Sony E1004, E1003, E1002 Instruction Manual
GB
Instruction Manual
PSP-E1004 7017787
Table of contents
Warning and caution
WARNING······················································ 4
Precautions ···················································· 6
Using the PSP® system
Part names and functions ·····························10
Charging the battery ·····································12
Turning the system on and off·······················15
Using the XMBTM (XrossMediaBar) menu······16
Playing Universal Media Disc games ············18
Playing Memory Stick DuoTM content·············19
Using the on-screen keyboard ····················· 20
Setting the parental control level ·················· 22
Updating the system software ····················· 24
Downloading games ···································· 26
2
Table of contentsTable of contents
Support
Troubleshooting ··········································· 28
Additional information
Before disposing of or transferring
the PSP® system ······································ 33
Specifications··············································· 34
Compatible media ········································ 35
Copyright and trademarks ··························· 37
Information about system functionality and images
published in this document may vary from those for your
PSP® system, depending on the system software version
in use.
PSP® system documentation
You can find information about the PSP® system in this
manual as well as online.
• Instruction Manual (this document)
This manual explains hardware features and provides
basic information about how to set up and operate the
PSP® system, including instructions on how to
download and start playing games. The manual also
includes warnings and precautions for the safe and
proper use of the system.
• User’s Guide
This online guide contains detailed information about
using PSP® system features. You can view the online
user’s guide using a PC Web browser.
eu.playstation.com/psp/support/manuals
Table of contents
3
WARNING
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
CAUTION - Use of controls or adjustments or
performance of procedures other than those specified
herein may result in hazardous radiation exposure.
CLASS 1 LASER PRODUCT
LASER KLASSE 1 PRODUKT
This appliance is classified as a CLASS 1 LASER product under
IEC60825-1+A2: 2001.
This product is intended for ages 6 and up.
Avoid prolonged use of the PSP
strain, take a break of about 15 minutes during every hour
of play.
If you experience any of the following health problems,
discontinue use of the system immediately. If symptoms persist,
consult with your doctor.
– Dizziness, nausea, fatigue or symptoms similar to motion
sickness
– Discomfort or pain in a part of the body, such as eyes, ears,
hands or arms
4
WARNING
® system. To help prevent eye
Regulatory information
The nameplate is located inside the disc cover of the system.
The manufacturer of this product is Sony Computer Entertainment
Inc., 1-7-1 Konan, Minato-ku, Tokyo 108-0075 Japan.
The Authorised Representative for EMC and product safety is Sony
Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart,
Germany.
Distributed in Europe by Sony Computer Entertainment Europe Ltd,
10 Great Marlborough Street, London, W1F 7LP.
Photosensitivity
Always play in a well lit environment. Take regular breaks, 15
minutes every hour. Avoid playing when tired or suffering from lack
of sleep. Some individuals are sensitive to flashing or flickering
lights or geometric shapes and patterns, may have an undetected
epileptic condition and may experience epileptic seizures when
watching television or playing videogames. Consult your doctor
before playing videogames if you have an epileptic condition and
immediately should you experience any of the following symptoms
whilst playing: dizziness, altered vision, muscle twitching, other
involuntary movement, loss of awareness, confusion and/or
convulsions.
Repetitive Motion Injuries
Avoid prolonged use of the PSP® system. Take a 15 minute break
every hour. Stop using the PSP
experience an unpleasant sensation or pain in your hands, wrists or
arms. If the condition persists, consult a doctor.
® system immediately if you
Headphones
Adjust your headphone volume so that surrounding sounds can be
heard. If you experience ringing or any discomfort in your ears,
discontinue use of your Headphones.
System Software
The System Software included within this product is subject to a
limited licence from Sony Computer Entertainment Inc. Refer to
http://www.scei.co.jp/psp-eula/ for further details.
About national export control
This product may fall within the scope of national export control
legislation. You must comply fully with the requirements of such
legislation and of all other applicable laws of any jurisdiction in
relation to this product.
GB
Warning and caution
WARNING
5
Precautions
Before using this product, carefully read this manual and retain it
for future reference.
Accessory compatibility
Do not use accessories or peripherals that are intended for
another model of the PSP
peripherals may not be compatible with your system.
Visit http://eu.playstation.com/psp for details.
Safety
This product has been designed with the highest concern for safety.
However, any electrical device, if used improperly, has the potential
for causing fire, electrical shock or personal injury. To help ensure
accident-free operation, follow these guidelines:
Observe all warnings, precautions and instructions.
Regularly inspect the AC adaptor.
