISTOR 2SC3052-EF

R005 1-216-174-00 METAL GLAZE 100 5% 1/8W R006 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W

R007 1-216-089-00 METAL GLAZE 47K 5% 1/10W R008 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R009 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R010 1-216-031-00 METAL GLAZE 180 5% 1/10W

R011 1-216-073-00 METAL GLAZE 10K 5% 1/10W R012 1-249-437-11 CARBON 47K 5% 1/4W R013 1-216-069-00 METAL GLAZE 6.8K 5% 1/10W R014 1-216-071-00 METAL GLAZE 8.2K 5% 1/10W R015 1-216-296-00 CONDUCTOR, CHIP

R016 1-216-069-00 METAL GLAZE 6.8K 5% 1/10W R017 1-216-095-00 METAL GLAZE 82K 5% 1/10W R018 1-216-025-00 METAL GLAZE 100 5% 1/10W R019 1-216-067-00 METAL GLAZE 5.6K 5% 1/10W R020 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W

R021 1-216-258-00 METAL GLAZE 330K 5% 1/8W R022 1-216-081-00 METAL GLAZE 22K 5% 1/10W R023 1-216-041-00 METAL GLAZE 470 5% 1/10W R025 1-216-091-00 METAL GLAZE 56K 5% 1/10W R026 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W

R027 1-216-081-00 METAL GLAZE 22K 5% 1/10W R029 1-216-039-00 METAL GLAZE 390 5% 1/10W R030 1-215-900-11 METAL OXIDE 22K 5% 2W F R031 1-216-025-00 METAL GLAZE 100 5% 1/10W R032 1-216-025-00 METAL GLAZE 100 5% 1/10W

R033 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R034 1-216-073-00 METAL GLAZE 10K 5% 1/10W R036 1-216-295-00 CONDUCTOR, CHIP R037 1-216-093-00 METAL GLAZE 68K 5% 1/10W R038 1-216-295-00 CONDUCTOR, CHIP

Q408 8-729-620-06 TRANSISTOR 2SC3052-EF Q409 8-729-620-06 TRANSISTOR 2SC3052-EF Q410 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R Q411 8-729-620-06 TRANSISTOR 2SC3052-EF Q500 8-729-017-06 TRANSISTOR 2SC4793

Q501 8-729-620-06 TRANSISTOR 2SC3052-EF Q601 8-729-025-04 TRANSISTOR 2SC3852A Q602 8-729-320-28 TRANSISTOR 2SA1667 Q603 8-729-027-08 TRANSISTOR 2SC2389STP-R Q604 8-729-024-35 TRANSISTOR 2SC2808STP-R

Q606 8-729-029-56 TRANSISTOR DTA144ESA Q608 8-729-027-56 TRANSISTOR DTC143TKA-T146 Q617 8-729-119-78 TRANSISTOR 2SC2785-HFE Q801 8-729-140-50 TRANSISTOR 2SC3209LK Q802 8-729-041-25 TRANSISTOR S2055N-16E305A

R040 1-216-073-00 METAL GLAZE 10K 5% 1/10W R041 1-216-206-00 METAL GLAZE 2.2K 5% 1/8W R042 1-216-027-00 METAL GLAZE 120 5% 1/10W R043 1-216-022-00 METAL GLAZE 75 5% 1/10W R044 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R045 1-216-081-00 METAL GLAZE 22K 5% 1/10W R046 1-216-254-00 METAL GLAZE 220K 5% 1/8W R047 1-216-077-91 METAL GLAZE 15K 5% 1/10W R049 1-216-041-00 METAL GLAZE 470 5% 1/10W R050 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R051 1-216-174-00 METAL GLAZE 100 5% 1/8W R052 1-216-073-00 METAL GLAZE 10K 5% 1/10W R053 1-216-045-00 METAL GLAZE 680 5% 1/10W R054 1-216-129-00 METAL GLAZE 2.2M 5% 1/10W R057 1-216-198-91 METAL GLAZE 1K 5% 1/8W

4-382-854-11 SCREW (M3X10), P, SW (+);Q802

R058 1-216-198-91 METAL GLAZE 1K 5% 1/8W Q803 1-801-806-11 TRANSISTOR DTC144EKA Q804 8-729-019-01 TRANSISTOR 2SD2394-EF *4-368-683-11 SPRING, TRANSISTOR; Q804 Q805 8-729-255-12 TRANSISTOR 2SC2551-0

R060 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W

R061 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R062 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R063 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W Q810 8-729-027-38 TRANSISTOR DTA144EKA-T146

R064 1-216-222-00 METAL GLAZE 10K 5% 1/8W Q811 1-801-806-11 TRANSISTOR DTC144EKA Q1200 8-729-620-06 TRANSISTOR 2SC3052-EF Q1201 8-729-620-06 TRANSISTOR 2SC3052-EF

R065 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R066 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R067 1-216-081-00 METAL GLAZE 22K 5% 1/10W

