Sony KDL-37M3000 Service Manual
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER DESTINATION
KDL-37M3000
KDL-37M3000
RM-YD021 US/CANADA/MEXICO
RM-YD021 CHILE/PERU
MA1
CHASSIS
ORIGINAL MANUAL ISSUE DATE: 9/2007
: UPDATED ITEM
☛
REVISION DATE SUBJECT
9/2007 No revisions or updates are applicable at this time.
9/2007 Added (Balancer Board) ETC-Inverter MT Board P/N to Exploded View Section 5-4. Replaced Page 60.
11/2007 Updated G5M PWB. Replaced Page 49.
1/2008 Corrected Ref. No. for LCD Panel and speakers. Replaced page 60.
LCD DIGITAL COLOR TELEVISION
9-883-766-04
Self Diagnosis
Supported model
SERVICE MANUAL
MODEL NAME REMOTE COMMANDER DESTINATION
KDL-37M3000
KDL-37M3000
RM-YD021 US/CANADA/MEXICO
RM-YD021 CHILE/PERU
MA1
CHASSIS
9-883-766-04
KDL-37M3000 RM-YD021
LCD DIGITAL COLOR TELEVISION
KDL-37M3000
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifi cations ................................................................................. 4
Warnings and Cautions .................................................................. 6
Safety-Related Component Warning .............................................. 7
Safety Check-Out ........................................................................... 9
Self-Diagnostic Function ............................................................... 10
SECTION 1: DISASSEMBLY ............................................................... 12
1-1. Rear Cover Removal ............................................................ 12
1-2. Arm, Under Cover and Stand Removal ................................ 12
1-3. HM1 Board Removal ............................................................ 13
1-4. UM Board and Jack Holder Removal ................................... 13
1-5. Speaker, Light Guide and HM3 Board Removal .................. 14
1-6. BM Board Removal .............................................................. 14
1-7. G5 Bracket and G5M Board Removal .................................. 15
1-8. Bracket Removal ................................................................... 15
1-9 LCD Panel and Inverter Board Removal .............................. 16
SECTION 2: WIRE DRESSINGS ......................................................... 17
2-1. Overall View ......................................................................... 17
2-2. LVDS Connector .................................................................. 18
2-3. LVDS Connector (Continued) ............................................... 19
2-4. HM3 Board and Speakers .................................................... 20
2-5. HM3 Board and Speakers (Continued) ................................ 21
2-6. G5M Board Connectors ....................................................... 22
2-7. HM1 Board ........................................................................... 23
2-8. Video 2 Cable ....................................................................... 24
2-9. AC Cord ............................................................................... 25
2-10. Tuner .................................................................................... 26
2-11. Tuner (Continued) ................................................................ 27
2-12. Tuner (Continued) ................................................................ 28
SECTION 3: SERVICE ADJUSTMENTS ............................................. 29
3-1. Using the Remote Commander for Electrical Adjustments .. 29
3-2. Accessing Service Adjustment Mode ................................... 29
3-3. Viewing the Service Menus .................................................. 30
3-4. Resetting to Factory Defaults ............................................... 30
SECTION 4: DIAGRAMS ..................................................................... 31
4-1. Circuit Boards Location ........................................................ 31
4-2. Printed Wiring Boards and
Schematic Diagrams Information ......................................... 31
4-3. Block Diagram ...................................................................... 33
4-4. Connection Diagram ............................................................ 34
4-5. Schematics and Supporting Information .............................. 35
BM Board Schematic Diagram (1 of 12) .............................. 35
BM Board Schematic Diagram (2 of 12) .............................. 36
BM Board Schematic Diagram (3 of 12) .............................. 37
BM Board Schematic Diagram (4 of 12) .............................. 38
BM Board Schematic Diagram (5 of 12) .............................. 39
