Introduction

Thank you for choosi ng this Sony product.
Before operating the TV, please read this manual thoroughly and
retain it for fu ture ref erence.

• Before operating the TV, please read the “Safety Information”
(page 2).

• Instructio ns about “Installing the TV to the Wall” are included
within this TV’s instruction manual.

• Imag es and illust rations used in t he Setup Guid e and this
manual are for reference only and may differ from the actual
product.

Location of the Setup Guide

Setup Guide is placed on top of the cushion inside the TV carton.

Help/Help Guide

Help feature offers a lot of informat ion about your TV. To use the
Help feature, press HELP on the remote co ntrol. You can f ind how
to and troubleshooting 's from the list or keyword search. Select
[Help Guide] on Help Menu to view the manual. If you connect
your TV to internet, the H elp feature and information will be
updated.

Location of the identification label

Labels for the TV Model No. and Power Supply rating are located
on the rear of the TV. They can be found by removing the center
cover.

This television is designed for use in Hong Kong and ensured
the usage in Hong Kong on ly.

Safety Information

WARN ING

Batteries must not be expose d to excessive heat such as
sunshine, fire or the like.
Never place a television set in an unstable location . A television
set may fall, ca using serious personal inju ry or death. Many
injuries, particularly to children, can be avoided by taking simple
precautions such as:
 Using cabi nets or stands recommended by the manufacturer of

the television set.

 Only us ing furniture that can safely sup port the television set.
 Ensuri ng the television set is not ove rhanging the edge of t he

supporting furniture.

 Not plac ing the television set on tall furniture (for example,

cupboards or bookcases) w ithout anchoring both the furniture
and the television s et to a suitable support.

 Not plac ing the television set on cloth or other materials that

may be located between the television set and supporting
furniture.

 Educating c hildren about the dangers of climbing on furniture

to reach the television set or its controls.
If your existing television set is b eing retained and relocated, the
same considerations as above should be ap plied.

GB

2

GB

Installation/Set-up

Screw (M6)

Wall-Mount Bracket

10 mm - 12 mm

TV’s rear cover

8 mm - 12 mm

M4 screw
(not supplied)

Screw (not supplied)

Cord (not
supplied)

30 cm

10 cm

10 cm

10 cm

Leave at least this space around the set.

30 cm

10 cm

10 cm

Leave at least this space around the set.

6 cm

Air circulation is blocked.

Wall Wall

Install and use the TV s et in accordance with the instruction s
below in order to avoid any risk of fire, electric shock or damage
and/or in juries.

Installation

• The TV se t should be insta lled near an easily accessible AC
power outlet (mains socket).

• Place the TV on a stable, level surface to prevent it from falling
over and causing personal injury or property damage.

• Install the TV where it cannot be pulled, pushed, or knocked
over.

• Only qualified service personnel should carry out wall-mount
installations.

• For safety reasons, it is strongly recommended that yo u use
Sony accessories, includ ing:

 Wall-Mou nt Bracket SU-WL500 (KD-75Z9D)
 Wall-Mou nt Bracket SU-WL450 (KD-65 Z9D)

• Be sure to use the screws supplied with the Wall-Mount Bracket
when attaching the Wall-Moun t Bracket to the TV set. The
supplied screws are designed as indicated by illustration when
measured from the attaching surface of the Wall-Mount Bracket.
The diameter and length of the screws differ depending on the
Wall-Mount Bracket model.
Use of screws other than t hose supplied may result in internal
damage to the TV se t or cause it to fall, etc.

Tran spo rti ng

• Before transporting the TV set, disconnect all cables.

• Two or three people are needed to transport a large TV set.

• When transpo rting the TV set by han d, hold it as shown below.
Do not put stress on the LCD pane l and the frame around th e
screen.

Topple prevention

Ventilation

• Never cover the ventilation holes or insert anything in the
cabin et.

• Leave space around the TV set as shown below.

• It is strongly recomme nded that you use a Sony Wall-Mo unt
Bracket in order to provide adequate air circulation.