R068 1-216-073-00 METAL GLAZE 10K 5% 1/10W < RESISTOR >

R069 1-216-081-00 METAL GLAZE 22K 5% 1/10W R001 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R002 1-216-025-00 METAL GLAZE 100 5% 1/10W R003 1-216-025-00 METAL GLAZE 100 5% 1/10W R004 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W

R070 1-216-049-00 METAL GLAZE 1K 5% 1/10W

R071 1-216-174-00 METAL GLAZE 100 5% 1/8W

R072 1-216-174-00 METAL GLAZE 100 5% 1/8W

R073 1-216-025-00 METAL GLAZE 100 5% 1/10W

— 53 —

KV-20WS1

A

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARK

R074 1-216-025-00 METAL GLAZE 100 5% 1/10W R078 1-216-071-00 METAL GLAZE 8.2K 5% 1/10W

REF.NO. PART NO. DESCRIPTION REMARK

R231 1-216-035-00 METAL GLAZE 270 5% 1/10W

(KV-20WS1B) R088 1-216-043-91 METAL GLAZE 560 5% 1/10W R089 1-216-043-91 METAL GLAZE 560 5% 1/10W R090 1-216-043-91 METAL GLAZE 560 5% 1/10W

R236 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R237 1-216-093-00 METAL GLAZE 68K 5% 1/10W

R238 1-216-089-00 METAL GLAZE 47K 5% 1/10W R097 1-216-051-00 METAL GLAZE 1.2K 5% 1/10W R098 1-216-051-00 METAL GLAZE 1.2K 5% 1/10W

R239 1-216-093-00 METAL GLAZE 68K 5% 1/10W

R240 1-216-073-00 METAL GLAZE 10K 5% 1/10W R099 1-216-200-11 METAL GLAZE 1.2K 5% 1/8W R110 1-216-174-00 METAL GLAZE 100 5% 1/8W R111 1-216-174-00 METAL GLAZE 100 5% 1/8W

R301 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R302 1-216-037-00 METAL GLAZE 330 5% 1/10W

R303 1-216-090-00 METAL GLAZE 51K 5% 1/10W R112 1-216-073-00 METAL GLAZE 10K 5% 1/10W R113 1-216-113-00 METAL GLAZE 470K 5% 1/10W

R304 1-216-025-00 METAL GLAZE 100 5% 1/10W

R305 1-216-025-00 METAL GLAZE 100 5% 1/10W R114 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R115 1-216-190-00 METAL GLAZE 470 5% 1/8W R116 1-216-049-00 METAL GLAZE 1K 5% 1/10W

R306 1-216-113-00 METAL GLAZE 470K 5% 1/10W

R307 1-216-121-91 METAL GLAZE 1M 5% 1/10W

R308 1-216-085-00 METAL GLAZE 33K 5% 1/10W R117 1-216-222-00 METAL GLAZE 10K 5% 1/8W R118 1-216-069-00 METAL GLAZE 6.8K 5% 1/10W

R309 1-216-121-91 METAL GLAZE 1M 5% 1/10W

R310 1-216-089-00 METAL GLAZE 47K 5% 1/10W R119 1-216-031-00 METAL GLAZE 180 5% 1/10W R120 1-216-041-00 METAL GLAZE 470 5% 1/10W R124 1-216-025-00 METAL GLAZE 100 5% 1/10W

R311 1-216-025-00 METAL GLAZE 100 5% 1/10W

R312 1-216-097-00 METAL GLAZE 100K 5% 1/10W

R313 1-216-045-00 METAL GLAZE 680 5% 1/10W R125 1-216-025-00 METAL GLAZE 100 5% 1/10W R126 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W

R314 1-216-045-00 METAL GLAZE 680 5% 1/10W

R315 1-216-045-00 METAL GLAZE 680 5% 1/10W R134 1-216-037-00 METAL GLAZE 330 5% 1/10W R163 1-216-029-00 METAL GLAZE 150 5% 1/10W R174 1-216-033-00 METAL GLAZE 220 5% 1/10W

R316 1-216-033-00 METAL GLAZE 220 5% 1/10W

R317 1-216-033-00 METAL GLAZE 220 5% 1/10W

R318 1-216-021-00 METAL GLAZE 68 5% 1/10W R200 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W R202 1-216-097-00 METAL GLAZE 100K 5% 1/10W

R322 1-216-022-00 METAL GLAZE 75 5% 1/10W

R323 1-216-089-00 METAL GLAZE 47K 5% 1/10W R203 1-216-077-00 METAL GLAZE 15K 5% 1/10W R204 1-216-077-00 METAL GLAZE 15K 5% 1/10W R205 1-216-295-00 CONDUCTOR, CHIP

R324 1-216-133-00 METAL GLAZE 3.3M 5% 1/10W

R325 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R326 1-216-041-00 METAL GLAZE 470 5% 1/10W R206 1-249-399-11 CARBON 33 5% 1/4W R208 1-216-049-00 METAL GLAZE 1K 5% 1/10W