BM Board Schematic Diagram (6 of 12) .............................. 40
BM Board Schematic Diagram (7 of 12) .............................. 41
BM Board Schematic Diagram (8 of 12) .............................. 42
BM Board Schematic Diagram (9 of 12) .............................. 43
BM Board Schematic Diagram (10 of 12) ............................ 44
BM Board Schematic Diagram (11 of 12) ............................. 45
BM Board Schematic Diagram (12 of 12) ............................ 46
G5M Board Schematic Diagram .......................................... 48
HM1 Board Schematic Diagram ........................................... 50
HM3 Board Schematic Diagram ........................................... 52
UM Board Schematic Diagram ............................................. 54
4-6. Semiconductors ................................................................... 56
SECTION 5: EXPLODED VIEWS ........................................................ 57
5-1. Rear Cover Assembly and Stand Assembly ........................ 57
5-2. Chassis ................................................................................ 58
5-3. Connectors ........................................................................... 59
5-4. Bezel Assembly, LCD Panel and Speakers ......................... 60
KDL-37M3000
SECTION 6: ELECTRICAL PARTS LIST ............................................ 61
APPENDIX A: ENCRYPTION KEY COMPONENTS ..........................A-1
3
SPECIFICATIONS
KDL-37M3000
Power Requirements
120V AC, 60Hz
220V, 50/60 Hz (Chile, Perú)
Video (IN) 1/2/3
S Video (4-Pin Mini DIN (VIDEO 1 Only)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Video
1.0 Vp-p, 75 ohms unbalanced, sync negative
Audio
500 mVrms (100% modulation)
Impedance:47 kilohms
COMPONENT IN 1/2
YP
(Component Video)
BPR
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative
P
:0.7 Vp-p, 75 ohms
B
PR:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i
AUDIO
500 mVrms (100% modulation)
Impedance: 47 kilohms
HDMI IN 1/2:
HDMI: Video:480i, 480p, 720p, 1080i
Audio: Two channel linear PCM 32, 44.1 and
48 kHz, 16, 20 and 24 bits
AUDIO: 500 mVrms (100% modulation)
Impedance: 47 kilohms
AUDIO OUT:
500 mVrms (100% modulation)
More than 500 mVrms (Fixed)
PC IN:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
PC AUDIO INPUT:
Stereo mini jack, 500 mVrms, 47 kilohms
HEADPHONES:
Stereo mini jack
Impedance: 16 ohms
Trademark Information
Manufactured under license from Dolby Laboratories. “Dolby” and
double-D symbol are trademarks of Dolby Laboratories.
This TV incorporates High-Definition Multimedia Interface (HDMI™)
technology. HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing
LLC.
Blu-ray is a trademark. “BRAVIA” and , , a and PS3 are
trademarks or registered marks of Sony Corporation.
Macintosh is a trademark licensed to Apple,Inc.,
registered in the U.S.A. and other countries.
KDL-37M3000
Design and specifi cations are subject to change without notice.
4
Power Consumption
in use
in standby
Speaker Output (W)
mm
Dimensions (W x H x D)
with stand
mm
Dimensions (W x H x D)
without stand
mm
Mass
with stand
without stand
in
in
in
kg
lbs
kg
lbs
KDL-37M3000
180W
Less than 1W
10W + 10W
146 x 35 mm
3/4
3/8
x 1
7/8
x 10
22 kg
49 lbs
18.5 kg
41 lbs
in
3/8
1/2
in
5
918 x 655 x 265 mm
1/4
x 25
36
918 x 609 x 108 mm
1/4
x 24 x 4
36
KDL-37M3000
in
Television system
NTSC American TV Standard
ATSC (8VSB terrestrial) ATSC compliant 8VSB
QAM on cable: ANSI/SCTE 07 2000
Channel coverage
Analog Digital
Terrestrial 2-69 2-69
Cable 1-125 1-135
Antenna
75-ohm external terminal for VHF/UHF
Panel System
LCD (Liquid Crystal Display) Panel
Display Resolution (horizontal x vertical):
1,366 dots x 768 lines
Screen Size (measured diagonally)
approx. 37 inches
All measurements are approximations.
Supplied Accessories
Remote Commander RM-YD021
Two Size AA (R6) Batteries
Suport Belt, Securing Screw, and Wood Screw
Cable Holder
Operating Instructions
Quick Setup Guide
Warranty Card
Online Registration Card
Wall-Mount Instructions
Optional Accessories
Headphones Plug Adapter
Connecting Cables
Wall-Mount Bracket
SU-WL500
75-ohm Coaxial Cable
HD15-HD15 Cable
KDL-37M3000
5
KDL-37M3000
WARNINGS AND CAUTIONS
CAUTION
These servicing instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualifi ed to do so.
CARRYING THE TV
To avoid dropping the TV and causing serious injury, be sure to follow
these guidelines:
s Before carrying the TV, disconnect all cables.
s Carrying the large size TV requires two or more people.
s When you carry the TV, place your hand as illustrated and hold it
securely. Do not put stress on the LCD panel.
