How to use this handbook
Click on a button on the right to jump to the corresponding page.
This is convenient when searching for a function you want to view.
contents
Table of
Search for information by function.
Operation
Search
Settings
Search
Index
Marks and notations used in this handbook
Search for information by operation.
Search for information in a listing of
Settings items.
Search for information by keyword.
contents
Search
Search
Table of
Operation
Settings
The default setting is indicated by .
Indicates cautions and limitations relevant
to the correct operation of the camera.
z Indicates information that is useful to
know.
Index
US
2
Notes on using the camera
Notes on the battery pack
About the displayed language
The display panel displays only English.
Other languages are not available.
Notes on recording/playback and
connection
• Before you start recording, make a trial
recording to make sure that the camera is
working correctly.
• To play back images, connect the camera to
another device with a micro HDMI cable (sold
separately).
• The camera is neither dust-proof, nor splashproof, nor water-proof. Read “Precautions”
(page 55) before operating the camera.
• Avoid exposing the camera to water. If water
enters inside the camera, a malfunction may
occur. In some cases, the camera cannot be
repaired.
• Do not aim the camera at the sun or other bright
light. It may cause malfunctions.
• Do not use the camera near a location that
generates strong radio waves or emits radiation.
Otherwise, the camera may not properly record
or play back images.
• Using the camera in sandy or dusty locations
may cause malfunctions.
• If moisture condensation occurs, remove it
before using the camera (page 55).
• Do not shake or strike the camera. It may cause
a malfunction and you may not be able to record
images. Furthermore, a memory card may
become unusable or image data may be
damaged.
• When connecting the camera to another device
with a cable, be sure to insert the connector plug
in the correct way. Pushing the plug forcibly
into the terminal will damage the terminal and
may result in a malfunction of the camera.
• Playback of movies other than those shot, edited
or composed on this camera is not guaranteed.
On camera’s temperature
The camera may get warm due to continuous use,
but it is not a malfunction.
On the overheat protection
Depending on the camera and battery temperature,
you may be unable to record movies or the power
may turn off automatically to protect the camera.
A message will be displayed on the display panel
before the power turns off or you can no longer
record movies.
• Charge the battery pack before using for the first
time.
• You can charge the battery pack even if it is not
completely discharged. In addition, even if the
battery pack is not fully charged, you can use the
partially charged capacity of the battery pack as
is.
• For details on the battery packs, see page 53.
Notes on the display panel and lens
• Exposing the display panel or the lens to direct
sunlight for long periods may cause
malfunctions. Be careful when placing the
camera near a window or outdoors.
• Do not press against the display panel. It may
cause a malfunction.
On image data compatibility
• This camera supports "MP4 format" as movie
file format. However, it is not guaranteed that all
MP4 compliant devices can play back images
recorded with this camera.
• The camera conforms with DCF (Design rule
for Camera File system) universal standard
established by JEITA (Japan Electronics and
Information Technology Industries
Association).
Warning on copyright
Television programs, films, videotapes, and other
materials may be copyrighted. Unauthorized
recording of such materials may be contrary to the
provisions of the copyright laws.
No compensation for damaged
content or recording failure
Sony cannot compensate for failure to record or
loss or damage of recorded content due to a
malfunction of the camera or memory card, etc.
The illustrations and images used in
this handbook
• The images used as examples in this handbook
are reproduced images, and are not actual
images shot using the camera.
• In this manual, “Memory Stick Micro” media
and microSD memory card are referred to as
“memory card.”
• Design and specifications are subject to change
without notice.
Continued r
contents
Table of
Operation
Search
Settings
Search
Index
US
3
Notes on playing back on other
devices
• The camera is compatible with MPEG-4 AVC/
H.264 Main Profile for HD (high definition)
image quality recording. Therefore, you cannot
play back images recorded with HD (high
definition) image quality on the camera with the
devices which are not compatible with the
MPEG-4 AVC/H.264.
• Movies recorded using this camera may not play
back normally on devices other than this
camera. Also, movies recorded on other devices
may not play back properly on this camera.
On wireless network function
• Only the HDR-AS15 is equipped with the Wi-Fi
function.
• The wireless network function built into this
camera has been confirmed to conform with WiFi specifications set forth by the Wi-Fi Alliance
(WFA).
