Projection TV

Operating Instructions

• Before operating the unit, please read this manual thoroughly and retain it for future reference.

KP-FW51 KP-FW46

M31

2

WARNING

To prevent fire or shock hazard, do not expose the projection TV to rain or moisture. Dangerously high voltages are present inside the projection TV. Do not open the cabinet. Refer servicing to qualified personnel only.

For general safety:

• Do not expose the projection TV to rain or moisture.

• Do not open the rear cover.

For safe installation:

• Do not block the ventilation openings.

• Do not install the projection TV in hot, humid or excessively dusty places.

• Do not install the projection TV where it may be exposed to mechanical vibrations.

•Avoid operating the projection TV at temperatures below 5°C (41°F).

• If the projection TV is transported directly from a cold to a warm location, or if the room temperature has changed suddenly, the picture may be blurred or show poor color. This is because moisture has condensed on the mirror or lenses inside. If this happens, let the moisture evaporate before using the projection TV.

•To obtain the best picture, do not expose the screen to direct illumination or direct sunlight. It is recommended to use spot lighting directed down from the ceiling or to cover the windows that face the screen with opaque drapery. It is desirable to install the projection TV in a room where the floor and walls are not of reflecting material. If necessary, cover them with dark carpeting or wall paper.

• Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.

For safe operations:

• Do not operate the projection TV on anything but 220-240 V AC, 50/60 Hz.

• Do not operate the projection TV if any liquid or solid object falls in it—have it checked immediately.

• Do not keep the projection TV plugged in if you are not going to use it for several days. Even if your projection TV is turned off, it is still connected to the AC power source (mains) as long as the power cord is plugged in.

• Do not pull the power cord to disconnect the projection TV. Pull it out by the plug.

• Do not plug in too many appliances to the same power socket. Do not damage the power cord.

• Do not place any objects on the projection TV. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

• Install the projection TV on a stable projection TV stand and floor which can support the projection TV set weight. Ensure that the projection TV stand surface is flat and its area is larger than the bottom area of the projection TV.

• Do not carry the projection TV holding the screen edges.

Caution

• When using TV games, computers, and similar products with your projection TV, keep the brightness and contrast functions at low settings. If a fixed (non-moving) pattern is left on the screen for long periods of time at a high brightness or contrast setting, the image can be permanently imprinted onto the screen. These types of imprints are not covered by your warranty.

• Do not use the projection TV at altitudes higher than 4000 m, as doing so might cause malfunctions.

Cleaning the Screen

•To clean the screen with a cloth, please use the supplied cleaning cloth lightly moistened with water. Do not use any type of abrasive pad, alkaline cleaner, scouring powder or solvent, such as alcohol or benzine. As a safety precaution, unplug the projection TV before cleaning it.

• Do not rub, touch, or tap the surface of the screen with sharp or abrasive items, like a ball point pen or a screw driver. Otherwise, this type or contact may result in a scratched screen.

3

The features you will enjoy include:

• “DRC-MF” for viewing higher quality pictures (page 21)

• “TWIN” for viewing two programs (page 26)

• “PROGRAM INDEX“ for displaying multiple programs (page 29)

• “Picture Mode”/“Sound Mode”/ “Surround” for customizing your projection TV (pages 20 and 31)

•“Wide Screen” to enjoy wide mode pictures (page 22)

• “MEMORY STICK” button on the remote control for viewing still pictures and movies stored in a “Memory Stick”(page 40)

Using Your New Projection TV

4

Your projection TV also offers the following features:

• Initial Setup function for on-screen language selection, automatic channel presetting and automatic convergence adjustment. (page 9)

• Menu language options — English/Chinese/Arabic (page 82)

• “Program Block” for locking out specific channels (page 91)

• “Intelligent Volume” for automatic volume adjustment (page 76)

• “Fine” tuning feature (page 87)

• Button Joystick on the remote control for easier operation (page 71)

• “Eco Mode” to save energy (page 83)

• “Game Mode” for video games (page 83)

Table of Contents

WARNING Using Your New Projection TV

Getting Started ............................................................................................. 6

Step 1 Install the projection TV............................................................ 6

Step 2 Connect the antenna .................................................................. 7

Step 3 Insert the batteries into the remote.......................................... 8

Step 4 Set up your projection TV automatically ............................... 9

Connecting optional components ........................................................... 11

Watching the projection TV...................................................................... 17

Using Your New projection TV

Advanced Operations

Selecting the picture and sound

modes...............................................20

Viewing higher quality pictures ......21

Using wide screen mode ..................22

Watching two programs at the same

time................................................... 26

Displaying multiple programs ........29

Listening with surround sound.......31

Enjoying stereo or bilingual

programs ......................................... 32

Viewing Teletext.................................34

Operating optional components......36

Using the projection TV’s center

speaker.............................................39

Using the “Memory Stick” viewer ..40

Adjusting Your Setup (MENU)

Introducing the menu system ..........68

Changing the “Picture” setting........ 72

Changing the “Sound” setting.........75

Entering the “Memory Stick”

menu ................................................ 78

Changing the “Wide Screen”

setting............................................... 79

Operating the “Multi Picture” using

the menu..........................................81

Changing the “Setup” setting ..........82

Additional Information

Troubleshooting .................................94

Self-diagnosis function................... 100

Identifying parts and controls ...... 101

Specifications...................... Back cover

Table of Contents

5

Using Your New projection TV

Getting Started

Step 1

Install the projection TV

For the best picture quality, install the projection TV within the areas below.

Optimum viewing area (Horizontal)

KP-FW46 KP-FW51

min. 1.7 m

(5.6 ft.)

60°

Optimum viewing area (Vertical)

KP-FW46 KP-FW51

min. 1.7 m

(5.6 ft.)

20°

min. 1.9 m

(6 ft.)

60°

min. 1.9 m

(6 ft.)

20°

Using Your New Projection TV

6

Step 2

Connect the antenna

If you wish to connect a VCR, see the “Connect a VCR” diagram on page 8.

Rear of projection TV

Antenna cable (not supplied)

or

Antenna cable (not supplied)

: Signal flow

For optimum Performance

To connect the projection TV to the antenna or the VCR, use an antenna cable (not supplied).

Note that one end of the cable has a male plug fitted while the other end is fitted with a female socket. Connect the male plug to the 8 (antenna) terminal of the projection TV.

Using Your New Projection TV

CAUTION

Do not connect the power cord until all other connections are complete; otherwise, a minimal current leakage through the antenna and/or other terminals to the ground could occur.

continued

Using Your New Projection TV

7

Getting Started (continued)

Connect a VCR

To play a video tape, press t (see page 18).

Antenna cable (not supplied)

Rear of projection TV

To antenna output

AUDIO

R L

VIDEO IN

VIDEO OUT

To video and audio outputs

: Signal flow

VCR

To (S video input)

S video

VIDEO

cable (not supplied)

To S video output

Audio/Video cable (not supplied)

Notes

• If you connect a monaural VCR, connect the yellow plug to (the yellow jack) and the black plug to -L (MONO) (the white jack).

• If you connect a VCR to the 8 (antenna) terminal, preset the signal output from the VCR to the program number 0 on the projection TV.

• When you connect a VCR to the S video input, display the “Setup” menu and select “Auto” for “S Input” (see page 84). If the signals are input to both (S video input) and (video input), the S video signal is automatically selected. To view the video signal input to (video input), select “Off” for “S Input”.

To 8 (antenna)

(MONO)

L

R

Y

PB/ C

B

PR/ C

R

L

2 3

R

1 2

1

To t 1, 2 or 3 (video input)

(yellow)

-L (MONO) (white)

-R (red)

Y

G

HD

PB/

SYNC

C

B

VD

B

PR/ C

R

L

R

Step 3

Insert the batteries into the remote

Note

• Do not use old batteries or different types of batteries together.

Using Your New Projection TV

8

Step 4

Set up your projection TV automatically

Press ! to turn on the

1

projection TV.

The “Initial Setup” menu appears, and you can select the on-screen language.

Move up or down to

2

select the desired language, then press

“Start auto program now?” appears.

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

INDEX

PROG

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

T

+

MENU

–

T

G

W

O

I

R

N

P

123 456 7809

JUMP

I n i t i a l S e t u p

L a n g u a g e :

]

S e l e c t :

S e l e c t : C o n f i r m : E n d :

C o n f i r m : E n d :

I n i t i a l S e t u p

F i r s t p l e a s e c a b l e / a n t e n n a

S t a r t a u t o p r o g r a m n o w ?

Yes No

Using Your New Projection TV

MENU

E n g l i s h

c o n n e c t

Move up or down to

3

select “Yes”, then press

to preset the channels

automatically.

The screen will indicate automatic presetting is in progress. After channel presetting is complete, automatic convergence adjustment menu appears.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w :

S e l e c t :

0 9 A u t o

C o n f i r m :

E n d :

I n i t i a l S e t u p

S t a r t d i g i t a l q u i c k f o c u s n o w ?

A u t o P r o g r a m

Y e s N o

S e l e c t : C o n f i r m : E n d :

continued

Using Your New Projection TV

9

Getting Started (continued)

Make sure that “Yes” is selected, then press .

4

The convergence adjustment screen appears, and the convergence is automatically adjusted. The last “Initial Setup” menu appears.

Move up or down to select “No”, then press .

5

The “Initial Setup” menu will not appear again the next time you turn on the projection TV by pressing !.

To allow this menu to appear again, select “Yes”, then press

Tip

If your projection TV has preset an unwanted channel or cannot preset a particular channel, then preset your projection TV manually (see page 86).

Notes

• If you want to cancel any setup, move up or down to select No and press , or press MENU.

• Convergence is also adjusted manually using the menu (see page 85.)

•You can also perform the Digital Quick Focus feature using on the front panel.

• Sound will mute while the Digital Quick Focus feature is running.

• The MENU, 2 + or – and (Enter) buttons on the projection TV can be also used for the above operations instead of and MENU buttons on the remote control.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

I n i t i a l S e t u p

D i s p l a y t h i s m e n u n e x t t i m e ?

S e l e c t : C o n f i r m :

.

Y e s N o

Using Your New Projection TV

10

Connecting optional components

You can connect optional audio/video components, such as a VCR, a DTV (Digital Television) receiver, multi disc player, camcorder, video game, or stereo system. To watch and operate the connected equipment, see pages 18 and 36.

Connecting a camcorder/video game equipment using t 4 (video input 4) jacks

Using Your New Projection TV

Video game equipment

or

Camcorder

To open the drop-down panel of your projection TV, push it up until you hear a click, then it will slide down.

To S video output

S video cable (not supplied)

Audio/Video cable (not supplied)

To video and audio outputs

Notes

• When connecting video game equipment, display the “Setup” menu and select “On” for “Game Mode” to adjust the picture setting that is suitable for video games (see page 83).

•You can also connect video equipment to the t 1, 2, or 3 (video input) jacks at the rear of your projection TV.

• When you connect video equipment to the S video input, display the “Setup” menu and select “Auto” for “S Input” (see page 84). If the signals are input to both (S video input) and (video input), the S video signal is automatically selected. To view the video signal input to (video input), select “Off” for “S Input”.

To (S video input)

To t 4 (video input)

(yellow)

-L (MONO) (white)

-R (red)

Front of projection TV

L(MONO)

4

: Signal flow

R

continued

Using Your New Projection TV

11

Connecting optional components (continued)

Connecting audio/video equipment using the T (monitor output) jacks

Rear of projection TV

C

#3

120W MAX 8Ω

Y

PB/ C

B

PR/ C

(MONO)

R

L

1

2 3

L

R

1 2

To T (monitor output)

Audio/Video cable (not supplied)

Note

• If you select “HD/DVD 1” or “HD/DVD 2” on your projection TV screen

Antenna cable (not supplied)

Y

G

HD

VD

SYNC

To antenna output

To video and audio inputs

VCR

PB/ C

B

PR/ C

R

L

R

or

Audio system

To audio inputs

(yellow)

-L (MONO) (white)

-R (red)

Audio cable (not supplied)

: Signal flow

(see page 18), sound will be heard but and no picture will be output from the T (monitor output) jacks. This does not indicate a malfunction.

Using Your New Projection TV

12

Connecting a DVD player to (component video input) 1 or 2 jacks

Rear of projection TV

Using Your New Projection TV

Component video cable (not supplied)

To component video output

To audio outputs

Y

CB CR

COMPONENT VIDEO OUT

S VIDEO OUT

DVD player

Notes

• Some DVD player terminals may be labeled differently:

Connect To (on the DVD player)

Y (green) Y PB/CB (blue) Cb, B-Y or PB PR/CR (red) Cr, R-Y or PR

R-AUDIO-L

LINE OUT

To 1 or 2 (component video input)

Audio cable (not supplied)

VIDEO

To -L (white)

-R (red)

Y

PB/ C

B

PR/ C

R

L

R

12

Y

G

PB/

C

B

PR/

C

R

L

R

: Signal flow

• Connect nothing to the HD/VD jacks when connecting a DVD player to 1 or 2 (component video input).

• If you select “HD/DVD 1” or “HD/DVD 2” on your projection TV screen

(see page 18), sound will be heard but and no picture will be output from T (monitor output). This does not indicate a malfunction.

• When receiving a progressive signal through (component video

input), TWIN pictures and PROGRAM INDEX features are not available, and “DRC-MF” and “Game Mode” are not selectable.

continued

Using Your New Projection TV

13

Connecting optional components (continued)

Connecting a DVD player to t (video input) 1, 2 or 3 jacks

To video and audio outputs

R-AUDIO-L

VIDEO

LINE OUT

DVD player

Rear of projection TV

Audio/Video cable (not supplied)

To t 1, 2, or 3 (video input)

(yellow)

3

: Signal flow

-L (MONO) (white)

-R (red)

Notes

• Since the high quality pictures on a DVD disc contain a lot of information, picture noise may appear. In this case, display the “Picture” menu and select “Personal” for “Picture Mode”, then adjust the sharpness (“Sharpness”) under “Picture Adjustment” (see page 74).