R327 1-216-097-00 METAL GLAZE 100K 5% 1/10W

R328 1-216-073-00 METAL GLAZE 10K 5% 1/10W R209 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R210 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R211 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R329 1-216-075-00 METAL GLAZE 12K 5% 1/10W

R330 1-216-295-00 CONDUCTOR, CHIP

R331 1-216-222-00 METAL GLAZE 10K 5% 1/8W R213 1-216-174-00 METAL GLAZE 100 5% 1/8W R214 1-216-174-00 METAL GLAZE 100 5% 1/8W

R333 1-216-037-00 METAL GLAZE 330 5% 1/10W

R334 1-216-033-00 METAL GLAZE 220 5% 1/10W R215 1-216-073-00 METAL GLAZE 10K 5% 1/10W R218 1-216-037-00 METAL GLAZE 330 5% 1/10W (KV-20WS1B)

R335 1-216-025-00 METAL GLAZE 100 5% 1/10W

R336 1-216-025-00 METAL GLAZE 100 5% 1/10W

R337 1-216-025-00 METAL GLAZE 100 5% 1/10W R219 1-216-049-00 METAL GLAZE 1K 5% 1/10W (KV-20WS1B)

R338 1-216-071-00 METAL GLAZE 8.2K 5% 1/10W

R339 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W R220 1-216-045-00 METAL GLAZE 680 5% 1/10W (KV-20WS1B) R221 1-216-033-00 METAL GLAZE 220 5% 1/10W (KV-20WS1B)

R340 1-216-246-00 METAL GLAZE 100K 5% 1/8W

R341 1-216-069-00 METAL GLAZE 6.8K 5% 1/10W

R342 1-216-186-00 METAL GLAZE 330 5% 1/8W

R343 1-216-295-00 CONDUCTOR, CHIP R222 1-216-001-00 METAL GLAZE 10 5% 1/10W

R344 1-216-295-00 CONDUCTOR, CHIP (KV-20WS1B) R223 1-216-041-00 METAL GLAZE 470 5% 1/10W (KV-20WS1B) R224 1-216-025-00 METAL GLAZE 100 5% 1/10W (KV-20WS1B)

R345 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R351 1-218-463-11 METAL GLAZE 8.2M 5% 1/10W

R354 1-216-033-00 METAL GLAZE 220 5% 1/10W

R355 1-216-689-11 METAL GLAZE 39K 5% 1/10W

R359 1-216-101-00 METAL GLAZE 150K 5% 1/10W R225 1-216-037-00 METAL GLAZE 330 5% 1/10W R226 1-216-081-00 METAL GLAZE 22K 5% 1/10W R227 1-216-081-00 METAL GLAZE 22K 5% 1/10W R228 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W (KV-20WS1B)

R360 1-216-049-00 METAL GLAZE 1K 5% 1/10W

R361 1-216-022-00 METAL GLAZE 75 5% 1/10W

R362 1-216-022-00 METAL GLAZE 75 5% 1/10W

R363 1-216-022-00 METAL GLAZE 75 5% 1/10W

R364 1-216-081-00 METAL GLAZE 22K 5% 1/10W R229 1-216-073-00 METAL GLAZE 10K 5% 1/10W (KV-20WS1B) R230 1-216-025-00 METAL GLAZE 100 5% 1/10W (KV-20WS1B)

R365 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R366 1-216-041-00 METAL GLAZE 470 5% 1/10W

R367 1-216-081-00 METAL GLAZE 22K 5% 1/10W

— 54 —

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK

KV-20WS1

A

R368 1-216-089-00 METAL GLAZE 47K 5% 1/10W R369 1-216-238-91 METAL GLAZE 47K 5% 1/8W

R371 1-216-192-00 METAL GLAZE 560 5% 1/8W R372 1-216-043-91 METAL GLAZE 560 5% 1/10W R401 1-216-041-00 METAL GLAZE 470 5% 1/10W R402 1-247-807-31 CARBON 100 5% 1/4W R403 1-247-807-31 CARBON 100 5% 1/4W

R404 1-216-022-00 METAL GLAZE 75 5% 1/10W R405 1-216-113-00 METAL GLAZE 470K 5% 1/10W R406 1-216-091-00 METAL GLAZE 56K 5% 1/10W R407 1-216-691-11 METAL CHIP 47K 0.50% 1/10W R408 1-216-691-11 METAL CHIP 47K 0.50% 1/10W

R409 1-216-691-11 METAL CHIP 47K 0.50% 1/10W R410 1-216-022-00 METAL GLAZE 75 5% 1/10W R411 1-216-091-00 METAL GLAZE 56K 5% 1/10W R412 1-216-041-00 METAL GLAZE 470 5% 1/10W R413 1-216-113-00 METAL GLAZE 470K 5% 1/10W

