Sony DVP-FX850 User Manual

Portable CD/DVD Player

Operating Instructions

3-100-247-11(2)

To find out useful hints, tips and

information about Sony products and services please visit: www.sony-europe.com/myproduct

DVP-FX850

WARNING

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. The mains lead must be changed only at a qualified service shop. Batteries or batteries installed apparatus shall not be exposed to excessive heat such as sunshine, fire or the like.

This label is located on the bottom of the unit.

This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the bottom of the unit.

CAUTION

• The use of optical instruments with this product will increase eye hazard. As the laser beam used in this CD/DVD player is harmful to eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only.

• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions.

Notice for customers in the United Kingdom and Republic of Ireland

A moulded plug complying with BS1363 is fitted to this equipment for your safety and convenience. Should the fuse in the plug supplied need to be replaced, a 5AMP fuse approved by ASTA or BSI to BS1362, (i.e., marked with

or mark) must be used.

If the plug supplied with this

equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.

Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Disposal of waste batteries (applicable in the European Union and other European countries with separate collection systems) This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste. By ensuring these batteries are disposed of correctly, you will help prevent potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural resources.

In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the product at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment.

For all other batteries, please view the section on how to remove the battery from the product safely. Hand the battery over to the applicable collection point for the recycling of waste batteries.

For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Precautions

Safety

• The power requirements of this unit are indicated on the AC adapter. Check that the unit’s operating voltage is identical with your local power supply.

• To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.

Installing

• Do not install the unit in an inclined position. It is designed to be operated in a horizontal position only.

• Keep the unit and discs away from equipment with strong magnet, such as microwave ovens, or large loudspeakers.

• Do not place heavy objects on the unit.

Notes About the Discs

• To keep the disc clean, handle the disc by its edge. Do n ot touch the surface.

• Do not expose the disc to direct sunlight or heat sources such as hot air ducts, or leave it in a car parked in direct sunlight as the temperature may rise considerably inside the car.

• After playing, store the disc in i ts case.

• Clean the disc with a cleaning cloth. Wipe the disc from the centre out.

• Do not use solvents such as benzine, thinner, disc/lens cleaners, or anti-static spray intended for vinyl LPs.

• If you have printed the disc’s label, dry the label before playing.

Precautions

Road safety

Do not use the monitor unit and headphones while driving, cycling, or operating any motorized vehicle. Doing so may create a traffic hazard and is illegal in some areas. It can also be potentially dangerous to play your headsets at high volume while walking, especially at pedestrian crossings. You should exercise extreme caution or discontinue use in potentially hazardous situations.

On safety

Should any solid object or liquid fall into the cabinet, unplug the player and have it checked by qualified personnel before operating it any further.

On power sources

• The player is not disconnected from the AC power source (mains) as long as it is connected to the wall outlet, even if the player itself has been turned off.

• If you are not going to use the player for a long time, be sure to disconnect the player from the wall outlet. To disconnect the AC power cord (mains lead), grasp the plug itself; never pull the cord.

• Do not touch the mains lead or the AC adaptor with wet hands. Doing so may cause shock hazard.

On temperature increases

Heat may build up inside the player during charging or if it is being used for a long time. This is not a malfunction.

On placement

• Place the player in a location with adequate ventilation to prevent heat build-up in the player.

• Do not place the player on a soft surface such as a rug that might block the ventilation holes.

• Do not place the player in a confined space such as a bookshelf or similar unit.

• To reduce the risk of fire, do not cover the ventilation of the apparatus with newspapers, tablecloths, curtains, etc.

• Do not place the player in a location near heat sources, or in a place subject to direct sunlight, excessive dust, sand, moisture, rain, or mechanical shock, or in a car with its windows closed.

On operation

• If the player is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lenses inside the player. Should this occur, the player may not operate properly. In this case, remove the disc and leave the player turned on for about half an hour until the moisture evaporates.

