Sony DVP-S9 Service Manual

Download

Page 1

DVP-S9

SERVICE MANUAL

Ver 1.7 2004.09

DVP-S9 is the D VD/Video CD/CD pla yer section in MHC-S9D.

SPECIFICATIONS

AEP Model

UK Model

E Model

Austr alian Model

Model Name Using Similar Mechanism NEW CD Mechanism Type CDM63D

Optical Pick-up Name

KHM-240AAA (TYPE A) KHM-270AAA (TYPE B)

DVD/Video CD/CD player section

Laser Semiconductor laser

Frequency response DVD (PCM 48 kHz):

Signal-to-noise ratio More than 90 dB Dynamic range More than 90 dB Video color system format

OPTICAL OUT (Square optical connector jack, rear panel)

General

Power requirements European model: 230 V AC, 50/60 Hz Australian model: 230 – 240 V AC,

Mexican model: 120 V AC, 60 Hz Korean model: 220 V AC, 60 Hz Thailand model: 220 V AC, 50/60 Hz Other models: 120 V, 220 V or

Dimensions (w/h/d) Mass Approx. 2.9 kg Design and specifications are subject to change

without notice.

(λ=660 nm/780 nm) Emission duration: continuous

2 Hz – 22 kHz = (±1 dB) CD: 2Hz – 20 kHz = (±1 dB)

NTSC, PAL

50/60 Hz

230 – 240 V AC, 50/60 Hz

Approx. 280 x 108 x 330 mm

9-873-280-08 Sony Corporation

DVD/VIDEO CD/CD PLAYER

Page 2

DVP-S9

CAUTION

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior.

CAUTION

The use of optical instruments with this product will increase eye hazard. As the laser beam used in this CD/DVD Player is harmful to eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

The following caution label is located inside the apparatus.

NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT

The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care.

NOTES ON LASER DIODE EMISSION CHECK

The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick-up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objectiv e lens.

Notes on chip component replacement

•Never reuse a disconnected chip component.

• Notice that the minus side of a tantalum capacitor may be damaged by heat.

Flexible Circuit Board Repairing

•Keep the temperature of the soldering iron around 270 ˚C during repairing.

• Do not touch the soldering iron on the same conductor of the circuit board. (within 3 times)

• Be careful not to apply force on the conductor when soldering or unsoldering.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

Page 3

DVP-S9

1. SERVICING NOTES ............................................... 3

2. GENERAL ................................................................... 5

3. DISASSEMBLY

3-1. Disassembly Flow ........................................................... 6

3-2. Cover ............................................................................... 7

3-3. CD Mechanism Deck (CDM63D) .................................. 7

3-4. MB Board........................................................................ 8

3-5. VIDEO Board .................................................................. 8

3-6. MAIN Board ................................................................... 9

3-7. Front Panel Section......................................................... 9

3-8. PANEL Board, SUB PANEL Board............................... 10

3-9. Lid (CD) .......................................................................... 10

4. TEST MODE.............................................................. 11

5. ELECTRICAL ADJUSTMENTS......................... 22

6. DIAGRAMS

6-1. Block Diagram – RF/SERVO Section – ........................ 23

6-2. Block Diagram – MAIN Section (1/2) –....................... 24

6-3. Block Diagram – MAIN Section (2/2) –....................... 25

6-4. Block Diagram

– INTERFACE CONTROL Section – ............................ 26

6-5. Note For Printed Wiring Boards

and Schematic Diagrams ................................................ 27

6-6. Printed W iring Board – RF Board – .............................. 28

6-7. Schematic Diagram – RF Board –................................. 29

6-8. Printed Wiring Boards – DISC SENSOR/DRIVER/

IN OUT SW/MOTOR/TRAY SENSOR Boards – ......... 30

6-9. Schematic Diagram – DISC SENSOR/DRIVER/

IN OUT SW/MOTOR/TRAY SENSOR Boards – ......... 31

6-10. Printed W iring Board

– MB Board (Component Side) –................................... 32

6-11. Printed W iring Board

– MB Board (Conductor Side) –..................................... 33

6-12. Schematic Diagram – MB Board (1/6) –....................... 34

6-13. Schematic Diagram – MB Board (2/6) –....................... 35

6-14. Schematic Diagram – MB Board (3/6) –....................... 36

6-15. Schematic Diagram – MB Board (4/6) –....................... 37

6-16. Schematic Diagram – MB Board (5/6) –....................... 38

6-17. Schematic Diagram – MB Board (6/6) –....................... 39

6-18. Printed W iring Board – MAIN Board – ........................ 40

6-19. Schematic Diagram – MAIN Board –........................... 41

6-20. Printed W iring Boards

– PANEL/SUB PANEL/VIDEO Boards – ..................... 42

6-21. Schematic Diagram

– PANEL/SUB PANEL/VIDEO Boards – ..................... 43

6-22. IC Pin Function Description ........................................... 47

SECTION 1

SERVICING NOTES

This set is a component of the MHC-S9D. The MHC-S9D system configuration is as shown below, and therefore it does not operate normally unless all four components are connected. In performing the repair, connect all components with the system cables.

Note: The precaution to the users is described on the label stuck on the

back panel (DVD/video CD/CD player) and in the troubleshooting section in the Operation Manual.

System Configuration:

AC IN

POWER SUPPLY

MASTER & GRAPHIC µcon

DISPLAY

DVP

HTC & MB µcon

POWER BLOCK

TC µcon

7. EXPLODED VIEWS

7-1. Case Section.................................................................... 57

7-2. Front Panel Section......................................................... 58

7-3. Chassis Section ............................................................... 59

7-4. CD Mechanism Deck Section-1 (CDM63D) ................. 60

7-5. CD Mechanism Deck Section-2 (CDM63D) ................. 61

7-6. CD Mechanism Deck Section-3 (CDM63D) ................. 62

7-7. CD Mechanism Deck Section-4 (CDM63D) ................. 63

7-8. Optical Pick-up Section .................................................. 64

8. ELECTRICAL PARTS LIST ............................... 65

Page 4

DVP-S9

Ver 1.7

NOTE OF REPLACING THE MB BOARD

When replacing the MB board, since the adjustment value is not set up correctly, “Drive Auto Adjustment” can’t be performed. In this case, initialize Memory in the following procedures.

Procedure:

1. Set the test mode. (See page 12)

2. Press the [2] key of the remote commander , and set the “DRIVE MANUAL OPERATION”. (See page 18)

3. Press the [6] key of the remote commander, and set the “2-6, Memory Check”. (See page 20)

4. Press the [CLEAR] key of the remote commander, and initialize Memory.

MODEL IDENTIFICATION

- Back Panel -

PART No.

Model PART No.

AEP model 4-236-808-0 UK model 4-236-808-1 Korean model 4-236-808-3 Singapore model 4-236-808-4 Saudi Arabia model 4-236-808-5 Austrarian model 4-236-808-6 Thai model 4-236-808-7 E model 4-236-808-8 Mexican model 4-236-808-9

[]

TYPE A/B DISCRIMINATION

optical device

SILVER: KHM-240AAA (TYPE A) BLACK: KHM-270AAA (TYPE B)

SERVICE POSITION

In checking the CD block and another board, prepare jigs (extension cable J-2501-155-A: 300 mm 9 cores, J-2501-199-A: 300 mm 25 cores, J-2501-202-A: 300 mm 8 cores).

VIDEO board

Connect jig (extension cable J-2501-155-A) to the MB board (CN015) and optical pick-up block.

RF board

optical pick-up bloc

Connect jig (extension cable J-2501-202-A) to the MB board (CN012) and VIDEO board (CN201).

MB board

Connect jig (extension cable J-2501-199-A) to the MB board (CN010) and RF board (CN002).

Page 5

Parts Identification

The items are arranged in alphabetical order. Refer to the pages indicated in parentheses ( ) for details.

SECTION 2

GENERAL

DVP-S9

This section is extracted from instruction manual.

Main unit

DVD/VIDEO CD/CD player

wl e;ea es

1 2 3

DISC 1–3 rd (25, 26) DISC 1–3 indicators rs DISC 1–3 Z (eject) ea (25, 26) NEXT el (26, 27) PLAY MODE wl (25, 28, 29, 46) PREV ra (26, 27) REPEAT e; (12, 30) RETURN O ej (12, 27, 39, 40) N SELECT (play) r; (25–27,

41, 55, 60)

X (pause) ek (26) x (stop) eh (12, 26, 27, 30, 38,

45, 55, 61)

. (go back) eg (26, 28, 30) > (go forward) ef (26, 28, 30) m (rewind) es (26) M (fast forward) ed (26)

HSx

ejelra

Remote control

1234 5

ef eg

rg rd

rs ra

ehekr;rs

ek eh

ed ea wl

el ej eg ef es e;

Mm>.

TtCc

6 7

8 9 q; qa

qd qf

qh qk w; ws wf

qg qj

ql wa wd

wh wj

ANGLE es (37) AUDIO ws (34) CLEAR qs (22, 29, 30, 36) CLOCK/TIMER SELECT 3

(47, 56)

CLOCK/TIMER SET 2 (17, 47,

56) DBFB ra (48) D.SKIP 9 (26) DIGITAL rf (57) DISPLAY rj (17, 31, 32, 43, 54) DVD DISPLAY wd (18, 19, 30,

32–34, 36–40) DVD MENU wa (27) DVD SET UP ql (18, 19, 24, 39) ENTER wj EQ ea (52) EQ ON/OFF wl (53) FILE SELECT +/– wh (48, 49,

53)

FUNCTION rd (18, 25, 27, 28,

36, 45, 46, 55, 57) GROOVE rs (48) KARAOKE PON (Except for

North American and European

models) el (54) MD rh (57) Numeric buttons 8 (28, 30) PLAY MODE qa (25, 28, 29, 46) REPEAT q; (30) RETURN O qd (27, 39, 40) SELECT DVD N eh (20, 25,

27, 29, 30) SET UP wf (14, 16, 51, 53, 54) SLEEP 1 (55) SLOW t/T qk (26) SPECTRUM ANALYZER rk

(54) STEP c/C ef (26) SUBTITLE ed (37) SUR e; (51) TAPE A nN ek (44) TAPE B nN qf (44, 45) TITLE w; (27) TUNER/BAND ej (42) TV @/1 4 (13) TV CH +/– 7 (13) TV/VIDEO rl (13) TV VOL +/– 6 (13) VIDEO rg (57) VOL +/– wg

BUTTON DESCRIPTIONS

@/1 (power) 5 X (pause) qj x (stop) qg m/M (rewind/fast forward),

TUNING –/+ qh

./> (go back/go forward),

PRESET –/+, PREV/NEXT eg O/o/P/p wk >10 r;

Page 6

DVP-S9

• This set can be disassembled in the order shown below.

3-1. DISASSEMBLY FLOW

SET

3-2. COVER

(Page 7)

SECTION 3

DISASSEMBLY

3-3. CD MECHANISM DECK

(CDM63D) (Page 7)

3-4. MB BOARD

(Page 8)

3-5. VIDEO BOARD

(Page 8)

3-6. MAIN BOARD

(Page 9)

3-7. FRONT PANEL SECTION

(Page 9)

3-8. PANEL BOARD,

SUB PANEL BOARD (Page 10)

3-9. LID (CD)

(Page 10)

Page 7

Note: Follow the disassembly procedure in the numerical order given.

)

3-2. COVER

cover

two screws (case 3 TP2)

screw (BVTT3 × 6)

DVP-S9

3-3. CD MECHANISM DECK (CDM63D)

CD mechanism deck (CDM63D)

wire (flat type) (25 core) (CN010)

two screws (case 3 TP2

connector (CN701)

four screws (BVTP3

wire (flat type) (9 core (CN015)

Page 8

DVP-S9

3-4. MB BOARD

two screws (BV)

wire (flat type) (25 core) (CN010)

wire (flat type) (8 core) (CN011)

wire (flat type) (9 core) (CN015)

two screws (BV)

lug

MB board

connecto (CN008)

3-5. VIDEO BOARD

VIDEO board

connector (CN202)

wire (flat type) (8 core)

three screws (BVTP3

Page 9

3-6. MAIN BOARD

)

wire (flat type) (10 core) (CN107)

connector (CN401)

two connectors (CN101, 102)

MAIN board

screw (BVTP3 × 8)

screw (BVTP3

DVP-S9

3-7. FRONT PANEL SECTION

front panel section

claw

connector (CN701)

lug

connector (CN401)

three screws (BVTP3

two claws

Page 10

DVP-S9

)

3-8. PANEL BOARD, SUB PANEL BOARD

SUB PANEL board

two claws

four screws (BVTP2.6

five screws (BVTP2.6

PANEL boar

3-9. LID (CD)

spring (CD)

two claws

bracket (LID) assy

screw (BVTP2.6 × 8

lid (CD)

Page 11

SECTION 4

TEST MODE

DVP-S9

Note: Use following buttons in the test mode.

no mark: Button of DVD/video CD/CD player (DVP-S9)

*1 : Button of A/V amplifier (TA-S9D) *2 : Button of tuner (ST-S9)

[CHANGE-OVER THE COLOR SYSTEM]

•The color system can be changed over NTSC or PAL.

Procedure:

1. Press the I/1 *1 button to turn the power on.

2. Turn the [FUNCTION]*

knob to select “DVD”, and press

the x button.

3. While pressing the both [RETURN] and [REPEAT] buttons, turn the power off.

4. Press the I/1 *1 button to turn the power on. The color system is changed over.

[COLD RESET]

• The cold reset clears all data including preset data stored in the

RAM to initial conditions. Execute this mode when returning the set to the customer.

Procedure 1:

1. Press the I/1 *1 button to turn the power on.

2. While pressing the both [PLAY MODE] and x buttons, press the M button.

3. The set is reset, and becomes standby state.

Procedure 2:

1. Press the I/1 *1 button to turn the power on.

2. While pressing the [DIGITAL]*1 button, press the [DISPLAY]* button.

3. The set is reset, and becomes standby state.

[DVD DELIVERY MODE]

•This mode moves the optical pick-up to the position durable to

vibration. Use this mode when returning the set to the customer after repair.

Procedure:

1. Press the I/1 *1 button to turn the power on.

2. Turn the [FUNCTION]*1 knob to select “DVD”.

3. While pressing the [EQ ON/OFF]*1 button, press the I/1 * button.

4. The message “LOCK” is displayed on the fluorescent indicator tube of tuner unit and turn the power off automatically, and the DVD delivery mode is set.

[GC TEST MODE]

Enter the GC Test Mode

Procedure 1:

1. Press the I/1 *1 button to turn the power on.

2. While pressing the both [PLAY MODE] and x buttons, press the Z (DISC 1) button.

3. LEDs and fluorescent indicator tube are all turned on of all units.

Procedure 2:

1. Press the I/1 *1 button to turn the power on.

2. While pressing the both [STEREO/MONO]*2 and

[CINEMA STUDIO C]*

button.

3. LEDs and fluorescent indicator tube are all turned on of all units.

buttons, press the [CLOCK/TIMER]*

Version Display Mode

Procedure:

1. Enter the GC test mode.

2. Each time the [DISC 1] or [TUNER MEMORY]*2 button is pressed, microcomputer or mechanism deck version is displayed of each unit.

3. Press the [DISC 3] or [TUNING +]*2 button to detail is displayed the version.

Key Check Mode

Procedure:

1. Enter the GC test mode.

2. Press the [DISC 2] or [TUNING --]*2 button to set the key check mode, and displays “K 0 J 0 V 0” on the fluorescent indicator tube of tuner unit.

3. All buttons are pressed of video CD unit, all LEDs are blinking of video CD unit. (not change the display of fluorescent indicator tube)

Releasing the GC Test Mode

To release from this mode, press three buttons in the same manner as entering this mode or disconnect the power cord.

[DVD SERVICE MODE]

•This mode can run the DVD sled motor optionally. Use this

mode, for instance, when cleaning the optical pick-up.

Procedure:

1. Press the I/1 *1 button to turn the power on.

2. Turn the [FUNCTION]*1 knob to select “DVD”.

3. While pressing the both [PLAY MODE] and x buttons, press the . button.

4. Set to the DVD service mode.

5. With the DVD in stop status, press the

M button to move

the optical pick-up to outside track, or press the m button to inside track.

6. To release from this mode, perform as follows.

1) Move the optical pick-up to the most inside track.

2) Disconnect the power cord.

Notes: • Always move the optical pick-up to most inside track when

releasing from this mode. Otherwise, a disc will not be unloaded.

• Do not run the sled motor excessively, otherwise the gear can be chipped.

[DVD CANCELLATION MODE OF REPEAT LIMITATION]

•This mode can cancel the DVD repeat limitation (5 times).

Procedure:

1. Press the I/1 *1 button to turn the power on.

2. Turn the [FUNCTION]*1 knob to select “DVD”.

3. While pressing the both [PLAY MODE] and x buttons, press the [REPEAT] button.

4. DVD repeat limitation is canceled.

5. To release this mode, disconnect the power cord.

[DVD DISC TRA Y LOCK MODE FOR B URGLAR Y PREVENTION]

Procedure:

1. Press the I/1 *1 button to turn the power on.

2. Turn the [FUNCTION]*1 knob to select “DVD”.

3. While pressing the both [PLAY MODE] and x buttons, press the m button, turn the power off.

Page 12

DVP-S9

Ver 1.6

[GENERAL DESCRIPTION]

The T est Mode allo ws you to mak e diagnosis and adjustment easily using the remote commander and monitor TV. The instructions, diagnostic results, etc. are given on the on-screen display (OSD).

[STARTING TEST MODE]

1. Press the I/1 *1 button to turn the power on.

2. Turn the [FUNCTION]*2 knob to select “DVD”.

3. While pressing the x and [PLAY MODE] button, press the . button to enter the test mode.

4. It displays “TEST MODE” on the fluorescent indicator tube, and displays the Test Mode Menu on the monitor screen as follows. (At the bottom of the menu screen, the model name and revision number are displayed)

Test Mode Menu

0. Syscon Diagnosis

1. Drive Auto Adjustment

2. Drive Manual Operation

3. Mecha Aging

4. Emergency History

5. Version Information

6. Video Level Adjustment Exit: POWER Key _ Model : xxx-xxxx_xx Revision: 1.xxx

5. T o e xecute each function, select the desired menu and press its number on the remote commander (RM-SD390AV or RMSD395AV).

6. To release from test mode, press the I/1 *1 button and turn the power off.

1. All

All items continuous check This menu checks all diagnostic items continuously. Normally, all items are checked successively one after another automatically unless an error is found, but at a certain item that requires judgment through a visual check to the result, the following screen is displayed for the key entry.

### Syscon Diagnosis ###

Diag All Check No. 2 Version

2-3. ROM Check Sum Check Sum = 2005

Press NEXT Key to Continue Press PREV Key to Repeat _

For the ROM Check, the check sum calculated by the Syscon is output, and therefore you must compare it with the specified value for confirmation. Following the message, press > key to go to the next item, or . key to repeat the same check again. To quit the dia gnosis and return to the Check Menu screen, press x or [ENTER] key. If an error occurred, the diagnosis is suspended and the error code is displayed as shown below.