•You can also connect a DVD player to (S video input) on the projection TV.

Using Your New Projection TV

14

Connecting a DTV (digital television) receiver to

1 or 2 (component video input) jacks

Rear of projection TV

Using Your New Projection TV

Component video cable (not supplied)

Digital TV receiver

To audio outputs

Note

• The projection TV is equipped with the G/B/R/HD/VD inputs.

Tip

• The projection TV accepts the following signal formats:

To 1 or 2 (Component video input)

To component video output

Audio cable (not supplied)

If your DTV receiver is equipped with the Y/PB/PR output connectors, connect it to the Y/PB/PR connectors of 1 or 2. Connect nothing to the HD/VD connectors of 2.

If your DTV receiver is not equipped with the Y/PB/PR output connectors, connect it to the G/B/R/HD/VD connectors of 2.

Total scanning line Effective scanning line fV (Hz)

1125i 1080i 50/60 750p 720p 50/60 625p 576p 50 625i 576i 50 525p 480p 60 525i 480i 60

To -L (white)

-R (red)

: Signal flow

continued

Using Your New Projection TV

15

Connecting optional components (continued)

Connecting an amplifier

If you use an amplifier with a Dolby* surround decoder instead of the projection TV’s audio system, you can use the projection TV’s speakers as the center speaker for your audio system.

Using the speaker cords supplied with the amplifier, connect the speaker terminals of the amplifier to the terminals on the projection TV.

(center speaker input)

To component video cable (not supplied)

To component video output

DVD player

To 1 or 2 (Component video input)

Audio cable (not supplied)

To digital audio output

To -L (white)

To audio outputs

Optical digital cable (not supplied)

Rear of projection TV

C

120W MAX 8W

Y

PB/

C

B

PR/

C

(MONO)

L

R

-R (red)

L

R

321

To digital

R

audio input

Front

speaker (L)

1 2

Rear

Y

G

PB/

C

B

PR/

C

R

L

R

Amplifier

Woofer

C

HD

SYNC

VD

Rear

speaker (R)

Ω

120W MAX 8

To (center speaker input)

Front

speaker (R)

: Signal flow

Using Your New Projection TV

16

Note

To use the projection TV’s speakers as the center speaker, display the “Sound” menu and select “CENTER IN” for “Speaker” (see page 76).

* “Dolby” is a trademark of Dolby Laboratories.

Watching the projection TV

This section explains various functions and operations used while watching the TV. Most operations can be done using the remote.

1 indicator

PROG

MENU

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

P

R

N

I

O

W

G

T

HD/DVD

+

–

G

W

O

I

R

N

P

INDEX

PROG

123 456 7809

PROG

OPTION RESET

TV

A/B

V CENTER

JUMP

Using Your New Projection TV

MENU

HD/DVD

Number buttons

JUMP

PROG +/–

2 +/–

Press ! to turn on the projection TV.

1

When the projection TV is in standby mode (the 1 indicator on the projection TV is lit red), press !/1 on the remote.

Press PROG +/– or the number

2

buttons to select the TV channel.

For double digit numbers, press -/--, then the number (e.g., for 25, press -/--, then 2 and 5).

Note

• When you turn on the projection TV, either the program number or video mode is displayed for approximately 40 seconds. The Eco Mode ( ) icon will also appear if “Eco Mode” in the “Setup” menu is set to “On” (see page 83).

PROG

123 456

or

78

0

continued

Using Your New Projection TV

9

17

Watching the projection TV (continued)

To select a projection TV program quickly

1Press and hold PROG +/–. 2 Release PROG +/– when the desired program number appears.

Note

• When you select a TV program quickly, the picture may be disrupted.

This does not indicate a malfunction.

Additional tasks

To Press

Turn off temporarily

Turn off completely Adjust the volume Mute the sound Watch the video input

(VCR, camcorder, etc.)

Watch the component input (DVD, DTV receiver)

Jump back to the previous channel

Display the on-screen information*

@/1. The 1 indicator on the projection TV lights up red.

! on the projection TV. 2 +/–. %.

t (or t on the projection TV) to select “VIDEO 1”, “VIDEO 2”, “VIDEO 3”, “VIDEO 4”, “HD/DVD 1” or “HD/DVD 2”. To return to the TV screen, press a (or t on the TV).

HD/DVD to select “HD/DVD 1” or “HD/DVD 2”. To return to the TV screen, press a (or t on the projection TV).

JUMP.

.

18

Using Your New Projection TV

* Some picture/sound settings, and either the program number or video

mode are displayed. The on-screen display for the picture/sound settings disappears after about 3 seconds.

Setting the Wake Up timer

Press until the desired

1

period of time appears.

Wake Up Timer:10M

After 10 minutes

The Wake Up timer starts immediately after you have set it.

Select the TV channel or video mode you want to wake up to.

2

Press !/1, or set the Sleep timer if you want the projection TV to turn off

3

automatically.

The

indicator on the projection TV lights up orange.

Wake Up Timer:Off No Wake Up Timer After 12 hours

Wake Up Timer:12H00M

To cancel the Wake Up timer

Press until “Wake Up Timer: Off” appears, or press ! on the projection TV to turn it off.

Note

• If no buttons or controls are pressed for more than two hours after the projection TV is turned on using the Wake Up timer, the projection TV automatically goes into standby mode. To resume watching the TV, press any button on the projection TV or the remote.

Setting the Sleep timer

Using Your New Projection TV

Press until the desired period of time appears.

You can select the period of time from among 15, 30, 45, 60, 75 and 90 minutes.

The Sleep timer starts immediately after you have set it.

To cancel the Sleep timer

Press until “Sleep Timer: Off” appears, or turn the projection TV off.

Sleep Timer:15M

After 15 minutes

Sleep Timer:Off Sleep Timer:90M

No Sleep Timer

Using Your New Projection TV

After 90 minutes

19

Advanced Operations

Selecting the picture and sound modes

JUMP

0

You can select picture and sound modes and adjust the setting to your preference in the “Personal” option.

OPTION RESET

Selecting the picture mode

Press repeatedly until the desired picture mode is selected.

Select To

“Dynamic” receive high contrast pictures. “Standard” receive normal pictures. “Hi-Fine” receive higher resolution pictures with mild contrast. “Personal” receive the last adjusted picture setting from the “Picture

Adjustment” menu under the “Picture” menu (see page 74).

Dynamic

Personal

Selecting the sound mode

Press repeatedly until the desired sound mode is selected.

9

Dynamic

PROG

Standard

Hi-Fine

9

Drama

Select To

“Dynamic” listen to dynamic and clear sound that emphasizes both the low

“Drama” listen to sound that emphasizes voice and high tones. “Soft” receive soft sound. “Personal” receive the last adjusted sound setting from the “Sound

20

Advanced Operations

9

Personal

and high tones.

Adjustment” menu under the “Sound” menu (see page 77).

Tip

•You can also set the picture and sound modes using the menu (see

“Changing the “Picture” setting” on page 72 and “Changing the “Sound” setting” on page 75).

9

Soft

Viewing higher quality pictures

VIDEO

— “DRC-MF”

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

The Digital Reality Creation-Multi Function (DRC-MF) feature allows you to enjoy higher quality pictures on your projection TV. You can select from among three DRC-MF modes: “DRC1250” to watch super real (higher resolution)

DRC-MF

INDEX

PROG

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

pictures, or “DRC100” for moving pictures or “Progressive” for still pictures to reduce flicker if necessary.

123 456 7809

JUMP

Press DRC-MF repeatedly until you receive the desired picture quality.

DRC-MF

Select To

“DRC1250” select higher resolution pictures. “DRC100” reduce flicker on the screen. “Progressive” reduce jitter of any small areas or scanning lines (e.g., letters or the

edge of objects) on the screen.

DRC-MF: DRC1250 DRC-MF: DRC100

DRC-MF: Progressive

DRC-MF

Advanced Operations

Tip

• When the broadcast signal is weak, you may see some dots or noise on the TV screen. To reduce this interference, display the “Picture” menu and select “Personal” for “Picture” mode, then adjust “Sharpness” under “Picture Adjustment” to reduce the sharpness (see page 74).

Note

• The DRC-MF mode is not selectable when using the PROGRAM INDEX feature, or when the “Game Mode” or “Twin” mode is turned “On”. The mode is not available for HD (high-definition) or progressive input signal, or the picture recorded on a “Memory Stick”.

The DRC-MF logo ( ) and “DRC-MF” are trademarks of Sony Corporation.

Advanced Operations

21

Using wide screen mode

The wide screen mode feature allows you to watch the picture filling the 16:9 screen of the projection TV.

DRC-MF

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

V CENTER

MENU

123 456 7809

JUMP

PROG

OPTION RESET

TV

Watching the picture in wide screen mode automatically

— AUTO WIDE

22

Advanced Operations

The projection TV automatically selects optimum wide screen mode according to the signal input and displays the picture to fill the 16:9 screen.

Notes

• The AUTO WIDE feature may not work correctly depending on the quality of signal. In this case, select the wide screen mode manually using the button (see page 24).

• The examples in the table on page 23 show the settings preset at the factory; “Auto Wide” is set to “On” and “4:3 Default” is set to “Wide Zoom” in the “Wide Screen” menu (see page 79).

When receiving ...

normal 4:3 aspect ratio picture with an ID-1 or S1 signal or a signal without ID-1.

4:3 letter box movie or a video or DVD with an ID-1 signal.

4:3 squeezed video camera picture with an ID-1 or S1 signal.

HDTV 16:9 picture

AUTO WIDE functions to select ...

Wide

Zoom*

Zoom

Full

The picture changes to ...

enlarge the 4:3 picture, with the upper and lower parts condensed to fit the 16:9 screen.

enlarge the picture horizontally and vertically in an equal aspect ratio that fills the 16:9 screen*.

enlarge the picture horizontally only, to fill the 16:9 screen.

An HDTV 16:9 picture is always displayed in “Full” mode.

* When a normal 4:3 picture is received, “Wide Zoom” mode is

automatically selected with the factory setting. You can display that picture as it is without enlarging it (“Normal” mode) if you set “4:3 Default” in the “Wide Screen” menu to “Normal” (see page 79).

** Black bands may appear on the top and bottom of the screen.

Note

• The 720p/1080i format signal is always displayed in “Full” mode even if it has no ID-1 signal.

continued

Advanced Operations

23

Using wide screen mode (continued)

Watching the picture in wide screen mode manually

You can select the desired wide screen mode manually.

Press repeatedly until the mode indication you want is displayed on the screen.

For details on each mode, see “Watching the picture in wide screen mode automatically”.

Notes

• You can also select the wide screen mode manually using the menu (see page 79).

• When the wide screen mode is selected by pressing the button on the remote or using the menu, the AUTO WIDE feature does not work temporarily.

The AUTO WIDE feature functions again when: – you change a TV channel with PROG +/–. – you change the video input with t. – the projection TV is turned off and on again.

• The 720p/1080i format signal (HDTV 16:9 picture) is always displayed in “Full” mode.

• You can adjust the vertical position of the picture when wide screen mode is set to “Wide Zoom” or “Zoom” (see page 25).

Wide Zoom Normal

Zoom Full

24

Advanced Operations

Adjusting the position of the picture

You can adjust the vertical position of the picture when – the upper or lower part of the picture cannot be seen in “Wide

Zoom” mode.

– you want to adjust the vertical position of the picture in the screen

for “Zoom” mode. This feature is available only for “Wide Zoom” and “Zoom”

modes.

Press V CENTER.

1

V CENTER

Move up or down to

2

move the picture up or down.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Wide Zoom V Center: 00

Wide Zoom V Center: +15

3

Press .

Wide Zoom V Center: –15

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Notes

• The adjusted V Center value remains stored even after the TV is turned off.

• You can also adjust the position of the picture in “Wide Zoom” and “Zoom” modes using the menu (see page 79).

Advanced Operations

25

Watching two programs at the same time

— “TWIN”

With the TWIN pictures feature, you can display a different TV program beside the main picture.

Displaying TWIN pictures

Press .

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

DRC-MF

INDEX

PROG

123 456 7809

JUMP

10 12

To return to the normal screen

Press . The left picture is displayed in full screen.

Tip

•You can also display the Twin pictures using the menu (see “Operating the

“Multi Picture” using the menu” on page 81).

26

Advanced Operations

Additional tasks

To

change a TV program in the right picture

swap the left and right pictures

swap sound between the left and right pictures.

change the screen size of the TWIN pictures

Press/Move

Move up or down (TWIN PROG + or –).

Press .

Press . The “ ” symbol will appear to indicate which screen you are hearing.

Move left to increase the left screen size. Move right to increase the right screen size.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Notes

• Swapping the pictures is not available for HD or DVD input signal.

• The TWIN pictures feature is not available for HD (high-definition) and progressive signals. If you change the left main picture to an HD or progressive signal, a message appears and the TWIN pictures feature is cancelled. The selected HD or progressive picture will be displayed in full screen.

• The TWIN pictures feature is not available when the TV is in the center speaker mode (page 39) and you cannot set the TV to the center speaker mode while viewing the TWIN pictures.

•You cannot enjoy stereo sound in the right picture.

•You cannot change the picture to a video input in the right picture. You can only display a video input, except for HD and progressive signals, in the right picture by swapping the pictures when a video input is displayed in the left picture.

• When the button is pressed, the TV screen flickers or goes blank for about one second before the TWIN pictures appear. This does not indicate a malfunction of the projection TV.

continued

Advanced Operations

27

Watching two programs at the same time — “TWIN” (continued)

Selecting a TV program using PAP (Picture And Picture)

You can select your desired TV program directly from the right picture by using (TWIN PROG +/–).

Move up or down

1

(TWIN PROG +/–).