R414 1-260-311-11 CARBON 39 5% 1/2W R415 1-260-311-11 CARBON 39 5% 1/2W R416 1-216-022-00 METAL GLAZE 75 5% 1/10W R417 1-216-174-00 METAL GLAZE 100 5% 1/8W R418 1-216-113-00 METAL GLAZE 470K 5% 1/10W

R419 1-216-113-00 METAL GLAZE 470K 5% 1/10W R420 1-247-807-31 CARBON 100 5% 1/4W R421 1-247-807-31 CARBON 100 5% 1/4W R422 1-216-691-11 METAL CHIP 47K 0.50% 1/10W R423 1-216-691-11 METAL CHIP 47K 0.50% 1/10W

R604 1-215-902-11 METAL OXIDE 47K 5% 2W F R605 1-216-363-00 METAL OXIDE 0.33 5% 2W F

R606 1-535-143-11 LEAD, JUMPER (10.0MM) R607 1-215-860-11 METAL OXIDE 33 5% 1W F R608 1-216-365-00 METAL OXIDE 0.47 5% 2W F R609 1-249-420-11 CARBON 1.8K 5% 1/4W R610 1-249-417-11 CARBON 1K 5% 1/4W

R611 1-216-354-11 METAL OXIDE 2.7 5% 1W F R612 1-260-135-11 CARBON 1M 5% 1/2W R613 1-249-417-11 CARBON 1K 5% 1/4W R614 1-218-265-11 METAL 8.2M 5% 1W R615 1-216-073-00 METAL GLAZE 10K 5% 1/10W

R616 1-215-479-00 METAL 270K 1% 1/4W R617 1-215-877-11 METAL OXIDE 22K 5% 1W F R618 1-247-863-91 CARBON 22K 5% 1/4W R619 1-249-424-11 CARBON 3.9K 5% 1/4W R620 1-247-895-91 CARBON 470K 5% 1/4W

R621 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W R622 1-249-437-11 CARBON 47K 5% 1/4W R623 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W R625 1-249-417-11 CARBON 1K 5% 1/4W R626 1-535-303-00 LEAD, JUMPER (5.0MM)

R628 1-216-049-00 METAL GLAZE 1K 5% 1/10W R629 1-216-357-00 METAL OXIDE 4.7 5% 1W F R630 1-216-365-00 METAL OXIDE 0.47 5% 2W F R631 1-216-389-11 METAL OXIDE 1 5% 3W F R632 1-247-807-31 CARBON 100 5% 1/4W

R424 1-216-691-11 METAL CHIP 47K 0.50% 1/10W R425 1-216-651-11 METAL CHIP 1K 0.50% 1/10W R426 1-216-651-11 METAL CHIP 1K 0.50% 1/10W R427 1-216-651-11 METAL CHIP 1K 0.50% 1/10W R428 1-216-053-00 METAL GLAZE 1.5K 5% 1/10W

R429 1-216-188-00 METAL GLAZE 390 5% 1/8W R430 1-216-001-00 METAL GLAZE 10 5% 1/10W R431 1-216-041-00 METAL GLAZE 470 5% 1/10W R432 1-216-049-00 METAL GLAZE 1K 5% 1/10W R433 1-216-051-00 METAL GLAZE 1.2K 5% 1/10W

R434 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W R435 1-216-049-00 METAL GLAZE 1K 5% 1/10W R436 1-216-001-00 METAL GLAZE 10 5% 1/10W R437 1-216-017-00 METAL GLAZE 47 5% 1/10W R501 1-216-079-00 METAL GLAZE 18K 5% 1/10W

R502 1-216-675-11 METAL CHIP 10K 0.50% 1/10W R503 1-216-212-00 METAL GLAZE 3.9K 5% 1/8W R504 1-216-077-00 METAL GLAZE 15K 5% 1/10W R505 1-216-079-00 METAL GLAZE 18K 5% 1/10W R506 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W

R507 1-216-350-11 METAL OXIDE 1.2 5% 1W F R508 1-215-865-11 METAL OXIDE 220 5% 1W F R509 1-249-383-11 CARBON 1.5 5% 1/4W F R510 1-216-093-00 METAL GLAZE 68K 5% 1/10W R513 1-249-431-11 CARBON 15K 5% 1/4W

R514 1-216-113-00 METAL GLAZE 470K 5% 1/10W R515 1-216-093-00 METAL GLAZE 68K 5% 1/10W R516 1-216-047-91 METAL GLAZE 820 5% 1/10W R517 1-215-912-11 METAL OXIDE 150 5% 3W F R518 1-215-868-00 METAL OXIDE 680 5% 1W F

R634 1-249-397-11 CARBON 22 5% 1/4W F R635 1-249-437-11 CARBON 47K 5% 1/4W R636 1-249-417-11 CARBON 1K 5% 1/4W R637 1-247-815-91 CARBON 220 5% 1/4W R638 1-247-863-91 CARBON 22K 5% 1/4W