Stop use, unplug the AC adaptor from the electrical outlet and
disconnect any other cables immediately if the device functions in
an abnormal manner, produces unusual sounds or smells or
becomes too hot to touch, or has become misshapen.
6
Precautions
® system, as these accessories/
Use and handling
Use in a well-lit area and keep the screen a safe distance from
your face.
Keep the system and accessories out of the reach of small
children. Small children may swallow the Memory Stick Duo
media or wrap the cables/straps around themselves, which may
inflict injury or cause an accident or a malfunction.
Do not use the system while driving or riding a bicycle.
Do not use the system or accessories near water.
Use only attachments/accessories specified by the manufacturer.
Do not expose the system or accessories to high temperatures,
high humidity, or direct sunlight.
Do not leave the system or accessories in a car with the windows
closed (particularly in summer).
Do not expose the system or accessories to dust, smoke
or steam.
Do not allow liquid or small particles to get into the system
or accessories.
Do not place the system or accessories on surfaces that are tilted,
unstable or subject to vibration.
Do not throw, drop or step on the system or accessories, and do
not subject the devices to strong physical shock. Sitting down
with the PSP
bottom of a backpack along with heavy objects may cause
damage to the system.
® system in a pocket or placing the system in the
™
Do not forcibly twist the PSP
strong physical shock during gameplay, as doing so can damage
the system.
Handle the analog stick with care.
Do not put heavy objects on the system or accessories.
Do not touch or insert foreign objects into the connectors of the
system or accessories.
Depending on the conditions of use, the system or AC adaptor
may reach temperatures of 40°C or more. Do not touch the system
or AC adaptor for an extended period of time under these
conditions. Extended contact under these conditions may cause
low-temperature burns*.
* Low-temperature burns are burns that occur when the skin
is in contact with objects of relatively low temperatures
(40°C or more) for an extended period of time.
® system or expose the system to
AC adaptor use
For your safety, use only a supplied AC adaptor. Other types may
cause fire, electrical shocks or a malfunction.
Do not touch the plug of the AC adaptor with wet hands.
Do not touch the AC adaptor or the system, if connected to an
electrical outlet, during an electrical storm.
Do not allow dust or foreign matter to build up around the system
or accessory connectors. If there is dust or foreign matter on the
system’s connectors or the AC adaptor, wipe it off with a dry
cloth before connecting. Dust or other matter on the connectors
can result in fire or electrical shock.
Unplug the AC adaptor from the electrical outlet and disconnect
any other cables from the system before cleaning or when you do
not intend to use the system for an extended period of time.
Protect the AC adaptor from being walked on or pinched
particularly at plugs, convenience receptacles and the point where
they exit from the system.
When disconnecting the AC adaptor, hold it by the plug and pull
straight out from the electrical outlet. Never pull by the cord and
do not pull at an angle.
Do not use the system to play games or video when the system is
covered with any type of fabric. If you want to pause or
temporarily store the system while playing games or video, put
the system in sleep mode before placing it in the case or covering.
Also do not use the AC adaptor when covered with fabric to help
avoid overheating.
Do not connect the AC adaptor to a voltage transformer or
inverter. Connecting the AC adaptor to a voltage transformer for
overseas travel or an inverter for use in an automobile may cause
heat to build up in the AC adaptor and may cause burns or a
malfunction.
Precautions
Warning and caution
7GB7
7
LCD screen
The LCD screen is made of glass and may crack if subjected to
excessive force.
Pixels that are not lit or are continuously lit may appear in certain
locations on the LCD screen. The appearance of such spots is a
normal occurrence associated with LCD screens and is not a sign
of a system malfunction. LCD screens are made using highly
precise technology. However, a very small number of dark pixels
or continuously lit pixels exist on each screen. Also, a distorted
image may remain on the screen for several seconds after the
system has been turned off.
Direct exposure to sunlight may damage the system’s LCD
screen. Be careful when using the system outdoors or near a
window.
When using the system in a cold environment, you may notice
shadows on the graphics or the screen may appear darker than
usual. This is not a malfunction, and the screen will return to
normal when the temperature goes up.
Do not leave still images displayed on the screen for an extended
period of time, as doing so may cause a faint image to be left
permanently on the screen.
8
Precautions
About the “pickup”
Do not touch the “pickup” located inside the disc cover of the
system. Touching the pickup may damage the system.
Pickup
Never disassemble the system or accessories
Use the PSP® system and accessories according to the instructions
in this manual. No authorisation for the analysis or modification of
the system, or the analysis and use of its circuit configurations, is
provided. Disassembling will void the system warranty and may be
harmful. The LCD screen, in particular, contains dangerous,
high-voltage parts, and the laser beam for reading Universal Media
Disc may cause visual impairment if exposed directly to the eyes.