### Syscon Diagnosis ###

[SYSCON DIAGNOSIS]

The same contents as board detail check by serial interface can be checked from the remote commander. On the Test Mode Menu screen, pr ess [10/0] key on the remote commander, and the following check menu will be displayed.

### Syscon Diagnosis ###

Check Menu

0. Quit

1. All

2. Version

3. Peripheral

4. Servo

5. Supply

6. AV Decoder

7. Video

8. Audio

0. Quit

Quit the Syscon Diagnosis and return to the Test Mode Menu.

3-3. EEPROM Check Error 03: EEPROM Write/Reed N Address : 00000001 Write Data : 2492 Read Data : 2490 Press NEXT Key to Continue Press PREV Key to Repeat _

Press x key to quit the diagnosis, or > key to repeat the same item where an error occurred, or . key to continue the check from the item next to faulty item.

Page 13

DVP-S9

Ver 1.6

Selecting 2 and subsequent items calls the submenu screen of each item. For example, if “5. Supply” is selected, the following submenu will be displayed.

### Syscon Diagnosis ###

Check Menu

No. 5 Supply

0. Quit

1. All

2. ARP Register Check

3. ARP to RAM Data Bus

4. ARP to RAM Address Bus

5. ARP RAM Check _

0. Quit

Quit the submenu and return to the main menu.

1. All

All submenu items continuous check This menu checks 2 and subsequent items successively . At the item where visual check is required for judgment or an error occurred, the checking is suspended and the message is output for key entry . Normally, all items are check ed successiv ely one after another automatically unless an error is found.

Selecting 2 and subsequent items executes respective menus and outputs the results. For the contents of each submenu, see “Check Items List”.

General Description of Checking Method

2. Version

(2-2) Revision

ROM revision number is displayed.Error: Not detected. The revision number defined in the source file of R OM (At the beginning of mass production, the Flash ROM of IC107 is used) is displayed with four digits.

(2-3) ROM Check Sum

Check sum is calculated. Error: Not detected. The 8-bit data are added at addresses 0x000F0000 ~ 0x002EFFFF of ROM (IC107) and the result is displayed with 4-digit hexadecimal number. Error is not detected. Compare the result with the specified value.

(2-4) Model T ype

Model code is displayed. Error: Not detected. The model code read from EEPROM (IC101) is displayed with 2-digit hexadecimal number.

(2-5) Region

Region code is displayed. Error: Not detected. The region code determined from the model code is displayed.

3. Peripheral

(3-2) EEPROM Check

Data write → read, and accord check Error 03: EEPROM write/read discord Data 0x9249, 0x2942, 0x4294 are written to addresses 0x00~0xFF of EEPROM (IC101), then read and checked. Before writing, the data are saved, then after checking, they are written to restore the contents of EEPROM.

4. Servo

(4-2) Servo DSP Check

Data write → read, and accord check Error 12: Read data discord Data 0x9249, 0x2942, 0x4294 are written to the address 0x602 of RAM in the Servo DSP (IC302), then read and checked.

(4-3) DSP Driver Test

Test signal data → DSP Driver Error: Not detected. Caution: Do not conduct this test with a mechanical deck connected. The maximum voltage is applied to the Servo Driver IC (IC401). If mechanical deck is connected, the motor and optics could be damaged. Disconnect mechanical deck following the output message, then enter specified 4- or 5digit number from the remote commander, and press the

[ENTER]. The test is conducted only when the input data

accord. Check the output level, then press the > to finish the test. This test is skipped if “All” is selected.

Supplement: How to disconnect mechanical deck Disconnect flat cables connected to the CN010 and CN015 of MB board. Also, disconnect harness from the CN203.

Page 14

DVP-S9

Ver 1.6

5. Supply

Caution: Do not conduct this check with a mechanical deck con-

nected. An access is made to the stream supply and servo control IC (IC302) and external RAM (IC303) using check data. If mechanical deck is connected, the motor and optics could be damaged. This check is also executed by the “All” menu item.

Supplement: How to disconnect mechanical deck

Disconnect flat cables connected to the CN010 and CN015 of MB board. Also, disconnect harness from the CN203.

(5-2) ARP Register Check

Data write → read, and accord check Error 08: ARP register write, and read data discord Data 0x00 to 0xFF are written to the TMAX register (address 0xC6) in ARP (IC302), then they are read and check ed.

(5-3) ARP to RAM Data Bus

Data write → read, and accord check Error 09: ARP ←→ RAM data bus error Data 0x0001 to 0x8000 where one bit each is set to 1 are written to the address 0 of RAM (IC303) connected to the ARP (IC302) through the bus, then they are read and checked. In case of discord, written bit pattern and read data are displayed. If data where multiple bits are 1 are read, the bits concerned may touch each other. Further, if data where certain bit is always 1 or 0 regardless of written data, the line could be disconnected or shorted.

(5-4) ARP to RAM Address Bus

Data write → other address read discord check Error 10: ARP → RAM address bus error Caution: Address and data display in case of an error is

different from the display of other diagnosis (de-

scribed later). Before starting the test, all addresses of RAM (IC303) are cleared to 0x0000. First, 0xA55A is written to the address 0x00000, and the address data are read and checked from addresses 0x00001 to 0x80000 while shifting 1 bit each. Next, the data at that address is cleared, and it is written to the address 0x00001, and read and checked in the same manner. This check is repeated up to the address 0x80000 while shifting the address data by 1 bit each. If data other than 0 is read at the addresses except written address, an error is given because all addresses were already cleared to 0. In this check, the error display pattern is different from that of other diagnosis; read data, written address, and read address are displayed in this order. Ho wever, the message uses same template, and accordingly exchange Address and Data when reading. The following display, for example,

### Syscon Diagnosis ###

5-4. ARP to RAM Address Bus Error 10: ARP - RAM Address B Address : 0000A55A Write Data : 00000000 Read Data : 00080000 Press NEXT Key to Continue Press PREV Key to Repeat _

shows the data 0xA55A was read from address 0x00080000 though it was written to the address 0x00000000. This implies that these addresses are in the form of shadow. Also, if the read data is not 0xA55A, another error will be present.

(5-5) ARP RAM Check

Data write → read, and accord check Error 11: ARP RAM read data discord The program code data stored in ROM are copied to all areas of RAM (IC303) connected to the ARP (IC302) through the bus, then they are read and checked if they accord. If the detail check was selected initially, the data are written to all areas and read, then the same test is conducted once again with the data where all bits are inverted between 1 and 0. If discord is detected, faulty address, written data, and read data are displayed following the error code 11, and the test is suspended.

Page 15

DVP-S9

Ver 1.6

6. AV Decoder

(6-2) 1930 RAM

Data write → read, and accord check Error 13: AVD RAM read data discord The program code data stored in ROM (IC107) are copied to all areas oo»RAM (IC504, IC505) connected to the AVD (IC503) through the bus, then they are read and checked if they accord. Further, the same test is conducted once ag ain with the data where all bits are inverted between 1 and 0. If discord is detected, faulty address, written data, and read data are displayed following the error code 13, and the test is suspended.

(6-3) 1930 SP

ROM → AVD RAM → Video OUT Error: Not detected. The data including sub picture streams in ROM (IC107) are transferred to the RAM (IC504, IC505) in AVD (IC503), and output as video signals from the AVD (IC503). They are output from all video terminals (Composite, Y/C).

7. Video

(7-2) Color Bar

AVD color bar command write → Video OUT Error: Not detected. The command is transferred to the AVD, and the color bar signals are output from video terminals. They are output from all video terminals (Composite, Y/C).

Check Items List

2) Version (2-2) Revision (2-3) ROM Check Sum (2-4) Model T ype (2-5) Region

3) Peripheral (3-2) EEPROM Check

4) Servo (4-2) Servo DSP Check (4-3) DSP Driver Test

5) Supply (5-2) ARP Register Check (5-3) ARP to RAM Data Bus (5-4) ARP to RAM Address Bus (5-5) ARP RAM Check

6) AV Decoder (6-2) 1930 RAM (6-3) 1930 SP

7) Video (7-2) Color Bar (7-3) Composit Out (7-4) Y/C Out (7-6) Component Out

(7-3) Composit Out

(7-4) Y/C Out

(7-6) Component Out

8. Audio

(8-2) ARP → 1930

Error 14 : ARP → 1930 video NG 15 : ARP → 1930 audio NG

(8-3) Test Tone

All channels 2ch Left 2ch Right Front Left Front Right Rear Left Rear Right Center Sub Woof er

8) Audio (8-2) ARP → 1930 (8-3) Test Tone

Error Codes List

00: Error not detected 01: RAM write/read data discord 02: Gate array NG 03: EEPROM NG 08: ARP register read data discord 09: ARP ←→ RAM data bus error 10: ARP ←→ RAM address bus error 11: ARP RAM read data discord 12: Servo DSP NG 13: 1930 SDRAM NG 14: ARP → 1930 video NG 15: ARP → 1930 audio NG 16: 1910 UCODE download NG 17: System call error (function not supported) 18: System call error (parameter error) 19: System call error (illegal ID number) 20: System call error (time out) 90: Error occurred 91: User verification NG 92: Diagnosis cancelled

Page 16

DVP-S9

Ver 1.6

[DRIVE AUTO ADJUSTMENT]

On the T est Mode Menu scr een, press [1] key on the remote commander, and the drive auto adjustment menu will be displayed.

## Drive Auto Adjustment ##

Adjustment Menu

0. ALL

1. DVD-SL

2. CD

3. DVD-DL

Exit: RETURN

Normally, [10/0] is selected to adjust DVD (single layer), CD and DVD (dual layer). But, individual items can be adjusted for the case where adjustment is suspended due to an error. In this mode, the adjustment can be made easily through the operation following the message displayed on the screen. The disc used for adjustment must be the one specified for adjustment.

0. ALL

Select [10/0] and press [ENTER] key, and the servo set data in EEPROM will be initialized. Then, 1. DVD-SL disc, 2. CD disc and 3. DVD-DL disc are adjusted in this order . Eac h time one disc was adjusted, it is ejected. Replace it with the specified disc following the message. You can finish the adjustment if pressing

x button. During adjustment of each disc, the measurement

the for disc type judgment is made. As automatic adjustment does not judge the disc type unlike conventional models, take care not to insert wrong type discs. Also, do not give a shock during adjustment.

1. DVD-SL (single layer)

Select

[1], insert DVD single layer disc, and press [ENTER] key,

and the adjustment will be made through the following steps, then adjusted values will be written to the EEPROM.

DVD Single Layer Disc Adjustment Steps

1. SLED TILT Reset

2. Disc Check Memory SL

3. Wait 300 msec

4. Set Disc Type SL

5. LD ON

6. Spdl Start

7. Wait 1 sec

8. Focus Servo ON 0

9. Auto Track Offset Adjust

10. CLVA ON

11. Wait 500 msec

12. Tracking ON

13. Wait 1 sec

14. Sled ON

15. Check CLV Loc k

16. Auto LFO Adjust

17. Auto Focus Offset Adjust

18. Auto Tilt Position Adjust

19. Auto Focus Gain Adjust

20. Auto Focus Offset Adjust

21. EQ Boost Adjust

22. Auto LFO Adjust

23. Auto Track Gain Adjust, Search Check

24. 32Tj Fwd

25. 32Tj Rev

26. 500Tj Fwd

27. 500Tj Rev

28. All Servo Stop

29. Eep Copy Loop Filter Offset

Page 17

DVP-S9

Ver 1.6

2. CD

Select [2], insert CD disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the EEPROM.

CD Adjustment Steps

1. Sled Tilt Rest

2. Disc Check Memory CD

3. Wait 500 msec

4. Set Disc Type CD

5. LD ON

6. Spdl Start

7. Wait 500 msec

8. Focus Servo ON 0

9. Auto Track Offset Adjust

10. CLVA ON

11. Wait 500 msec

12. Tracking ON

13. (TC Display Start)

14. Wait 1 sec

15. Jitter Display Start

16. Sled ON

17. Check CLV ON

18. Auto LFO Adjust

19. Auto Focus Offset Adjust

20.

21. Auto Focus Gain Adjust

22. Auto Focus Offset Adjust

23. Eq Boost Adjust

24. Auto LFO Adjust

25. Auto Track Gain Adjust, Search Check

26. 32Tj Fwd

27. 32Tj Rev

28. 500Tj Fwd

29. 500Tj Rev

30. All Servo Stop

3. DVD-DL (dual layer)

Select [3], insert DVD dual layer disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the EEPROM.

DVD Dual Layer Disc Adjustment Steps

1. Sled Tilt Reset

2. Disc Check Memory DL

3. Wait 500 msec

4. Set Disc Type DL

5. LD ON

6. Spdl Start

7. Wait 1 sec, Layer 1 Adjust

8. Focus Servo ON 0

9. Auto Track Offset Adjust

10. Clva ON

11. Wait 500 msec

12. Tracking ON

13. Wait 500 msec

14. Sled ON

15. Check CLV Lock

16. Auto Loop Filter Offset Auto Focus Adjust

17.

18. Auto Focus Gain Adjust

19. Auto Focus Offset Adjust

20. Eq Boost Adjust

21. Auto Loop Filter Offset

22. Auto Track Gain Adjust, Search Check

23. 32Tj Fwd

24. 32Tj Rev

25. 500Tj Fwd

26. 500Tj Rev, Layer 0 Adjust

27. Fj (L1 -> L0)

28. Auto Track Offset Adjust L0

29. Clva ON

30. Wait 500 msec

31. Tracking ON

32. Wait 500 msec

33. Sled ON

34. Check CLV Lock

35. Auto Focus Filter Offset

36. Auto Focus Adjust

37.

38. Auto Focus Gain Adjust

39. Auto Focus Offset Adjust

40. Eq Boost Adjust

41. Auto Loop Filter Offset

42. Auto Track Gain Adjust, Search Check

43. 32Tj Fwd

44. 32Tj Rev

45. 500Tj fwd

46. 500Tj Rev, Layer Jump Check

47. Lj (L0 -> L1)

48. Lj (L1 -> L0)

49. All Servo Stop

Page 18

DVP-S9

Ver 1.6

[DRIVE MANUAL OPERATION]

On the T est Mode Men u screen, select [2], and the manual operation menu will be displayed. For the manual operation, each servo on/off control and adjustment can be executed manually.

## Drive Manual Operation ##

1. Disc type

2. Servo Control

3. Track/Layer Jump

4. Manual Adjustment

5. Auto Adjustment

6. Memory Check

7. Sacd Water Mark

0. Disc Check Memory _

Operation Menu

Exit: Return

In using the manual operation menu, take care of the following points. These commands do not provide protection, thus requiring correct operation. The sector address or time code field is displayed when a disc is loaded.

1. Set correctly the disc type to be used on the Disc Type screen. The disc type must be set after a disc was loaded. The set disc type is cleared when the tray is opened.

2. After power ON, if the Drive Manual Operation was selected, first perform “Reset SLED TILT” by opening 1. Disc Type screen.

3. In case of an alarm, immediately press the x button to stop the servo operation, and turn the power OFF.

Basic operation (controllable from front panel or remote commander)

I/1 Power OFF

x Servo stop Z Stop+Eject/Loading

[RETURN] Return to Operation Menu or Test Mode

> , . Transition between sub modes of menu

[1] to [9], [10/0] Selection of menu items

Cursor ↑ / ↓ Increase/Decrease in manually adjusted

value

0. Disc Check Memory

Disc Check

1. SL Disc Check

2. CD Disc Check

3. DL Disc Check

0. Reset SLED TILT _

On this screen, the mirror time is measured to judge the disc and it is written to the EEPROM. First load D VD SL disc and press [1], next load CD disc and press [2], and finally load DVD DL disc and press [3]. The adjustment must be executed more than once after default data were written. External vibration or shock to the player must not be given. Reference value for DVD is from 10 to 20, and for CD, from 28 to 4F. Check that the value of CD is larger than that of DVD . When those values are beyond a range perform this adjustment again. From this screen, you can go to another mode by pressing > or . key, but you cannot enter this mode from another mode. You can enter this mode from the Operation Menu screen only.

1. Disc T ype

Disc Type

1. Disc Type Auto Check

2. DVD SL 12 cm

3. DVD DL 12 cm

4. CD 12cm

5. LCD 12 cm

6. DVD SL 8 cm

7. DVD DL 8 cm

8. CD 8 cm

9. LCD 8 cm

0. Reset SLED TILT

-- SA. ------ SI. -- EMG. 00 DVD SL12cm

On this screen, select the disc type. To select the disc type, press the number of the loaded disc. The selected disc type is displayed at the bottom. Selecting [1] automatically selects and displays the disc type. In case of wrong display, retry “Disc Check Memory”. Also, opening the tray causes the set disc type to be cleared. In this case, set the disc type again after loading. In performing manual operation, the disc type must be set. Once the disc type has been selected, the sector address or time code display field will appear as shown below. These values are displayed when PLL is locked.

Page 19

DVP-S9

Ver 1.6

1. Disc Type Auto Check

Disc Type

2. DVD SL 12 cm

3. DVD DL 12 cm

4. CD 12cm

5. LCD 12 cm

6. DVD SL 8 cm

7. DVD DL 8 cm

8. CD 8 cm

9. LCD 8 cm

0. Reset SLED TILT SA. SI. EMG. 00

DVD SL 12 cm

Display when DVD SL 12cm disc was selected

Disc Type

1. Disc Type Auto Check

2. DVD SL 12 cm

3. DVD DL 12 cm

4. CD 12cm

5. LCD 12 cm

6. DVD SL 8 cm

7. DVD DL 8 cm

8. CD 8 cm

9. LCD 8 cm

0. Reset SLED TILT

TC. : : EMG. 00

CD 12 cm

2. Servo Control

Servo Control

1. LD Off R.Sled FWD

2. SP Off L.Sled REV

3. Focus Off

4. TRK. Off

5. Sled Off

6. CLVA Off

7. FCS. Srch Off

0. Reset SLED TILT SA. SI. EMG. 00

DVD SL 12 cm

On this screen, the servo on/off control necessary for replay is executed. Normally, turn on each servo from 1 sequentially and when CL VA is turned on, the usual trace mode becomes acti ve. In the trace mode, DVD sector address or CD time code is displayed. This is not displayed where the spindle is not locked. The spindle could run overriding the control if the spindle system is faulty or RF is not present. In such a case, do not operate CL VA.

[10/0] Reset SLED TILT Reset the Sled

and Tilt to initial position.

[1] LD Turn ON/OFF the laser.

Display when CD 12cm disc was selected

[0] Reset SLED TILT Reset the Sled and Tilt to initial posi-

tion.

[1] Disk Type Check Judge automatically the loaded disc. As

the judged result is displayed at the bottom of screen, make sure that it is correct. If Disc Check Memory menu has not been executed after EEPROM default setting, the disc type cannot be judged. In this case, return to the initial menu and make a check for three types of discs (SL, DL, CD).

[2] to [9] Select the loaded disc. The adjusted

value is written to the address of selected disc. No further entry is necessary if [1] was selected.