• Depending on the region, access to a wireless
LAN may not be available, may require a
separate service charge, or communications may
be blocked or suffer from intermittent outages.
For details, check your wireless LAN
administrator and/or service provider.
• Sony makes no guarantees whatsoever in the
provision of a network service. Sony bears
absolutely no responsibility for damages that
may arise from the use of a network service
even in the case of claims made by a third-party.
contents
Search
Search
Table of
Operation
Settings
Index
About the security on using Wireless
LAN products
It is important to set security when using the
wireless network function. Sony makes no
guarantees and is not responsible for any damage
resulting from having inadequate security or using
the wireless network function.
Carl Zeiss lens
The camera is equipped with a Carl Zeiss lens
which is capable of reproducing sharp images with
excellent contrast. The lens for the camera has
been produced under a quality assurance system
certified by Carl Zeiss in accordance with the
quality standards of Carl Zeiss in Germany.
US
4
How to enjoy the camera
Enjoy more using the accessories
Movies are recorded at a maximum of 1920×1080 30p full high definition.
contents
Table of
Waterproof Head Mount Kit & Waterproof Case
Adhesive Mount & Waterproof Case
Search
Search
Operation
Settings
Index
Headband Mount
Continued r
US
5
Share your life
Upload captured moments
You can directly upload images and share
them by using the wireless network function
of this camera (page 39).
contents
Search
Search
Table of
Operation
Settings
Connect to TV
Connect the camera to a TV with a micro
HDMI cable (sold separately), and enjoy
images on the big screen (page 38).
Index
US
6
Table of contents
Notes on using the camera
How to use this handbook····································· 2
Notes on using the camera ··································· 3
How to enjoy the camera ······································ 5
Operation Search·················································· 9
Settings Search··················································· 10
Identifying parts··················································· 11
Getting started
Checking the bundled items································ 12
Inserting the battery pack···································· 13
Inserting a memory card ····································· 16
Recording Mode·················································· 18
SteadyShot·························································· 19
Field Angle ·························································· 20
Interval Photo Recording····································· 21
Smart Remote Control (HDR-AS15 only)············ 22
Auto Power Off···················································· 23
Date & Time Setting············································ 24
USB Power Supply·············································· 25
Resetting the Settings········································· 26
Format································································· 27
Using Accessories··············································· 28
contents
Search
Search
Table of
Operation
Settings
Index
Shooting
Viewing
Shooting······························································ 37
Viewing images on a TV ····································· 38
US
7
Wireless Network (Wi-Fi)
Setting Wi-Fi (HDR-AS15 only)··························· 39
Copying data to a smartphone
(HDR-AS15 only) ················································ 41
Computer
Useful functions when connecting the camera to
your computer ····················································· 42
Preparing a computer (Windows)························ 43
Starting the “PlayMemories Home” software ······ 45
Troubleshooting
Troubleshooting ·················································· 46
Warning indicators and messages ······················ 50
contents
Search
Search
Table of
Operation
Settings
Index
Others
Index
Recordable time ·················································· 51
Battery pack ························································ 53
Using the camera abroad···································· 54
Precautions ························································· 55
Specifications ······················································ 57
Index ··································································· 60
US
8
Operation Search
contents
Table of
Shooting movies and
photos
Changing the movie file
size
Deleting images
Changing the date,
time and region
Initializing settings
Viewing on TVs
Operating using a
smartphone or tablet
Shooting································································· 37
Recording Mode ·················································· 18
Format ···································································· 27
Date & Time Setting············································ 24
Resetting the Settings········································ 26
Viewing images on a TV···································· 38
Smart Remote Control (HDR-AS15 only)····· 22
Search
Search
Operation
Settings
Index
Uploading images to a
network service
Setting Wi-Fi (HDR-AS15 only)······················· 39
US
9
Settings Search
Setting items
Click each item to jump to the corresponding page.
contents
Table of
Items Display Default setting
Recording Mode VIDEO HQ (1920×1080/30P)
SteadyShot STEDY ON
Field Angle ANGLE 120°
Interval Photo Recording LAPSE 5sec
Smart Remote Control (HDR-AS15
only)
Auto Power Off A.OFF 10sec
Date & Time Setting DATE 2012/1/1 00:00 GMT+0
USB Power Supply USBPw ON
Resetting the Settings RESET —
Format FORMT —
Note
• The display panel displays only English. Other languages are not available.
