Sony E2033, E2043, E2063 User Guide
User guide
™
Xperia
E2033/E2043/E2063
E4g Dual
Contents
Getting started...............................................................................6
About this User guide........................................................................6
Device overview.................................................................................6
Assembly...........................................................................................7
Starting your device for the first time.................................................9
Why do I need a Google™ account?...............................................10
Charging your device.......................................................................10
Learning the basics......................................................................12
Using the touchscreen.....................................................................12
Locking and unlocking the screen...................................................14
Home screen....................................................................................14
Application screen...........................................................................16
Navigating applications....................................................................17
Small apps.......................................................................................18
Widgets............................................................................................18
Shortcuts and folders......................................................................19
Background and themes..................................................................20
Taking a screenshot.........................................................................21
Status and notifications...................................................................21
Icons in the status bar.....................................................................22
Application overview........................................................................24
Downloading applications............................................................26
Downloading applications from Google Play™...............................26
Downloading applications from other sources................................26
Internet and networks..................................................................27
Browsing the web............................................................................27
Internet and MMS settings ..............................................................27
Wi-Fi®..............................................................................................28
Sharing your mobile data connection..............................................30
Controlling data usage.....................................................................30
Selecting mobile networks...............................................................32
Virtual private networks (VPNs)........................................................32
Synchronising data on your device..............................................34
Synchronising with online accounts................................................34
Synchronising with Microsoft® Exchange ActiveSync®.................34
Synchronising with Outlook® using a computer.............................35
Basic settings...............................................................................36
Accessing settings...........................................................................36
Sound, ringtone and volume............................................................36
2
This is an Internet version of this publication. © Print only for private use.
SIM card protection.........................................................................37
Using multiple SIM cards.................................................................38
Screen settings................................................................................38
Daydream.........................................................................................39
Screen lock......................................................................................39
Language settings............................................................................41
Date and time...................................................................................41
Enhancing the sound output............................................................42
Typing text...................................................................................43
On-screen keyboard........................................................................43
Phonepad.........................................................................................44
Entering text using voice input........................................................45
Editing text.......................................................................................45
Personalising the Xperia keyboard..................................................46
Calling..........................................................................................47
Making calls.....................................................................................47
Receiving calls.................................................................................48
Ongoing calls...................................................................................50
Using the call log.............................................................................50
Forwarding calls...............................................................................51
Restricting calls................................................................................51
Multiple calls....................................................................................52
Conference calls..............................................................................53
Voicemail..........................................................................................53
Emergency calls...............................................................................54
Contacts.......................................................................................55
Transferring contacts.......................................................................55
Searching and viewing contacts......................................................56
Adding and editing contacts............................................................57
Adding medical and emergency contact information......................58
Favourites and groups.....................................................................59
Sending contact information............................................................60
Avoiding duplicate entries in the Contacts application...................60
Backing up contacts........................................................................60
Messaging and chat.....................................................................61
Reading and sending messages......................................................61
Organising your messages..............................................................62
Calling from a message...................................................................63
Messaging settings..........................................................................63
Instant messaging and video chat...................................................63
Email.............................................................................................65
Setting up email...............................................................................65
3
This is an Internet version of this publication. © Print only for private use.
Sending and receiving email messages..........................................65
Email preview pane..........................................................................66
Organising your email messages.....................................................67
Email account settings.....................................................................67
Gmail™............................................................................................68
Music............................................................................................69
Transferring music to your device...................................................69
Listening to music............................................................................69
Walkman® home screen menu.......................................................70
Playlists............................................................................................71
Sharing music..................................................................................72
Enhancing the sound.......................................................................72
Visualiser .........................................................................................72
Recognising music with TrackID™..................................................73
FM radio.......................................................................................75
Listening to the radio.......................................................................75
Favourite radio channels..................................................................76
Sound settings.................................................................................76
Camera.........................................................................................77
Taking photos and recording videos...............................................77
Face detection.................................................................................78
Using Smile Shutter™ to capture smiling faces..............................78
Adding the geographical position to your photos...........................79
General camera settings..................................................................79
Still camera settings.........................................................................82
Video camera settings.....................................................................86
Photos and videos in Album........................................................89
Viewing photos and videos..............................................................89
Sharing and managing photos and videos......................................90
Editing photos with the Photo editor application.............................91
Editing videos with the Movie Creator application..........................92
Hiding photos and videos................................................................92
Album home screen menu...............................................................93
Viewing your photos on a map........................................................94
Videos..........................................................................................96
Watching videos in the Movies application.....................................96
Transferring video content to your device.......................................97
Managing video content..................................................................97
Connectivity.................................................................................98
Mirroring the screen of your device wirelessly on a TV...................98
Sharing content with DLNA Certified™ devices..............................98
Bluetooth® wireless technology....................................................101
4
This is an Internet version of this publication. © Print only for private use.
