Television
Reference Guide
GB
CT
KD-65X8500C / 55X8500C / 49X8300C / 43X8300C
Table of Contents
Screw
Wall-Mount Bracket
8 mm - 12 mm
TV’s rear cover
Safety Information . . . . . . . . . . . . . . . . . . . . . 2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Parts and Controls . . . . . . . . . . . . . . . . . . . 6
Controls and Indicators . . . . . . . . . . . . . . . . . 6
Inputs and Outputs . . . . . . . . . . . . . . . . . . . . 7
Using Remote Control . . . . . . . . . . . . . . . . 9
Remote Control Parts Description. . . . . . . . . 9
Using the Touchpad Remote Control . . . . . 10
Launching the Touchpad Remote Control
Introduction/Tutorial . . . . . . . . . . . . . . . . . . 10
Connecting the TV . . . . . . . . . . . . . . . . . . .11
Installing the TV to the Wall . . . . . . . . . . 14
SU-WL450 . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting . . . . . . . . . . . . . . . . . . . . 19
Troubles and Solutions . . . . . . . . . . . . . . . . 19
Specifications . . . . . . . . . . . . . . . . . . . . . . 20
Introduction
Thank you for choosi ng this Sony product.
Before operating the TV, please read this manual thoroughly and
retain it for fu ture ref erence.
Note
• Before operating the TV, please read “Safety Information”
(page 2).
• Instructio ns about “Installing the TV to the Wall” are included
within this TV’s instructions manual.
• Images an d illustrations used in Startup G uide and this manual
are for reference only and ma y differ from actual p roduct
appearance.
Location of the identification label
Labels for the Model No. and Power Supply rating are located on
the rear of the TV.
This television is designed for use in Hong Kong and ensured
the usage in Hong Kong on ly.
Safety Information
WARN ING
Batteries must not be expose d to excessive heat such as
sunshine, fire or the like.
Installation/Set-up
Install and use the TV s et in accordance with the instructio ns
below in order to avoid any risk of fire, electrical shock or damage
and/or in juries.
Installation
• The TV se t should be insta lled near an easily accessible AC
power outlet (mains socket).
• Place the TV set on a stable, level surface to avoid it from falling
down and cause pe rsonal injury or dam age to the TV.
• Install the TV where it cannot be pulled, pushed, or knocked
over.
• Only qualified service personnel should carry out wall
installations.
• For safety reasons, it i s strongly recommended that y ou use
Sony accessories, inc luding:
Wall-Mount B racket SU-WL450
• Be sure to use the screws supplied with the Wall-Mount Bracket
when attaching the Wall-Moun t Bracket to the TV set. The
supplied screws are designed as indicated by illustration when
measured from the attaching surface of the Wall-Mount Bracket.
The diameter and length of the screws differ depending on the
Wall-Mount Bracket model.
Use of screws other than t hose supplied may res ult in internal
damage to the TV se t or cause it to fall, etc.
GB
2
Tran spo rti ng
• Before transpor ting the TV set, disconne ct all cables.
• Two or three people are needed to transp ort a large TV set.
• When transpo rting the TV set by han d, hold it as shown b elow.
Do not put stress on the LCD pan el and the frame around the
screen.
• When transpo rting the TV set, do not su bject it to jolts or
30 cm
10 cm
10 cm
10 cm
Leave at least this space around the set.
30 cm
10 cm
10 cm
Leave at least this space around the set.
6 cm
Air circulation is blocked.
Wall Wall
excessive vibration.
• When transpo rting the TV set for repairs or when moving, pack
it using the original carton and packing material.
Ventilation
• Never cover the ventilation holes or insert anything in the
cabinet.
• Leave space around the TV set as shown below.
• It is strongly recommend ed that you use a Sony Wall-Mount
Bracket in order to provide adequate air circulat ion.
Installed on the wall
Installed with stand
• To ensure proper ventilation an d prevent the collection of dir t or
dust:
Do not lay the TV set flat, install up side down, backwa rds, or
sideways.
Do not place the TV set on a shelf, rug, b ed or in a closet.
Do not cover the TV set with a cloth, such as curtains, or items
such as newspapers, etc.
Do not install the TV set as show n below.
