SERVICE MANUAL

MODEL COMMANDER DEST CHASSIS NO.

KV-20M42 RM-Y156 US SCC-S27A-A KV-20M42 RM-Y156 CND SCC-S28B-A KV-20S42 RM-Y155 US SCC-S27B-A KV-20S42 RM-Y155 CND SCC-S28C-A KV-20S43 RM-Y156W US SCC-S27C-A KV-20S43 RM-Y156W CND SCC-S28D-A KV-21MB42C RM-Y156 E SCC-S25E-A KV-21MB42M RM-Y156 MX SCC-S26A-A KV-21MB42P RM-Y156 E SCC-S25A-A KV-21ME42 RM-Y156 E SCC-S25B-A KV-21ME42C RM-Y156 E SCC-S25F-A KV-21SB42C RM-Y155 E SCC-S25G-A

BA-4D CHASSIS

KV-21SB42M RM-Y155 MX SCC-S26B-A KV-21SE42 RM-Y155 E SCC-S25D-A KV-21SE42C RM-Y155 E SCC-S25H-A KV-21SE82 RM-Y165 E SCC-S25J-A KV-21SE82C RM-Y165 E SCC-S25K-A

RM-Y155

MICROFILM

KV-21SE82

TRINITRON® COLOR TV

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

SPECIFICA TIONS

KV-21MB42C,

KV-20M42

Power Requirements 120V 60Hz Number of inputs/outputs

Video

Audio Input

Audio Out

Speaker Output (W) 3W 3W 3Wx2 3W x 2 3Wx2 4Wx2 5Wx2

Power Consumption (W)

In Use (Max) 80W 80W 80W 90W 90W 90W 90W

In Standby 1W 1W 1W 1W 1W 1W 1W

Dimensions (W/H/D)

(mm)

(in)

Mass

2222222

------1

522 x 477 x 479 mm522 x 477 x 479 mm522 x 477 x 479 mm522 x 477 x 479 mm522 x 477 x 479 mm522 x 477 x 479 mm522 x 477 x 479

/8 x 1813/16 x

/8 in.

KV-21MB42M,

KV-21MB42P

AUTO VOLT

120-220V,

50/60 Hz

/8 x 1813/16 x

/8 in.

KV-21ME42,

KV-21ME42C

AUTO VOLT

120-220V,

50/60 Hz 120V 60 Hz

/8 x 1813/16 x

/8 in.

KV-20S42,

KV-20S43

/8 x 1813/16 x

/8 in.

KV-21SB42C, KV-21SB42M

AUTO VOLT

120-220V,

50/60 Hz

/8 x 1813/16 x

/8 in.

KV-21SE42,

KV-21SE42C

AUTO VOLT

120-220V,

50/60 Hz

/8 x 1813/16 x

/8 in.

KV-21SE82,

KV-21SE82C

AUTO VOLT

120-220V,

50/60 Hz

/8 x 1813/16 x

/8 in.

(kg) 21.6 kg 21.6 kg 21.6 kg 21.6 kg 21.6 kg 21.6 kg 21.6 kg

(lbs) 48 lbs. 48 lbs. 48 lbs. 48 lbs. 48 lbs. 48 lbs. 48 lbs.

Television system

American TV standard/NTSC

1 Vp-p 75 ohms unbal anced, sync negativ e

2 )

500 mVrms (100% modulation), impedance: 47 kilohms

More than 408 mVrms at the maximum volume setting (variable)

More than 408 mVrms (fix), Impedance: 5 kilohms

Picture tube

Trinitron® Tube

Channel coverage

VHF:2-13/UHF:14-69/CATV:1-125

Visible screen size

20" picture measured diagonally

Actual screen size

21" picture measured diagonally

Antenna

75 ohm external terminal for VHF/UHF

Supplied Accessories

Remote Commander (RM-Y155)

(KV-20S42/21SB42M/42C/21SE42/42C)

Remote Commander (RM-Y156)

(KV-20M42/21MB42C/42M/42P/21ME42/42C)

Remote Commander (RM-Y156W)

(KV-20S43)

Remote Commander (RM-Y165)

(•) SRS (SOUND RETRIEVAL SYSTEM)

(KV-21SE82/82C)

Size AA (R6) batteries (2)

Optional Accessories

Dipole antenna Connecting cables VMC-810S/820S, VMC-720M, YC-15V/30V, RK74A U/V mixer EAC-66

Design and specifications are subject to change without notice.

The (•) SRS (SOUND RETRIEVAL SYSTEM) is manufactured by Sony Corporation under license from SRS Labs, Inc. It is covered by U.S. Patent No. 4,748,669. Other U.S. and foreign patents pending.

The word ‘SRS’ and the SRS symbol (•) are registered trademarks of SRS Labs, Inc.

BBE and BBE symbol are trademarks of BBE Sound, Inc. and are licensed by BBE Sound, Inc. under U.S. Patent No. 4,638,258 and 4,482,866.

— 2 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Section Title Page

Warnings and Cautions..................................................................................................................................................4

Self-Diagnostic Function.................................................................................................................................................4

Safety Check Out Instructions........................................................................................................................................7

1. GENERAL............................................................................................................................................................8

2. DISASSEMBLY

2-1. Rear Cover Removal....................................................................................................................................................12

2-2. A Board Removal..........................................................................................................................................................12

2-3. Service Position............................................................................................................................................................12

2-4. Picture Tube Removal..................................................................................................................................................13

3. SET-UP ADJUSTMENTS

3-1. Beam Landing...............................................................................................................................................................14

3-2. Convergence.................................................................................................................................................................15

3-3. Focus............................................................................................................................................................................16

3-4. Screen (G2)...................................................................................................................................................................16

3-5. Method of Setting the Service Adjustment Mode.........................................................................................................16

3-6. White Balance Adjustments..........................................................................................................................................16

4. SAFETY RELATED ADJUSTMENTS

4-1. R582 Confirmation Method (HV Hold-Down Confirmation and Readjustments)....................................................17

4-2. B+ Voltage Confirmation and Adjustment....................................................................................................................17

5. CIRCUIT ADJUSTMENTS

5-1. Setting the Service Adjustment Mode..........................................................................................................................19

5-2. Memory Write Confirmation Method.............................................................................................................................19

5-3. Adjust Buttons and Indicators.......................................................................................................................................19

5-4. A Board Adjustments....................................................................................................................................................22

6. DIAGRAMS

6-1. Block Diagram...............................................................................................................................................................27

6-2. Circuit Board Location..................................................................................................................................................30

6-3. Printed Wiring Boards and Schematic Diagrams.........................................................................................................33

• A Board.....................................................................................................................................................................33

• C Board....................................................................................................................................................................42

6-4. Semiconductors............................................................................................................................................................43

7. EXPLODED VIEWS

7-1. Chassis (KV-20S43/21SE42/42C/82/82C/ME42/42C).................................................................................................44

7-2. Chassis (KV-20M42/S42/21MB42C/42M/42P/SB42C/42M)........................................................................................45

8. ELECTRICAL PARTS LIST ...........................................................................................................................47

Table of Contents for Parts List ...........................................................................................................................................47

A Board Common Parts Listing............................................................................................................................................48

C Board Parts List................................................................................................................................................................56

A Board Variant Parts Lists...................................................................................................................................................57

Packaging List and Accessories....................................................................................................................................................65

— 3 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

WARNINGS AND CAUTIONS

CAUTION

SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND THE ANODE CAP TO THE METAL CHASSIS, CRT SHIELD, OR CARBON PAINTED ON THE CRT, AFTER REMOVING THE ANODE.

WARNING!!

AN ISOLATION TRANSFORMER SHOULD BE USED DURING ANY SERVICE TO AVOID POSSIBLE SHOCK HAZARD, BECAUSE OF LIVE CHASSIS. THE CHASSIS OF THIS RECEIVER IS DIRECTLY CONNECTED TO THE AC POWER LINE.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY SHADING AND MARK ON THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS, AND IN THE PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. CIRCUIT ADJUSTMENTS THAT ARE CRITICAL FOR SAFE OPERATION ARE IDENTIFIED IN THIS MANUAL. FOLLOW THESE PROCEDURES WHENEVER CRITICAL COMPONENTS ARE REPLACED OR IMPROPER OPERATION IS SUSPECTED.

SELF-DIAGNOSTIC FUNCTION

ATTENTION

APRES AVOIR DECONNECTE LE CAP DE L'ANODE, COURT-CIRCUITER L'ANODE DU TUBE CATHODIQUE ET CELUI DE L'ANODE DU CAP AU CHASSIS METALLIQUE DE L'APPAREIL, OU AU COUCHE DE CARBONE PEINTE SUR LE TUBE CATHODIQUE OU AU BLINDAGE DU TUBE CATHODIQUE.

ATTENTION!!

AFIN D'EVITER TOUT RESQUE D'ELECTROCUTION PROVENANT D'UN CHÁSSIS SOUS TENSION, UN TRANSFORMATEUR D'ISOLEMENT DOIT ETRE UTILISÉ LORS DE TOUT DÉPANNAGE. LE CHÁSSIS DE CE RÉCEPTEUR EST DIRECTEMENT RACCORDÉ À L'ALIMENTATION SECTEUR.

ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!

LES COMPOSANTS IDENTIFIES PAR UNE TRAME ET PAR UNE MARQUE SUR LES SCHEMAS DE PRINCIPE, LES VUES EXPLOSEES ET LES LISTES DE PIECES SONT D'UNEIMPORTANCE CRITIQUE POUR LA SECURITE DU FONCTIONNEMENT. NE LES REMPLACER QUE PAR DES COMPOSANTS SONY DONT LE NUMERO DE PIECE EST INDIQUE DANS LE PRESENT MANUEL OU DANS DES SUPPLEMENTS PUBLIES PAR SONY. LES REGLAGES DE CIRCUIT DONT L'IMPORTANCE EST CRITIQUE POUR LA SECURITE DU FONCTIONNEMENT SONT IDENTIFIES DANS LE PRESENT MANUEL. SUIVRE CES PROCEDURES LORS DE CHAQUE REMPLACEMENT DE COMPOSANTS CRITIQUES, OU LORSQU'UN MAUVAIS FONTIONNEMENT SUSPECTE.

The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to flash. The number of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER LED flash indicators is listed in the instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often these problems occur.

Diagnostic Test Indicators

When an error occurs, the STANDBY/TIMER LED will flash a set number of times to indicate the possible cause of the problem. If there is more than one error, the LED will identify the first of the problem areas.

Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays a “0”.

Diagnostic Item

Description

Power does not turn on Does not light

+B overcurrent (OCP)* 2 times 2 :0 or 2: 1 • H.OUT (Q50 2) is sh orted (A Board)

Vertical deflection stopped* 4 times 4:0 or 4:1 • +13V is not supplied. (A Board)

White balance f ailure (not balanced)

No. of Times

STANDBY/TIMER

LED Flashes

5 times 5:0 or 5:1 • Video OUT (Q394 t o 392) is faulty. (A Board)

Self-diagnostic Display/

Diagnostic Result

Probable Cause

Location

• Po w er c ord is not plugged in.

• Fuse is burned out (F601).

• IC701 and Q70 1 (C Board) are shorted.

• IC541 is faulty. (A Board)

• IC301 is faulty. (A Board)

• Screen (G2) is im properly adjusted.**

Detected Symptoms

• Power does not come on.

• No power is supplied to the TV.

• AC power supply is faulty.

• Power does not come on.

• Load on power line is shorted.

• Has entered standby state after horizontal raster.

• Vertical deflectio n puls e is s to pped.

• Power line is shorted or power supply is stoppe d.

• No raster is generated.

• CRT cathode current detect ion reference pulse output is small.

* If a +B overcurrent is detected, stoppage of the vertical deflection is detected simultaneously.

The symptom that is diagnosed first by the microcontroller is displayed on the screen.

** Refer to Scr een (G2) Adjustments in Sections 3 and 4 of this manual.

— 4 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Display of Standby/Timer LED Flash Count

2 times 4 times 5 times

LED ON 0.3 sec. LED OFF 0.3 sec.

Diagnostic Item Flash Count*

+B overcurrent 2 times Vertical deflection stopped 4 times White balance failure 5 times

*One flash count is not used for self-diagnostic.

LED OFF

3 sec.

STANDBY/TIMER LED

Stopping the Standby/Timer LED Flash

Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER LED from flashing.

Self-Diagnostic Screen Display

For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurrences of failure on the screen for confirmation.

To Bring Up Screen Test

In standby mode, press buttons on the Remote Commander sequentially, in rapid succession, as shown below:

Display Channel

Self Diagnostic Screen Display

SELF DIAGNOSTIC

2: 0 3: N/A 0 4: 0 5: 1 101: N/A 0

Sound volume

Numeral “0” means that no fault was detected.

Numeral “1” means a fault was detected one time only.

Power ON

Note that this differs from entering the service mode (sound volume

— 5 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Handling of Self-diagnostic Screen Display

Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen during repairs. When you have completed the repairs, clear the result display to “0”.

Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after completion of the repairs.

Clearing the Result Display

To clear the result display to “0”, press buttons on the Remote Commander sequentially when the diagnostic screen is displayed, as shown below:

ENTERChannel

Quitting the Self-Diagnostic Screen

To quit the entire self-diagnostic screen, turn off the power switch on the Remote Commander or the main unit.

Self-diagnostic Circuit

FROM

CRT

FROM

IC521 PIN 7

IC301

Y/CHROMA JUNGLE

IK IN

HP/PROTECT

SDA

IC541

V. OUT

REF

IC001

SYSTEM

IO-BDAT

O-LED

I-PROT

IO-SDAT

DISPLAY

IC003

MEMORY

B-DAT

+B overcurrent (OCP) Occurs when an overcurrent on the +B (115V) line is detected by pin 18 of IC301. If the voltage

of pin 18 of IC301 is less than 1V when V.SYNC is more than seven verticals in a period, the unit will automatically turn off.

V ertical deflection stopped Occurs when an absence of the vertical deflection pulse is detected by pin 17 of IC001. Power

supply will shut down when waveform interval exceeds 2 seconds.

White balance failure If the RGB levels* do not balance within 2 seconds after the power is turned on, this error will be

detected by IC301. TV will stay on, but there will be no picture.

*(Refers to the RGB levels of the AKB detection Ref pulse that detects 1K.)

— 6 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

Trouble Light

AC Outlet Box

Ohmmeter

Cold-water Pipe

SAFETY CHECK-OUT

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

After correcting the original service problem, perform the following safety checks before releasing the set to the customer:

1. Check the area of your repair for unsoldered or poorly soldered connections. Check the entire board surface for solder splashes and bridges.

2. Check the interboard wiring to ensure that no wires are “pinched” or touching high-wattage resistors.

3. Check that all control knobs, shields, covers, ground straps, and mounting hardware have been replaced. Be absolutely certain that you have replaced all the insulators.

4. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement.

5. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement.

6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer.

7. Check the B+ and HV to see if they are specified values. Make sure your instruments are accurate; be suspicious of your HV meter if sets always have low HV.

8. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below.

Leakage Test

The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed

0.5 mA (500 microampere). Leakage current can be measured by any one of three methods.

1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers' instructions to use these instructions.

2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job.

3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low voltage scale. The Simpson’s 250 and Sanwa SH-63Trd are examples of passive VOMs that are suitable. Nearly all battery-operated digital multimeters that have a 2 VAC range are suitable (see Figure A).

How to Find a Good Earth Ground

A cold-water pipe is guaranteed earth ground; the coverplate retaining screw on most AC outlet boxes is also at earth ground. If the retaining screw is to be used as your earth ground, verify that it is at ground by measuring the resistance between it and a cold-water pipe with an ohmmeter. The reading should be zero ohms. If a coldwater pipe is not accessible, connect a 60- to 100-watt trouble light (not a neon lamp) between the hot side of the receptacle and the retaining screw. Try both slots, if necessary, to locate the hot side on the line; the lamp should light at normal brilliance if the screw is at ground potential (see Figure B).

To Exposed Metal Parts on Set

AC Voltmeter (0.75 V)

Earth Ground

Figure B. Checking for earth ground.Figure A. Using an AC voltmeter to check AC leakage.

— 7 —

SECTION 1 GENERAL

User Guide

Connecting Additional Equipment

TV and VCR

Connect the coaxial cable from your TV antenna or cable TV to the IN jack on your VCR.

Connect a coaxial cable (not supplied) from the OUT jack on your VCR to the VHF/UHF IN jack on the TV.

(Optional Connection)

If your VCR is equipped with video inputs, for best picture quality you should connect A/V connectors to AUDIO/VIDEO OUT on your VCR to AUDIO/VIDEO IN on your TV. You can use the button to switch between the TV and VCR inputs.

✍

To watch video programs from your VCR, tune your TV to channel 3 or 4 (as set on the rear of your VCR).

The instructions mentioned here are partial abstracts from the Operating Instruction

Manual. The page numbers shown reflect those of the Operating Instruction Manual.

Connecting Your TV

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Read this chapter before setting up your TV for the first time. This section covers basic connections in addition to any optional equipment you may be connecting.

Basic Connections

TV with indoor or outdoor antenna, or CATV cable

Depending on the cable available in your home, choose one of the connections below:

— 8 —

✍

If you are connecting to an indoor or outdoor antenna, it will be necessary to adjust the orientation of the antenna for best reception.

Connecting Your TV

User Guide

TV, VCR, and Cable box

Connect the coaxial cable from the wall to the IN jack on your cable box.

Connect a coaxial cable (not supplied) from the OUT jack on your cable box to the IN jack on your VCR.

Connect a coaxial cable from OUT on your VCR to VHF/UHF IN on your TV.

(Optional Connection)

✍

If you will be controlling all channel selection through your cable box, you should consider using the CHANNEL FIX feature on page 17.

TV and Cable Box

— 9 —

Connect the coaxial cable from the wall to the IN jack on your cable box.

Connect a coaxial cable (not supplied) from the OUT jack on your cable box to the VHF/UHF IN jack on the TV.

✍

To view channels from your cable box, tune your TV to channel 3 or 4 (as set on the rear panel of your cable box) and use the cable box’ s remote control to change channels.

✍

If you will be controlling all channel selection through your cable box, you should consider using the CHANNEL FIX feature on page 17.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Connecting Your TV

Using the Remote Control and Basic Functions

This section shows you how to use more advanced buttons on the remote control and how to use the on-screen menus.

Turns the TV off automatically in approximately 30, 60 or 90 minutes. Cancel by pressing until SLEEP OFF appears.

Instantly turns off the sound. Press again or press to restore sound.

Cycles through the available video inputs. Press once to show current time, (if set) and channel number.