Smart apps and features that save you time.............................104
Controlling accessories and settings with Smart Connect............104
Travel and maps.........................................................................107
Using location services..................................................................107
Google Maps™ and navigation.....................................................107
Using data traffic when travelling..................................................108
Airplane mode................................................................................109
Calendar and alarm clock..........................................................110
Calendar.........................................................................................110
Alarm and clock.............................................................................111
Support and maintenance..........................................................113
Support for your device.................................................................113
Computer tools..............................................................................113
Updating your device.....................................................................114
Finding a lost device .....................................................................116
Finding the identification number of your device...........................116
Battery and power management...................................................117
Memory and storage......................................................................118
Managing files using a computer...................................................120
Backing up and restoring content.................................................121
Running diagnostic tests on your device.......................................122
Restarting and resetting.................................................................123
Recycling your device....................................................................124
Limitations to services and features..............................................124
Legal information...........................................................................125
5
This is an Internet version of this publication. © Print only for private use.
Getting started
About this User guide
This is the Xperia™ E4g Dual User guide for the Android™ 4.4.4 software version. If
you're not sure which software version your device is running, you can check it via
the Settings menu. For more information about software updates, see
on page 114.
device
To check the current software version of your device
1
From your Home screen, tap .
2
Find and tap Settings > About phone > Android version.
Device overview
Updating your
6
This is an Internet version of this publication. © Print only for private use.
1. Charging/Notification light
2. Front camera lens
3. Proximity/Light sensor
4. Ear Speaker
5. Power key
6. Volume/Zoom key
7. Main microphone
8. Second microphone
9. Camera light
10. Main camera lens
11. Headset jack
12. Port for charger/USB cable
13. Strap hole
14. Loudspeaker
Assembly
A protective plastic sheet is attached to the screen. You should peel off this sheet
before using the touchscreen. Otherwise, the touchscreen might not function
properly.
To remove the back cover
•
Insert a fingernail into the gap (as indicated in the illustration) and lift up the
cover.
To attach the back cover
1
Place the back cover over the back of the device, then press down on the
bottom corners to lock them into place.
2
Moving from bottom to top, press down the sides of the cover until the cover
clicks into place.
To insert the micro SIM cards
If you insert a micro SIM card while the device is powered on, the device restarts
automatically.
•
Remove the back cover, then insert the micro SIM cards into the
corresponding slots with the gold-coloured contacts facing down.
You must use a micro SIM card for your device to work correctly. Some standard-sized SIM
cards allow you to detach an integrated micro SIM card. Once you detach the micro SIM card
7
This is an Internet version of this publication. © Print only for private use.
from the standard-sized SIM card, you cannot reattach it and use the standard-sized SIM card
again. If you do not have a micro SIM card, or if your current SIM card does not contain a
detachable micro SIM card, contact your network operator for information on how to collect or
exchange your SIM card.
To insert a memory card
1
Remove the back cover.
2
Insert the memory card into the memory card slot, with the gold-coloured
contacts facing down.
To remove the micro SIM cards
1
Detach the back cover.
2
Drag out the micro SIM cards from their slots and remove them fully.
8
This is an Internet version of this publication. © Print only for private use.
To remove the memory card
1
Turn off the phone, or unmount the memory card from Settings > Storage >
Unmount SD card.
2
Remove the back cover, then draw the memory card outwards to remove it.
Starting your device for the first time
The first time you start your device, a setup guide opens to help you configure basic
settings, sign in to online accounts and personalise your device. For example, if you
have a Sony Entertainment Network account, you can sign in to it here and get set up
straight away.
You can also access the setup guide later from the Settings menu.
To turn on the device
Make sure that the battery is charged for at least 30 minutes before you turn on the device for
the first time.
1
Press and hold down the power key
2
Enter your SIM card PIN when requested, then tap .
3
Wait a while for the device to start.
until the device vibrates.
Your SIM card PIN is initially supplied by your network operator, but you can change it later
from the Settings menu. To correct a mistake made while entering your SIM card PIN, tap .
9
This is an Internet version of this publication. © Print only for private use.
To turn off the device
1
Press and hold down the power key until the options menu opens.
2
In the options menu, tap Power off.
3
Tap OK.
It may take a while for the device to shut down.