The two pictures of the same channel appear on the screen (PAP).

Move up or down

2

(TWIN PROG +/–) until the desired program appears on the right screen.

Press to display the

3

right picture in full screen.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

10

8

–

T

G

W

O

I

R

N

P

To change the left picture channel

Press PROG +/– or the number buttons.

To return to the normal screen from the PAP mode

Press . The left picture is displayed in full screen.

Notes

•You cannot change the picture size or swap the two pictures in the PAP

mode. (You can swap the sounds of the two pictures.)

• The PAP feature is not available for HD (high-definition) and progressive

signals. If you change the left main picture to an HD or progressive signal, a message appears and the PAP feature is cancelled. The selected HD or

28

Advanced Operations

progressive picture will be displayed in full screen.

Displaying multiple programs

— “PROGRAM INDEX”

The PROGRAM INDEX feature displays all tuned TV programs scrolling on the screen for direct selection.

Press PROG INDEX.

1

The current program is reduced in size and displayed on the left. The first tuned program is briefly displayed on the bottom-right side of the screen, then frozen. It scrolls up and the next program appears on the bottom-right, and all tuned programs appear one by one.

INDEX

PROG

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

P

R

N

I

O

W

G

T

HD/DVD

+

–

G

W

O

I

R

N

P

INDEX

PROG

123 456 7809

A/B

V CENTER

MENU

JUMP

PROG INDEX

10

Move up or down so

2

that the program you want to view is displayed in the frame, and press

.

To return to scrolling, move up or down again.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

continued

10

Advanced Operations

29

Displaying multiple programs — “PROGRAM INDEX”(continued)

Press again to enlarge

3

the selected program into the left frame.

The selected program is displayed in normal

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

8

motion picture, and the sound also switches to this program.

Press PROG INDEX.

4

The selected program is displayed in full screen.

Tip

•To change the direction of scrolling, move up or down once. To

increase scrolling speed, hold up or down.

INDEX

PROG

To return to the normal screen

Press PROG INDEX again, or:

1 Select “Program Index” from the “Multi Picture” menu. 2Press .

8

30

Advanced Operations

Tip

•You can also display multiple programs using the menu (see “Operating

the “Multi Picture” using the menu” on page 81).

Notes

• When displaying multiple programs, only the sound of the left screen is

heard.

• The PROGRAM INDEX feature is not available for HD (high-definition)

and progressive signals. The selected HD or progressive picture will be displayed in full screen.

Listening with surround sound

The surround feature enables you to enjoy the sound effects of a concert hall or movie theater.

Press repeatedly until you receive the desired surround sound.

123 456 7809

JUMP

PROG

OPTION RESET

TV

Surround: TruSurround

Surround: Off

Select To

“TruSurround”* listen to the surround sound that spreads out to the rear of a room.

“Simulated” listen to monaural sound with a stereo-like effect.

“Off” turn off the surround sound.

*TruSurround, SRS and the  symbol are trademarks of SRS Labs,

Inc. TruSurround technology is incorporated under license from SRS Labs, Inc.

Note

•You cannot change the surround sound when the TV is in the center speaker mode (page 39).

Surround: Sim u lated

Advanced Operations

31

Enjoying stereo or bilingual programs

You can enjoy stereo sound or bilingual programs of NICAM and A2 (German) stereo systems.

Press A/B repeatedly until you receive the sound you want.

When receiving a NICAM program

Broadcasting On-screen display (Selected sound)

NICAM stereo

A/B

NICAM

(Stereo sound)

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

V CENTER

P

R

N

I

O

W

G

T

HD/DVD

+

–

G

W

O

I

R

N

P

INDEX

PROG

123 456

A/B

MENU

(Regular sound)

A/B

NICAM

Mono

32

Advanced Operations

NICAM bilingual

NICAM monaural

NICAM

Main

(Main sound)

NICAM

Main

(Main sound)

NICAM

Sub

(Sub sound)

Mono

(Regular sound)

Mono

(Regular sound)

When receiving an A2 (German) program

Broadcasting On-screen display (Selected sound)

A2 (German) stereo

Mono

(Regular sound)

Stereo

(Stereo sound)

A2 (German) bilingual

Main

(Main sound)

Receiving area for NICAM and A2 (German) programs

System Receiving area

NICAM New Zealand, Hong Kong, Singapore, Malaysia,

Thailand, etc.

A2 (German) Australia, Malaysia, Thailand, etc.

Notes

• If the signal is very weak, the sound becomes monaural automatically.

• If the stereo sound is noisy when receiving a NICAM program, select “Mono”. The sound becomes monaural, but the noise is reduced.

• Before receiving a NICAM stereo program in China, please check the NICAM broadcast condition at your area. When receiving a NICAM stereo program, the receiving conditions might vary depending on area. In addition, different strength of the NICAM broadcast signal might affect the receiving quality.

If the sound is distorted or noisy when receiving a monaural program through the 8 (antenna) terminal

Press A/B repeatedly until “Mono” appears on the screen. To cancel the monaural sound setting, press A/B again until “Auto”

appears on the screen.

Sub

(Sub sound)

Mono

Auto

Notes

• The “Mono” or “Auto” setting is memorized for each program position.

•You cannot receive a stereo broadcast signal when the projection TV is in the “Mono” setting. Normally, set the projection TV to “Auto”.

Advanced Operations

33

Viewing Teletext

VIDEO

Some TV stations broadcast an information service called Teletext which allows you to receive various information, such as stock market reports and news.

DRC-MF

INDEX

PROG

M

T

HD/DVD

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

123 456 7809

JUMP

PROG

OPTION RESET

TV

Displaying Teletext

Select a TV channel that carries the Teletext broadcast you want to watch.

1

A/B

Number buttons

(red, green, yellow, blue)

PROG +/–

Press to display the

2

text.

A Teletext page (normally the index page) is displayed. If there is no Teletext broadcast, “100” is displayed at the top left corner of the screen.

To turn off Teletext

34

Advanced Operations

Press a.

P166 SECTEXT 166 FR1 MAR 03:59:09

From Singapore

Day Dep/Arr Flight Alrcraft

1.6 220/0588 SQ28 747

To PAR IS

2 2130/1225 PA115 L15 3 2115/1330 SQ26 747

2.5 1000/1715 SQ6 747

To OSAKA

4.6 0930/2015 CX522 L10

2.7 2130/0745 SQ24

To ROMA

4 2300/0915 AZ487 747 1 2210/0610 SQ21A 747

To SYDNEY

2 2100/0835 SQ21A 747

747

Additional Teletext tasks

To

display a Teletext page on the TV picture

check the contents of a Teletext service

select a Teletext page

hold (pause) a Teletext page (stop the page from scrolling)

reveal concealed information (e.g., an answer to a quiz)

enlarge the Teletext display

stand by for a Teletext page while watching a TV program

Do this

Press . Each time you press , the screen changes as follows: Teletext t Teletext and TV t TV.

Press . An overview of the Teletext contents, including page numbers, appears on the screen.

Press the number buttons to enter the three-digit page number of the desired Teletext page.* If you make a mistake, reenter the correct page number. To access the next or previous page, press PROG +/–.

Press to display the symbol “z” at the top left corner of the screen. To resume normal Teletext viewing, press or .

Press . To conceal the information, press the button again.

Press . Each time you press , the Teletext display changes as follows: Enlarge upper half t Enlarge lower half t Normal size.

1 Enter the Teletext page number that you want to

refer to, then press .

2 When the page number is displayed, press to

show the text.

*You can also select a Teletext page of any page number that appears in the

colored column at the bottom of the screen using the corresponding colorcoded button on the remote.

Using FASTEXT

This feature allows you to quickly access a Teletext page that uses FASTEXT. When a FASTEXT program is broadcast, colored menus appear at the bottom of the screen. The color of each menu corresponds to the color-coded buttons on the remote (red green

To access a FASTEXT menu

Press the color-coded button on the remote corresponding to the menu you want. The menu page appears on the screen after a few seconds.

, yellow , and blue ).

,

Advanced Operations

35

Operating optional components

You can use the supplied remote to operate Sony video equipment such as Beta, 8 mm, VHS or DVD.

DRC-MF

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

T

+

–

G

W

O

I

R

N

P

VIDEO I/1

MENU

123 456 7809

JUMP

PROG

OPTION RESET

TV

Setting up the remote to work with other connected equipment

While keeping VIDEO @/1 pressed, press the number button 0, then the corresponding number button for the desired equipment (see the chart below).

To control While holding First press the Next press the

down number button number button

DVD VIDEO @/1 00 VTR1 (Beta) VIDEO @/1 01 VTR2 (8 mm) VIDEO @/1 02 VTR3 (VHS) VIDEO @/1 03 MDP VIDEO @/1 04 CD VIDEO @/1 06 MD VIDEO @/1 07

For example, to operate a Sony 8 mm VCR:

VIDEO

02

+

Number buttons 1-7

Number button 0

OPTION

36

Advanced Operations

Note

• If the equipment does not have a certain function, the corresponding button on the remote will not operate.

Operating video equipment

Press VIDEO @/1, or while keeping OPTION pressed, press (N) or move up (X), down (x), left (.) or right (>) (see the chart below).

VIDEO

or

OPTION

+

N

I

W

T

W

I

N

Operating a VCR using the remote

To Press/Move

turn on/off VIDEO ?/1

play N while keeping OPTION pressed.

stop x while keeping OPTION pressed.

fast forward (M) > while keeping OPTION pressed.

rewind the tape (m) . while keeping OPTION pressed.

pause X while keeping OPTION pressed.

Press again to resume normal playback.

search the picture forward (M) or backward (m)

> or . during playback while keeping OPTION pressed. Release to resume normal playback.

Operating a DVD player using the remote

To Press/Move

turn on/off VIDEO ?/1

play N while keeping OPTION pressed.

stop x while keeping OPTION pressed.

pause X while keeping OPTION pressed.

step through different tracks of an audio disc

Press again to resume normal playback.

> to step forward or . to step backward while keeping OPTION pressed.

P

R

O

G

+

–

G

O

R

P

or

OPTION

+

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

continued

Advanced Operations

37

Operating optional components (continued)

Operating an MDP using the remote

To Press/Move

turn on/off VIDEO I/1

play N while keeping OPTION pressed.

stop x while keeping OPTION pressed.

pause X while keeping OPTION pressed.

search the picture forward or backward

Press again to resume normal playback.

> or . during playback while keeping OPTION pressed. Release to resume normal playback.

Operating a CD or MD player using the remote

To Press/Move

turn on/off VIDEO ?/1

play N while keeping OPTION pressed.

stop x while keeping OPTION pressed.

pause X while keeping OPTION pressed.

step through different tracks > to step forward or . to step

Press again to resume normal playback.

backward while keeping OPTION pressed.

38

Advanced Operations

Using the projection TV’s center speaker

You can use the projection TV’s speakers as the center speaker of your audio system and control its sound volume from the remote of the projection TV.

Notes

• For the speaker connection, see “Connecting an amplifier that supports Dolby Pro Logic decoder” on page 16.

•You cannot switch to the center speaker mode while viewing the TWIN pictures.

To switch to the center speaker mode

Press CENTER SP.

1

Press 2 +/– to adjust the

2

volume of the sound from the TV’s center speaker.

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

DRC-MF

INDEX

PROG

123 456 7809

JUMP

PROG

N

E

T

C

E

R

S

P

CENTER IN Speaker

MENU

CENTER SP

+/–

0

5

To return to the normal speaker mode

Press CENTER SP again.

Tip

• The center speaker mode is automatically cancelled when you select the video input or the “Memory Stick” viewer, or turn the TV off and on again. It is not cancelled, however, when using the PROGRAM INDEX feature.

Notes

• If “CENTER IN” is selected for “Speaker” in the “Sound” menu and nothing is connected to the center speaker input terminals on the rear of the projection TV, no sound is heard from the projection TV’s speakers.

• No sound is heard from the TV’s center speakers if the sound source emitted from the amplifier does not contain the center speaker channel.

• When the TV is in the center speaker mode, you cannot use the TWIN pictures feature, or change the surroud sound, the “Intelligent Volume” mode or the “BBE” mode.

Advanced Operations

39

Using a “Memory Stick” viewer (continued)

Using the “Memory Stick” viewer

About “Memory Stick”

“Memory Stick” (sold separately) is a new, compact, portable, and versatile Integrated Circuit recording medium with a data capacity that exceeds that of a floppy disk. “Memory Stick” is specially designed for exchanging and sharing digital data among “Memory Stick” compatible products such as digital cameras and digital video cameras. Because it is removable, “Memory Stick” can also be used for external data storage.

The “Memory Stick” viewer on your projection TV allows you to view still images (JPEG* files) and movies (MPEG1** files) stored on “Memory Stick” media.

For more information on using “Memory Stick” media, see “Notes on using “Memory Stick”, “Memory Stick PRO” media” on page 42 and “Notes on Memory Stick Duo” on page 43.

“Memory Stick”, “Memory Stick PRO”, “Memory Stick Duo” and

” are registered trademarks of Sony Corporation.

“

Notes

• The data loading speed may differ depending on the “Memory Stick”.

• When you view a still image stored on “Memory Stick” media, the sound

is not output from the TV’s speakers. Do not attempt to adjust the volume.

•A “Memory Stick” formatted by a computer may not be used with this

projection TV.

File Compatibility

40

Advanced Operations

The “Memory Stick” viewer can display still images and movies that are stored on “Memory Stick” media using the following compression format:

– JPEG* files (DCF compliant*) with an extension, .jpg – MPEG1** files, MPEG MOVIE, MPEG MOVIE AD, MPEG MOVIE

EX, MPEG MOVIE HQ, MPEG MOVIE HQX, MPEG MOVIE CV,

VAIO Giga Pocket MPEG1. – Images with more than 16 horizontal and/or vertical dots per line – Images with less than 4096 horizontal and/or vertical dots per

line

Example: Still images recorded with a Sony digital still camera

Folder name: /DCIM/101MSDCF File name: DSC00001.JPG

101MSDCF

DSC00001

DSC00002

DSC00003

Image folder name

Image file names

Example: Movie files recorded with a Sony digital still camera

Folder name: /MSSONY/MOML0001 File name: MOV00001.MPG

Note

• The projection TV’s “Memory Stick” viewer cannot display still images and movies stored in TIFF or any other non-JPEG or nonMPEG1 compression format.

