DSC-WX100/WX150

Digital Still Camera / Instruction Manual GB

Cámara fotografía digital / Manual de instrucciones ES

Câmera fotográﬁca digital / Manual de instruções PT

DSC-WX100/WX150

English

Learning more about the camera (“Cyber-shot User Guide”)

“Cyber-shot User Guide” is an on-line manual. Refer to it for in-depth instructions on the many functions of the camera. 1 Access the Sony support page.

http://www.sony.net/SonyInfo/Support/

2 Select your country or region. 3 Search for the model name of your camera within the

support page.

• Check the model name on the bottom of your camera.

Checking the supplied items

The number in parentheses indicates the number of pieces.

• Camera (1)

• Rechargeable battery pack NP-BN (1) (This rechargeable battery pack cannot be used with Cyber-shot that are supplied with the NP-BN1 battery pack.)

• Micro USB cable (1)

• AC Adaptor AC-UB10/UB10B/UB10C/UB10D (1)

• Power cord (mains lead) (not supplied in the USA and Canada) (1)

• Wrist strap (1)

• Instruction Manual (this manual) (1)

Owner’s Record

The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call your Sony dealer regarding this product.

Model No. DSC-WX100/DSC-WX150 Serial No. _____________________________ Model No. AC-UB10/AC-UB10B/AC-UB10C/AC-UB10D Serial No. _____________________________

WARNING

To reduce fire or shock hazard, do not expose the unit to rain or moisture.

IMPORTANT SAFETY INSTRUCTIONS

-SAVE THESE INSTRUCTIONS DANGER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS

If the shape of the plug does not fit the power outlet, use an attachment plug adaptor of the proper configuration for the power outlet.

CAUTION

[ Battery pack

If the battery pack is mishandled, the battery pack can burst, cause a fire or even chemical burns. Observe the following cautions.

• Do not disassemble.

• Do not crush and do not expose the battery pack to any shock or force such as

hammering, dropping or stepping on it.

• Do not short circuit and do not allow metal objects to come into contact with the battery

terminals.

• Do not expose to high temperature above 60°C (140°F) such as in direct sunlight or in a

car parked in the sun.

• Do not incinerate or dispose of in fire.

• Do not handle damaged or leaking lithium ion batteries.

• Be sure to charge the battery pack using a genuine Sony battery charger or a device that can charge the battery pack.

• Keep the battery pack out of the reach of small children.

• Keep the battery pack dry.

• Replace only with the same or equivalent type recommended by Sony.

• Dispose of used battery packs promptly as described in the instructions.

[ AC Adaptor

Connect the AC Adaptor to the nearest wall outlet (wall socket). If some trouble occurs while using the AC Adaptor, immediately shut off the power by disconnecting the plug from the wall outlet (wall socket).

The power cord (mains lead), if supplied, is designed specifically for use with this camera only, and should not be used with other electrical equipment.

For Customers in the U.S.A. and Canada

[ RECYCLING LITHIUM-ION BATTERIES

Lithium-Ion batteries are recyclable. You can help preserve our environment by returning your used rechargeable batteries to the collection and recycling location nearest you.

For more information regarding recycling of rechargeable batteries, call toll free 1-800-822-8837, or visit http://www.rbrc.org/

Caution: Do not handle damaged or leaking Lithium-Ion batteries.

[ Battery pack

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

For Customers in the U.S.A.

UL is an internationally recognized safety organization. The UL Mark on the product means it has been UL Listed.

If you have any questions about this product, you may call:

Sony Customer Information Center 1-800-222-SONY (7669)

The number below is for the FCC related matters only.

[ Regulatory Information

Declaration of Conformity

Trade Name: SONY Model No.: DSC-WX100 Responsible Party: Sony Electronics Inc. Address: 16530 Via Esprillo,

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

Trade Name: SONY Model No.: DSC-WX150 Responsible Party: Sony Electronics Inc. Address: 16530 Via Esprillo,

Telephone No.: 858-942-2230

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

[ CAUTION

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

San Diego, CA 92127 U.S.A.

[ Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

The supplied interface cable must be used with the equipment in order to comply with the limits for a digital device pursuant to Subpart B of Part 15 of FCC Rules.

For Customers in Europe

[ Notice for the customers in the countries applying EU Directives

The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.

This product has been tested and found compliant with the limits set out in the EMC Directive for using connection cables shorter than 3 meters (9.8 feet).

[ Attention

The electromagnetic fields at the specific frequencies may influence the picture and sound of this unit.

[ Notice

If static electricity or electromagnetism causes data transfer to discontinue midway (fail), restart the application or disconnect and connect the communication cable (USB, etc.) again.

[ Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate collection systems)

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural

please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

resources. For more detailed information about recycling of this product,

[ Disposal of waste batteries (applicable in the European Union

and other European countries with separate collection systems)

This symbol on the battery or on the packaging indicates that the battery provided with this product shall not be treated as household waste. On certain batteries this symbol might be used in combination with a chemical symbol. The chemical symbols for mercury (Hg) or lead (Pb) are added if the battery contains more than 0.0005% mercury or 0.004% lead.

potentially negative consequences for the environment and human health which could otherwise be caused by inappropriate waste handling of the battery. The recycling of the materials will help to conserve natural resources. In case of products that for safety, performance or data integrity reasons require a permanent connection with an incorporated battery, this battery should be replaced by qualified service staff only. To ensure that the battery will be treated properly, hand over the product at end-of-life to the applicable collection point for the recycling of electrical and electronic equipment. For all other batteries, please view the section on how to remove the battery from the product safely. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

By ensuring these batteries are disposed of correctly, you will help prevent

Notice for customers in the United Kingdom

A moulded plug complying with BS 1363 is fitted to this equipment for your safety and convenience. Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as the supplied one and approved by ASTA or BSI to BS 1362, (i.e., marked with an or mark) must be used. If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.

Identifying parts

A Shutter button B For shooting: W/T (Zoom) lever

For viewing: (Playback zoom) lever/ (Index) lever

C Flash D Self-timer lamp/Smile Shutter

lamp/AF illuminator

E ON/OFF (Power) button F Power/Charge lamp G Microphone H Lens

I LCD screen J Mode switch

(Still Image)/ (Sweep

Panorama)/ (Movie)

K MOVIE (Movie) button L HDMI mini jack M Hook for wrist strap N Control wheel O (Playback) button P / (In-Camera Guide/Delete)

button

Q MENU button R (TransferJet™) mark S Battery insertion slot T Tripod receptacle

• Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the camera, and damage to the camera may occur.

U Speaker V Battery eject lever W Access lamp X Memory card slot Y Micro USB connector Z Battery/memory card cover

Inserting the battery pack

Battery eject lever

Open the cover.

Insert the battery pack.

• While pressing the battery eject lever, insert the battery pack as illustrated. Make sure that the battery eject lever locks after insertion.

• Closing the cover with the battery inserted incorrectly may damage the camera.

Charging the battery pack

For customers in the USA and Canada

Power cord (Mains lead)

For customers in countries/regions other than the USA and Canada

Connect the camera to the AC Adaptor (supplied),

using the micro USB cable (supplied).

Connect the AC Adaptor to the wall outlet (wall socket).

The Power/Charge lamp lights orange, and charging starts.

• Turn off the camera while charging the battery.

• You can charge the battery pack even when it is partially charged.

• When the Power/Charge lamp flashes and charging is not finished,

remove and re-insert the battery pack.

Power/Charge lamp Lit: Charging Off: Charging finished Flashing:

Charging error Charging paused due to overheating

Notes

• If the Power/Charge lamp on the camera flashes when the AC Adaptor is connected to the wall outlet (wall socket), this indicates that charging is temporarily stopped because the temperature is outside the recommended range. When the temperature gets back within the appropriate range, the charging resumes. We recommend charging the battery pack in an ambient temperature of between 10°C to 30°C (50ºF to 86ºF).

• The battery pack may not be effectively charged if the terminal section of the battery is dirty. In this case, wipe any dust off lightly using a soft cloth or a cotton swab to clean the terminal section of the battery.