KDL-37M3000
s When lifting or moving the TV, hold it firmly from the bottom. Place
your palm directly under the panel.
s When carrying, do not subject the TV to shocks or vibration, or
excessive force.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this receiver is
directly connected to the ac power line.
! SAFETY-RELATED COMPONENT WARNING!!
Components identifi ed by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace
these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that
are critical for safe operation are identifi ed in this manual. Follow these procedures whenever critical components are replaced or improper operation is
suspected.
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifi é seulement. Pour prévenir le risque de choc électrique, ne pas faire
l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifi é faire ainsi.
POUR TRANSPORTER LE TÉLÉVISEUR
Assurez-vous de suivre ces consignes pour éviter de laisser tomber le
téléviseur et de provoquer des blessures graves :
s Avant de transporter le téléviseur, débranchez tous les câbles.
s Le transport du téléviseur doit être effectué par au moins deux
personnes.
s Lorsque vous le transportez, placez vos mains tel que cela est illustré
et tenez solidement l’appareil. N’appliquez pas de pression sur
l’écran ACL.
KDL-37M3000
s Lorsque vous levez ou déplacez le téléviseur, assurez-vous de tenir
solidement de la base. Placez la paume des mains directement sous
le panneau.
s Lorsque vous transportez le téléviseur, ne le soumettez pas à des
chocs ou vibrations, ni à une force excessive.
Afi n d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage. Le
chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
! ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifi es par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une
importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le
present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement
sont identifi es dans le present manuel. Suivre ces procedures lors de chaque remplacement de composants critiques, ou lorsqu’un mauvais
fonctionnement suspecte.
KDL-37M3000
6
SAFETY-RELATED COMPONENT WARNING
KDL-37M3000
There are critical components used in LCD color TVs that are important for safety. These components are identifi ed with shading and
mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number
specifi ed in the electrical parts list to prevent electric shock, fi re, or other hazard.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and
labor guarantee.
!
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
To avoid damaging the LCD panel:
do not press on the panel or frame edge to avoid the risk of electric shock.
do not scratch or press on the panel with any sharp objects.
do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
do not expose the LCD panel to direct sunlight.
avoid contact with water. It may cause a short circuit within the module.
disconnect the AC adapter when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
always clean the LCD panel with a soft cloth material.
use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
LEAKAGE CURRENT HOT CHECK CIRCUIT
KDL-37M3000
7
The circuit boards used in these models have been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation e.g. H1 etc [ see example ]. The
servicing of these boards requires special precautions to be taken as
outlined below.
KDL-37M3000
example 1
It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints.
Lead Free Solder is available under the following part numbers :
rebmuntraP retemaiD skrameR
91-500-046-7mm3.0gK52.0
02-500-046-7mm4.0gK05.0
12-500-046-7mm5.0gK05.0
22-500-046-7mm6.0gK52.0
32-500-046-7mm8.0gK00.1
42-500-046-7mm0.1gK00.1
52-500-046-7mm2.1gK00.1
62-500-046-7mm6.1gK00.1
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade.
This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics.
For more information on the use of Lead Free Solder, please refer to
http://www.sony-training.com
KDL-37M3000
8
SAFETY CHECK-OUT
KDL-37M3000
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
Leakage Test
0.15 F
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.
To Exposed Metal
Parts on Set
Earth Ground
AC
Voltmeter
(0.75V)
Trouble Light
AC Outlet Box
Ohmmeter
Cold-water Pipe
KDL-37M3000
9
KDL-37M3000
SELF-DIAGNOSTIC FUNCTION
The units in this manual contain a self-diagnostic function. If an error occurs, the TIMER LED indicator will automatically begin to fl ash. The number
of times the LED fl ashes translates to a probable source of the problem. A defi nition of the TIMER LED fl ash indicators is listed in the instruction
manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review the failure
occurrence data stored in memory to reveal past problems and how often these problems occur.
1. Diagnostic Test Indicators
When an error occurs, the TIMER LED indicator will fl ash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the indicator will identify the fi rst of the problem areas.
Control Buttons
Self Diagnosis
Supported model
Description of LED Indictors
LED LED Type Description
POWER LED Green LED
TIMER
LED
Display of TIMER LED Flash Count
Amber/Green/Red LED
LED ON 0.3 sec.
LED OFF 0.3 sec.
* Light is green when the TV set is on
* Light is amber when the timer is set.
* Light is green when the Picture Off feature is activated.
* Blinks red when indicating the TV may need servicing.
2 times
5 times
LED OFF
3 sec.
