Sony CUH100F1 Users Manual

Safety Guide

CUH-1115A

Guide de Sécurité

4-541-426-51(1)

WARNING

To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.

Caution
Use of controls or adjustments or performance of
procedures other than those specified herein
may result in hazardous radiation exposure.

The use of optical instruments with this product
will increase eye hazard.

This appliance is classified as a CLASS 1 LASER product under
IEC60825-1:2007.

FCC and IC notice

This equipment complies with FCC/IC radiation exposure
limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines and RSS-102
of the IC radio frequency (RF) Exposure rules. This equipment
should be installed and operated with at least 20 cm (8 in) and
more between the radiator and person's body (excluding
extremities: hands, wrists, feet and ankles).
This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.
The wireless controller complies with FCC/IC radiation
exposure limits set forth for uncontrolled environment and
meets the FCC radio frequency (RF) Exposure Guidelines and
RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment has very low levels of RF energy that are deemed
to comply without testing of specific absorption rate (SAR).

NOTE:

This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:

2

– Reorient or relocate the receiving antenna.

Declaration of Conformity

Trade Name : SONY
Model No. : CUH-1115A
Responsible Party : Sony Electronics Inc.
Address : 16530 Via Esprillo San Diego, CA

92127 U.S.A.
Telephone No. : 858-942-2230
This device complies with Part 15 of FCC Rules and Industry
Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference
that may cause undesired operation.

– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician

for help.

You are cautioned that any changes or modifications not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.

If you have questions about this product, visit
us.playstation.com/support or contact SCEA Consumer
Services at 1-800-345-7669. You can also write to:
Sony Computer Entertainment America LLC
Consumer Services/Technical Support
PO Box 5888, San Mateo, CA 94402-0888 U.S.A.

Photosensitivity/Epilepsy/Seizures

A very small percentage of individuals may experience
epileptic seizures or blackouts when exposed to certain light
patterns or flashing lights. Exposure to certain patterns or
backgrounds on a television screen or when playing video
games may trigger epileptic seizures or blackouts in these
individuals. These conditions may trigger previously
undetected epileptic symptoms or seizures in persons who
have no history of prior seizures or epilepsy. If you, or anyone
in your family, has an epileptic condition or has had seizures
of any kind, consult your doctor before playing.

IMMEDIATELY DISCONTINUE use and consult your doctor
before resuming gameplay if you or your child experience any
of the following health problems or symptoms:

• dizziness,

• altered vision,

• eye or muscle twitches,

• loss of awareness,

• disorientation,

EN

• seizures, or

• any involuntary movement or convulsion.

RESUME GAMEPLAY ONLY ON APPROVAL OF YOUR
DOCTOR.

Use and handling of video games to reduce the likelihood
of a seizure

• Use in a well-lit area and keep as far away as possible from
the television screen.

• Avoid large screen televisions. Use the smallest television
screen available.

3

• Avoid prolonged use of the PlayStation®4 system. Take a
15-minute break during each hour of play.

• Avoid playing when you are tired or need sleep.

3D images

Some people may experience discomfort (such as eye strain,
eye fatigue, or nausea) while watching 3D video images or
playing stereoscopic 3D games on 3D televisions. If you
experience such discomfort you should immediately
discontinue use of your television until the discomfort
subsides.
SCE recommends that all viewers take regular breaks while
watching 3D video, or playing stereoscopic 3D games. The
length and frequency of necessary breaks may vary from
person to person - please take breaks that are long enough to
allow any feelings of discomfort to subside. If symptoms
persist, consult your doctor.
The vision of young children (especially those under 6 years
old) is still under development. SCE recommends that you
consult with a doctor (such as a pediatrician or eye doctor)
before allowing a young child to watch 3D video images or
play stereoscopic 3D games. Adults should supervise young
children to ensure they follow the recommendations listed
above. When using any 3D enabled device with your PS4™
system you should read the instruction manual for that device
and check us.playstation.com/support/3D for updated
information.

• If you use a pacemaker or other medical device, consult
your doctor or the manufacturer of your medical device
before using the wireless networking feature (Bluetooth®
and wireless LAN).