* JPEG stands for “Joint Photographic Experts Group,” which is the

organization that implemented this format. DCF stands for “Design Rules for Camera File Systems,” which are specifications established by the Japan Electronics and Information Technology Industries Association (JEITA).

** MPEG1 stands for “Motion Picture Experts Group” which is the

organization that implemented this format and is the typical compression format for movie files.

To prevent accidental erasure of still images and movies

Set the “Memory Stick” erasure prevention switch to “LOCK”.

In this position, you cannot rotate the images. (See page 53.)

Label area

Erasure prevention switch

Front

Tip

• When you set the erasure prevention switch on a “Memory Stick Duo”, use a sharp object such as a ballpoint pen.

Rear

continued

41Advanced Operations

Using a “Memory Stick” viewer (continued)

Notes on using “Memory Stick,” “Memory Stick PRO” media

When using “Memory Stick,” “Memory Stick PRO” media, follow these precautions:

•To avoid permanent damage to still image data, do not turn off the projection TV or remove “Memory Stick” media from the insertion slot while data is being read (as indicated by the “Memory Stick” indicator light being on).

•Avoid touching the terminal of “Memory Stick” media or bringing it into contact with a metal object.

• Do not drop, bend, or submit “Memory Stick” media to external shock.

• Do not disassemble or modify “Memory Stick” media.

•Avoid getting liquid on “Memory Stick” media.

• Apply labels only within the designated label area.

Label area

•To avoid permanent damage to still image data, do not use or store “Memory Stick” media in a location subject to:

— High temperature (such as near a heater or inside a hot car) — High humidity — Direct sunlight — Corrosive substances — Magnetic fields — Excessive dust — Static electricity or electric noise — Electric surgess

• Store and carry “Memory Stick” media in its original case to ensure protection of stored data.

• Save a backup of stored data.

42

Advanced Operations

Notes on “Memory Stick Duo”

“Memory Stick Duo” is a new, compact version of the standardsized “Memory Stick” recording medium. You can use a “Memory Stick Duo” on your projection TV by inserting a “Memory Stick Duo” into an adapter before inserting it into the projection TV.

• Be sure to attach a “Memory Stick Duo” to the adapter with the correct orientation.

• Be sure to insert the “Memory Stick Duo” adapter into the “Memory Stick” slot with the correct orientation. Otherwise, the projection TV may be damaged.

• Do not insert the “Memory Stick Duo” adapter without the “Memory Stick Duo” attached. Doing so may result in malfunction of the projection TV.

Inserting and removing a “Memory Stick”

To insert a “Memory Stick”

Locate the “Memory Stick” slot (see page 101 ) and insert the “Memory Stick” into the “Memory Stick” slot as illustrated.

Insert the “Memory Stick” media with the v symbol upward. When inserted properly, it should slide in with little resistance and click into place. The “Memory Stick” indicator flashes and goes off.

When the “Memory Stick” is inserted or removed, the following indication appears in the right-bottom side of the display in addition to the indication of the indicator (LED).

: when the “Memory Stick” is inserted

: when the “Memory Stick” is removed

Notes

• Be sure to insert the “Memory Stick” in the correct direction. If the “Memory Stick” is forced in the wrong way, it may become damaged.

• Insert only “Memory Stick” media into the “Memory Stick” slot. Attempting to insert other objects into the slot may damage the projection TV.

continued

43Advanced Operations

Using a “Memory Stick” viewer (continued)

To remove a “Memory Stick”

Check that the “Memory Stick” indicator is off. (When the light is on, this

1

indicates that the projection TV is reading data from the “Memory Stick”.) Push the “Memory Stick” gently

2

into the slot, and then release it.

The “Memory Stick” media is ejected.

Pull the “Memory Stick”

3

completely out of the slot.

Tip

• When removing the “Memory Stick”, do not attempt to just pull it from its slot.

Notes

•To protect small children from injury from “Memory Stick” media, remove all “Memory Stick” media from the projection TV’s “Memory Stick” slot and store it in a safe location when it is not in use.

• The screen return to the normal screen if you leave the still picture or the moving picture in pause about for 60 minutes.

44

Advanced Operations

Displaying thumbnails of still images and movie files

You can view up to 20 still images and movies on the “Memory Stick” index.

Insert a “Memory Stick” into the “Memory Stick” slot of the

1

projection TV.

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK.

2

The “Memory Stick Home” appears, which displays thumbnails of still image and movie files stored on the “Memory Stick”.

Highlighted thumbnail

DRC-MF

INDEX

PROG

M

T

HD/DVD

M

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

Y

R

S

T

O

I

C

M

K

E

MEMORY STICK

MENU

Scroll bar

“Memory Stick” menus

Digi. Cam. Mode (Digital Camera Mode) indication

First 20 thumbnails of still images and movies

Memory Stick Home Slide Show

Options

Filter : Still

Select Folder

Digi. Cam. Mode

No : Size :

File : Date :

Information about the highlighted image or movie

continued

45Advanced Operations

Using a “Memory Stick” viewer (continued)

When there are more than 20 still images and movies

Move right to elect the scroll bar at the right end of the “Memory Stick Home”, then move

down to display the next 20 thumbnails.

About the “Digi. Cam. Mode” (Digital Camera Mode)

“Digi. Cam. Mode” displays all JPEG and MPEG1 files recorded with the DCF compliant digital cameras. When you set the “Digi. Cam. Mode” to “Off”, only the selected files or all the files with the extension .jpg and .mpg can be displayed. The “Memory Stick” viewer of this projection TV sets “Digi. Cam. Mode” to “On” at the factory. To set “Digi. Cam. Mode” to “Off”, see page 64.

Digi. Cam. Mode Viewable images

“On” Still images in DCF compliant JPEG files recorded on a

“Off” JPEG still pictures and MEPG1 movies in the folder

Notes

• When “Digi. Cam. Mode” is “On”, you cannot set “Sort” and “Filter” in the “Options” menu (pages 66 and 67).

• When “Digi. Cam. Mode” is set to “On”, the maximum 2000 pieces of still images and/or movies can be displayed. When you want to display more than 2000 pictures, set “Digi. Cam. Mode” to “Off”.

Sony digital still camera or digital video camera recorder. Movies in MPEG1 files recorded on a Sony digital still camera or digital video camera.

whose name has been changed by a computer.

To view still images and movies that have been arranged and saved as in a computer

You need to select the folder. To select the folder, set “Digi. Cam. Mode” to “Off”.

About the icons on the thumbnail images

(Movie) Indicates the thumbnail is a movie (MPEG1) file.

46

Advanced Operations

(Protect) Indicates the thumbnail is protected. Protected files

(Relative file) Indicates another file named the same in the last four

cannot be changed or deleted. For details, see “Protecting still images and movies” on page 59.

digits exists in the “Memory Stick” but is not displayed. (appears only when the Digi. Cam. Mode is “On”.)

Notes

• The Relative file icon is added with the first file of those in the same file format (JPEG, MPEG1, and others) and having the file name with the same last 4-digits.

• If you delete the file with the Relative file icon, the other related files are all deleted at the same time.

About caution displays

To return to the normal screen

Press the number buttons or PROG +/–.

Tip

• When you press PROG +/–, the last selected channel appears.

This image data is the JPEG or MPEG1 format that is not compatible.

There is the thumbnail but it is not DCF compliant.

There is the image data but the thumbnail is broken.

The image data is broken.

continued

47Advanced Operations

Using a “Memory Stick” viewer (continued)

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

Viewing still images and movies in sequence — Slide Show

You can view the still images and movies stored on a “Memory Stick” with a specified interval.

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

DRC-MF

INDEX

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up or down to select “Slide Show”, then press .

3

The “Slide Show” menu appears.

Move up or down to select “Start”, then press .

4

Still images and movies are displayed according to the setting.

A movie is played automatically. At the end of the movie, the next image appears.

MEMORY STICK

48

Advanced Operations

Tip

•You can start the Slide Show even when a still image or movie is selected.

Note

• The still images and movies do not change automatically if “Advance” is in the “Slide Show” menu is set to “Manual”.

To exit the “Slide Show”

Press on the remote.

To change still images and movies in “Slide Show” manually

1Press MEMORY STICK to display the “Memory Stick Home”. 2 Move up or down to select “Slide Show”, then press .

The “Slide Show” menu appears. 3 Move 4 Move up or down to select “Manual”, then press . 5 Move up or down to select “Start”, then press .

If you move right, the next still image or movie appears; if you

move

up or down to select “Advance”, then press .

left, the previous still image or movie appears.

To change the slide advance interval

You can select a time interval with which still images or movies change, from among “5 sec”, “10 sec”, “30 sec”, “1 min”, “5 min” and “10 min”. The factory setting is “5 sec”.

The interval can be changed when “Advance” in the “Slide Show” menu is set to “Auto”.

1Press MEMORY STICK to display the “Memory Stick Home”. 2 Move

The “Slide Show” menu appears. 3 Move up or down to select “Interval”, then press . 4 Move

press . 5 Move up or down to select “Start”, then press .

The “Slide Show” starts.

up or down to select “Slide Show”, then press .

up or down to select the interval you want to set, then

To start the “Slide Show” from the specified still image or movie

1Press MEMORY STICK to display the “Memory Stick Home”. 2 Move up or down to select the still image or movie from which

you want to start the “Slide Show”, then press

The “Memory Stick Home” (index menu) appears. 3 Move up or down to select “Slide Show”, then press .

.

continued

49Advanced Operations

Using a “Memory Stick” viewer (continued)

Notes

• The “Movie Player” (page 55) cannot be displayed when “Advance” is set to “Auto”.

•You cannot specify the interval when “Advance” is set to “Manual”.

• When “Advance” is set to “Auto”, a movie file is played to the end regardless of the specified interval. When playback is finished, the next image file is displayed.

• The “Interval” setting does not show the exact time, because the time required for displaying an image depends on its file size.

50

Advanced Operations

Viewing a still image on the full screen

DRC-MF

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

MEMORY STICK

Move up/down/right/

3

left to select the still image you want to view, then press

.

The still image index menu appears.

Move up or down to

4

select “Full Screen”, then press

.

The selected still image is displayed on the full screen.

To go to the previous or next still image, move left or right.

Memory Stick Home

Slide Show Options

Filter : Still

Select Folder

Digi. Cam. Mode

Still image index menu

No : 123/1234 Size : 1024x768

File : 100MSDCF/SJP0001.JPG Date : 2003.MAY.31 1:00PM

Full Screen

Slide Show

Delete

Close

No : 1/1234

No : 1/1234 Size : 1024x768

Size : 1024x768

Menu :

Protect Rotate Startup

File : 100MSDCF/SJP0001.JPG

File : 100MSDCF/SJP0001.JPG Date : 2003.MAY.31 1:00PM

Date : 2003.MAY.31 1:00PM

continued

51Advanced Operations

Using a “Memory Stick” viewer (continued)

Press .

5

The image setup menu appears.

To display another still image that is not the previous or next image, move

up to select “Return”, then press . The “Memory Stick Home” appears.

Image setup menu

Return

Information

On

Protect Rotate

Delete

Close

No : 1/1234 Size : 1024x768

Select : Back : Select :

File : 100MSDCF/SJP0001.JPG Date : 2003.MAY.31 1:00PM

File information

Tip

• The file information automatically appears at the bottom right when a still image is displayed on the full screen. You can turn off the display of file information by setting “Information” in the image setup menu to “Off”.

Notes

• The full screen display may be rough depending on the still image quality.

• Small size images may not be enlarged on the full screen.

• Displaying a large file will take a longer time.

• If an index menu, a still image or a moving picture in pause is left for 60 minutes, the display returns to the normal display.

52

Advanced Operations

Rotating a still image

You can rotate a thumbnail of the still image that you have selected from the “Memory Stick Home” or a still image displayed on the full screen, in 90 degree increments clockwise or counterclockwise.

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

DRC-MF

INDEX

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up/down/right/

3

left to select the still image you want to rotate, then press

.

The still image index menu

Memory Stick Home

Slide Show Options

Filter : Still Select Folder

Digi. Cam. Mode

appears.

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

A/B

V CENTER

P

R

N

I

O

W

G

T

HD/DVD

+

MENU

–

G

W

O

I

R

N

P

PROG

Still image index menu

Full Screen

Slide Show

Protect Rotate Startup

Delete

Close

MEMORY STICK

No : 123/1234 Size : 1024x768

Move up or down to select “Rotate”, then press .

4

Move up or down to select the rotating direction “ ”

5

(clockwise) or “

”(counterclockwise) , then press .

Each time you press , the still image is rotated 90 degrees.

Move down to select “Close”, then press .

6

The rotated image is stored.

File : 100MSDCF/SJP0001.JPG Date : 2003.MAY.31 1:00PM

continued

53Advanced Operations

Using a “Memory Stick” viewer (continued)

To rotate a full screen image

1 After displaying an image on the full screen (see page 51), press

.

The image setup menu appears. 2 Move up or down to select “Rotate”, then press . 3 Move up or down to select the rotating direction, then press

.

Each time you press , the still image is rotated 90 degrees in the

selected direction. 4 Move down to select “Close”, then press .

Notes

•You cannot rotate movie files.

•You cannot rotate a still image that has been protected (see page 59).

Confirm the protect icon in the file information and unlock the protect

before rotating.

•You cannot rotate a still image if the “Memory Stick” is locked.