Press again to activate CAPTION VISION settings, if available. To cancel, press again until DISPLAY OFF appears.

Cycles through the Multi-Channel TV Sound (MTS) options: STEREO, SAP (Second Audio Programming) and MONO, (KV-20S42, 20S43 only).

Press for channel selection, the channel will change after 2 seconds.

Press after selecting a channel using the - buttons to immediately activate selection.

Alternates back and forth between the last two channels selected with the - buttons.

Displays the on-screen menu. Press again to exit the menu at any time.

Activates highlighted selections in the on-screen menu. Moves the cursor in the on-screen menu.

Press to restore factory settings while in the on-screen menu.

✍

Buttons shown are for remote control RM-Y155, your remote control may not look exactly like the one illustrated.

Connecting a Camcorder

Using A/V cables, connect AUDIO and VIDEO OUT on your camcorder to AUDIO and VIDEO IN on your TV.

(Front A/V Panel)

A/V output

— 10 —

✍

For model KV-13M42, this connection can be made to the A/V input located on the rear of the TV.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Other Information

User Guide

If, after reading these operating instructions, you have additional questions related to the use of your Sony television, please call our Direct Response Center at 1-800-222-SONY (7669) (U.S. customers only) or (416) 499-SONY (7669) (Canadian customers only).

Cannot receive higher number channels (UHF) when using an antenna

❏ Make sure CABLE is set to OFF in the SET UP menu

(page 17).

❏ Use AUTO PROGRAM to add channels that are not

presently in the memory (page 17).

Cable stations don’t seem to work

❏ Make sure CABLE is set to ON in the SET UP menu

(page 16).

❏ Use AUTO PROGRAM to add channels that are not

presently in the memory (page 17).

Remote control does not operate

❏ Batteries could be weak. Replace them (page 2). ❏ Move the TV 3-4 feet away from fluorescent lights.

The TV needs to be cleaned

❏ Clean the TV with a soft dry cloth. Never use strong

solvents such as thinner or benzine, which might damage the finish of the cabinet.

Lost password for PARENTAL CONTROL

❏ In the password screen, enter the following master

password: 4357. After using the master password, you must create a new password, it cannot be used to unlock currently blocked programs.

Other Information

Troubleshooting

If you are having a problem with your TV, try the suggestions below. If the problem persists, contact your nearest Sony dealer.

No picture, no sound

— 11 —

Poor or no picture, good sound

Good picture, no sound

No color ❏ Adjust COLOR in the VIDEO menu (page 13). Only snow

appears on the screen

Dotted lines or stripes

Double images or ghosts

❏ Make sure the power cord is plugged in. ❏ If a red light is flashing on the front of your TV for

more than a few minutes, call your local service center.

❏ Check the TV/VIDEO settings: when watching TV , set

to TV; when watching video equipment, set to VIDEO (page 13).

❏ Check your PARENTAL CONTROL settings, (see

pages 22-23).

❏ Make sure the batteries have been inserted correctly

into the remote control.

❏ Try another channel, it could be station trouble. ❏ Adjust PICTURE in the VIDEO menu (page 13). ❏ Adjust BRIGHTNESS in the VIDEO menu (page 13). ❏ Check the antenna and/or cable connections (page 3). ❏ Press so that MUTING disappears from the

screen (page 9).

❏ Check your AUDIO settings. Your TV may be set to

SAP (page 14).

❏ Check the CABLE setting in the SET UP menu

(page 17).

❏ Check the antenna and/or cable connections (page 3). ❏ Make sure the channel selected is currently

broadcasting.

❏ Adjust the antenna. ❏ Move the TV away from other electronic equipment.

Some electronic equipment can create electrical noise, which can interfere with TV reception.

❏ Check your outdoor antenna or call your cable service.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

SECTION 2

DISASSEMBLY

2-1. REAR COVER REMOV AL

Rear Cover

Four Screws (BVTP 4x16)

2-2. A BOARD REMOVAL 2-3. SERVICE POSITION

C Board

Claw

A Board

— 12 —

2-4. PICTURE TUBE REMOV AL

WARNING:

BEFORE REMOVING

THE ANODE CAP

High voltage remains in the CRT even after the power is disconnected.

To avoid electric shock, discharge CRT before attempting to remove the anode cap. Short between anode and CRT coated earth ground strap.

Degaussing Coil

Tension Spring (B)

C Board

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Two Screws

Two Speaker Boxes (KV-21SE82/82C ONLY)

A Board

Tuner

Coated

Deflection Yoke

Four Tapping Screws

Anode Cap

Two Screws

Earth Ground Strap

Picture Tube

Cushion

ANODE CAP REMOV AL

WARNING: High voltage remains in the CRT even after the power is disconnected. To avoid electrical shock, discharge the CRT before

NOTE: After removing the anode, short circuit the anode of the picture tube and the anode cap to either the metal chassis, CRT shield,

attempting to remove the anode cap. Short between anode and coated earth ground strap of CRT.

or carbon painted on the CRT.

REMOVAL PROCEDURES

Turn up one side of the rubber cap in the direction indicated by arrow

Use your thumb to pull the rubber cap firmly in the direction indicated by arrow

HOW TO HANDLE AN ANODE CAP

Do not use sharp objects which may cause damage to the surface of the anode cap.

To avoid damaging the anode cap, do not squeeze the rubber covering too hard. A material fitting called a shatter-hook terminal is built into the rubber.

Do not force turn the foot of the rubber cover. This may cause the shatter-hook terminal to protrude and damage the rubber.

— 13 —

Anode Button

When one side of the rubber cap separates from the anode button, the anode cap can be removed by turning the rubber cap and pulling it in the direction of arrow

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

SECTION 3

SET -UP ADJUSTMENTS

The following adjustments should be made when a complete realignment is required or when a new picture tube is installed.

These adjustments should be performed with rated power supply voltage unless otherwise noted.

Set the controls and switch as follows unless otherwise noted.

PICTURE control ................. Normal

BRIGHTNESS control......... Normal

3-1. BEAM LANDING

Before beginning adjustment procedure:

1. Degauss the entire screen.

2. Feed in the white pattern signal.

Adjustment Procedure

1. Input a raster signal with the pattern generator.

2. Loosen the deflection yoke mounting screw and set the purity control to the center as shown below.

Perform the adjustments in order as follows:

1. Beam Landing

2. Convergence

3. Focus

4. Screen (G2)

5. White Balance

Note: Test equipment required:

• Color bar pattern generator

• Degausser

• DC power supply

• Digital multimeter

5. Move the deflection yoke forward and adjust so that the entire screen becomes green.

Purity Control

3. Turn the raster signal of the pattern generator to green.

4. Move the deflection yoke backward and adjust the purity control so that green is in the center and red and blue are at the sides evenly.

Blue Red

Green

6. Switch over the raster signal to red and blue and confirm the condition.

7. When the position of the deflection yoke is determined, tighten it with the deflection yoke mounting screw.

8. If landing at the corner is not right, adjust by using the disk magnets.

Purity control

corrects this area

Disk magnets

or rotatable disk

Deflection yoke positioning

corrects these areas

magnets correct

these areas (a-d)

— 14 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

3-2. CONVERGENCE

Before starting convergence adjustments:

1. Perform FOCUS, V .LIN AND V.SIZE adjustments.

2. Set BRIGHTNESS control to minimum.

3. Feed in dot pattern.

Vertical Static Convergence

1. Adjust V.STAT magnet to converge red, green and blue dots in the center of the screen (vertical movement).

Center dot

R G B

V.STAT magnet

If the blue dot does not converge with the red and green dots, perform the following:

1. Move BMC magnet (a) to correct insufficient H. Static convergence.

2. Rotate BMC magnet (b) to correct insufficient V. Static convergence.

3. In either case, repeat Beam Landing Adjustment.

PURITY

V. STAT

BMC MAGNET

BMC magnet

2. Tilt the V.STAT magnet and adjust static convergence to open or close the V.STAT magnet.

When the V.STAT magnet is moved in the direction of arrows

and , red, green, and blue dots move as shown

below:

(1)

(2) a

(3)

B G

BGR

RGB

B G

Dynamic Convergence Adjustment

Before performing this adjustment, perform Horizontal and Vertical Static Convergence Adjustment.

1. Slightly loosen deflection yoke screw.

2. Remove deflection yoke spacers.

3. Move the deflection yoke for best convergence, as shown below:

BGR

R G B

RGB

BGR

B G R

4. Tighten the deflection yoke screw.

5. Install the deflection yoke spacers.

RGB

BGR RGB

R G B

— 15 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

(G2)

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Screen-Corner Convergence

1. Affix a permalloy assembly corresponding to the misconverged areas.

a-d: screen-corner

misconvergence cd

3-3. FOCUS

1. Adjust FOCUS control for best picture.

FOCUS

(FV)

SCREEN

3-5. METHOD OF SETTING THE SERVICE

ADJUSTMENT MODE

Service Mode Procedure

1. Standby mode (power off).

Display Channel

on the Remote Commander (press each button within a second).

Sound volume Power ON

Service Adjustment Mode In

1. The CRT displays the item being adjusted.

Disp.

Item

(Item)

Data

SERVICE HSIZ 0

2. Press or on the Remote Commander to select the item.

3. Press

or on the Remote Commander to change the

data.

4. Press

then to save into the memory.

Service Adjustment Mode Memory

Turn set off then on to exit service adjustment mode.

3-4. SCREEN (G2)

1. Input a dots pattern.

2. Set the PICTURE and BRIGHTNESS controls at minimum and COLOR control at normal.

3. Adjust SBRT, GCUT, BCUT in service mode with an oscilloscope as shown below so that voltages on the red, green, and blue cathodes are 170 VDC.

170 VDC

Ground

4. Observe the screen and adjust SCREEN (G2) VR to obtain the faintly visible background of dot signal.

Pedestal

SERVICE WRITE

MUTING

ENTER

Green

Red

3-6. WHITE BALANCE ADJUSTMENTS

1. Input an entire white signal.

2. Set to Service Adjustment Mode.

3. Set DCOL to “0”.

4. Set the PICTURE and BRIGHTNESS to minimum.

5. Adjust with SBRT if necessary.

6. Select GCUT and BCUT with

7. Adjust with

and for the best white balance.

8. Set PICTURE and BRIGHTNESS to maximum.

9. Select GDRV and BDRV with

10.Adjust with

and for the best white balance.

11.Reset DCOL to “1”.

12. To write into memory, press

and .

then .

— 16 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

I ABL

ABL

T504

FBT

Range

Ammeter

3.0 mA DC

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

SECTION 4

SAFETY RELATED ADJUSTMENTS

4-1. R582 CONFIRMATION METHOD

(HV HOLD-DOWN CONFIRMATION) AND READJUSTMENTS

The following adjustments should always be performed when replacing the following components which are marked with

on the schematic diagram.

DY, C511, C574, C575, D572, D573, D574, R582, R583, R584, R585, R586, R578, R625, R626, R634, R635, T504, IC301, IC521, IC602

Preparation Before Confirmation

1. Turn the POWER switch ON. Input an entirely white signal and set the PICTURE and BRIGHTNESS controls to maximum.

2. Confirm that the voltage between C574 (+) and ground is more than 99.8 VDC when the set is operating normally with 120.0 ± 2.0 VAC (or 120-220±VAC for KV-21MB42C/42M/42P/ME42/42C/SB42C/42M/ SE42/42C/82/82C).

Hold-down Operation Confirmation

1. Connect the current meter between Pin 11 of the FBT (T504) and the PCB land where Pin 11 would normally attach. (See Figure 1 on the following page.)

2. Input a dot signal and set PICTURE and BRIGHTNESS to minimum: IABL = 95 + 100/-95mA.

3. Confirm the voltage of A Board TP-600 is

117.0 ± 0.3 VDC.

4. Connect the digital voltmeter and the DC power supply via diode 1SS119 to C574 (+) and ground (See Figure 1 on the following page).

5. Increase the DC power voltage gradually until the picture blanks out.

6. Read the digital voltmeter indication.

7. Turn DC power source off immediately: (standard: less than or equal to 127.3 VDC).

8. Input a white signal and set PICTURE and BRIGHTNESS to maximum: (standard: less than or equal to 127.3 VDC).

9. Repeat steps 4 to 7.

Hold-down Readjustment

If the setting indicated in step 2 of Hold-down Operation Confirmation cannot be met, readjustment should be performed by altering the resistance value of R582, a component marked with

4-2. B+ VOL TAGE CONFIRMATION AND

ADJUSTMENT

Note: The following adjustments should always be performed when replacing the following components, which are marked with

on the schematic diagram.

IC001, IC602, R030, R626, R632, R633, R635, R636, R637, R638, R639

1. Supply 120.0 ± 2.0 VAC (or 120-220±VAC for KV-21MB42C/42M/42P/ME42/42C/SB42C/42M/SE42/ 42C/82/82C) to the set with a variable auto transformer.

2. Input a dot signal.

3. Set the PICTURE and BRIGHTNESS controls to minimum.

4. Set to Service Adjustment Mode.

5. Select PADJ with

6. Adjust with

7. Confirm the voltage of A board TP-600 is less than 125 VDC.

8. If step 7 is not satisifed, replace the components and repeat the above steps.

9. Supply 120.0 ± 2.0 VAC (or 120-220±VAC for KV-21MB42C/42M/42P/ME42/42C/SB42C/42M/SE42/ 42C/82/82C) to the set with a variable auto transformer.

10.Adjust with

11.Press

and .

to the 0 level.

and for 117.0 ± .3 VDC.

then to save into the memory.

— 17 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Digital

Multimeter

+ –

TP600

C574

R582

ABL11

Ammeter

3mA DC Range

+ –

T504

FBT

Power

Supply

–

Digital

Multimeter

1SS119

+ –

Figure 1

— 18 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

SERVICE RESET

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

SECTION 5

CIRCUIT ADJUSTMENTS

Electrical Adjustment by Remote Commander

Use the Remote Commander (RM-Y155) to perform the circuit adjustments in this section. NOTE: Test Equipment Required:

• Pattern generator

• Frequency counter

• Digital multimeter

• Audio oscillator

5-1. Setting the Service Adjustment Mode

1. Standby mode (power off).

Display Channel

Sound volume Power ON

on the Remote Commander (press each button within a second).

Service Adjustment Mode On

1. The CRT displays the item being adjusted.

Disp.

Item

(Item)

Data

SERVICE HSIZ 0

2. Press or on the Remote Commander to select an item.

3. Press the data.

4. Press

or on the Remote Commander to change

then to save into the memory.

5-2. Memory Write Confirmation Method

1. After adjustment, remove the power plug from the AC outlet, then plug it in again.

2. Turn the power switch ON and set to service mode.

3. Call the adjusted items again to confirm they were adjusted.

5-3. Adjust Buttons and Indicators

MUTING

Write into memory

DISPLAY

Service mode

Item up

Item down

MUTING

MTS

1 4

123

456

789

JUMP

RESET

SLEEP

POWER

TV/VIDEODISPLAY

ENTER

SELECT

POWER

Service mode

Data up

Data down

Service mode

Initialize

ENTER

Write into memory

Service Adjustment Mode Memory

SERVICE WRITE

MUTING

ENTER

1. Press then on the Remote Commander to initialize.

Carry out step 1 when adjusting IDs 0–4 and when replacing and adjusting IC003.

2. Turn set off then on to exit service adjustment mode.

Green

Red

— 19 —

VOL(+)

Service mode

VOL

+ –

RM-Y155

+ –

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Adjustment Items

NO. ITEM FUNCTION

1 HSIZ HORIZONT AL SIZE ADJ. 0-63 31 31 2 HPOS HORIZONTAL POS. ADJ. 0-63 31 20 3 VBOW VRT LI NE BOWING ADJ. 0-15 7 6 4 VANG VRT LINE BOW SLANT ADJ. 0-15 7 6 5 TRAP H ORIZ. TRAPEZOID ADJ. 0-15 7 15 6 PAMP HORIZ. PIN DISTORTION ADJ. 0-63 31 3 1 7 CPIN S AME AS PAMP-SCRN TP/BTM 0-63 31 31 8 VSIZ VERTICAL SIZE ADJ. 0-63 31 37

9 VPOS VERTICAL POSITION ADJ. 0-63 31 38 10 VLIN VERTICAL LINEARITY ADJ. 0-15 7 7 11 SCOR VERTICAL “S” CORRECTION ADJ. 0-15 7 7

12 VZOM 16:9 CRT Z MODE ON/OFF 0, 1 0 0 13 EHT VRT HI-VOLT. CORRECTION 0-15 7 4 14 ASP ASPECT RATIO CONTROL 0-63 63 47 15 SCRL 16:9 CRT Z MODE TRANS SCROLL 0-63 31 31 16 HBLK HORIZONTAL BLANKING ON/OFF 0, 1 0 1 17 LBLK LEFT BLANKING ADJ. 0-15 7 15 18 RBLK RIGHT BLANKING ADJ. 0-15 7 3 19 VUSN V SAW WAVEFORM COMPRESS 0, 1 0 0 20 HDW H. DRIVE PULSE WIDTH 0, 1 0 0 21 EWDC “PARABOLA” EW/DC ADJ. 0, 1 0 0 22 LVLN LOWER SCR EEN BTM VRT LIN ADJ. 0-15 0 0 23 UVLN UPPER SCREEN BTM VRT LIN ADJ. 0-15 0 0 24 RDRV R OUTPUT DRIVE CO NTROL 0-63 31 27 25 GDRV G OUTPUT DRIVE CONTROL 0-63 31 22 26 BDRV B OUTPUT DRIVE CONTROL 0-63 31 22 27 RCUT R OUT P UT CUTOFF CONTROL 0-15 7 9 28 GCUT G OUTPUT CUTOFF CONTROL 0-15 7 4 29 BCUT B OUTPUT CUTOFF CONTROL 0-15 7 4 30 DCOL DYNAMIC COLOR ON/OFF 0, 1 0 0 31 SHUE SUB HUE 0-31 14 18 32 SCOL SUB COLOR 0-31 14 18 33 SBRT SUB BRIGHTNESS 0-31 14 10 34 RON R OUTPUT ON/OFF 0, 1 0 1 35 GON G OUTPUT ON/OFF 0, 1 0 1 36 BON B OUTPUT ON/OFF 0, 1 0 1 37 AXPL AXIS PAL 0, 1 0 0 38 AXNT AXIS NTSC 0, 1 0 0 39 CBPF CHROMA BPF ON/OFF 0, 1 0 1 40 CTRP Y TRAP FILTER ON/OFF 0, 1 0 1 41 COFF COLOR ON/OFF 0, 1 0 0 42 KOFF SET COLOR KILLER 0, 1 0 0 43 SSHP SUB SHARPNESS 0-15 8 6 44 SHPF SHARPNESS CIRCUIT F0 0, 1 0/0 *2 0/0 *2 45 PREL PRE/O VR SHOOT SWITCHING 0, 1 0 1 46 Y-DC DC TRANS RATIO SWITCHING 0, 1 0 1 47 GAMM GAMMA CORRECTION AMNT 0-3 0 0 48 ABLM ABL MODE SWITCHING 0, 1 1 1 49 VTH ABL CD VHT SWITCHING 0, 1 0 1 50 YDEL Y DELAY TIME CONTROL 0-15 7 7 51 NCOL NO COLOR ID 0, 1 0 1 52 FSC FSC OUT ON/OFF 0, 1 0 1 53 K-ID KILLER ID CONTROL SW 0, 1 0 0 54 HOSC H VCO OSCILLATION FREQ 0-15 7 7 55 VSS V SYNC SLICE LEVEL 0, 1 0 0 56 HSS H SYNC SLICE LEVEL 0, 1 0 0 57 HMSK H SYNC MASK WIDTH 0, 1 0 1 58 VTMS SELECT SIGNAL VTIM PIN 0-3 0 0 59 CDMD V CNT DWN MODE SWITCHING 0-3 0/1 *2 0/1 *2 60 AFC AFC LOOP GAIN SWITCHING 0-3 0/0 *2 0/0 *2 61 FIFR FIELD FREQUENCY 0-3 0 3 62 SBAS SUB BASS 0-15 7 8 63 STRE 0-15 7 9