• Do not use the wireless networking feature in the following
locations:

– Areas where wireless network use is prohibited, such as

in hospitals. Abide by medical institution regulations
when using the system on their premises.

– Areas near fire alarms, automatic doors and other types

of automated equipment.

About the lithium coin memory back-up battery

The lithium coin memory back-up battery inside this product
contains Perchlorate. The following statement is required by
the State of California, USA:
Perchlorate Material - special handling may apply. See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate

Radio waves

Radio waves may affect electronic equipment or medical
devices (for example, pacemakers), which may cause
malfunctions and possible injuries.

4

Contents

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

End of life product recycling . . . . . . . . . . . . . . . . . . . . . . . . . .13

LIMITED HARDWARE WARRANTY AND LIABILITY . . . . . . . . .14

Copyright and trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . 16

EN

5

Precautions

Before using this product, carefully read this manual and
retain it for future reference. Parents and guardians of
children should read this manual and make sure that the child
follows all safety precautions.

Safety

This product has been designed with the highest concern for
safety. However, any electrical device, if used improperly, has
the potential for causing fire, electrical shock or personal
injury. To help ensure accident-free operation, follow these
guidelines:

• Observe all warnings, precautions and instructions.

• Regularly inspect the AC power cord for damage.

• Stop use, unplug the AC power cord from the electrical
outlet and disconnect any other cables immediately if the
device functions in an abnormal manner, produces unusual
sounds or smells or becomes too hot to touch.

• Do not handle damaged or leaking lithium-ion batteries.

• Do not allow the battery to come into contact with fire or
subject it to extreme temperatures such as in direct
sunlight, in a vehicle exposed to the sun or near a heat
source.

• For more information on product safety and support, visit
our website ( back cover).

Use and handling

• Do not use the system in a closed cabinet or other locations
where heat may build up. Doing so may cause the system
to overheat and may lead to fire, injury or malfunction.

• If the system's internal temperature becomes elevated, the
power indicator will blink in red. In this case, turn off the
system and leave it unused for a while. After the system
cools down, move it to a location with good ventilation, and
then resume use.

• Use in a well-lit area and keep as far away as possible from
the television screen.

• Avoid prolonged use of the PS4™ system and wireless
controller.

• Stop using the system immediately if you begin to feel tired
or if you experience discomfort or pain in your hands or
arms while operating the wireless controller. If the
condition persists, consult a doctor.

• If you experience any of the following health problems,
discontinue use of the system immediately. If symptoms
persist, consult with your doctor.

– Dizziness, nausea, fatigue or symptoms similar to motion

sickness

– Discomfort or pain in a part of the body, such as eyes,

ears, hands or arms

• Keep the system, accessories, and any small components
out of the reach of small children.

• Any TV or component connected to the system must be
functioning properly and free of defects. If a TV or
component connected to the system is faulty or defective, it
may cause damage to the TV or component, or to the system
itself. As with all electrical products, connection to faulty or
defective components, or the failure to connect to a properly
wired outlet, may cause sparking and pose a fire hazard.

6

• Do not touch the system or connected cables or accessories
during an electrical storm.

• Do not use the system or accessories near water.

• Do not allow liquid, small particles or other foreign objects
to get into the system or accessories.

• Do not touch the connectors of the system or accessories.

• Do not expose the system or accessories to dust, smoke or
steam. Also, do not place the system in an area subject to
excessive dust or cigarette smoke. Dust build-up or
cigarette smoke residue on the internal components (such
as the lens) may cause the system to malfunction.

• Do not expose the system or accessories to high
temperatures, high humidity or direct sunlight.

• Do not place the system or accessories on surfaces that are
unstable, tilted or subject to vibration.

• Do not set the system other than in the vertical or horizontal
position. When setting the system in the vertical position,
use the vertical stand (sold separately) for this model of the
system.

• Be careful when carrying the system. If you do not have a
good grip, the system may drop causing potential damage
or injury.

• Do not turn off the system while data is being saved on or
loaded from the hard disk drive.

• Do not remove the AC power cord from the electrical outlet
until the power indicator has turned off. If you disconnect
the AC power cord while the power indicator is lit or
blinking, data may be lost or corrupted, or the system may
be damaged.

