1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
Part List
TM
C6902, C6903, C6906,C6943,L39h
- mechanical -
Xperia
Sony Mobile Communications AB – Company Internal
2(11)
Part List (mech)
CONTENTS
1 Part List ........................................................................................... 3
2 Revision History ........................................................................... 11
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
3(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
1 Part List
The following parts are available for order in ‘E-star’.
The ‘E-star’ name of a part may often be complex and even confusing, so the name of certain parts
mentioned in the Working Instructions, Repair Movies and Troubleshooting Guide are often referred t o
by a simple descriptive name for better understanding.
Both names (designations) will in that case be included in this Part List, where the name being used in
the documents mentioned above is underlined, e.g.
RLC, Reversed Logistic Classification column for replaced part handling, See the Spare part handling
chapter in Mechanical/Generic Repair Manual 1220-1333).
Battery Cover
.
Adhesive Earspeaker
Adhesive FPC Relay Bottom
Adhesive WP Audio Jack
Adhesive WP Camera Key
1272-0782
1273-9725
1272-0161
1272-0111
C
C
C
C
Adhesive WP Cover Rear
1272-0383
C
Adhesive WP Loudspeaker
1272-0243
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
4(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
Adhesive WP Main Frame
Adhesive WP Side Key
Adhesive WP Window Back
Battery
1272-0163
1272-0106
1272-0690
1271-9084
C
C
C
B
BT + WLAN Flex Antenna
Camera
Camera Holder
Camera Key
Camera Key Black
Camera Key Purple
Camera Key White
1271-7548
1271-4830
1272-0235
1272-0716
1274-9007
1273-9705
C
B
C
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
5(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
Chat Camera
Chat Camera Holder
Core Unit Label
Cushion 1st Mic
1272-0870
1272-0198
1276-1828
1272-0159
C
C
C
C
Cushion 2nd Mic
Ear Speaker
FPC Assembly Audio Jack
FPC Assembly Charger
1272-0379
1275-9546
1270-6398
1270-6403
C
C
C
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
6(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
FPC Assembly Mic
FPC Assembly Relay (RoW)
FPC Assembly Relay (C6906)
Front Cover
Front Cover RoW Black
Front Cover RoW Purple
Front Cover RoW White
Gasket Charger
1270-6400
1270-6401
1276-6631
1276-5214
1276-5216
1276-5215
1276-5058
C
C
A
C
Gasket Side Key
1272-0103
C
Holder Magnetic Charger Connector
1272-2740
C
Liquid indicator
1275-3307
C
Loudspeaker
1267-9538
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
7(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
Loudspeaker Holder
Magnetic charger connector
Magnetic charger connector
Black/Purple
Magnetic Charger Connector White
Main Frame Assy
Main Frame Assy Black
Main Frame Assy Purple
Main Frame Assy White
PBA Cellular Sub
PBA Cellular Sub C6906
PBA Cellular Sub RoW
1272-0238
1272-1417
1275-9331
1272-0048
1274-9002
1273-9702
1276-8165
1271-2428
C
C
B
C
PBA WLAN Sub
1271-2437
C
Plate Contact RF A
1272-0337
C
Power Key
1272-0089
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
8(11)
Designation
Part No.
RLC
Part
Location
Rear Cover Assy
Rear Cover Assy Black
Rear Cover Assy Purple
Rear Cover Assy White
Part List (mech)
1272-0350
1274-8999
C
1273-9712
RF Cable A
RF Cable B
Screw 3.5x1.4
SD Cap
SD Cap Black
SD Cap Purple
SD Cap White
1272-3938
1272-3918
1248-2355
1272-0134
1274-9010
1273-9708
C
C
C
C
Sheet Battery
1277-0900
C
Sheet Conductive Charger FPC
1273-9721
C
Sheet Conductive Relay FPC
1273-9719
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
9(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
Sheet Thermal A
Sheet Thermal B
Sheet WP 2nd Mic
Sheet WP Check
1272-0035
1273-9723
1272-0376
1272-0157
C
C
C
C
Shield Camera
SIM Cap
SIM Cap Black
SIM Cap Purple
SIM Cap White
SIM T ray
Speaker Panel
Speaker Panel Black
Speaker Panel Purple
Speaker Panel White
1272-0230
1272-0142
1274-9012
1273-9710
1272-5201
1272-0699
1274-9049
1273-9716
C
C
C
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
10(11)
Designation
Part No.
RLC
Part
Location
Part List (mech)
Tray Core Unit Label
USB Cap
USB Cap Black
USB Cap Purple
USB Cap White
USB Holder
Vibrator
1272-0043
1272-0117
1274-9008
1273-9706
1272-0200
1276-5086
C
C
C
C
Window Back
Window Back RoW Black
Window Back RoW Purple
Window Back RoW White
Volume Key
Volume Key Black
Volume Key Purple
Volume Key White
1276-6948
1276-6949
1276-6950
1272-0713
1274-9006
1273-9704
B
C
1277-9817 Rev 2
Sony Mobile Communications AB – Company Internal
11(11)
Rev.
Date
Changes / Comments
2 Revision History
1 2013-08-26 Initial release
2 2013-11-12 Added C6943
Part List (mech)
1277-9817 Rev 2