[2] SP Turn ON/OFF the spindle.

[3] Focus Search the focus and turn on the focus.

[4] TRK Turn ON/OFF the tracking servo.

[5] Sled Turn ON/OFF the sled servo.

[6] CLVA Turn ON/OFF normal servo of spindle

servo.

[7] FCS. Srch Apply sam e voltage as that of focus

search to the focus drive to check the focus drive system.

→ Sled FWD Move the sled outward. Perform this

operation with the tracking servo turned off.

← Sled REV Move the sled inward. Perform this op-

eration with the tracking servo turned off.

↑ Tilt UP Move the tilt upward.

↓ Tilt DOWN Move the tilt downward.

The following menus are normally not used.

3. Track/Layer Jump

4. Manual Adjustment

5. Auto Adjustment

The persons who do not know well about these menus should not use them.

Page 20

DVP-S9

Ver 1.6

6. Memory Check

EEPROM Data1

-– DL – CD LCD SL L0 L1

Focus Gain xx xx xx xx xx TRK. Gain xx xx xx xx xx FCS Balance xx xx xx xx xx Focus Bias xx xx xx xx xx TRV. Offset xx xx xx xx xx L. F. Offset xx xx xx xx xx EQ Boost xx xx xx xx xx Mirror Time xx xx xx xx xx _DOWN: Next Data CLEAR: Default Set page.1/2

EEPROM Data1

-– DL – CD LCD SL L0 L1

RF Jitter xx -- xx xx xx RF Level xx -- xx -- -FE Level xx -- xx -- -FE Balance xx -- xx -- -TRV. Level xx -- xx -- -Analog FRSW xx xx xx xx xx PLL DacGain xx xx xx xx xx _ UP : Prev Data CLEAR: Default Set page.2/2

This screen displays current servo adjusted data stored in the EEPROM. Though adjusted data can be initialized with the

[CLEAR] key, they cannot be restored after initialization.

So, before clearing, make a note of the adjusted data. For reference, the drive has been designed so that the gain center value is 20 and offset value is 80. Other values will be in a range of 10 to 80. If extreme value such as 00 or FF is set, adjustment will be faulty. In such a case, check for disc scratch or cable disconnection, then perform adjustment again.

[MECHA AGING]

### Mecha Aging ###

[EMERGENCY HISTORY]

### EMG. History ###

Laser Hours CD xxxxxxxh

DVD xxxxxxxh

1. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

2. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

Select: 1 – 9 Scroll: UP/DOWN (1: Last EMG.) Exit: RETURN

On the Test Mode Menu screen, selecting [4] displays the information such as servo emergency history. The history information from last 1 up to 10 can be scrolled with ↑ key or ↓ key. Also, specific information can be displayed by directly entering that number with ten keys.

The upper two lines display the laser ON total hours. Data below minutes are omitted.

Clearing History Information

Clearing laser hours Press [DVD DISPLAY] and [CLEAR] keys in this order. Both CD and DVD data are cleared. Clearing emergency history Press [TITLE] and [CLEAR] keys in this order. Initializing set up data Press [DVD SET UP] and [CLEAR] keys in this order. The data have been initialized when “Set Up Initialized” message is displayed. The EMG. History screen will be restored soon.

How to see Emergency History

31.12

Press OPEN Key

Abort: STOP key

On the Test Mode Menu Screen, selecting [3] executes the aging of the mechanism. Start aging with PLAY. During aging, the repeat cycle is displayed. Aging can be aborted at any time by pressing the x key. After the operation is stopped, press the x key or [RETURN] key again to return to the Test Mode Menu. SEARCH Aging is only for a CD.

1 : Emergency Code 2 : Don’t Care

These codes are used for verification of software designing.

3 : Historical order 1 to 9

Page 21

DVP-S9

Ver 1.6

Emergency Codes List

10: Communication to IC001 (RF board) failed. 11: Each servo for focus, tracking, and spindle is unlocked. 12: Communication to EEPROM, IC101 (MB board) failed. 13: Writing of hours meter data to EEPROM, IC101 (MB board)

failed.

14: Communication to Servo DSP IC302 (MB board) failed, or

Servo DSP is faulty.

20: Initialization of tilt servo and sled servo failed. They are not

placed in the initial position. 21: Tilt servo operation error 22:

Syscon made a request to move the tilt servo to wrong position. 23: Sled servo operation error 24:

Syscon made a request to move the sled servo to wr ong position. 30: Tracking balance adjustment error 31: Tracking gain adjustment error 32: Focus balance adjustment error 33: Focus bias adjustment error 34: Focus gain adjustment error 35: Tilt servo adjustment error 36: RF equalizer adjustment error 37: RF group delay adjustment error 38: Jitter value after adaptive servo operation is too large. 40: Focus servo does not operate. 41: With a dual layer (DL) disc, focus jump failed.50: CLV

(spindle) servo does not operate. 51: Spindle does not stop. 60: With a DVD disc, Syscon made a request to seek nonexistent

address. 61: With a CD disc, Syscon made a request to seek nonexistent

address. 62: With a CD disc, Syscon made a request to seek nonexistent

track No. and index No. 63: With a DVD disc, seeking of target address failed. 64: With a CD disc, seeking of target address failed. 65: With a CD disc, seeking of target index failed. 70: With a D VD disc, physical information data could not be read. 71: With a CD disc, TOC data could not be read. 80: Disc type judgment failed. 81: As disc type judgment failed, retry was repeated. 82: As disc type judgment failed, a measurement error occurred. 83: Disc type could not be judged within the specified time. 84: Illegal command code was received from Syscon. 85: Illegal command was received from Syscon.

[VIDEO LEVEL ADJUSTMENT]

On the Test Mode Menu screen, selecting [6] displays color bars for video level adjustment. During display of color bars, OSD disappears but the menu screen will be restored if pressing any key.

Measurement point :VIDEO OUT jack

(75 Ω terminating resistance) Measuring instrument: Oscilloscope Adjustment device : RV501 on MB board Specified value : 1.0

+ 0.04 – 0.02

Vpp

1.0

+ 0.04 – 0.02

Vp-p

[VERSION INFORMATION]

## Version Information ##

IF con. Ver: x. xxx (xxxx)

Group 00

SYScon. Ver: x. xxx (xxxx)

Model xx Region 0x

Servo DSP Ver:X.XXX OPT Type:2 Laser Exit: RETURN

On the Test Mode Menu screen, selecting [5] displays the ROM version and region code. The parenthesized hexadecimal number in version field is checksum value of ROM.

Page 22

DVP-S9

IC202

IC103

IC503

IC302

RV501 Video Level Adjustment

– MB Board (Component Side) –

Ver 1.6

SECTION 5

ELECTRICAL ADJUSTMENTS

Note: During diagnostic check, the characters and color bars can be seen

only with the NTSC monitor. Therefore, for diagnostic check, use the monitor that supports both NTSC and PAL modes

Instruments required:

1) Color monitor TV

2) Oscilloscope 1 or 2 phenomena, band width over 100 MHz, with delay mode

3) DVD reference disc HLX-501 (J-6090-071-A) (dual layer) (NTSC) HLX-503 (J-6090-069-A) (single layer) (NTSC) HLX-504 (J-6090-088-A) (single layer) (NTSC) HLX-505 (J-6090-089-A) (dual layer) (NTSC) HLX-506 (J-6090-077-A) (single layer) (PAL) HLX-507 (J-6090-078-A) (dual layer) (PAL)

AUTO SERVO ADJUSTMENT

After parts related to the servo circuit (RF amplifier (IC001), DSP (IC302), motor driver (IC401), EEPROM (IC101) so on) are replaced, re-adjusting the servo circuit is necessary . Select “ALL” at “DRIVE AUTO ADJUSTMENT” (Refer to page 16 in TEST MODE) and adjust DVD-SL (single layer), CD and D VD-DL (dual layer).

VIDEO LEVEL ADJUSTMENT

This adjustment is made to satisfy the NTSC/P AL standard, and if not adjusted correctly, the brightness will be too large or small.

Signal Color bars Test point

VIDEO OUT jack

(75 Ω terminated) Instrument Oscilloscope Adjusting element RV501 (MB board) Specified Value 1.0

+ 0.04 – 0.02

Vp-p

Procedure:

1. Press the I/1 button to turn the power on, and turn the

[FUNCTION] knob to select “DVD” of A/V amplifier (TA-

S9D).

2. Adjust the RV501 on the MB board to attain 1.0

+ 0.04 – 0.02

Vp-p.

Procedure:

1. Press the I/1 button to turn the power on, and turn the

[FUNCTION] knob to select “DVD” of A/V amplifier (TA-

S9D).

2. Confirm that the S-Y level is 1.0 ± 0.05 Vp-p.

1.0 ± 0.05 Vp-p

Figure 5-2

CHECKING S VIDEO OUTPUT S-C

This checks whether the S-C satisfies the NTSC Standard. If it is not correct, the colors will be too dark or light.

Signal Color bars Test point

S VIDEO OUT (S-C) jack (75 Ω terminated)

Instrument Oscilloscope Specified Value

286 ± 30 mVp-p (NTSC) 300 ± 100 mVp-p (PAL)

Procedure:

1. Press the

I/1 button to turn the power on, and turn the

[FUNCTION] knob to select “DVD” of A/V amplifier (TA-

S9D).

2. Confirm that the S-C burst is 286 ± 30 mVp-p (NTSC) or 300 ± 100 mVp-p (PAL).

286 ± 50 mVp-p (NTSC) or 300 ± 100 mVp-p (PAL)

Figure 5-3

Adjustment Location :

+ 0.04

1.0

– 0.02

Figure 5-1

CHECKING S VIDEO OUTPUT S-Y

Check S-terminal video output. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with a Sterminal cable.

Signal Color bars Test point Instrument Oscilloscope

Specified Value 1.0 ± 0.05 Vp-p

S VIDEO OUT (S-Y) jack (75 Ω terminated)

Vp-p

Page 23

SECTION 6

DIAGRAMS

6-1. BLOCK DIAGRAM – RF/SERVO Section – • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

OPTICAL PICK-UP

BLOCK (KHM-240AAA) (TYPE A) (KHM-270AAA) (TYPE B)

ATOP

RF IN

ATON

64 63

AIP

AIN

FNP FNN

55 54

DIP

DIN

SIGO

RF+

DVP-S9

Ver 1.5

(Page 24)

DVD/CD

DETECTOR

DVD/CD

LASER

DIODE

MODULE

INLIMIT

SENSOR

2-AXIS DEVICE

FOCUS

COIL

DVD LD

CD LD

INLIM

FCS+ FCS–

A B C

F G H

AUTOMATIC POWER

CONTROL (FOR DVD)

Q001

AUTOMATIC POWER

CONTROL (FOR CD)

Q002

D+3.3V

DVDLD

CDLD

DVDPD

CDPD

LDSELO

FOCUS/TRACKING COIL DRIVE, SPINDLE/SLED MOTOR DRIVE

37 36

IC401

FOCUS COIL

DRIVE

DVD/CD RF AMP,

FOCUS/TRACKING ERROR AMP

IC001

TZIN

MIRR

TZC

SRD SWD

SCLK

SDEN

DFT

MON

VCI

LDON

41 40

PII

33 37

45 46 47 48

136 135

137

197 196

173 174 175 180

185

184 172

166

204 205

ADC1 ADC0

ADC2

MIRR TZC

GIO6/SDI GIO7/SDO GIO8/SCK GIO13

DFCTI

ADC7 GIO5/PGIN

GIO0/INT2

PDM2 PDM3

SERVO DIGITAL

SIGNAL PROCESSOR

IC302 (1/2)

• SIGNAL PATH

: DVD PLAY

: CD PLAY

XLDON

TRACKING

COIL

(SPINDLE)

(SLED)

TRK+ TRK–

SPM+ SPM–

SLA+ SLA–

SLB+ SLB–

35 34

27 28

32 31 30 29

TRACKING COIL

DRIVE

– +

SPINDLE MOTOR

DRIVE

SLED MOTOR

DRIVE

TSD-M

POWER SAVE

3 4

202 203

139

140

159 161

167

198 199

168

PDM0 PDM1

ADC3

ADC4

MDSO MDPO

GIO1/INT3

PWM0 PWM1

GIO2/INT4

HINT

HCS

XDSPRST

22 24

156

XSDPIT

XSDPCS

XDRVMUTE

XRST

XLDON

XSDPIT, XSDPCS,

XDRVMUTE

(Page 24)

(Page 25)

2323

Page 24

DVP-S9

6-2. BLOCK DIAGRAM – MAIN Section (1/2) –

ARP

IC302 (2/2)

(Page 25)

(Page 23)

RF+

(Page 23)

MEMD0 –

MEMD15

2 – 5, 7 – 10,

41 – 44, 46 – 49

MEMA0 –

A0 – A9 I/O0 – I/O15

21 – 24,

33 18 34 35

33MARP

MEMA9

27 – 32

36 71 67 62 17

D-RAM

IC303

RAS UCAS LCAS

33MARP, 33MAVD, 27MAVD, 512FSAVD

(Page 25)

TRST

(Page 25)

HD8 – HD11

HA0 – HA3, HA19

XRD, XWRH XWRH

XRST

131

128

182 187 189

157

XARPRST

RFIN1

RFIN2

44 – 51, 53 – 60

27 – 36

MA0 – MA9 MD0 –MD15

XMWR

XOE

XRAS

XCAS

CLKIN MCKI SCKI

XARPRST

HD8 – HD15

11 – 15, 17 – 192 – 9

A0 – A7D0 – D7

HA0 – HA7

SOI0 –SOI7

SD0 – SD7

73 – 76, 78 – 81

SDCK

68 41

XSHD

69 44

XSRQ

70 46

XSAK

71 45

SDEF

72 43

DATA

62 23

BCLK

63 25

LRCK

65 26

DOUT

66 22

TDO

195 118

TDI

193 119

TCK

194 120

TMS

192 121

TRST

191 122

(FOR JTAG)

XINT

XCS

XWAT

XWRH

207

XRD

208

XRD

XWRH

XWAIT

CS4X

INT1

33MAVD 27MAVD

512FSAVD

DTI0 – DTI7

31 – 34, 36 – 39

ICLKI ISTARTI IREQO IVALI IERRI

CDIN1I CDBCKI CDLRKI CDIN2I

TDI TDO TCK TMS TRST

CRPCLKI

CLKI

180

SCLKI

182

ACLK

DATA BUS

ADDRESS BUS

COMPOUT

YOUT COUT

VREFI

HAD23 HAD22

HIREQ0

HCSB

HRWB

220 221 224 231

HWAITOB

80 74

RV501

VIDEO LEVEL

AV DECODER

IC503

223 – 235, 237 – 240,

190 191

223

RSTB

35 16 61 60

INT0

XRST

CS3X

SYSTEM CONTROLLER

IC103 (1/2)

V Y C

DQ0 – DQ15

2, 3, 5, 6, 8, 9, 11, 12, 39,

40, 42, 43, 45, 46, 48 ,49

177, 174, 171, 168, 165, 163, 160, 158, 157, 159, 162, 164,

167, 170, 173, 176

SDDQ0 – SDDQ15

HD0 – HD15 HAD0 – HAD21

2 – 5, 7 – 10

HD0 – HD15

CS2X

218 – 215, 213 – 210, 208 – 205,

203 – 200, 198 – 195, 193, 192

HA0 – HA21

16MB SDRAM

IC504

A0 – A11

21 – 24, 27 – 32,

20, 19

226 227 228 229

DACK0

DACK1

DREQ0

49504647

DACK1

DACK0

DREQ0

35 34 14 36 15 16 17 18

CLK

SDRAM DATA BUS

SDRAM ADDRESS BUS

134, 131, 128, 125, 124, 127, 130, 133, 136, 139,

137, 140

SDAD0 – SDAD11

DM ACK1

DM REQ1

DM ACK0

DM REQ0

DACK0

DREQ0

DACK1

DREQ1

DATA BUS

ADDRESS BUS

DREQ1

CLK

CKE

DQML

DQMUWECAS

RAS

CKE

DQML

DQMUWECAS

RAS

144

SDCS0B

FLASH MEMORY

DQ0 – DQ15

WECEOE

31, 33, 35, 38, 40, 42,

11 26

44, 30, 32, 34, 36, 39, 41,

43, 45

HD0 – HD15

85 – 100

HD0 – HD15

DQ0 – DQ15 A0 – A11

2, 3, 5, 6, 8, 9, 11, 12, 39,

40, 42, 43, 45, 46, 48 ,49

IC107

A0 – A20

25, 24 – 18,

8 – 1, 48, 17,

16, 9, 10

HA0 – HA21

102 – 109, 111 – 118,

120, 1 – 5

HA0 – HA21

HA1 – HA21

16MB SDRAM

21 – 24, 27 – 32,

CS0X

SDA

SCL

IC505

20, 19

CLK

CKE

35 34 14 36 15 16 17 18

CLK

CKE

DQML

CLK

CKE

DQML

DQMU

149 146 155 154 152 151 147

SDCLKO

SDCKEO

SDDQM0

• SIGNAL PATH

: DVD PLAY

: CD PLAY

: DVD/CD PLAY (VIDEO)

: DVD/CD PLAY (AUDIO)

: DVD/CD PLAY (DIGITAL OUT)

EEPROM

IC101

SDA

SCL

DQML

DQMUWECAS

CAS

SDDQM1

SDWEOB

RAS

SDCKCOB

SDRASOB

RAS

143

V, Y, C

SPDIF

SDCS1B

(Page 25)

2424

Page 25

6-3. BLOCK DIAGRAM – MAIN Section (2/2) –

V, Y, C

(Page 24)

SPDIF

(Page 24)

WIDE

SYSTEM CONTROLLER

IC103 (2/2)

XLDON

INT2

CS5X

XDRVMUTE

48/44.1k

SO0

SC0

XIFCS

INT4

MAMUTE

XFRST

SO2

CPUCK

CS6X

INT3

SI0

SI2

25 27 51 20 83 76

77 65 19

TRST

(Page 24)

XLDON, XSDPIT, XSDPCS XDRVMUTE

(Page 23)

HD8 – HD11

(Page 24)

HA0 – HA3, HA19

(Page 24)

XRD, XWRH

(Page 24)

XRST

(Page 24)

X101

16.5MHz

XLDON XSDPIT XSDPCS XDRVMUTE

XIFINT XIFOK

XFRRST

X102

27MHz

CN103

12TXD

RXD

DATA BUS

ADDRESS BUS

(FOR TEST)

HD8 – HD11

HA0 – HA3,

XRD XWRH

CLOCK GENERATOR

IC102

XTO

XTI

FSEL

IC106 (1/3) 1

4 5

12 13

33-1OUT

33-2OUT 27-1OUT

512-1OUT

IC106 (2/3)

IC106 (3/3)

CS5

INT

18 – 15

D0 – D3

5 – 1

SHA0 – SHA3.