RMOTE OFF
How to set items
You can set items using the following 3 buttons on the
camera.
NEXT*: Goes to the next menu
PREV*: Goes to the previous menu
ENTER: Executes the menu
* Both NEXT and PREV buttons are used to change the menu.
In this manual, we usually use the NEXT button for
description. When using only the PREV button, we describe it
as the PREV button.
REC START/
STOP button/
ENTER button
PREV button
NEXT button
Search
Search
Operation
Settings
Index
1 Press the NEXT or PREV button to turn on the power.
To power off, select [PwOFF] and press the ENTER button.
2 Press the NEXT button to display [SETUP], then press the ENTER button.
3 Press the NEXT button to display the setting item, then press the ENTER
button.
To return to the [SETUP] menu, select [BACK] and press the ENTER button.
10
US
Identifying parts
A REC/access lamp
B REC START/STOP button
ENTER (Menu execute) button
C b HOLD switch*
D Display panel
E Speaker
F PREV button
G NEXT button
H Microphones
I Lens
J Connector cover
K m (Mic) jack*
L Expansion connector*
M CHG (Charge) lamp
N HDMI OUT jack
O (USB) jack
P Battery pack/memory card cover
Q Memory card insertion slot
R Battery tray lever
S Battery tray
1
2
3
contents
Search
Search
Table of
Operation
Settings
Index
*1Used to prevent accidental operation. Slide in
the direction of b to lock. Slide in the opposite
direction to release.
2
When an external microphone (sold separately)
*
is connected, audio cannot be recorded through
the built-in microphone.
3
Used to connect accessories.
*
11
US
Checking the bundled items
Make sure that you have following bundled items.
The number in parentheses indicates the quantity of that item bundled.
• Camera (1)
• Micro USB cable (1)
• Rechargeable battery pack (NP-BX1) (1)
• Battery tray, type X (only for NP-BX1) (1)
Attached to the camera.
• Battery tray, type G (only for NP-BG1/FG1) (1)
• Waterproof Case (SPK-AS1) (1)
contents
Search
Search
Table of
Operation
Settings
• Adhesive Mount (VCT-AM1)
Attachment Buckle (1)
Flat Adhesive Mount (1)
Curved Adhesive Mount (1)
• Handbook (this manual)
Included in the internal memory of this camera.
• Set of printed documentation
Index
12
US
Inserting the battery pack
1 Slide the Battery pack/memory card cover
in the direction of the arrow, then open the
cover.
contents
Table of
2 Pull out the battery tray from the camera,
set the battery pack on the tray, then
return it into the camera.
3 Close the cover.
Pinch the tab
and pull out.
Match the direction of v.
Search
Search
Operation
Settings
Index
zTo set Auto Power Off function
Select [A.OFF] from the [SETUP] screen, then set the Auto Power Off function. The default
setting is [10sec]. Change the setting as necessary.
For detail, see “Auto Power Off” (page 23).
Continued r
13
US
Charging the battery pack
1 Turn off the power of the camera.
Charging is not possible when the camera is turned
on.
2 Connect the camera to the computer that
is turned on with the micro USB cable
(supplied).
The CHG (Charge) lamp lights up.
Micro USB
cable
(supplied)
Insert until fully
seated
3 When charging is finished, delete the USB connection between the
camera and the computer (page 44).
Charging is complete when the CHG (Charge) lamp turns off (full charge) (page 53).
Notes
• You can use only type X or G battery with this camera.
• Turn off the camera while charging the battery.
• Do not apply force to the camera, when you connect the camera to a computer. This may cause damage to
the camera or the computer.
• When you connect the camera to a notebook computer that is not connected to an AC power source, the
battery of the notebook computer may be depleted rapidly. Do not leave the camera connected to the
computer for a long time.
• Charging the battery pack or the connection with customized or hand-built computers is not guaranteed.
Depending on the type of USB device used, charging may not function properly.
• Operation with all computers is not assured.
• If you do not intend to use the camera for an extended period, charge the camera once every 6 to 12
months to maintain battery performance.
