Sony DSC-W80, DSC-W85, DSC-W90 Instruction Manual

Digital Still Camera

Instruction Manual

DSC-W80/W85/W90

For details on the advanced operations, please access
“Cyber-shot Handbook” and “Cyber-shot Step-up Guide”
contained on the supplied CD-ROM via a computer.

Operating Instructions

Before operating the unit, please read this manual thoroughly, and retain it for future reference.

© 2007 Sony Corporation 3-095-004-12(1)

GB

Owner’s Record

The model and serial numbers are located
on the bottom. Record the serial number in
the space provided below. Refer to these
numbers whenever you call upon your Sony
dealer regarding this product.

Model No. DSC-W80/W85/W90

Serial No. ___________________________

WARNING

To reduce fire or shock hazard, do
not expose the unit to rain or
moisture.

For Customers in the U.S.A.

This symbol is intended to
alert the user to the presence
of uninsulated “dangerous
voltage” within the
product's enclosure that may
be of sufficient magnitude
to constitute a risk of
electric shock to persons.

This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the
appliance.

IMPORTANT SAFEGUARDS

For your protection, please read these safety
instructions completely before operating
the appliance, and keep this manual for
future reference.
Carefully observe all warnings, precautions
and instructions on the appliance, or the one
described in the operating instructions and
adhere to them.

Use

[ Power Sources

This set should be operated only from the type of
power source indicated on the marking label. If
you are not sure of the type of electrical power
supplied to your home, consult your dealer or
local power company. For those sets designed to
operate from battery power, or other sources, refer
to the operating instructions.

[ Polarization

This set may be equipped with a polarized ac
power cord plug (a plug having one blade wider
than the other).

This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit, contact
your electrician to have a suitable outlet installed.
Do not defeat the safety purpose of the polarized
plug by forcing it in.

[ Overloading

Do not overload wall outlets, extension cords or
convenience receptacles beyond their capacity,
since this can result in fire or electric shock.

[ Object and Liquid Entry

Never push objects of any kind into the set
through openings as they may touch dangerous
voltage points or short out parts that could result
in a fire or electric shock. Never spill liquid of any
kind on the set.

[ Attachments

Do not use attachments not recommended by the
manufacturer, as they may cause hazards.

2

[ Cleaning

Unplug the set from the wall outlet before
cleaning or polishing it. Do not use liquid cleaners
or aerosol cleaners. Use a cloth lightly dampened
with water for cleaning the exterior of the set.

Installation

[ Water and Moisture

Do not use power-line operated sets near water –
for example, near a bathtub, washbowl, kitchen
sink, or laundry tub, in a wet basement, or near a
swimming pool, etc.

[ Power-Cord Protection

Route the power cord so that it is not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to the
plugs, receptacles, and the point where the cord
exits from the appliance.

[ Accessories

Do not place the set on an unstable cart, stand,
tripod, bracket, or table. The set may fall, causing
serious injury to a child or an adult, and serious
damage to the set. Use only a cart, stand, tripod,
bracket, or table recommended by the
manufacturer.

[ Ventilation

The slots and openings in the cabinet are provided
for necessary ventilation. To ensure reliable
operation of the set, and to protect it from
overheating, these slots and openings must never
be blocked or covered.

–Never cover the slots and openings with a cloth

or other materials.

–Never block the slots and openings by placing

the set on a bed, sofa, rug, or other similar
surface.

–Never place the set in a confined space, such as a

bookcase, or built-in cabinet, unless proper
ventilation is provided.

–Do not place the set near or over a radiator or

heat register, or where it is exposed to direct
sunlight.

[ Lightning

For added protection for this set during a lightning
storm, or when it is left unattended and unused for

long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system.
This will prevent damage to the set due to
lightning and power-line surges.

Service

[ Damage Requiring Service

Unplug the set from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:

–When the power cord or plug is damaged or

frayed.

–If liquid has been spilled or objects have fallen

into the set.
–If the set has been exposed to rain or water.
–If the set has been subject to excessive shock by

being dropped, or the cabinet has been damaged.
–If the set does not operate normally when

following the operating instructions. Adjust only

those controls that are specified in the operating

instructions. Improper adjustment of other

controls may result in damage and will often

require extensive work by a qualified technician

to restore the set to normal operation.
–When the set exhibits a distinct change in

performance – this indicates a need for service.

[ Servicing

Do not attempt to service the set yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

[ Replacement parts

When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer that have the same
characteristics as the original parts.

Unauthorized substitutions may result in fire,
electric shock, or other hazards.

[ Safety Check

Upon completion of any service or repairs to the
set, ask the service technician to perform routine
safety checks (as specified by the manufacturer)
to determine that the set is in safe operating
condition.

3

Read this first

CAUTION

Replace the battery with the specified type
only. Otherwise, fire or injury may result.

For Customers in the U.S.A. and
Canada

[ RECYCLING LITHIUM-ION

BATTERIES

Lithium-Ion batteries are
recyclable.

You can help preserve our
environment by returning your
used rechargeable batteries to
the collection and recycling
location nearest you.

For more information regarding recycling of
rechargeable batteries, call toll free
1-800-822-8837, or visit http://www.rbrc.org/

Caution: Do not handle damaged or leaking
Lithium-Ion batteries.

Battery charger

This power unit is intended to be correctly
orientated in a vertical or floor mount position.

For Customers in the U.S.A.