Why do I need a Google™ account?
Your Xperia™ device from Sony runs on the Android™ platform developed by
Google™. A range of Google™ applications and services is available on your device
when you purchase it, for example, Gmail™, Google Maps™, YouTube™ and Google
Play™, the online store for downloading Android™ applications. To get the most out
of these services, you need a Google™ account. For example, a Google™ account is
mandatory if you want to:
•
Download and install applications from Google Play™.
•
Synchronise email, contacts and the calendar.
•
Chat with friends using the Hangouts™ application.
•
Synchronise your browsing history and bookmarks.
For more information about Android™ and Google™, go to
www.sonymobile.com/support
To set up a Google™ account on your device
1
From your Home screen, tap
2
Find and tap Settings > Add account > Google.
3
Follow the registration wizard to create a Google™ account, or sign in if you
already have an account.
.
.
You can also sign in to or create a Google™ account from the setup guide the first time you
start your device. Or you can go online and create an account at
www.google.com/accounts
Charging your device
Your device has an embedded, rechargeable battery that should be replaced only by
Sony or an authorised Sony repair centre. You should never try to open or take apart
this device yourself. Opening the device can cause damage that will void your
warranty.
The battery is partly charged when the device is shipped from the factory. Depending
on how long it has been in the box before you purchased it, the battery level may be
quite low. It is therefore recommended that you change the battery for at least 30
minutes before starting up your device for the first time. You can still use your device
while it is charging. Read more about the battery and how to improve the
performance in
Battery and power management
on page 117.
.
10
This is an Internet version of this publication. © Print only for private use.
To charge your device
1
Plug the charger into a power outlet.
2
Plug one end of the USB cable into the charger (or into the USB port of a
computer).
3
Plug the other end of the cable into the micro USB port on your device, with
the USB symbol facing up. The notification light illuminates when charging
begins.
4
When the device is fully charged, disconnect the cable from your device by
pulling it straight outwards. Make sure not to bend the connector.
If the battery is completely discharged, it may take a few minutes before the notification light
illuminates and the charging icon appears.
Battery notification light status
Green The battery charge level is greater than 90%
Flashing red The battery is charging and the battery charge level is less than 15%
Orange The battery is charging and the battery charge level is less than 90%
11
This is an Internet version of this publication. © Print only for private use.
Learning the basics
Using the touchscreen
Tapping
•
Open or select an item.
•
Mark or unmark a checkbox or option.
•
Enter text using the on-screen keyboard.
Touching and holding
•
Move an item.
•
Activate an item-specific menu.
•
Activate selection mode, for example, to select several items from a list.
12
This is an Internet version of this publication. © Print only for private use.
Pinching and spreading
•
Zoom in or out on a web page, a photo or a map.
Swiping
•
Scroll up or down a list.
•
Scroll left or right, for example, between Home screen panes.
13
This is an Internet version of this publication. © Print only for private use.
Flicking
•
Scroll quickly, for example, in a list or on a web page. You can stop the scrolling
movement by tapping the screen.
Locking and unlocking the screen
When your device is on and left idle for a set period of time, the screen darkens to
save battery power and locks automatically. This lock prevents unwanted actions on
the touchscreen when you are not using it. When you buy your device, a basic screen
swipe lock is already set. In other words, you have to swipe up or down on the
screen to unlock it. You can later change the security settings and add other kinds of
locks. See
Screen lock
on page 39.
To activate the screen
•
Briefly press the power key .
To lock the screen
•
When the screen is active, briefly press the power key .
Home screen
The Home screen is the starting point for using your device. It's similar to the desktop
on a computer screen. Your Home screen can have up to seven panes, which extend
beyond the regular screen display width. The number of Home screen panes is
represented by a series of dots at the lower part of the Home screen. The highlighted
dot shows the pane that you are currently in.
14
This is an Internet version of this publication. © Print only for private use.
To go to the Home screen
•
Press .
To browse the Home screen
Home screen panes
You can add new panes to your Home screen (up to a maximum of seven panes) and
delete panes. You can also set the pane that you want to use as the main Home
screen pane.
To set a pane as the main Home screen pane
1
Touch and hold an empty area on your Home screen until the device vibrates.
2
Flick left or right to browse to the pane that you want to set as your main Home
screen pane, then tap at the top corner of the pane.
To add a pane to your Home screen
1
Touch and hold an empty area on your Home screen until the device vibrates.
2
Flick left or right to browse the panes, then tap
.
15
This is an Internet version of this publication. © Print only for private use.