• Connect the AC Adaptor (supplied) to the nearest wall outlet (wall socket). If malfunctions occur while using the AC Adaptor, disconnect the plug from the wall outlet (wall socket) immediately to disconnect from the power source.

• When charging is finished, disconnect the AC Adaptor from the wall outlet (wall socket).

• Be sure to use only genuine Sony brand battery packs, micro USB cable (supplied) and AC Adaptor (supplied).

• BC-TRN2 battery charger (sold separately) is able to quick-charge the NP-BN rechargeable battery pack supplied with this model. BC-TRN battery charger (sold separately) is not able to quick-charge the NP-BN rechargeable battery pack supplied with this model.

Charging time (Full charge)

The charging time is approximately 115 min. using the AC Adaptor (supplied).

Note

• The above charging time applies when charging a fully depleted battery pack at a temperature of 25°C (77°F). Charging may take longer depending on conditions of use and circumstances.

Charging by connecting to a computer

The battery pack can be charged by connecting the camera to a computer using a micro USB cable.

Note

• Note the following points when charging via a computer:

– If the camera is connected to a laptop computer that is not connected to a power

source, the laptop battery level decreases. Do not charge for an extended period of time.

– Do not turn on/off or restart the computer, or wake the computer to resume from

sleep mode when a USB connection has been established between the computer and the camera. The camera may cause a malfunction. Before turning on/off, or restarting the computer or waking the computer from sleep mode, disconnect the camera and the computer.

– No guarantees are made for charging using a custom-built computer or a

modified computer.

Battery life and number of images that can be recorded and played back

Battery life Number of images

Shooting (still images)

Viewing (still images)

Shooting (movies)

DSC-WX100 Approx. 120 min. Approx. 240 images DSC-WX150 Approx. 120 min. Approx. 240 images DSC-WX100 Approx. 180 min. Approx. 3600 images DSC-WX150 Approx. 180 min. Approx. 3600 images DSC-WX100 Approx. 60 min. — DSC-WX150 Approx. 60 min. —

Notes

• The above number of images applies when the battery pack is fully charged. The number of images may decrease depending on the conditions of use.

• The number of images that can be recorded is for shooting under the following conditions: – Using Sony “Memory Stick PRO Duo” (Mark2) media (sold separately) – The battery pack is used at an ambient temperature of 25°C (77°F). – [Disp. Resolution]: [Standard]

• The number for “Shooting (still images)” is based on the CIPA standard, and is for shooting under the following conditions: (CIPA: Camera & Imaging Products Association) – DISP (Display Setting) is set to [ON]. – Shooting once every 30 seconds. – The zoom is switched alternately between the W and T ends. – The flash strobes once every two times. – The power turns on and off once every ten times.

• The battery life for movies applies shooting under the following conditions: – Movie quality: AVC HD HQ – When continuous shooting ends because of set limits (page 25), press the

MOVIE (Movie) button again and continue shooting. Shooting functions such as the zoom do not operate.

Supplying power

The camera can be supplied with power from the wall outlet (wall socket) by connecting to the AC Adaptor, using the micro USB cable (supplied). You can import images to a computer without worrying about draining the battery pack by connecting the camera to a computer using the micro USB cable. In addition, you can use the AC Adaptor AC-UD10 (sold separately) for shooting to supply power when shooting.

Notes

• Power cannot be supplied when the battery pack is not inserted in the camera.

• When the camera is connected directly to a computer or to a power outlet using the supplied AC Adaptor, power supply is available only in playback mode. If the camera is in shooting mode or while you are changing the settings of the camera, power is not supplied even if you make a USB connection using the micro USB cable.

• If you connect the camera and a computer using the micro USB cable while the camera is in playback mode, the display on the camera will change from the playback screen to the USB connection screen. Press (Playback) button to

switch to the playback screen.

Inserting a memory card (sold separately)

Ensure the notched corner faces correctly.

Open the cover.

Insert the memory card (sold separately).

• With the notched corner facing as illustrated, insert the memory card until it clicks into place.