Note
• Do not use the supplied AC power cord (mains lead) on any
other equipment.
• Do not pinch, bend, or twist the AC power cord (mains lead)
excessively. The core conductors may be exposed or broken.
• Do not mod ify the AC power cord (mains l ead).
• Do not put a nything heavy on the AC po wer cord (mains lead).
• Do not pull o n the AC power cord (mains lead ) itself when
disconnecting the AC powe r cord (mains lead).
• Do not connec t too many appliances to the sa me AC power
outlet (mains socket).
• Do not use a poor fitting AC power outlet (mains socket).
Prohibited Usage
Do not install/use th e TV set in locations, environmen ts or
situations such as th ose listed below, or the TV set m ay
malfunction and cause a fire, electrical shock, damage and/or
injuries.
Location:
• Outdoor s (in direct sunlight), at the se ashore, on a ship or other
vessel, insid e a vehicle, in medical inst itutions, unstable
locations, near water, rain, moisture or smo ke.
• If the TV is placed in the changing room of
a public bath or hot spring, the TV may be
damaged by airborne sulfur, etc.
• For best picture quality, do not expose the screen to direct
illumination or sunlight.
• Avoid moving the TV from a cold area to a warm area. Sudden
room te mperat ure cha nges may cau se moisture conde nsatio n.
This may cause the TV to show poor picture and/or poor colour.
Should this occur, allow mois ture to evaporate completely
before powering the TV on.
Environment:
• Places that are hot, humid, or excessively dusty; where insects
may enter; where it might be exposed to mechanical vibration,
near flammable obje cts (candles, etc). The TV set shal l not be
exposed to dripping or splashing and no objects filled with
liquids, such a s vases, shall be pla ced on the TV.
• Do not place the TV in a humid or dusty
space, or in a room with oi ly smoke or
steam (near cooking tables or
humidifier s). Fire, electr ic shock, or
warping may result.
• Do not install th e TV in places subject to extreme tem perature,
such as in direct sunlight, nea r a radiator or a heating vent. T he
TV may overheat in su ch conditions which can cause
deformation of the encl osure and/or TV ma lfunction.
GB
AC power cord (mains lead)
Handle the AC power cord (mains lead) and outlet (mains s ocket)
as follows in order to avoid an y risk of fire, electrical shock or
damage and/or injuries:
Inser t the plug fully into the AC p ower outlet (mains socket ).
Operate the TV set on a 220–240 V AC supply onl y.
When wiring cables, be sure to unplug the AC power cord
(mains lead) for yo ur safety and take care not to catch your feet
on the cables.
Discon nect the AC power cord (mains le ad) from the AC power
outlet (mains socket) before working on or moving the TV set.
Keep the AC pow er cord (mains lead) away from heat s ources.
Unplug the AC power plug (mains plug) and clean it regularly. If
the plug is covered with dust and it picks up moisture, its
insulation may deterio rate, which could result in a fire.
Situation:
• D o not use when your hands a re wet, with the cabinet removed,
or with attachments not recommended by the manufac turer.
Disconnect the TV set from AC p ower outlet (mains socket) and
antenna (aerial) during ligh tning storms.
• Do not instal l the TV so that it sticks out
into an open space. Injury or damage
from a person or object bumping into
the TV may result.
Broken pieces:
• D o not throw anything at the TV set. The screen glass may break
by the impact and cause serious injury.
• If the surfa ce of the TV set cracks, do not touch it unt il you have
unplugged the AC power cord (m ains lead). Other wise electric
shock may result.
3
GB
When not in use
• If you will not be using the TV set for seve ral days, the TV set
should be disconnected from the AC power (mains) for
environmental and safety rea sons.
• As the TV set is not disconnected from the AC pow er (mains)
when the TV set is just turned off, pull the plug from the AC
power outlet (main s socket) to disconnect the TV s et
completely.
• However, some TV sets may have features that require the TV
set to be left in standby to work correctly.
For children
• Do not allow chi ldren to climb on the TV se t.
• Keep small accessories out of the reach of children, so that they
are not mistakenly swallowed.
If the following problems occur...
Turn off the T V set and unplug the AC pow er cord (mains lead)
immediately if any of the foll owing problem s occur.