• When you move the player, take out any discs. If you do not, the disc may be damaged.

• Keep the lens on the player clean and do not touch it. Touching the lens may damage the lens and cause the player to malfunction. Leave the disc lid closed except when you insert or remove discs.

On Liquid Crystal Display

• Although manufactured with high precision technology, the LCD may occasionally display dots of various colours. That is not a malfunction.

• Do not wipe the LCD surface with wet cloth. If water enters, a malfunction may result.

• Do not place or drop any object onto the LCD surface. Also, do not apply pressure from hands or elbows.

• If the player is brought directly from a cold to a warm location, moisture may condense over the LCD surface. In which case, wipe out the moisture with tissue paper, etc., before use. However, moisture condensation will continue if the LCD surface is cold. Wait until the surface warms to room temperature.

On AC adaptor

Install this system so that the mains lead can be unplugged from the wall socket immediately in the event of trouble.

• Use the supplied AC adaptor for this player, as other adaptors may cause a malfunction.

• Do not confine the AC adaptor in a closed place such as a bookshelf or an AV cabinet.

,continued

• Do not connect the AC adaptor

to a traveler’s electric transformer, which may generate heat and cause a malfunction.

On battery pack

• Certain countries may regulate disposal of the battery used to power this product. Please consult with your local authority.

• Because of the battery’s limited life, its capacity gradually deteriorates over time and repeated use. Purchase a new one when the battery holds about only half the normal period.

• The battery may not be charged to its fullest capacity when charged for the first time, or when it has not been used for a long time. The capacity recovers after being charged and discharged several times.

• Do not leave the battery pack in a car or direct sunlight, where temperature goes up above 60 ºC.

• Do not expose to water.

• Avoid short-circuiting the battery connecting jacks (A) located on the bottom of the player and the connecting jacks (C) on the battery pack with metal objects such as a necklace.

• Make sure dust or sand does not enter the battery connecting jacks (A) and the guide holes (B) located on the bottom of the player, and the connecting jacks (C) and the guide holes (D) on the battery pack.

Bottom of the player B

Battery pack D

On car adapter

• Use the supplied car adaptor for this player, as other adaptors may cause a malfunction.

• Do not dissemble or reverseengineer.

• Do not drop or apply shock.

• Do not touch the metal parts, as it may cause a short and damage the car adaptor, especially if touched by other metal objects.

• Do not place the car adaptor in a location near heat sources, or in a place subject to direct sunlight or mechanical shock, or in a car with its windows closed.

On adjusting volume

Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speakers may be damaged when a peak level section is played.

On headphones

• Preventing hearing damage

Avoid using headphones at high volumes. Hearing experts advice against continuous, loud, and extended play. If you experience a ringing in your ears, reduce the volume or discontinue use.

• Showing consideration for

others

Keep the volume at a moderate level. This will allow you to hear outside sounds and still be considerate to the people around you.

On cleaning

Clean the cabinet, panel, and controls with a soft cloth slightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent such as alcohol or benzine.

On cleaning discs, disc/ lens cleaners

Do not use cleaning discs or disc/ lens cleaners (including wet or spray types). These may cause the apparatus to malfunction.

IMPORTANT NOTICE

Caution: This player is capable of holding a still video image or on-screen display image on your television screen indefinitely. If you leave the still vide o image or on-screen display image displayed on your TV for an extended period of time you risk permanent damage to your television screen. Plasma display panel televisions and projection televisions are susceptible to this.

If you have any questions or problems concerning your player, please consult your nearest Sony dealer.