Close the cover.

Memory cards that can be used

Memory card For still images For movies

Memory Stick PRO Duo aa (Mark2 only)

Memory Stick PRO-HG Duo aa Memory Stick Duo a — Memory Stick Micro (M2) a —

Memory Stick Micro (Mark2) aa SD memory card aa (Class 4 or faster)

SDHC memory card aa (Class 4 or faster) SDXC memory card aa (Class 4 or faster) microSD memory card aa (Class 4 or faster)

microSDHC memory card aa (Class 4 or faster)

• In this manual, the products in the table are collectively referred to as follows:

A: “Memory Stick Duo” media B: “Memory Stick Micro” media C: SD card D: microSD memory card

Note

• To use a “Memory Stick Micro” media or microSD memory card with the camera, be sure to insert it into a dedicated adaptor first.

To remove the memory card/battery pack

Memory card: Push the memory card in once to eject the memory card. Battery pack: Slide the battery eject lever. Be sure not to drop the battery pack.

Note

• Never remove the memory card/battery pack when the access lamp (page 9) is lit. This may cause damage to data in the memory card/internal memory.

Setting the clock

Power/Charge lamp (green)

ON/OFF (Power)

Control Wheel

Select items: v/V/b/B Set the numeric value of date and time: / Set:

Press the ON/OFF (Power) button.

Date & Time setting is displayed when you turn on the camera for the first time.

• It may take time for the power to turn on and allow operation.

Select a desired language.

Select a desired geographic location by following the

on-screen instructions, then press z on the control

wheel.

Set [Date & Time Format], [Daylight Savings] or

[Summer Time] and [Date & Time], then select [OK] t [OK].

• Midnight is indicated as 12:00 AM, and noon as 12:00 PM.

Follow the instructions on the screen.

• The battery pack will run out quickly when: – [Disp. Resolution] is set to [High].

Shooting still images/movies

Shutter button

Mode switch

: Still image : Movie

Shooting still images

Press the shutter button halfway down to focus.

When the image is in focus, a beep sounds and the z indicator lights.

Press the shutter button fully down to shoot an image.

Shooting movies

Press the MOVIE (Movie) button to start recording.

• Use the W/T (zoom) lever to change the zoom scale.

• Press the shutter button to shoot still images while continuing to record the movie.

Press the MOVIE button again to stop recording.

W/T (Zoom) lever

W: zoom out T: zoom in

MOVIE

Notes

• The sound of the lens and lever operating will be recorded when the zoom function operates while shooting a movie. The sound of the MOVIE button operating may also be recorded when movie recording is finished.

• Continuous shooting is possible for approximately 29 minutes at one time at the camera’s default settings and when the temperature is approximately 25°C (77°F). When movie recording is finished, you can restart recording by pressing the MOVIE button again. Recording may stop to protect the camera depending on the ambient temperature.

Viewing images

W: zoom out T: zoom in

Control wheel

/ (Delete)

(Playback)

Press the (Playback) button.

• When images on a memory card recorded with other cameras are played back on this camera, the registration screen for the data file appears.

Selecting next/previous image

Select an image by pressing B (next)/b (previous) on the control wheel or by turning the control wheel. Press z in the center of the control wheel to view movies.

Select images: B (next)/b (previous) or turn

the control wheel

Set: z

Deleting an image

1 Press / (Delete) button. 2 Select [This Image] with v on the control wheel, then press z.

Returning to shooting images

Press the shutter button halfway down.

In-Camera Guide

This camera is equipped with a built-in instruction guide. This allows you to search the camera’s functions according to your needs.

/ (In-Camera Guide)

Press the MENU button.

Select the desired MENU item, then press the / (In-

Camera Guide) button.

The operation guide for the selected item is displayed.

• If you press the / (In-Camera Guide) button when the MENU screen

is not displayed, you can search the guide using keywords or icons.

Introduction of other functions

Other functions used when shooting or playing back can be operated using the control wheel or MENU button on the camera. This camera is equipped with a Function Guide that allows you to easily select from the functions. While displaying the guide, you can use various functions.