Ask your dealer or Sony service centre to have it checked by
qualified ser vice personnel.
When:
AC power cord (mains lead) is damaged.
Poor fitting of AC power outlet (mains socket).
TV set is damaged by being dropped, hit or having something
thrown at it.
Any liquid or solid object falls through openings in the cabinet.
About LCD Monitor Temperature
When the LCD Monitor is used for an extended period, the panel
surrounds become warm. You may feel hot whe n touching there
by the hand.
Precautions
Viewing the TV
• View the TV in moderate light, as viewing t he TV in poor light or
during long period of time, strains your eyes.
• When using headphones, adju st the volume so as to av oid
excessive levels, as he aring damage may result.
(3D compatible models only)
• Some people may experience discomfort (such as eye strain,
fatigue, or nausea) whil e watching 3D video images or playing
stereoscopic 3D games. Sony recommends that all vi ewers take
regular breaks while watching 3 D video images or playing
stereoscopic 3D games. T he length and frequency of necessary
breaks will vary from person to person. You must decide what
works best. If you experience any discomfort, you should stop
watching the 3D video im ages or playing stereoscopic 3D
games until the discomfort ends; consult a doctor if you believe
necessary. You should als o review (i) the in struction m anual of
any other device or m edia used with this tel evision and (ii) our
website (http://www.sony-asia.com/support) for the latest
information . The vision of y oung children (especially th ose
under six years old) is still under development. Consult your
doctor (such as a pediatrician or eye doctor) before allowing
young children to watch 3D video images or play stereoscopic
3D games. Adults should supervise young children to ensure
they follow the recommendations listed above.
• Do not use, store, or lea ve the 3D Glasses or battery near a fire,
or in places with a high temperature, e.g., in direct sunlight, or
in sun-heated cars.
LCD Screen
• Although th e LCD screen is made with high-precision
technology and 99.99% or more of the pixels are effective, black
dots may appear or bright points of light (red, blue, or green)
may appear constant ly on the LCD screen. This is a structural
property of the LCD screen an d is not a malfunction.
• Do not push or sc ratch the front filter, or place objects on top of
this TV set. The image may be uneven or the LCD screen may be
damaged.
• If this TV set is used in a cold place, a smear may occur in the
picture or the picture may become dark. This does not indicate a
failure. These phenomena disappear as the temperature rises.
• Ghos ting may occu r when still p ictures are dis played
continuously. It may disappear af ter a few moments.
• The screen an d cabinet get warm when this TV s et is in use. This
is not a malfunction.
• The LCD screen con tains a small amount of liquid cr ystal. Follow
your local ordinances and regulations for disposal.
Handling and cleaning the screen surface/
cabinet of the TV set
Be sure to unplug the AC powe r cord (mains lead) connected to
the TV set from AC power ou tlet (mains socket) before clea ning.
To avoid material degradation or screen coating deg radation,
observe the following precautions.
• To remove dust from the screen surface/cabinet, wipe gently
with a soft cloth. If du st is persistent, wipe w ith a soft cloth
slightly moistened wit h a diluted mild detergent solu tion.
• Never spray wate r or detergent directly on
the TV set. It may drip to the bottom of the
screen or exterior parts and enter the TV set,
and may cause dam age to the TV set.
• Never use any type of abrasive pad, alkaline/acid cleaner,
scouring powder, or volatile solvent, such as alcohol, benzene,
thinner o r insecticide. Using such ma terials or ma intaining
prolonged contact with ru bber or vinyl materials may result in
damage to the screen sur face and cabinet material.
• Period ic vacuuming of the vent ilation op enings is
recommended to ensure to proper ventilation.
• When adju sting the angle of the T V set, move it slowly so as to
prevent the TV set from moving or slipping off from its table
stand.
GB
4
Optional Equipment
Keep optional components or any equipment emitting
electromagnetic radiation awa y from the TV set. Otherwise
picture distortion and/or noisy sound may occur.
Wireless Function of the unit
• Do not operate this un it near medical equipmen t (pacemaker,
etc.), as malfunction of the medical equipment may result.
• Althoug h this unit transmits/receives scrambled signa ls, be
careful of unauthorise d interception. We cannot be respon sible
for any trouble as a result.