Table of Contents

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Notes About the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

About This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

This Player Can Play the Following Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Checking the Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using the Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Using the LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting the AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Using with Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Using With the Car Battery Adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using the Playback Settings Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Searching for a Particular Point on a Disc (Search, Scan, Slow Play, Repeat

Play, Random Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Playing MP3 Audio Tracks or JPEG Image Files. . . . . . . . . . . . . . . . . . . . . . 25

Adjusting the Picture Size and Quality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Enjoying DivX® Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Playing DivX Video Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

About DivX Video Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using the Setup Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Settings for the Display (General Setup) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Settings for the Sound (Audio Setup) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setting the Display or Sound Track Language (Language Setup). . . . . . . . . 36

Parental Control Settings (Parental Control) . . . . . . . . . . . . . . . . . . . . . . . . . 37

Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Connecting to another device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

About MP3 Audio Tracks and JPEG Image Files . . . . . . . . . . . . . . . . . . . . . 44

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Index to Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

About This Manual

• Instructions in this manual describe the controls on the remote. You can also use the controls on the player if they have the same or similar names as those on the remote.

• “DVD” may be used as a general term for DVD VIDEOs, DVD+RWs/DVD+Rs (+VR mode) and DVD-RWs/DVD-Rs (VR mode, video mode).

• The meaning of the icons used in this manual is described below:

Icons Meaning

Functions available for DVD VIDEOs and DVD+RWs/DVD+Rs in +VR mode or DVD-RWs/DVD-Rs in video mode

Functions available for DVD-RWs/DVD-Rs in VR (Video Recording) mode

Functions available for VIDEO CDs (including Super VCDs or CD-Rs/CDRWs in video CD format or Super VCD format)

Functions available for music CDs or CD-Rs/CD-RWs in music CD format

Functions available for DATA CDs (CD-ROMs/CD-Rs/CD-RWs containing MP3

Functions available for DATA DVDs (DVD-ROMs/DVD+RWs/DVD+Rs/ DVD-RWs/DVD-Rs containing MP3

*2*3

DivX

Functions available for USB devices JPEG image files

*1 MP3 (MPEG-1 Audio Layer III) is a standard format defined by ISO (International Organization for

Standardization)/IEC (International Electrotechnical Commission) MPEG which compresses audio data.

*2 DivX *3 DivX, DivX Certified, and associated logos are trademarks of DivX, Inc. and are used under licence.

is a video file compression technology, developed by DivX, Inc.

audio tracks, JPEG image files, and DivX

video files

)

audio tracks,

containing MP3*1 audio tracks, and

*2*3

video files)

JPEG image files, and

This Player Can Play the Following Discs

Format of discs

DVD VIDEO

DVD-RW/-R (finalized disc)

DVD+RW/+R (finalized disc)

Example of discs that the player cannot play

The player cannot play the following discs:

• Blu-ray discs.

• Discs recorded in AVCHD format.

• HD DVDs.

• DVD-RAMs.

• CD-ROMs/CD-Rs/CD-RWs other than those recorded in the formats listed on this page.

• CD-ROMs recorded in PHOTO CD format.

• Data part of CD-Extras.

• DVD Audio discs.

• DATA DVDs that do not contain MP3 audio tracks, JPEG image files, or DivX video files.

• HD layer on Super Audio CDs.

VIDEO CD/ Music CD

CD-RW/-R

“DVD+RW,” “DVD-RW,” “DVD+R,” “DVD-R,” “DVD VIDEO,” and “CD” logos are trademarks.

Note about CDs/DVDs

The player can play CD-ROMs/CD-Rs/CDRWs recorded in the following formats: – music CD format – video CD format – MP3 audio tracks, JPEG image files, and

DivX video files of format conforming to ISO 9660* Level 1, or its extended format, Joliet

– KODAK Picture CD format

* A logical format of files and folders on CD-

ROMs, defined by ISO (International Organization for Standardization).

The player can play DVD-ROMs/ DVD+RWs/DVD-RWs/DVD+Rs/DVD-Rs recorded in the following format: – MP3 audio tracks, JPEG image files, and

DivX video files of format conforming to UDF (Universal Disk Format).

Also, the player cannot play the following discs:

• A DVD VIDEO with a different region code.

• A disc that has a non-standard shape (e.g., card, heart).