KDL-37M3000
10
KDL-37M3000
Viewing the Self Check Diagnostic List
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a second of each other:
DISPLAY
The Self Check list displays. This is the SAME as accessing Service Adjustments.
Results for all of the following diagnostic items are displayed at the bottom of the screen. No error has occurred if the screen displays a “0”.
Channel 5 Volume +
Software Version:
TVM: ER3.2
SUBM: 1.4
NVM: 1.2
Model Name:
Stored data from ADC
calibration (from
factory)
TV POWER
.
How many times each
protection has been
activated
Diagnosis Information
2: MAIN_POWER 06: BL (Back Light) 0
3: DC_ALERT1 07:TEMP 1
4: DC_ALERT2 07:Audio 0
5:DC_ALERT3 0
Clearing the Self Check Diagnostic List
1. In Service Mode, press the Channel
Channel 0.
8
Protection name and
LED blinking times
Í 0 indicates no error was detected
Í 1 indicates an error was detected
KDL-37M3000
11
1-1. REAR COVER REMOVAL
1
Remove 16 screws from Rear Cover, +BVTP2 4X16
2
Remove 2 screws from Rear Cover arm positions, +PSW M5X16
3
Remove 2 screws from Terminals, +BVTP 3X12 TYPE2 TT(B)
KDL-37M3000
SECTION 1: DISASSEMBLY
2
1
3
1-2. ARM, UNDER COVER AND STAND REMOVAL
1
Remove 2 screws from bottom of VESA Arms, +PSW M5X16
2
Remove 2 screws from Under Cover and Bezel, +BVTP2 4X16
3
Remove 4 screws from Stand and Stand Holder, +BVTP2 4X16
Rear Cover
Bezel
KDL-37M3000
Top Brackets
VESA Arms
1
Under Cover
2
3
Stand Assembly
Bottom Bracket
12
1-3. HM1 BOARD REMOVAL
1
Remove from bezel
2
Disconnect one connector
3
Release hooks and remove HM1 Board
KDL-37M3000
2
HM1 Board
3
Multi Button Assembly
1
Bezel
1-4. UM BOARD AND JACK HOLDER REMOVAL
1
Remove one screw, +BVTP 3X12 TYPE2 TT(B)
2
Disconnect 2 connectors
3
Remove 2 screws, +BVTP 3X12 TYPE2 TT(B)
2
UM Board
1
3
Side Jack Holder
Bezel
KDL-37M3000
13
1-5. SPEAKER, LIGHT GUIDE AND HM3 BOARD REMOVAL
1
Slide out Speakers from Bezel
2
Disconnect one connector
3
Remove 2 screws, +BVTP 3X12 TYPE2 TT(B)
1
Speakers
1
KDL-37M3000
2
3
HM3 Board
Light Guide
1-6. BM BOARD REMOVAL
1
Remove 6 screws, +BVST 3X8
2
Remove 2 screws, +PSW M3X5
3
Remove 2 screws, HEX
4
Remove 2 screws, +PSW M3X5
5
Remove 1 screw, +PSW M3X5
6
Disconnect 8 connectors
7
Remove 7 screws, +BVST 3X8
8
Remove 4 screws, +PSW M3X5
3
2
1
7
8
Top Shield
4
5
Terminal Bracket
6
BM Board
Bottom Shield
KDL-37M3000
14
1-7. G5 BRACKET AND G5M BOARD REMOVAL
1
Disconnect 4 connectors
2
Remove 3 screws, +BVTP 3X12 TYPE2 TT(B)
3
Remove 4 screws, +PSW 3SG
4
Remove 1 screw, +BVST 3X8
1
KDL-37M3000
2
3
G5M Board
1-8. BRACKET REMOVAL
1
Remove 2 screws, +BVTP2 4X16
2
Remove 2 screws, +PSW M4X8
3
Remove 3 screws, +PSW M5X8
4
Remove 4 screws, +PSW M4X8
5
Remove 4 screws, +PSW M5X8
6
Remove 2 screws, +PSW M3X5
7
Remove 4 screws, +PSW M5X8
8
Remove 4 screws, +PSW M4X8
4
Side Stay
G5 Bracket
7
8
4
5
Frame Bracket
Bottom Bracket
KDL-37M3000
6
2
3
1
Side Stay
Top Bracket (L)
3
1
2
Top Bracket (R)
15
1-9 LCD PANEL AND INVERTER BOARD REMOVAL
CAUTION:
Be sure to identify the inverter cover screws before proceeding. DO NOT remove the screws securing the plastic strip holding the
lamp sockets.