If you have any questions about this product, you
may call:

Sony Customer Information Center
1-800-222-SONY (7669)

The number below is for the FCC related matters
only.

[ Regulatory Information

Declaration of Conformity

Trade Name: SONY
Model No.: DSC-W80, DSC-W85
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo,

San Diego, CA 92127U.S.A.

Telephone No.: 858-942-2230

This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.

Declaration of Conformity

Trade Name: SONY
Model No.: DSC-W90
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo,

San Diego, CA 92127U.S.A.

Telephone No.: 858-942-2230

This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.

4

[ CAUTION

You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.

[ Note:

This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the
receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

The supplied interface cable m ust be used with the
equipment in order to comply with the limits for a
digital device pursuant to Subpart B of Part 15 of
FCC Rules.

For the State of California, USA
only

Perchlorate Material - special handling may apply,
See

www.dtsc.ca.gov/hazardouswaste/perchlorate

Perchlorate Material: Lithium battery contains
perchlorate.

For Customers in Europe

This product has been tested and found compliant
with the limits set out in the EMC Directive for
using connection cables shorter than 3 meters (9.8
feet).

[ Attention

The electromagnetic fields at the specific
frequencies may influence the picture and sound
of this unit.

[ Notice

If static electricity or electromagnetism causes
data transfer to discontinue midway (fail), restart
the application or disconnect and connect the
communication cable (USB, etc.) again.

[ Disposal of Old Electrical &

Electronic Equipment (Applicable

in the European Union and other

European countries with separate

collection systems)

This symbol on the product or on its packaging
indicates that this product shall not be treated as
household waste. Instead it shall be handed over
to the applicable collection point for the recycling
of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product. The recycling of
materials will help to conserve natural resources.
For more detailed information about recycling of
this product, please contact your local Civic
Office, your household waste disposal service or
the shop where you purchased the product.

5

Notice for customers in the
United Kingdom

A moulded plug complying with BS 1363 is fitted
to this equipment for your safety and convenience.

Should the fuse in the plug supplied need to be
replaced, a fuse of the same rating as the supplied
one and approved by ASTA or BSI to BS 1362,
(i.e., marked with an or mark) must be
used.

If the plug supplied with this equipment has a
detachable fuse cover, be sure to attach the fuse
cover after you change the fuse. Never use the
plug without the fuse cover. If you should lose the
fuse cover, please contact your nearest Sony
service station.

6

Table of contents

IMPORTANT SAFEGUARDS ..................................................................... 2

Read this first ............................................................................................ 4

Notes on using your camera .................................................................... 8

Getting started ................................................................................. 9

Checking the accessories supplied ......................................................... 9

1 Preparing the battery pack .................................................................. 10

2 Inserting the battery pack/a “Memory Stick Duo” (not supplied) ........ 11

3 Turning the camera on/setting the clock ............................................. 13

Shooting images easily ................................................................. 14

Mode dial/Zoom/Flash/Macro/Self-timer/Display ................................... 15

Viewing/deleting images ............................................................... 16

Learning the various functions – HOME/Menu ........................... 18

Using the HOME screen ......................................................................... 18

HOME items ........................................................................................... 19

Using menu items ................................................................................... 20

Menu items ............................................................................................. 21

Enjoying your computer ...............................................................22

Supported Operating Systems for USB connection and application

software (supplied) ................................................................................. 22

Viewing “Cyber-shot Handbook” and “Cyber-shot Step-up Guide” ....... 23

Indicators on the screen ...............................................................24

Battery life and memory capacity ................................................ 26

Battery life and number of images that can be recorded/viewed .......... 26

Number of still images and recording time of movies ............................ 27

Troubleshooting ............................................................................. 28

Battery pack and power ......................................................................... 28

Shooting still images/movies .................................................................. 29

Viewing images ...................................................................................... 29

Precautions .................................................................................... 30

Specifications ................................................................................31

7

Notes on using your camera

[ Internal memory and “Memory

Stick Duo” back up

Do not turn off the camera or remove the
battery pack or “Memory Stick Duo” while
the access lamp is lighted, as the internal
memory data or “Memory Stick Duo” data
may be destroyed. Always protect your data
by making a back up copy.

[ Notes on recording/playback

• Before you start recording, make a trial
recording to make sure that the camera is
working correctly.

• This camera is neither dust-proof, nor splash­proof, nor water-proof. Read “Precautions”
(page 30) before operating the camera.

• Be careful not to get the camera wet. Water
entering the inside of the camera may cause
malfunctions which in some cases may not be
repairable.

• Do not aim the camera at the sun or other bright
light. It may cause the malfunction of your
camera.

• Do not use the camera near a location that
generates strong radio waves or emits radiation.
The camera may not be able to record or play
back properly.

• Using the camera in sandy or dusty locations
may cause malfunctions.

• If moisture condensation occurs, remove it
before using the camera (page 30).

• Do not shake or strike the camera. In addition to
malfunctions and an inability to record images,
this may render the recording medium unusable,
or cause image data breakdown, damage or loss.

• Clean the flash surface before use. The heat of
flash emission may cause dirt on the flash
surface to become discolored or to stick to the
flash surface, resulting in insufficient light
emission.

[ Notes on the LCD screen

• The LCD screen is manufactured using
extremely high-precision technology so over

99.99% of the pixels are operational for
effective use. However, there may be some tiny
black points and/or bright points (white, red,
blue or green in color) that constantly appear on
the LCD screen. These points are normal in the
manufacturing process and do not affect the
recording in any way.