Control wheel

Function Guide

Control wheel

DISP (Display Setting): Allows you to change the screen display.

(Self-Timer): Allows you to use the self-timer.

(Cont. Shooting Settings): Allows you to use the burst shooting mode.

(Flash): Allows you to select a flash mode for still images. Center button (Tracking focus): The camera tracks the subject and adjusts focus automatically even when the subject is moving.

Menu Items

Shooting

REC Mode Select still image recording mode.

Movie shooting scene

Panorama Shooting Scene

Picture Effect

Scene Selection Select pre-set settings to match various scene conditions.

Easy Mode Shoot still images using minimal functions.

Select movie recording mode.

Select recording mode when shooting panoramic images.

Shoot a still image with an original texture according to the desired effect.

Defocus Effect

Still Image Size(Dual Rec)

Still Image Size/ Panorama Image Size/Movie Size/ Movie Quality

HDR Painting effect

Area of emphasis

Color hue

Extracted Color

Watercolor Effect

Illustration Effect

EV Adjust the exposure manually.

ISO Adjust the luminous sensitivity.

White Balance Adjust color tones of an image.

Underwater White Balance

Focus Select the focus method.

Metering Mode

Cont. Shooting Interval

Scene Recognition Set to automatically detect shooting conditions.

Soft Skin Effect Set the Soft Skin Effect and the effect level.

Smile Shutter

Set the level of background defocus effect when shooting in Background Defocus mode.

Set the still image size shot while recording a movie.

Select the image size and the quality for still images, panoramic images or movie files.

When [HDR Painting] is selected in Picture Effect, sets the effect level.

When [Miniature] is selected in Picture Effect, sets the part to focus on.

When [Toy camera] is selected in Picture Effect, sets the color hue.

When [Partial Color] is selected in Picture Effect, selects the color to extract.

When [Watercolor] is selected in Picture Effect, sets the effect level.

When [Illustration] is selected in Picture Effect, sets the effect level.

Adjust color tones when shooting underwater.

Select the metering mode that sets which part of the subject to measure to determine the exposure.

Select the number of images taken per second for Burst shooting.

Set to automatically release the shutter when a smile is detected.

Smile Detection Sensitivity

Face Detection

Anti Blink

Movie SteadyShot

In-Camera Guide Search the camera’s functions according to your needs.

Set the Smile Shutter function sensitivity for detecting smiles.

Select to detect faces and adjust various settings automatically.

Set to automatically shoot two images and select image in which the eyes are not blinking.

Set the strength of SteadyShot in movie mode. If you change the setting for [Movie SteadyShot], the angle of view will change.

Viewing

Easy Mode Increase the text size on the screen for ease of use.

Slideshow Select a method of continuous playback.

Send by TransferJet

Delete Delete an image.

Retouch Retouch an image using various effects.

Picture Effect Add various texture on images.

3D Viewing Set to play back images shot in 3D mode on a 3D TV.

View Mode Select the display format for images.

Display Cont. Shooting Group

Protect Protect the images.

Print (DPOF) Add a print order mark to a still image.

Rotate Rotate a still image to the left.

In-Camera Guide Search the camera’s functions according to your needs.

Transfer data by closely aligning two products equipped with TransferJet.

Select to display burst images in groups or display all images during playback.

Setting items

If you press the MENU button while shooting or during playback,

(Settings) is provided as a final selection. You can change the default

settings on the (Settings) screen.

Shooting Settings

Main Settings

Memory Card

Tool

Clock Settings

* If a memory card is not inserted, (Internal Memory Tool) will be displayed and

only [Format] can be selected.