• A disc with paper or stickers on it.

• A disc that has the adhesive of cellophane tape or a sticker still left on it.

Notes

• Notes about DVD+RWs/DVD+Rs, DVD-RWs/ DVD-Rs or CD-Rs/CD-RWs

Some DVD+RWs/DVD+Rs, DVD-RWs/DVDRs, or CD-Rs/CD-RWs cannot be played on this player due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software.

The disc will not play if it has not been correctly finalized. For more information, refer

to the operating instructions for the recording device. Note that some playback functions may not work with some DVD+RWs/DVD+Rs, even if they have been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs/DATA DVDs created in Packet Write format or multiple sessions cannot be played.

• Notes about DVD+R DLs/DVD-R DLs MP3 and JPEG files recorded on the second layer of a DVD+R DL/-R DL (double layered) cannot be played. DVD-R DL discs recorded in VR mode cannot be played.

,continued

• Music discs encoded with copyright protection technologies

This product is designed to playback discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product.

• Note on DualDiscs

A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. However, since the audio material side does not conform to the Compact Disc (CD) standard, playback on this product is not guaranteed.

Region code

It is the system that is used to protect copyrights. The region code is shown on the DVD VIDEO packages according to the region of sale. DVD VIDEOs labelled “ALL” or “2” will play on this player.

ALL

Note on playback operations of DVDs and VIDEO CDs

Some playback operations of DVDs and VIDEO CDs may be intentionally set by software producers. Since this player plays DVDs and VIDEO CDs according to the disc contents the software producers designed, some playback features may not be available. Also, refer to the instructions supplied with the DVDs or VIDEO CDs.

Trademarks

• Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories.

• “DTS” and “DTS Digital Out” are registered trademarks of DTS, Inc.

Copyrights

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Preparations

Checking the Accessories

Check that you have the following items:

• Audio/video cord (mini plug × 2 y phono

plug × 3) (1)

• Mains lead (1)

•AC adaptor (1)

• Car battery adaptor (1)

• Battery pack (NP-FX110) (1)

• Remote (with battery) (1)

•Carry case (1)

Using the Remote

When operating, point it at the remote sensor on the player.

To replace the remote control battery

Insert a lithium battery CR2025 matching the 3 and # ends of the battery.

1 Pull out the battery holder (2) while

pressing the lock lever (1).

2 Remove the old battery.

Notes

• Do not expose the remote sensor to direct sunlight or a lighting apparatus. Doing so may cause a malfunction.

• No button operation can be made, when the battery drains. If the remote does not work at all, change the battery and check the status.

• When disposing the used batteries, follow the battery maker’s instructions.

3 Insert the new battery in the battery

holder with the 3 side up and then push the holder fully.

Preparations

Using the LCD Panel

The LCD panel of the player can rotate a maximum of 180 degrees clockwise and still be used. After rotation of the LCD panel, it can be folded down on the main body of the player and still function.

Rotating the LCD panel

1 Place the player on a table or other flat stable surface. 2 Push the LCD panel up with your thumbs until it is open to the vertical position.

3 Slowly rotate the LCD panel 180 degrees in the direction indicated by the arrow

(clockwise).

Rotating and folding down the LCD panel

After rotating the LCD panel 180 degrees clockwise push the LCD panel down onto the main body of the player. In this position the panel is facing up.

To return the LCD panel to its original position

Open the LCD panel to the vertical position and rotate the LCD panel counter-clockwise slowly.

Notes

• Do not rotate the LCD panel over 180 degrees. In addition, do not rotate in the opposite direction. Doing so will break the LCD panel.

• If the LCD panel does not fully open, do not further rotate it. The LCD panel may become damaged.

• Return the LCD panel to its original positions after use. The LCD screen can be damaged by sudden shocks or similar treatment.

Connecting the AC Adapter

Connect the AC adaptor (supplied) in the order of 1 to 3 below. To disconnect, follow the steps in reverse order. See also “On AC adaptor” in “Precautions” (page 3).