RDN

WRN

XRST

SHA19

8 15

1481

HA19

D+5V

B+

IFSO0

IFSI0

IFSC0

XIFCS

GATE ARRAY

IC202

512FSAVD

TRMP

TRMM

CKMM

CKMP

DSW1

VIDEO SWITCH

Q711, 712

33MARP

33MAVD 27MAVD

33 32

36 – 34

TSW1 – TSW3

LOADING MOTOR

DRIVE IC701

SUB TRAY1 – 3

HEIGHT SENSOR

IC731 – 733

Q701

VIDEO BUFFER

IC701

MUTE

OUTC1 OUTC2 OUTB1 OUTB2 OUTA1 OUTA2

9 13 12 15 14

INC

INB

INA

S741

ON: WHEN SUB TRAY SLIDES OUT

(IN)

OF THE CHUCKING POSITION

S742

ON: WHEN SUB TRAY IS

(OUT)

CHUCKING POSITION

DISC IN DETECT

IC751

M721

(LOADING)

OPTICAL

TRANSMITTER

IC201

33MARP, 33MAVD,

27MAVD, 512FSAVD

IFSO0, IFSI0, IFSC0, XIFCS,

XIFINT, XIFOK, XFRRST

• SIGNAL PATH

: DVD/CD PLAY (VIDEO)

: DVD/CD PLAY (DIGITAL OUT)

VIDEO OUT

S VIDEO OUT

OPTICAL

TO ST-S9

VMUTE

DVP-S9

J202

J201

OUT

(Page 26)

(Page 24)

(Page 26)

2525

Page 26

DVP-S9

6-4. BLOCK DIAGRAM – INTERFACE CONTROL Section –

IFSO0, IFSI0, IFSC0, XVIFCS, XIFINT, XIFOK, XFRRST

(Page 25)

VMUTE

(Page 25)

S701 – 708

IFSO0 IFSI0 IFSC0 XVIFCS XIFINT XIFOK XFRRST

SYS DATAIN

SYS DATAOUT

SYS CLK

SYS CS

SYS RQ

SYS OK

SYS RST

INTERFACE CONTROLLER

KEY0

EXP-OUT DATA

EXP-IN DATA

REC/PB/PAS

IC401

EXP-CLK EXP-LAT

KEY2 A-TRIG B-TRIG

A-SHUT B-SHUT

B-HALF

IIC DATA

IIC CLK

RESET

VMUTE

85 84 87 86 94 55 53 59 89 90 91

30 29 12

D+5V (LED)

B+

INTERFACE CONTROLLER (IC401) B+

GATE ARRAY (IC202), MOTOR/COIL DRIVE (IC401),

SERVO DSP (IC503), VIDEO BUFFER (IC701) B+

EVER+5V

D+5V

RF SECTION,

SERVO DSP (IC302) B+

+3.3V

D514

D513

D512

+5V REGULATOR

IC502

+3.3V REGULATOR

IC301

RECT

D501 – 504

CN103

DATA-OUT DATA-IN

CLK

LAT

KEY2

ATRIG

BTRIG

REC/PB/PAS

ASHUT

BSHUT

BHALF

UNREG

CN102

UNREG (TC)

CN101

I2C-DATA

I2C-CLK

MRESET

V-MUTE

EVER+5V

POWER BLOCK

+5V

SYSTEM CONTROL 5

FROM TC-S9

SYSTEM CONTROL 3

FROM ST-S9

S711 – 720

D701 – 705

X401

16MHz

KEY0

LED DISC1

LED DISC3

LED PLAY

65 – 83, 88

LED PAUSE

X-OUT

X-IN

+3.3V

AV DECODER (IC503) B+

EEPROM (IC101), CLOCK GENERATOR (IC102),

GATE ARRAY (IC202), D-RAM (IC303),

P-CONT

D+3.3V

SYSTEM CONTROLLER (IC103),

FLASH MEMORY (IC107),

SDRAM (IC504, 505) B+

+1.8V

SERVO DSP (IC302),

AV DECODER (IC503) B+

+1.8V

AV DECODER (IC503) B+

M+12V

MOTOR/COIL DRIVE (IC401) B+

M+7V

MOTOR DRIVE (IC701) B+

+3.3V REGULATOR

IC502

+1.8V REGULATOR

IC006

+1.8V REGULATOR

IC501

+7V REGULATOR

IC501

+3.3V

M+12V

+12V

P. CONT

AC IN

TO TA-S9D

2626

Page 27

DVP-S9

Ver 1.5

6-5. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

Note on Printed Wiring Board:

• X : parts extracted from the component side.

• Y : parts extracted from the conductor side.

•

• : Pattern from the side which enables seeing. Caution:

Pattern face side: Parts on the pattern face side seen from (Conductor Side) the pattern face are indicated. Parts face side: Parts on the par ts face side seen from (Component Side) the parts face are indicated.

• MB board is multi-layer board.

: internal component.

However , the patterns of intermediate-layer not been included in diagram.

Note on Schematic Diagram:

• All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums.

• All resistors are in Ω and 1/ specified.

•

• C : panel designation.

Note: The components identified by mark 0 or dotted line

• A : B+ Line.

• H : adjustment for repair.

•Voltages and waveforms are dc with respect to ground

•Voltages are taken with a V OM (Input impedance 10 MΩ).

•Waveforms are taken with a oscilloscope.

• Circled numbers refer to waveforms.

• Signal path.

•Abbreviation

• Refer to servicing notes (page 4) for discrimination of

: internal component.

with mark 0 are critical for safety. Replace only with part number specified.

under no-signal conditions. no mark : DVD PLAY (): CD PLAY

Voltage var iations may be noted due to normal production tolerances.

c : DVD PLAY J : CD PLAY L : DVD/CD PLAY (VIDEO OUT) F : DVD/CD PLAY (AUDIO OUT) I : DVD/CD PLAY (DIGITAL OUT)

AUS: Australian model EA : Saudi Arabia model KR : Korean model MX : Mexican model SP : Singapore model TH : Thai model

TYPE A/B.

W or less unless otherwise

• Circuit Boards Location

SUB PANEL board

MB board

PANEL board

IN OUT SW board

VIDEO board

MAIN boar

TRAY SENSOR board

RF board

DRIVER boar

MOTOR board

DISC SENSOR board

2727

Page 28

DVP-S9

Ver 1.5

6-6. PRINTED WIRING BOARD – RF Board – • See page 27 for Circuit Boards Location. • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

1 2 3 4 5 6 7 8 9 10 11 12 13 14

RF BOARD

(COMPONENT SIDE)

R023

L002

R020

Q002

C047

R006

C048

C043

C039

C021

C024

R029

R005

C040

C046

C035

R037

R025

R038

C038

C033

D004

C034

C036

IC001

C032

C031

C023

C026

C028

R008

1732

6449

C027

R007

C022

L001

C025

Q001

C015

C017

C016

C019

C009

C018

C008

R045

R011

C007

R002

C002

D001

R010

C006

R003

C005

C001

CN001

OPTICAL

PICK-UP

BLOCK

(KHM-240AAA)

(TYPE A)

(KHM-270AAA)

(TYPE B)

RF BOARD

(CONDUCTOR SIDE)

• Semiconductor Location

Ref. No. Location

D001 B-5 D004 B-4

IC001 E-4

Q001 C-5 Q002 C-3

CN002

C044

MB BOARD

CN010

(Page 32)

R009

1-682-815-

(11)

MB BOARD

CN015

(Page 32)

1-682-815-

2828

(11)

Page 29

6-7. SCHEMATIC DIAGRAM – RF Board – • See page 44 for Waveforms. • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

OPTICAL

PICK-UP

BLOCK

(KHM-240AAA)

(TYPE A)

(KHM-270AAA)

(TYPE B)

DVP-S9

Ver 1.5

(Page 34)

Note: The components identified by mark 0 or dotted line

with mark 0 are critical for safety. Replace only with part number specified.

2929

Page 30

DVP-S9

6-8. PRINTED WIRING BOARDS – DISC SENSOR/DRIVER/IN OUT SW/MOTOR/TRAY SENSOR Boards – • See page 27 for Circuit Boards Location.

1 2 3 4 5 6 7 8

BOARD

CN203

(Page 32)

• Semiconductor Location

Ref. No. Location

IC701 D-8 IC731 A-1 IC732 A-2 IC733 A-4 IC751 E-5

3030

Q701 B-8

Page 31

6-9. SCHEMATIC DIAGRAM – DISC SENSOR/DRIVER/IN OUT SW/MOTOR/TRAY SENSOR Boards – • See page 46 for IC Block Diagram.

RPI-321

IC731

SUB TRAY1

HEIGHT SENSOR

DVP-S9

Ver 1.2

IC732

SUB TRAY2

HEIGHT SENSOR

IC733

SUB TRAY3

HEIGHT SENSOR

RPI-321

BOARD (6/6)

CN203

(Page 39)

IC751 DISC IN DETECT

3131

Page 32

DVP-S9

6-10. PRINTED WIRING BOARD – MB Board (Component Side) – • See page 27 for Circuit Boards Location.

• Semiconductor Location

Ref. No. Location

IC006 H-5 IC103 H-10 IC202 F-10 IC302 E-5 IC503 H-7

1 2 3 4 5 6 7 8 9 10 11

(Page 42)

MB BOARD

RF BOARD

CN002

(Page 28)

CN010

(COMPONENT SIDE)

L701

C315

R313

R345

C309

C312

R316

C304

R336

C320

R314

C319

R337

R338

R343

C310

R315

R341 C317 R334

C313

R317

R319

C311

C351

R342

C324

R356

R385

C349

C352

105

C306

C307

C347

C348

156

104

R349

R352

157

R328

C331

R368

R332

IC302

C766

C345

R330

C336

R384

60 1

208

C339

C340

R107

R140 R137

R509

C765

C106

C105

R125

R510

R740

C701

C764

C104

C107C108

X102

C111

R739

R508

CN012

240

VIDEO BOARD

CN201

C745

C743

FB714

R719

C744

C742

36 25

IC202

R203

R206 R207

CN203

DRIVER

BOARD

CN701

(Page 30)

C505

R412

C420

C404

R413

R414

R415

R425

C422

R439

C406

R301

R302

C004

C401 R417

C405

R304

R327

R419

C403

C414

R433

R432

C416

C418

C419

CN015

OPTICAL

PICK-UP

BLOCK

(Page 28)

C512

C521

IC006

R518

C005

R522

C006

120

121

3232

RV501

CN404

(FOR TEST)

C529

IC503

R174

C506

181

C502

R525

180

CN008

MAIN BOARD

NO106

(Page 40) (Page 40)

R121

R106

R164

R165

CN101

120 91

IC103

31 60

R182

R114

R185

R186

MAIN BOARD

CN107

R105

C110

R170

CN103

(FOR TEST)

R133

C501

R111

X101

R129 R179

R143

C112

1-682-900-

(11)

Page 33

6-11. PRINTED WIRING BOARD – MB Board (Conductor Side) – • See page 27 for Circuit Boards Location. • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

DVP-S9

Ver 1.5

1 2 3 4 5 6 7 8 9 10

• Semiconductor Location

Ref. No. Location

IC101 I-3

MB BOARD

(CONDUCTOR SIDE)

IC102 E-5 IC106 I-3 IC107 G-3 IC301 F-9 IC303 D-7 IC401 H-9 IC501 I-4

IC502 G-8 IC504 H-6 IC505 G-6

R737

R738

C721

R713

IC701

FB712

R718

FB711

C741

R717

Q712

C702

R142

R126

R138

R725

R724

Q711

R211

C205

R212

FL202

C204

C202

C206

C203

R202

FL204

R215

FL203

R210

R214

R209

R208

C207

R141

R712

R711

C504

R517

C547

C546

R021

C514

C516

FL505

R532

C508

C532

C526

R017

C509

C530

C545

R112

R156

R184

R183

R145

R113

FL103

C124

R163

C103

FL102

IC107

R155 R153

R151

C109

C114

R119

R147

R168

IC101

C116

R154

R116

R152

R117

R118

R150

C113

R128

R130

IC106

R187

R167

R175

R166

R172

R123

R146

FL502

IC501

R507

R134

C523

C524

C525

R554

R162

R160

R161

C119

R149

R132

R157

R131

R188

C716

C711

FL101

IC102

C722

L715

C717

L713

C712

L711

R101

FB112

C535

IC505

IC504

C531

C007

C534

C533

R109

R124

C510

C342

R533

FB011

R320

C343

C341

R136

C344

C511

FL005

C536

C538

C539

FB012

C337

IC303

C338

C513

C520

C522

C537

C542

R524

R515

C540

C519

C518

C541

R516

FL501

C335

R513

C503

FB007

C334

C350

R512

R511

R514

IC502

C018

FL004

FB010

FB009

FB008

FL003

R521

C019

R321

C333

C325 C326

R318

R312

C332

C318 R335 C327

C346

R428

C415

R435

R310

R311

C321

R416

C411

R701

R306

R308

R199

R307

R411

R424

C429

R299

C305

R423

R305

R351 R350

R409

R309 R344

C323

C328

R420

C322

R410

C430

R426

IC401

25 5130 31

R080

IC301

453

4976

R329

R408

R422

C408

C301

R407

R421

C407

C402

(TYPE A)

R406 R418

R427

C413

R434

C417

R430

R429 C412

R431

R078

R076 R077

1-682-900-

(11)

IC701 C-5

Q711 D-4 Q712 D-4

3333

Page 34

DVP-S9

Ver 1.5

6-12. SCHEMATIC DIAGRAM – MB Board (1/6) – • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

(Page 35)

(Page 29)

(Page 35)

(Page 39)

(Page 38)

(Page 37)

(Page 35)

(TYPE A)

R077

∗

330 (TYPE A)

10k (TYPE B)

∗

(Page 37)

(Page 35)

(Page 29)

(Page 35)

(Page 36)

(Page 37)

(Page 41)

(Page 39)

3434

Page 35

6-13. SCHEMATIC DIAGRAM – MB Board (2/6) – • See page 44 for Waveforms.

(Page 36)

DVP-S9

(Page 36)

(Page 34)

(Page 37)

(Page 36)

(Page 37)

(Page 34)

(Page 37)

3535

(Page 34)

(Page 37)

Page 36

DVP-S9

6-14. SCHEMATIC DIAGRAM – MB Board (3/6) – • See page 44 for Waveforms.

(Page 37)

(Page 38)

(Page 35)

(Page 34)

(Page 38)

(Page 37)

(Page 35)

3636

Page 37

6-15. SCHEMATIC DIAGRAM – MB Board (4/6) – • See page 44 for Waveforms. • See page 46 for IC Block Diagram.

(Page 36)

(Page 35)

DVP-S9

(Page 35)

(Page 36)

(Page 39)

(Page 35)

(Page 36)

(Page 34)

(Page 36)

(Page 39)

(Page 35)

(Page 36)

(Page 38)

(Page 36)

(Page 39)

(Page 41)

(Page 34)

(Page 35)

(Page 36)

(Page 39)

(Page 38)

(Page 35)

(Page 36)

(Page 34)

3737

Page 38

DVP-S9

6-16. SCHEMATIC DIAGRAM – MB Board (5/6) – • See page 44 for Waveforms. • See page 46 for IC Block Diagram.

(Page 34)

(Page 37)

(Page 36)

(Page 37)

(Page 43)

(Page 36)

3838

Page 39

6-17. SCHEMATIC DIAGRAM – MB Board (6/6) –

(Page 34)

DVP-S9

(Page 37)

(Page 31)

(Page 34)

3939

Page 40

DVP-S9

6-18. PRINTED WIRING BOARD – MAIN Board – • See page 27 for Circuit Boards Location.

1 2 3 4 5 6 7 8 9 10

(Page 32)

MB BOARD

E DG

CN101

(Page 42)

VIDEO BOARD

CN202

MAIN BOARD

CN501

(FOR TEST)

CN401

JW145

R465

R469

R473

R477

R481

R434

C407

(FOR TEST)

R431

JW143

JW144

CN503

R433

R435

R441

R443

EL105

JW140

R447

R457

LP104

R444

R456

JW138

R448

R453

R455

JW137

JW133

R454

R442

R451

R459

R437

R436

C402

JW132

R440

C408

R432

R419

JW131

R567

R430

31 30

IC401

R429

R497

JW130

LP103

JW128

JW146

R413

JW147

R411

R409

C406

C403

JW126

R496

R417

C404

X401

100

R480

R492

R495

CN107

C411

R483

JW127

C401

JW125

JW121

JW124

JW123

EL104

C427

R427

R493

R488

R412

JW120

C425

R482

R134

R494

R491

R485

JW119

JW118

JW117

R425

R490

R484

R133

R489

R487

JW115

JW113

JW114

R132

R486

NO105

C505

C405

FB502

C502

JW111

JW402

R104

JW407

JW108

FB501

NO106

C504

C507

D105

D513

D514

C557

D512

R103

R102

R101

(Page 32)

MB BOARD

CN008

C506

FB503

C509

C513

D505

C514

CN101

JW102

NO104

IC501

IC502

C500

POWER BLOCK

JW103

C101

C102

C512

C508

JW105

JW107

D504

EL103

LP101

LP102

C501

D503

EL101

D502

TO TA-S9D

JW151

JW101

EL102

AC IN

CN102

D501

JW100

CN103

1-682-811-

SYSTEM CONTROL 5

(11)

CN103

FROM TC-S9

(Page 42)

• Semiconductor Location

Ref. No. Location

D105 D-7 D501 C-9 D502 C-9 D503 C-9 D504 C-9 D505 C-8 D512 D-8 D513 C-8 D514 C-8

IC401 C-4 IC501 B-8 IC502 C-8

PANEL BOARD

NO703

SYSTEM CONTROL 3

FROM ST-S9

4040

Page 41

6-19. SCHEMATIC DIAGRAM – MAIN Board – • See page 44 for Waveform.

(Page 43)

(Page 34)

(Page 37)

DVP-S9

(Page 43)

Note: The components identified by mark 0 or dotted line

with mark 0 are critical for safety.

4141

Replace only with part number specified.

Page 42

DVP-S9

6-20. PRINTED WIRING BOARDS – PANEL/SUB PANEL/VIDEO Boards – • See page 27 for Circuit Boards Location.