54

Advanced Operations

Playing movies — Movie Player

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

INDEX

PROG

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up/down/right/

3

left to select the movie you want to play, then press

.

The movie index menu appears.

Memory Stick Home

Slide Show Options

Filter : Still

Select Folder

Digi. Cam. Mode

A/B

V CENTER

P

R

N

I

O

W

G

T

+

MENU

–

T

G

W

O

I

R

N

P

HD/DVD

Movie index menu

Movie Player

Slide Show

Protect

Rotate Startup

Delete

Close

MEMORY STICK

No : 124/1234 Size : 320x240

File : 100MSDCF/BASEBALL.MPG Date :

2003.MAY.31 1:00PM

continued

55Advanced Operations

Using a “Memory Stick” viewer (continued)

Move up or down to

4

select “Movie Player”, then press

.

The Movie Player appears.

Return

Full Screen

Menu

No : 124/1234 Size : 320x240

File : SJP0001.MPG Date :

2003.MAY.31 1:00PM

Movie Player Operation menu

Item To

“Return” return to the “Memory Stick Home”.

“B / X” play the movie. Select this item during playback to

“x” stop playback.

“.” Move left during movie stop mode to display the

“>” Move right during movie stop mode to display the

“Full Screen” display the movie full screen.

“Menu” display the movie setup menu to access additional

Notes

• If you select . or > during the movie stop mode, it may take a longer time to load the previous or next file. During loading the file, “Return” lights up. If you press when “Return” is lit, the projection TV returns to the “Memory Stick Home”.

• If a moving picture in pause is left for 60 minutes, the display returns to the normal display.

•“m” (Fast-reverse) and “M” (Fast-forward) may not work due to the movie file.

pause playing.

previous file on the ”Memory Stick”. During playback, the control changes to “m” (Fast-reverse) and the movie is rewound rapidly.

next file on the ”Memory Stick”. During playback, the control changes to “M” (Fast-forward) and the movie is forwarded rapidly.

options.

56

Advanced Operations

Move up or down to select “B / X”, then press .

5

The movie playback starts. At the end of the movie, it returns to the beginning and stops.

To stop playback manually, move

up or down to select “x” and

press .

To select the sound

1 On the Movie Player screen, move up or down to select

“Menu”, then press . The Movie setup menu appears.

Movie setup menu

Return

Information On

Audio Select

Full Screen

Menu

2 Move up or down to select “Audio Select”, then press . 3 Move up or down to select the sound to be heard, then press

.

L/R

Protect

Delete

Close

No : 124/1234 Size : 320x240

File : SJP0001.MPG Date :

2003.MAY.31 1:00PM

Audio Select menu and selectable sounds

Item Stereo program Bilingual program

L/R left and right sounds main and sub sounds

L left sound main sound

R right sound sub sound

Note

• The ”Audio Select” menu is disabled when the movie does not contain sound.

continued

57Advanced Operations

Using a “Memory Stick” viewer (continued)

To display the movie on the full screen

1 Display the Movie Player, following steps 1 to 4 on page 55. 2 Move up or down to select “Full Screen”, then press .

The movie is displayed on the full screen, and playback starts automatically.

To return to the Movie Player

During movie playback, move up/down/right/left or press .

Notes

• Small size movies may not be enlarged on the full screen.

• The full screen display may be rough depending on the movie qualify.

• Enlarging a file may take a time and a short file may not be played.

•“m” and “M” are disabled when a movie is displayed on the full screen.

58

Advanced Operations

Protecting still images or movies

You can protect a still image or movie from inaccidental erasure. The protect can be unlocked.

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

DRC-MF

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

MEMORY STICK

MENU

Move up/down/right/

3

left to select the movie you want to protect, then press

.

The still image or movie

Memory Stick Home

Slide Show Options

Filter : Still Select Folder

Digi. Cam. Mode

index menu appears.

Move up or down to select “Protect”, then press .

4

Move up or down to select “On”, then press .

5

The (protect) icon is displayed.

To unlock the protect, select “Off”, then press .

Still image or movie index menu

Full Screen

Slide Show

Protect Rotate Startup

Delete

Close

No : 123/1234 Size : 1024x768

File : 100MSDCF/SJP0001.JPG Date : 2003.MAY.31 1:00PM

continued

59Advanced Operations

Using a “Memory Stick” viewer (continued)

To protect a full screen image

1 After displaying a still image on the full screen (see page 51),

press .

The image setup menu appears. 2 Move 3 Move up or down to select “On”, then press .

up or down to select “Protect”, then press .

To protect a movie on the Movie Player

1 After displaying the Movie Player (see page 55), move up or

down to select “Menu”, then press .

The movie setup menu appears. 2 Move 3 Move up or down to select “On”, then press .

Tip

• The property of the protected image is shown as “Read-only” on a

computer.

up or down to select “Protect”, then press .

60

Advanced Operations

Deleting a still image or movie

You can delete unnecessary still image and movie files from the “Memory Stick”. Before deleting, make sure they are really unnecessary because the deleted images cannot be restored.

Insert a “Memory Stick” into the “Memory Stick” slot of the proection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

DRC-MF

INDEX

PROG

E

M

W

T

W

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

A/B

V CENTER

P

R

N

I

O

G

+

MENU

–

G

O

I

R

N

P

MEMORY STICK

Move up/down/right/

3

left to select the movie you want to delete, then press

.

The still image or movie

Memory Stick Home

Slide Show Options

Filter : Still Select Folder

Digi. Cam. Mode

index menu appears.

Move up or down to select “Delete”, then press .

4

Move up to select “Selected”, then press .

5

A confirmation message appears.

Move left to select “Yes”, then press .

6

To cancel deleting, select “No”, then press .

Still image or movie index menu

Full Screen

Slide Show

Protect Rotate Startup

Delete

Close

No : 123/1234 Size : 1024x768

File : 100MSDCF/SJP0001.JPG Date : 2003.MAY.31 1:00PM

continued

61Advanced Operations

Using a “Memory Stick” viewer (continued)

Notes

• When “Digi. Cam. Mode” is set to “On”, deleting a file with the Relative file icon deletes the other related files at the same time. (See page 46).

• Before performing deleting, confirm the file information.

•You cannot delete protected image (see page 59). First unlock the protect.

• If the erasure prevention switch on the “Memory Stick” is in the LOCK position, you cannot delete the still images and movies in that “Memory Stick”.

To erase a full screen image

1 After displaying a still image on the full screen (see page 51), press

.

The image setup menu appears.

2 Move up or down to select “Delete”, then press . 3 Move

up to select “Selected”, then press .

A confirmation message appears.

4 Move left to select “Yes”, then press .

To erase a movie on the Movie Player

1 After displaying the Movie Player (see page 55), move up or

down to select “Menu”, then press . The movie setup menu appears.

2 Move 3 Move up to select “Selected”, then press . 4 Move left to select “Yes”, then press .

up or down to select “Delete”, then press .

62

Advanced Operations

Displaying the current status of “Memory Stick”

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

You can display the “Memory Stick” type, total capacity, used capacity and free capacity of the “Memory Stick”.

DRC-MF

INDEX

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up or down to select “Options”, then press .

3

The “Options” menu appears.

Move up or down to select “Memory Stick”.

4

The current status of the “Memory Stick” appears.

MEMORY STICK

continued

63Advanced Operations

Using a “Memory Stick” viewer (continued)

Selecting folders

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

To view the still images and movies stored in different folders using a computer, you need to select the folder.

DRC-MF

Before operating this function, make sure that “Digi. Cam. Mode” is set to “Off”.

Tip

• If you set “Digi. Cam. Mode” to “Off”, you can display more than 2,000 images and movies on the screen.

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up or down to select “Select Folder”, then press .

3

The “Select Folder” menu appears.

Move up or down to select “Digi. Cam. Mode”, then press .

4

Move up or down to

5

select “Off”, then press

.

Current folder Folder list

Memory Stick Home

Slide Show Options

Filter : Still Select Folder

Digi.Camera Mode

Off

MEMORY STICK

64

Advanced Operations

To upper stage

Close

No : Size :

File : Date :

First image or movie file included in the current folder

Move right to select the folder list.

6

Move up or down to select the folder which includes the file you want to

7

view, then press

Move up or down to select “Close”, then press or move left.

8

The still images and movies included in the selected folder are displayed on “Memory Stick Home”.

.

continued

65Advanced Operations

Using a “Memory Stick” viewer (continued)

Sorting images — Options

You can change the displaying order of the images in a “Memory Stick”, in alphabetical order by filename, in chronological order by recording date.

Before operating this function, make sure that “Digi. Cam. Mode” is set to “Off”.

• If you set “Digi. Cam. Mode” to “Off”, you can display more than 2,000 images and

DRC-MF

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

movies on the screen.

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up or down to select “Options”, then press .

3

The “Options” menu appears.

Move up or down to select “File”, then press .

4

Move up or down to select “Sort”, then press .

5

MEMORY STICK

Move up or down to select the desired item, then press .

6

66

Advanced Operations

Sort menu

Item To

Name Order

Date Order

Note

• If an image file has been processed by a computer, the modified date may be displayed for that file.

A

sort in alphabetical order (A to Z) by filename

m

Z

sort in reverse alphabetical order (Z to A) by filename

m

A

1

sort in chronological order by recording (1 to 9)

m

9

m

sort in reverse chronological order by recording (9 to 1)

1

Displaying either still images or movies — Options

You can display either the still images or the movies that are stored in a “Memory Stick”.

Before operating this function, make sure that “Digi. Cam. Mode” is set to “Off”.

Insert a “Memory Stick” into the “Memory Stick” slot of the projection TV.

1

For details on inserting a “Memory Stick”, see page 44.

Press MEMORY STICK to display the “Memory Stick Home”.

2

Move up or down to select “Options”, then press .

3

The “Options” menu appears.

Move up or down to select “File”, then press .

4

Move up or down to select “Filter”, then press .

5

DRC-MF

INDEX

PROG

M

T

HD/DVD

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

MEMORY STICK

Move up or down to select the desired item, then press .

6

Filter menu

Item Images to be displayed

“Show Stills” Still images only

“Show Movies” Movies only

“Off” Still images and movies

Tip

• If“Show Stills” or “Show Movies” is selected on “Filter” , the selected image type (still image or movie) is displayed on “Memory Stick Home”.

continued

67Advanced Operations

Adjusting Your Setup (MENU)

Introducing the menu system

The MENU button lets you open a menu and change the settings of your projection TV. The following is an overview of the menu system.

Menu level 1

Picture icon

Sound icon

Memory Stick icon

Wide Screen icon

Multi Picture icon

Setup icon

S e t u p

O f f A u t o

O f f

E n g l i s h

L a n g u a g e : Convergence Channel Setup G a m e M o d e : V i d e o L a b e l C o l o r S y s t e m : E c o M o d e :

S e l e c t : C o n f i r m : E n d :

Name of the current menu Return icon

Menu level 3

Navigation Help

Menu level 2

Selecting some items in Menu level 2 of Setup menu displays another menu (Menu level 3), and selecting some options in this menu also displays the adjustment menu (Menu level 4).

C h a n n e l S e t u p

A u t o P r o g r a m M a n u a l P r o g r a m T V S y s t e m : B/G P r o g r a m L a b e l P r o g r a m B l o c k P r o g r a m Edit

S e l e c t : C o n f i r m : E n d :

Level 1

“Picture”

“Sound”

Menu level 3

Level 2/Level 3

“DRC-MF”

“Picture Mode”

“Picture Adjustment”

“3D-NR” “Sound Mode”

“Sound Adjustment”

“Balance”

“Intelligent Volume”

“Surround”

“Speaker”

Level 3/Level 4/Function

Selects the “DRC-MF” mode: “DRC1250” t “DRC100” t “Progressive”

Selects the picture mode: “Dynamic” t “Standard” t “Hi-Fine” t “Personal”

Adjusts the “Personal” option: “Picture” t “Brightness” t “Color” t “Hue” t “Sharpness” t “Color Temperature” t “Reset”

Activates or deactivates picture noise reduction mode. Selects the sound mode:

“Dynamic” t “Drama” t “Soft” t “Personal” Adjusts the “Personal” option:

“Treble” t “Bass” t “BBE”* t “Reset” Adjusts the balance between the left and right speaker

volume. Activates or deactivates the Intelligent Volume feature.

Selects the “Surround” mode: “TruSurround” t “Simulated” t “Off”

Selects the speaker mode: “MAIN” or “CENTER IN”.

A u t o P r o g r a m

P r o g r a m : T V S y s t e m : V H F L o w :

0 9 A u t o

C o n f i r m :S e l e c t : E n d :

Menu level 4

* Licensed by BBE Sound, Inc. under USP4638258, 4482866.

“BBE” and BBE symbol are trademarks of BBE Sound, Inc.

68

Adjusting Your Setup (MENU)

Level 1

“Memory Stick”

“Wide Screen”

“Multi Picture”

“Setup”

Level 2/Level 3

“Memory Stick

Menu”

“Wide Mode”

“Auto Wide” “4:3 Default”

“V Center”

“Twin” “Swap” “Program Index” “Language”

“Convergence”

“Digital Quick Focus”

“Manual Adjust”

“Channel Setup”

“Auto Program”

“Manual Program”

“TV System” “Program

Label” “Program

Block”

“Program Edit” “Game Mode” “Video Label”

“Video Input”

Level 3/Level 4/Function

Display still pictures and movies stored in a “Memory Stick”. You can also display this menu by pressing MEMORY STICK on the remote.

Select the wide screen mode: “Wide Zoom” t “Normal” t “Full” t “Zoom”

Select an optimum wide screen mode automatically. Change the picture to “Wide Zoom” or “Normal” when

the normal 4:3 picture with ID-1 or 480i/480p format signal without ID-1 is received.

Adjust the vertical position of the picture in “Wide Zoom” or “Zoom” mode.