• When the battery level becomes low, the lens
might stop moving. Insert a charged battery
pack and turn on the camera again.

[ On image data compatibility

• This camera conforms with DCF (Design rule
for Camera File system) universal standard
established by JEITA (Japan Electronics and
Information Technology Industries
Association).

• Playback of images recorded with your camera
on other equipment and playback of images
recorded or edited with other equipment on your
camera are not guaranteed.

[ Warning on copyright

Television programs, films, videotapes, and other
materials may be copyrighted. Unauthorized
recording of such materials may be contrary to the
provisions of the copyright laws.

[ No compensation for contents of

the recording

The contents of the recording cannot be
compensated for if recording or playback is
not possible due to a malfunction of your
camera or recording media, etc.

8

Getting started

Checking the accessories supplied

• Battery charger BC-CSG/BC-CSGB/
BC-CSGC (1)

• Power cord (mains lead) (1)
(not supplied in the USA and Canada)

• Rechargeable battery pack NP-BG1 (1)/
Battery case (1)

• USB, A/V cable for multi-use terminal (1)

Attach the strap and place your hand
through the loop to prevent the camera
from damage by being dropped, etc.

•Strap
Wrist strap (1) (DSC-W80/W90)

Neck strap (1) (DSC-W85)

• Soft carrying case (1) (DSC-W85 only)

• CD-ROM (Cyber-shot application software/
“Cyber-shot Handbook”/“Cyber-shot Step-up
Guide”) (1)

• Instruction Manual (this manual) (1)

Hook

9

1 Preparing the battery pack

For customers in the USA and
Canada

Plug

ɟ

CHARGE lamp

For customers other than those in the USA and
Canada

ɟ

CHARGE lamp

Power cord (mains lead)

1Insert the battery pack into the battery charger.

2Connect the battery charger to the wall outlet (wall socket).

The CHARGE lamp lights on, and charging starts.
When the CHARGE lamp turns off, charging is finished (Practical charge).
If you continue charging the battery pack for about one more hour (until it is fully charged), the charge

will last slightly longer.

[ Charging time

Full charge time Practical charge time

Approx. 330 min. Approx. 270 min.

• Time required to charge a fully depleted battery pack at a temperature of 25°C (77°F). Charging may take
longer under certain circumstances or conditions.

• See page 26 for the number of images that can be recorded.

• Connect the battery charger to an easily accessible wall outlet (wall socket) close by.

• Even if the CHARGE lamp is not lit, the battery charger is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet (wall socket). If some trouble occurs while using the
battery charger, immediately shut off the power by disconnecting the plug from the wall outlet (wall
socket).

• When charging is finished, disconnect the power cord (mains lead) from the wall outlet (wall socket), and
remove the battery pack from the battery charger.

• Designed for use with compatible Sony batteries.

10

2 Inserting the battery pack/a “Memory Stick Duo” (not

supplied)

ɟ ɠ

Insert the “Memory Stick
Duo” with the terminal side

Battery/“Memory Stick
Duo” cover

facing the LCD screen.

1Open the battery/“Memory Stick Duo” cover.

2Insert the “Memory Stick Duo” (not supplied) all the way in until it clicks.

3Insert the battery pack.

4Close the battery/“Memory Stick Duo” cover.

[ When there is no “Memory Stick Duo” inserted

The camera records/plays back images using the internal memory (approx. 31 MB).

[ To check the remaining battery time

Press POWER button to turn on and check the remaining battery on the LCD screen.

Battery
remaining
indicator

Battery
remaining
guidelines

Sufficient
power
remaining

Battery
almost fully
charged

Battery half
full

Battery low,
recording/
playback
will stop
soon.

Insert the battery
pack while pressing
the battery eject
lever with the tip of
the battery pack.

Change the battery
with fully charged
one, or charge the
battery. (The warning
indicator flashes.)

• It takes about one minute until the correct battery remaining indicator appears.

• The displayed battery remaining indicator may not be correct under certain circumstances.

• The Clock Set screen appears when the camera is turned on for the first time (page 13).

11

[ To remove the battery pack/“Memory Stick Duo”

Open the battery/“Memory Stick Duo” cover.

Battery pack“Memory Stick Duo”

Make sure that the access
lamp is not lit, then push the

“Memory Stick Duo” in once.

• Never remove the battery pack/“Memory Stick Duo” when the access lamp is lit. This may cause damage
to data in the “Memory Stick Duo”.

Slide the battery eject lever.
Be sure not to drop the
battery pack.

12

3 Turning the camera on/setting the clock

POWER button

(Playback) button

1

z button

ɟ

Control button

HOME button

1Press the POWER button or press (Playback) button.

2Set the clock with the control button.

1 Select the date display format with v/V, then press z.
2 Select each item with b/B and set the numeric value with v/V, then press z.
3 Select [OK], then press z.

[ To change the date and time

Press the HOME button, and select [ Clock Settings] in (Settings) (pages 18, 19).

[ When you turn on the power

• Once the battery is inserted in the camera, it may take time before operation becomes

possible.

• If the camera is running on battery power and you do not operate the camera for about three

minutes, the camera turns off automatically to prevent wearing down the battery pack (Auto
power-off function).

2
3

13

Shooting images easily

Finder

Microphone

HOME button

Tripod receptacle (bottom)

Shutter button

ɠ

W/T (Zoom) button

Mode dial

MENU button

Control button

1Select the desired function from the mode dial.