DAT A

RANGE INITIAL DATA AVERAGE DATA

— 20 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

DAT A

NO. ITEM FUNCTION

64 SBAL SUB BALANCE 0-31 14 13 65 DISP O.S.D DISPLAY POSITION 0-127 0 5 66 PADJ POWER ADJUSTMENT 0-63 3 42 67 HCHM 0-255 69 69 68 HCLM 0-255 16 16 69 HCHS 0-255 69 69 70 HCLS 0-255 16 16 71 PVCH 0-1 0 0 72 PVON 0-1 0 1 73 PVLN 0-31 17 17 74 PVSB 0-255 64 64 75 PVLV 0-255 130 130 76 ID1 ID1 0-255 3 See ID Map below 77 ID2 ID2 0-255 11 See ID Map below 78 ID3 ID3 0-255 1 See ID Map below 79 ID4 ID4 0-255 23 See ID Map below 80 ID5 ID5 0-255 0 See ID Map below 81 ID6 ID6 0-255 0 See ID Map below 82 ID7 ID7 0-255 64 See ID Map below

*2: T V/VIDEO

RANGE INITIAL DATA AVERAGE DATA

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Notes: No. 1–82 show the order that each adjustment mode may be selected while in service mode. Data Range shows the range of possible settings for each adjustment mode. Initial Data shows the standard settings for each adjustment mode.

Feature ID Map

MODEL DEST. ID-0 ID-1 ID-2 ID-3 ID-4 ID-5 ID-6 ID-7

KV-20M42 US KV-20M42 CND KV-20S42 US KV-20S42 CND KV-20S43 US KV-20S43 CND KV-21MB42C E KV-21MB42M MX KV-21MB42P E KV-21ME42 E KV-21ME42C E KV-21SB42C E KV-21SB42M MX KV-21SE42 E KV-21SE42C E KV-21SE82 E KV-21SE82C E

25302273100 89301473100 25312273100 89311473100 25312273100 89311473100 17 3 0 195 115 1 0 0 17 3 0 195 115 1 0 0 17 3 0 195 115 1 0 0 17 3 0 195 115 1 0 0 17 3 0 195 115 1 0 0 17 3 1 195 115 1 0 0 17 3 1 195 115 1 0 0 17 3 1 195 115 1 0 0 17 3 1 195 115 1 0 0 17 3 159 195 123 3 0 0 17 3 159 195 123 3 0 0

SERVICE ID0 25

— 21 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

V2 V3

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

5-4. A BOARD ADJUSTMENTS H. Frequency Adjustment

1. Input a monoscope signal.

2. Set to Service Adjustment Mode.

3. Connect a frequency counter to base of Q501 (TP-500 H. DRIVE).

4. Select the item of AFC, set to 3 level (free run).

5. Check H. Frequency for the 15735 ± 200 Hz.

6. Select the AFC item again and adjust level to 0.

7. Press

then to save into the memory.

V. Frequency Adustment

1. Select video 1 with no signal input.

2. Set the conditions for a standard setting.

3. Connect the frequency counter across TP-508 or CN501 VDY (+) pin

connector and ground.

4. Check that V. Frequency shows 60 ± 2 Hz.

Sub Contrast Adjustment (RDRV)

1. Input a color-bar signal.

2. Set the red color.

3. Set to Service Adjustment Mode.

4. Select the item DCOL level to 0.

5. Set the conditions as follows:

PICTURE: MAX

COLOR: MIN

BRIGHT: CENTER

R ON: ON (1) G ON: OFF (0) B ON: OFF (0)

SERVICE RON 1

1: ON 0: OFF

11.Return the following back to normal after adjustment. PICTURE: MAX

COLOR: CENTER

BRIGHT: CENTER

R ON: ON (1) G ON: OFF (0) B ON: OFF (0)

Display Position Adjustment (DISP)

1. Input a color-bar signal.

2. Set to Service Adjustment Mode.

3. Select DISP with and .

4. Adjust with

5. Press

and to adjust characters to the center.

then to save into the memory.

6. Check to see if the text is displayed on the screen.

SERVICE DISP 15

Sub Bright Adjustment (SBRT)

1. Input a crosshatch signal.

2. Set to Service Adjustment Mode.

3. Set the PICTURE and BRIGHTNESS to minimum.

4. Select the SBRT item with

5. Adjust with

6. Press

and to obtain a faintly visible crosshatch.

then to save into the memory.

and .

Sub Hue, Sub Color Adjustment (SHUE, SCOL)

1. Input a color-bar signal.

2. Set to Service Adjustment Mode.

3. Select the DCOL item and set the value to 0.

6. Connect an oscilloscope probe to CN301 pin (R OUT) and ground.

7. Select RDRV with

8. Adjust with

9. Reset the item DCOL to 1.

10.Press

and .

and for 1.70 ± 0.05 Vp-p

White

Black

then to save into the memory.

1.70 ± 0.05 Vp-p

4. Connect an oscilloscope probe to CN301 Pin (BLUE OUT) and ground.

5. Select SHUE and SCOL with

6. Adjust with

and for the V1 = V4 ± 0.2 Vp-p

(SCOL) and V2 = V3 ± 0.2 Vp-p (SHUE).

7. Reset the DCOL level to 1.

8. Press

then to save into the memory.

— 22 —

and .

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

SERVICE READ

Green

Red

ENTER

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

V. Size Adjustment (VSIZ)

1. Input a crosshatch signal.

2. Set to Service Adjustment Mode.

3. Select the VSIZ item with

4. Adjust value of VPOS with

and .

and for the best vertical

center.

5. Press then to save into the memory.

V. Center Adjustment (VPOS)

1. Input a crosshatch signal.

2. Set to Service Adjustment Mode.

3. Select the VPOS item with

4. Adjust value of VPOS with center.

and .

and for the best vertical

V. Linearity (VLIN), V Correction

1. Input a crosshatch signal.

2. V. correction is automatically adjusted from the circuit and should satisfy the conditions below.

Service Adjustment Mode Memory

1. Change the value of the DCOL item to 1.

2. After completing all adjustments, press

Read From Memory

then .

5. Press then to save into the memory.

H. Center Adjustment (HPOS)

Perform this adjustment after checking H. Frequency.

1. Input a crosshatch signal.

2. Set to Service Adjustment Mode.

3. Select the HPOS item with

4. Adjust the value of HPOS with horizontal center.

5. Press then to save into the memory.

and .

and for the best

— 23 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

NOTES:

— 24 —

NOTES:

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

— 25 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

NOTES:

— 26 —

6.1 BLOCK DIAGRAM

SECTION 6 DIAGRAMS

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

6.2 CIRCUIT BOARD LOCATIONS

•When replacing parts shown in the table below, be sure to perform the related adjustments.

C Board

A Board

6-3.PRINTED WIRING BOARDS AND

SCHEMATIC DIAGRAMS

•All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytic and tantalums.

•All electrolytics are 50V unless otherwise specified.

•Indication of resistance, which does not have one for rating electrical power, is as follows:

Pitch: 5mm

Rating electrical power 1/4W (CHIP: 1/10W)

•All resistors are in ohms.

KΩ = 1000Ω MΩ = 1000KΩ

•

•All variable and adjustable resistors have characteristic

•The components identified by

•When replacing components identified by

:nonflammable resistor :fusible resistor :internal component :panel designation and adjustment for repair :earth-ground :earth-chassis

curve B, unless otherwise noted.

in this manual have been carefully factory-selected for each set in order to satisfy regulations regarding X-ray radiation. Should replacement be required, replace only with the value originally used.

, make the necessary adjustments indicated. If results do not meet the specified value, change the component identified

and repeat the adjustment until the specified value

by is achieved (refer to Safety Related Adjustments on page 17).

Part Replaced ( )

DY, C511, C574, C575, D572, D573, D574, R582, R583, R584, R585, R586, R578, R625, R626, R634, R635, T504, IC301, IC521, IC602

Adjustment ( )

HV HOLD-DOWN (R582)

IC001, IC602, R030, R626,

R632, R633, R635, R636, R637,

R638, R639

B+ VOLTAGE CONFIRMATION

•All voltages are in Volts

•Voltage is DC with respect to ground unless otherwise noted.

•Readings are taken with a 10MΩ digital multimeter.

•Readings are taken with a color-bar signal input.

•Voltage variations may be noted due to normal production tolerance.

•Circled numbers are waveform references.

•* :cannot be measured

-----

:B + Line :B − Line :Signal path

•

Reference Information

RESISTOR : RN METAL FILM

: RC SOLID : FPRD NON FLAMMABLE CARBON : FUSE NON FLAMMABLE FUSIBLE : RW NON FLAMMABLE WIREWOUND : RS NON FLAMMABLE METAL OXIDE : RB NON FLAMMABLE CEMENT

COIL : LF-8L MICRO INDUCTOR

CAPACITOR : TA TANTALUM

: PS STYROL : PP POLYPROPYLENE : PT MYLAR : MPS METALIZED POLYESTER : MPP METALIZED POLYPROPYLENE : ALB BIPOLAR : ALT HIGH TEMPERATURE : ALR HIGH RIPPLE

ADJUSTMENT RESISTOR

Note:

The components identified by shading and mark are critical for safety. Replace only with the part number specified. The symbol circuit board) indicates fast operating fuse. Replace only with fuse of the same rating as marked.

Les composants identifiés per un tramé et une marque

sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. Le symbole Doit etre remplacee par une fusible de meme yaleur, comme marque.

(displayed on component side of the

indique une fusible a action rapide.

855 Block Diagram.p65 3/31/99, 6:44 PM1

— 28 — — 29 — — 30 —— 27 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

A BOARD: IC521 NJM4558M-TE2

[TUNING CONTROL, Y/C/J, POWER SUPPL Y , DEFLECTION, TUNER/IF, AUDIO MTS]

1234567891011

A BOARD: IC301 CXA2061S

A BOARD: IC541 TDA8172

A BOARD LOCATION LIST

DIODE

D001 F-9 D520 C-4 D635 A-11 Q001 F-9 Q358 G-4 D002 F-10 D541 E-3 D636 C-10 Q002 F-8 Q359 G-8 D003 H-7 D552 C-2 D637 A-11 Q003 E-8 Q380 G-8 D004 H-7 D561 C-2 D638 C-10 Q200 G-3 Q390 F-8 D201 F-2 D562 C-1 D650 H-6 Q201 G-1 Q391 F-6 D202 G-2 D571 C-2 D653 A-5 Q202 E-6 Q392 G-9 D203 H-11 D572 E-2 D670 D-9 Q203 E-9 Q393 F-8 D204 H-11 D573 E-3 D205 D-5 D574 E-3 IC001 G-9 Q206 F-4 Q501 C-5 D206 E-9 D581 E-2 IC002 H-10 Q207 F-5 Q502 B-5 D207 G-2 D601 C-7 IC003 H-9 Q252 G-9 Q556 E-8 D208 E-8 D602 D-8 IC004 F-11 Q300 F-8 Q571 D-2 D209 G-2 D603 B-8 IC200 G-3 Q301 F-7 Q601 D-7 D210 H-2 D609 B-6 IC201 F-4 Q302 F-7 Q602 F-8 D215 E-6 D611 D-6 IC202 G-2 Q303 F-3 Q605 D-6 D280 H-11 D613 C-7 IC301 G-7 Q305 F-8 Q606 E-8 D301 F-2 D614 C-7 IC302 G-5 Q340 F-4 Q607 B-10 D302 F-7 D615 C-7 IC400 E-5 Q350 G-6 Q608 D-8 D310 F-8 D616 B-6 IC401 F-5 Q351 G-6 Q650 G-6 D31 1 F-8 D617 C-6 IC402 I-4 Q352 G-6 Q670 E-9 D320 F-7 D620 B-5 IC521 E-3 Q353 G-6 D403 E-10 D631 C-9 IC541 D-3 Q354 F-7 D434 E-9 D632 B-9 IC601 B-8 Q355 G-7 D501 B-4 D633 B-10 IC602 D-6 Q356 G-7

D502 C-3 D634 A-11

TRANSISTOR

Q205 G-6 Q394 G-8

Q357 G-7

A Board

855 A PWB page.p65 3/31/99, 7:52 PM1

— 31 —

— 32 —

— 33 —

— 34 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

IC001 IC002 IC301 IC302

6GND

IC601

PIN VOLT PIN VOLT PIN VOLT PIN VOLT 7 .8 PIN VOLT

1 .9 1 7.0 1 3.4 1 5.1 8 6.5 1 -55.3 2 4.9 2 GND 2 5.2 2 0 9 GND 2 -57.2 3 .5 3 5.4 3 1.3 3 0 10 6.5 3 94.8

42.0 4GND 45.3 45.0 116.5 4-41.6 5 0 5GND 54.9 51.3 12GND 5-57.1 6 .1 6 4.9 6 4.5 6 0

IC402 IC602

7 NC 7 GND 7 2.0 7 5.1 PIN VOLT PIN VOLT 8 NC 8 4.9 8 5.1 8 1.1 1 4.5 1 2.5 9NC

IC003

9 0 9 5.1 2GND 2GND 10 0 PIN VOLT 10 GND 10 .8 3 4.5 3 10.9 11 .1 1 GND 11 3.8 11 0 4 4.5

All voltages are in V

12 4.9 2 GND 12 2.4 12 2.0 5 4.6 13 0 3 GND 13 3.5 13 2.8 6 4.5 14 4.9 4 GND 14 3.5 14 1.0 7 4.5 15 4.9 5 4.8 15 5.8 15 2.1 8 4.2 16 -.1 6 4.8 16 7.6 16 0 9 4.5 17 -.3 7 GND 17 .7 17 0 10 1.8 18 4.9 8 5.0 18 .8 18 0 11 4.9 19 4.9

IC004

19 3.0 19 0 12 4.9 20 1.8 PIN VOLT 20 2.6 20 0 13 1.6 21 0 1 4.9 21 1.0 21 0 14 4.5 22 2.2 2 4.9 22 1.5 22 5.1 15 4.5 23 0 3 0 23 1.5 23 5.0 16 4.5 24 2.2

IC200

24 1.5 24 0 17 4.5 25 2.3 PIN VOLT 25 .1 25 2.4 18 4.5 26 GND 1 5.9 26 4.4 26 0 19 4.6 27 4.9 2 .2 27 4.4 27 2.5 20 4.6 28 NC 3 6.1 28 4.4 28 5.1 21 9.1 29 NC 4 .2 29 0 29 2.3 22 4.5 30 4.9 5 6.1 30 4.6 30 2.3

IC521

31 4.9 6 9.1 31 4.6

IC400

PIN VO LT 32 0 7 5.3 32 4.6 PIN VOLT 1 12.5 33 4.9 8 GND 33 9.0 1 NC 2 .7 34 2.6

IC201

34 4.9 2 12.6 3 .9 35 0 PIN VOLT 35 4.9 3 2.4 4 GND 36 4.9 1 5.9 36 .1 4 GND 5 8.6 37 4.9 2 .2 37 4.4 5 0.8 6 9.8 38 4.9 3 6.1 38 5.1 6 6.0 7 1.3 39 4.8 4 .2 39 5.1 7 GND 8 12.9 40 0 5 6.1 40 GND 8 6.0

IC541

41 0 6 9.1 41 5.3 9 NC PIN VOLT 42 .1 7 5.3 42 7.2

IC401

12.6 43 4.9 8 GND 43 5.5 PIN VOLT 2 12.9 44 .1

IC202

44 9.1 1 .8 3 -11.1 45 4.9 1 6.8 45 5.3 2 NC 4 -12.9 46 4.9 2 6.8 46 4.8 3 2.4 5 0 47 0 3 6.8 47 1.9 4 13.6 6 13.6 480 4GND48 0 52.4 72.4 49 0 5 6.8 50 0 6 6.8 51 0 7 6.8 52 0 8 13.6

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

A BOARD SCHEMATIC DIAGRAM

123456789101112131415

16 17 18 19

A BOARD WAVEFORMS

1 2 3

253.1mV p-p (H) 3.5V p-p (8 MHz) 1.5V p-p (H)

2.0V p-p (H)

1.1V p-p (V)

9 10 11 12

1.4V p-p (V)

5.7V p-p (H)

13 14

2.8V p-p (H)

3.2V p-p (H)

17 18

7 8

1.8V p-p (H)

4.4V p-p (V)

1.5V p-p (H) 1.1V p-p (H)

4.2V p-p (V)

1.4V p-p (V)

3.1V p-p (H)

855 A Schematic.p65 3/31/99, 6:52 PM1

— 35 —

1.4V p-p (H)

2.6V p-p (H)

90V p-p (H)

21 22 23 24

1.05kV p-p (H) 28.0V p-p (V)

52.8V p-p (V)

25 26

6.1V p-p (V)

A BOARD IC VOLTAGE LIST

110.6V p-p (H)