R639 1-249-429-11 CARBON 10K 5% 1/4W R645 1-249-422-11 CARBON 2.7K 5% 1/4W R646 1-249-382-11 CARBON 1.2 5% 1/4W F R647 1-202-933-61 FUSIBLE 0.1 10% 1/2W F R648 1-249-407-11 CARBON 150 5% 1/4W

R651 1-215-902-11 METAL OXIDE 47K 5% 2W F R800 1-215-886-11 METAL OXIDE 100 5% 2W F R801 1-216-049-00 METAL GLAZE 1K 5% 1/10W R802 1-216-174-00 METAL GLAZE 100 5% 1/8W R803 1-216-081-00 METAL GLAZE 22K 5% 1/10W

R804 1-217-778-11 FUSIBLE 1K 5% 1W F R806 1-216-347-11 METAL OXIDE 0.68 5% 1W F R807 1-249-399-11 CARBON 33 5% 1/4W R808 1-202-823-11 SOLID 2.7K 10% 1/2W R810 1-247-895-91 CARBON 470K 5% 1/4W

R813 1-216-295-00 CONDUCTOR, CHIP R814 1-217-811-11 FUSIBLE 0.47 5% 1/4W R815 1-216-105-91 METAL GLAZE 220K 5% 1/10W R816 1-216-366-00 METAL OXIDE 0.56 5% 2W F R819 1-249-441-11 CARBON 100K 5% 1/4W

R820 1-249-923-11 CARBON 1K 5% 1/4W F R821 1-216-115-00 METAL GLAZE 560K 5% 1/10W R823 1-249-413-11 CARBON 470 5% 1/4W R826 1-216-296-00 CONDUCTOR, CHIP R828 1-216-103-00 METAL GLAZE 180K 5% 1/10W

R601 1-202-962-11 WIREWOUND 3.3 5% 10W R602 1-249-417-11 CARBON 1K 5% 1/4W R603 1-215-875-11 METAL OXIDE 10K 5% 1W F

R829 1-535-143-71 LEAD, JUMPER (7.5MM) R831 1-216-113-00 METAL GLAZE 470K 5% 1/10W R832 1-216-079-00 METAL GLAZE 18K 5% 1/10W

— 55 —

KV-20WS1

A

C

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARK

R834 1-249-441-11 CARBON 100K 5% 1/4W R841 1-212-849-00 FUSIBLE 4.7 5% 1/4W F

R844 1-260-115-11 CARBON 22K 5% 1/2W R863 1-216-085-00 METAL GLAZE 33K 5% 1/10W R864 1-216-452-11 METAL OXIDE 180 5% 2W F R1200 1-216-206-00 METAL GLAZE 2.2K 5% 1/8W R1201 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W

R1202 1-216-081-00 METAL GLAZE 22K 5% 1/10W R1203 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W R1204 1-216-222-00 METAL GLAZE 10K 5% 1/8W R1205 1-216-222-00 METAL GLAZE 10K 5% 1/8W R1206 1-216-079-00 METAL GLAZE 18K 5% 1/10W

R1207 1-216-043-91 METAL GLAZE 560 5% 1/10W R1208 1-212-849-00 FUSIBLE 4.7 5% 1/4W F R1209 1-212-849-00 FUSIBLE 4.7 5% 1/4W F R1211 1-249-424-11 CARBON 3.9K 5% 1/4W R1212 1-249-424-11 CARBON 3.9K 5% 1/4W

R1213 1-216-079-00 METAL GLAZE 18K 5% 1/10W R1214 1-216-192-00 METAL GLAZE 560 5% 1/8W

< RELAY > RY600 1-755-018-11 RELAY < SWITCH > S001 1-571-532-21 SWITCH, TACTIL

S002 1-571-532-21 SWITCH, TACTIL S003 1-571-532-21 SWITCH, TACTIL S004 1-571-532-21 SWITCH, TACTIL S005 1-571-532-21 SWITCH, TACTIL

S006 1-571-532-21 SWITCH, TACTIL S601 1-571-433-21 SWITCH, PUSH (AC POWER)

REF.NO. PART NO. DESCRIPTION REMARK

*A-1638-109-A C BOARD, COMPLETE *****************

< CAPACITOR > C700 1-136-189-00 FILM 0.1MF 10% 250V

C701 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C702 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C703 1-163-131-00 CERAMIC CHIP 390PF 5% 50V C704 1-163-005-11 CERAMIC CHIP 470PF 10% 50V

C705 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C706 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C709 1-162-114-00 CERAMIC 0.0047MF 2KV C710 1-104-664-11 ELECT 47MF 20% 16V C711 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V

C712 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V C713 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V C714 1-162-318-11 CERAMIC 0.001MF 10% 500V C715 1-162-114-00 CERAMIC 0.0047MF 2KV

< CONNECTOR > CN071 *1-568-881-51 PIN, CONNECTOR 6P

CN072 *1-568-880-51 PIN, CONNECTOR 5P CN073 1-695-915-11 TAB (CONTACT) CN074 1-695-915-11 TAB (CONTACT)