When shooting still images (Auto Adjustment mode):
When shooting movies: Select .

Select .

2Hold the camera steady, keeping your arm at your side.

Position the subject
in the center of the
focus frame.

3Shoot with the shutter button.

When shooting still images:

1 Press and hold the shutter button

halfway down to focus.

The z (AE/AF lock) indicator (green)
flashes, a beep sounds, the indicator stops
flashing and remains lit.

2 Press the shutter button fully down.

AE/AF lock indicator

When shooting movies:

Press the shutter button fully down.
To stop recording, press the shutter button fully down again.

Macro button

DISP button

Flash button

Self-timer button

14

Mode dial/Zoom/Flash/Macro/Self-timer/Display

[ Using the mode dial

Set the mode dial to the desired function.

Auto Adjustment

Allows easy shooting with the settings
adjusted automatically.

Program Auto

Allows you to shoot with the exposure
adjusted automatically (both the shutter speed
and the aperture value). Also you can select
various setting using the menu.

Movie mode

Allows you to record movies with audio.

High Sensitivity

Shoot images without a flash even in low
lighting.

Soft Snap

Shoot images with a softer atmosphere for
portraits of people, flowers, etc.

Twilight Portrait

Shoot sharp images of people in a dark place
without losing the nighttime atmosphere.

Twilight

Shoot night scenes without losing the
nighttime atmosphere.

Landscape

Shoot with the focus on a distant subject.

Beach

Shoot seaside or lakeside scenes with the
blueness of the water captured more vividly.

Snow

Shoot snow scenes in white more clearly.

[ W/T Using the zoom

Press T to zoom, press W to undo zoom.

[ Flash (Selecting a flash mode

for still images)

Press B ( ) on the control button repeatedly
until the desired mode is selected.

: Flash Auto

Strobes when there is insufficient light or
backlight (default setting)

: Flash forced on

: Slow synchro (Flash forced on)

The shutter speed is slow in a dark place to
clearly shoot the background that is out of
flash light.

: Flash forced off

[ Macro (Shooting close-up)

Press b ( ) on the control button
repeatedly until the desired mode is
selected.

: Macro off

: Macro on (W side: Approx. 4 cm or farther

(1 5/8 inches or farther), T side: Approx. 35 cm or
farther (13 7/8 inches or farther))

[ Using the self-timer

Press V ( ) on the control button
repeatedly until the desired mode is
selected.

: Not using the self-timer

: Setting the 10-second delay self-timer

: Setting the 2-second delay self-timer

Press the shutter button, the self-timer lamp
flashes, and a beep sounds until the shutter
operates.

Self-timer lamp

[ DISP Changing the screen

display

Press v (DISP) on the control button.
Each time you press v (DISP) button, the
display changes as follows.

Brightness of LCD backlight up

r

Histogram on

r

Indicators off

r

LCD screen off

r

Indicators on

15

Viewing/deleting images

ɟ

(playback zoom)/ (Index) button

(playback zoom)

button

(Playback)

MENU button

HOME button

Multi connector (bottom)

Speaker (bottom)

1Press (Playback) button.

If you press when the camera is powered off, the camera is turned on automatically and set to
playback mode. To switch to the shooting mode, press again.

2Select an image with b/B on the control button.

Movie:

Press z to play back a movie. (Press z again to stop playback.)
Press B to fast forward, b to rewind. (Press z to return to normal playback.)
Press V to display the volume control screen, then press b/B to adjust the volume.

[ To delete images

1 Display the image you want to delete, then press MENU.
2 Select [Delete] with v and select [This Image] with b/B, then press z.
3 Select [OK] with v, then press z.

button

Control button

[ To view an enlarged image (playback zoom)

Press while displaying a still image.
To undo the zoom, press .
Adjust the position: v/V/b/B
Cancel playback zoom: z

16

[ Viewing an index screen

Press (Index) button to display the index screen while a still image is displayed.
Then, select an image with v/V/b/B.
To return to the single image screen, press z.

• You can also access the index screen by selecting [ Index Display] in (View Images) on the
HOME screen.

• Each time you press (Index), the number of pictures on the index screen changes.

[ To delete images in index mode

1 Press MENU while the index screen is displayed.
2 Select [Delete] with v and select [Multiple Images] with b/B, then press z.
3 Select the image you want to delete with v/V/b/B, then press z.

mark is checked in the checkbox of the image.

To cancel a selection, select an image you have selected for deletion, then press z again.

4 Press MENU and select [OK] with v, then press z.

• To delete all the images in a folder, select [All In This Folder], then press z in step 2.

[ To play back a series of images (Slide Show)

Select [ Slide Show] in (View Images) on the HOME screen, and then select [Start]
with v, then press z.

[ To view images on TV screen

Connect the camera to the TV with the cable for multi-use terminal (supplied).

To the multi connector

Cable for multi-use terminal

To audio/video input jacks

17

Learning the various functions – HOME/Menu

Using the HOME screen

The HOME screen is the gateway screen for all the functions of your camera.
You can select the shooting mode or playback mode, or change the settings from the HOME
screen.

Control button

HOME button

z button

1Press HOME to display the HOME screen.

Category

Item

Guide

2 Select a category with b/B on the control button.

3 Select an item with v/V, then press z.

[ When you select the (Manage Memory) or (Settings) category

1 Select the desired item with v/V on the control button.

• This is functional only when you select (Settings).