A BOARD TRANSISTOR VOLTAGE LIST

Q001 4.9 0.7 4.8 Q002 .4 0 .9 Q003 .4 0 .9 Q200 .7 0 GND Q201 .7 0 GND Q202 1.4 .7 GND Q203 1.7 GND .8 Q204 0 .5 GND Q205 4.5 GND 5.2 Q206 4.9 0 3.9 Q207 4.9 0 3.9 Q252 0 7.4 0 Q300 .6 .8 GND Q301 3.6 1.0 3.9 Q302 3.6 GND 3.9 Q303 .7 .1 0 Q305 3.9 GND 4.4 Q340 1.2 5.0 1.3 Q350 .8 GND 1.5 Q351 1.5 8.4 .9 Q352 8.4 1.2 9.0 Q353 1.2 GND 1.8 Q354 1.1 GND 1.7 Q355 1.7 8.4 1.1 Q356 8.4 1.4 9.0 Q357 1.4 GND 2.0 Q358 6.0 9.1 5.3 Q359 3.8 5.2 4.5 Q380 4.8 GND 5.4 Q390 5.7 9.0 5.0 Q391 4.5 9.1 3.8 Q392 0 GND 2.9 Q393 2.3 GND 2.9 Q394 2.2 GND 2.9 Q501 Q502−3.1 111.9−3.1 Q556 2.1 4.4 1.5 Q571 110.8 10.7 111.6 Q601 0 13 GND Q602 .9 3.6 .4 Q605 9.8 10.8 9.1 Q606 .1 3.9 GND Q608 .4 1.5 0 Q650 5.7 9.1 5.1 Q670 .7 .1 0

Q607 1.5 0 152.3

— 36 — — 37 — — 38 —

18.9V p-p (H)

29.4V p-p (V)

BCE

−

.7 48.0 GND

GSD

All voltages are in V

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

C BOARD IC VOLTAGE LIST

IC1751

PIN VOLT

12.1

22.2

32.1 4GND

53.7 6 193.4 7 146.5 8 133.8 9 134.9

All voltages are in V

C BOARD WAVEFORMS

1 2 3

148.4V p-p (H) 118.8V p-p (H) 122.5V p-p (H)

R,G,B DRIVE

CRT DRIVE

123456

A BOARD (*) MARK VARIANT LIST

KV-21MB42C KV-21MB42M

REF NO. LOC. KV-20M42

C202 B-11 # # # 1 1 1 1 C206B-9###1111 C207 B-12 # # # # # # 0. 47 C208 B-12 # # # # # # 0. 47 C209 B-13 # # # # # # 4.7 C211 B-14 # # # # # # 10 C212 C-13 # # # # # # 4.7 C213 C-13 # # # # # # 10 C214 C-16 # # # 0.22 0.22 0.22 0.22 C216 C-17 # # 0.47 0.47 0.47 0.47 0.47 C220 B-18 # # 470 25V 470 25V 470 25V 470 25V 470 25V C229 G-2 # # # # # # 0.01 C233 D-6 # # # 1 1 1 1 C234 D-8 10 10 10 10 10 10 # C260 D-16 1 1 1 # # # # C304 H-11 # # # # # # 0.1 25V F C307 H-12 # # # # # # 10 C340 F-14 # # # # # # 1 C348 I-17 # # # # # # 330p C350 G-16 # # # # # # 0.01 C351 G-16 # # # # # # 10 C352 G-16 # # # # # # 0.01 C353 G-17 # # # # # # 0.1 25V C354 G-17 # # # # # # 0.1 25V C355 G-17 # # # # # # 0.22 25V C356 G-18 # # # # # # 0.1 25V C357 F-17 # # # # # # 0.01 C358 F-17 # # # # # # 47 25V C359 F-17 # # # # # # 0.01 C360 F-16 # # # # # # 0.01 C361 F-15 # # # # # # 0.022 C362 I-12 # # # # # # 10 C400 D-13 # # # # # # 4.7 C401 D-14 # # # # # # 0.1 C402 D-14 # # # # # # .0047 C403 D-14 # # # # # # 4.7 C404 D-14 # # # # # # 4.7 C405 D-14 # # # # # # 4.7 C406 D-15 # # # # # # 4.7 C407 D-15 # # # # # # 10 C410 D-15 # # # # # # 4.7 C411 D-15 # # # # # # 0.1 C412 D-14 # # # # # # 0.1 C413 D-14 # # # # # # 47 C414 D-14 # # # # # # .0047 C415 D-14 # # # # # # 0.1 C416 D-14 # # # # # # 4.7 C418 F-9 10 10 10 10 10 10 4.7 C601 N-2 0.47 125V 0.47 300V 0.47 300V 0.47 125V 0.47 300V .47 300V 0.47 300V C613 L-2 470 250V 330 400V 330 400V 470 250V 330 400V 330 400V 330 400V C616 L-3 # 0.022 400V 0.022 400V # 0.022 400V 0.022 400V 0.022 400V C617 M-3 # 220pF 1KV 220pF 1KV # 220pF 1KV 220pF 220pF 1KV C638 M-2 0.47 # # 0.47 # # #

CN401 D-19 # # 2P 2P 2P 2p 2P

D202 B-11 # # # MTZJ-T-77-10B MTZJ-T-77-10B MTZJ-T-77-10B MTZJ-T-77-10B D204 B-8 # # # MTZJ-T-77-10B MTZJ-T-77-10B MTZJ-T-77-10B MTZJ-T-77-10B D206 H-2 # # # # # # MTZJ-T-77-10B D207 D-11 # # # # # # RD3.3ES-T1B D215 B-16 MTZJ-T-77-10B MTZJ-T-77-10B MTZJ-T-77-10B # # # # D280 G-3 # # # # # # MTZJ-T-77-10B

D609 L-3 # RU-1P RU-1P # RU-1P RU-1P RU-1P FB350 G-16 # # # # # # JW 5MM IC200 D-11 # # # NJM2521M-TE1 NJM2521M-TE1 NJM2521M-TE1 NJM2521M-TE1 IC202 C-13 # # # # # # NJM4558M-TE2 IC302 F-16 # # # # # # CXD2073S IC400 B-16 TDA7056B/N1 TDA7056B/N1 # # # # # IC401 B-18 # # TDA7057AQ/N2 TDA7057AQ/N2 TDA7057AQ/N2 TDA7057AQ/N2 TDA7057AQ/N2 IC402 C-14 # # # # # # CXA2021S IC601 L-4 STR-F6624 STR-F6654 STR-F6654 STR-F6624 STR-F6654 STR-F6654 STR-F6654

J200 A-12 # # # # # # 2P

KV-21MB42P

KV-21ME42

KV-21ME42C

KV-20S42 KV-20S43

KV-21SB42C

KV-21SB42M

KV-21SE42

KV-21SE42C

KV-21SE82

KV-21SE82C

REF NO. LOC. KV-20M42

J201 B-10 2P 2P 2P 3P 3P 3P 3P

J202 B-8 2P 2P 2P 3P 3P 3P 3P JW203 C-18 7.5MM 7.5MM # # # # # JW380 F-13 # # # # # # 7.5MM JW690 L-1 5MM # # 5MM # # # JW691 L-1 5MM # # 5MM # # #

L351 F-17 # # # # # # 47µH

L352 F-16 # # # # # # 10µH PS201 C-17 1-532-637-00 1-532-637-00 1-532-984-11 1-532-984-11 1-532-984-11 1-532-984-11 1-532-984-11

Q200 D-12 # Q201 D-12 # # # # # # 2SD601A Q202 D-17 2SD601A 2SD601A 2SD601A # # # # Q206 C-16 # # # # # # 2SD601A Q207 D-16 # # # # # # 2SD601A Q340 F-14 # # # # # # 2SD601A Q350 H-17 # # # # # # 2SB709A Q351 H-17 # # # # # # 2SD601A Q352 G-16 # # # # # # 2SB709A Q353 H-16 # # # # # # 2SB709A Q354 I-17 # # # # # # 2SB709A Q355 H-17 # # # # # # 2SD601A Q356 H-16 # # # # # # 2SB709A Q357 I-15 # # # # # # 2SB709A Q358 I-12 # # # # # # 2SD601A Q359 I-11 # # # # # # 2SB709A Q380 F-14 # # # # # # 2SB709A R010 G-7 # # # 220 220 220 220 R011 G-7 # # # 220 220 220 220 R051 G-7 # # # 220 220 220 220 R053 F-8 # # # # # # 220 R070 G-8 # # # 4.7K 4.7K 4.7K 4.7K R071 G-8 # # # 4.7K 4.7K 4.7K 4.7K R080 F-7 # # # # # # 10K R202 B-11 # # # 470K 470K 470K 470K R206 B-9 # # # 470K 470K 470K 470K R214 B-12 # # # # # # 470K R215 B-12 # # # # # # 220 R216 B-13 # # # # # # 470K R217 B-13 # # # # # # 220 R218 B-13 # # # # # # 5.6K R219 B-13 # # # # # # 10K R220 B-13 # # # # # # 10K R221 B-13 # # # # # # 10K R222 C-13 # # # # # # 5.6K R223 D-13 # # # # # # 10K R224 C-13 # # # # # # 10K R225 C-13 # # # # # # 10K R226 D-11 # # # # # # 4.7K R227 D-12 # # # # # # 100K R228 D-12 # # # # # # 4.7K R229 D-12 # # # # # # 100K R230 B-14 # # 12K 12K 12K 10K # R231 D-16 # # 12K 12K 12K 10K # R232 C-16 # # # # # # 10K R233 D-16 # # # # # # 10K R234 C-16 # # 3.3K 3.3K 3.3K 3.3K 2.2K R235 D-16 3.3K 3.3K 3.3K 3.3K 3.3K 3.3K 2.2K R237 B-18 # # 220 220 220 220 220 R238 C-18 # # 1K 1K 1K 1K 1K R241 G-8 # # # 4.7K 4.7K 4.7K 4.7K R245 C-17 # # 0 # # # # R246 B-3 0 0 0 # # # # R247 C-16 # # # # # # 100 R248 D-16 # # # # # # 100 R249 C-16 # # # # # # 22K R250 D-16 # # # # # # 22K R260 D-16 100K 100K 100K # # # # R261 D-16 100K 100K 100K # # # # R262 D-17 100 100 100 # # # # R268 C-17 # # 3.3K 3.3K 6.8K 5.6K 22K R269 D-17 5.6K 6.8K 3.3K 3.3K 3.3K 5.6K 22K

KV-21MB42C KV-21MB42M KV-21MB42P

KV-21ME42

KV-21ME42C

# # # # 2SD601A

KV-20S42 KV-20S43

KV-21SB42C KV-21SB42M

KV-21SE42

KV-21SE42C

KV-21SE82

KV-21SE82C

KV-21MB42C

REF NO. LOC. KV-20M42

R283 G-2 # # # # # # 75 R287 G-3 # # # # # # 4.7K R303 F-13 # # # # # # 100 R341 G-15 # # # # # # 47 R342 F-15 # # # # # # 100K R343 F-14 # # # # # # 10K R344 F-14 # # # # # # 3.3K R350 G-17 # # # # # # 220 R351 G-17 # # # # # # 220 R352 G-17 # # # # # # 3.3K R354 G-18 # # # # # # 3.3K R357 F-16 # # # # # # 56K R358 F-16 # # # # # # 560 R359 G-17 # # # # # # 2.2K R360 H-17 # # # # # # 220pF R361 G-17 # # # # # # 1K R362 H-17 # # # # # # 560 R363 H-16 # # # # # # 330 R364 G-16 # # # # # # 100 R365 H-16 # # # # # # 0 R366 G-16 # # # # # # 1.5K R367 H-17 # # # # # # 2.2K R368 I-17 # # # # # # 100 R369 I-16 # # # # # # 680 R370 G-17 # # # # # # 220 R372 I-16 # # # # # # 270 R373 H-16 # # # # # # 100 R374 I-16 # # # # # # 100 R375 H-15 # # # # # # 1.5K R376 I-12 # # # # # # 1K R377 I-12 # # # # # # 1K R378 I-11 # # # # # # 470 R379 H-16 # # # # # # 1K R380 G-17 # # # # # # 2.2K R382 E-14 # # # # # # 1.5K R387 I-17 # # # # # # 100 R388 G-17 # # # # # # 100 R395 I-11 # # # # # # 100 R396 G-16 # # # # # # 100 R397 H-15 # # # # # # 100 R400 F-8 56K 56K 22K 22K 22K 22K 22K R402 D-15 # # # # # # 1M R403 D-15 # # # # # # 220 R404 D-15 # # # # # # 220 R432 F-9 33K 33K 12K 12K 12K 12K 8.2K R433 F-9 27K 27K 12K 12K 12K 12K # R651 M-2 4.7M 8.2M 8.2M 4.7M 8.2M 8.2M 8.2M R652 M-1 # 1.8 1.8 # 1.8 1.8 1.8 R658 L-3 # 100K 100K # 100K 100K 100K R664 L-2 390K 270K 270K 390K 270K 270K 270K R698 L-2 JW 5.0mm 270K 270K JW 5.0mm 270K 270K 270K T603 M-5 1-433-816-11 1-433-817-11 1-433-817-11 1-433-816-11 1-433-817-11 1-433-817-11 1-433-817-11

THP601 M-2 1-810-597-11 1-803-540-11 1-803-540-11 1-810-597-11 1-803-540-11 1-803-540-11 1-803-540-11

TU101 A-2 8-598-430-00 8-598-430-00 8-598-430-00 8-598-431-00 8-598-431-00 8-598-431-00 8-598-431-00

VDR601 N-2 1-803-585-11 1-803-587-11 1-803-587-11 1-803-585-11 1-803-587-11 1-803-587-11 1-803-587-11

KV-21MB42M KV-21MB42P

KV-21ME42

KV-21ME42C

KV-20S42 KV-20S43

KV-21SB42C KV-21SB42M

KV-21SE42

KV-21SE42C

KV-21SE82

KV-21SE82C

#: Not Mounted

C BOARD SCHEMATIC DIAGRAM

12345678

A Board

855 C Board.p65 3/31/99, 7:03 PM1

C Board

— 39 —

— 40 — — 41 — — 42 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

CATHODE

ANODE

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

2SA1091 2SD1292

2SB709 2SD601A

2SD2137

2SC3311A

LETTER SIDE

2SC5426

2SK2845

2SC3209 2SD774

1SS133T-77

D3SB60F D1NS4-TA D1N20R-TA RD3.3ES-T1B

CATHODE

ANODE

MA111-TX RU4AM-T3

ANODE

CATHODE

ANODE

ERC04-06S MTZJ-T-77-5.1C MTZJ-T-77-5.6C MTZJ-T-77-6.2C MTZJ-T-77-8.2B MTZJ-T-77-10B MTZJ-T-77-30D S2L20UF S3L20UF4 RU-1P UDZ-TE-17-5.1B

1SS83TD D1NL20U-TA EL1Z-V1 ERA22-08TP3 EZ0150AV1 RGP10GPKG23 GP08DPKG23

CATHODE

ANODE

 43 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C/21XE42C

SECTION 7

EXPLODED VIEWS

 Items with no part number and no

description are not stocked because they are seldom required for routine service.

Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

 The component parts of an assembly

are indicated by the reference numbers in the remarks column.

Note:

Les composants identifies per un trame et une marque

sont critiques pour la securite. Ne les remplacer

quepar une piece portant le numero specifie.

7-1. CHASSIS (KV-20S43/21SE42/42C/82/82C/ME42/42C)

4-384-096-01 SCREW 4X16 TAPPING +P 4-365-808-01 SCREW 5,TAPPING 7-685-663-79 SCREW +BVTP 4X16 TYPE 2 N-S

 Items marked  *  are not stocked

since they are seldom required for routine service. Some delay should be anticipated when ordering these items.

REF. NO. PART NO. DESCRIPTION REMARK

1 X-1036-731-1 BEZNET ASSY (KV-21ME42/42C) 2-4 1 X-4036-797-1 BEZNET ASSY (KV-20S43) 2-4 1 X-4036-730-1 BEZNET ASSY (KV-21SE42/42C) 2-4 1 X-4035-233-1 BEZNET ASSY (KV-21SE82/82C) 2-4

REF. NO. PART NO. DESCRIPTION REMARK

14 1-416-572-21 COIL, DEMAGNETIC (KV-20S43) 15 * A-1298-885-A A COMPLETE PC BOARD (KV-21SE82/82C) 15 * A-1298-893-A A COMPLETE PC BOARD (KV-20S43) 15 * A-1298-882-A A COMPLETE PC BOARD (KV-21ME42/42C)

15 * A-1298-832-A A COMPLETE PC BOARD (KV-21SE42/42C) 2 4-062-604-01 DOOR (KV-21SE42/42C/21SE82/82C) 2 4-062-596-11 DOOR (KV-20S43) 2 4-062-604-11 DOOR (KV-21ME42/42C)

16 1-751-057-11 CORD, POWER (KV-21SE42/82/ME42)

16 1-769-796-71 CORD, POWER (KV-21SE42C/82C/ME42C)

16 1-790-316-31 CORD, AC POWER (KV-20S43) 3 4-062-597-11 BUTTON, MULTI (KV-20S43)

3 4-062-603-01 BUTTON, MULTI (KV-21ME42/42C/SE82/82C)

17 * 4-062-609-01 BAFFLE, SPEAKER (KV-21SE82/82C ONLY)

18 1-505-404-11 SPEAKER (8CM) (KV-21SE82/82C) 3 4-062-603-11 BUTTON, MULTI (KV-21SE42/42C)

4 4-062-607-01 GUIDE, LED (KV-21ME42/42C/SE42/42C/82/82C) 4 4-062-599-01 GUIDE, LED (KV-20S43)

5 4-046-161-01 EMBLEM (NO.8), SONY 6 * 4-031-698-01 SHEET, ADHESIVE 7 8-738-768-05 CRT 21NX (SD-275)

(KV-20S43/21/ME42/SE42/82)

7 8-738-781-05 CRT 21NX (SD-275/SA)

(KV-21ME42C/SE42C/82C)

8 1-452-277-00 MAGNET, BMC 9 8-451-440-21 DY Y21NXA-X 10 4-053-005-01 SPACER, DY 11 3-704-372-31 HOLDER, HV CABLE 12 * A-1331-917-A C MOUNTED PC BOARD

13 * 4-375-394-01 SPRING, TENSION

14 1-416-951-11 COIL, DEGAUSS (KV-21ME42/42C/SE42/42C/82/82C)

19 X-4033-616-1 COVER ASSY, SPEAKER (KV-21SE82/82C ONLY)

20 8-598-430-00 TUNER, FSS BTF-FA401 (KV-21ME42/42C)

20 8-598-431-00 TUNER, FSS BTF-WA411

21 1-766-374-11 PLUG, F-PIN

22 4-068-826-01 LABEL, REAR COVER

23 4-062-610-03 COVER, REAR (KV-21SE82/82C)

23 4-062-598-44 COVER, REAR (KV-20S43)

23 4-062-602-03 COVER, REAR (KV-21SE42/42C)

23 4-062-602-23 COVER, REAR (KV-21ME42/42C)

24 4-051-735-22 PIECE A(75), CONV. CORRECT

25 1-452-032-00 MAGNET, DISC

26 1-453-283-21 FBT (NX-1744//X4E4)

27 * 4-064-221-01 SPONGE, ACOUSTIC (KV-21SE82/82C ONLY)

28 1-505-831-11 SPEAKER (9X5CM) (KV-20S43/21ME42/42C/)

28 1-505-930-11 SPEAKER (9X5CM) (KV-21SE42/42C)

 44 

(KV-20S43/21SE42/42C/82/82C)

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

Note:

Les composants identifies per un trame et une marque

sont critiques pour la securite. Ne les remplacer

quepar une piece portant le numero specifie.