To delete a pane from your Home screen
1
Touch and hold an empty area on your Home screen until the device vibrates.
2
Flick left or right to browse to the pane that you want to delete, then tap .
Application screen
The Application screen, which you open from the Home screen, contains the
applications that come pre-installed on your device as well as applications that you
download.
To view all applications on the Application screen
1
From your Home screen, tap .
2
Flick left or right on the Application screen.
To open an application from the Application screen
•
Flick left or right to find the application, and then tap the application.
To open the Application screen menu
•
When the Application screen is open, drag the left edge of the screen to the
right.
To move an application on the Application screen
1
To open the Application screen menu, drag the left edge of the Application
screen to the right.
2
Make sure that Own order is selected under SHOW APPS.
3
Touch and hold the application until it magnifies and the device vibrates, then
drag it to the new location.
To add an application shortcut to the Home screen
1
From the Application screen, touch and hold an application icon until the
screen vibrates, then drag the icon to the top of the screen. The Home screen
opens.
2
Drag the icon to the desired location on the Home screen, then release your
finger.
To arrange applications on the Application screen
1
To open the Application screen menu, drag the left edge of the Application
screen to the right.
2
Select the desired option under SHOW APPS.
16
This is an Internet version of this publication. © Print only for private use.
To search for an application from the Application screen
1
To open the Application screen menu, drag the left edge of the Application
screen to the right.
2
Tap Search apps.
3
Enter the name of the application that you want to search for.
To uninstall an application from the Application screen
1
To open the Application screen menu, drag the left edge of the Application
screen to the right.
2
Tap Uninstall. All uninstallable applications are indicated by .
3
Tap the application that you want to uninstall, then tap Uninstall.
Navigating applications
You can navigate between applications using the navigation keys, the favourites bar,
and the recently used applications window, which lets you switch easily between all
recently used applications. Some applications are closed when you press
while others are paused or continue to run in the background. If the application is
paused or runs in the background, you can continue where you left off the next time
you open the application.
to exit
1 Recently used applications window – Open a recently used application
2 Favourites bar – Use a shortcut to access applications or widgets
3 Task navigation key – Open the recently used applications window and the favourites bar
4 Home navigation key – Exit an application and go back to the Home screen
5 Back navigation key – Go back to the previous screen within an application or close the application
To open the recently used applications window
•
Press .
To close all the recently used applications
•
Tap and then tap Close all.
To open a menu in an application
•
While using the application, press .
A menu is not available in all applications.
17
This is an Internet version of this publication. © Print only for private use.
Small apps
Small apps are miniature apps that run on top of other applications on the same
screen, to enable multi-tasking. For example, you can have a webpage open showing
details of currency exchange rates and then open the Calculator small app on top of
it and perform calculations. You can access your small apps via the favourites bar. To
download more small apps, go to Google Play™.
To open a small app
1
To make the favourites bar appear, press
2
Tap the small app that you want to open.
You can open several small apps at the same time.
To close a small app
•
Tap on the small app window.
To download a small app
1
From the favourites bar, tap
2
Search for the small app that you want to download, then follow the
instructions to download it and complete the installation.
To move a small app
•
When the small app is open, touch and hold the top left corner of the small
app, then move it to the desired location.
, then tap and tap .
.
To minimise a small app
•
When the small app is open, touch and hold the top left corner of the small
app, then drag it to the right edge or to the bottom edge of the screen.
To rearrange the small apps in the favourites bar
•
Touch and hold a small app and drag it to the desired position.
To remove a small app from the favourites bar
1
Touch and hold a small app, then drag it to .
2
Tap OK.
To restore a previously removed small app
1
Open the favourites bar, then tap
2
Touch and hold the small app that you want to restore, then drag it into the
favourites bar.
To add a widget as a small app
1
To make the favourites bar appear, press .
2
Tap > > .
3
Select a widget.
4
Enter a name for the widget, if desired, then tap OK.
.
Widgets
Widgets are small applications that you can use directly on your Home screen. They
also function as shortcuts. For example, the Weather widget allows you to see basic
weather information directly on your Home screen. But when you tap the widget, the
full Weather application opens. You can download additional widgets from Google
Play™.
18
This is an Internet version of this publication. © Print only for private use.
To add a widget to the Home screen
1
Touch and hold an empty area on your Home screen until the device vibrates,
then tap Widgets.
2
Find and tap the widget that you want to add.
To resize a widget
1
Touch and hold a widget until it magnifies and the device vibrates, then release
the widget. If the widget can be resized, for example, the Calendar widget,
then a highlighted frame and resizing dots appear.