2 Move to the right with B, select a setting with v/V, then press z.
3 Select a setting with v/V, then press z.

• The camera is set to the shooting mode by pressing the shutter button halfway down.

18

For details on the operation 1 page 18

HOME items

Press HOME button displays the following items. Details on the items are displayed on the
screen by the guide.

Category Items

Shooting

View Images

Printing, Other

Manage Memory

Settings

Shooting

Single Image

Index Display

Slide Show

Print

Music Tool

Download Music Format Music

Memory Tool

Memory Stick Tool

Format Create REC. Folder
Change REC. Folder Copy

Internal Memory Tool

Format

Main Settings

Main Settings 1

Beep Function Guide
Initialize

Main Settings 2

USB Connect COMPONENT
Video Out

Shooting Settings

Shooting Settings 1

AF Illuminator Grid Line
AF Mode Digital Zoom

Shooting Settings 2

Auto Orientation Auto Review

Clock Settings

Language Setting

19

Using menu items

MENU button

ɟ

Control button

Press MENU to display the menu.

1

Function Guide

• The menu will be displayed only during shooting and playback mode.

• Different items will become visible depending on the selected mode.

2Select the desired item with v/V on the control button.

• If the desired item is hidden, keep pressing v/V until the item appears on the screen.

3Select the desired setting with b/B on the control button.

z button

• If the desired item is hidden, keep pressing b/B until the item appears on the screen.

• Press z after selecting an item in playback mode.

4Press MENU to turn off the menu.

20

For details on the operation 1 page 20

Menu items

The available menu items vary depending on the camera mode.
The shooting menu is available only in the shooting mode, and the viewing menu is available
only in the playback mode.
Also, the menu items available vary depending on the mode dial position. Only the available
items are displayed on the screen.

Menu for shooting

Image Size Selects the still image size.

Face Detection Detects the faces of your subjects and adjusts focus, etc.

REC Mode Selects the continuous shooting method.

Color Mode Changes the vividness of the image or adds special effects.

ISO Selects a luminous sensitivity.

EV Adjusts Exposure.

Metering Mode Selects the metering mode.

Focus Changes the focus method.

White Bal Adjusts the color tones.

Flash Level Adjusts the amount of flash light.

Red Eye Reduction Sets to reduce the red-eye phenomenon.

SteadyShot Selects the anti-blur mode.

SETUP Selects shooting settings.

Menu for viewing

(Delete) Deletes images.

(Slide Show) Plays back a series of images.

(Retouch) Retouches images.

(Protect) Prevents accidental erasure.

Adds a Print order mark on image that you want to print out.

(Print) Prints images using a PictBridge compliant printer.

(Rotate) Rotates a still image.

(Select Folder) Selects the folder for viewing images.

21

Enjoying your computer

You can display images shot with the camera on the computer. Also, you can use still images
and movies from the camera more than ever by taking advantage of the software. For details,
refer to “Cyber-shot Handbook”.

Supported Operating Systems for USB connection and application software (supplied)

For Windows users For Macintosh users

USB connection

Application software
“Picture Motion
Browser”

*64-bit editions and Starter (Edition) are not supported.

• Must be installed with above OS at delivery.

• If your OS does not support USB connections, use a commercially available Memory Stick Reader/Writer.

• For further details on the operating environment of “Picture Motion Browser” Cyber-shot application
software, refer to “Cyber-shot Handbook”.

Windows 2000 Professional,
Windows XP*,
Windows Vista*

Windows 2000 Professional,
Windows XP*,
Windows Vista*

Mac OS 9.1/9.2/ Mac OS X(v10.1
to v10.4)

not compatible

22

Viewing “Cyber-shot Handbook” and “Cyber-shot Step-up Guide”

[ For Windows users

1 Turn on your computer, and insert the CD-

ROM (supplied) into the CD-ROM drive.

The screen below appears.

When you click the [Cyber-shot Handbook]
button, the screen for copying “Cyber-shot
Handbook” appears.

2 Follow the on-screen instructions to copy.

When you click the “Cyber-shot Handbook”
button, the both of the “Cyber-shot
Handbook” and the “Cyber-shot Step-up
Guide” will be installed.

3 After the installation is complete, double-

click the shortcut created on the desktop.

[ For Macintosh users

Turn on your computer, and insert the CD­ROM (supplied) into the CD-ROM drive.
Follow the instructions below.

To view the “Cyber-shot Handbook”

1 Select the [Handbook] folder and copy

“Handbook.pdf” stored in the [GB] folder
to your computer.

2 After copying is complete, double-click

“Handbook.pdf”.

To view the “Cyber-shot Step-up Guide”

1 Copy the [stepupguide] folder in the

[stepupguide] folder to your computer.

2 Select [stepupguide], [language] and then

[GB] folder stored in the CD-ROM and
copy all the files in the [GB] folder, then
write over them to the files in the [img]
folder stored in [stepupguide] which is
copied to your computer in the step 1.

3 After copying is completed, double-click

“stepupguide.hqx” in the [stepupguide]
folder to uncompress it, then double-click
the generated file “stepupguide”.

• If an uncompress tool for HQX file is not
installed, install the Stuffit Expander.

23

Indicators on the screen

Each time you press v (DISP) button, the
display changes (page 15).