Display a TV program beside the main screen. Swap the pictures between the left and right screens. Scroll all tuned programs one by one for direct selection. Change the menu language:

“English” t “ ” (Chinese) t “ ” (Arabic) Adjust the Convergence. Adjust the convergence automatically.

The manual adjustment screen appears. Adjust the convergence manually.

Preset channels, or select the TV system. The “Auto Program” menu is displayed.

Preset channels automatically. The “Manual Program” menu is displayed.

Preset channels manually. Select the TV system:

“B/G” t “I” t “D/K” t “M” Assign labels (such as station names) to the preset

channels. Lock out specific channels.

Changes the order of the preset channels. Activate or deactivate GAME MODE feature. Assign labels to the audio/video equipment connected to

the TV. Select the input to which the audio/video equipment is

connected. “Video 1” t “Video 2” t “Video 3” t “Video 4” t “HD/DVD 1” t “HD/DVD 2”

Adjusting Your Setup (MENU)

continued

69Adjusting Your Setup (MENU)

Introducing the menu system (continued)

Level 1

“Setup”

Level 2/Level 3

“Label”

“Color System”

“Eco Mode”

“S Input”

To restore the factory settings

Press the RESET button on the remote. The settings other than the following items in the menu can be reset

by using the RESET button: – “Language” – “Convergence” – “Program” and “Skip” in “Manual Program” – “Fine” in “Manual Program” – “TV System” – “Memory Stick Menu” items – “Personal” in “Picture mode”/“Sound mode” – “Program Label” – “Video Lavel”

Level 3/Level 4/Function

Selects one of the prefixed labels or assign your own label in “Edit” position. “Video 1” t “VCR” t “SAT” t “Game” t “Edit”

Selects the color system: “Auto” t “PAL” t “SECAM” t “NTSC3.58” t “NTSC4.43”

Activates or deactivates ECO MODE feature. Selects the S video input mode: “Auto” or “Off”.

70

Adjusting Your Setup (MENU)

How to use the menu

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

DRC-MF

INDEX

PROG

123 456 7809

JUMP

PROG

Press MENU to display the menu.

MENU

Move the button joystick ( ) up, down, left or right to select the desired item.

W

T

W

Press the button joystick (

) to confirm the selection and/or go to the next level.

Other menu operations

To

Adjust the setting value Move to the next/previous menu level Cancel the menu

MENU

P

R

N

I

R

N

P

N

I

W

T

W

I

N

P

P i c t u r e

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

3 D - N R :

S e l e c t : C o n f i r m : E n d :

M u l t i P i c t u r e

O

G

+

–

G

O

T w i n :

O n S w a p P r o g r a m I n d e x

S e l e c t : C o n f i r m : E n d :

M u l t i P i c t u r e

R

O

G

+

–

G

O

R

T w i n :

O n S w a p P r o g r a m I n d e x

S e l e c t : C o n f i r m : E n d :

Press/Move

Move up, down, left or right. Move left or right. Press MENU.

D R C 1 2 5 0 P e r s o n a l

O ff

Tips

• If you want to exit from Menu level 2 to Menu level 1, move up or down until the return icon (3) is highlighted, then press .

• The MENU, (Enter), and 2 + or – buttons on the projection TV can also be used for the operations above.

Note

• If more than 90 seconds elapse between entries, the menu screen other than that for “Memory Stick” menu automatically disappears.

71Adjusting Your Setup (MENU)

Changing the “Picture” setting

The “Picture” menu allows you to: adjust the picture setting, view higher quality pictures and reduce picture noise.

Press MENU.

1

Move up or down to

2

select , then press .

Move up or down to

3

select the desired option (see the table below), then press

.

T

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

DRC-MF

INDEX

PROG

P i c t u r e

MENU

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

3 D - N R :

D R C 1 2 5 0 P e r s o n a l

Off

S e l e c t : C o n f i r m : E n d :

P i c t u r e

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

3 D - N R :

D R C 1 2 5 0 P e r s o n a l

Off

S e l e c t : C o n f i r m : E n d :

P i c t u r e

P

R

N

I

O

W

G

+

–

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

3 D - N R :

D R C 1 2 5 0

P e r s o n a l

D R C 1 0 0 P r o g r e s s i v e

O ff

S e l e c t : C o n f i r m : E n d :

Select To

“DRC-MF” activate the Digital Reality Creation-Multi function feature to

“Picture Mode” receive suitable picture mode.

* When the “Personal” mode is selected, the last adjusted picture setting in the “Picture

Adjustment” menu is received (see page 74).

72

Adjusting Your Setup (MENU)

display higher quality pictures. Move up or down to select “DRC1250”, “DRC100” or “Progressive”, then press .

Move up or down to select “Dynamic”, “Standard”, “Hi-Fine”, “Personal”*, then press .

Select To

“Picture Adjustment” adjust the picture quality when “Picture Mode” is set to

“Personal”.

A d j u s t m e n t

P i c t u r e

P i c t u r e B r i g h t n e s s C o l o r H u e0 0 S h a r p n e s s C o l o r T e m p e r a t u r e :N e u t r a l R e s e t

S e l e c t : C o n f i r m : E n d :

8 0 5 0 5 0

5 0

“3D-NR” improve the picture quality of TV or video if a signal received is

weak. Move up or down to select “On”, then press . To cancel, select “Off”, then press .

Tips

• For details on the options under the “DRC-MF” and “Picture Mode” modes, see pages 20 and 21, respectively.

• When high-definition (HD) or progressive signals are input, “DRC-MF” does not function.

• When using the “Memory Stick” viewer, “3D-NR” does not function.

• Some items of the “Picture Adjustment” menu are not available for the pictures stored in a “Memory Stick”.

To return to the normal screen

Press MENU.

continued

73Adjusting Your Setup (MENU)

Changing the “Picture” setting (continued)

Adjusting the “Picture Adjustment” options

You can access the “Picture Adjustment” menu only when you have selected “Personal” for “Picture Mode”.

Display the “Picture” menu and select “Personal” for “Picture Mode”.

1

A d j u s t m e n t

Move up or down to

2

select “Picture

P

R

N

I

O

W

G

T

+

P

R

N

I

O

W

G

T

+

Adjustment”, then press

.

Move up or down to

3

select the desired item

–

T

G

W

O

I

R

N

P

N

I

W

T

–

T

G

W

O

I

R

N

P

R

O

G

+

(e.g., “Color”), then press

.

Adjust the value or select the desired option according to the following

4

table, then press

.

–

T

G

W

O

I

R

N

P

P i c t u r e

P i c t u r e B r i g h t n e s s C o l o r H u e0 0 S h a r p n e s s C o l o r T e m p e r a t u r e :N e u t r a l R e s e t

S e l e c t : C o n f i r m : E n d :

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Color

8 0 5 0 5 0

5 0

08

For

“Picture” “Brightness” “Color” “Hue”* “Sharpness” “Color Move up or down to select “Cool”, “Neutral” or “Warm”.

Temperature” “Reset” Select “Reset” and press to reset the picture to the factory preset

Repeat steps 3 and 4 to adjust other items.

5

The adjusted settings will be received when you select “Personal”.

74

Adjusting Your Setup (MENU)

Move down or left to

decrease picture contrast darken the picture decrease color intensity increase red picture tones soften the picture

Move up or right to

increase picture contrast brighten the picture increase color intensity increase green picture tones sharpen the picture

settings.

*You can adjust “HUE” for the NTSC color system only.

Changing the “Sound” setting

The “Sound” menu allows you to adjust the sound setting and adjust the volume automatically. You can also listen to the sound with surround effect.

Press MENU.

1

Move up or down to

2

select , then press .

Move up or down to

3

select the desired option

P

N

I

W

T

(see the table below), then press

.

T

W

I

N

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

INDEX

PROG

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

T

+

MENU

–

T

G

W

O

I

R

N

P

P i c t u r e

MENU

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

3 D - N R :

D R C 1 2 5 0 P e r s o n a l

O ff

S e l e c t : C o n f i r m : E n d :

S o u n d

S o u n d M o d e :P e r s o n a l

S o u n d A d j u s t m e n t B a l a n c e I n t e l l i g e n t V o l u m e : O f f S u r r o u n d :

S p e a k e r :

O f f

M A I N

0 0

S e l e c t : C o n f i r m : E n d :

S o u n d

R

O

G

+

–

G

O

R

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

S o u n d M o d e :

S o u n d A d j u s t m e n t B a l a n c e I n t e l l i g e n t V o l u m e : O f f S u r r o u n d : S p e a k e r :

O f f M A I N

D y n a m i c D r a m a

5 0

S o f t P e r s o n a l

S e l e c t : C o n f i r m : E n d :

Select To

“Sound Mode” select the suitable sound mode.

Move up or down to select “Dynamic”, “Drama”, “Soft” or “Personal”*, then press .

* When the “Personal” mode is selected, the last adjusted sound

setting in the “Sound Adjustment” menu is received (see page

77).

“Sound Adjustment” adjust the sound quality when “Sound Mode” is set to “Personal”.

S o u n d A d j u s t m e n t

T r e b l e B a s s B B E :O f f R e s e t

5 0 5 0

S e l e c t : C o n f i r m : E n d :

continued

75Adjusting Your Setup (MENU)

Changing the “Sound” setting (continued)

Select To

“Balance” adjust the balance between the left and right speaker volume.

“Intelligent Volume” adjust the volume of all TV programs and video inputs

“Surround” select the Surround mode.

“Speaker” select if you use the projection TV’s speakers as the center speaker

Tip

• For details on the options under the “Sound Mode” and “Surround”

Move down or left to increase the left speaker’s volume, up or right to increase the right speaker’s volume, then press .

automatically. Move up or down to select “On” to activate the Intelligent Volume feature, then press . To cancel, select “Off”, then press .

Move up or down to select “TruSurround”, “Simulated” or “Off”, then press .

of your audio system. Normally select “MAIN”. When you want to use the projection TV’s speakers as the center speaker, move up or down to select “CENTER IN”, then press .

modes, see pages 20 and 31, respectively.

To return to the normal screen

Press MENU.

76

Adjusting Your Setup (MENU)

Adjusting the “Sound Adjustment” options

You can access the “Sound Adjustment” menu only when you have selected “Personal” for “Sound Mode”.

Display the “Sound” menu and select “Personal” for “Sound Mode”.

1

Move up or down to

2

select “Sound Adjustment”, then press

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

S o u n d A d j u s t m e n t

T r e b l e B a s s B B E :O f f R e s e t

S e l e c t : C o n f i r m : E n d :

Move up or down to

3

select the desired item (e.g., “Treble”), then press

.

Adjust the value or select the desired option according to the following

4

table, then press .

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Treble 50

For Move

“Treble” down or left to decrease the treble, up or right to increase the

treble. “Bass” down or left to decrease the bass, up or right to increase the bass. “BBE” up or down to select “High”, “Low” or “Off”.

“BBE” can produce clear sound. “Reset” Select “Reset” and press to reset the sound to the factory preset

settings.

Repeat steps 3 and 4 to adjust other items.

5

The adjusted settings will be received when you select “Personal”.

5 0 5 0

Note

•You cannot change the “BBE” mode when the TV is in the center speaker mode (page 39).

77Adjusting Your Setup (MENU)

Entering the “Memory Stick” menu

The “Memory Stick” menu allows you to view still pictures and movies stored in a “Memory Stick”.

Insert a “Memory Stick” into the “Memory Stick” slot. For details on using a “Memory Stick”, see pages 40 to 67.

Press MENU.

1

Move up or down to

2

select , then press .

Make sure that “Memory

3

Stick Menu” is selected, then press

.

For details on the options under the “Memory Stick Menu”, see pages 45 to 67.

P

R

N

I

O

W

G

T

W

O

I

R

N

P

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

DRC-MF

INDEX

PROG

P i c t u r e

MENU

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

3 D - N R :

D R C 1 2 5 0 P e r s o n a l

O ff

S e l e c t : C o n f i r m : E n d :

M e m o r y

P

R

N

I

O

W

G

+

–

G

T

+

–

T

G

W

O

I

R

N

P

S t i c k

M e m o r y S t i c k M e n u

S e l e c t : C o n f i r m : E n d :

Memory Stick Home Slide Show

Option

Filter : Still

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Select Folder

Dig. Cam. Mode

No :

File :

Size :

Date :

78

Adjusting Your Setup (MENU)

Tip

• If you select the “Memory Stick” menu in the TWIN or PROGRAM INDEX mode, the TWIN or PROGRAM INDEX mode is cancelled.

Changing the “Wide

DRC-MF

INDEX

PROG

M

E

M

W

T

W

HD/DVD

P i c t u r e

D R C - M F : P i c t u r e M o d e :

3 D - N R :

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

K

A/B

V CENTER

P

R

N

I

O

G

+

MENU

–

G

O

I

R

N

P

P i c t u r e A d j u s t m e n t

Screen” setting

The “Wide Screen” menu allows you to watch the picture filling the 16:9 screen of the projection TV.

Press MENU.

1

MENU

S e l e c t : C o n f i r m : E n d :

Move up or down to

2

select

, then press .

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

W i d e S c r e e n

W i d e M o d e :

A u t o W i d e : 4 : 3 D e f a u l t : V C e n t e r : 0 0 V S i z e :

S e l e c t : C o n f i r m : E n d :

Move up or down to

3

select the desired option (see the table below), then press

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

W i d e S c r e e n

W i d e M o d e : A u t o W i d e : 4 : 3 D e f a u l t : V C e n t e r : 0 0

S e l e c t : C o n f i r m : E n d :

Select To

“Wide Mode” select the desired wide screen mode to fit the 16:9 screen.

Move up or down to select “Wide Zoom”, “Normal”, “Full” or “Zoom”, then press . For details on each mode, see “Using wide screen mode” on page 22.

“Auto Wide” automatically display the picture in optimum wide screen mode.