Installed on the wall

• When transpo rting the TV set, do not su bject it to jolts or
excessive vibration.

• When transpo rting the TV set for repairs or when moving, pack
it using the original carton and packing material.

Installed with stand

• To ensure proper ventilation and prevent the collection of dirt or
dust:
 Do not la y the TV set flat, install up side down, backwards, or

sideways.

 Do not pla ce the TV set on a shelf, rug, bed or in a closet.
 Do not cover the TV set with a cloth , such as curtains, or items

such as newspapers, etc.

 Do n ot install the T V set as shown below.

3

GB

AC power cord (mains lead)

Note

Handle the AC power cord (mai ns lead) and outlet (main s socket)
as follows in order to avoi d any risk of fire, electric shoc k or
damage and/or injuries:
 Use only Sony supplied AC power cords (mains lead), not those

of other brands.

 Insert the plug fully into the AC power outlet (mains socket).
 Operate the TV set on a 220 V - 240 V AC supply on ly.
 When wiring cables, be sure to unplug the AC power cord

(mains lead) for yo ur safety and take care not to catch your feet
on the cables.

 Disconnect the AC power cord (mains lead) from the AC power

outlet (mains socket) before working on or moving the TV set.

 Keep the AC po wer cord (mains lead) away from heat sources.
 Unplug the AC power plug (mains plug) and clean it regularly. If

the plug is covered with dust and it picks up moisture, its
insulation may deterio rate, which could result in a fire.

• Do not use the s upplied AC power cord (mai ns lead) on any
other equipment.

• Do not pinch, bend, or twist the AC power cord (m ains lead)
excessively. The core conductors may be exposed or broken.

• Do not modify the AC power cord (mains lead).

• Do not put anythi ng heavy on the AC power cord (mains lead).

• Do not pull on th e AC power cord (mains lead) itse lf when
disconnecting the AC power cord (mains lead).

• Do not connect to o many appliances to the sam e AC power
outlet (m ains so cket).

• Do not use a po or fitting AC power outlet (mains socket).

Prohibited Usage

Do not install/use the TV s et in locations, environments or
situations such as t hose listed below, or the TV set ma y
malfunction and cau se a fire, electric shock, dama ge and/or
injuries.

Locations:

• Outdoors (in d irect sunlight), at the seashore, on a sh ip or other
vessel, inside a vehicle, in medical institutions, unstable
locations, near water, rain, moisture or s moke.

Environments:

• Places that are hot, hu mid, or excessively dusty; where insects
may enter; where it mig ht be exposed to mechani cal vibration,
near flammable objects (candles, etc.). The TV set shall not be
exposed to dripping or splashing and no objects filled with
liquids, such as va ses, shall be placed on th e TV.

Situations:

• Use when yo ur hands are wet, with the cabinet removed, or
with attachments not recomm ended by the manufact urer.
Disconnect the TV s et from AC power outlet (mai ns socket) and
antenna (aerial) during li ghtning storms.

• Install the TV s o that it sticks out into an
open space. Injury or damage from a
person or object bumping into the TV
may result.

• Place the T V in a humid or dusty space,
or in a room with oily smoke or steam
(near cooking tables or humidifiers).
Fire, electric shock, or warping may
result .

• Install the TV in places subject to extreme temperature, such as
in direct sunlight, near a radiator or a he ating vent. The TV may
overheat in such condition s which can cause deformation of the
enclosure and/or TV malfunction.

• If the TV is placed in the changing room of
a public bath or hot spring, the TV may be
damaged by airborne sulfur, etc.

• For best picture quality, do not expose the screen to direct
illumination or sunlight.

• Avoid moving the TV from a cold area to a warm area. Sudden
room temperature changes ma y cause moisture condensation .
This may cause the TV to show poor picture and/or poor colour.
Should this occur, allow mo isture to evaporate completely
before powering the TV on.

Broken pieces:

• Do n ot throw anything at the TV set. T he screen glass may break
by the impact and cause serious injury.

• If the surface of th e TV set cracks, do not touch it until yo u have
unplugged the AC powe r cord (mains lead). Other wise this may
cause an electric shock.