Caution about handling the remote control
• Observe the correct polarity when inserting batteries.
• Do not use di fferent types of batteries together o r mix old and
new batteries.
• Dispose o f batteries in an environmentall y friendly way. Certain
regions may regulate the disposal of batteries. Please consult
your local a uthority.
• Handle the remote control with care. Do not drop or step on it,
or spill liquid of any kind onto it.
• Do not place the rem ote control in a location near a heat source,
a place subject to direct sunlight, or a damp room.
GB
GB
5
Parts and Controls
Ȫ
ȫ
Ȭ
ȭ
Controls and Indicators
Remote Control sensor*1 / Light
1
sensor*
Transmitter*
The illumination LED lights up or blinks
according to the status of the TV.
•White
•Cyan
•Amber
/ Illumination LED / 3D Sync
1*2
When turning on the TV/picture off
mode/software update, etc.
When connecting with a mobile device
wirelessly.
Timer is set.
(Power)
CH +/- (Channel)
+/- (Volume)
TV
Switch to a TV channel or input from other
applications.
(Input select)
Display and select the input source.
*1 Do not place anything near the sensor.
*2 3D compatible models only.
GB
6
Inputs and Outputs
KD-65/55X8500C
KD-49/43X8300C
GB
GB
7
LAN
HDMI 3 AUDIO IN
For HDMI 3 analogue audio connection.
DIGITAL AUDIO OUT (OPTICAL)
/ VIDEO IN 1
For a composite connection*.
VIDEO IN 2, / COMPONENT IN
• For a composite connection:
Use VIDEO IN, and (L/R) of
COMPONENT IN*.
• For a component connection:
Use Y, P
B, PR, and (L/R).
/
CABLE/ANTENNA
Connect to your cable or antenna (aerial).
(USB 1/2), (USB 3)
• Connecting a large USB device may
interfere with other connected devices
beside it.
• When connecting a large USB device,
connect to the USB 1 jack.
HDMI IN 1/3/4
• If the device has a DVI jack, connect it to
HDMI IN 3 through a DVI - HDMI adaptor
interface (not supplied), and connect the
device's audio out jack to HDMI 3 AUDIO
IN.
• If connecting a digital audio system that is
compatible with Audio Return Channel
(ARC) technology, use HDMI IN 4. If not, an
additional connection with DIGITAL AUDIO
OUT (OPTICAL) is necessary.
AUDIO OUT /
To listen to the TV's sound through the
connected equipment, press HOME. Select
[Settings] [Sound] [Headphone/Audio
out] and then select the desired item.
HDMI IN 2/MHL
You can connect your MHL (Mobile Highdefinition Link) device using an HD quality
MHL cable.
* When connecting mono equipment, connect to the L
(MONO) audio jack.
GB
8
Using Remote Control
IR (infrared) Remote Control
Touchpad Remote Control
For models with supplied Touchpad Remote
Control.
Remote Control Parts Description
ȩ
Ȫ
ȫ
Ȭ
ȭ
Ȯ
ȯ
/ (Input select/Text hold)
In TV mode: Display and select the input
source.
In Text mode: Hold the current page.
(TV standby)
Turn on or turn off the TV (standby mode).
DIGITAL/ANALOG
Switch between digital and analogue mode.
EXIT
Return to the previous screen or exit from
the menu. When an Interactive Application
service is available, press to exit from the
service.
Number buttons
(Twin picture/PIP)*
Display two pictures simultaneously.
1*2
(Text)
Display text information.
Colour buttons
Execute correspondent function at that time.
(Wide mode)
Change the screen format.
TV
Switch to a TV channel or input from other
applications.
HELP
Display Help Menu.
ACTION MENU
Display a list of contextual functions.
You can also display it by slide down your
finger from ACTION MENU on the Touchpad
Remote Control.
GB
GB
9
/ (Info/Text reveal)
Display information.
GUIDE/ *
Display the digital programme guide.
1
BACK
Return to previous screen.
HOME
Display the TV Home Menu.
DISCOVER
Bring up the Content Bar to search for
content.
You can also launch Content Bar by slide up
your finger from DISCOVER on the
Touchpad Remote Control.
//// (Item select/Enter)
+/– (Volume)
Adjust the volume.