Move up or down to select “On” (factory setting), then press . Select “Off” if you want to display any picture in currently selected wide screen mode.

“4:3 Default” display a 4:3 picture in “Wide Zoom” (factory setting) or in

“Normal” mode. Move up or down to select “Wide Zoom” or “Normal”, then press .

D R C 1 2 5 0 P e r s o n a l

O ff

W i d e Z o o m O n W i d e Z o o m

0 0

W i d e Z o o m

O n

N o r m a l

W i d e Z o o m

F u l l Z o o m

continued

MENU

79Adjusting Your Setup (MENU)

Changing the “Wide Screen” setting (continued)

Select To

“V Center” adjust the vertical position of the picture within the screen in “Wide

Zoom” or “Zoom” mode. Move up or down to move the picture, then press .

Notes

• “4:3 Default” does not function when “Auto Wide” is set to “Off”.

• When a 720p or 1080i format signal is received, the picture is always displayed in Full mode.

To return to the normal screen

Press MENU.

80

Adjusting Your Setup (MENU)

Operating the “Multi Picture” using the menu

The “Multi Picture” menu allows you to use the TWIN pictures, or PROGRAM INDEX feature.

Press MENU.

1

Move up or down to

2

select

Move up or down to

3

select the desired option

, then press .

(see the table below), then press

.

N

I

W

T

W

I

N

I

W

T

W

I

N

VIDEO

PROG

MENU

D R C 1 2 5 0 P e r s o n a l

O ff

INDEX

MENU

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

DRC-MF

INDEX

PROG

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P i c t u r e

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

MENU

3 D - N R :

S e l e c t : C o n f i r m : E n d :

M u l t i P i c t u r e

P

R

O

G

+

–

G

O

R

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

T w i n :

O n S w a p P r o g r a m I n d e x

S e l e c t : C o n f i r m : E n d :

P

R

O

G

+

–

G

O

R

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Select To

“Twin” display a different TV program beside the main picture (TWIN).

Move up or down to select “On”, then press .

To cancel, press or select “Off”, then press . “Swap” swap the left and right pictures of the TWIN screen. “Program Index” view multiple programs on the sub-screens.

To cancel, press PROG INDEX.

To return to the normal screen

Press MENU.

81Adjusting Your Setup (MENU)

Changing the “Setup” setting

The “Setup” menu allows you to adjust the setup of your projection TV. For example, you can change the menu language, preset channels, etc.

Press MENU.

1

Move up or down to

2

select

, then press .

N

I

W

T

W

I

N

VIDEO

N

E

T

C

E

R

S

P

Y

R

S

T

O

I

C

M

K

E

M

T

HD/DVD

A/B

V CENTER

P

R

N

I

O

W

G

+

MENU

–

G

W

O

I

R

N

P

DRC-MF

INDEX

PROG

123

D R C 1 2 5 0 P e r s o n a l

O ff

O f f A u t o

O f f

Number buttons

456 7809

JUMP

P i c t u r e

D R C - M F : P i c t u r e M o d e :

P i c t u r e A d j u s t m e n t

MENU

P

R

O

G

+

–

G

O

R

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

3 D - N R :

S e l e c t : C o n f i r m : E n d :

S e t u p

L a n g u a g e : E n g l i s h Co n v e r g e n c e C h a n n e l S e t u p G a m e M o d e : V i d e o L a b e l C o l o r S y s t e m : E c o M o d e :

S e l e c t : C o n f i r m : E n d :

Move up or down to

3

select the desired option (see the table below), then press

Select To

“Language” change the menu language.

82

Adjusting Your Setup (MENU)

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Move up or down to select “English”, “ ” (Chinese), or “ ” (Arabic), then press .

Select To

“Convergence” adjust the convergence.

C o n v e r g e n c e

D i g i t a l Q u i c k F o c u s Ma n u a l A d j u s t

S e l e c t : C o n f i r m : E n d :

you can select automatic or manual convergence adjustment.

See “Adjusting the convergence manually” on page 85. “Channel Setup” preset channels.

C h a n n e l S e t u p

A u t o P r o g r a m M a n u a l P r o g r a m T V S y s t e m : D/K P r o g r a m L a b e l P r o g r a m B l o c k P r o g r a m Edit

S e l e c t : C o n f i r m : E n d :

You can select automatic or manual channel presetting.

See “Presetting channels manually” on page 86.

You can change the TV system by selecting “TV System”.

For “Program Label” and “Program Block”, see “Assigning labels

to the preset channels” on page 90 and “Blocking channels” on

page 91, respectively.

You can also change the order of the preset channels to preference.

See “Changing the order of the preset channels” on page 88. “Game Mode” adjust the picture setting that is suitable to view video games.

Move up or down to select “On”, then press .

To cancel, select “Off”, then press . “Video Label” assign labels to the connected audio/video equipment.

V i d e o L a b e l

V i d e o I n p u t : L a b e l :

V i d e o 1 V i d e o 1

S e l e c t : C o n f i r m : E n d :

See “Assigning labels to the connected audio/video equipment”

on page 92. “Color System” select the color system. Normally, set this to “Auto”.

You can select the color system for each channel or each video

input. “Eco Mode” reduce power consumption of your projection TV to save energy.

Move up or down to select “On”, then press .

To cancel, select “Off”, then press .

continued

83Adjusting Your Setup (MENU)

Changing the “Setup” setting (continued)

Select To

“S Input” select the S video input mode.

Notes

• If “Eco Mode” is on, the ECO MODE ( ) icon will appear at the bottom

• “Game Mode” is available only when receiving signals through the t

• When high-definition (HD) signals or progressive signals are input,

• “Language” selection is disabled when the “Memory Stick” viewer is

Move up or down to select “Auto” to receive the S video signal automatically when the signals are input through both the (S video input) and (video input) jacks of the same video input channel, then press . To deactivate the S video input, select “Off”, then press .

right corner of the screen when you turn on the projection TV or when you press on the remote.

(video input), (S video input), or (component video input) jacks.

“Game Mode” does not function.

displayed.

To return to the normal screen

Press MENU.

84

Adjusting Your Setup (MENU)

Adjusting the convergence manually

After selecting

1

“Convergence”, move up or down to select “Manual Adjust”, then press

.

The cross pattern appears on the screen.

Move up, down, left

2

or right to adjust the red lines until they converge with the green lines, then press

Move up, down, left

3

or right to adjust the blue

.

lines until they converge with the center cross pattern, then press

.

To return to the normal screen

Press MENU.

Tip

• Selecting “Digital Quick Focus” under “Convergence” allows you to adjust the convergence automatically. When the Digital Quick Focus feature is performed, manual adjustment values are erased.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Adjust : Mm< , Next Color :

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

Adjust : Mm< , Finish :

Notes

• Adjust convergence about 20 – 30 minutes after the projection TV is first turned on.

•You cannot use the 2 +/– buttons on the projection TV for manual convergence adjustment.

continued

85Adjusting Your Setup (MENU)

Changing the “Setup” setting (continued)

Presetting channels manually

After selecting “Channel

1

Setup”, move up or down to select “Manual Program”, then press

P

R

N

I

O

W

G

T

+

–

T

G

W

.

O

I

R

N

P

R

N

I

O

W

T

W

O

I

R

N

P

M a n u a l P r o g r a m

G

+

–

G

P r o g r a m : T V S y s t e m : V H F L o w F i n e : A u t o S k i p : O f f

S e n s i t i v i t y : H i g h

0 9 B/G

S e l e c t : C o n f i r m : E n d :

Select the program

2

number to which you want to preset a channel.

(1) Make sure “Program” is

selected, then press

(2) Move up or down until

the program number you want to preset (e.g., program number “10”) appears on the menu, then press

Tip

•You can also select the program number with the PROG +/– or number buttons.

Select the desired channel.

3

(1) Move

.

up or down to

select either “VHF Low”, “VHF High”, or “UHF”, then press

.

(2) Move up or down

until the desired channel’s broadcast appears on the TV screen, then press

If the sound of the

4

desired channel is abnormal, select the appropriate TV system.

(1) Move

up or down to

select “TV System”, then press .

(2) Move up or down

until the sound becomes normal, then press .

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : A u t o S k i p : O f f

S e n s i t i v i t y : H i g h

0 9

B/G

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : S k i p : O f f

S e n s i t i v i t y : H i g h

1 0

B/G A u t o

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : A u t o S k i p : O f f

S e n s i t i v i t y : H i g h

1 0 B/G

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : A u t o S k i p : O f f

S e n s i t i v i t y : H i g h

1 0 B/G

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : A u t o S k i p : O f f

S e n s i t i v i t y : H i g h

1 0

B / G

I D/K M

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : A u t o S k i p : O f f

S e n s i t i v i t y : H i g h

1 0

I

S e l e c t : C o n f i r m : E n d :

86

Adjusting Your Setup (MENU)

If you are not satisfied with

5

the picture and sound quality, you may be able to improve them by using the “Fine” tuning feature.

(1) Move

up or down to select “Fine”, then press .

(2) Move

up or down to select “Manual”, then press .

(3) Move

either up, down, left or right until the picture and sound quality are optimal, then press

. The + or – icon on the menu flashes while tuning.

If the TV signal is too

6

strong and the picture is distorted, you can adjust the TV reception sensitivity.

(1) Move

up or down to select “

Sensitivity”, then

press .

(2) Move

up or down to select “Low”, then press .

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : S k i p : O f f

S e n s i t i v i t y : H i g h

1 0 I

A u t o M a n u a l – +

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : S k i p : O f f

S e n s i t i v i t y : H i g h

1 0 I

A u t o M a n u a l – +

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : S k i p : O f f

S e n s i t i v i t y : H i g h

1 0 I

M a n u a l

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : S k i p : O f f

S e n s i t i v i t y :

S e l e c t : C o n f i r m : E n d :

1 0

I

M a n u a l

H i g h L o w

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : M a n u a l S k i p : O f f

S e n s i t i v i t y : L o w

1 0 I

S e l e c t : C o n f i r m : E n d :

Notes

• The TV system (“TV System”) and the TV reception sensitivity (“ Sensitivity”) settings are memorized for each program number.

• If there is a locked channel (see page 91), while you are presetting in “VHF-Low” and “Fine” mode, that channel will be unlocked automatically.

continued

87Adjusting Your Setup (MENU)

Changing the “Setup” setting (continued)

Changing the order of the preset channels (“Program Edit”)

After performing “Auto Program” or “Manual Program”, you can change the preset channel assigned to each program number to preference.

After selecting “Program

1

Edit”under “Channel Setup”, make sure “Program” is selected, then press

Move up or down to

2

select the program number to which you want to assign another channel, then press

Move up or down to

3

select “Edit”, then press

.

Move up or down

4

until your preferred program appears on the screen, then press confirm that channel.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : Edit

0 9

S e l e c t : C o n f i r m : E n d :

P r o g r a m Edit

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : Edit

1 0

S e l e c t : C o n f i r m : E n d :

P r o g r a m Edit

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : Edit

1 0

S e l e c t : C o n f i r m : E n d :

P r o g r a m Edit

to

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : Edit

1 0

S e l e c t : C o n f i r m : E n d :

To change the channels assigned to other program numbers, select

5

“Program”, then repeat steps 1 to 4.

To return to the normal screen

Press MENU.

88

Adjusting Your Setup (MENU)

Skipping unwanted or unused channels (“Skip”)

After performing automatic channel presetting, you can erase unwanted or unused channels.

After selecting “Manual

1

Program” under “Channel Setup”, make sure “Program” is selected, then press

Move up or down

2

until the unused or

.

unwanted channel number appears, then press

Move up or down to

3

select “Skip”, then press

.

Move up or down to

4

select “On”, then press

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : M a n u a l S k i p : O f f

S e n s i t i v i t y : H i g h

0 9

B/G

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : M a n u a l S k i p : O f f

S e n s i t i v i t y : H i g h

0 6

B/G

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : M a n u a l S k i p :

S e n s i t i v i t y : H i g h

0 6 B/G

O n O f f

S e l e c t : C o n f i r m : E n d :

M a n u a l P r o g r a m

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : T V S y s t e m : V H F L o w F i n e : S k i p : O n

S e n s i t i v i t y : H i g h

0 6 B/G

M a n u a l

S e l e c t : C o n f i r m : E n d :

To disable other channels, select “Program”, then repeat steps 2 to 4.

5

To restore the skipped channel

Select “Off” in step 4.

To return to the normal screen

Press MENU.

continued

89Adjusting Your Setup (MENU)

Changing the “Setup” setting (continued)

Assigning labels to the preset channels (“Program Label”)

You can assign a label (such as station name) of up to 5 characters to each preset channel.

After selecting “Program

1

Label”under “Channel

P

R

N

I

O

W

G

T

+

P

R

N

I

O

W

G

T

+

P r o g r a m L a b e l

P r o g r a m :

0 9

_____

L a b e l :

Setup”, make sure

–

T

G

W

O

“Program” is selected, then press

Move up or down to

2

select the channel you

.

I

R

N

P

R

N

I

O

W

G

T

+

want to assign a label, then press

Move up or down to

3

select “Label”, then press

.

Move up or down to scroll through the label characters (A to Z, 0 to 9,

4

etc.), then press

.

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

to confirm the highlighted character.

To insert a blank, leave “_” and move right.

To change the confirmed character, move

left to

highlight it, then move

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

up or down to select the

–

T

G

W

O

I

R

N

P

S e l e c t : C o n f i r m : E n d :

P r o g r a m L a b e l

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : L a b e l :

1 0 _____

S e l e c t : C o n f i r m : E n d :

P r o g r a m L a b e l

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : L a b e l :

1 0 _____

S e l e c t : C o n f i r m : E n d :

P r o g r a m L a b e l

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : L a b e l :

1 0

A____

S e l e c t : C o n f i r m : E n d :

correct character.