Moisture condensation
If the PSP® system or Universal Media Disc is brought directly from
a cold location to a warm one, moisture may condense on the lens
inside the system or on the Universal Media Disc. Should this occur,
the system may not operate properly. In this case, remove the
Universal Media Disc and turn off and unplug the system. Do not
put the Universal Media Disc back in until the moisture evaporates
(this may take several hours). If the system still does not operate
properly, contact the appropriate PSP
which can be found within every PSP
Universal Media Disc handling
Do not touch the opening on the rear of the disc (recorded surface
of the disc) with your fingers.
Do not allow dust, sand, foreign objects or other types of dirt to
get on the disc.
If the Universal Media Disc becomes dirty, gently wipe the
exterior and recorded surfaces of the Universal Media Disc using
a soft cloth. Do not use solvents or other chemicals.
Do not use a Universal Media Disc that is cracked or warped or
has been repaired. The Universal Media Disc may break inside
the PSP
® system, leading to injury or malfunction.
Handling and care of exterior surfaces
Follow the guidelines listed below to help avoid deterioration or
discolouration of the PSP
Do not use solvents or other chemicals to clean the exterior
surface.
Do not allow the system to remain in direct contact with rubber or
vinyl products for an extended period of time.
® customer service helpline
® format software manual.
® system.
Do not use a chemically-treated cleaning cloth to wipe off the
system.
Before using the analog stick
Do not attempt to remove the analog stick from the system front,
as doing so will damage the system and may result in injury.
For best results, go to
and then with the [System Information] screen displayed, rotate
the analog stick in a circular motion to adjust the analog stick’s
range of movement.
Cleaning
For safety reasons, unplug the AC adaptor from the electrical outlet
and disconnect any other cables before cleaning the system.
Cleaning the exterior surface and LCD screen
Wipe gently with a soft cloth.
Cleaning the connectors
If the connectors on the PSP® system or on the USB cable become
dirty, signals may not be sent or received properly. Also, if the
connector on the headphones becomes dirty, you may experience
noise or interruptions in sound. Wipe the connectors with a dry, soft
cloth to keep in clean condition.
Cases and coverings
When placing the PSP® system in a commercially available case,
turn off the power or put the system in sleep mode. Do not use the
system while it is in the case. Leaving the system on, or using it
while in a case or covering may cause overheating or may damage
the system.
(Settings) (System Settings),
GB
Warning and caution
Precautions
9
Part names and functions
3
4 5
2
1
11 12 13 14 15
10
Part names and functions
7 896
10
System bottom
1716 18
1
Directional buttons
2
Speaker
3
L button
4
Memory Stick PRO Duo™ slot
5
Memory Stick PRO Duo™
access indicator
Lights up when data is being
read or written from Memory
TM
Stick Duo
media.
Notice
When the Memory Stick PRO
Duo™ access indicator is lit, do
not eject the Memory Stick
Duo™ media, turn off the
system, or put the system into
sleep mode, as doing so may
cause data loss or corruption.
6
POWER indicator
Solid green
Power on
Solid orange
Charging
Flashing green
Charge level low
Light off
Power off/In sleep mode
7
USB connector
8
LCD screen
9
R button
10
button, button,
button, button
11
Analog stick
For use with games that support
analog stick operation
12
PS button
13
Volume button
14
Select button
15
START button
16
Strap holder
Attach a strap (sold separately) as
shown below.
17
POWER/HOLD switch
Slide right
Turn the system on and off
(
page 15).
Slide left
Lock the system buttons.
18
Headset connector
GB
Using the PSP® system
Part names and functions
11
Charging the battery
Before using the PSP® system for the first time after
purchase, or when the battery charge level is low, follow
the steps below to charge the battery.
Caution
Stop use, unplug the AC adaptor from the electrical outlet
and disconnect any other cables immediately if the device
functions in an abnormal manner, produces unusual sounds
or smells or becomes too hot to touch, or has become
misshapen.
Do not plug the AC adaptor for the PSP
electrical outlet until you have made all other connections.
The socket-outlet shall be installed near the equipment and
shall be easily accessible.
12
Charging the battery
® system into an
Charging methods
Charging with an AC adaptor
The system’s battery can be charged using an AC adaptor.
POWER indic ator
1
2
To e lectr ica l ou tle t
The power indicator lights up in orange, indicating that
charging has begun. The power indicator turns off when
the battery is fully charged.
Loading...