When not in use

• If you will not be using the TV set for seve ral days, the TV set
should be disconnected from the AC power (mains) for
environmental and safety reasons.

• As the TV s et is not disconnected from the AC powe r (mains)
when the TV set is just turned off, pull the plug from the AC
power outlet (mains socket) to disconnect the TV set
completely.

• Some TV se ts may have features that require the TV set to be
left in standby to work correctly.

For children

• Do not allow children to climb on the T V set.

• Keep small accessorie s out of the reach of children, so that they
are not mistakenly swallowe d.

If the following problems occur...

Turn off the T V set and unplug the AC pow er cord (mains lead)
immediately if any of the following pro blems occur.
Ask your dealer or Sony service centre to have it checked by
qualified service personnel.

When:

 AC powe r cord (mains lead) is damaged.
 Poor fittin g of AC power outlet (mains socket).
 TV set is damaged by being dropped, hit or having something

thrown at it.

 Any liquid or solid object falls through openings in the cabinet.

About LCD TV Temperature

When the LCD TV is used for an extended period, the panel
surrounds become warm. You may feel hot wh en touching there
by the hand.

GB

4

GB

Precautions

Viewing the TV

• Vi ew the TV i n moderate li ght, as view ing the TV i n poor ligh t or
during long period of time, strains your eyes.

• When using he adphones, adjust the volume so as to avoid
excessive levels , as hearing damage may result.

(3D compatible models only)

• Some people may experience discomfort (such as eye strain,
fatigue, or nausea) whil e watching 3D video images or playing
stereoscopic 3D games. Sony recommends that all view ers take
regular breaks while watching 3 D video images or playi ng
stereosco pic 3D gam es. The length a nd freque ncy of nece ssary
breaks will vary from person to person. You must decide what
works best. If you experience any discomfort, you should stop
watching the 3D video images or playing stereoscop ic 3D
games until the discomfort ends; consult a doctor if you believ e
necessary. You should als o review (i) the in struction m anual of
any other device or medi a used with this televisi on and (ii) our
website (http://www.sony-asia.com/support) for the latest
information . The vision o f young chil dren (especia lly those
under six years old) is still under development. Consult your
doctor (such as a pediatrician or eye doctor) before allowing
young children to watch 3D video images or play stereoscopic
3D games. Adults should supervise young children to ensure
they follow the recomme ndations listed above.

• Do not use, store, or lea ve the 3D Glasses or battery near a fire,
or in places with a high temperature, e.g., in direct sunlight, or
in sun-heated cars.

LCD Screen

• Although th e LCD screen is made with high-precision
technology and 99.99 % o r more of the pixels are effect ive,
black dots may appear or bright points of light (red, blue, or
green) may appear cons tantly on the LCD screen. This is a
structural property of th e LCD screen and is not a malfunction.

• Do not push or sc ratch the front filter, or place objects on top of
this TV set. The image may be uneven or the LCD screen may be
damaged.

• If this TV set is u sed in a cold place, a smear may occur in the
picture or the picture may become dark. This does not indicate a
failure. These phenomena d isappear as the temperature ris es.

• Ghos ting may o ccur when stil l pictures are d isplayed
continuously. It may disappe ar after a few moments.

• The screen an d cabinet get warm when this TV s et is in use. This
is not a malfunction.

• The LCD screen con tains a small amount of liquid cry stal. Follow
your local ordi nances and reg ulations for disp osal.

Handling and cleaning the screen surface/
cabinet of the TV set

Be sure to unplug the AC pow er cord (mains lead) connected to
the TV set from AC power outlet (mains socket) before cleaning.
To avoid material degradation or screen coating deg radation,
observe the following precautions.

• To remove dust from the screen surface/cabinet, wipe gently
with a soft cloth. If dust is persistent, wipe with a soft cloth
slightly moistened w ith a diluted mild detergent solu tion.

• Never spray water or d etergent directly on
the TV set. It may drip to the bottom of the
screen or exterior parts and enter the TV
set, and may cause da mage to the TV set.