Preparations

OPTICAL OUT

LINE SELECTAUDIO VIDEOPHONES

A B IN OUT

DC IN

9.5V

To DC IN 9.5 V jack

DC plug

AC Adaptor (supplied)

Mains lead (supplied)

To mains

Note

Stop playback before disconnecting the mains lead. Failure to do so may cause a malfunction.

Using with Battery Pack

When a mains connection is not available, the player can be enjoyed with the battery pack (supplied) installed. Please charge the battery pack before using it. See also “On battery pack” in “Precautions” (page 4).

Installing the battery pack

1 Aligning the battery pack with the lines on the player’s bottom, engage the hooks of

the battery pack in the holes on the bottom of the player.

2 Slide the battery pack in the direction of the arrow until it clicks into place.

Battery pack

Bottom of the player

To remove the battery pack

Push the release knob and slide the battery pack in the direction of the arrow.

Release knob

Notes

• Turn the player off before installing the battery pack.

• Do not remove the battery pack during playback.

• Do not touch the connecting points of the player and the battery pack. Doing so may cause a malfunction.

• Be careful not to drop the battery pack when installing and removing it.

Charging the battery pack

HOLD

CHARGE

1 Attach the battery pack to the player (page 12). 2 Connect the AC adaptor to the player, and then connect the mains lead into a mains

(page 11).

CHARGE indicator

DC IN 9.5 V jack

Preparations

VOLUME A B IN OUT

Player Battery pack

LINE SELECTAUDIO VIDEOPHONES OPTICAL OUT

DC IN

9.5V

When charging begins, the CHARGE indicator turns on. When charging ends, the CHARGE indicator turns off.

3 After charging is finished, disconnect the mains lead from the mains and remove the

AC adaptor.

To check the battery level

When the player is stopped, a battery indicator is displayed on the screen. Recharge the battery, when is displayed or the CHARGE indicator flashes.

Full Exhausted

The battery indicator is not displayed when a DVD, VIDEO CD or JPEG file are being played. Stop the player and check the battery level.

Charging time and maximum playing time

Charging time (with the player turned off) Playing time (with the display turned on)

Approx. 6 hours

* This is the indication of the longest continuous playback on the following conditions. – normal temperature (20°C) – Headphone Use – Set Backlight Adjustment to the Minimum – Set “Digital Output” to “Off” in “Audio Setup.” Battery condition may reduce operating time.

Approx. 6 hours*

Notes

• The battery indicator does not appear on the screen when the AC adaptor is used or when inputting from external sources.

• Charging times may differ from that indicated above due to conditions of use, environment, and other factors. The recommended charge up surrounding temperature is in the 10-30°C range.

Using With the Car Battery Adaptor

Use the car battery adaptor (supplied) to supply power from the cigarette lighter socket to the player. The adaptor is for a 12V car battery. Do not use it with a 24V car battery. The adaptor is also for use with negatively grounded cars. Do not use it with cars grounded positively.

A B IN OUT

OPTICAL OUT

LINE SELECTAUDIO VIDEOPHONES

To DC IN 9.5V jack

DC IN

9.5V

To cigarette lighter socket

Car battery adaptor (supplied)

z Hint

If the car adaptor interferes with car operation, use a commercial cigarette lighter extension cord.

Notes

• Do not use the car adaptor if it has been dropped or damaged.

• Arrange the cord so as not to interfere with the driver. Also, do not place the LCD panel where the driver can watch.

• If the picture is not clear, keep the player away from the car battery adaptor.

• Use the car battery adaptor with the car engine running. If it is used with the car engine off, the car battery may become unusable.

• If the cigarette lighter socket is dirty with ash, etc, a bad connection may cause the plug to heat up. Always clean well before use.

• The car battery adaptor may heat up while charging or after a long period of use. That is not a malfunction.