< DIODE > D704 8-719-991-33 DIODE 1SS133T-77

D705 8-719-991-33 DIODE 1SS133T-77 D706 8-719-991-33 DIODE 1SS133T-77 D707 8-719-991-33 DIODE 1SS133T-77 D708 8-719-991-33 DIODE 1SS133T-77

D709 8-719-991-33 DIODE 1SS133T-77 < TRANSFORMER > T601 1-427-962-21 TRANSFORMER, LINE FILTER

T602 1-431-594-11 TRANSFORMER, CONVERTER T801 1-437-090-31 HDT T802 1-453-254-11 TRANSFORMER ASSY, FLYBACK (NX-4004/M3A4)

< THERMISTOR > THP601 1-809-827-11 THERMISTOR, POSITIVE < TUNER > TU101 1-693-338-11 TUNER/VIF (AEP)

(KV-20WS1A/20WS1D/20WS1E /20WS1K/20WS1R) 1-693-340-11 TUNER/VIF (FR) (KV-20WS1B) 1-693-339-11 TUNER/VIF (UK) (KV-20WS1U)

< CRYSTAL > X201 1-760-628-11 VIBRATOR, CRYSTAL

X301 1-760-907-21 VIBRATOR, CRYSTAL X302 1-760-710-21 VIBRATOR, CRYSTAL

**************************************************************

< CRT SOCKET >

J701 1-251-311-11 SOCKET, CRT

< COIL >

L703 1-408-617-21 INDUCTOR 150UH

L704 1-408-617-21 INDUCTOR 150UH

< TRANSISTOR >

Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE

Q702 8-729-119-78 TRANSISTOR 2SC2785-HFE

Q703 8-729-119-78 TRANSISTOR 2SC2785-HFE

Q704 8-729-906-70 TRANSISTOR BF871-127

Q705 8-729-906-70 TRANSISTOR BF871-127

Q706 8-729-906-70 TRANSISTOR BF871-127

Q707 8-729-200-17 TRANSISTOR 2SA1091-0

Q708 8-729-200-17 TRANSISTOR 2SA1091-0

Q709 8-729-200-17 TRANSISTOR 2SA1091-0

< RESISTOR >

R700 1-260-076-11 CARBON 10 5% 1/2W

R701 1-216-206-91 METAL GLAZE 2.2K 5% 1/8W

R702 1-216-206-91 METAL GLAZE 2.2K 5% 1/8W

R705 1-216-009-91 METAL GLAZE 22 5% 1/10W

R706 1-216-164-91 METAL GLAZE 39 5% 1/8W

R707 1-216-295-71 CONDUCTOR CHIP

R708 1-216-033-00 METAL GLAZE 220 5% 1/10W

R709 1-216-182-00 METAL GLAZE 220 5% 1/8W

— 56 —

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK

C

KV-20WS1

H

U

R710 1-216-033-00 METAL GLAZE 220 5% 1/10W R711 1-216-057-71 METAL GLAZE 2.2K 5% 1/10W

R714 1-216-049-00 METAL GLAZE 1K 5% 1/10W R715 1-249-417-11 CARBON 1K 5% 1/4W R716 1-216-198-91 METAL GLAZE 1K 5% 1/8W R717 1-202-824-00 SOLID 3.3K 10% 1/2W R718 1-202-824-00 SOLID 3.3K 10% 1/2W

R719 1-202-824-00 SOLID 3.3K 10% 1/2W R720 1-215-923-00 METAL OXIDE 10K 5% 3W F R721 1-215-923-00 METAL OXIDE 10K 5% 3W F R722 1-215-923-00 METAL OXIDE 10K 5% 3W F R727 1-202-824-00 SOLID 3.3K 10% 1/2W

R729 1-216-368-11 METAL OXIDE 0.82 5% 2W F R732 1-202-846-00 SOLID 470K 10% 1/2W R734 1-216-206-00 METAL GLAZE 2.2K 5% 1/8W R735 1-216-206-00 METAL GLAZE 2.2K 5% 1/8W R736 1-249-421-11 CARBON 2.2K 5% 1/4W

R740 1-216-194-00 METAL GLAZE 680 5% 1/8W R741 1-216-045-00 METAL GLAZE 680 5% 1/10W R742 1-216-049-00 METAL GLAZE 1K 5% 1/10W

**************************************************************** *A-1646-142-A H BOARD, COMPLETE

***************** < CAPACITOR > C900 1-102-114-00 CERAMIC 470PF 10% 50V

C901 1-102-114-00 CERAMIC 470PF 10% 50V C906 1-535-303-00 LEAD, JUMPER (5.0MM) C907 1-535-303-00 LEAD, JUMPER (5.0MM) C910 1-130-489-00 FILM 0.033MF 5% 50V

C911 1-130-489-00 FILM 0.033MF 5% 50V < CONNECTOR > CN906 *1-564-512-11 PLUG, CONNECTOR 9P < SOCKET > J900 1-691-293-11 JACK