[ When shooting still images

[ When shooting movies

[ When playing back

A

Battery remaining

E

Recording mode

Metering mode

SteadyShot

Self-timer

VOL. Vo l u me

Low battery warning

Image size

• 8M ( ) is displayed only
for the DSC-W90.

• 7M ( ) is displayed only
for the DSC-W80/W85.

Mode dial (Scene
Selection)

Mode dial (Program)

White balance

Face Detection

Vibration warning

Zoom scaling

Color mode

PictBridge connecting

Protect

Print order (DPOF) mark

Zoom scaling

PictBridge connecting

24

BC

1.0m Focus preset distance

z AE/AF lock

ISO400

ISO number

NR slow shutter

125

F3.5

+2.0EV

Shutter speed

Aperture value

Exposure Value

AF range finder frame

indicator

Macro

N Playback

Playback bar

Standby
REC

00:00:12

Standby/Recording a movie

Counter

Histogram

• appears when histogram
display is disabled.

101-0012

2007 1 1
9:30 AM

z STOP
z PLAY

Folder-file number

Recorded date/time of the
playback image

Function guide for playing

BACK/NEXT Select images

V VOLUME Adjust volume

Recording/playback Media

Recording folder

Playback folder

96

Remaining number of
recordable images

12/12

Image number/Number of
images recorded in selected
folder

00:00:00 Remaining recordable time

Change folder

AF illuminator

Red-eye reduction

Metering mode

Flash mode

Flash charging

White balance

C:32:00

Self-diagnosis display

ISO400 ISO number

+2.0EV

500

F3.5

Exposure Value

Shutter speed

Aperture value

D

C:32:00

Self-diagnosis display

Self-timer

AF range finder frame

+

Spot metering cross hair

Histogram

25

Battery life and memory capacity

Battery life and number of images that can be recorded/viewed

The tables show the approximate number of
images that can be recorded/viewed and the
battery life when you shoot images in
[Normal] mode with the battery pack
(supplied) at full capacity and at an ambient
temperature of 25°C (77°F). The numbers
of images that can be recorded or viewed
take into account changing the “Memory
Stick Duo” as necessary.
Note that the actual numbers may be less
than those indicated in the table depending
on the conditions of use.

• Battery capacity decreases as you use it more, as
the time passes.

• The number of images that can be recorded/
viewed and the battery life are decreased under
the following conditions:

– The surrounding temperature is low.
– The flash is used frequently.
– The camera has been turned on and off many

times.
– The zoom is used frequently.
– The brightness of LCD Backlight is set to up.
– [AF Mode] is set to [Monitor].
– [SteadyShot] is set to [Continuous].
– The battery power is low.
– [Face Detection] is set to [On].

[ When shooting still images

LCD

screen

DSC-W90

DSC-W80/W85

• Shooting in the following situations:
– [AF Mode] is set to [Single].
– [SteadyShot] is set to [Shooting].
– Shooting once every 30 seconds.

No. of Images Battery life (min.)

On Approx. 350 Approx. 175

Off Approx. 410 Approx. 205

On Approx. 340 Approx. 170

Off Approx. 400 Approx. 200

– The zoom is switched alternately between the

W and T ends.
– The flash strobes once every two times.
– The power turns on and off once every ten

times.

• The measurement method is based on the CIPA
standard.

(CIPA: Camera & Imaging Products
Association)

• The number of images/battery life does not
change, regardless of image size.

[ When viewing still images

No. of Images Battery life (min.)

DSC-W90

Approx. 7000 Approx. 350

DSC-W80/W85

Approx. 7000 Approx. 350

• Viewing single images in order at about three
second intervals

[ When shooting movies

LCD screen ON (min.) LCD screen OFF (min.)

DSC-W90

Approx. 150 Approx. 170

DSC-W80/W85

Approx. 140 Approx. 160

• Shooting movies continuously with an image
size of [320]

26

Number of still images and recording time of movies

The number of still images and the length of time for movies may vary depending on the
shooting conditions.

• You can select the image size to be used when shooting from the menu (pages 20, 21).

[ The approximate number of still images

(Units: Images)

Capacity

Size

Internal

memory

Approx.

31 MB

128 MB 256 MB 512 MB 1GB 2GB 4GB 8GB

8M (DSC-W90) 10 40 72 148 302 620 1225 2457

3:2 (DSC-W90) 10 40 72 148 302 620 1225 2457

7M (DSC-W80/

10 41 74 151 308 633 1250 2508

W85)

3:2 (DSC-W80/

10 41 74 151 308 633 1250 2508

W85)

5M 13 51 92 188 384 789 1559 3127

3M 21 82 148 302 617 1266 2501 5017

VGA 202 790 1428 2904 5928 12154 24014 48166

16:9 33 133 238 484 988 2025 4002 8027

• The number of images listed is for when [REC Mode] is set to [Normal].

• When the number of remaining shootable images is greater than 9,999, the “>9999” indicator appears.

• When images recorded using earlier Sony models are played back on this camera, the display may differ
from the actual image size.

[ The approximate recording time of movies

Capacity

Size

640(Fine) – – 0:02:50 0:06:00 0:12:20 0:25:10 0:50:00 1:40:20

640(Standard) 0:01:30 0:05:50 0:10:40 0:21:40 0:44:20 1:31:00 3:00:00 6:01:10

320 0:06:00 0:23:40 0:42:50 1:27:00 2:57:50 6:04:30 12:00:20 24:04:50

Internal

memory

Approx.