• Do not move the system or adjust its position when the
power indicator is lit or blinking. Data may be lost or
corrupted, or the system may be damaged.

• Do not place the system and connected accessories on the
floor or in a place where they may cause someone to trip or
stumble.

• Do not allow bodily contact with the system or air from the
system vents for an extended period of time while in use.
Extended contact under these conditions may cause low­temperature burns.

• When connecting the system to a plasma or projection* TV,
do not leave a still image on the TV screen for an extended
period of time, as this may leave a faint image permanently
on the screen.

* Except LCD screen types

• Parents are encouraged to monitor children in online
activities to ensure safe and responsible Internet usage.

• Permanent hearing loss may occur if the headset or
headphones are used at high volume. Set the volume to a
safe level. Over time, increasingly loud audio may start to
sound normal but can actually be damaging your hearing.
If you experience ringing or any discomfort in your ears or
muffled speech, stop listening and have your hearing
checked. The louder the volume, the sooner your hearing
could be affected. To protect your hearing:

– Limit the amount of time you use the headset or

headphones at high volume.
– Avoid raising the volume to block out noisy surroundings.
– Lower the volume if you can't hear people speaking near

you.

• Do not use the headset or headphones if they cause
discomfort to your skin. If the headset or headphones cause
discomfort to your skin, discontinue use immediately. If
symptoms do not subside even after discontinuing use,
seek medical attention.

EN

• Do not stand on or put objects on the system, and do not
stack the system with other devices.

7

• When using the headset or headphones in particularly dry

air conditions, you may sometimes experience a small and
quick (static) shock on your ears. This is a result of static
electricity accumulated in the body, and is not a
malfunction of your headset or headphones.

About the USB device

If "An unknown USB device has been connected" is displayed
on-screen, the reason may be one of the following:

• The connected USB device is not compatible with the

system.

• The connected USB device is compatible with only some

software titles.

• Too many USB devices are connected to the USB hub.

Notes on safety when using the DUALSHOCK™4
Wireless Controller*

• Stop using the system immediately if you begin to feel tired

or if you experience discomfort or pain in your hands or
arms while operating the wireless controller. If the
condition persists, consult a doctor.

• The vibration function of the wireless controller can

aggravate injuries. Do not use the vibration function if you
have any ailment or injury to the bones, joints or muscles of
your hands or arms. If you have an ailment or an injury, do
not use the wireless controller to play software titles that
contain the vibration function unless you first disable this
function.

• Avoid prolonged use of the wireless controller. Take a break

at about 30-minute intervals.

• Note that some software titles enable the vibration function
by default. To disable the vibration function,
select (Settings) [Devices] [Controllers] from the
function screen, and then remove the checkmark from
[Enable Vibration].

• When using the motion sensor function of the wireless
controller, be cautious of the following points. If the
controller hits a person or object, this may cause accidental
injury or damage.

– Before using, check that there is plenty of space around

you.

– When using the controller, grip it firmly to make sure it

cannot slip out of your hand.

– If using a controller that is connected to the PS4™ system

with a USB cable, make sure there is enough space for the
cable so that the cable will not hit a person or object. Also,
take care to avoid pulling the cable out of the PS4™
system while using the controller.

– Some PlayStation®, PlayStation®2 and PlayStation®3

system peripherals such as the analog controller
(DUALSHOCK™), the analog controller (DUALSHOCK™2)
and the DUALSHOCK™3 Wireless Controller are not
compatible with the PS4™ system. For details, visit
us.playstation.com.

• Avoid looking into the light bar of the controller when it is
flashing. Stop using the controller immediately if you
experience any discomfort or pain in any body parts.

• Charge in an environment where the temperature range is
between 10 °C - 30 °C (50 °F - 86 °F). Charging may not be as
effective when performed in other environments.

• The battery has a limited lifespan. Battery duration will
gradually decrease with repeated usage and age. Battery
life also varies depending on the storage method, usage
state, environment and other factors.

8

• When the wireless controller is not used for an extended
period of time, it is recommended that you fully charge it at
least once a year in order to maintain battery functionality.

* These notes may also apply to other controllers.