J902 1-764-073-11 TERMINAL BLOCK, S 4P

*A-1648-010-A U BOARD, COMPLETE *****************

< CAPACITOR > C1500 1-130-776-00 FILM 0.47MF 5% 63V

C1501 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C1502 1-137-133-11 FILM 0.15MF 5% 63V C1503 1-107-714-11 ELECT 10MF 20% 16V C1504 1-104-665-11 ELECT 100MF 20% 25V

C1506 1-107-698-11 ELECT 10MF 20% 25V C1507 1-164-346-11 CERAMIC CHIP 1MF 16V C1508 1-126-967-11 ELECT 47MF 20% 16V C1509 1-130-471-00 FILM 0.001MF 5% 50V C1510 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V

C1511 1-130-014-00 FILM 470PF 5% 50V C1512 1-163-038-00 CERAMIC CHIP 0.1MF 25V C1513 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V C1515 1-163-035-00 CERAMIC CHIP 0.047MF 50V C1516 1-163-243-11 CERAMIC CHIP 47PF 5% 50V

C1517 1-107-725-11 CERAMIC CHIP 0.1MF 10% 16V C1518 1-163-133-00 CERAMIC CHIP 470PF 5% 50V

< CONNECTOR > CN1500 *1-766-952-11 CONNECTOR, BOARD TO BOARD 11P < IC > IC1500 8-759-045-38 IC MC14538BCP

IC1501 8-759-045-38 IC MC14538BCP < COIL > L1500 1-410-200-31 INDUCTOR CHIP 4.7UH < TRANSISTOR > Q1500 8-729-620-06 TRANSISTOR 2SC3052-EF

Q1501 8-729-620-06 TRANSISTOR 2SC3052-EF Q1502 8-729-620-06 TRANSISTOR 2SC3052-EF Q1503 8-729-029-66 TRANSISTOR DTC114ESA Q1504 8-729-900-53 TRANSISTOR DTC114EK

Q1505 8-729-900-53 TRANSISTOR DTC114EK < COIL > L900 1-408-409-00 INDUCTOR 10UH

L901 1-408-409-00 INDUCTOR 10UH L902 1-408-409-00 INDUCTOR 10UH L903 1-408-409-00 INDUCTOR 10UH L904 1-535-143-61 LEAD JUMPER (5.0MM)

< RESISTOR > R904 1-535-303-00 LEAD, JUMPER (5.0MM)

R905 1-535-303-00 LEAD, JUMPER (5.0MM) R909 1-249-437-11 CARBON 47K 5% 1/4W R910 1-249-437-11 CARBON 47K 5% 1/4W

****************************************************************

< RESISTOR >

R1500 1-249-416-11 CARBON 820 5% 1/4W

R1501 1-249-419-11 CARBON 1.5K 5% 1/4W

R1502 1-216-049-00 METAL GLAZE 1K 5% 1/10W

R1503 1-216-093-00 METAL GLAZE 68K 5% 1/10W

R1504 1-216-091-00 METAL GLAZE 56K 5% 1/10W

R1505 1-216-077-00 METAL GLAZE 15K 5% 1/10W

R1506 1-216-091-00 METAL GLAZE 56K 5% 1/10W

R1507 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R1508 1-216-081-00 METAL GLAZE 22K 5% 1/10W

R1509 1-216-109-00 METAL GLAZE 330K 5% 1/10W

R1510 1-216-089-00 METAL GLAZE 47K 5% 1/10W

R1511 1-216-081-00 METAL GLAZE 22K 5% 1/10W

R1512 1-216-049-00 METAL GLAZE 1K 5% 1/10W

R1513 1-216-083-00 METAL GLAZE 27K 5% 1/10W

R1514 1-216-067-00 METAL GLAZE 5.6K 5% 1/10W

R1515 1-216-069-00 METAL GLAZE 6.8K 5% 1/10W

R1516 1-216-049-00 METAL GLAZE 1K 5% 1/10W

— 57 —

KV-20WS1

U

K

The components identified by shading and marked are critical for safety. Replace only with the part number specified.

Les composants identifies par une trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

REF.NO. PART NO. DESCRIPTION REMARK

R1517 1-216-079-00 METAL GLAZE 18K 5% 1/10W R1518 1-216-071-00 METAL GLAZE 8.2K 5% 1/10W R1519 1-216-057-00 METAL GLAZE 2.2K 5% 1/10W

R1520 1-216-073-00 METAL GLAZE 10K 5% 1/10W R1521 1-216-117-00 METAL GLAZE 680K 5% 1/10W R1523 1-216-256-00 METAL GLAZE 270K 5% 1/8W

< VARIABLE RESISTOR > RV1500 1-241-786-11 RES, ADJ, CARBON 22K **************************************************************** *A-1649-021-A K BOARD, COMPLETE