1
Remove 6 screws, +BVTP2 4X16
2
Disconnect 8 connectors
LCD Panel
Inverter Board Cover
1
KDL-37M3000
2
Inverter Board
1
Remove 6 screws, +BVTP2 4X16
2
Disconnect 8 connectors
1
Bezel
2
KDL-37M3000
16
2-1. OVERALL VIEW
KDL-37M3000
SECTION 2: WIRE DRESSINGS
KDL-37M3000
17
2-2. LVDS CONNECTOR
KDL-37M3000
,6$3#ABLE
MM
2EFERENCE
&OR2EFERENCE
3HIELD4APEXMM
&OR2EFERENCE
(IMELON4APE
X
2EFERENCE
%-)'!3+%4
,6$3CABLETROUGHTHE
MIDDLEOFTHISGASKET
KDL-37M3000
,6$3#ABLE
MM
18
2-3. LVDS CONNECTOR (CONTINUED)
KDL-37M3000
$RESS,6$3CABLETOHAVE
THISROUTE
-USTENTERBETWEENPANEL
AND"OTTOMSHIELDIN
VERTICALDIRECTION
&IX,6$3CABLE
POSITIONUSING
(IMELON4APE
X
2EFERENCEFOR,6$3CABLEENTRYPOINT
KDL-37M3000
19
2-4. HM3 BOARD AND SPEAKERS
KDL-37M3000
3PKRCABLETROUGHTHIS
CLAMP
3PEAKERCABLE
(-
(-(-CABLE
MM
2EFERENCE2IB
(-AND3PKR2CABLES
TROUGHTHISCLAMP
(IMELON4APEX,#$
X
2OUTECABLEBYINSERTINGITTROUGH
THESE(OLDER2IBSON"EZEL
2EFERENCE
(IMELON4APE,#$
X
3PEAKERCABLE
KDL-37M3000
20
2-5. HM3 BOARD AND SPEAKERS (CONTINUED)
KDL-37M3000
(-AND3PKR2CABLE
TROUGHTHISCLAMPONONE
DIRECTION3PKR,CABLE
OPPOSITEDIRECTION
$IFFERENT!NGLE
#OMPLETELYCOVER&ERRITEAND
GRABTHE(-CABLEUSING
(IMELON#ORE3HEET!
(IMELON4APE,#$
X
KDL-37M3000
21
2-6. G5M BOARD CONNECTORS
KDL-37M3000
)NVERTERCABLE
MM
'-
(OLDCABLESUSING0IN
7IRESON'-
5SECLAMPSONBRACKET
TOROUTECABLES
3TANDBYCABLE
MM
6CABLE
MM
KDL-37M3000
2EFERENCE
%-)'ASKETON"-"OTTOM3HIELD
'!3+%4
2EFERENCEON"OTTOMSHIELD
22
2-7. HM1 BOARD
B
D
KDL-37M3000
(IMELON4APE,#$
X
(-(-CABLE
(-
(IMELON0OSITION
5SE5,4APE0OSITION
ONCABLETOSETTHE
HIMELON$/./4
342%334(%#!",%
2EFERENCE
(-CABLEMUSTGOOVER
,6$3CABLE
(IMELON4APE
UNDERTHESEWIRES
X
2EFERENCE)NTHE
MIDDLEBETWEEN
'-AND"-
OAR
(-CABLEMUSTGO
KDL-37M3000
23
2-8. VIDEO 2 CABLE
KDL-37M3000
6IDEOCABLE
MM
2EFERENCE
&IXFERRITETOPANELUSING
(IMELON#ORE3HEET!
5SECLAMPSTOROUTE
'.$CABLEAND7IRES
'.$#ABLE&!34/.
MM
5-
KDL-37M3000
24
2-9. AC CORD
KDL-37M3000
MM
'-
2OUTETHECABLE
USINGTHISHOOKON
"RACKET
!#(/,$%2
'.$CABLEMM
KDL-37M3000
2EFERENCE
&IXFERRITETOPANELUSING
(IMELON#USHION,"X
25
P
2-10. TUNER
KDL-37M3000
4UNER
&OR2EFERENCE
#ONNECTTUNERSHIELD!SIDE"-AND"
SIDE"-USING
#UPPER4APEXMM
4O
VIEWAND"OTTOM6IEW
"SIDE
KDL-37M3000
26
Loading...