31 MB

128 MB 256 MB 512 MB 1GB 2GB 4GB 8GB

“Memory Stick Duo” formatted with this camera

(Units: hour : minute : second)

“Memory Stick Duo” formatted with this camera

• Movies with the size set to [640(Fine)] can only be recorded on a “Memory Stick PRO Duo”.

• The size of a movie file is limited to approx. 2 GB. During recording, movie recording stops automatically
when the file size of the movie reaches approx. 2 GB.

• This camera does not support HD recordings or playbacks for movies.

27

Troubleshooting

If you experience trouble with your camera, try the following solutions.

1 Check the items below, and refer to “Cyber-shot Handbook” (PDF).

If a code such as “C/E:ss:ss” appears on the screen, refer to “Cyber-shot
Handbook”.

2 Remove the battery pack, and insert the battery pack again after about one

minute, and turn on the power.

3 Initialize the settings (page 19).

4 Consult your Sony dealer or local authorized Sony service facility.

Please understand that you give your consent that the contents of the internal memory, Music
files may be checked when you send your camera to be repaired.

Battery pack and power

The battery pack cannot be inserted.

• Insert the battery pack correctly to push the battery eject lever (page 11).

Cannot turn on the camera.

• After installing the battery pack into the camera, it may take a little while to get the camera

powered.

• Insert the battery pack correctly (page 11).

• The battery pack is discharged. Insert charged battery pack (page 10).

• The battery pack is dead. Replace it with a new one.

• Use a recommended battery pack (page 9).

The power turns off suddenly.

• If you do not operate the camera for about three minutes while the power is on, the camera

turns off automatically to prevent wearing down the battery pack. Turn on the camera again
(page 13).

• The battery pack is dead. Replace it with a new one.

28

The battery remaining indicator is incorrect.

• This phenomenon occurs when you use the camera in an extremely hot or cold location.

• The displayed battery remaining differs from the current one. Fully discharge and then charge

the battery pack to correct the display.

• The battery pack is discharged. Insert the charged battery pack (page 10).

• The battery pack is dead. Replace it with a new one.

Cannot charge the battery pack.

• You cannot charge the battery pack using the AC Adaptor (not supplied).

Shooting still images/movies

Your camera cannot record images.

• Check the free capacity of the internal memory or “Memory Stick Duo” (page 27). If it is full,

do one of the following:

– Delete unnecessary images (page 16).
– Change the “Memory Stick Duo”.

• You are using the “Memory Stick Duo” with the write-protect switch, and the switch is set to

the LOCK position. Set the switch to the recording position.

• You cannot record images while charging the flash.

• When shooting a still image, set the mode dial to a position other than .

• Set the mode dial to when shooting movies.

• The image size is set to [640(Fine)] when recording movies. Do one of the following:
– Set the image size to other than [640(Fine)].
– Insert a “Memory Stick PRO Duo”.

Cannot insert dates on images.

• This camera does not have a feature for superimposing dates on images. By using “Picture

Motion Browser”, you can print or save images with the date.

Vertical streaks appear when you are shooting a very bright subject.

• The smear phenomenon is occurring and white, black, red, or purple streaks appear on the

image. This phenomenon is not a malfunction.

Viewing images

Your camera cannot play back images.

• Press (Playback) button (page 16).

• The folder/file name has been changed on your computer.

• When an image file has been processed by a computer or when the image file was recorded

using a model other than that of your camera, playback on your camera is not guaranteed.

• The camera is in USB mode. Delete the USB connection.

29

Precautions

[ Do not use/store the camera in

the following places

• In an extremely hot, cold or humid place
In places such as in a car parked in the sun, the

camera body may become deformed and this
may cause a malfunction.

• Under direct sunlight or near a heater
The camera body may become discolored or

deformed, and this may cause a malfunction.

• In a location subject to rocking vibration

• Near strong magnetic place

• In sandy or dusty places
Be careful not to let sand or dust get into the

camera. This may cause the camera to
malfunction, and in some cases this malfunction
cannot be repaired.

[ On carrying

Do not sit down in a chair or other place with the
camera in the back pocket of your trousers or
skirt, as this may cause malfunction or damage the
camera.

[ On cleaning

Cleaning the LCD screen

Wipe the screen surface with an LCD cleaning kit
(not supplied) to remove fingerprints, dust, etc.

Cleaning the lens

Wipe the lens with a soft cloth to remove
fingerprints, dust, etc.

Cleaning the camera surface

Clean the camera surface with a soft cloth slightly
moistened with water, then wipe the surface with
a dry cloth. Do not use the following as they may
damage the finish or the casing.

• Chemical products such as thinner, benzine,

alcohol, disposable cloths, insect repellent,
sunscreen or insecticide, etc.

• Do not touch the camera with the above on your

hand.

• Do not leave the camera in contact with rubber

or vinyl for a long time.

[ On operating temperatures

Your camera is designed for use under the
temperatures between 0°C and 40°C (32°F and
104°F). Shooting in extremely cold or hot places
that exceed this range is not recommended.

[ On moisture condensation

If the camera is brought directly from a cold to a
warm location, moisture may condense inside or
outside the camera. This moisture condensation
may cause a malfunction of the camera.

If moisture condensation occurs

Turn off the camera and wait about an hour for the
moisture to evaporate. Note that if you attempt to
shoot with moisture remaining inside the lens, you
will be unable to record clear images.