7-2. CHASSIS (KV-20M42/S42/21MB42C/42M/42P/SB42C/42M)

7-685-648-79 SCREW + BVTP 3X12 TYPE 2 IT3 4-365-808-01 SCREW 5,TAPPING 7-685-663-79 SCREW +BVTP 4X16 TYPE 2 N-S

REF. NO. PART NO. DESCRIPTION REMARK

1 X-4035-231-1 BEZNET ASSY (KV-20M42/21MB42C) 2-4 1 X-4035-309-1 BEZNET ASSY (KV-20S42/21SB42C/42M) 2-4 1 X-4035-306-1 BEZNET ASSY (KV-21MB42P/42M) 2-4

2 4-062-596-21 DOOR (KV-20S42/21SB42C/42M) 2 4-062-596-01 DOOR (KV-20M42/21MB42C/42M/42P)

3 4-062-597-01 BUTTON, MULTI

4 4-062-599-01 GUIDE, LED

5 4-046-161-01 EMBLEM (NO.8), SONY 6 * 4-031-698-01 SHEET, ADHESIVE 7 8-738-768-05 CRT 21NX (SD-275)

7 8-738-781-05 CRT 21NX (SD-275/SA)

8 1-452-277-00 MAGNET, BMC 9 8-451-440-21 DY Y21NXA-X 10 4-053-005-01 SPACER, DY 11 3-704-372-31 HOLDER, HV CABLE 12 * A-1331-917-A C MOUNTED PC BOARD 13 * 4-375-394-01 SPRING, TENSION

14 1-416-951-11 COIL, DEGAUSS (KV-

14 1-416-572-21 COIL, DEMAGNETIC (KV-20M42/S42)

(KV-20M42/S42/21MB42C/42M/42P/SB42C/42M)

(KV-20M42/S42/21MB42P/42M/SB42M)

(KV-21MB42C/SB42C)

21MB42C/42M/42P/SB42C/42M

REF. NO. PART NO. DESCRIPTION REMARK

15 * A-1298-835-A A COMPLETE PC BOARD (KV-20M42) 15 * A-1298-883-A A COMPLETE PC BOARD (KV-21SB42C/42M) 15 * A-1298-893-A A COMPLETE PC BOARD (KV-20S42)

15 * A-1298-881-A A COMPLETE PC BOARD (KV-21MB42C/42P/42M) 16 1-751-057-11 CORD, POWER (KV-21MB42P/42M/SB42M) 16 1-790-001-21 CORD, AC POWER (KV-20M42/S42) 16 1-769-796-71 CORD, POWER (KV-21SB42C/MB42C) 18 1-505-831-11 SPEAKER (9X5CM)

18 1-505-270-11 SPEAKER (9X5CM) (KV-20M42/21MB42C/42M/42P)

20 8-598-430-00 TUNER, FSS BTF-FA401

20 8-598-431-00 TUNER, FSS BTF-WA411

21 1-766-374-11 PLUG, F-PIN 22 4-068-826-01 LABEL, REAR COVER 23 4-062-598-04 COVER, REAR

24 4-051-735-22 PIECE A(75), CONV. CORRECT 25 1-452-032-00 MAGNET, DISC

)

26 1-453-283-21 FBT (NX-1744//X4E4)

(KV-20S42/21SB42C/42M)

(KV-20M42/21MB42C/42M/42P)

(KV-20S42/21SB42C/42M)

(KV-20M42/S42/21MB42C/42M/42P/SB42C/42M)

 45 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C/21XE42C

NOTES:

 46 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

SECTION 8

ELECTRICAL PARTS LIST

PARTS LISTING TABLE OF CONTENTS

Description Page

A BOARD COMMON P ARTS LIST: Parts common to all models listed in this manual...........................46

A BOARD V ARIANT PARTS LIST: Parts that belong only to the model specified.

Refer to the designated variant parts list when seeking a part indicated by an asterisk (*) on the A board schematic, or by the word “variant” on the common parts list.

Model Page

KV-20M42 ............................................55

KV-20S42/20S43 ............................................56

KV-21MB42C/42M/42P.......................................57

KV-21ME42/42C ............................................58

KV-21SB42C/42M ............................................59

KV-21SE42/42C ............................................60

KV-21SE82/82C ............................................61

C BOARD COMPLETE PARTS LIST.....................................................................................................54

P ACKAGING LIST AND ACCESSORIES..............................................................................................63

 47 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C/21XE42C

COMMON PARTS LISTING

Note:

 The components identified by in this

manual have been carefully factoryselected for each set in order to satisfy regulations regarding X-ray radiation. Should replacement be required, replace

RESISTORS  All resistors are in ohms  F : nonflammable

When indicating parts by reference number, please include the board name.

only with the value originally used.

 Items marked  *  are not stocked

sincethey are seldom required for routine service. Some delay should be anticipated when ordering these items.

 All variable and adjustable resistors have

characteristic curve B, unless otherwise noted.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

C047 1-163-259-91 CERAMIC CHIP 220pF 5% 50V

C048 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V

C050 1-163-251-11 CERAMIC CHIP 100pF 5% 50V C051 1-163-251-11 CERAMIC CHIP 100pF 5% 50V

* A BOARD, COMPLETE

A-1298-832-A (KV-21SE42/42C) A-1298-885-A (KV-21SE82/82C) A-1298-893-A (KV-20S42/20S43) A-1298-883-A (KV-21SB42M/42C) A-1298-882-A (KV-21ME42/42C)

A-1298-881-A (KV-21MB42C/42M/42P) A-1298-835-A (KV-20M42) 1-533-223-11 HOLDER, FUSE 4-382-854-1 SCREW (M3X10), P, SW (+) 4-382-854-11 SCREW (M3X10), P, SW (+)

CAPACITOR

C001 1-163-259-91 CERAMIC CHIP 220pF 5% 50V

C004 1-104-664-11 ELECT 47µF 20% 25V C005 1-126-960-11 ELECT 1µF 20% 50V C006 1-163-035-00 CERAMIC CHIP 0.047µF 50V

C007 1-163-259-91 CERAMIC CHIP 220pF 5% 50V

C008 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V C010 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V C011 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V C012 1-163-009-11 CERAMICCHIP 0.001µF 10% 50V

C013 1-163-259-91 CERAMIC CHIP 220pF 5% 50V

C014 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V C017 1-126-960-11 ELECT 1µF 20% 50V

C019 1-163-135-00 CERAMIC CHIP 560pF 5% 50V

C020 1-130-495-00 FILM 0.1µF 5% 50V

C027 1-163-259-91 CERAMIC CHIP 220pF 5% 50V

C028 1-163-005-11 CERAMIC CHIP 470pF 10% 50V C030 1-163-259-91 CERAMIC CHIP 220pF 5% 50V

C034 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V C037 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V C038 1-126-941-11 ELECT 470µF 20% 25V

C039 1-126-964-11 ELECT 10µF 20% 50V C046 1-104-664-11 ELECT 47µF 20% 25V

C052 1-163-251-11 CERAMIC CHIP 100pF 5% 50V C053 1-163-251-11 CERAMIC CHIP 100pF 5% 50V C055 1-163-251-11 CERAMIC CHIP 100pF 5% 50V

C060 1-163-005-11 CERAMIC CHIP 470pF 10% 50V

C062 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V C065 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V

C072 1-163-259-91 CERAMIC CHIP 220pF 5% 50V C074 1-163-251-11 CERAMIC CHIP 100pF 5% 50V C077 1-163-251-11 CERAMIC CHIP 100pF 5% 50V

C091 1-163-231-11 CERAMIC CHIP 15pF 5% 50V C092 1-163-231-11 CERAMIC CHIP 15pF 5% 50V

C101 1-126-963-11 ELECT 4.7µF 20% 50V C150 1-126-935-11 ELECT 470µF 20% 16V C151 1-104-664-11 ELECT 47µF 20% 25V

C160 1-126-382-11 ELECT 100µF 20% 16V C200 1-107-698-11 ELECT 10µF 20% 25V C201 1-126-960-11 ELECT 1µF 20% 50V

C202 VARIANT (SEE VARIANT PARTS LIST)

C203 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V C204 1-107-698-11 ELECT 10µF 20% 25V

C205 1-126-960-11 ELECT 1µF 20% 50V

C206 VARIANT (SEE VARIANT PARTS LIST) C207 VARIANT (SEE VARIANT PARTS LIST) C208 VARIANT (SEE VARIANT PARTS LIST)

C209 VARIANT (SEE VARIANT PARTS LIST) C211 VARIANT (SEE VARIANT PARTS LIST) C212 VARIANT (SEE VARIANT PARTS LIST) C213 VARIANT (SEE VARIANT PARTS LIST) C214 VARIANT (SEE VARIANT PARTS LIST)

C215 1-126-957-11 ELECT 0.22µF 20% 50V

C216 VARIANT (SEE VARIANT PARTS LIST)

C217 1-126-959-11 ELECT 0.47µF 20% 50V C218 1-126-941-11 ELECT 470µF 20% 25V C219 1-130-495-00 FILM 0.1µF 5% 50V

C220 VARIANT (SEE VARIANT PARTS LIST)

C221 1-126-941-11 ELECT 470µF 20% 25V

The components identified by shading andmark safety. Replace only with part number specified.

Note:

Les composants identifies per un trame et une marque pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

are critical for

sont critiques

 48 

Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

C222 1-126-964-11 ELECT 10µF 20% 50V C226 1-107-635-11 ELECT 4.7µF 20% 160V C228 1-126-964-11 ELECT 10µF 20% 50V

C229 VARIANT (SEE VARIANT PARTS LIST)

C232 1-126-960-11 ELECT 1µF 20% 50V

C233 VARIANT (SEE VARIANT PARTS LIST) C234 VARIANT (SEE VARIANT PARTS LIST)

C236 1-163-021-91 CERAMIC CHIP 0.01 µF 10% 50V C243 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V

C260 VARIANT (SEE VARIANT PARTS LIST) C301 1-163-233-11 CERAMIC CHIP 18pF 5% 50V

C303 1-126-964-11 ELECT 10µF 20% 50V

C304 VARIANT (SEE VARIANT PARTS LIST)

C305 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V C306 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V

C307 VARIANT (SEE VARIANT PARTS LIST)

C308 1-126-964-11 ELECT 10µF 20% 50V C309 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C310 1-126-960-11 ELECT 1µF 20% 50V C311 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C312 1-126-942-61 ELECT 1000µF 20% 25V C313 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C314 1-163-009-11 CERAMIC CHIP .001µF 10% 50V

C316 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C317 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C318 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C319 1-126-963-11 ELECT 4.7µF 20% 50V C320 1-126-959-11 ELECT 0.47µF 20% 50V

C321 1-163-133-00 CERAMIC CHIP 470pF 5% 50V C330 1-163-007-11 CERAMIC CHIP 680pF 10% 50V C340 VARIANT (SEE VARIANT PARTS LIST) C348 VARIANT (SEE VARIANT PARTS LIST) C350 VARIANT (SEE VARIANT PARTS LIST)

C351 VARIANT (SEE VARIANT PARTS LIST) C352 VARIANT (SEE VARIANT PARTS LIST) C353 VARIANT (SEE VARIANT PARTS LIST) C354 VARIANT (SEE VARIANT PARTS LIST) C355 VARIANT (SEE VARIANT PARTS LIST)

C356 VARIANT (SEE VARIANT PARTS LIST) C357 VARIANT (SEE VARIANT PARTS LIST) C358 VARIANT (SEE VARIANT PARTS LIST) C359 VARIANT (SEE VARIANT PARTS LIST) C360 VARIANT (SEE VARIANT PARTS LIST)

C361 VARIANT (SEE VARIANT PARTS LIST) C362 VARIANT (SEE VARIANT PARTS LIST)

C373 1-163-038-91 CERAMIC CHIP 0.1 µF 25V C374 1-126-935-11 ELECT 470µF 20% 16V

C375 1-163-038-91 CERAMIC CHIP 0.1µF 25V C376 1-104-664-11 ELECT 47µF 20% 25V C390 1-130-495-00 FILM 0.1µF 5% 50V

C400 VARIANT (SEE VARIANT PARTS LIST)

C401 VARIANT (SEE VARIANT PARTS LIST) C402 VARIANT (SEE VARIANT PARTS LIST) C403 VARIANT (SEE VARIANT PARTS LIST) C404 VARIANT (SEE VARIANT PARTS LIST) C405 VARIANT (SEE VARIANT PARTS LIST)

C406 VARIANT (SEE VARIANT PARTS LIST) C407 VARIANT (SEE VARIANT PARTS LIST) C410 VARIANT (SEE VARIANT PARTS LIST) C411 VARIANT (SEE VARIANT PARTS LIST) C412 VARIANT (SEE VARIANT PARTS LIST)

C413 VARIANT (SEE VARIANT PARTS LIST) C414 VARIANT (SEE VARIANT PARTS LIST) C415 VARIANT (SEE VARIANT PARTS LIST) C416 VARIANT (SEE VARIANT PARTS LIST) C418 VARIANT (SEE VARIANT PARTS LIST)

C502 1-106-371-00 MYLAR 0.015µF 20% 200V

C504 1-102-228-00 CERAMIC 470pF 10% 500V C505 1-117-626-11 FILM 2000pF 3% 1.2KV C507 1-117-633-11 FILM 3900pF 3% 1.2KV

C508 1-106-371-00 MYLAR 0.015µF 20% 200V

C509 1-162-115-00 CERAMIC 330pF 10% 2KV

C511 1-117-665-11 FILM 0.33µF 5% 250V C520 1-129-722-00 FILM 0.047µF 5% 630V C531 1-106-387-00 MYLAR 0.068µF 10% 200V C541 1-126-969-11 ELECT 220µF 20% 50V

C542 1-126-967-11 ELECT 47µF 20% 50V C543 1-136-169-00 FILM 0.22µF 5% 50V

C552 1-102-244-00 CERAMIC 220pF 10% 500V

C553 1-107-652-11 ELECT 10µF 20% 250V C556 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V

C561 1-102-244-00 CERAMIC 220pF 10% 500V

C562 1-126-941-11 ELECT 470µF 20% 25V C563 1-137-417-11 MYLAR 0.0047µF 10% 200V C564 1-126-941-11 ELECT 470µF 20% 25V C571 1-126-965-11 ELECT 22µF 20% 50V C573 1-126-963-11 ELECT 4.7µF 20% 50V

C574 1-107-635-11 ELECT 4.7µF 20% 160V C575 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C576 1-123-024-21 ELECT 33µF 160V C577 1-126-959-11 ELECT 0.47µF 20% 50V C591 1-137-150-11 MYLAR 0.01µF 10% 100V

C601 VARIANT (SEE VARIANT PARTS LIST)

C602 1-113-941-11 CERAMIC 0.0047µF 20% 125V C603 1-113-941-11 CERAMIC 0.0047µF 20% 125V

 49 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

Note: Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

C604 1-113-941-11 CERAMIC 0.0047µF 20% 125V C605 1-113-941-11 CERAMIC 0.0047µF 20% 125V

C611 1-125-772-91 CERAMIC 1500pF 10% 2KV C613 VARIANT (SEE VARIANT PARTS LIST)

C614 1-130-471-00 MYLAR 0.001µF 5% 50V

C616 VARIANT (SEE VARIANT PARTS LIST) C617 VARIANT (SEE VARIANT PARTS LIST)

C618 1-136-619-11 FILM 0.0016µF 3% 2KV

C620 1-102-114-00 CERAMIC 470pF 10% 50V C621 1-136-356-11 FILM 470pF 5% 50V

C622 1-136-479-11 FILM 0.001µF 5% 50V C623 1-136-153-00 FILM 0.01µF 5% 50V C626 1-126-959-11 ELECT 0.47µF 20% 50V C628 1-104-665-11 ELECT 100µF 20% 25V C629 1-104-665-11 ELECT 100µF 20% 25V

C630 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C631 1-126-768-11 ELECT 2200µF 20% 16V C632 1-126-942-61 ELECT 1000µF 20% 25V C633 1-126-967-11 ELECT 47µF 20% 50V C634 1-124-347-00 ELECT 100µF 20% 160V

C638 VARIANT (SEE VARIANT PARTS LIST) C641 1-102-002-00 CERAMIC 680pF 10% 500V

C643 1-113-924-11 CERAMIC 0.0047µF 20% 250V C644 1-113-924-11 CERAMIC 0.0047µF 20% 250V C645 1-137-605-11 FILM 0.01µF 10% 250V

CN601 * 1-580-843-11 PIN, CONNECTOR (POWER) CN602 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P

DIODE

D001 8-719-921-44 DIODE MTZJ-5.1C D002 1-810-039-21 LED UNIT D003 8-719-991-33 DIODE 1SS133T-77 D004 8-719-991-33 DIODE 1SS133T-77 D201 8-719-110-17 DIODE RD10ESB2

D202 VARIANT (SEE VARIANT PARTS LIST) D203 8-719-110-17 DIODE RD10ESB2 D204 VARIANT (SEE VARIANT PARTS LIST) D205 8-719-982-22 DIODE MTZJ-30D D206 VARIANT (SEE VARIANT PARTS LIST)

D207 VARIANT (SEE VARIANT PARTS LIST) D208 8-719-110-17 DIODE RD10ESB2 D209 8-719-110-17 DIODE RD10ESB2 D210 8-719-110-17 DIODE RD10ESB2 D215 VARIANT (SEE VARIANT PARTS LIST)

D280 VARIANT (SEE VARIANT PARTS LIST) D301 8-719-110-08 DIODE RD8.2ESB2 D302 8-719-921-44 DIODE MTZJ-5.1C D310 8-719-404-50 DIODE MA111-TX D311 8-719-404-50 DIODE MA111-TX

C646 1-107-679-91 ELECT 10µF 20% 450V

C647 1-130-467-00 MYLAR 470pF 5% 50V

C648 1-162-318-11 CERAMIC 0.001µF 10% 500V C650 1-130-471-00 MYLAR 0.001µF 5% 50V C651 1-126-382-11 ELECT 100µF 20% 16V

C653 1-104-664-11 ELECT 47µF 20% 25V C654 1-126-970-11 ELECT 330µF 20% 50V C656 1-126-965-11 ELECT 22µF 20% 50V

C657 1-102-002-00 CERAMIC 680pF 10% 500V

C690 1-126-959-11 ELECT 0.47µF 20% 50V C691 1-126-941-11 ELECT 470µF 20% 25V

C692 1-104-664-11 ELECT 47µF 20% 25V C693 1-137-194-81 FILM 0.47µF 5% 50V

CONNECTOR

CN203 * 1-560-124-00 PLUG, CONNECTOR (2.5MM) 4P CN301 * 1-564-508-11 PLUG, CONNECTOR 5P CN401 VARIANT (SEE VARIANT PARTS LIST) CN402 * 1-564-505-11 PLUG, CONNECTOR 2P CN501 * 1-580-798-11 CONNECTOR PIN (DY) 6P

CN502 * 1-564-509-11 PLUG, CONNECTOR 6P

D320 8-719-976-99 DIODE DTZ5.1B D403 8-719-991-33 DIODE 1SS133T-77 D434 8-719-991-33 DIODE 1SS133T-77 D501 8-719-945-80 DIODE ERC06-15S D502 8-719-302-43 DIODE EL1Z

D520 8-719-067-63 DIODE MDV04-600RL D541 8-719-908-03 DIODE GP08D D552 8-719-302-43 DIODE EL1Z D561 8-719-979-85 DIODE EGP20G D562 8-719-979-85 DIODE EGP20G

D571 8-719-991-33 DIODE 1SS133T-77 D572 8-719-991-33 DIODE 1SS133T-77 D573 8-719-110-08 DIODE RD8.2ESB2 D574 8-719-302-43 DIODE EL1Z D581 8-719-991-33 DIODE 1SS133T-77

D601 8-719-510-51 DIODE D3SB60F D602 8-719-991-33 DIODE 1SS133T-77 D603 8-719-063-70 DIODE D1NL20U D609 VARIANT (SEE VARIANT PARTS LIST) D611 8-719-110-17 DIODE RD10ESB2

D613 8-719-063-70 DIODE D1NL20U D614 8-719-063-70 DIODE D1NL20U

 50 

Note:

The components identified by shading and mark are critical for safety. Replace only with part number specified.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer que par une piece portant le numero specifie.