(Jump)
Jump back and forth between two channels
or inputs. The TV alternates between the
current channel or input and the last
channel or input that was selected.
(Muting)
Mute the sound. Press again to restore the
sound.
PROG +/–//
In TV mode: Select the channel.
In Text mode: Select the next (
previous (
) page.
) or
AUDIO
Change the language for the programme
currently being viewed.
(Subtitle setting)
Turn subtitles on or off (when the feature is
available).
//////
Operate media contents on TV and
connected BRAVIA Sync-compatible device.
SYNC MENU
Display the BRAVIA Sync Menu.
FOOTBALL
Turn Live Football Mode on or off (when the
feature is available).
(Microphone)
Use Voice Function. (e.g., Search various
content by voice.)
Touchpad
Operate the TV with the touchpad.
(NFC)
Touch the device (e.g. some models of
Xperia) corresponding to the One-touch
mirroring function, then its screen is
displayed on the TV.
*1 The location, availability and function of remote
control button may vary depending on your country/
region/T V model.
*2 Twin Picture function will be available from July 2015.
You will receive Twin Picture function automatically
as a network software upgrade. Make sure your TV is
connected to the Internet. If you do not have a
network connection, you will be able to download
the software from the Sony support website using
your PC. For details on how to upgrade, please visit
the Sony support website.
Using the Touchpad Remote Control
Touchpad Remote Control can only be used
after pairing with the TV.
To pair, follow the pairing screen instruction.
Pairing screen can be displayed by pressing the
button on the TV for 5 seconds, or select
[Settings] - [Touchpad Remote Control settings]
- [Pair Touchpad Remote Control].
Launching the Touchpad Remote Control Introduction/Tutorial
1 Press HOME.
2 Select [Settings] - [Touchpad Remote
Control settings] - [Start Introduction/
Tut orial ].
10
GB
Connecting the TV
To H D MI O UT
< 12 mm
< 21 mm
To H D MI O UT
< 12 mm
< 21 mm
To AUDIO
OUT
To C OMP ONE NT
OUT (P
R/PB/Y)
Note
• To select an input device connected to the TV, press
.
• When connecting the cable to the Cable/Antenna,
input finger tighten only, over-tightening the
connection can damage the TV.
To connect with an HDMI cable
KD-65/55X8500C
To connect with component cables
GB
KD-49/43X8300C
GB
11
To connect with AV composite cables To connect MHL device
To VIDEO OUT
Use authorized MHL
CABLE with MHL logo
(not supplied)
MHL device
KD-65/55X8500C
12
GB
KD-49/43X8300C The TV simultaneously charges the MHL-
Use authorized MHL
CABLE with MHL logo
(not supplied)
MHL device
Picture Quality
• AV composite cable
• Antenna (aerial) cable
Standard definition (SD) videos have picture signals with a
vertical resolution of 480 (NTSC) or 576 (PAL/SECAM) lines.
• Component cable • HDMI cable
High definition (HD) videos have picture signals
with a vertical resolu tion of 720 or 1,080 lines.
(For 4K vertical resol ution: 2,160 lines)
compatible connected device while playing
photo/music/video files. You can use the TV
remote control to control the connected MHLcompatible device.
Note
• If [MHL charging during standby] is set to [On], you
can continue charging the MHL-compatible device
even when the TV is in standby mode.
• Use authorized MHL 3 CABLE with MHL logo for 4K
smartphone or mobile devices.
GB
GB
13
Installing the TV to the Wall
This TV’s instruction manual only shows the steps on preparing the installation of the TV before
installing to the wall.
To Custo m er s :
For product protection and safety reasons, Sony strongly recommends that installation of your
TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the installation, periodic maintenance and examination of
this product.
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for
withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers
or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for
any damage or injury caused by mishandling or improper installation.
Use the Wall-Mount Bracket SU-WL450 (not supplied) to install the TV to the wall.
When installing the Wall-Mount Bracket, also refer to the Operating Instructions and Installation Guide
supplied with the Wall-Mount Bracket.
Note
• Be sure to store the removed screws in a safe place, keeping them away from children.
To change the cable management (KD-55X8500C, KD-49/43X8300C)
GB
14
Loading...