[ On the internal rechargeable

backup battery

This camera has an internal rechargeable battery
for maintaining the date and time and other
settings regardless of whether the power is on or
off.

This rechargeable battery is continually charged
as long as you are using the camera. However, if
you use the camera for only short periods, it
discharges gradually, and if you do not use the
camera at all for about one month it becomes
completely discharged. In this case, be sure to
charge this rechargeable battery before using the
camera.

However, even if this rechargeable battery is not
charged, you can still use the camera as long as
you do not record the date and time.

Charging method of the internal
rechargeable backup battery

Insert charged battery pack in the camera, and
then leave the camera for 24 hours or more with
the power off.

30

Specifications

Camera

[System]

Image device:

DSC-W90:

7.18 mm (1/2.5 type) color CCD,
Primary color filter

DSC-W80/W85:

7.20 mm (1/2.5 type) color CCD,
Primary color filter

Total pixel number of camera:

DSC-W90:

Approx. 8 286 000 pixels

DSC-W80/W85:

Approx. 7 410 000 pixels

Effective pixel number of camera:

DSC-W90:

Approx. 8 083 000 pixels

DSC-W80/W85:

Approx. 7 201 000 pixels

Lens: Carl Zeiss Vario-Tessar 3× zoom lens f =

5.8 – 17.4 mm (35 – 105 mm when converted
to a 35 mm still camera) F2.8 – 5.2

Exposure control: Automatic exposure, Scene

Selection (7 modes)

White balance: Automatic, Daylight, Cloudy,

Fluorescent 1,2,3, Incandescent, Flash

File format (DCF compliant):

Still images: Exif Ver. 2.21 JPEG compliant,
DPOF compatible
Movies: MPEG1 compliant (Monaural)

Recording media: Internal Memory (approx.

31 MB), “Memory Stick Duo”

Flash:Flash range (ISO sensitivity

(Recommended exposure Index) set to Auto):
approx. 0.2 to 3.3 m (7 7/8 inches to 10 feet
10 inches) (W)/approx. 0.4 to 1.8 m (1 feet
3 3/4 inches to 5 feet 10 7/8 inches) (T)

[Input and Output connectors]

Multi connector Video output

USB communication: Hi-Speed USB (USB 2.0

compliant)

Audio output (Monaural)
USB communication

[LCD screen]

LCD panel: 6.2 cm (2.5 type) TFT drive
Total number of dots: 115 200 (480 × 240) dots

[Power, general]

Power: Rechargeable battery pack NP-BG1, 3.6 V

AC-LS5K AC Adaptor (not supplied), 4.2 V

Power consumption (during shooting with the

LCD screen on):

DSC-W90:

1.1 W

DSC-W80/W85:

1.1 W
Operating temperature: 0 to 40°C (32 to 104°F)
Storage temperature: –20 to +60°C (–4 to +140°F)
Dimensions: 91.0 × 58.0 × 22.9 mm (3 5/8 ×

2 3/8 × 29/32 inches) (W/H/D, excluding
protrusions)

Mass:

DSC-W90/W80:

Approx. 155 g (5.5 oz) (including NP­BG1 battery pack and strap, etc.)

DSC-W85:

Approx. 166 g (5.9 oz) (including NP-

BG1 battery pack and strap, etc.)
Microphone: Monaural
Speaker: Monaural
Exif Print: Compatible
PRINT Image Matching III: Compatible
PictBridge: Compatible

BC-CSG/BC-CSGB/BC-CSGC
battery charger

Power requirements: AC 100 V to 240 V,

50/60 Hz, 2 W (BC-CSG/BC-CSGC)/ 2.6 W

(BC-CSGB)
Output voltage: DC 4.2 V, 0.25 A
Operating temperature: 0 to 40°C (32 to 104°F)
Storage temperature: -20 to +60°C (–4 to

+140°F)
Dimensions: Approx. 62 × 24 × 91 mm (2 1/2 ×

31/32 × 3 5/8 inches) (W/H/D)
Mass: Approx. 75 g (2.7 oz)

Rechargeable battery pack NP­BG1

Used battery: Lithium-ion battery
Maximum voltage: DC 4.2 V
Nominal voltage: DC 3.6 V
Capacity: 3.4 Wh (960 mAh)

Design and specifications are subject to change
without notice.

31

Trademarks

• is a trademark of Sony
Corporation.

• “Memory Stick”, , “Memory Stick PRO”,

Duo”, , “Memory
Stick Micro”, “MagicGate”, and

Corporation.

• Microsoft, Windows, Windows Vista and
DirectX are either registered trademarks or
trademarks of Microsoft Corporation in the
United States and/or other countries.

• Macintosh, Mac OS, iMac, iBook, PowerBook,
Power Mac and eMac are trademarks or
registered trademarks of Apple Inc.

• Intel, MMX, and Pentium are trademarks or
registered trademarks of Intel Corporation.

• Google is a registered trademark of Google, Inc.

• In addition, system and product names used in
this manual are, in general, trademarks or
registered trademarks of their respective
developers or manufacturers. However, the ™ or

marks are not used in all cases in this manual.

®

, “Memory Stick Duo”,

, “Memory Stick PRO

are trademarks of Sony

32

Additional information on this product and answers

to frequently asked questions can be found at our

Customer Support Website.

Printed on 70% or more recycled paper using VOC
(Volatile Organic Compound)-free vegetable oil based
ink.

Printed in China