2
Drag the dots inward or outward to shrink or expand the widget.
3
To confirm the new size of the widget, tap anywhere on the Home screen.
To move a widget
•
Touch and hold the widget until it magnifies and the device vibrates, then drag
it to the new location.
To remove a widget
•
Touch and hold the widget until it magnifies and the device vibrates, then drag
on the top of the screen.
it to
Shortcuts and folders
Use shortcuts and folders to manage your applications and keep your Home screen
tidy.
19
This is an Internet version of this publication. © Print only for private use.
1 Access an application using a shortcut
2 Access a folder containing applications
To add an application shortcut to your Home screen
1
Touch and hold an empty area on your Home screen until the device vibrates
and the customisation menu appears.
2
In the customisation menu, tap Apps.
3
Scroll through the list of applications and select an application. The selected
application gets added to the Home screen.
In step 3, alternatively, you can tap Shortcuts and then select an application from the list
available. If you use this method to add shortcuts, some of the applications available allow
you to add specific functionality to the shortcut.
To move an item on the Home screen
•
Touch and hold the item until it magnifies and the device vibrates, then drag
the item to the new location.
To remove an item from the Home screen
•
Touch and hold an item until it magnifies and the device vibrates, then drag the
item to
on the top of the screen.
To create a folder on the Home screen
•
Touch and hold an application icon or a shortcut until it magnifies and the
device vibrates, then drag and drop it on top of another application icon or
shortcut.
To add items to a folder on the Home screen
•
Touch and hold an item until it magnifies and the device vibrates, then drag the
item to the folder.
To rename a folder on the Home screen
1
Tap the folder to open it.
2
Tap the folder's title bar to show the Folder name field.
3
Enter the new folder name and tap Done.
Background and themes
You can adapt the Home screen to your own style using wallpapers and different
themes. You can also change the wallpaper on the lock screen.
20
This is an Internet version of this publication. © Print only for private use.
To change your Home screen wallpaper
1
Touch and hold an empty area on your Home screen until the device vibrates.
2
Tap Wallpapers and select an option.
To set a theme
1
Touch and hold an empty area on your Home screen until the device vibrates.
2
Tap Themes.
3
Select an option and follow the instructions in your device.
When you change a theme, the background also changes in some applications.
To change the wallpaper for the lock screen
1
From your Home screen, tap
2
Find and tap Settings > Personalization> Lock screen.
3
Select an option, then follow the instructions to change your wallpaper.
.
Taking a screenshot
You can capture still images of any screen on your device as a screenshot.
Screenshots you take are automatically saved in Album.
To take a screenshot
1
Press and hold down the power key until a prompt window appears.
2
Tap
You can also take the screenshot by pressing the power key and volume down key at the
same time until you hear a clicking sound.
To view your screenshot
•
Drag the status bar fully downwards, then tap the screenshot you want to view.
You can also view your screenshots by opening the Album application.
Status and notifications
The icons in the status bar inform you of events such as new messages and calendar
notifications, activities in progress such as file downloads, and status information
such as battery level and signal strength. You can drag down the status bar to open
the Notification panel and handle your notifications. You can also customise the icons
and notifications by selecting which system icons to display in the status bar and
selecting apps that are allowed to send notifications.
21
This is an Internet version of this publication. © Print only for private use.
To open or close the Notification panel
To take action on a notification
•
Tap the notification.
To dismiss a notification from the Notification panel
•
Place your finger on a notification and flick left or right.
To clear all notifications from the Notification panel
•
Tap Clear.
Notification light
The notification light informs you about battery status and some other events. For
example, a flashing white light means there is a new message or a missed call.
Icons in the status bar
Status icons
Signal strength
No signal
Roaming
LTE is available
GPRS is available
EDGE is available
3G is available
Mobile data network is available
Sending and downloading LTE data
Sending and downloading GPRS data
22
This is an Internet version of this publication. © Print only for private use.
Sending and downloading EDGE data
Sending and downloading 3G data
Sending and downloading mobile data
Battery status
The battery is charging
STAMINA mode is activated
Low battery mode is activated
Airplane mode is activated
The Bluetooth® function is activated
The SIM card is not inserted
SIM card 1 is inserted
SIM card 2 is inserted
The microphone is muted
The speakerphone is on
Silent mode
Vibrate mode
An alarm is set
GPS is activated
Synchronisation is ongoing
Problem with sign-in or synchronisation
Depending on your service provider, network and/or region, the functions or services
represented by some icons in this list may not be available.