Repeat step 4 to add up to 5 characters to the label.

5

To assign labels to other channels, select “Program”, then repeat steps 1 to

6

5.

To return to the normal screen

Press MENU.

90

Adjusting Your Setup (MENU)

Blocking channels (“Program Block”)

After selecting “Program

1

Block” under “Channel

P

R

N

I

O

W

G

T

Setup”, make sure “Program” is selected, then press

Move up or down to

2

select the desired channel

.

(e.g. 06), then press

Move up or down to

3

select “Block”, then press

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

.

T

G

W

O

I

R

N

P

R

N

I

O

W

T

.

T

W

O

I

R

N

P

Move up or down to

4

select “On”, then press

. To unlock the channel, select “Off”.

The lock symbol (

)

P

R

N

I

O

W

G

T

G

W

O

I

R

N

P

appears on the screen when “On” is selected.

If a locked channel is selected, the lock symbol appears on the screen.

P

R

N

I

O

W

G

+

–

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : B l o c k :

0 9

O f f

S e l e c t : C o n f i r m : E n d :

P r o g r a m B l o c k

P

R

N

I

O

W

G

+

–

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : B l o c k :

0 6 O f f

S e l e c t : C o n f i r m : E n d :

P r o g r a m B l o c k

P

R

N

I

O

G

+

–

G

W

G

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : B l o c k :

0 6

O n O f f

S e l e c t : C o n f i r m : E n d :

P r o g r a m B l o c k

P

R

N

I

O

W

G

+

–

T

+

–

T

G

W

O

I

R

N

P

P r o g r a m : B l o c k :

0 6 O n

S e l e c t : C o n f i r m : E n d :

6

To lock other channels, select “Program”, then repeat steps 2 to 4.

5

To return to the normal screen

Press MENU.

Note

• If you preset a locked channel manually (see page 86), that channel will be unlocked automatically.

continued

91Adjusting Your Setup (MENU)

Changing the “Setup” setting (continued)

Assigning labels to the connected audio/video equipment (“Video Label”)

You can assign one of the prefixed labels (such as VCR, SAT, etc.) or your favorite label to the audio/video equipment connected to the video inputs of the projection TV.

To assign a prefixed label

After selecting “Video

1

Label”, make sure “Video

P

R

N

I

O

W

G

T

+

P

R

N

I

O

W

G

T

+

Input” is selected, then press

Move up or down to

2

select the video input you

.

have connected the equipment you want to assign a label, then press

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

.

Move up or down to

3

select “Label”, then press

.

Move up or down to

4

select one of the prefixed labels, then press

To assign your favorite

.

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

R

N

I

O

W

G

T

+

–

T

G

W

O

I

R

N

P

label, see page 91.

To assign labels to other equipment, select “Video Input”,

5

then repeat steps 2 to 4.

V i d e o L a b e l

V i d e o I n p u t : L a b e l : V i d e o 1

V i d e o 1 V i d e o 2 V i d e o 3 V i d e o 4 H D / D V D 1 H D / D V D 2

S e l e c t : C o n f i r m : E n d :

V i d e o L a b e l

V i d e o I n p u t : L a b e l :

V i d e o 1 V i d e o 1

S e l e c t : C o n f i r m : E n d :

V i d e o L a b e l

V i d e o I n p u t : L a b e l :

V i d e o 1

V i d e o 1 VC R S A T G a m e E d i t [

_ _ _ _ _

S e l e c t : C o n f i r m : E n d :

V i d e o L a b e l

V i d e o I n p u t : L a b e l :

V i d e o 1 V CR

S e l e c t : C o n f i r m : E n d :

]

To return to the normal screen

Press MENU.

92

Adjusting Your Setup (MENU)

To assign your favorite label

1 Follow steps 1 to 3 on page 92 and select “Edit” in step 4, then

press .

2 Move

0 to 9, etc.), then press to confirm the highlighted character.

To insert a blank, leave “_” and move right. To change the confirmed character, move left to highlight it,

then move up or down to select the correct character.

3 Repeat step 2 to add up to 5 characters to the label.

up or down to scroll through the label characters (A to Z,

V i d e o L a b e l

V i d e o I n p u t : L a b e l :

S e l e c t : C o n f i r m : E n d :

V i d e o 1

V i d e o 1 V C R S A T G a m e E d i t [

V _ _ _ _

]

93Adjusting Your Setup (MENU)

Additional Information

Troubleshooting

If you have any problem while viewing your projection TV, please check the following troubleshooting guide. If the problem persists, contact your Sony dealer.

Symptom

Snowy picture

Noisy sound

Distorted picture

Noisy sound

Good picture

Noisy sound

Possible cause

• The connection is loose or the cable is damaged.

• Channel presetting is inappropriate or incomplete.

• The antenna type is inappropriate.

• The antenna direction needs adjustment.

• Signal transmission is low.

•Broadcast signals are too strong.

• The TV system setting is inappropriate.

• The sound of the right picture is selected when P&P pictures are displayed.

Solutions

• Check the antenna cable and connection on the projection TV, VCR and on the wall.

• Display the “Channel Setup” menu under the “Setup” menu and select “Manual Program” to preset the channel again.

• Check the antenna type (VHF/UHF). Contact a Sony dealer for advice.

• Adjust the antenna direction. Contact a Sony dealer for advice.

•Try using a booster.

• Display the “Channel Setup” menu under the “Setup” menu and select “Manual Program”. Then, select “ Sensitivity: Low”.

•Turn off or disconnect the booster if it is in use.

• If the sound of all the channels are noisy, display the “Channel Setup” menu under the “Setup”menu and select “Auto Program” to preset the channels again.

• If the sound of some channels is noisy, select the channel, then display the “Channel Setup” menu under the “Setup”menu and select the appropriate TV system (“TV System”).

•Press or .

Page

7

86

–

87

–

83

86

26

94

Additional Information

Symptom

No picture

No sound

Possible cause

• The power cord, antenna or VCR is not connected.

• The projection TV is not turned on.

Solutions

• Check the power cord, antenna and the VCR connections.

•Press I/1 on the remote.

•Press ! on the projection TV to turn off the projection TV for about five seconds, then turn it on again.

Page

7

17 18

Good picture

No sound

Dotted lines or stripes

Double images or “ghosts”

No color

• The volume level is too low.

• The sound is muted.

• The broadcast signal has a transmission problem.

• The sound of the right picture is selected when P&P pictures are displayed.

• There is local interference from cars, neon signs, hair dryers, power generators, etc.

•

Broadcast signals are reflected by nearby mountains or buildings.

• The antenna direction needs adjustment.

• Use of a booster is inappropriate.

• The color level setting is too low.

•

The color system setting is inappropriate.

• The antenna direction needs adjustment.

•Press 2 + to increase the volume level.

•Press % to cancel the muting.

•Press A/B until a better sound is heard.

•Press or .

• Do not use a hair dryer or other equipment near the projection TV.

• Adjust the antenna direction for minimum interference. Contact a Sony dealer for advice.

• Use a highly directional antenna.

• Use the fine tuning (“Fine”) function.

• Adjust the antenna direction. Contact a Sony dealer for advice.

•Turn off or disconnect the booster if it is in use.

•

Display the “Picture” menu and select “Personal” of “Picture Mode”, then adjust the “Color” level under “Picture Adjustment”.

• Display the “Setup” menu and check the color system (“Color System”) setting (usually set this to “Auto”).

• Adjust the antenna direction. Contact a Sony dealer for advice.

18

18 32

26

–

87

–

Additional Information

–

74

83

–

continued

95Additional Information

Troubleshooting (continued)

Symptom

Projection TV cannot receive stereo broadcast signal.

Stereo broadcast sound switches on and off or is distorted.

or The sound switches

between stereo and monaural frequently.

“100 appears at the top of the screen after approximately 10 seconds and there is no Teletext display.

Teletext display is incomplete (snowy picture or double images).

Lines moving across the TV screen.

Possible cause

• The stereo reception setting is inappropriate.

• The sound of the sub picture is selected when TWIN pictures are displayed.

• The connection is loose or the cable is damaged.

• The antenna direction needs adjustment.

• The broadcast signal has a transmission problem.

• The channel carries no Teletext broadcast.

• Connection is loose or the cable is damaged.

• The antenna direction is inappropriate.

• Signal transmission is too low.

• There is interference from external sources, e.g., heavy machineries, nearby broadcast station.

Solutions

•Press A/B until “Auto” appears on the screen.

•Press or .

• Check the antenna cable and connection on the projection TV, VCR and on the wall.

• Adjust the antenna direction. Contact a Sony dealer for advice.

•Press A/B until a better sound is heard.

—

•

Check the antenna cable and connection on the projection TV, VCR, and at the wall.

• Adjust the antenna direction. Contact a Sony dealer for advice.

•Try using a booster.

• Use the fine tuning (”Fine”) function.

Page

33

26

7

–

32

38

7

–

91

87

96

Additional Information

Symptom

The wide screen mode changes spontaneously when “Auto Wide” is “On”.

The images in the “Memory Stick” are not displayed.

“No Memory Stick” is displayed.

“Memory Stick error” is displayed.

“File error” is displayed.

“Format error” is displayed.

Possible cause

• During a transition between two programs, the TV detects the optimum wide screen mode. During this period, an irregular wide screen mode may appear.

• The wide screen mode is switched automatically according to the received signal with an ID-1 or S1 signal.

• The AUTO WIDE feature stops working temporarily when you have pressed

, and functions

again after a while.

• The “Memory Stick” is inserted inappropriately.

• The “Memory Stick” menu is not displayed.

• No photo or movie files are contained in the “Memory Stick”.

• The photo or movie image is processed by a computer.

• The “Memory Stick” is inserted inappropriately.

• The “Memory Stick” is irregular .

• The “Memory Stick” may be broken.

• The name of the selected file is not correct.

• The “Memory Stick” is not formatted correctly.

Solutions

—

•To fix in the manually selected wide screen mode, set “Auto Wide” to “Off” in the “Wide Screen” menu.

• Insert the “Memory Stick” correctly.

•Press the MEMORY STICK button.

• Insert a “Memory Stick” with photo or movie files.

• Set “Digi. Cam. Mode” to “Off” and select the folder.

• Insert the “Memory Stick” correctly.

• Remove the “Memory Stick” and insert it again.

• Insert another “Memory Stick”.

—

• Format it correctly using a digital camera or other equipment, or insert another “Memory Stick” formatted correctly.

Page

22

23

79

44

45

44

46

44

41

40

continued

97Additional Information

Troubleshooting (continued)

Symptom

“Too many files. Cannot enter Digital Camera Mode”. is displayed.

“Memory Stick type error” is displayed.

“No file” is displayed.

The file name is not displayed correctly.

“Memory Stick locked” is displayed.

“No movie file” is displayed.

“No still file” is displayed.

“Playback has been stopped. The file is broken.”

Possible cause

• When “Digi. Cam. Mode” is set to “On”, 2,000 files or less can be displayed.

• The inserted “Memory Stick” is not available for use with this TV.

• No photo or movie files available for playback are contained in the selected folder of the “Memory Stick” when “Digi. Cam. Mode” is set to “On”.

• No photo or movie files available for playback are contained in the selected folder of the “Memory Stick” when “Digi. Cam. Mode” is set to “Off”.

• The file name has been processed by a computer.

• The erasure prevention switch of the “Memory Stick” is in the LOCK position.

• “Show Movies” is selected from “Filter” of the “Options” menu and no movie files are contained in the selected folder.

• “Show Stills” is selected from “Filter” of the “Options” menu and no still image files are contained in the selected folder.

• The data in the movie file is broken.

Solutions

• Set “Digi. Cam. Mode” to “Off” and select the folder.

• Insert a “Memory Stick” available for use with this TV.

• Set “Digi. Cam. Mode” to “Off” and select the folder.

• Select another folder that contains photo or movie files.

—

• Unlock the switch.

• Select the folder with movie files.

• Select the folder with still image files.

—

Page

64

44

46

41

51

67

–

98

Additional Information

Symptom

Cannot play shooting games.

Projection TV cabinet creaks.

Static discharge is felt when touching the projection TV cabinet.

Possible cause

• Some shooting games which involve pointing a light beam at the projection TV screen with an electronic gun or rifle cannot be used with your TV. For detail, see the instruction manual supplied with the video game software.

• Changes in room temperature sometimes make the projection TV cabinet expand or contract, causing a noise. This does not indicate a malfunction.

• This is the same static discharge that is felt when touching metal door handles or car doors especially when the air is dry, for example in winter. This does not indicate a malfunction.

Solutions

__

—

Page

_

99Additional Information

Self-diagnosis function

Your projection TV is equipped with a self-diagnosis function. If there is a problem with your projection TV, the 1 (standby) indicator flashes red. The number of times the 1 indicator flashes indicates the possible causes.

1 indicator

PROG

MENU

1 Check that the 1 indicator flashes red a number of times between 3-second

intervals.

2 Count the number of times the 1 indicator flashes. 3 Press ! (main power) to turn off your projection TV. 4 Inform your nearest Sony service center about the number of times the 1

indicator flashed.

Be sure to note the model name and serial number located on the rear of your projection TV.

100

Additional Information

Sony KP-FW46, KP-FW51 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

WARNING

Using Your New projection TV

Getting Started

Connecting optional components

Watching the projection TV

Advanced Operations

Selecting the picture and sound modes

Viewing higher quality pictures

Using wide screen mode

Watching two programs at the same time

Displaying multiple programs

Listening with surround sound

Enjoying stereo or bilingual programs

Viewing Teletext

Operating optional components

Using the projection TV’s center speaker

Adjusting Your Setup (MENU)

Introducing the menu system

Changing the “Picture” setting

Changing the “Sound” setting

Entering the “Memory Stick” menu

Operating the “Multi Picture” using the menu

Changing the “Setup” setting

Additional Information

Troubleshooting

Self-diagnosis function