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

D615 8-719-510-02 DIODE D1NS4 D616 8-719-510-73 DIODE S3L20UF4 D617 8-719-027-43 DIODE S2L20UF

IC602 8-759-198-31 IC UPC1093J-1-T

JACK

D620 8-719-057-52 DIODE EZ0150AV1 D631 8-719-911-55 DIODE U05G D632 8-719-911-55 DIODE U05G D633 8-719-948-45 DIODE ERA22-08 D634 8-719-991-33 DIODE 1SS133T-77 D635 8-719-991-33 DIODE 1SS133T-77

J200 VARIANT (SEE VARIANT PARTS LIST) J201 VARIANT (SEE VARIANT PARTS LIST) J202 VARIANT (SEE VARIANT PARTS LIST) J400 1-568-267-21 JACK

D636 8-719-063-70 DIODE D1NL20U D637 8-719-109-93 DIODE RD6.2ESB2 D638 8-719-510-48 DIODE D1N20R D650 8-719-109-89 DIODE RD5.6ESB2 D653 8-719-312-10 DIODE RU4AM-T3 D670 8-719-991-33 DIODE 1SS133T-77

FUSE

F601 1-532-506-51 FUSE 6.3A/250V (except KV-20M42/20S42/20S43) F601 1-533-795-11 FUSE 6.3A/125V (KV-20M42/20S42/20S43 only)

FERRITE BEAD

FB501 1-410-396-41FERRITE 0.45mH FB600 1-410-397-21 FERRITE 1.1µH FB601 1-410-397-21 FERRITE 1.1µH FB602 1-410-397-21 FERRITE 1.1µH FB604 1-410-397-21 FERRITE 1.1µH

FB605 1-410-397-21 FERRITE 1.1µH FB606 1-410-397-21 FERRITE 1.1µH FB609 1-412-911-11 FERRITE 0µH FB611 1-410-397-21 FERRITE 1.1µH

CHIP CONDUCTOR

JR002 1-216-295-91 SHORT JR003 1-216-295-91 SHORT

COIL

L001 1-414-267-11 INDUCTOR 10µH L002 1-414-273-11 INDUCTOR 100µH L003 1-414-273-11 INDUCTOR 100µH L150 1-414-273-11 INDUCTOR 100µH L151 1-414-267-11 INDUCTOR 10µH

L160 1-414-267-11 INDUCTOR 10µH L301 1-414-271-11 INDUCTOR 47µH L302 1-414-267-11 INDUCTOR 10µH L351 VARIANT (SEE VARIANT PARTS LIST) L352 VARIANT (SEE VARIANT PARTS LIST)

L503 1-412-553-11 INDUCTOR 3.3µH L504 1-412-533-21 INDUCTOR 47µH L591 1-412-531-31 INDUCTOR 33µH

PHOTO COUPLER

PH600 8-749-010-64 PHOTO COUPLER PC123F2

IC001 8-759-576-00 IC M37273MF-252SP IC002 8-759-575-47 IC NJM78LR05BM-TE2 IC003 8-759-527-75 IC M24C04-MN6T IC004 8-742-014-11 HYB IC SBX1981-51 IC200 VARIANT (SEE VARIANT PARTS LIST)

IC201 8-759-450-93 IC NJM2521M-TE1 IC202 VARIANT (SEE VARIANT PARTS LIST) IC301 8-752-083-09 IC CXA2061S IC302 VARIANT (SEE VARIANT PARTS LIST) IC400 VARIANT (SEE VARIANT PARTS LIST)

IC401 VARIANT (SEE VARIANT PARTS LIST) IC402 VARIANT (SEE VARIANT PARTS LIST) IC521 8-759-100-96 IC NJM4558M-TE2 IC541 8-759-980-58 IC TDA8172 IC601 VARIANT (SEE VARIANT PARTS LIST)

IC LINK

PS201 VARIANT (SEE VARIANT PARTS LIST)

TRANSISTOR

Q001 8-729-216-22 TRANSISTOR 2SB709A-QRS-TX Q002 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX Q003 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX Q200 VARIANT (SEE VARIANT PARTS LIST) Q201 VARIANT (SEE VARIANT PARTS LIST)

Q202 VARIANT (SEE VARIANT PARTS LIST) Q203 8-729-216-22 TRANSISTOR 2SA1162-G Q205 8-729-216-22 TRANSISTOR 2SA1162-G Q206 VARIANT (SEE VARIANT PARTS LIST)

— 51 —

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

Note: Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

Q207 VARIANT (SEE VARIANT PARTS LIST) Q252 8-729-422-27 TRANSISTOR 2SD601A-Q Q300 8-729-422-27 TRANSISTOR 2SD601A-Q Q301 8-729-216-22 TRANSISTOR 2SA1162-G Q302 8-729-216-22 TRANSISTOR 2SA1162-G Q303 8-729-119-78 TRANSISTOR 2SC2785-HFE

Q305 8-729-216-22 TRANSISTOR 2SA1162-G Q340 VARIANT (SEE VARIANT PARTS LIST) Q350 VARIANT (SEE VARIANT PARTS LIST) Q351 VARIANT (SEE VARIANT PARTS LIST) Q352 VARIANT (SEE VARIANT PARTS LIST)

Q353 VARIANT (SEE VARIANT PARTS LIST) Q354 VARIANT (SEE VARIANT PARTS LIST) Q355 VARIANT (SEE VARIANT PARTS LIST) Q356 VARIANT (SEE VARIANT PARTS LIST) Q357 VARIANT (SEE VARIANT PARTS LIST)

Q358 VARIANT (SEE VARIANT PARTS LIST) Q359 VARIANT (SEE VARIANT PARTS LIST) Q380 VARIANT (SEE VARIANT PARTS LIST) Q390 8-729-422-27 TRANSISTOR 2SD601A-Q Q391 8-729-422-27 TRANSISTOR 2SD601A-Q

Q392 8-729-216-22 TRANSISTOR 2SA1162-G Q393 8-729-216-22 TRANSISTOR 2SA1162-G Q394 8-729-216-22 TRANSISTOR 2SA1162-G Q501 8-729-140-50 TRANSISTOR 2SC3209LK Q502 8-729-043-43 TRANSISTOR 2SC5426-01

R013 1-247-863-91 CARBON 22K 5% 1/4W R016 1-249-413-11 CARBON 470 5% 1/4W R017 1-216-113-00 RES, CHIP 470K 5% 1/10W R018 1-249-417-11 CARBON 1K 5% 1/4W R019 1-249-425-11 CARBON 4.7K 5% 1/4W R020 1-249-427-11 CARBON 6.8K 5% 1/4W

R021 1-249-415-11 CARBON 680 5% 1/4W R022 1-249-416-11 CARBON 820 5% 1/4W R023 1-249-421-11 CARBON 2.2K 5% 1/4W R025 1-249-426-11 CARBON 5.6K 5% 1/4W R026 1-249-426-11 CARBON 5.6K 5% 1/4W

R027 1-249-426-11 CARBON 5.6K 5% 1/4W R028 1-216-049-91 RES, CHIP 1K 5% 1/10W R030 1-249-429-11 CARBON 10K 5% 1/4W R031 1-216-045-00 RES, CHIP 680 5% 1/10W R032 1-216-033-00 RES, CHIP 220 5% 1/10W

R033 1-247-815-91 CARBON 220 5% 1/4W R038 1-216-049-91 RES, CHIP 1K 5% 1/10W R040 1-249-413-11 CARBON 470 5% 1/4W R043 1-249-417-11 CARBON 1K 5% 1/4W R044 1-216-033-00 RES, CHIP 220 5% 1/10W

R045 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R046 1-216-033-00 RES, CHIP 220 5% 1/10W R047 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R048 1-216-025-91 RES, CHIP 100 5% 1/10W R049 1-216-089-91 RES, CHIP 47K 5% 1/10W

Q556 8-729-422-27 TRANSISTOR 2SD601A-Q Q571 8-729-200-17 TRANSISTOR 2SA1091-O Q601 8-729-119-78 TRANSISTOR 2SC2785-HFE Q602 8-729-422-27 TRANSISTOR 2SD601A-Q Q605 8-729-423-99 TRANSISTOR 2SD2137-OP

Q606 8-729-111-55 TRANSISTOR 2SD1312-K Q607 8-729-044-30 TRANSISTOR 2SK2845-LB102 Q608 8-729-119-78 TRANSISTOR 2SC2785-HFE Q650 8-729-111-55 TRANSISTOR 2SD1312-K Q670 8-729-140-96 TRANSISTOR 2SD774-34

RESISTOR

R001 1-249-429-11 CARBON 10K 5% 1/4W R002 1-249-429-11 CARBON 10K 5% 1/4W R003 1-216-033-00 RES, CHIP 220 5% 1/10W R004 1-216-073-00 RES, CHIP 10K 5% 1/10W R005 1-247-815-91 CARBON 220 5% 1/4W

R007 1-216-025-91 RES, CHIP 100 5% 1/10W R008 1-216-033-00 RES, CHIP 220 5% 1/10W R009 1-247-815-91 CARBON 220 5% 1/4W R010 VARIANT (SEE VARIANT PARTS LIST) R011 VARIANT (SEE VARIANT PARTS LIST)

R050 1-249-429-11 CARBON 10K 5% 1/4W R051 VARIANT (SEE VARIANT PARTS LIST) R053 VARIANT (SEE VARIANT PARTS LIST) R054 1-216-073-00 RES, CHIP 10K 5% 1/10W R055 1-216-033-00 RES, CHIP 220 5% 1/10W

R056 1-249-425-11 CARBON 4.7K 5% 1/4W R057 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R058 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R065 1-216-033-00 RES, CHIP 220 5% 1/10W R066 1-216-033-00 RES, CHIP 220 5% 1/10W

R070 VARIANT (SEE VARIANT PARTS LIST) R071 VARIANT (SEE VARIANT PARTS LIST) R072 1-247-815-91 CARBON 220 5% 1/4W R074 1-216-073-00 RES, CHIP 10K 5% 1/10W R075 1-216-073-00 RES, CHIP 10K 5% 1/10W

R076 1-216-121-91 RES, CHIP 1M 5% 1/10W R077 1-216-097-91 RES, CHIP 100K 5% 1/10W R078 1-216-049-91 RES, CHIP 1K 5% 1/10W R080 VARIANT (SEE VARIANT PARTS LIST) R085 1-216-073-00 RES, CHIP 10K 5% 1/10W R086 1-216-073-00 RES, CHIP 10K 5% 1/10W R087 1-216-045-00 RES, CHIP 680 5% 1/10W

 52 

Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

R088 1-216-045-00 RES, CHIP 680 5% 1/10W R089 1-216-045-00 RES, CHIP 680 5% 1/10W

R090 1-249-429-11 CARBON 10K 5% 1/4W R091 1-249-429-11 CARBON 10K 5% 1/4W R092 1-216-051-00 RES, CHIP 1K 5% 1/10W R093 1-249-425-11 CARBON 4.7K 5% 1/4W R096 1-216-057-00 RES, CHIP 2.2K 5% 1/10W

R097 1-216-073-00 RES, CHIP 10K 5% 1/10W R099 1-249-425-11 CARBON 4.7K 5% 1/4W R101 1-216-073-00 RES, CHIP 10K 5% 1/10W R150 1-216-025-91 RES, CHIP 100 5% 1/10W R151 1-216-025-91 RES, CHIP 100 5% 1/10W

R201 1-216-113-00 RES, CHIP 470K 5% 1/10W R202 VARIANT (SEE VARIANT PARTS LIST) R204 1-216-022-00 RES, CHIP 75 5% 1/10W R205 1-247-895-91 CARBON 470K 5% 1/4W R206 VARIANT (SEE VARIANT PARTS LIST)

R214 VARIANT (SEE VARIANT PARTS LIST) R215 VARIANT (SEE VARIANT PARTS LIST) R216 VARIANT (SEE VARIANT PARTS LIST) R217 VARIANT (SEE VARIANT PARTS LIST) R218 VARIANT (SEE VARIANT PARTS LIST)

R219 VARIANT (SEE VARIANT PARTS LIST) R220 VARIANT (SEE VARIANT PARTS LIST) R221 VARIANT (SEE VARIANT PARTS LIST) R222 VARIANT (SEE VARIANT PARTS LIST) R223 VARIANT (SEE VARIANT PARTS LIST)

R224 VARIANT (SEE VARIANT PARTS LIST) R225 VARIANT (SEE VARIANT PARTS LIST) R226 VARIANT (SEE VARIANT PARTS LIST) R227 VARIANT (SEE VARIANT PARTS LIST) R228 VARIANT (SEE VARIANT PARTS LIST)

R229 VARIANT (SEE VARIANT PARTS LIST) R230 VARIANT (SEE VARIANT PARTS LIST) R231 VARIANT (SEE VARIANT PARTS LIST) R232 VARIANT (SEE VARIANT PARTS LIST) R233 VARIANT (SEE VARIANT PARTS LIST)

R234 VARIANT (SEE VARIANT PARTS LIST) R235 VARIANT (SEE VARIANT PARTS LIST) R237 VARIANT (SEE VARIANT PARTS LIST) R238 VARIANT (SEE VARIANT PARTS LIST) R239 1-247-815-91 CARBON 220 5% 1/4W

R240 1-249-417-11 CARBON 1K 5% 1/4W R241 VARIANT (SEE VARIANT PARTS LIST) R242 1-249-434-11 CARBON 27K 5% 1/4W R243 1-216-689-11 RES, CHIP 39K 5% 1/10W R245 VARIANT (SEE VARIANT PARTS LIST)

R246 VARIANT (SEE VARIANT PARTS LIST) R247 VARIANT (SEE VARIANT PARTS LIST) R248 VARIANT (SEE VARIANT PARTS LIST)

R249 VARIANT (SEE VARIANT PARTS LIST) R250 VARIANT (SEE VARIANT PARTS LIST) R251 1-216-041-00 RES, CHIP 470 5% 1/10W R252 1-216-041-00 RES, CHIP 470 5% 1/10W R253 1-215-899-11 METAL OXIDE 15K 5% 2W F

R254 1-216-025-91 RES, CHIP 100 5% 1/10W R255 1-216-025-91 RES, CHIP 100 5% 1/10W R256 1-249-425-11 CARBON 4.7K 5% 1/4W R257 1-216-073-00 RES, CHIP 10K 5% 1/10W R260 VARIANT (SEE VARIANT PARTS LIST)

R261 VARIANT (SEE VARIANT PARTS LIST) R262 VARIANT (SEE VARIANT PARTS LIST) R268 VARIANT (SEE VARIANT PARTS LIST) R269 VARIANT (SEE VARIANT PARTS LIST) R280 1-216-022-00 RES, CHIP 75 5% 1/10W

R283 VARIANT (SEE VARIANT PARTS LIST) R284 1-216-295-91 SHORT R287 VARIANT (SEE VARIANT PARTS LIST) R288 1-216-295-91 SHORT R289 1-216-295-91 SHORT

R290 1-216-025-91 RES, CHIP 100 5% 1/10W R291 1-216-065-91 RES, CHIP 2.2K 5% 1/10W R293 1-249-429-11 CARBON 10K 5% 1/4W R294 1-216-295-91 SHORT R295 1-216-295-91 SHORT

R297 1-247-807-31 CARBON 100 5% 1/4W R298 1-216-025-91 RES, CHIP 100 5% 1/10W R301 1-216-295-91 SHORT R303 VARIANT (SEE VARIANT PARTS LIST) R304 1-216-073-00 RES, CHIP 10K 5% 1/10W

R306 1-216-675-11 METAL CHIP 10K 0.5% 1/10W R307 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R308 1-247-887-00 CARBON 220K 5% 1/4W R309 1-247-863-91 CARBON 22K 5% 1/4W R310 1-216-049-91 RES, CHIP 1K 5% 1/10W