After using the car battery adaptor

After turning the player off, disconnect the car battery adaptor from the cigarette lighter socket.

Notes

• Do not turn off the car engine while the player is turned on. Doing so stops the power supp ly and may cause damage to the player.

• Disconnect the car battery adaptor after use. Since some cars supply power to the cigarette lighter socket even when the engine is turned off, the car battery may discharge over time.

• When disconnecting the car battery adaptor, hold the plug to pull it out.

• When listening to the car radio, disconnect the car battery adaptor from the cigarette lighter socket to avoid noise.

Playing Discs

Depending on the DVD or VIDEO CD, some operations may be different or restricted. Refer to the operating instructions supplied with the disc. Connect the AC adaptor or install the battery pack.

2 Press [/1 on the remote or slide

the [/1/HOLD switch of the player to the right.

The player turns on and the power indicator lights up in green.

3 Slide the OPEN knob to the left and

open the disc lid.

4 Insert the disc to be played.

Push with the playback side down until it clicks.

Playing Discs

OPEN

OPEN knob \/1/HOLD

123

456

7809

RETURN OPTIONSMENUDISPLAY

CHARGE

HOLD

\/1

1 Open the player’s LCD panel.

Set the LINE SELECT switch on the player’s right side to “OUT” and set the CD/DVD USB switch on the player’s left side to “CD/DVD.”

Playback side facing down

5 Push the PUSH CLOSE on the

player to shut the disc lid.

6 Press H.

Playback starts.

• Some discs may start playing automatically after the disc lid is shut.

• Depending on the disc, a menu may appear on the screen. For DVD VIDEOs, see page 17. For VIDEO CDs, see page 20.

• After all titles have been played, the player will stop itself and the display will return to the menu screen.

Notes

• If the disc is inserted with playback side up, a “No Disc” or “Cannot play this disc.” message appears.

• Discs created on DVD recorders must be correctly finalized to play on this player. For more information about finalizing, refer to the operating instructions supplied with the DVD recorder.

,continued

• The disc may be still spinning when the disc lid is opened. Wait until the spinning stops before removing the disc.

• During operation, “ ” may appear on the scree n. This symbol indicates that a function explained in this operating instruction is not available on the current DVD VIDEO.

• Some DVD-RWs/DVD-Rs (VR mode) may take time before starting playback because of the recorded content.

To stop playback

Press x. Pressing H again will start playback from the point you stopped (Resume Play). See page 17 for details. To play from the beginning, press x twice, then press H.

To turn off the power

Press the remote’s \/1 button or slide the player’s \/1/HOLD switch to the right.

To avoid accidental button operation on the player

Set the player’s \/1/HOLD switch to “HOLD.” All the buttons on the player are locked, while the button on the remote remains operable.

To play DTS sound tracks on a DVD VIDEO

• The player’s speaker does not output DTS sound. When you play DTS sound tracks on a DVD VIDEO, connect the player to an AV amplifier (receiver) (page 40) and set up “DTS” in “Audio Setup” (page 36).

• If you connect the player to audio equipment such as an AV amplifier (receiver) without a DTS decoder, do not set “DTS” to “On” in “Audio Setup” (page 36). A loud noise may come out from the speakers, which may affect your ears or cause speaker damage.

Additional playback operations

123

456

7809

To Operation

Stop Press x Pause Press X

Go to the next chapter,

Press >

track, or scene in continuous play mode

Go back to the

Press .

previous chapter, track, or scene in continuous play mode

Briefly fast forward the current scene*

* DVD VIDEOs, DVD-RWs/DVD-Rs (VR mode)

only. The above functions may not be used for some scenes.

Press during playback.

Notes

• A screen saver image appears when you leave the player in pause or stop without operatio n for more than 15 minutes. The image disappears when you press H. See page 35 for details.

• The player turns off, 15 minutes after starting the screen saver function (Auto Power Off).

+ 36 hidden pages