***************** 7-682-548-04 SCREW +P 3X8 < CAPACITOR > C280 1-126-163-11 ELECT 4.7MF 20% 50V

C281 1-126-163-11 ELECT 4.7MF 20% 50V C282 1-130-785-11 MYLAR 0.47MF 10% 100V C283 1-126-163-11 ELECT 4.7MF 20% 50V C284 1-126-942-61 ELECT 1000MF 20% 25V

C285 1-126-942-61 ELECT 1000MF 20% 25V C286 1-136-153-00 FILM 0.01MF 5% 50V C287 1-136-173-00 FILM 0.47MF 5% 50V C288 1-102-074-00 CERAMIC 0.001MF 10% 50V C289 1-102-074-00 CERAMIC 0.001MF 10% 50V

< CONNECTOR >

REF.NO. PART NO. DESCRIPTION REMARK

MISCELLANEOUS *************

1-416-425-11 COIL, DEGAUSSING 1-452-032-00 MAGNET, DISC; 10MM Ø 1-452-094-00 MAGNET, ROTATABLE DISK; 15MM Ø 1-452-787-11 NECK ASSY (NA222) 1-453-254-11 TRANSFORMER ASSY, FLYBACK (NX-4004/M3A4)

1-505-800-11 SPEAKER (5X9CM) 1-540-007-12 CAP ASSY, HIGH-VOLTAGE 1-571-433-21 SWITCH, PUSH (AC POWER) 1-765-286-11 CORD, POWER 2.5A/250V (KV-20WS1A/20WS1B/20WS1D/ 20WS1E/20WS1K/20WS1R) 1-776-860-11 POWER CORD, FILTER 2.5A/250V (KV-20WS1U)

1-693-338-11 TUNER (TUVIF) (AEP) (KV-20WS1A/20WS1D/20WS1E 20WS1K/20WS1R) 1-693-340-11 TUNER (TUVIF) (FR) (KV-20WS1B) 1-693-339-11 TUNER (TUVIF) (UK) (KV-20WS1U) 8-737-804-05 PICTURE TUBE (SD-281) (W46LEZ070X)

8-451-457-11 DEFLECTION YOKE (Y20G1AK) 1-505-426-11 SPEAKER (10.6CM) 1-782-757-11 CABLE, SPEAKER (WITH GROMMET)

**************************************************************** ACCESSORIES AND PACKING MATERIALS

*********************************

CN223 *1-568-878-51 PIN, CONNECTOR 3P CN225 *1-568-882-51 PIN, CONNECTOR 7P

< DIODE > D201 8-719-110-14 DIODE RD9.1ES-B3

D202 8-719-109-97 DIODE RD6.8ES-B2 < IC > IC271 8-759-988-94 IC TDA2050 < TRANSISTOR > Q205 8-729-119-78 TRANSISTOR 2SC2785-HFE < RESISTOR > R216 1-249-441-11 CARBON 100K 5% 1/4W

R217 1-247-885-00 CARBON 180K 5% 1/4W R280 1-249-429-11 CARBON 10K 5% 1/4W R281 1-249-429-11 CARBON 10K 5% 1/4W R282 1-249-436-11 CARBON 39K 5% 1/4W

R283 1-249-435-11 CARBON 33K 5% 1/4W R284 1-249-435-11 CARBON 33K 5% 1/4W R285 1-249-417-11 CARBON 1K 5% 1/4W R288 1-216-353-00 METAL OXIDE 2.2 5% 1W F R289 1-249-429-11 CARBON 10K 5% 1/4W

R290 1-247-897-11 CARBON 560K 5% 1/4W R291 1-249-425-11 CARBON 4.7K 5% 1/4W

*4-039-905-02 BAG, PROTECTION *4-203-715-01 INDIVIDUAL CARTON *4-203-716-01 CUSHION (UPPER) (ASSY) *4-203-719-01 CUSHION (LOWER) (ASSY) 4-203-822-41 MANUAL, INSTRUCTION (KV-20WS1A) (ITALIAN)

4-203-822-51 MANUAL, INSTRUCTION (KV-20WS1B) (FRENCH/GERMAN/ITALIAN/DUTCH) 4-203-822-11 MANUAL, INSTRUCTION (KV-20WS1D) (GERMAN/GREEK/DUTCH/ENGLISH/TURKISH) 4-203-579-71 MANUAL, INSTRUCTION (KV-20WS1E) (SPANISH/PORTUGUESE/DANISH/SWEDISH/ FINNISH/NORWEGIAN/HUNGARIAN)

4-203-579-61 MANUAL, INSTRUCTION (KV-20WS1U) (ENGLISH) 4-203-822-91 MANUAL, INSTRUCTION (KV-20WS1K/20WS1R) (CZECH/ENGLISH/POLISH/ RUSSIAN/BULGARIAN)

REMOTE COMMANDER ****************

1-473-194-11 COMMANDER, STANDARD TYPE (RM-836) ****************************************************************

**************************************************************

— 58 —

Sony kv20ws1 schematic [en, fr]