R312 1-216-033-00 RES, CHIP 220 5% 1/10W R313 1-247-815-91 CARBON 220 5% 1/4W R314 1-247-815-91 CARBON 220 5% 1/4W R315 1-247-815-91 CARBON 220 5% 1/4W R316 1-216-025-91 RES, CHIP 100 5% 1/10W

R317 1-249-421-11 CARBON 2.2K 5% 1/4W R318 1-216-073-00 RES, CHIP 10K 5% 1/10W R319 1-216-073-00 RES, CHIP 10K 5% 1/10W R321 1-216-069-00 RES, CHIP 6.8K 5% 1/10W

 53 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

Note: Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

R322 1-216-073-00 RES, CHIP 10K 5% 1/10W R323 1-249-415-11 CARBON 680 5% 1/4W R324 1-249-425-11 CARBON 4.7K 5% 1/4W R325 1-216-097-91 RES, CHIP 100K 5% 1/10W R329 1-216-025-91 RES, CHIP 100 5% 1/10W

R330 1-216-025-91 RES, CHIP 100 5% 1/10W R331 1-216-025-91 RES, CHIP 100 5% 1/10W R341 VARIANT (SEE VARIANT PARTS LIST) R342 VARIANT (SEE VARIANT PARTS LIST) R343 VARIANT (SEE VARIANT PARTS LIST)

R344 VARIANT (SEE VARIANT PARTS LIST) R347 1-216-045-00 RES, CHIP 680 5% 1/10W R350 VARIANT (SEE VARIANT PARTS LIST) R351 VARIANT (SEE VARIANT PARTS LIST) R352 VARIANT (SEE VARIANT PARTS LIST)

R353 1-216-295-91 SHORT R354 VARIANT (SEE VARIANT PARTS LIST) R356 1-216-057-00 RES, CHIP 2.2K 5% 1/10W R357 VARIANT (SEE VARIANT PARTS LIST) R358 VARIANT (SEE VARIANT PARTS LIST)

R359 VARIANT (SEE VARIANT PARTS LIST) R360 VARIANT (SEE VARIANT PARTS LIST) R361 VARIANT (SEE VARIANT PARTS LIST) R362 VARIANT (SEE VARIANT PARTS LIST) R363 VARIANT (SEE VARIANT PARTS LIST)

R364 VARIANT (SEE VARIANT PARTS LIST) R365 VARIANT (SEE VARIANT PARTS LIST) R366 VARIANT (SEE VARIANT PARTS LIST) R367 VARIANT (SEE VARIANT PARTS LIST) R368 VARIANT (SEE VARIANT PARTS LIST)

R369 VARIANT (SEE VARIANT PARTS LIST) R370 VARIANT (SEE VARIANT PARTS LIST) R372 VARIANT (SEE VARIANT PARTS LIST) R373 VARIANT (SEE VARIANT PARTS LIST) R374 VARIANT (SEE VARIANT PARTS LIST)

R375 VARIANT (SEE VARIANT PARTS LIST) R376 VARIANT (SEE VARIANT PARTS LIST) R377 VARIANT (SEE VARIANT PARTS LIST) R378 VARIANT (SEE VARIANT PARTS LIST) R379 VARIANT (SEE VARIANT PARTS LIST)

R380 VARIANT (SEE VARIANT PARTS LIST) R382 VARIANT (SEE VARIANT PARTS LIST) R383 1-216-057-00 RES, CHIP 2.2K 5% 1/10W R384 1-216-057-00 RES, CHIP 2.2K 5% 1/10W R385 1-216-057-00 RES, CHIP 2.2K 5% 1/10W

R387 VARIANT (SEE VARIANT PARTS LIST) R388 VARIANT (SEE VARIANT PARTS LIST)

R390 1-216-025-91 RES, CHIP 100 5% 1/10W R391 1-216-049-91 RES, CHIP 1K 5% 1/10W R392 1-216-025-91 RES, CHIP 100 5% 1/10W R393 1-216-049-91 RES, CHIP 1K 5% 1/10W

R394 1-216-025-91 RES, CHIP 100 5% 1/10W R395 VARIANT (SEE VARIANT PARTS LIST) R396 VARIANT (SEE VARIANT PARTS LIST) R397 VARIANT (SEE VARIANT PARTS LIST) R400 VARIANT (SEE VARIANT PARTS LIST)

R402 VARIANT (SEE VARIANT PARTS LIST) R403 VARIANT (SEE VARIANT PARTS LIST) R404 VARIANT (SEE VARIANT PARTS LIST) R432 VARIANT (SEE VARIANT PARTS LIST) R433 VARIANT (SEE VARIANT PARTS LIST)

R501 1-249-421-11 CARBON 2.2K 5% 1/4W R502 1-215-923-00 METAL OXIDE 10K 5% 3W F R508 1-215-864-00 METAL OXIDE 150 5% 1W F R532 1-215-437-00 METAL 4.7K 1% 1/4W R533 1-215-461-00 METAL 47K 1% 1/4W

R534 1-215-453-00 METAL 22K 1% 1/4W R535 1-249-441-11 CARBON 100K 5% 1/4W R541 1-216-065-91 RES,CHIP 4.7K 5% 1/10W R542 1-249-429-11 CARBON 10K 5% 1/4W R543 1-249-429-11 CARBON 10K 5% 1/4W

R544 1-216-377-11 METAL OXIDE 4.7 5% 2W F R546 1-215-890-11 METAL OXIDE 470 5% 2W F R547 1-249-385-11 CARBON 2.2 5% 1/4W F R548 1-249-425-11 CARBON 4.7K 5% 1/4W R549 1-216-073-00 RES, CHIP 10K 5% 1/10W

R552 1-247-887-00 CARBON 220K 5% 1/4W R553 1-260-312-11 CARBON 47 5% 1/2W R559 1-216-101-00 RES, CHIP 150K 5% 1/10W R560 1-216-093-91 RES, CHIP 68K 5% 1/10W R561 1-216-349-00 METAL OXIDE 1 5% 1W F

R562 1-216-349-00 METAL OXIDE 1 5% 1W F R565 1-216-081-00 RES, CHIP 22K 5% 1/10W R566 1-216-077-00 RES, CHIP 15K 5% 1/10W R567 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R568 1-216-121-91 RES, CHIP 1M 5% 1/10W

R571 1-216-369-00 METAL OXIDE 1 5% 2W F R572 1-249-421-11 CARBON 2.2K 5% 1/4W R573 1-247-895-91 CARBON 470K 5% 1/4W R574 1-249-417-11 CARBON 1K 5% 1/4W F R575 1-247-891-00 CARBON 330K 5% 1/4W

R576 1-249-441-11 CARBON 100K 5% 1/4W R577 1-249-432-11 CARBON 18K 5% 1/4W R578 1-216-467-11 METAL OXIDE 56K 5% 2W F

 54 

Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMMON PARTS LISTING

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

R579 1-208-777-11 RES, CHIP 620 0.5% 1/10W R580 1-216-295-91 SHORT R582 1-208-826-11 RES, CHIP 68K 0.5% 1/10W

R583 1-208-830-11 RES, CHIP 100K 0.5% 1/10W R584 1-208-806-11 RES, CHIP 10K 0.5% 1/10W R585 1-216-085-00 RES, CHIP 33K 5% 1/10W R586 1-216-069-00 RES, CHIP 6.8K 5% 1/10W R591 1-215-880-00 METAL OXIDE 10 5% 2W F

R602 1-249-389-11 CARBON 4.7 5% 1/4W F R603 1-247-895-91 CARBON 470K 5% 1/4W R608 1-240-205-91 CARBON 22M 5% 1/2W R609 1-249-421-11 CARBON 2.2K 5% 1/4W R610 1-249-417-11 CARBON 1K 5% 1/4W

R661 1-216-485-11 METAL OXIDE 5.6K 5% 3W F R662 1-260-288-11 CARBON 0.47 5% 1/2W

R663 1-216-362-11 METAL OXIDE 0.27 5% 2W F R664 VARIANT (SEE VARIANT PARTS LIST) R670 1-249-421-11 CARBON 2.2K 5% 1/4W R671 1-249-417-11 CARBON 1K 5% 1/4W R672 1-216-485-11 METAL OXIDE 5.6K 5% 3W F

R674 1-249-415-11 CARBON 680 5% 1/4W R675 1-215-859-00 METAL OXIDE 22 5% 1W F R682 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R683 1-249-421-11 CARBON 2.2K 5% 1/4W R688 1-216-485-11 METAL OXIDE 5.6K 5% 3W F R698 1-215-479-00 METAL 270K 1% 1/4W

R611 1-249-437-11 CARBON 47K 5% 1/4W R612 1-249-415-11 CARBON 680 5% 1/4W R614 1-249-429-11 CARBON 10K 5% 1/4W R616 1-260-302-51 CARBON 6.8 5% 1/2W R617 1-249-415-11 CARBON 680 5% 1/4W

R620 1-219-512-11 CARBON 2.2M 5% 1/2W R623 1-249-429-11 CARBON 10K 5% 1/4W R625 1-215-429-00 METAL 2.2K 1% 1/4W R626 1-215-469-00 METAL 100K 1% 1/4W R630 1-249-421-11 CARBON 2.2K 5% 1/4W

R631 1-249-429-11 CARBON 10K 5% 1/4W R632 1-208-806-11 RES, CHIP 10K 5% 1/10W R633 1-215-457-00 METAL 33K 1% 1/4W R634 1-249-417-11 CARBON 1K 5% 1/4W R635 1-216-073-00 RES, CHIP 10K 5% 1/10W

R636 1-208-798-11 RES, CHIP 4.7K 0.5% 1/10W R637 1-208-806-11 RES, CHIP 10K 0.5% 1/10W R638 1-208-814-91 RES, CHIP 22K 0.5% 1/10W R639 1-216-089-91 RES, CHIP 47K 5% 1/10W R640 1-216-089-91 RES, CHIP 47K 5% 1/10W

R641 1-216-397-11 METAL OXIDE 4.7 5% 3W F R643 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R644 1-249-418-11 CARBON 1.2K 5% 1/4W R647 1-260-081-11 CARBON 33 5% 1/2W R648 1-249-421-11 CARBON 2.2K 5% 1/4W

R649 1-249-413-11 CARBON 470 5% 1/4W R650 1-249-415-11 CARBON 680 5% 1/4W R651 VARIANT (SEE VARIANT PARTS LIST) R652 VARIANT (SEE VARIANT PARTS LIST) R655 1-216-361-00 METAL OXIDE 0.22 5% 2W F

R656 1-249-419-11 CARBON 1.5K 5% 1/4W R657 1-247-843-11 CARBON 3.3K 5% 1/4W R658 VARIANT (SEE VARIANT PARTS LIST) R659 1-202-961-11 CEMENTED 1.8 5% 10W R660 1-202-933-61 FUSIBLE 0.1 10% 1/2W F

RELAY

RY601 1-755-018-11 RELAY RY602 1-755-266-11 RELAY, AC POWER

SWITCH

S001 1-692-431-21 SWITCH, TACTILE S002 1-692-431-21 SWITCH, TACTILE S003 1-692-431-21 SWITCH, TACTILE S004 1-692-431-21 SWITCH, TACTILE

S005 1-692-431-21 SWITCH, TACTILE S006 1-692-431-21 SWITCH, TACTILE S007 1-692-431-21 SWITCH, TACTILE

TRANSFORMER

T501 1-437-210-11 TRANSFORMER, HORIZONTAL DRIVE T504 1-453-283-21 TRANSFORMER ASSY, FLYBACK T601 1-423-895-11 TRANSFORMER, LINE FILTER (LFT) T603 VARIANT (SEE VARIANT PARTS LIST) T604 1-431-852-11 TRANSFORMER, CONVERTER (SRT)

THERMISTOR

THP601 VARIANT (SEE VARIANT PARTS LIST)

TUNER

TU101 VARIANT (SEE VARIANT PARTS LIST)

VARISTOR

VDR601 VARIANT (SEE VARIANT PARTS LIST)

CRYSTAL

X001 1-767-487-11 VIBRATOR, CRYSTAL X301 1-567-505-11 OSCILLATOR, CRYSTAL

 55 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

COMPLETE PARTS LISTING

Note: Note:

The components identified by shading andmark are critical for safety. Replace only with part number specified.

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

RESISTOR

R1756 1-260-099-11 CARBON 1K 5% 1/2W R1757 1-260-099-11 CARBON 1K 5% 1/2W R1758 1-260-099-11 CARBON 1K 5% 1/2W

* A-1331-917-A C MOUNTED PC BOARD

4-382-854-11 SCREW (M3X10), P, SW (+)

CAPACITOR

C1751 1-107-652-11 ELECT 10µF 20% 250V C1752 1-162-114-00 CERAMIC 0.0047µF 2KV C1755 1-107-667-11 ELECT 2.2µF 20% 160V

R1759 1-260-087-11 CARBON 100 5% 1/2W R1760 1-260-123-11 CARBON 100K 5% 1/2W

R1761 1-216-392-11 METAL OXIDE 1.8 5% 3W F R1763 1-247-807-31 CARBON 100 5% 1/4W R1764 1-247-807-31 CARBON 100 5% 1/4W R1765 1-247-807-31 CARBON 100 5% 1/4W R1770 1-260-132-11 CARBON 560K 5% 1/2W

CONNECTOR

CN1751 * 1-564-509-11 PLUG, CONNECTOR 6P CN1752 * 1-564-508-11 PLUG, CONNECTOR 5P CN1753 1-695-915-11 TAB (CONTACT) CN1754 1-695-915-11 TAB (CONTACT)

DIODE

D1754 8-719-901-83 DIODE 1SS83 D1755 8-719-901-83 DIODE 1SS83 D1756 8-719-901-83 DIODE 1SS83 D1758 8-719-302-43 DIODE EL1Z

IC1751 8-759-562-43 IC TDA6108JF/N1B

JACK

J1751 1-251-688-11 SOCKET, CRT

COIL

L1751 1-408-613-31 INDUCTOR 68µH

 56 

Note: Note:

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s) only:

KV-20M42

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-20M42

CAPACITOR

C234 1-126-964-11 ELECT 10µF 20% 50V C260 1-126-960-11 ELECT 1µF 20% 50V C418 1-126-964-11 ELECT 10µF 20% 50V C601 1-136-311-51 FILM 0.47µF 20% 125V C613 1-117-893-11 ELECT 470µF 20% 250V C638 1-136-311-11 FILM 0.47µF 20% 125V

DIODE

D215 8-719-110-17 DIODE RD10ESB2

IC400 8-759-490-18 IC TDA7056B/N1 IC601 8-749-015-60 IC STR-F6624

JACK

TRANSFORMER

T603 1-433-816-11 TRANSFORMER

THERMISTOR

THP601 1-810-597-11 THERMISTOR, POSITIVE

TUNER

TU101 8-598-430-00 TUNER, FSS BTF-FA401

VARISTOR

VDR601 1-803-585-11 VARISTOR ,ERZV10D271

J201 1-580-441-71 JACK, PIN 2P J202 1-580-441-41 JACK, PIN 2P

IC LINK

PS201 1-532-637-00 LINK, IC 1A/150V

TRANSISTOR

Q202 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX

RESISTOR

R231 1-216-073-00 RES,CHIP 10K 5% 1/10W R235 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R246 1-216-295-91 SHORT R260 1-216-097-91 RES, CHIP 100K 5% 1/10W R261 1-216-097-91 RES, CHIP 100K 5% 1/10W

R262 1-216-025-91 RES, CHIP 100 5% 1/10W R269 1-216-067-00 RES, CHIP 5.6K 5% 1/10W R400 1-249-438-11 CARBON 56K 5% 1/4W R432 1-249-435-11 CARBON 33K 5% 1/4W R433 1-216-083-00 RES, CHIP 27K 5% 1/10W R651 1-219-513-11 CARBON 4.7M 5% 1/2W R664 1-215-483-00 METAL 390K 1% 1/4W

 57 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Note:

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s)only:

KV-21MB42C/21MB42M/21MB42P

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21MB42C/21MB42M/21MB42P

CAPACITOR

C234 1-126-964-11 ELECT 10µF 20% 50V C260 1-126-960-11 ELECT 1µF 20% 50V C418 1-126-964-11 ELECT 10µF 20% 50V C601 1-136-311-61 FILM 0.47µF 20% 300V C613 1-128-714-11 ELECT 330µF 20% 400V C616 1-130-202-00 FILM 0.022µF 10% 400V

C617 1-107-824-11 CERAMIC 220pF 5% 1KV

DIODE

D215 8-719-110-17 DIODE RD10ESB2 D609 8-719-311-31 DIODE RU-1P

IC400 8-759-490-18 IC TDA7056B/N1 IC601 8-749-013-75 IC STR-F6654

R651 1-247-289-00 CARBON 8.2M 5% 1W R652 1-202-961-11 CEMENTED 1.8 5% 10W R658 1-215-929-11 METAL OXIDE 100K 5% 3W F R664 1-215-479-00 METAL 270K 1% 1/4W R698 1-215-479-00 METAL 270K 1% 1/4W

TRANSFORMER

T603 1-433-817-11 TRANSFORMER

THERMISTOR

THP601 1-803-540-11 THERMISTOR

TUNER

TU101 8-598-430-00 TUNER, FSS BTF-FA401

VARISTOR

VDR601 1-803-585-11 VARISTOR ,ERZV10D271

JACK

J201 1-580-441-71 JACK, PIN 2P J202 1-580-441-41 JACK, PIN 2P

IC LINK

PS201 1-532-637-00 LINK, IC 1A/150V

TRANSISTOR

Q202 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX

RESISTOR

R231 1-216-073-00 RES,CHIP 10K 5% 1/10W R235 1-208-794-11 RES, CHIP 3.3K 0.50% 1/10W R246 1-216-295-91 SHORT R260 1-216-097-91 RES, CHIP 100K 5% 1/10W R261 1-216-097-91 RES, CHIP 100K 5% 1/10W

R262 1-216-025-91 RES, CHIP 100 5% 1/10W R269 1-216-069-00 RES, CHIP 6.8K 5% 1/10W R400 1-249-438-11 CARBON 56K 5% 1/4W R432 1-249-435-11 CARBON 33K 5% 1/4W R433 1-216-083-00 RES, CHIP 27K 5% 1/10W

 58 

Note: Note:

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s) only:

KV-21ME42/42C

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21ME42/42C

CAPACITOR

C216 1-126-959-11 ELECT 0.47µF 20% 50V C220 1-126-941-11 ELECT 470µF 20% 25V C234 1-126-964-11 ELECT 10µF 20% 50V C260 1-126-960-11 ELECT 1µF 20% 50V C418 1-126-964-11 ELECT 10µF 20% 50V