1 2 3 4 5 6 7 8 9 10

J202

VIDEO BOARD

VIDEO OUT

PANEL BOARD

J201

NO703

R712

R711

S715

S718

RETURN NEXT PREV

R714

R713

S712

R715

S713

D701

S716

D701, S716

S720

R716

R718

S711

S714

D702

S717

S719

BOARD

CN401

(Page 40)

D702, S717

R717

MAIN

S VIDEO OUT

FB201

FB202

FB203

FB204

C206

JW201

IC201

CN201

MB BOARD

F G

CN012

(Page 32)

D703

3 2 1

(DISC 3)

D704

(DISC 2)

D705

(DISC 1)

IC201

OPTICAL

OUT

TO ST-S9

C203

C204

CN202

L201

MAIN BOARD

NO105

(Page 40)

NO702

1-682-813-

1 2

(11)

SUB PANEL BOARD

S701 – 708S711 – 720

S706

(DISC 3)

NO701

S701

DISC 3 DISC 2 DISC 1

R701

S707

R706

R705

S705

(DISC 2)

S702

R702

S708

PLAY MODEREPEAT

R707

R704

S704

(DISC 1)

S703

R703

• Semiconductor Location

Ref. No. Location

D701 C-2 D702 C-2 D703 C-5 D704 C-6 D705 C-7

IC201 A-7

R719

1-682-812-

(11)

1-682-814-

(11)

4242

Page 43

6-21. SCHEMATIC DIAGRAM – PANEL/SUB PANEL/VIDEO Boards –

DVP-S9

(Page 38)

(Page 41)

4343

Page 44

DVP-S9

•Waveforms

– RF Board –

– MB Board –

1 IC001 2 (RF IN) (DVD PLAY)

2 IC001 2 (RF IN) (CD PLAY)

3 IC001 ra (TE) (DVD PLAY)

Approx. 570 mVp-p

Approx. 550 mVp-p

6 IC001 rs (FE) (CD PLAY)

Approx. 600 mVp-p

7 IC001 tl (SIGO) (DVD/CD PLAY)

Approx.

1.4 Vp-p

8 IC302 <zx, (RFIN2) (CD PLAY)

9 IC302 <zcz (RFIN1) (DVD PLAY)

0 IC302 <zcb (ADC0) (DVD PLAY)

Approx.

1.4 Vp-p

Approx.

1.4 Vp-p

qd IC302 <zcn (ADC1) (CD PLAY)

Approx. 600 mVp-p

qf IC302 <z,x (CLKIN), <z,m (MCKI), <z,. (SCKI)

3.4 Vp-p

29.5 ns

qg IC503 qs (ACLK) (DVD PLAY)

qk IC503 uf (YOUT) (COLOR BAR (NTSC))

1 Vp-p

ql IC503 uf (YOUT) (COLOR BAR (PAL))

1 Vp-p

w; IC503 uj (COUT) (COLOR BAR (NTSC))

wd IC503 i; (COMPOUT)

(COLOR BAR (PAL))

1 Vp-p

wf IC503 <z,/ (CLKI), <z,x (SCLKIN)

3.4 Vp-p

37 ns

wg IC103 tf (X0)

4 IC001 ra (TE) (CD PLAY)

5 IC001 rs (FE) (DVD PLAY)

Approx. 120 mVp-p

Approx. 800 mVp-p

Approx. 180 mVp-p

qa IC302 <zcb (ADC0) (CD PLAY)

qs IC302 <zcn (ADC1) (DVD PLAY)

Approx. 120 mVp-p

Approx. 800 mVp-p

Approx. 180 mVp-p

40.7 ns

qh IC503 qs (ACLK) (CD PLAY)

44.3 ns

qj IC503 wl (CRPCLKI)

3.4 Vp-p

710 mVp-p

wa IC503 uj (COUT) (COLOR BAR (PAL))

710 mVp-p

ws IC503 i; (COMPOUT)

(COLOR BAR (NTSC))

1 Vp-p

1.8 Vp-p

60.6 ns

wh IC102 3 (27-1OUT)

3.4 Vp-p

37 ns

wj IC102 7 (XTI)

1.6 Vp-p

29.5 ns

37 ns

4444

Page 45

– MAIN Board –

DVP-S9

wk IC102 9 (512-2OUT), 0 (512-1OUT)

(DVD PLAY)

3.4 Vp-p

40.7 ns

wl IC102 9 (512-2OUT), 0 (512-1OUT)

(CD PLAY)

3.4 Vp-p

44.3 ns

e; IC102 qd (33-2OUT), qg (33-1OUT)

ed IC701 qd (OUTB1) (COLOR BAR (NTSC))

2 Vp-p

ef IC701 qd (OUTB1) (COLOR BAR (PAL))

2 Vp-p

eg IC701 qg (OUTA1) (COLOR BAR (NTSC))

ej IC401 qd (X-OUT)

2.5 Vp-p

62.5 ns

3.4 Vp-p

29.5 ns

ea IC701 0 (OUTC1) (COLOR BAR (NTSC))

2 Vp-p

es IC701 0 (OUTC1) (COLOR BAR (PAL))

2 Vp-p

1.8 Vp-p

eh IC701 qg (OUTA1) (COLOR BAR (PAL))

1.8 Vp-p

Page 46

DVP-S9

• IC Block Diagrams – DRIVER Board –

IC701 BA6956AN

TSD

CONTROL LOGIC

1 2 3 4 5 6 7 8 9

OUT2

RNF

OUT1

VREF

– MB Board –

IC102 IMIC6001BTD

VCC

FIN

GND

RIN

VDD

VSS

27-1OUT

27-2OUT

VDD

VSS

XTI

XTO

OSC PLL2

PLL1

IC701 BA7666FS-E2

MUTE

1 16

INA

GND

INB

GND

INC

GND

6dB

75Ω

TEST

33-1OUT

FSEL

33-2OUT

VDD

VSS

512-1OUT

512-2OUT

VCC

OUTA1

143

OUTA2

OUTB1

OUTB2

OUTC1

OUTC2

Page 47

6-22. IC PIN FUNCTION DESCRIPTION

• RF BOARD IC001 SP3728AC (DVD/CD RF AMP, FOCUS/TRACKING ERROR AMP)

Pin No. Pin Name I/O Description

1, 2 RFIP, RFIN I

3CP— 4WINI 5WPPO 6CN—

7 to 10 A2 to D2 I 11 to 14 D to A I 15 to 18 E to H I

19 VC O 20 VPB — 21 DVDPD I 22 CDPD I 23 VNB — 24 LDSELO O 25 DVDLD O 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52

53 54, 55 56, 57

CDLD O

LDON I

MEVO O

MIN I

MP —

MB — MLPF — MIRR O

BYP2 —

PII I

PI O TZC O DFT O

VCI I

TZIN I

TE O FE O

TPH —

MON O

SRD O

SWD I SCLK I SDEN I

V33 —

RX I

TPA — MEV — VNA —

FNN, FNP O

DIP, DIN I

RF signal input terminal Tracking LPF terminal Wobble detection signal input terminal Not used (open) Wobble push-pull signal output terminal Not used (open) Tracking LPF terminal Photo detector interface input terminal (AC coupled input for the DPD and wobble) Photo detector interface input terminal (main) Photo detector interface input terminal (sub) Reference voltage (+2.5V) output terminal Power supply terminal (+5V) (servo block) DVD APC signal input terminal CD APC signal input terminal Ground terminal (servo block) APC LD select signal output terminal DVD APC signal output terminal CD APC signal output terminal APC LD output control signal input terminal Envelope signal output terminal for mirror RF signal input terminal for mirror Mirror top hold terminal Mirror bottom hold terminal Mirror LPF terminal Mirror detect signal output to the servo DSP (IC302) Servo AGC gain control terminal Pull-in signal input terminal Pull-in signal output terminal Tracking zero crossing signal output to the servo DSP (IC302) Defect signal output to the servo DSP (IC302) Reference voltage input terminal Tracking zero crossing signal input terminal Tracking error signal output to the servo DSP (IC302) Focusing error signal output to the servo DSP (IC302) PI top hold terminal Monitor signal output to the servo DSP (IC302) Serial data output to the servo DSP (IC302) serial data input from the servo DSP (IC302) Serial clock signal input from the servo DSP (IC302) Serial data enable signal input from the servo DSP (IC302) Power supply terminal (+3.3V) (CMOS output buffers) Reference resistor input terminal RF top hold terminal RF bottom envelope terminal Ground terminal (RF block and serial port) Differential filter normal signal output terminal Analog signal input terminal for RF single buffer

DVP-S9

Page 48

DVP-S9

Pin No. Pin Name I/O Description

58 59

60 61, 62 63, 64

BYP —

SIGO O

VPA —

AIP, AIN I

ATON, ATOP O

RF AGC gain control terminal Single-ended RF signal output terminal Power supply terminal (+5V) (RF block and serial port) AGC amp signal input terminal Differential attenuator signal output terminal

Page 49

• MB BOARD IC103 MB91307APFV-G-BND-E1 (SYSTEM CONTROLLER)

Pin No. Pin Name I/O Description

1 to 5 HA17 to HA21 O

6 HA22 — 7WPO 8 TRM/XKRCS —

9 AVCC — 10 AVRH — 11 AVSS — 12 AN0 I 13 AN1 I 14 AN2 I 15 AN3 I 16 INT0 I 17 INT1 I 18 INT2 I 19 INT3 I 20 INT4 I

21, 22 INT5, INT6 —

23 INT7 — 24 VCC — 25 SI0 I 26 SO0 O 27 SC0 O 28 SI1 I 29 SO1 O 30 SC1 O 31 SI2 I 32 SO2 O 33 DSENS — 34 VSS — 35 XRST O 36 XARPPST O

RGBSEL/MICMUTE

37 38 SDA I/O 39 SCL O 40 TRM+/XKRRST —

EUROV/Y/CLAPSW1

DISCEXT/CLPSW0

42 43 MD0 I 44 MD1 I 45 MD2 I 46 DREQ0 I 47 DACK0 O Acknowledge 0 signal output to the AV decoder (IC503) 48 XDRVMUTE O 49 DREQ1 I 50 DACK1 O

Address signal output terminal Not used (open) Write control signal output to the EEPROM (IC101) Not used (open) Power supply terminal (+3.3V) (for A/D converter) Reference voltage input (+3.3V) terminal (for A/D converter) Ground terminal (for A/D converter) Mode 0 set input terminal Mode 1 set input terminal Mode 2 set input terminal Mode 3 set input terminal Interrupt request signal input from the AV decoder (IC503) Interrupt request signal input from the ARP (IC302) Interrupt request signal input from the servo DSP (IC302) Interrupt request signal input from the gate array (IC202) Interrupt request signal input from the interface controller (IC401) Not used (fixed at “H”) Not used (open) Power supply terminal (+3.3V) Serial data input from the interface controller (IC401) Serial data output to the interface controller (IC401) Serial clock signal output to the interface controller (IC401) Serial data input terminal Not used (open) Serial data output terminal Not used (open) Serial clock signal output terminal Not used (open) Serial data input terminal (for test) Serial data output terminal (for test) Not used (open) Ground terminal System reset signal output terminal “L”: reset Reset signal output to the ARP (IC302) “L”: reset

—

Not used (open) Two-way data bus with EEPROM (IC101) Serial clock signal output to the EEPROM (IC101) Not used (fixed at “L”)

—

Not used (open)

—

Not used (open) Mode select 0 signal input terminal (fixed at “H” in this set) Mode select 1 signal input terminal (fixed at “L” in this set) Mode select 2 signal input terminal (fixed at “L” in this set) Request 0 signal input from the AV decoder (IC503)

Drive mute signal output terminal Request 1 signal input from the AV decoder (IC503) Acknowledge 1 signal output to the AV decoder (IC503)

DVP-S9

Page 50

DVP-S9

Pin No. Pin Name I/O Description

51 XIFCS O 52 VSS — 53 X1 O 54 X0 I 55 VCC — 56 CKSW1 — 57 OCSSW1 — 58 CS0X O 59 CS1X — 60 CS2X O 61 CS3X O 62 CS4X O 63 CS5X O 64 C — 65 CS6X O 66 CS7X — 67 XWAIT I 68 BGRNTX — 69 BGR — 70 XRD O 71 XWRH O 72 XWRL — 73 NMIX — 74 HSTX — 75 VSS — 76 XFRRST I 77 CPUCK O 78 OCSW2 — 79 XDACX — 80 VESCS/X39CS — 81 48/44.1K O 82 WIDE O 83 MAMUTE I 84 XLDON O

85 to 100 HD0 to HD15 I/O

101 VSS —

102 to 10

110 VCC —

111 to 118 HA8 to HA15 O

119 VSS — 120 HA16 O

HA0 to HA7 O

Chip select signal output to the interface controller (IC401) Ground terminal System clock output terminal (16.5MHz) System clock input terminal (16.5MHz) Power supply terminal (+3.3V) Not used (open) Not used (open) Chip select signal output to the flash memory (IC107) Not used (open) Chip select signal output to the AV decoder (IC503) Chip select signal output to the AV decoder (IC503) Chip select signal output to the ARP (IC302) Chip select signal output to the Servo DSP (IC302) Capacitor connected terminal Chip select signal output to the gate array (IC202) Not used (open) Wait signal input terminal Not used (fixed at “H”) Not used (open) Read enable signal output terminal High byte write enable signal output terminal Not used (open) Not used (fixed at “H”) Not used (fixed at “H”) Ground terminal Reset signal input from the interface controller (IC401) “L”: reset CPU clock signal output terminal Not used (fixed at “H”) Not used (fixed at “H”) Not used (fixed at “H”) Sampling frequency selection signal output terminal “L”: 48kHz, “H”: 44.1kHz Wide signal output terminal System OK signal input terminal LD control signal output terminal Two-way data bus terminal Ground terminal Address signal output terminal Power supply terminal (+3.3V) Address signal output terminal Ground terminal Address signal output terminal

Page 51

• MB BOARD IC302 CXD9635R (SERVO DIGITAL SIGNAL PROCESSOR, ARP)

Pin No. Pin Name I/O Description

1 VSS —

2 to 9 D0 to D7 I/O

10 VDD 3.3V —

11 to 15 A0 to A4 I

16 VSS —

17 to 19 A5 to A7 I

20 VDD 1.8V — 21 XINT O 22 HINT O 23 XCS I 24 HCS I 25 XWAT O 26 VSS —

27 to 36 MA0 to MA9 O

37 VDD 3.3V — 38 XMWR O 39 XCAS O 40 VSS — 41 XRAS O 42 XOE O 43 VDD1 1.8V —

44 to 51 MD0 to MD7 I/O

52 VSS —

53 to 60 MD8 to MD15 I/O

61 VDD 3.3V — 62 DATA O 63 BCLK O 64 VSS — 65 LRCK O 66 DOUT O 67 VDD 1.8V — 68 SDCK O 69 XSHD O 70 XSRQ I 71 XSAK O 72 SDEF O

73 to 81 SD0 to SD7 O

82 VDD 3.3V —

83 to 88 MNT0 to MNT5 I/O

89, 90 MNT6, MNT7 I/O

91 ESTB O 92 VDD 1.8V — 93 RFD I/O RF digital data input/output terminal Not used (fixed at “H”) 94 VSS —

Ground terminal (for digital system) Two-way data bus terminal Power supply terminal (+3.3V) (for digital system) Address signal input terminal Ground terminal (for digital system) Address signal input terminal Power supply terminal (+1.8V) (for digital system) Interrupt request signal output to the system controller (IC103) Interrupt request signal output to the system controller (IC103) Chip select signal input from the system controller (IC103) Chip select signal input from the system controller (IC103) Wait signal output terminal Ground terminal (for digital system) Address signal output to the D-RAM (IC303) Power supply terminal (+3.3V) (for digital system) Write enable signal output to the D-RAM (IC303) CAS signal output to the D-RAM (IC303) Ground terminal (for digital system) RAS signal output to the D-RAM (IC303) Output enable signal output to the D-RAM (IC303) Power supply terminal (+1.8V) (for digital system) Two-way data bus with the D-RAM (IC303) Ground terminal (for digital system) Two-way data bus with the D-RAM (IC303) Power supply terminal (+3.3V) (for digital system) CD data output to the AV decoder (IC503) CD bit clock signal output to the AV decoder (IC503) Ground terminal (for digital system) CD LR clock signal output to the AV decoder (IC503) Digital signal output to the AV decoder (IC503) Power supply terminal (+1.8V) (for digital system) SD bus clock signal output to the AV decoder (IC503) SD bus header signal output to the AV decoder (IC503) SD bus request signal input from the AV decoder (IC503) SD bus acknowledge signal output to the AV decoder (IC503) SD bus error flag signal output to the AV decoder (IC503) SD bus data output to the AV decoder (IC503) Power supply terminal (+3.3V) (for digital system) Monitor signal input/output terminal Not used (open) Monitor signal input/output terminal Not used (fixed at “H”) Error strobe signal output terminal Not used (open) Power supply terminal (+1.8V) (for digital system)

Ground terminal (for digital system)

DVP-S9

Page 52

DVP-S9

Pin No. Pin Name I/O Description

95 PLCKO O

96 to 103 ADO0 to ADO7 O

104 VSS — 105 VSSA4 — 106 VCO I

107, 108 R1, R2 I

109 VDDA4 3.3V — 110 VSSA3 — 111 INP I 112 INM I

113 to 115 FR3 to FR1 I

116 Y O 117 VDDA3 3.3V — 118 VREF I 119 BIAS I 120 VDDA2 3.3V — 121 VSSA2 — 122 AOUT O 123 IREF I 124 VSSD2 — 125 VDDD2 3.3V — 126 VRT I 127 VDDA1 3.3V — 128 RFIN2 I 129 NMIX — 130 VSSA1 — 131 RFIN1 I 132 VRB I 133 VSSD1 — 134 VDDD1 3.3V — 135 ADC0 I 136 ADC1 I 137 ADC2 I 138 VDDA0 3.3V — 139 ADC3 I 140 ADC4 I 141 VSSA0 —

142, 143 ADC5, ADC6 I

144 ADC7 I 145 VDDD0 3.3V — 146 VSSD0 — 147 VRBA I 148 VSSA0 — 149 TESTAA O 150 VDDA0 3.3V —

Not used (open) Not used (fixed at “H”) Ground terminal (for digital system) Ground terminal (for analog system) VCO control signal input terminal VCO outside resistance signal input terminal Power supply terminal (+3.3V) (for analog system) Ground terminal (for analog system) OP amp positive input terminal OP amp negative input terminal Feedback resistance signal input terminal OP amp output terminal Power supply terminal (+3.3V) (for analog system) Reference voltage input terminal (for D/A converter) Bias input terminal (for D/A converter) Power supply terminal (+3.3V) (for analog system) Ground terminal (for analog system) D/A converter output terminal (for D/A converter) Reference current input terminal (for D/A converter) Ground terminal (for D/A converter) Power supply terminal (+3.3V) (for D/A converter) A/D converter reference input terminal Power supply terminal (+3.3V) (for analog system) RF signal input terminal RF signal input terminal Not used Ground terminal (for analog system) RF signal input terminal A/D converter reference input terminal Ground terminal (for A/D converter) Power supply terminal (+3.3V) (for A/D converter) Tracking error signal input from the SP3728AC (IC001) Focusing error signal input from the SP3728AC (IC001) Pull-in signal input from the SP3728AC (IC001) Power supply terminal (+3.3V) (for analog system) Tracking coil drive signal input from the FAN8034 (IC401) Spindle motor drive signal input from the FAN8034 (IC401) Ground terminal (for analog system) A/D converter input terminal Monitor signal input from the SP3728AC (IC001) Power supply terminal (+3.3V) (for A/D converter) Ground terminal (for A/D converter) A/D converter reference input terminal Ground terminal (for analog system) ASW output terminal Not used (open) Power supply terminal (+3.3V) (for analog system)