Movie format/AF Illuminator/Grid Line/Clear Image Zoom/Digital Zoom/Wind Noise Reduct./Red Eye Reduction/Blink Alert/Write Date/Disp. Resolution

Beep/Panel Brightness/Language Setting/Display color/ Demo Mode/Initialize/Function Guide/CTRL FOR HDMI/Eco Mode/USB Connect Setting/USB Power Supply/LUN Setting/Download Music/Empty Music/ TransferJet/Eye-Fi/Version

Format/Create REC.Folder/Change REC.Folder/Delete REC.Folder/Copy/File Number

Area Setting/Date & Time Setting

Install PC application (Windows)

The built-in software “PlayMemories Home” allows you to import still images and movies to your computer and use them. You can shoot or play back images on this camera even if you do not install “PlayMemories Home”, however, “PlayMemories Home” is required to import AVCHD movies to your computer.

Connect the camera to a computer.

Windows 7: [Computer] t camera icon t media icon

t Double-click [PMHOME.EXE] Windows XP/Vista: [Computer] (in Windows XP, [My

Computer]) t [PMHOME] t Double-click [PMHOME.EXE]

Follow the instructions on the screen to complete the

installation.

Note

• “PlayMemories Home” is not compatible to Mac OS. If you play back images on a

Mac, use the applications that are installed on your Mac. For details, see http://www.sony.co.jp/imsoft/Mac/

Features of “PlayMemories Home”

Below are examples of the functions available when you use “PlayMemories Home”. To take advantage of the various “PlayMemories Home” functions, connect to the Internet and install the “Expanded Feature”.

• You can import images shot with the camera to a computer and display them.

• You can display images stored on a computer by shooting date in a calendar

display.

• You can correct (Red Eye Correction, etc.) still images, print the images,

send images by e-mail, and change the shooting date and time.

• You can save and print images with the date.

• You can create a disc from AVCHD movies imported to a computer.

(Expanded Feature)

Number of still images and recordable time of movies

The number of still images and recordable time may vary depending on the shooting conditions and the memory card.

Still images

(Units: Images)

Capacity

Size

18M 3 295 VGA 65 6400 16:9(13M) 3 330

Movies

The table below shows the approximate maximum recording times. These are the total times for all movie files. Continuous shooting is possible for approximately 29 minutes. The maximum size of an MP4-format movie file is up to approximately 2 GB.

Capacity

Size

AVC HD 24M (FX) — 10 m

AVC HD 9M (HQ) — 20 m

MP4 12M — 15 m MP4 3M — 1 h 5 m

The number in ( ) is the minimum recordable time.

• The recordable time of movies varies because the camera is equipped with VBR (Variable Bit Rate), which automatically adjusts image quality depending on the shooting scene. When you record a fast-moving subject, the image is clearer but the recordable time is shorter because more memory is required for recording. The recordable time also varies depending on the shooting conditions, the subject or the image quality/size settings.

Internal memory Memory card

Approx. 19 MB 2 GB

(h (hour), m (minute))

Internal memory Memory card

Approx. 19 MB 2 GB

(10 m)

(15 m)

Notes on using the camera

Functions built into this camera

• This manual describes each of the functions of TransferJet compatible/ incompatible devices, 1080 60i-compatible devices and 1080 50i-compatible devices. To check if your camera supports the TransferJet function, and whether it is a 1080 60i-compatible device or 1080 50i-compatible device, check for the following marks on the bottom of the camera. TransferJet-compatible device: 1080 60i-compatible device: 60i 1080 50i-compatible device: 50i

• Do not watch 3D images shot with this camera for extended periods of time on 3D-compatible monitors.

• When you view 3D images shot with this camera on a 3D-compatible monitors, you may experience discomfort in the form of eye strain, fatigue, or nausea. To prevent these symptoms, we recommend that you take regular breaks. However, you need to determine for yourself the length and frequency of breaks you require, as they vary according to the individual. If you experience any type of discomfort, stop viewing the 3D images until you feel better, and consult a physician as necessary. Also refer to the operating instructions supplied with the device or software you have connected or are using with this camera. Note that a child’s eyesight is still at the development stage (particularly children below the age of 6). Consult a pediatrician or ophthalmologist before letting your child view 3D images, and make sure he/she observes the above precautions when viewing such images.

(TransferJet)

On use and care

Avoid rough handling, disassembling, modifying, physical shock, or impact such as hammering, dropping, or stepping on the product. Be particularly careful of the lens.