• Never use any type of abrasive pad,
alkaline/acid cle aner, scouring powder, or
volatile solvent, su ch as alcohol, benzene, thinner or insecti cide.
Using such materials o r maintaining prolonged conta ct with
rubber or vinyl materials may resul t in damage to the screen
surface and cabinet material.

• Do not touch the TV if your hand is covered in any chemical
substance such as ha nd cream or sunblock.

• Periodic vacuuming of the ventilation openings is
recommended to ensure proper ventilation.

• When adju sting the angle of the T V set, move it slowly so as to
prevent the TV set from m oving or slipping off from its table
stand.

Optional Equipment

Keep optional components or any equipment emitting
electromagnetic radiation away from the TV set. Otherwise
picture distortion and/or noisy sound may occur.

Wireless Function of the unit

• Do not operate this u nit near medical equipm ent (pacemaker,
etc.), as thi s may result i n the malfu nction of th e medical
equipme nt.

• Altho ugh this un it transmits/re ceives scramble d signals, be
careful of unauthorised i nterception. We cannot be responsible
for any trouble as a result.

Caution about handling the remote control

• Obser ve the correct polarity when in serting batteries.

• Do not use di fferent types of batteries to gether or mix old and
new batteries.

• Disp ose of batterie s in an environ mentally frie ndly way. Certain
region may regulate the dispos al of batteries. Please consult
your local au thority.

• Handle the rem ote control with care. Do not drop or step on it,
or spill liquid of any kind onto it.

• Do not pla ce the remote control in a location near a heat source,
a place subject to direct sunligh t, or a damp room.

GB

5

Parts and Controls

1

2

Controls and Indicators

 Remote Control sensor* / Light sensor*

/ Illumination LED / 3D Sync
Transmitter*

The illumination LED lights up or blinks
according to the status of the TV.

•White
When turning on the TV/picture off
mode/software update, etc.

•Cyan
When connecting with a mobile device
wirelessly.

•Amber
Timer is set.

 (Power) / + / –

When the TV is off,

Press  to power on.

When the TV is on,

Long press  to power off.
Press  repeatedly to change the function,
then press + or - button to:

• Adjust the volume

• Select the channel

• Select the input source of TV

* Do not place anything near the sensor.

GB

6

GB

Using Remote Control

Ȫ

ȩ

ȫ

Ȭ

ȭ

Ȯ

MIC

Remote Control Parts Description

The remote control shape, location, availability and function of remote control button may vary
depending on your region/country/TV model.

/ (Input select/Text hold)

In TV mode: Display and select the input
source.
In Text mode: Hold the current page.

(Microphone)

Use Voice Function. (e.g., Search various
content by voice.)

 (TV standby)

Turn on or turn off the TV (standby mode).

DIGITAL/ANALOG

Switch between digital and analogue mode.

EXIT

Return to the previous screen or exit from
the menu. When an Interactive Application
service is available, press to exit from the
service.

 Number buttons

/ (Info/Text reveal)

Display information.

 (Text)

Display text information.

GB

7

 Google Play

Access the “Google Play” online service.

NETFLIX (Only on limited region/
country/TV model)

Access the “NETFLIX” online service.

Colour buttons

Execute corresponding function at that time.

 ACTION MENU

Display a list of contextual functions.

TV

• Switch to a TV channel or input from other
applications.

• Turn on the TV to display TV channel or
input.

GUIDE/

Display the digital programme guide.

BACK

Return to previous screen.

HOME

Display the TV Home Menu.

DISCOVER

Bring up the Content Bar to search for
content.

//// (Item select/Enter)

 AUDIO

Change the language for the programme
currently being viewed.

//////

Operate media contents on TV and
connected BRAVIA Sync-compatible device.

(Subtitle setting)

Turn subtitles on or off (when the feature is
available).

HELP

Display Help Menu. Help Guide can be
accessed from here.

(Wide mode)

Change the screen format.

SYNC MENU

Display the BRAVIA Sync Menu.

 +/– (Volume)

Adjust the volume.