To manage status bar icons
1
From your Home screen, tap .
2
Find and tap Settings > Personalization> Status bar icons.
3
Mark the checkboxes for the system icons that you want to appear in the
status bar.
Notification icons
New text message or multimedia message
Missed call
Call ongoing
Call forwarding is turned on
New voicemail message
New email message
A Wi-Fi® connection is enabled and data is being transmitted
Downloading data
Uploading data
23
This is an Internet version of this publication. © Print only for private use.
Mobile data is disabled
A software update is available
System updates are available
Downloading system updates
Tap to install the downloaded system updates
Screenshot captured
New Hangouts™ chat message has arrived
Video chat with friends using the Hangouts™ application
Upcoming calendar event
A small app is running
Smart Connect is activated
A song is playing
The radio is playing
The device is connected to a computer via a USB cable
Internal storage is 75% full. Tap to transfer data to the memory card
Warning message
Error message
More (undisplayed) notifications
Not all icons that may appear in your device are listed here. These icons are for reference
purposes only, and changes may be made without notice.
To manage notifications
1
From your Home screen, tap .
2
Find and tap Settings > Personalization> Manage notifications.
3
Mark the checkboxes for the apps that are allowed to send notifications.
Application overview
Use the Alarm & clock application to set various kinds of alarms.
Use your web browser to navigate and view web pages, manage bookmarks,
text and images.
Use the Calculator application to perform basic calculations.
Use the Calendar application to keep track of events and manage your
appointments.
Use the camera to take photos and record video clips.
Use the Contacts application to manage phone numbers, email address and
other information related to your contacts.
Access your downloaded applications, documents and pictures.
Use the Email application to send and receive emails through both private
and corporate accounts.
24
This is an Internet version of this publication. © Print only for private use.
Use the Facebook™ application to engage in social networking with friends,
family members and colleagues around the world.
Browse and listen to FM radio stations.
Use the Album application to view and to work with your photos and videos.
Use the Gmail™ application to read, write and organise email messages.
Search for information in your device and on the web.
View your current location, find other locations and calculate routes using
Google Maps™.
Go to Google Play™ to download free and paid applications for your device.
Use the Messaging application to send and receive text and multimedia
messages.
Use the Movies application to play videos on your device and share content
with your friends.
Use the Walkman® application to organise and play music, audio books and
podcasts.
View news stories and weather forecasts.
Make phone calls by dialling the number manually or by using the smart dial
function.
Optimise settings to suit your own requirements.
Use the Hangouts™ application to chat with friends online.
Identify music tracks that you hear playing in your surroundings, and get
artist, album and other info.
Use YouTube™ to share and view videos from around the world.
Use the Support application to access user support in the device. For
example, you can access a User guide, troubleshooting information, plus tips
and tricks.
Download and install new applications and updates.
Some applications are not supported or listed by all networks and/or service providers in all
areas.
25
This is an Internet version of this publication. © Print only for private use.
Downloading applications
Downloading applications from Google Play™
Google Play™ is the official online Google store for downloading applications,
games, music, movies and books. It includes both free and paid applications. Before
you start downloading from Google Play™, make sure that you have a working
Internet connection, preferably over Wi-Fi® to limit data traffic charges.
To use Google Play™, you need to have a Google™ account. Google Play™ may not be
available in all countries or regions.
To download an application from Google Play™
1
From the Home screen, tap
2
Find and tap Play Store.
3
Find an item you wish to download by browsing categories, or by using the
search function.
4
Tap the item to view its details, and follow the instructions to complete the
installation.
Some applications may need to access data, settings and various functions on your device in
order to work properly. Only install and give permissions to applications that you trust.
You can view the permissions granted to a downloaded application by tapping the application
under Settings > Apps.
.
Downloading applications from other sources
When your device is set to allow downloads from sources other than Google Play™,
you can download applications directly from other websites by following the relevant
download instructions.
Installing applications of unknown or unreliable origin can damage your device. Only download
applications from reliable sources. Contact the application provider if you have any questions
or concerns.
To allow the download of applications from other sources
1
From your Home screen, tap .
2
Find and tap Settings > Security.
3
Mark the Unknown sources checkbox.
4
Tap OK.
Some applications may need to access data, settings and various functions on your device in
order to work properly. Only install and give permissions to applications you trust.
You can view the permissions granted to a downloaded application by tapping the application
under Settings > Apps.
26
This is an Internet version of this publication. © Print only for private use.