Page 53

Pin No. Pin Name I/O Description

151 VRTA I 152 VSS —

153 to 155

TESTK0 to TESTK

156 XDSPRST I 157 XARPRST I 158 VSS — 159 MDS0 O 160 MON O 161 MDP0 O 162 DFCT O 163 JITPWM O 164 LOCK O 165 VDD1 1.8V — 166 GIO0/INT2 I 167 GIO1/INT3 O 168 GIO2/INT4 I 169 GIO3/INT5 — 170 VDD 3.3V — 171 GIO4/PGREF — 172 GIO5/PGIN I 173 GIO6/SDI I 174 GIO7/SDO O 175 GIO8/SCK O 176 GIO9/FGREF O 177 GIO10/FGIN O 178 GIO11/TMC2 — 179 GIO12 — 180 GIO13 O 181 VSS — 182 CLKIN I 183 VSSA5 — 184 VDDA5 1.8V — 185 DFCTI I 186 VSS — 187 MCKI I 188 VDD 1.8V — 189 SCKI I 190 VSS — 191 TRST I 192 TMS I 193 TDI I 194 TCK I 195 TDO O 196 TZC I 197 MIRR I

A/D converter reference input terminal Ground terminal (for digital system)

Test signal input terminal (fixed at “L”) DSP reset signal input from the system controller (IC103) “L”: reset ARP reset signal input from the system controller (IC103) “L”: reset Ground terminal (for digital system) Spindle motor drive signal output to the FAN8034 (IC401) Motor ON/OFF signal output terminal Not used (open) Spindle motor drive signal output to the FAN8034 (IC401) Defect detection signal output terminal Jitter PWM signal output terminal Not used (open) EFM lock detection signal output terminal Not used (open) Power supply terminal (+1.8V) (for digital system) Inlimit sensor input terminal Spindle motor drive control signal output to the FAN8034 (IC401) TSD-M signal input from the FAN8034 (IC401) Not used (open) Power supply terminal (+3.3V) (for digital system) Not used (open) Monitor signal input from the SP3728AC (IC001) Serial data input from the SP3728AC (IC001) Serial data output to the SP3728AC (IC001) Serial clock signal output to the SP3728AC (IC001) Motor drive signal output terminal Not used Motor drive signal output terminal Not used Not used (open) Not used (open) Serial data enable signal output to the SP3728AC (IC001) Ground terminal (for digital system) Clock signal input terminal Ground terminal (for analog system) Power supply terminal (+1.8V) (for analog system) Defect signal input from the SP3728AC (IC001) Ground terminal (for digital system) Clock signal input terminal Power supply terminal (+1.8V) (for digital system) Clock signal input terminal Ground terminal (for digital system) Reset signal input terminal (for JTAG boundary scan) MS signal input terminal (for JTAG boundary scan) Serial data input terminal (for JTAG boundary scan) Clock signal input terminal (for JTAG boundary scan) Serial data output terminal (for JTAG boundary scan) Tracking zero crossing signal input from the SP3728AC (IC001) Mirror detect signal input terminal from the SP3728AC (IC001)

DVP-S9

Page 54

DVP-S9

Pin No. Pin Name I/O Description

198, 199 PWM0, PWM1 O

200 PWM2 O

201 VDD 3.3V — 202, 203 PDM0, PDM1 O 204, 205 PDM2, PDM3 O

206 VSS —

207 XWR I

208 XRD I

Sled motor drive signal output to the FAN8034 (IC401) Motor drive signal output terminal Not used Power supply terminal (+3.3V) (for digital system) Tracking coil drive signal output to the FAN8034 (IC401) Focusing coil drive signal output to the FAN8034 (IC401) Ground terminal (for digital system) Write enable signal input terminal Read enable signal input terminal

Page 55

• MAIN BOARD IC401 M30622MAA-B33FP (INTERFACE CONTROLLER)

Pin No. Pin Name I/O Description

1 to 7

9CNVSS — 10 11 12 13 14 VSS — 15 16 VCC — 17 18 19

20 to 28

29 30 IIC-DATA I/O 31 32 33 34 35 SYS DATAOUT O 36 SYS DATAIN I 37 SYS CLK O 38 39 40 41 42 SYS RQ O 43 44 P.CONT O 45 NC — 46 NC — 47 48

49, 50 NC —

51 52 NC — 53 B-TRIG O 54 55 A-TRIG O

56 to 58

60, 61

NC — Not used (open)

BYTE I

NC — Not used (fixed at “L”)

NC — Not used (open) RESET I System reset signal input terminal X-OUT

X-IN

NMI

NC — Not used (open)

SYS CS

NC — Not used (open)

IIC-CLK I/O Communication data reading clock signal input or transfer clock signal output terminal

TXD1 I Serial data input terminal (for test) RXD1 O serial data output terminal (for test)

CLK1 O Serial clock signal output terminal (for test) RTS1 O RTS signal output terminal (for test)

SYS POWER

NC — Not used (open)

SYS RST O System reset signal output terminal “L”: reset

NO-USE — Not used (fixed at “L”)

SYS OK

DVDFRCHK

VMUTE O Mute signal output to the video buffer (IC701) “H”: mute

NC — Not used (fixed at “H”)

ECO CHECK — Not used (fixed at “H”)

NC — Not used (open)

REC/PB/PASS

NC — Not used (open)

External data bus line byte selection signal input “L”: 16 bits, “H”: 8 bits Not used (fixed at “L”)

Processor mode switch terminal (for test)

System clock output terminal (16 MHz) Ground terminal

System clock input terminal (16 MHz) Power supply terminal (+5V)

Non-maskable interrupt input terminal Not used (fixed at “H”)

Chip select signal input from the system controller (IC103)

Communication data bus terminal

serial data output to the system controller (IC103) serial data input from the system controller (IC103) Serial clock signal output to the system controller (IC103)

Power ON/OFF control signal output terminal “H”: ON Not used (open)

Interrupt request signal output to the system controller (IC103)

System OK signal output to the system controller (IC103) Power block ON/OFF control signal output terminal “H”: ON Not used (open) Not used (fixed at “H”)

Flash memory (for DVD) check signal output terminal Not used (fixed at “H”)

Not used (open)

Not used (open) Deck-B trigger plunger drive signal output terminal “H”: trigger plunger on

Deck-A trigger plunger drive signal output terminal “H”: trigger plunger on

Recording/playback/pass selection signal output terminal

“L”: recording, center voltage: playback, “H”: pass

DVP-S9

Page 56

DVP-S9

Pin No. Pin Name I/O Description

62 VCC — 63

64 VSS — 65 to 68 69 to 72 73 to 76 77 to 80 81 to 83

89 A-SHUT I

90 B-SHUT I

96 AVSS —

99 AVCC —

100

SOFT-TEST

LED_DISC1 O LED drive signal output of the LED_DISC2 O LED drive signal output of the LED_DISC3 O LED drive signal output of the

LED_PLAY O LED drive signal output of the

LED_PAUSE O LED drive signal output of the

EXP-IN DATA I Serial data input terminal

EXP-OUT DATA

EXP-LAT O Serial data latch pulse signal output terminal

EXP-CLK O Serial clock signal output terminal

LED_PAUSE O LED drive signal output of the

B-HALF

MODEL-IN I Model destination setting terminal

PWRCHK — Power check terminal Fixed at “H”

KEY2 I Key input terminal KEY1 I Key (S711 to S720) input terminal (A/D input)

KEY0 I Key (S701 to S708) input terminal (A/D input) VREF

NC — Not used (open)

Power supply terminal (+5V)

For software check terminal Not used (open) Ground terminal

indicator (D705) “L”: LED on

indicator (D704) “L”: LED on

indicator (D703) “L”: LED on

indicator (D702) “L”: LED on

indicator (D701) “L”: LED on

O Serial data output terminal

indicator (D701) “L”: LED on Shut off (deck-A) detection signal input terminal Shut off (deck-B) detection signal input terminal

Detection input terminal from the deck-B cassette detect switch “L”: cassette in

Ground terminal (for A/D converter)

Reference voltage (+5V) input terminal (for A/D converter) Power supply terminal (+5V) (for A/D converter)

Page 57

SECTION 7

EXPLODED VIEWS

DVP-S9

Ver 1.5

NOTE:

• -XX and -X mean standardized parts, so they may have some difference from the original one.

• Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED)

↑↑

Parts Color Cabinet's Color

• Refer to servicing notes (page 4) for discrimination of TYPE A/B.

7-1. CASE SECTION

• Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

• The mechanical parts with no reference number in the exploded views are not supplied.

•Abbreviation AUS: Australian model EA : Saudi Arabia model KR : Korean model

MX : Mexican model SP : Singapore model TH : Thai model

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

chassis section

front panel section

Ref. No. Part No. Description Remark

0 1 1-476-027-11 POWER BLOCK (AUS, EA, SP, TH) 0 1 1-476-028-11 POWER BLOCK (AEP, KR, UK) 0 1 1-476-029-11 POWER BLOCK (E, MX)

3 3-363-099-21 SCREW (CASE 3 TP2) 4 4-233-134-11 CASE

0 5 1-823-394-11 CORD, POWER (E, MX) 0 5 1-823-396-11 CORD, POWER (AEP, AUS, EA, SP, TH, UK) 0 5 1-823-399-11 CORD, POWER (KR)

Ref. No. Part No. Description Remark * 6 3-703-244-00 BUSHING (2104), CORD

(AEP, AUS, EA, KR, SP, UK) 6 3-703-571-11 BUSHING (S) (4516), CORD (E, MX, TH) 7 4-965-822-01 FOOT

0 F1 1-532-388-31 MINIATURE FUSE-LINKS, TIME-LAG FUSE

(T2AL/250V)

#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S

#2 7-685-871-01 SCREW +BVTT 3X6 (S)

Page 58

DVP-S9

7-2. FRONT PANEL SECTION

not supplied

Ref. No. Part No. Description Remark

51 4-233-136-21 LID (CD) 52 4-233-147-01 SPRING (CD) 53 X-4953-614-1 PANEL ASSY, FRONT 54 4-951-620-01 SCREW (2.6X8), +BVTP

Ref. No. Part No. Description Remark

55 1-682-814-11 SUB PANEL BOARD 56 1-682-812-11 PANEL BOARD 57 4-963-404-21 EMBLEM (5-A), SONY (TH)

Page 59

7-3. CHASSIS SECTION

CD mechanism deck section-1

104

106

DVP-S9

105

not supplied

108

107

101

102

103

102

not supplied

110

not supplied

109

Ref. No. Part No. Description Remark

101 1-823-609-11 WIRE (FLAT TYPE) (25 CORE) 102 3-970-608-01 SUMITITE (B3), +BV 103 A-4727-239-A MB BOARD, COMPLETE (AEP, UK) 103 A-4727-244-A MB BOARD, COMPLETE (AUS) 103 A-4727-246-A MB BOARD, COMPLETE (E, MX)

103 A-4727-248-A MB BOARD, COMPLETE (EA) 103 A-4727-252-A MB BOARD, COMPLETE (KR, SP, TH) 104 1-823-608-11 WIRE (FLAT TYPE) (10 CORE) 105 A-4727-237-A MAIN BOARD, COMPLETE 106 A-4727-238-A VIDEO BOARD, COMPLETE

107 1-823-607-11 WIRE (FLAT TYPE) (8 CORE) 108 1-757-633-11 CORD (WITH CONNECTOR) 17P

Ref. No. Part No. Description Remark

109 4-236-808-01 PANEL (DVD), BACK (AEP) 109 4-236-808-11 PANEL (DVD), BACK (UK) 109 4-236-808-31 PANEL (DVD), BACK (KR) 109 4-236-808-41 PANEL (DVD), BACK (SP) 109 4-236-808-51 PANEL (DVD), BACK (EA)

109 4-236-808-61 PANEL (DVD), BACK (AUS) 109 4-236-808-71 PANEL (DVD), BACK (TH) 109 4-236-808-81 PANEL (DVD), BACK (E) 109 4-236-808-91 PANEL (DVD), BACK (MX) 110 1-823-611-11 WIRE (FLAT TYPE) (9 CORE)

#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S

Page 60

DVP-S9

Ver 1.3

7-4. CD MECHANISM DECK SECTION-1

(CDM63D)

501

not supplied

505

504

501

508

not supplied

501

506

501

507

not supplie

506

509

510

513

501

503

502

511

CD mechanism deck section-2

Ref. No. Part No. Description Remark

501 4-218-253-01 SCREW (M2.6), +BTTP 502 4-228-996-01 SPRING (R), TORSION 503 4-228-995-01 SPRING (L), TORSION 504 4-228-972-02 TRAY (MAIN) 505 4-228-975-02 COVER (TRAY.L)

506 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING 507 4-234-121-01 PULLEY (A) (DVD), CHUCKING

512

Ref. No. Part No. Description Remark

508 4-228-986-02 RACK (TRAY.L) 509 4-231-858-01 PULLEY (B.DVD) 510 4-228-978-02 COVER (TRAY.R) 511 4-228-990-03 LEVER (SUB.L) 512 4-228-991-03 LEVER (SUB.R)

513 4-228-987-02 RACK (TRAY.R)

Page 61

7-5. CD MECHANISM DECK SECTION-2

(CDM63D)

DVP-S9

Ver 1.4

551

553

552

551

555

554

551

556

557

558

551

not supplied

556

559

551

560

561

551

not supplied

562

CD mechanism deck section-3

Ref. No. Part No. Description Remark

551 4-218-253-01 SCREW (M2.6), +BTTP 552 4-228-970-22 TRAY (SUB) 553 4-228-970-12 TRAY (SUB) 554 4-228-970-02 TRAY (SUB) 555 4-228-963-01 SLIDER (STOCKER.L)

556 4-228-981-02 STOPPER (TRAY)

551

not supplied

551

Ref. No. Part No. Description Remark

557 4-234-423-01 SPRING (STOCKER L), LEAF 558 4-228-980-01 SPRING (STOCKER), LEAF 559 4-228-964-01 SLIDER (STOCKER.R) 560 4-229-001-01 HOLDER (SENSOR) 561 1-678-457-11 TRAY SENSOR BOARD

562 4-228-993-05 SLIDER (LOADING)

Page 62

DVP-S9

7-6. CD MECHANISM DECK SECTION-3

(CDM63D)

609

610

608

605

607

not supplied

601

605

604

optical pick-up section

606

605

604

CD mechanism deck section-4

603

605

602

601

614

611

not supplied

612

613

not supplied

615

616

617

606

Ref. No. Part No. Description Remark

601 4-218-253-71 SCREW (M2.6), +BTTP 602 4-229-000-02 LEVER (MAIN.R) 603 4-228-999-02 LEVER (MAIN.L) 604 4-228-969-02 SPRING (TABLE), LEAF

605 4-218-253-01 SCREW (M2.6), +BTTP 606 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING 607 4-228-977-01 SLIDER (BU.L) 608 1-678-463-11 DISK SENSOR BOARD 609 4-231-520-01 HOLDER (BU DVD)

Ref. No. Part No. Description Remark

610 4-228-968-01 BELT 611 4-218-254-21 SCREW (M2.6), +PTPWH 612 4-229-003-01 PULLEY 613 4-228-997-02 GEAR (CAM) 614 4-228-985-01 GEAR (PULLEY)

615 4-228-976-01 SLIDER (BU.R) 616 1-678-460-11 DRIVER BOARD 617 4-218-253-61 SCREW (M2.6), +BTTP

Page 63

7-7. CD MECHANISM DECK SECTION-4

(CDM63D)

DVP-S9

656

652

657

654

658

651

655

653

659

M721

651

653

651

Ref. No. Part No. Description Remark

651 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING 652 4-229-002-02 GEAR (SLIDER) 653 4-218-254-21 SCREW (M2.6), +PTPWH 654 4-228-971-01 CAM 655 4-228-974-02 RACK (CENTER)

656 4-228-988-01 CHASSIS

661

652

651

Ref. No. Part No. Description Remark

657 4-218-253-01 SCREW (M2.6), +BTTP 658 1-678-462-11 IN OUT SW BOARD 659 4-228-998-01 GEAR (DETECTION) 661 1-678-461-11 MOTOR BOARD M721 X-4952-971-2 MOTOR ASSY (LOADING)

657

Page 64

DVP-S9

Ver 1.5

7-8. OPTICAL PICK-UP SECTION

• Refer to servicing notes (page 4) for discrimination of TYPE A/B.

704

705

704

706

707

704

708

703

701

Ref. No. Part No. Description Remark

701 A-4727-278-A RF BOARD, COMPLETE 703 1-823-610-11 WIRE (FLAT TYPE) (26 CORE) 704 3-053-847-01 INSULATOR 705 4-981-923-01 SCREW (M), STEP

0 706 8-820-144-06 OPTICAL PICK-UP KHM-240AAA/J1RP

(TYPE A)

709

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

Ref. No. Part No. Description Remark

0 706 A-6062-709-A SERVICE ASSY, KHM-270AAA (TYPE B)

707 4-236-450-01 SCREW (L), STEP 708 4-236-467-01 BASE (DVD), FITTING 709 4-951-620-01 SCREW (2.6X8), BVTP

Page 65

DVP-S9

SECTION 8

Ver 1.5

ELECTRICAL PARTS LIST DISC SENSOR

DRIVER IN OUT SW MAIN

NOTE:

• Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set.

• -XX and -X mean standardized parts, so they may have some difference from the original one.

• RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable

• Refer to servicing notes (page 4) for discrimination of TYPE A/B.

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

1-678-463-11 DISC SENSOR BOARD

******************

< PHOTO REFLECTOR >

IC751 8-749-924-30 PHOTO REFLECTOR GP2S28

< RESISTOR >

R751 1-249-407-11 CARBON 150 5% 1/4W

**************************************************************

1-678-460-11 DRIVER BOARD

*************

< CAPACITOR >

C701 1-124-261-00 ELECT 10uF 20% 50V C705 1-124-261-00 ELECT 10uF 20% 50V C706 1-164-159-11 CERAMIC 0.1uF 50V C707 1-164-159-11 CERAMIC 0.1uF 50V

< CONNECTOR >

CN701 1-785-324-11 PIN, CONNECTOR (STRAIGHT) 12P CN702 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P CN703 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P CN704 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P CN705 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P

< IC >

IC701 8-759-598-69 IC BA6956AN

< TRANSISTOR >

Q701 8-729-029-66 TRANSISTOR RT1N141S-TP

< RESISTOR >

R701 1-249-429-11 CARBON 10K 5% 1/4W R702 1-249-401-11 CARBON 47 5% 1/4W R705 1-249-435-11 CARBON 33K 5% 1/4W R706 1-249-417-11 CARBON 1K 5% 1/4W R707 1-249-429-11 CARBON 10K 5% 1/4W

**************************************************************

• Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

• SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. .