(Jump)

Jump back and forth between two channels
or inputs. The TV alternates between the
current channel or input and the last
channel or input that was selected.

 (Muting)

Mute the sound. Press again to restore the
sound.

PROG +/–//

In TV mode: Select the channel.
In Text mode: Select the next () or
previous () page.

GB

8

GB

Connection Diagram

*4

*1

*1

*1

*1

*3

*2

DVD player with
component output

VCR/Video game equipment/
DVD player/Camcorder

Home Audio
System with
ARC/HDMI Device

HDMI Device

HDMI Device

Cable/Antenna

Headphone/Home
Audio System/
Subwoofer

Digital still
camera/
Camcorder/
USB storage
media

HDMI Device

VCR/Video game
equipment/DVD
player/Camcorder
Home Audio
System with Optical
Audio Input

Router

For more information on connections, refer to the Help Guide (page 2).

GB

9

 USB 1/2, USB 3

< 12 mm

< 21 mm

3.5 mm

1234

1: L
2: Video
3: Ground
4: R

< 14 mm

Standard definition (SD) videos have picture signals with a
vertical resolutio n of 480 (NTSC) or 576 (PAL/SECAM) line s.

High definition (HD) videos have picture signals
with a vertical resolution of 720 or 1,080 lines.
(For 4K vertical resol ution: 2,160 lines)

Picture Quality

• AV composite cable

• Antenna (aerial) cable

• Component cable

•HDMI cable

• Connecting a large USB device may
interfere with other connected devices
beside it.

• When connecting a large USB device,
connect to the USB 1 port.

 AUDIO OUT*5 /

• To listen to the TV's sound through the
connected equipment, press HOME.
Select [Settings]  [Sound] 
[Headphone/Audio out] and then select
the desired item.

 HDMI IN 1/2/3/4

• If connecting a digital audio system that is
compatible with Audio Return Channel
(ARC) technology, use HDMI IN 3. If not, an
additional connection with DIGITAL AUDIO
OUT (OPTICAL) is necessary.

/ VIDEO IN 1

• For a composite connection, use the
supplied Analogue Extension Cable*

*1

*2

*3

6

.

*4 When connecting mono equipment, connect to the

L (MONO) audio jack (socket).

*5 Supports 3-pole stereo mini jack only.

*6 Only on limited region/country/TV model.

10

GB

GB

Installing the TV to the Wall

Note

1

2

3

2

1

2

2

This TV’s instruction manual only shows the steps on preparing the installation of the TV before
installing to the wall.

To C u stome r s :

For product protection and safety reasons, Sony strongly recommends that installation of your
TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.

To Sony Dealers and Contractors:

Provide full attention to safety during the installation, periodic maintenance and examination of
this product.

Sufficient expertise is required for installing this product, especially to determine the strength of the wall for
withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or
licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any
damage or injury caused by mishandling or improper installation.

Use the Wall-Mount Bracket SU-WL500 (not supplied) (KD-75Z9D) or SU-WL450 (not supplied)
(KD-65Z9D) to install the TV to the wall.
When installing the Wall-Mount Bracket, also refer to the Operating Instructions and Installation Guide
supplied with the Wall-Mount Bracket.

• Be sure to store the removed screws in a safe place, keeping them away from children.

1 Remove the center cover and terminal covers.

2 Remove the screws from the rear of the TV.

GB

11

Note

Note

SU-WL500 (KD-75Z9D)

Mounting Hook

Screw (+PSW 6 × 16)

Screen centre point

1 Attach the Mounting Hook using the four screws supplied with the Wall-Mount Bracket.

• If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}.

• Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference.

2 Make sure that the wall has enough space for the TV and is capable of supporting a

weight of at least four times that of the TV. Refer to the following table on installing the TV
to the wall. See page 18-19 (Specifications) for the TV’s weight.

Model Name

KD-

75Z9D 1,684 973 198 691 138

• Only applicable for 0° for this TV model.

• Figures in the table may differ slightly depending on the installation.

GB

12

Display dimensions

Screen centre

dimension

Unit: mm

Length for mounting

Angle (0°)