Internet and networks
Browsing the web
The Google Chrome™ web browser for Android™ devices comes pre-installed in
most markets. Go to http://support.google.com/chrome and click the "Chrome for
Mobile" link to get more detailed information about how to use this web browser.
To browse with Google Chrome™
1
From your Home screen, tap
2
Find and tap .
3
If you are using Google Chrome™ for the first time, select to either sign in to a
Google™ account or browse with Google Chrome™ anonymously.
4
Enter a search term or web address in the search and address field, then tap
Go on the keyboard.
Internet and MMS settings
To send multimedia messages, or to access the Internet when there is no available
Wi-Fi® network, you must have a working mobile data connection with the correct
Internet and MMS (Multimedia Messaging Service) settings. Here are some tips:
•
For most mobile networks and operators, Internet and MMS settings come preinstalled on your device. You can then start using the Internet and send multimedia
messages right away.
•
In some cases, you get the option to download Internet and MMS settings the first
time you turn on your device when a SIM card is inserted. It is also possible to
download these settings later from the Settings menu.
•
You can manually add, change or delete Internet and MMS settings on your device at
any time. If you change or delete an Internet or MMS setting by mistake, download
the Internet and MMS settings again.
•
If you cannot access the Internet over a mobile network or if multimedia messaging is
not working, even though the Internet and MMS settings have been downloaded
successfully to your device, refer to the troubleshooting tips for your device at
www.sonymobile.com/support/
If STAMINA mode is activated to save power, all mobile data traffic gets paused when the
screen is off. If this causes connection problems, try excluding some applications and services
from being paused, or deactivate STAMINA mode temporarily. For more information, see
STAMINA mode feature overview
.
for network coverage, mobile data, and MMS issues.
on page 118.
To download Internet and MMS settings
1
From your Home screen, tap .
2
Find and tap Settings > More… > Internet settings.
3
Select the SIM card, or SIM cards, for which you want to download Internet
and MMS settings.
4
Tap Accept. Once the settings have been downloaded successfully, appears
in the status bar and mobile data is turned on automatically.
If the settings cannot be downloaded to your device, check the signal strength of your mobile
network. Move to an open location free from obstructions or get close to a window and then
try again.
To check whether mobile data is turned on or off
1
From your Home screen, tap .
2
Find and tap Settings > More… > Mobile networks.
3
Select a SIM card.
4
Check whether the Mobile data traffic checkbox is marked or not.
27
This is an Internet version of this publication. © Print only for private use.
To add Internet and MMS settings manually
1
From your Home screen, tap .
2
Find and tap Settings > More… > Mobile networks.
3
Select a SIM card.
4
Tap Access Point Names > .
5
Tap Name and enter a name as desired.
6
Tap APN and enter the access point name.
7
Enter all other information as required. If you don’t know what information is
required, contact your network operator for more details.
8
When you're done, tap
9
To select the APN that you have just added, tap the radio button besides the
, then tap Save.
name of the APN. Once selected, this APN becomes the default APN for
Internet and MMS services.
To view the downloaded Internet and MMS settings
1
From your Home screen, tap
2
Find and tap Settings > More… > Mobile networks.
3
Select a SIM card.
4
Tap Access Point Names.
5
To view more details, tap any of the available items.
If you have several available connections, the active network connection is indicated by a
marked button .
.
Wi-Fi®
Use Wi-Fi® connections to surf the Internet, download applications, or send and
receive emails. Once you have connected to a Wi-Fi® network, your device
remembers the network and automatically connects to it the next time you come
within range.
Some Wi-Fi® networks require you to log in to a web page before you can get
access. Contact the relevant Wi-Fi® network administrator for more information.
Available Wi-Fi® networks may be open or secured:
•
Open networks are indicated by
•
Secured networks are indicated by
Some Wi-Fi® networks do not show up in the list of available networks because they do not
broadcast their network name (SSID). If you know the network name, you can add it manually
to your list of available Wi-Fi® networks.
To turn on Wi-Fi®
1
From your Home screen, tap .
2
Find and tap Settings.
3
Drag the slider beside Wi-Fi to the right to turn on the Wi-Fi® function.
It may take a few seconds before Wi-Fi® is enabled.
To connect to a Wi-Fi® network automatically
1
From your Home screen, tap .
2
Find and tap Settings.
3
Tap Wi-Fi. All available Wi-Fi® networks are displayed.
4
Tap a Wi-Fi® network to connect to it. For secured networks, enter the
relevant password. is displayed in the status bar once you are connected.
next to the Wi-Fi® network name.
next to the Wi-Fi® network name.