• CAPACITORS uF: µF

• COILS uH: µH

(DISC IN DETECT)

•Abbreviation AUS: Australian model EA : Saudi Arabia model KR : Korean model

1-678-462-11 IN OUT SW BOARD

S741 1-771-821-11 SWITCH, PUSH (1 KEY) (IN) S742 1-771-821-11 SWITCH, PUSH (1 KEY) (OUT)

**************************************************************

A-4727-237-A MAIN BOARD, COMPLETE

C101 1-164-159-11 CERAMIC 0.1uF 50V C102 1-164-159-11 CERAMIC 0.1uF 50V C401 1-126-934-11 ELECT 220uF 20% 10V C402 1-126-934-11 ELECT 220uF 20% 10V C403 1-164-159-11 CERAMIC 0.1uF 50V

C404 1-164-159-11 CERAMIC 0.1uF 50V C405 1-164-159-11 CERAMIC 0.1uF 50V C406 1-126-934-11 ELECT 220uF 20% 10V C407 1-126-934-11 ELECT 220uF 20% 10V C408 1-164-159-11 CERAMIC 0.1uF 50V

C411 1-164-159-11 CERAMIC 0.1uF 50V C425 1-162-282-31 CERAMIC 100PF 10% 50V C427 1-162-282-31 CERAMIC 100PF 10% 50V C500 1-164-159-11 CERAMIC 0.1uF 50V C501 1-126-768-11 ELECT 2200uF 20% 16V

C502 1-126-935-11 ELECT 470uF 20% 10V C504 1-164-159-11 CERAMIC 0.1uF 50V C505 1-164-159-11 CERAMIC 0.1uF 50V C506 1-164-159-11 CERAMIC 0.1uF 50V C507 1-164-159-11 CERAMIC 0.1uF 50V

C508 1-126-964-11 ELECT 10uF 20% 50V C509 1-126-935-11 ELECT 470uF 20% 10V C512 1-164-159-11 CERAMIC 0.1uF 50V C513 1-126-935-11 ELECT 470uF 20% 10V C514 1-126-947-11 ELECT 47uF 20% 10V

C557 1-164-159-11 CERAMIC 0.1uF 50V

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

When indicating parts by reference number, please include the board.

MX : Mexican model SP : Singapore model TH : Thai model

****************

< SWITCH >

*********************

< CAPACITOR >

< CONNECTOR >

* CN101 1-568-419-11 PIN, CONNECTOR 9P

CN102 1-568-373-11 PIN, CONNECTOR 8P CN103 1-566-859-11 SOCKET, CONNECTOR 15P

(SYSTEM CONTROL 5 FROM TC-S9)

Page 66

DVP-S9

MAIN MB

Ref. No. Part No. Description Remark

CN107 1-779-278-11 CONNECTOR, FFC (LIF (NON-ZIF)) 10P

* CN401 1-568-936-11 PIN, CONNECTOR 9P

CN501 1-506-469-11 PIN, CONNECTOR 4P

* CN503 1-568-937-11 PIN, CONNECTOR 10P

< DIODE >

D105 8-719-911-19 DIODE 1SS133T-72 D501 8-719-024-99 DIODE 11ES2-NTA2B D502 8-719-024-99 DIODE 11ES2-NTA2B D503 8-719-024-99 DIODE 11ES2-NTA2B D504 8-719-024-99 DIODE 11ES2-NTA2B

D505 8-719-911-19 DIODE 1SS133T-72 D512 8-719-024-99 DIODE 11ES2-NTA2B D513 8-719-024-99 DIODE 11ES2-NTA2B D514 8-719-024-99 DIODE 11ES2-NTA2B

< FERRITE BEAD >

FB501 1-412-473-21 FERRITE BEAD FB502 1-412-473-21 FERRITE BEAD FB503 1-412-473-21 FERRITE BEAD

< IC >

IC401 6-800-720-01 IC M30622MAA-B33FP IC501 8-759-071-48 IC TA7807S IC502 8-759-604-35 IC M5F78M05L

< CONNECTOR >

* NO104 1-568-936-11 PIN, CONNECTOR 9P

< RESISTOR >

R101 1-247-807-31 CARBON 100 5% 1/4W R102 1-247-807-31 CARBON 100 5% 1/4W R103 1-249-417-11 CARBON 1K 5% 1/4W R104 1-247-807-31 CARBON 100 5% 1/4W R132 1-247-876-11 CARBON 75K 5% 1/4W

R133 1-247-876-11 CARBON 75K 5% 1/4W R134 1-249-417-11 CARBON 1K 5% 1/4W R409 1-249-429-11 CARBON 10K 5% 1/4W R411 1-249-409-11 CARBON 220 5% 1/4W R412 1-249-425-11 CARBON 4.7K 5% 1/4W

R413 1-249-411-11 CARBON 330 5% 1/4W R417 1-249-429-11 CARBON 10K 5% 1/4W R419 1-249-409-11 CARBON 220 5% 1/4W R425 1-249-425-11 CARBON 4.7K 5% 1/4W R427 1-249-425-11 CARBON 4.7K 5% 1/4W

R429 1-247-807-31 CARBON 100 5% 1/4W R430 1-247-807-31 CARBON 100 5% 1/4W R431 1-249-409-11 CARBON 220 5% 1/4W R432 1-249-409-11 CARBON 220 5% 1/4W R433 1-249-409-11 CARBON 220 5% 1/4W

R434 1-249-409-11 CARBON 220 5% 1/4W R435 1-249-409-11 CARBON 220 5% 1/4W R436 1-249-409-11 CARBON 220 5% 1/4W R437 1-249-409-11 CARBON 220 5% 1/4W R440 1-249-409-11 CARBON 220 5% 1/4W

R441 1-249-429-11 CARBON 10K 5% 1/4W R442 1-249-409-11 CARBON 220 5% 1/4W

Ref. No. Part No. Description Remark

R443 1-249-409-11 CARBON 220 5% 1/4W R444 1-249-409-11 CARBON 220 5% 1/4W R447 1-249-409-11 CARBON 220 5% 1/4W

R448 1-249-409-11 CARBON 220 5% 1/4W R451 1-249-429-11 CARBON 10K 5% 1/4W R453 1-249-409-11 CARBON 220 5% 1/4W R454 1-249-429-11 CARBON 10K 5% 1/4W R455 1-249-409-11 CARBON 220 5% 1/4W

R456 1-249-429-11 CARBON 10K 5% 1/4W R457 1-249-429-11 CARBON 10K 5% 1/4W R459 1-249-409-11 CARBON 220 5% 1/4W R465 1-249-407-11 CARBON 150 5% 1/4W R469 1-249-407-11 CARBON 150 5% 1/4W

R473 1-249-407-11 CARBON 150 5% 1/4W R477 1-249-407-11 CARBON 150 5% 1/4W R480 1-249-441-11 CARBON 100K 5% 1/4W R481 1-249-407-11 CARBON 150 5% 1/4W R482 1-249-429-11 CARBON 10K 5% 1/4W

R483 1-249-429-11 CARBON 10K 5% 1/4W R484 1-249-409-11 CARBON 220 5% 1/4W R485 1-249-409-11 CARBON 220 5% 1/4W R486 1-249-409-11 CARBON 220 5% 1/4W R487 1-249-409-11 CARBON 220 5% 1/4W

R488 1-249-409-11 CARBON 220 5% 1/4W R489 1-249-409-11 CARBON 220 5% 1/4W R490 1-249-409-11 CARBON 220 5% 1/4W R491 1-249-409-11 CARBON 220 5% 1/4W R492 1-249-425-11 CARBON 4.7K 5% 1/4W

R493 1-249-415-11 CARBON 680 5% 1/4W R494 1-247-807-31 CARBON 100 5% 1/4W R495 1-249-410-11 CARBON 270 5% 1/4W R496 1-249-429-11 CARBON 10K 5% 1/4W R497 1-249-410-11 CARBON 270 5% 1/4W

R567 1-249-441-11 CARBON 100K 5% 1/4W

< VIBRATOR >

X401 1-781-107-21 VIBRATOR, CERAMIC (16MHz)

**************************************************************

A-4727-239-A MB BOARD, COMPLETE (AEP, UK) A-4727-244-A MB BOARD, COMPLETE (AUS) A-4727-246-A MB BOARD, COMPLETE (E, MX) A-4727-248-A MB BOARD, COMPLETE (EA) A-4727-252-A MB BOARD, COMPLETE (KR, SP, TH)

********************

< CAPACITOR >

C004 1-126-204-11 ELECT CHIP 47uF 20% 16V C005 1-126-246-11 ELECT CHIP 220uF 20% 4V C006 1-126-204-11 ELECT CHIP 47uF 20% 16V C007 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C104 1-126-209-11 ELECT CHIP 100uF 20% 4V C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C107 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V

Page 67

DVP-S9

Ref. No. Part No. Description Remark

C108 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C109 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C110 1-126-209-11 ELECT CHIP 100uF 20% 4V C111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C114 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C116 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C124 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C204 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C205 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C206 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C304 1-126-246-11 ELECT CHIP 220uF 20% 4V C305 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C306 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C307 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C309 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C310 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C311 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V

C312 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C313 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C315 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C317 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C318 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C319 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V C320 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C321 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C322 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C326 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C327 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C328 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C331 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C333 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C334 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C335 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C336 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C337 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C338 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C339 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C340 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C341 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C342 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C343 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C344 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C345 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C346 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C347 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C348 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C349 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

Ref. No. Part No. Description Remark

C350 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C351 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C352 1-126-204-11 ELECT CHIP 47uF 20% 16V C401 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V C402 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C403 1-162-927-11 CERAMIC CHIP 100PF 5% 50V

C404 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V C405 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C406 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C407 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C408 1-162-927-11 CERAMIC CHIP 100PF 5% 50V

C411 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C412 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C413 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C414 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C417 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C419 1-126-204-11 ELECT CHIP 47uF 20% 16V C420 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C429 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C430 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C501 1-126-193-11 ELECT 1uF 20% 50V C502 1-117-370-11 CERAMIC CHIP 10uF 10V C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C505 1-117-370-11 CERAMIC CHIP 10uF 10V C506 1-117-370-11 CERAMIC CHIP 10uF 10V C508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C511 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C512 1-126-246-11 ELECT CHIP 220uF 20% 4V C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C514 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C516 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C519 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C520 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C521 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C522 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C523 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C524 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C525 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C526 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C529 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C530 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C531 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C532 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C533 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C534 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C535 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C536 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C537 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C538 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C539 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

Page 68

DVP-S9

Ver 1.5

Ref. No. Part No. Description Remark

C540 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C541 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C542 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C545 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C546 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C547 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C701 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C711 1-162-918-11 CERAMIC CHIP 18PF 5% 50V

C712 1-162-921-11 CERAMIC CHIP 33PF 5% 50V C716 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C717 1-162-921-11 CERAMIC CHIP 33PF 5% 50V C721 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C722 1-162-921-11 CERAMIC CHIP 33PF 5% 50V

C741 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C742 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C743 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C744 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C745 1-124-778-00 ELECT CHIP 22uF 20% 6.3V

C764 1-126-193-11 ELECT 1uF 20% 50V C765 1-126-193-11 ELECT 1uF 20% 50V C766 1-126-193-11 ELECT 1uF 20% 50V

< CONNECTOR >

CN008 1-779-992-11 PIN, CONNECTOR (PWB) 8P CN010 1-784-875-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P CN012 1-784-860-21 CONNECTOR, FFC (LIF (NON-ZIF)) 8P CN015 1-784-368-11 CONNECTOR, FFC/FPC 9P CN101 1-784-369-21 CONNECTOR, FFC/FPC 10P

CN103 1-793-687-11 PIN, CONNECTOR (1.5mm) (SMD) 5P

* CN203 1-764-007-11 PIN, CONNECTOR (SMD) 12P

CN404 1-793-687-11 PIN, CONNECTOR (1.5mm) (SMD) 5P

< FERRITE BEAD/RESISTOR >

FB007 1-469-324-21 FERRITE BEAD FB008 1-469-324-21 FERRITE BEAD FB009 1-469-324-21 FERRITE BEAD FB010 1-469-324-21 FERRITE BEAD FB011 1-469-324-21 FERRITE BEAD

Ref. No. Part No. Description Remark

< IC >

IC006 6-700-398-01 IC uPC2918T-E1 IC101 8-759-640-41 IC BR24C08F-E2 IC102 8-759-831-81 IC IMIC6001BTD IC103 8-759-829-75 IC MB91307APFV-G-BND-E1 IC106 8-759-645-76 IC TC74VHCT32AFT

IC107 8-759-826-41 IC MBM29DL324BE-90PFTN IC202 6-700-740-01 IC LC22004A-RJ6-TBM-E IC301 8-759-599-45 IC MM1385ENLE IC302 8-759-828-01 IC CXD9635R IC303 8-759-683-75 IC MSM51V18160F-60TSKR1

IC401 8-759-826-42 IC FAN8034 IC501 8-759-832-30 IC TK71518ASCL IC502 8-759-599-45 IC MM1385ENLE IC503 8-752-399-55 IC CXD1933Q IC504 8-759-663-74 IC HY57V161610DTC-7TR

IC505 8-759-663-74 IC HY57V161610DTC-7TR IC701 8-759-680-28 IC BA7666FS-E2

< COIL >

L701 1-412-788-41 INDUCTOR 10uH L711 1-412-790-31 INDUCTOR 15uH L713 1-412-790-31 INDUCTOR 15uH L715 1-412-790-31 INDUCTOR 15uH

< TRANSISTOR >

Q711 8-729-027-23 TRANSISTOR DTA114EKA-T146 Q712 1-801-806-11 TRANSISTOR DTC144EKA-T146

< RESISTOR >

R017 1-216-864-11 METAL CHIP 0 5% 1/16W R021 1-216-864-11 METAL CHIP 0 5% 1/16W R076 1-216-837-11 METAL CHIP 22K 5% 1/16W

(TYPE A)

R077 1-216-815-11 METAL CHIP 330 5% 1/16W

(TYPE A)

R077 1-216-833-11 METAL CHIP 10K 5% 1/16W

(TYPE B)

FB012 1-469-324-21 FERRITE BEAD FB112 1-216-864-11 METAL CHIP 0 5% 1/16W FB711 1-216-864-11 METAL CHIP 0 5% 1/16W FB712 1-216-864-11 METAL CHIP 0 5% 1/16W FB714 1-216-864-11 METAL CHIP 0 5% 1/16W

< EMI FILTER >

FL003 1-234-177-21 FILTER, CHIP EMI FL004 1-234-177-21 FILTER, CHIP EMI FL005 1-233-893-21 FILTER, CHIP EMI FL101 1-233-893-21 FILTER, CHIP EMI FL102 1-233-893-21 FILTER, CHIP EMI

FL103 1-233-893-21 FILTER, CHIP EMI FL202 1-233-893-21 FILTER, CHIP EMI FL203 1-233-893-21 FILTER, CHIP EMI FL204 1-234-177-21 FILTER, CHIP EMI FL501 1-233-893-21 FILTER, CHIP EMI

FL502 1-233-893-21 FILTER, CHIP EMI FL505 1-234-177-21 FILTER, CHIP EMI

R078 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R080 1-216-801-11 METAL CHIP 22 5% 1/16W R101 1-216-789-11 METAL CHIP 2.2 5% 1/16W R105 1-216-833-11 METAL CHIP 10K 5% 1/16W R106 1-216-833-11 METAL CHIP 10K 5% 1/16W

R107 1-216-821-11 METAL CHIP 1K 5% 1/16W R109 1-216-797-11 METAL CHIP 10 5% 1/16W R111 1-216-817-11 METAL CHIP 470 5% 1/16W R112 1-216-821-11 METAL CHIP 1K 5% 1/16W R113 1-216-833-11 METAL CHIP 10K 5% 1/16W

R114 1-216-845-11 METAL CHIP 100K 5% 1/16W R116 1-216-833-11 METAL CHIP 10K 5% 1/16W R117 1-216-821-11 METAL CHIP 1K 5% 1/16W R118 1-216-821-11 METAL CHIP 1K 5% 1/16W R119 1-216-833-11 METAL CHIP 10K 5% 1/16W

R121 1-216-833-11 METAL CHIP 10K 5% 1/16W R123 1-216-833-11 METAL CHIP 10K 5% 1/16W R124 1-216-797-11 METAL CHIP 10 5% 1/16W R125 1-216-797-11 METAL CHIP 10 5% 1/16W

Page 69

DVP-S9

Ref. No. Part No. Description Remark

R126 1-216-797-11 METAL CHIP 10 5% 1/16W

R128 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R129 1-216-833-11 METAL CHIP 10K 5% 1/16W R130 1-216-833-11 METAL CHIP 10K 5% 1/16W R131 1-216-833-11 METAL CHIP 10K 5% 1/16W R132 1-216-833-11 METAL CHIP 10K 5% 1/16W

R133 1-216-833-11 METAL CHIP 10K 5% 1/16W R134 1-216-833-11 METAL CHIP 10K 5% 1/16W R136 1-216-797-11 METAL CHIP 10 5% 1/16W R137 1-216-797-11 METAL CHIP 10 5% 1/16W R138 1-216-797-11 METAL CHIP 10 5% 1/16W

R140 1-216-797-11 METAL CHIP 10 5% 1/16W R141 1-216-797-11 METAL CHIP 10 5% 1/16W R142 1-216-797-11 METAL CHIP 10 5% 1/16W R143 1-216-833-11 METAL CHIP 10K 5% 1/16W R145 1-216-833-11 METAL CHIP 10K 5% 1/16W

R146 1-216-833-11 METAL CHIP 10K 5% 1/16W R147 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R149 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R150 1-216-821-11 METAL CHIP 1K 5% 1/16W

(EA)

R150 1-216-827-11 METAL CHIP 3.3K 5% 1/16W

(AUS)

R150 1-216-831-11 METAL CHIP 6.8K 5% 1/16W

(KR, SP, TH)

R150 1-216-835-11 METAL CHIP 15K 5% 1/16W

(AEP, UK)

R150 1-216-839-11 METAL CHIP 33K 5% 1/16W

(E, MX) R151 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R152 1-216-833-11 METAL CHIP 10K 5% 1/16W

Ref. No. Part No. Description Remark

R186 1-216-833-11 METAL CHIP 10K 5% 1/16W R187 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R188 1-216-833-11 METAL CHIP 10K 5% 1/16W R199 1-216-826-11 METAL CHIP 2.7K 5% 1/16W R202 1-216-809-11 METAL CHIP 100 5% 1/16W

R203 1-216-821-11 METAL CHIP 1K 5% 1/16W R206 1-216-813-11 METAL CHIP 220 5% 1/16W R207 1-216-813-11 METAL CHIP 220 5% 1/16W R208 1-216-821-11 METAL CHIP 1K 5% 1/16W R209 1-216-821-11 METAL CHIP 1K 5% 1/16W

R210 1-216-821-11 METAL CHIP 1K 5% 1/16W R211 1-216-821-11 METAL CHIP 1K 5% 1/16W R212 1-216-821-11 METAL CHIP 1K 5% 1/16W R214 1-216-833-11 METAL CHIP 10K 5% 1/16W R215 1-216-833-11 METAL CHIP 10K 5% 1/16W

R299 1-216-847-11 METAL CHIP 150K 5% 1/16W R301 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R302 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R305 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R306 1-216-829-11 METAL CHIP 4.7K 5% 1/16W

R307 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R308 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R309 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R310 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R311 1-216-829-11 METAL CHIP 4.7K 5% 1/16W