Notes on recording/playback

• Before you start recording, make a trial recording to make sure that the camera is working correctly.

• The camera is neither dust-proof, nor splash-proof, nor water-proof.

• Avoid exposing the camera to water. If water enters inside the camera, a malfunction may occur. In some cases, the camera cannot be repaired.

• Do not aim the camera at the sun or other bright light. It may cause the malfunction of the camera.

• If moisture condensation occurs, remove it before using the camera.

• Do not shake or strike the camera. It may cause a malfunction and you may not be able to record images. Furthermore, the recording media may become unusable or image data may be damaged.

Do not use/store the camera in the following places

• In an extremely hot, cold or humid place

In places such as in a car parked in the sun, the camera body may become deformed and this may cause a malfunction.

• Under direct sunlight or near a heater

The camera body may become discolored or deformed, and this may cause a malfunction.

• In a location subject to rocking vibration

• Near a location that generates strong radio waves, emits radiation or is strongly

magnetic place. Otherwise, the camera may not properly record or play back images.

• In sandy or dusty places

Be careful not to let sand or dust get into the camera. This may cause the camera to malfunction, and in some cases this malfunction cannot be repaired.

On carrying

Do not sit down in a chair or other place with the camera in the back pocket of your trousers or skirt, as this may cause malfunction or damage the camera.

Notes on the screen and lens

The screen is manufactured using extremely high-precision technology so over

99.99% of the pixels are operational for effective use. However, some tiny black and/or bright dots (white, red, blue or green) may appear on the screen. These dots are a normal result of the manufacturing process, and do not affect the recording.

On camera’s temperature

Your camera and battery may get hot due to continuous use, but it is not a malfunction.

On the overheat protection

Depending on the camera and battery temperature, you may be unable to record movies or the power may turn off automatically to protect the camera. A message will be displayed on the screen before the power turns off or you can no longer record movies. In this case, leave the power off and wait until the camera and battery temperature goes down. If you turn on the power without letting the camera and battery cool enough, the power may turn off again or you may be unable to record movies.

On charging the battery

If you charge a battery that has not been used for a long time, you may be unable to charge it to the proper capacity. This is due to the battery characteristics, and is not a malfunction. Charge the battery again.

Warning on copyright

Television programs, films, videotapes, and other materials may be copyrighted. Unauthorized recording of such materials may be contrary to the provisions of the copyright laws.

No compensation for damaged content or recording failure

Sony cannot compensate for failure to record or loss or damage of recorded content due to a malfunction of the camera or recording media, etc.

Cleaning the camera surface

Clean the camera surface with a soft cloth slightly moistened with water, then wipe the surface with a dry cloth. To prevent damage to the finish or casing: – Do not expose the camera to chemical products such as thinner, benzine, alcohol,

disposable cloths, insect repellent, sunscreen or insecticide.

On Illustrations

Illustrations used in this manual are of DSC-WX100 unless noted otherwise.

Specifications

Camera

[System]

Image device: 7.76 mm (1/2.3 type)

Exmor R CMOS sensor

Total pixel number of camera:

Approx. 18.9 Megapixels

Effective pixel number of camera:

Approx. 18.2 Megapixels

Lens: Sony G 10× zoom lens

f = 4.45 mm – 44.5 mm (25 mm – 250 mm (35 mm film equivalent)) F3.3 (W) – F5.9 (T) While shooting movies (16:9):

27.5 mm – 275 mm* While shooting movies (4:3):

33.5 mm – 335 mm* * When [Movie SteadyShot] is set

to [Standard] SteadyShot: Optical Exposure control: Automatic exposure,

Scene Selection (15 modes)

White balance: Automatic, Daylight,

Cloudy, Fluorescent 1/2/3, Incandescent, Flash, One Push

Underwater White balance: Automatic,

Underwater 1/2, One Push

Signal format:

For 1080 50i: PAL color, CCIR standards HDTV 1080/50i specification For 1080 60i: NTSC color, EIA standards HDTV 1080/60i specification

File format:

Still images: JPEG (DCF, Exif, MPF Baseline) compliant, DPOF compatible 3D still images: MPO (MPF Extended (Disparity Image)) compliant Movies (AVCHD format): AVCHD format Ver. 2.0 compatible Video: MPEG-4 AVC/H.264 Audio: Dolby Digital 2ch, equipped with Dolby Digital Stereo Creator

• Manufactured under license from

Dolby Laboratories. Movies (MP4 format): Video: MPEG-4 AVC/H.264 Audio: MPEG-4 AAC-LC 2ch

Recording media: Internal Memory

(Approx. 19 MB), “Memory Stick Duo” media, “Memory Stick Micro” media, SD cards, microSD memory cards

Flash: Flash range (ISO sensitivity

(Recommended Exposure Index) set to Auto): Approx. 0.2 m to 3.7 m (7 7/8 inches to 12 feet 1 3/4 inches) (W) Approx. 1.5 m to 2.2 m (4 feet 11 1/8 inches to 7 feet 2 5/8 inches) (T)

[Input and Output connectors]

HDMI connector: HDMI mini jack Micro USB connector:

USB communication

USB communication: Hi-Speed USB

(USB 2.0)

[Screen]

LCD screen:

DSC-WX100:

6.7 cm (2.7 type) TFT drive DSC-WX150:

7.5 cm (3.0 type) TFT drive

Total number of dots:

460 800 dots

[Power, general]

Power: Rechargeable battery pack

NP-BN, 3.6 V AC Adaptor AC-UB10/UB10B/ UB10C/UB10D, 5 V

Power consumption (during shooting):

1.0 W

Operating temperature: 0 °C to 40 °C

(32 °F to 104 °F)

Storage temperature: –20 °C to +60 °C

(–4 °F to +140 °F)

Dimensions (CIPA compliant):

DSC-WX100:

92.3 mm × 52.4 mm × 21.6 mm (3 3/4 inches × 2 1/8 inches × 7/8 inches) (W/H/D) DSC-WX150:

94.7 mm × 56.4 mm × 21.6 mm (3 3/4 inches × 2 1/4 inches × 7/8 inches) (W/H/D)

Mass (CIPA compliant) (including NP-

BN battery pack, “Memory Stick Duo” media): DSC-WX100: Approx. 124 g (4.4 oz) DSC-WX150:

Approx. 133 g (4.7 oz)

Microphone: Stereo Speaker: Monaural Exif Print: Compatible PRINT Image Matching III:

Compatible

AC Adaptor AC-UB10/UB10B/ UB10C/UB10D

Power requirements: AC 100 V to

240 V, 50 Hz/60 Hz, 70 mA Output voltage: DC 5 V, 0.5 A Operating temperature: 0 °C to 40 °C

(32 °F to 104 °F) Storage temperature: –20 °C to +60 °C

(–4 °F to +140 °F) Dimensions:

Approx. 50 mm × 22 mm × 54 mm

(2 inches × 7/8 inches ×

2 1/4 inches) (W/H/D) Mass:

For the USA and Canada: Approx.

48 g (1.7 oz)

For countries or regions other than

the USA and Canada: Approx. 43 g

(1.5 oz)

Rechargeable battery pack NP-BN

Used battery: Lithium-ion battery Maximum voltage: DC 4.2 V Nominal voltage: DC 3.6 V Maximum charge voltage: DC 4.2 V Maximum charge current: 0.9 A Capacity:

typical: 2.3 Wh (630 mAh)

minimum: 2.2 Wh (600 mAh)

Design and specifications are subject to change without notice.

+ 145 hidden pages

Sony DSC-WX150 Users guide [es, zh]

Specifications and Main Features

Frequently Asked Questions

User Manual

English

Learning more about the camera (“Cyber-shot User Guide”)

Checking the supplied items

Identifying parts

Inserting the battery pack

Charging the battery pack

Inserting a memory card (sold separately)

Setting the clock

Shooting still images/movies

Viewing images

In-Camera Guide

Introduction of other functions

Install PC application (Windows)

Number of still images and recordable time of movies

Notes on using the camera

Specifications