To search for new available networks, tap
network successfully, refer to the relevant troubleshooting tips for your device at
www.sonymobile.com/support/
.
, then tap Scan. If you cannot connect to a Wi-Fi
28
This is an Internet version of this publication. © Print only for private use.
To add a Wi-Fi® network manually
1
From your Home screen, tap .
2
Find and tap Settings > Wi-Fi.
3
Tap .
4
Enter the Network name (SSID) information.
5
To select a security type, tap the Security field.
6
If required, enter a password.
7
To edit some advanced options such as proxy and IP settings, mark the Show
advanced options checkbox and then edit as desired.
8
Tap Save.
Contact your Wi-Fi® network administrator to get the network SSID and password.
Increasing Wi-Fi® signal strength
There are a number of things you can do to increase the strength of a Wi-Fi® signal:
•
Move your device closer to the Wi-Fi® access point.
•
Move the Wi-Fi® access point away from any potential obstructions or interference.
•
Don’t cover the Wi-Fi® antenna area of your device (the highlighted area in the
illustration).
Wi-Fi® settings
When you are connected to a Wi-Fi® network or when there are Wi-Fi® networks
available in your vicinity, it is possible to view the status of these networks. You can
also enable your device to notify you whenever an open Wi-Fi® network is detected.
If you are not connected to a Wi-Fi® network, your device uses a mobile data
connection to access the Internet (if you have set up and enabled a mobile data
connection on your device). By adding a Wi-Fi® sleep policy, you can specify when
to switch from Wi-Fi® to mobile data.
To enable Wi-Fi® network notifications
1
Turn on Wi-Fi®, if it is not already on.
2
From your Home screen, tap
3
Find and tap Settings > Wi-Fi.
4
Press .
5
Tap Advanced.
6
Mark the Network notification checkbox.
To view detailed information about a connected Wi-Fi® network
1
From the Home screen, tap .
2
Find and tap Settings > Wi-Fi.
3
Tap the Wi-Fi® network that you are currently connected to. Detailed network
information is displayed.
.
29
This is an Internet version of this publication. © Print only for private use.
To add a Wi-Fi® sleep policy
1
From the Home screen, tap .
2
Find and tap Settings > Wi-Fi.
3
Press .
4
Tap Advanced.
5
Tap Keep Wi-Fi on during sleep.
6
Select an option.
Sharing your mobile data connection
You can share your device's mobile data connection with a single computer using a
USB cable. This process is called USB tethering. You can also share your device's
data connection with up to eight other devices at once by turning your device into a
portable Wi-Fi® hotspot. When your device's mobile data connection is successfully
shared, the sharing devices can use your device's data connection, for example, to
surf the Internet, download applications, or send and receive emails.
You may need to prepare your computer to establish a network connection via USB cable. Go
to www.android.com/tether to get the most current information.
To share your data connection using a USB cable
1
Deactivate all USB cable connections to your device.
2
Using the USB cable that came with your device, connect your device to a
computer.
3
From your Home screen, tap
4
Find and tap Settings > More… > Tethering & portable hotspot.
5
Mark the USB tethering checkbox, then tap OK if prompted.
the status bar once you are connected.
6
To stop sharing your data connection, unmark the USB tethering checkbox or
disconnect the USB cable.
.
is displayed in
You cannot share your device's data connection and SD card over a USB cable at the same
time.
To use your device as a portable Wi-Fi® hotspot
1
From your Home screen, tap .
2
Find and tap Settings > More… > Tethering & portable hotspot.
3
Tap Portable Wi-Fi hotspot settings > Configure Wi-Fi hotspot.
4
Enter the Network name (SSID) information.
5
To select a security type, tap the Security field. If required, enter a password.
6
Tap Save.
7
Tap and mark the Portable Wi-Fi hotspot checkbox.
8
If prompted, tap OK to confirm. appears in the status bar once the portable
Wi-Fi® hotspot is active.
9
To stop sharing your data connection via Wi-Fi®, unmark the Portable Wi-Fi
hotspot checkbox.
To rename or secure your portable hotspot
1
From the Home screen, tap .
2
Find and tap Settings > More… > Tethering & portable hotspot.
3
Tap Portable Wi-Fi hotspot settings > Configure Wi-Fi hotspot.
4
Enter the Network name (SSID) for the network.
5
To select a security type, tap the Security field.
6
If required, enter a password.
7
Tap Save.
Controlling data usage
You can keep track of the amount of data transferred to and from your device over
your mobile data or Wi-Fi® connection during a given period. For example, you can
30
This is an Internet version of this publication. © Print only for private use.
Loading...