R312 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R313 1-216-817-11 METAL CHIP 470 5% 1/16W R314 1-216-817-11 METAL CHIP 470 5% 1/16W R315 1-216-817-11 METAL CHIP 470 5% 1/16W R316 1-216-829-11 METAL CHIP 4.7K 5% 1/16W

R153 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R154 1-216-835-11 METAL CHIP 15K 5% 1/16W

(AUS, E, MX)

R154 1-216-839-11 METAL CHIP 33K 5% 1/16W

(KR, SP, TH)

R154 1-216-843-11 METAL CHIP 68K 5% 1/16W

(AEP, EA, UK)

R155 1-216-829-11 METAL CHIP 4.7K 5% 1/16W

R156 1-216-833-11 METAL CHIP 10K 5% 1/16W R157 1-216-864-11 METAL CHIP 0 5% 1/16W R160 1-216-833-11 METAL CHIP 10K 5% 1/16W R161 1-216-864-11 METAL CHIP 0 5% 1/16W R162 1-216-833-11 METAL CHIP 10K 5% 1/16W

R163 1-216-833-11 METAL CHIP 10K 5% 1/16W R164 1-216-809-11 METAL CHIP 100 5% 1/16W R165 1-216-809-11 METAL CHIP 100 5% 1/16W R166 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R167 1-216-821-11 METAL CHIP 1K 5% 1/16W

R168 1-216-821-11 METAL CHIP 1K 5% 1/16W R170 1-216-821-11 METAL CHIP 1K 5% 1/16W R172 1-216-833-11 METAL CHIP 10K 5% 1/16W R174 1-216-797-11 METAL CHIP 10 5% 1/16W R175 1-216-864-11 METAL CHIP 0 5% 1/16W

R179 1-216-833-11 METAL CHIP 10K 5% 1/16W R182 1-216-845-11 METAL CHIP 100K 5% 1/16W R183 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R184 1-216-833-11 METAL CHIP 10K 5% 1/16W R185 1-216-833-11 METAL CHIP 10K 5% 1/16W

R317 1-216-833-11 METAL CHIP 10K 5% 1/16W R318 1-216-864-11 METAL CHIP 0 5% 1/16W R319 1-216-831-11 METAL CHIP 6.8K 5% 1/16W R320 1-216-864-11 METAL CHIP 0 5% 1/16W R321 1-216-817-11 METAL CHIP 470 5% 1/16W

R328 1-216-833-11 METAL CHIP 10K 5% 1/16W R329 1-216-864-11 METAL CHIP 0 5% 1/16W R330 1-216-864-11 METAL CHIP 0 5% 1/16W R332 1-216-864-11 METAL CHIP 0 5% 1/16W R334 1-218-871-11 METAL CHIP 10K 0.5% 1/10W

R335 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R336 1-216-833-11 METAL CHIP 10K 5% 1/16W R337 1-216-809-11 METAL CHIP 100 5% 1/16W R338 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R341 1-218-871-11 METAL CHIP 10K 0.5% 1/10W

R342 1-218-883-11 METAL CHIP 33K 0.5% 1/10W R343 1-218-831-11 METAL CHIP 220 0.5% 1/10W R344 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R345 1-216-833-11 METAL CHIP 10K 5% 1/16W R349 1-216-838-11 METAL CHIP 27K 5% 1/16W

R350 1-216-822-11 METAL CHIP 1.2K 5% 1/16W R351 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R352 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R356 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W R368 1-216-829-11 METAL CHIP 4.7K 5% 1/16W

R384 1-216-797-11 METAL CHIP 10 5% 1/16W R385 1-216-829-11 METAL CHIP 4.7K 5% 1/16W

Page 70

DVP-S9

MB MOTOR PANEL

Ref. No. Part No. Description Remark

R406 1-216-846-11 METAL CHIP 120K 5% 1/16W R407 1-216-846-11 METAL CHIP 120K 5% 1/16W R408 1-216-847-11 METAL CHIP 150K 5% 1/16W

R409 1-216-847-11 METAL CHIP 150K 5% 1/16W R410 1-216-842-11 METAL CHIP 56K 5% 1/16W R411 1-216-842-11 METAL CHIP 56K 5% 1/16W R412 1-216-850-11 METAL CHIP 270K 5% 1/16W R413 1-216-833-11 METAL CHIP 10K 5% 1/16W

R414 1-216-853-11 METAL CHIP 470K 5% 1/16W R415 1-216-846-11 METAL CHIP 120K 5% 1/16W R416 1-216-855-11 METAL CHIP 680K 5% 1/16W R417 1-216-833-11 METAL CHIP 10K 5% 1/16W R418 1-216-839-11 METAL CHIP 33K 5% 1/16W

R419 1-216-839-11 METAL CHIP 33K 5% 1/16W R420 1-216-853-11 METAL CHIP 470K 5% 1/16W R421 1-216-839-11 METAL CHIP 33K 5% 1/16W R422 1-216-839-11 METAL CHIP 33K 5% 1/16W R423 1-216-839-11 METAL CHIP 33K 5% 1/16W

R424 1-216-839-11 METAL CHIP 33K 5% 1/16W R425 1-216-849-11 METAL CHIP 220K 5% 1/16W R426 1-216-853-11 METAL CHIP 470K 5% 1/16W R427 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R428 1-216-839-11 METAL CHIP 33K 5% 1/16W

Ref. No. Part No. Description Remark

R725 1-216-833-11 METAL CHIP 10K 5% 1/16W R737 1-216-864-11 METAL CHIP 0 5% 1/16W R738 1-216-864-11 METAL CHIP 0 5% 1/16W R739 1-216-864-11 METAL CHIP 0 5% 1/16W R740 1-216-864-11 METAL CHIP 0 5% 1/16W

< VARIABLE RESISTOR >

RV501 1-223-583-11 RES, ADJ, CARBON 1K

< VIBRATOR >

X101 1-795-174-11 VIBRATOR, CERAMIC (16.5MHz) X102 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)

**************************************************************

1-678-461-11 MOTOR BOARD

*************

< CAPACITOR >

C721 1-162-306-11 CERAMIC 0.01uF 30% 16V

**************************************************************

1-682-812-11 PANEL BOARD

************

R429 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R430 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R431 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R432 1-216-833-11 METAL CHIP 10K 5% 1/16W R433 1-216-833-11 METAL CHIP 10K 5% 1/16W

R434 1-216-815-11 METAL CHIP 330 5% 1/16W R435 1-216-833-11 METAL CHIP 10K 5% 1/16W R439 1-216-864-11 METAL CHIP 0 5% 1/16W R507 1-216-809-11 METAL CHIP 100 5% 1/16W R508 1-216-864-11 METAL CHIP 0 5% 1/16W

R509 1-216-864-11 METAL CHIP 0 5% 1/16W R510 1-216-833-11 METAL CHIP 10K 5% 1/16W R511 1-216-813-11 METAL CHIP 220 5% 1/16W R512 1-216-813-11 METAL CHIP 220 5% 1/16W R513 1-216-813-11 METAL CHIP 220 5% 1/16W

R514 1-216-813-11 METAL CHIP 220 5% 1/16W R515 1-216-813-11 METAL CHIP 220 5% 1/16W R516 1-216-813-11 METAL CHIP 220 5% 1/16W R517 1-216-833-11 METAL CHIP 10K 5% 1/16W R518 1-216-822-11 METAL CHIP 1.2K 5% 1/16W

R521 1-216-864-11 METAL CHIP 0 5% 1/16W R522 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R524 1-216-833-11 METAL CHIP 10K 5% 1/16W R525 1-216-833-11 METAL CHIP 10K 5% 1/16W R532 1-216-833-11 METAL CHIP 10K 5% 1/16W

R533 1-216-797-11 METAL CHIP 10 5% 1/16W R554 1-216-797-11 METAL CHIP 10 5% 1/16W R701 1-216-833-11 METAL CHIP 10K 5% 1/16W R711 1-218-289-11 RES-CHIP 510 5% 1/16W R712 1-218-289-11 RES-CHIP 510 5% 1/16W

< DIODE >

D701 8-719-057-97 LED SEL5923A-TP15 (X) D702 8-719-058-03 LED SEL5423E-TP15 (N) D703 8-719-057-97 LED SEL5923A-TP15 (3 (DISC 3)) D704 8-719-057-97 LED SEL5923A-TP15 (2 (DISC 2)) D705 8-719-057-97 LED SEL5923A-TP15 (1 (DISC 1))

< RESISTOR >

R711 1-249-411-11 CARBON 330 5% 1/4W R712 1-249-413-11 CARBON 470 5% 1/4W R713 1-249-414-11 CARBON 560 5% 1/4W R714 1-249-415-11 CARBON 680 5% 1/4W R715 1-249-417-11 CARBON 1K 5% 1/4W

R716 1-249-418-11 CARBON 1.2K 5% 1/4W R717 1-249-420-11 CARBON 1.8K 5% 1/4W R718 1-249-422-11 CARBON 2.7K 5% 1/4W R719 1-247-843-11 CARBON 3.3K 5% 1/4W

< SWITCH >

S711 1-771-410-21 SWITCH, TACTILE (m) S712 1-771-410-21 SWITCH, TACTILE (M) S713 1-771-410-21 SWITCH, TACTILE (>) S714 1-771-410-21 SWITCH, TACTILE (.) S715 1-771-410-21 SWITCH, TACTILE (x)

S716 1-771-410-21 SWITCH, TACTILE (X) S717 1-771-410-21 SWITCH, TACTILE (N) S718 1-771-410-21 SWITCH, TACTILE (RETURN) S719 1-771-410-21 SWITCH, TACTILE (PREV) S720 1-771-410-21 SWITCH, TACTILE (NEXT)

**************************************************************

R713 1-218-289-11 RES-CHIP 510 5% 1/16W R717 1-218-285-11 RES-CHIP 75 5% 1/16W R718 1-218-285-11 RES-CHIP 75 5% 1/16W R719 1-218-285-11 RES-CHIP 75 5% 1/16W R724 1-216-833-11 METAL CHIP 10K 5% 1/16W

Page 71

DVP-S9

Ver 1.2

RF SUB PANEL TRAY SENSOR

Ref. No. Part No. Description Remark

A-4727-278-A RF BOARD, COMPLETE

********************

< CAPACITOR >

C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C005 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C006 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C007 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V

C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C009 1-124-779-00 ELECT CHIP 10uF 20% 16V C015 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C016 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C017 1-126-206-11 ELECT CHIP 100uF 20% 6.3V

C018 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C019 1-164-739-11 CERAMIC CHIP 560PF 5% 50V C021 1-124-779-00 ELECT CHIP 10uF 20% 16V C022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V

C024 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C027 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C028 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C033 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C034 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C036 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C038 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C040 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C044 1-124-779-00 ELECT CHIP 10uF 20% 16V C046 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C048 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

< CONNECTOR >

CN001 1-766-835-21 CONNECTOR, FFC/FPC (ZIF) 26P CN002 1-784-875-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P

< DIODE >

D001 8-719-988-61 DIODE 1SS355TE-17 D004 8-719-988-61 DIODE 1SS355TE-17

Ref. No. Part No. Description Remark

< RESISTOR >

R002 1-216-809-11 METAL CHIP 100 5% 1/16W R003 1-216-809-11 METAL CHIP 100 5% 1/16W R005 1-216-845-11 METAL CHIP 100K 5% 1/16W R006 1-216-838-11 METAL CHIP 27K 5% 1/16W R007 1-216-803-11 METAL CHIP 33 5% 1/16W

R008 1-216-803-11 METAL CHIP 33 5% 1/16W R009 1-216-821-11 METAL CHIP 1K 5% 1/16W R010 1-216-841-11 METAL CHIP 47K 5% 1/16W R011 1-216-809-11 METAL CHIP 100 5% 1/16W R020 1-216-803-11 METAL CHIP 33 5% 1/16W

R023 1-216-803-11 METAL CHIP 33 5% 1/16W R025 1-216-841-11 METAL CHIP 47K 5% 1/16W R029 1-216-809-11 METAL CHIP 100 5% 1/16W R037 1-216-834-11 METAL CHIP 12K 5% 1/16W R038 1-216-861-11 METAL CHIP 2.2M 5% 1/16W

R045 1-216-809-11 METAL CHIP 100 5% 1/16W

**************************************************************

1-682-814-11 SUB PANEL BOARD

*****************

R701 1-249-411-11 CARBON 330 5% 1/4W R702 1-249-413-11 CARBON 470 5% 1/4W R703 1-249-414-11 CARBON 560 5% 1/4W R704 1-249-415-11 CARBON 680 5% 1/4W R705 1-249-417-11 CARBON 1K 5% 1/4W

R706 1-249-418-11 CARBON 1.2K 5% 1/4W R707 1-249-420-11 CARBON 1.8K 5% 1/4W

< SWITCH >

S701 1-771-410-21 SWITCH, TACTILE (DISC 3) S702 1-771-410-21 SWITCH, TACTILE (DISC 2) S703 1-771-410-21 SWITCH, TACTILE (DISC 1) S704 1-771-410-21 SWITCH, TACTILE (Z (DISC 1)) S705 1-771-410-21 SWITCH, TACTILE (Z (DISC 2))

S706 1-771-410-21 SWITCH, TACTILE (Z (DISC 3)) S707 1-771-410-21 SWITCH, TACTILE (REPEAT) S708 1-771-410-21 SWITCH, TACTILE (PLAY MODE)

**************************************************************

1-678-457-11 TRAY SENSOR BOARD

*******************

< CAPACITOR >

C731 1-164-159-11 CERAMIC 0.1uF 50V

< IC >

IC001 8-759-828-02 IC SP3728AC

< COIL >

L001 1-412-031-11 INDUCTOR CHIP 47uH L002 1-412-031-11 INDUCTOR CHIP 47uH

< TRANSISTOR >

Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR

< PHOTO SENSOR >

IC731 8-749-016-76 PHOTO SENSOR RPI-321

(SUB TRAY 1 HEIGHT SENSOR)

IC732 8-749-016-76 PHOTO SENSOR RPI-321

(SUB TRAY 2 HEIGHT SENSOR)

IC733 8-749-016-76 PHOTO SENSOR RPI-321

(SUB TRAY 3 HEIGHT SENSOR)

< RESISTOR >

R731 1-247-876-11 CARBON 75K 5% 1/4W R732 1-249-408-11 CARBON 180 5% 1/4W

Page 72

DVP-S9

Ver 1.5

TRAY SENSOR VIDEO

Ref. No. Part No. Description Remark

R733 1-247-876-11 CARBON 75K 5% 1/4W R734 1-249-408-11 CARBON 180 5% 1/4W R735 1-247-876-11 CARBON 75K 5% 1/4W

R736 1-249-408-11 CARBON 180 5% 1/4W

**************************************************************

A-4727-238-A VIDEO BOARD, COMPLETE

**********************

< CAPACITOR >

C203 1-164-159-11 CERAMIC 0.1uF 50V C204 1-126-934-11 ELECT 220uF 20% 10V C206 1-164-159-11 CERAMIC 0.1uF 50V

< CONNECTOR >

CN201 1-779-276-11 CONNECTOR, FFC (LIF (NON-ZIF)) 8P CN202 1-568-951-11 PIN, CONNECTOR 2P

< FERRITE BEAD >

FB201 1-412-473-21 FERRITE BEAD FB202 1-412-473-21 FERRITE BEAD FB203 1-412-473-21 FERRITE BEAD FB204 1-412-473-21 FERRITE BEAD

Ref. No. Part No. Description Remark

< IC >

IC201 8-749-923-04 IC TOTX178A (OPTICAL OUT TO ST-S9)

< JACK >

J201 1-537-943-11 CONNECTOR (DIN) 1P (S VIDEO OUT) J202 1-794-970-11 JACK, PIN 1P (VIDEO OUT)

< COIL >

L201 1-410-525-11 INDUCTOR 220uH

**************************************************************

MISCELLANEOUS

**************

0 1 1-476-027-11 POWER BLOCK (AUS, EA, SP, TH) 0 1 1-476-028-11 POWER BLOCK (AEP, KR, UK) 0 1 1-476-029-11 POWER BLOCK (E, MX) 0 5 1-823-394-11 CORD, POWER (E, MX) 0 5 1-823-396-11 CORD, POWER (AEP, AUS, EA, SP, TH, UK)

0 5 1-823-399-11 CORD, POWER (KR)

101 1-823-609-11 WIRE (FLAT TYPE) (25 CORE) 104 1-823-608-11 WIRE (FLAT TYPE) (10 CORE) 107 1-823-607-11 WIRE (FLAT TYPE) (8 CORE) 108 1-757-633-11 CORD (WITH CONNECTOR) 17P

702 1-823-611-11 WIRE (FLAT TYPE) (9 CORE) 703 1-823-610-11 WIRE (FLAT TYPE) (26 CORE)

0 706 8-820-144-06 OPTICAL PICK-UP KHM-240AAA/J1RP

0 706 A-6062-709-A SERVICE ASSY, KHM-270AAA (TYPE B) 0 F1 1-532-388-31 MINIATURE FUSE-LINKS, TIME-LAG FUSE

(TYPE A)

(T2AL/250V)

M721 X-4952-971-2 MOTOR ASSY (LOADING)

The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified.

Sony DVP-S9 Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS

GENERAL

3-1. DISASSEMBLY FLOW

DISASSEMBLY

3-2. COVER

3-3. CD MECHANISM DECK (CDM63D)

3-4. MB BOARD

3-5. VIDEO BOARD

3-6. MAIN BOARD

3-7. FRONT PANEL SECTION

3-8. PANEL BOARD, SUB PANEL BOARD

3-9. LID (CD)

TEST MODE

ELECTRICAL ADJUSTMENTS

DIAGRAMS

6-1. BLOCK DIAGRAM – RF/SERVO Section – • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

6-2. BLOCK DIAGRAM – MAIN Section (1/2) –

6-3. BLOCK DIAGRAM – MAIN Section (2/2) –

6-4. BLOCK DIAGRAM – INTERFACE CONTROL Section –

6-5. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

6-7. SCHEMATIC DIAGRAM – RF Board – • See page 44 for Waveforms. • Refer to servicing notes (page 4) for discrimination of TYPE A/B.

6-8. PRINTED WIRING BOARDS – DISC SENSOR/DRIVER/IN OUT SW/MOTOR/TRAY SENSOR Boards – • See page 27 for Circuit Boards Location.

6-17. SCHEMATIC DIAGRAM – MB Board (6/6) –

6-20. PRINTED WIRING BOARDS – PANEL/SUB PANEL/VIDEO Boards – • See page 27 for Circuit Boards Location.

6-21. SCHEMATIC DIAGRAM – PANEL/SUB PANEL/VIDEO Boards –

6-22. IC PIN FUNCTION DESCRIPTION

EXPLODED VIEWS

7-1. CASE SECTION

7-2. FRONT PANEL SECTION

7-3. CHASSIS SECTION

7-8. OPTICAL PICK-UP SECTION

ELECTRICAL PARTS LIST DISC SENSOR