Vents

Do not block any vents. To maintain good ventilation, follow
the guidelines below:

• Place the system at least 10 cm (4 in) away from a wall
surface.

• Do not place on a carpet or rug with long fibers.

• Do not place in a narrow or cramped space.

• Do not place the AC power cord near heating equipment
and do not expose the cord to heat.

• Unplug the AC power cord from the electrical outlet before
cleaning or moving the system, or when you do not intend
to use the system for an extended period of time. When
disconnecting, grasp the AC power cord by the plug and
pull straight out of the electrical outlet. Never pull by the
cord and do not pull out at an angle.

• Do not connect the AC power cord to a voltage transformer
or inverter. Connecting the AC power cord to a voltage
transformer for overseas travel or an inverter for use in an
automobile may cause heat to build up in the system and
may cause burns or a malfunction.

EN

• Do not cover with cloth.

• Do not allow dust to build up on the vents.

AC power cord use

• Do not plug the AC power cord for the system into an
electrical outlet until you have connected the HDMI cable.
Make sure the TV or other component is unplugged from
the electrical outlet prior to connecting it to the system.

• To help ensure safe operation, regularly inspect the AC
power cord. If damaged, stop use immediately and contact
SCEA Consumer Services ( back cover).

• Do not use a power cord other than the supplied AC power
cord. Do not modify the cord.

• Do not touch the plug of the AC power cord with wet hands.

• Protect the AC power cord from being walked on or pinched
particularly at plugs, expansion receptacles and the point
where the cord exits from the system.

• Do not place heavy items on the cord.

Never disassemble or modify the system or accessories

Use the PS4™ system and accessories according to the
instructions in the product documentation. No authorization
for the analysis or modification of the system or accessories,
or the analysis and use of its circuit configurations, is
provided. Unauthorized modification of the system or
accessories will void your warranty. There are no user
serviceable components inside the PS4™ system (the
supplied hard disk drive may be removed but not
disassembled or modified).
Additionally, there is a risk of exposure to laser radiation as
well as to electrical shock.

Network

• A broadband connection is required to access the Internet.
Note that dial-up connectivity is not supported.

9

• You are responsible for Internet service fees. For details,
refer to the information provided in your service contract or
contact your Internet service provider.

• Do not use a cord for a standard residential telephone line
or cables of types other than those mentioned here. Using
the wrong type of cord or cable can cause more electrical
current than necessary to flow through the LAN connector,
which may lead to heat build-up, fire or malfunction.

Specifications

Design and specifications are subject to change without
notice.
Depending on the software version in use, the system may
operate differently than described in this manual.

Wireless networking feature

• The 2.4 GHz range of radio waves used by the wireless
networking feature of this product is a range shared by
various devices. This product has been designed to
minimize the effect of other devices using the same range.
However, in some cases interference from other devices
may reduce the connection speed, shorten the signal range
or cause the connection to be terminated unexpectedly.

• When using the PS4™ system's scan function to select a
wireless LAN access point, access points that are not
intended for public use may be displayed. Only connect to
an access point that you are authorized to use.

Moisture condensation

If the system or disc is brought directly from a cold location to
a warm one, moisture may condense either on the lens inside
the system or on the disc. Should this occur, the system may
not operate properly. In this case, remove the disc and turn
off and unplug the system. Do not put the disc back in until
the moisture evaporates from the system (this may take
several hours). If the system still does not operate properly,
contact SCEA Consumer Services ( back cover).

PlayStation®4 system

Single-chip custom processor
CPU : x86-64 AMD “Jaguar”,

Main Processor

Memory GDDR5 8 GB

Hard disk drive Internal, 500 GB

Optical drive
(read-only)

Laser

8 cores
GPU : 1.84 TFLOPS, AMD next­generation Radeon™-based
graphics engine

BD 6× CAV
DVD 8× CAV

Type: Semiconductor,

continuous

BD Wavelength: 395 - 415 nm

Power: Max. 1 mW

DVD

CD

Wavelength: 640 - 675 nm
Power: Max. 1 mW

*3

Wavelength: 765 - 805 nm
Power: Max. 1 mW

*1*2

10