CHG (Charge)
lamp
contents
Search
Search
Table of
Operation
Settings
Index
zHow long does it take to charge the camera?
Charging time
Battery pack Via a computer Via AC-UD20* (sold separately)
NP-BX1 (supplied) Approx. 245 min. Approx. 175 min.
NP-BG1/FG1 Approx. 185 min. Approx. 140 min.
• Time required to charge a fully depleted battery pack at a temperature of 25°C (77°F). Charging
may take longer under certain circumstances or conditions.
* Rapid charging is possible by using the USB charger AC-UD20 (sold separately). To connect to the
charger, use the micro USB cable (supplied).
Continued r
14
US
zChecking the remaining battery charge
A remaining charge indicator appears on the upper right of the display panel.
High Low
• The displayed remaining charge indicator may not be correct under certain circumstances.
• It takes about one minute until the correct remaining charge indicator appears.
contents
Search
Search
Table of
Operation
Settings
Index
15
US
Inserting a memory card
1 Slide the Battery pack/memory card cover
in the direction of the arrow, then open
the cover.
contents
Table of
2 Insert the memory card until it clicks.
microSD card: Insert in the direction of A.
“Memory Stick Micro (M2)” media: Insert in the
direction of B.
• When [WAIT] appears on the display panel, wait until
the message disappears.
• Insert a memory card directly in the correct orientation;
otherwise, the camera will not recognize it.
3 Close the cover.
zTo eject the memory card
Open the cover, then lightly push the memory card once.
microSD card
Operation
Search
AB
Settings
Search
“Memory Stick Mi cro
(Mark2)” media
Index
zWhat types of memory cards you can use with this
camera?
Types of memory cards SD Speed Class Phrase in this book
“Memory Stick Micro
(Mark2)” media
microSD memory card
microSDHC memory card
• Operation with all memory cards is not assured.
— “Memory Stick Micro” media
Class 4 or faster microSD card
Continued r
16
US
Notes
• In order to stabilize memory card operation, it is recommended that you format the memory card when
you use it with the camera for the first time (page 27).
All data recorded on the memory card will be erased by formatting, and cannot be recovered.
• Save important data on the memory card on other media such as a computer, before formatting the
memory card.
• If you insert a memory card into the slot in the wrong direction, the memory card, the memory card slot,
or image data may be damaged.
• Do not insert anything other than the compliant size of memory card into the memory card slot. Doing so
may cause a malfunction.
• When inserting or ejecting the memory card, be careful to prevent the memory card from popping out
and dropping.
• Guaranteed operating temperature of the camera is between 0°C to 40°C (32°F to 104°F). However,
depending on the types of memory cards, guaranteed operating temperature varies.
For details, refer to the operating instructions supplied with the memory card.
contents
Search
Search
Table of
Operation
Settings
Index
17
US
Recording Mode
You can set the image resolution and frame rate for shooting movies.
To make the setting, select [SETUP] first.
Setting
display
t
1 Press the NEXT button to display [SETUP], then press the ENTER button.
contents
Table of
2 While [VIDEO] (Video) is displayed, press the ENTER button.
If the camera turns off by the Auto Power Off function while setting, perform the procedure
again from step 1.
3 Press the NEXT button to select the Recording Mode, then press the
ENTER button.
Display Recorded image Resolution
Highest resolution 1920×1080 30p
High resolution 1280×720 30p
Slow motion image recorded at 2×
frame rate
Super slow motion image recorded at
4× frame rate
Standard resolution 640×480 30p
1280×720 60p
1280×720 120p
Imaging
frame rate
Playback
frame rate
30p
Search
Search
Operation
Settings
Index
Returns to the [VIDEO] menu.
Notes
• Continuous movie shooting time is approximately 13 hours.
In [SLOW] mode, it is approximately 6.5 hours.
In [SSLOW] mode, it is approximately 3 hours.
• If you select [SSLOW], SteadyShot will not be effective even if SteadyShot is set to [ON].
• Audio is not recorded during shooting in the following situation:
– [SSLOW] (720 120P), [SLOW] (720 60P) is set.
• When the recording mode is set to [VGA], the angle of view becomes narrower compared to other
recording modes.
18
US
Loading...