C601 1-136-311-61 FILM 0.47µF 20% 300V C613 1-128-714-11 ELECT 330µF 20% 400V C616 1-130-202-00 FILM 0.022µF 10% 400V

C617 1-107-824-11 CERAMIC 220pF 5% 1KV

CONNECTOR

CN401 * 1-564-505-11 PLUG, CONNECTOR 2P

DIODE

D215 8-719-110-17 DIODE RD10ESB2 D609 8-719-311-31 DIODE RU-1P

R238 1-249-417-11 CARBON 1K 5% 1/4W R245 1-216-295-91 SHORT R246 1-216-295-91 SHORT R260 1-216-097-91 RES, CHIP 100K 5% 1/10W R261 1-216-097-91 RES, CHIP 100K 5% 1/10W R262 1-216-025-91 RES, CHIP 100 5% 1/10W

R269 1-208-794-11 RES, CHIP 3.3K 0.50% 1/10W R400 1-247-863-91 CARBON 22K 5% 1/4W R432 1-249-430-11 CARBON 12K 5% 1/4W R433 1-216-075-00 RES, CHIP 12K 5% 1/10W R651 1-247-289-00 CARBON 8.2M 5% 1W

R652 1-202-961-11 CEMENTED 1.8 5% 10W R658 1-215-929-11 METAL OXIDE 100K 5% 3W F R664 1-215-479-00 METAL 270K 1% 1/4W R698 1-215-479-00 METAL 270K 1% 1/4W

TRANSFORMER

T603 1-433-817-11 TRANSFORMER

THERMISTOR

THP601 1-803-540-11 THERMISTOR

IC401 8-759-490-17 IC TDA7057AQ/N2 IC601 8-749-013-75 IC STR-F6654

JACK

J201 1-580-441-71 JACK, PIN 2P J202 1-580-441-41 JACK, PIN 2P

IC LINK

PS201 1-532-984-11 LINK, IC 2A/90V

TRANSISTOR

Q202 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX

RESISTOR

R231 1-216-073-00 RES,CHIP 10K 5% 1/10W R235 1-208-794-11 RES, CHIP 3.3K 0.50% 1/10W R237 1-247-815-91 CARBON 220 5% 1/4W

TUNER

TU101 8-598-430-00 TUNER, FSS BTF-FA401

 59 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Note:

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s)only:

KV-20S42/20S43

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-20S42/20S43

CAPACITOR

C202 1-126-960-11 ELECT 1µF 20% 50V C206 1-126-960-11 ELECT 1µF 20% 50V C214 1-126-957-11 ELECT 0.22µF 20% 50V C216 1-126-959-11 ELECT 0.47µF 20% 50V C220 1-126-941-11 ELECT 470µF 20% 25V

C233 1-126-960-11 ELECT 1µF 20% 50V C234 1-126-964-11 ELECT 10µF 20% 50V C418 1-126-964-11 ELECT 10µF 20% 50V C601 1-136-311-51 FILM 0.47µF 20% 125V C613 1-117-893-11 ELECT 470µF 20% 250V C638 1-136-311-11 FILM 0.47µF 20% 125V

CONNECTOR

CN401 * 1-564-505-11 PLUG, CONNECTOR 2P

DIODE

D202 8-719-110-17 DIODE RD10ESB2 D204 8-719-110-17 DIODE RD10ESB2

R206 1-247-895-91 CARBON 470K 5% 1/4W R230 1-216-075-00 RES, CHIP 12K 5% 1/10W R231 1-216-075-00 RES, CHIP 12K 5% 1/10W R234 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R235 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W

R237 1-247-815-91 CARBON 220 5% 1/4W R238 1-249-417-11 CARBON 1K 5% 1/4W R241 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R268 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R269 1-216-069-00 RES, CHIP 3.3K .5% 1/10W

R400 1-247-863-91 CARBON 22K 5% 1/4W R432 1-249-430-11 CARBON 12K 5% 1/4W R433 1-216-075-00 RES, CHIP 12K 5% 1/10W R651 1-219-513-11 CARBON 4.7M 5% 1/2W R664 1-215-483-00 METAL 390K 1% 1/4W

TRANSFORMER

T603 1-433-816-11 TRANSFORMER

THERMISTOR

THP601 1-810-597-11 THERMISTOR, POSITIVE

IC200 8-759-450-93 IC NJM2521M-TE1 IC401 8-759-490-17 IC TDA7057AQ/N2 IC601 8-749-015-60 IC STR-F6624

JACK

J201 1-580-443-11 JACK, PIN 3P J202 1-691-110-11 JACK, PIN 3P

IC LINK

PS201 1-532-984-11 LINK, IC 2A/90V

RESISTOR

R010 1-216-033-00 RES, CHIP 220 5% 1/10W R011 1-247-815-91 CARBON 220 5% 1/4W R051 1-216-033-00 RES, CHIP 220 5% 1/10W R070 1-249-425-11 CARBON 4.7K 5% 1/4W R071 1-249-425-11 CARBON 4.7K 5% 1/4W R202 1-216-113-00 RES, CHIP 470K 5% 1/10W

TUNER

TU101 8-598-431-00 TUNER, FSS BTF-WA411

VARISTOR

VDR601 1-803-585-11 VARISTOR, ERZV10D271

 60 

Note: Note:

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s) only:

KV-21SB42C/21SB42M

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21SB42C/21SB42M

CAPACITOR

C202 1-126-960-11 ELECT 1µF 20% 50V C206 1-126-960-11 ELECT 1µF 20% 50V C214 1-126-957-11 ELECT 0.22µF 20% 50V C216 1-126-959-11 ELECT 0.47µF 20% 50V C220 1-126-941-11 ELECT 470µF 20% 25V C233 1-126-960-11 ELECT 1µF 20% 50V

C234 1-126-964-11 ELECT 10µF 20% 50V C418 1-126-964-11 ELECT 10µF 20% 50V C601 1-136-311-61 FILM 0.47µF 20% 300V C613 1-128-714-11 CAPACITOR 330µF 400V C616 1-130-202-00 FILM 0.022µF 10% 400V

C617 1-107-824-11 CERAMIC 220pF 5% 1KV

CONNECTOR

CN401 * 1-564-505-11 PLUG, CONNECTOR 2P

R070 1-249-425-11 CARBON 4.7K 5% 1/4W R071 1-249-425-11 CARBON 4.7K 5% 1/4W R202 1-216-113-00 RES, CHIP 470K 5% 1/10W R206 1-247-895-91 CARBON 470K 5% 1/4W R230 1-216-075-00 RES, CHIP 12K 5% 1/10W

R231 1-216-075-00 RES, CHIP 12K 5% 1/10W R234 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R235 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R237 1-247-815-91 CARBON 220 5% 1/4W R238 1-249-417-11 CARBON 1K 5% 1/4W

R241 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R268 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R269 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R400 1-247-863-91 CARBON 22K 5% 1/4W R432 1-249-430-11 CARBON 12K 5% 1/4W

R433 1-216-075-00 RES, CHIP 12K 5% 1/10W R651 1-247-289-00 CARBON 8.2M 5% 1W R652 1-202-961-11 CEMENTED 1.8 5% 10W R658 1-215-929-11 METAL OXIDE 100K 5% 3W F R664 1-215-479-00 METAL 270K 1% 1/4W R698 1-215-479-00 METAL 270K 1% 1/4W

DIODE

D202 8-719-110-17 DIODE RD10ESB2 D204 8-719-110-17 DIODE RD10ESB2 D609 8-719-311-31 DIODE RU-1P

IC200 8-759-450-93 IC NJM2521M-TE1 IC401 8-759-490-17 IC TDA7057AQ/N2 IC601 8-749-013-75 IC STR-F6654

JACK

J201 1-580-443-11 JACK, PIN 3P J202 1-691-110-11 JACK, PIN 3P

IC LINK

PS201 1-532-984-11 LINK, IC 2A/90V

RESISTOR

R010 1-216-033-00 RES, CHIP 220 5% 1/10W R011 1-247-815-91 CARBON 220 5% 1/4W R051 1-216-033-00 RES, CHIP 220 5% 1/10W

TRANSFORMER

T603 1-433-817-11 TRANSFORMER

THERMISTOR

THP601 1-803-540-11 THERMISTOR

TUNER

TU101 8-598-431-00 TUNER, FSS BTF-WA411

VARISTOR

VDR601 1-803-587-11 VARISTOR, ERZV10D471

 61 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Note:

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s)only:

KV-21SE42/21SE42C

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21SE42/21SE42C

CAPACITOR

C202 1-126-960-11 ELECT 1MF 20% 50V C206 1-126-960-11 ELECT 1MF 20% 50V C214 1-126-957-11 ELECT 0.22MF 20% 50V C216 1-126-959-11 ELECT 0.47MF 20% 50V C220 1-126-941-11 ELECT 470MF 20% 25V C233 1-126-960-11 ELECT 1MF 20% 50V C234 1-126-964-11 ELECT 10MF 20% 50V C418 1-126-964-11 ELECT 10MF 20% 50V

C601 1-136-311-61 FILM 0.47µF 20% 300V C613 1-128-714-11 CAPACITOR 330µF 20% 400V C616 1-130-202-00 FILM 0.022µF 10% 400V

C617 1-107-824-11 CERAMIC 220pF 5% 1KV

CONNECTOR

CN401 * 1-564-505-11 PLUG, CONNECTOR 2P

DIODE

D202 8-719-110-17 DIODE RD10ESB2 D204 8-719-110-17 DIODE RD10ESB2 D609 8-719-311-31 DIODE RU-1P

R071 1-249-425-11 CARBON 4.7K 5% 1/4W R202 1-216-113-00 RES, CHIP 470K 5% 1/10W R206 1-247-895-91 CARBON 470K 5% 1/4W R230 1-216-075-00 RES, CHIP 12K 5% 1/10W

TRANSFORMER

T603 1-433-817-11 TRANSFORMER

IC200 8-759-450-93 IC NJM2521M-TE1 IC401 8-759-490-17 IC TDA7057AQ/N2 IC601 8-749-013-75 IC STR-F6654

JACK

J201 1-580-443-11 JACK, PIN 3P J202 1-691-110-11 JACK, PIN 3P

IC LINK

PS201 1-532-984-11 LINK, IC 2A/90V

RESISTOR

R010 1-216-033-00 RES, CHIP 220 5% 1/10W R011 1-247-815-91 CARBON 220 5% 1/4W R051 1-216-033-00 RES, CHIP 220 5% 1/10W R070 1-249-425-11 CARBON 4.7K 5% 1/4W

THERMISTOR

THP601 1-803-540-11 THERMISTOR

TUNER

TU101 8-598-431-00 TUNER, FSS BTF-WA411

VARISTOR

VDR601 1-803-587-11 VARISTOR, ERZV10D471

 62 

Note: Note:

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s) only:

KV-21SE82/21SE82C

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21SE82/21SE82C

CAPACITOR

C202 1-126-960-11 ELECT 1µF 20% 50V C206 1-126-960-11 ELECT 1µF 20% 50V C207 1-126-959-11 ELECT 0.47µF 20% 50V C208 1-126-959-11 ELECT 0.47µF 20% 50V C209 1-126-963-11 ELECT 4.7µF 20% 50V

C211 1-126-964-11 ELECT 10µF 20% 50V C212 1-126-963-11 ELECT 4.7µF 20% 50V C213 1-126-964-11 ELECT 10µF 20% 50V C214 1-126-957-11 ELECT 0.22µF 20% 50V C216 1-126-959-11 ELECT 0.47µF 20% 50V

C220 1-126-941-11 ELECT 470µF 20% 25V C229 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C233 1-126-960-11 ELECT 1µF 20% 50V C304 1-163-038-91 CERAMIC CHIP 0.1µF 25V C307 1-126-964-11 ELECT 10µF 20% 50V

C340 1-126-960-11 ELECT 1µF 20% 50V

C348 1-163-003-11 CERAMIC CHIP 330pF 10% 50V

C350 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C351 1-126-964-11 ELECT 10µF 20% 50V C352 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C353 1-163-038-91 CERAMIC CHIP 0.1µF 25V C354 1-163-038-91 CERAMIC CHIP 0.1µF 25V C355 1-164-222-11 CERAMIC CHIP 0.22µF 25V C356 1-163-038-91 CERAMIC CHIP 0.1µF 25V C357 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V

C413 1-126-967-11 ELECT 47µF 20% 50V C414 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V C415 1-126-956-91 ELECT 0.1µF 20% 50V C416 1-126-963-11 ELECT 4.7µF 20% 50V C418 1-126-963-11 ELECT 4.7µF 20% 50V C601 1-136-311-61 FILM 0.47µF 20% 300V

C613 1-128-713-11 CAPACITOR 330µF 20% 400V C616 1-130-202-00 FILM 0.022µF 10% 400V

C617 1-107-824-11 CERAMIC 220pF 5% 1KV

CONNECTOR

CN401 * 1-564-505-11 PLUG, CONNECTOR 2P

DIODE

D202 8-719-110-17 DIODE RD10ESB2 D204 8-719-110-17 DIODE RD10ESB2 D206 8-719-110-17 DIODE RD10ESB2 D207 8-719-109-66 DIODE RD3.3ESB2 D280 8-719-110-17 DIODE RD10ESB2 D609 8-719-311-31 DIODE RU-1P

IC200 8-759-450-93 IC NJM2521M-TE1 IC202 8-759-100-96 IC NJM4558M-TE2 IC302 8-752-385-80 IC CXD2073S IC401 8-759-490-17 IC TDA7057AQ/N2 IC402 8-752-072-39 IC CXA2021S IC601 8-749-013-75 IC STR-F6654

C358 1-104-664-11 ELECT 47µF 20% 25V C359 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C360 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V C361 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V C362 1-126-964-11 ELECT 10µF 20% 50V

C400 1-126-963-11 ELECT 4.7µF 20% 50V C401 1-126-956-91 ELECT 0.1µF 20% 50V C402 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V C403 1-126-963-11 ELECT 4.7µF 20% 50V C404 1-126-963-11 ELECT 4.7µF 20% 50V

C405 1-126-963-11 ELECT 4.7µF 20% 50V C406 1-126-963-11 ELECT 4.7µF 20% 50V C407 1-126-964-11 ELECT 10µF 20% 50V C410 1-126-963-11 ELECT 4.7µF 20% 50V C411 1-126-956-91 ELECT 0.1µF 20% 50V

C412 1-130-495-00 FILM 0.1µF 5% 50V

JACK

J200 1-580-441-61 JACK, PIN 2P J201 1-580-443-11 JACK, PIN 3P J202 1-691-110-11 JACK, PIN 3P

COIL

L351 1-414-271-11 INDUCTOR 47µH L352 1-414-267-11 INDUCTOR 10µH

IC LINK

PS201 1-532-984-11 LINK, IC 2A/90V

 63 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

Note:

BOARD VARIANT PARTS LIST

The parts on this page belong to the following model(s)only:

KV-21SE82/82C

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Note:

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21SE82/82C

TRANSISTOR

Q200 8-729-422-27 TRANSISTOR 2SD601A-Q Q201 8-729-422-27 TRANSISTOR 2SD601A-Q Q206 8-729-422-27 TRANSISTOR 2SD601A-Q Q207 8-729-422-27 TRANSISTOR 2SD601A-Q Q340 8-729-422-27 TRANSISTOR 2SD601A-Q

Q350 8-729-216-22 TRANSISTOR 2SA1162-G Q351 8-729-422-27 TRANSISTOR 2SD601A-Q Q352 8-729-216-22 TRANSISTOR 2SA1162-G Q353 8-729-216-22 TRANSISTOR 2SA1162-G Q354 8-729-216-22 TRANSISTOR 2SA1162-G

Q355 8-729-422-27 TRANSISTOR 2SD601A-Q Q356 8-729-216-22 TRANSISTOR 2SA1162-G Q357 8-729-216-22 TRANSISTOR 2SA1162-G Q358 8-729-422-27 TRANSISTOR 2SD601A-Q Q359 8-729-216-22 TRANSISTOR 2SA1162-G Q380 8-729-216-22 TRANSISTOR 2SA1162-G

RESISTOR

R010 1-216-033-00 RES, CHIP 220 5% 1/10W R011 1-247-815-91 CARBON 220 5% 1/4W R051 1-216-033-00 RES, CHIP 220 5% 1/10W R053 1-247-815-91 CARBON 220 5% 1/4W R070 1-249-425-11 CARBON 4.7K 5% 1/4W

R071 1-249-425-11 CARBON 4.7K 5% 1/4W R080 1-249-429-11 CARBON 10K 5% 1/4W R202 1-216-113-00 RES, CHIP 470K 5% 1/10W R206 1-247-895-91 CARBON 470K 5% 1/4W R214 1-216-113-00 RES, CHIP 470K 5% 1/10W

R215 1-216-033-00 RES, CHIP 220 5% 1/10W R216 1-216-113-00 RES, CHIP 470K 5% 1/10W R217 1-216-033-00 RES, CHIP 220 5% 1/10W R218 1-216-067-00 RES, CHIP 5.6K 5% 1/10W R219 1-216-073-00 RES, CHIP 10K 5% 1/10W

R220 1-216-073-00 RES, CHIP 10K 5% 1/10W R221 1-216-073-00 RES, CHIP 10K 5% 1/10W R222 1-216-067-00 RES, CHIP 5.6K 5% 1/10W R223 1-249-429-11 CARBON 10K 5% 1/4W R224 1-249-429-11 CARBON 10K 5% 1/4W

R225 1-216-073-00 RES, CHIP 10K 5% 1/10W R226 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R227 1-216-097-91 RES, CHIP 100K 5% 1/10W R228 1-216-065-91 RES, CHIP 4.7K 5% 1/10W

R229 1-216-097-91 RES, CHIP 100K 5% 1/10W R232 1-216-073-00 RES, CHIP 10K 5% 1/10W R233 1-216-073-00 RES, CHIP 10K 5% 1/10W R234 1-216-057-00 RES, CHIP 2.2K 5% 1/10W R235 1-216-057-00 RES, CHIP 2.2K 5% 1/10W

R237 1-247-815-91 CARBON 220 5% 1/4W R238 1-249-417-11 CARBON 1K 5% 1/4W R241 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R247 1-216-025-91 RES, CHIP 100 5% 1/10W R248 1-216-025-91 RES, CHIP 100 5% 1/10W

R249 1-216-081-00 RES, CHIP 22K 5% 1/10W R250 1-216-081-00 RES, CHIP 22K 5% 1/10W R268 1-216-081-00 RES, CHIP 22K 5% 1/10W R269 1-216-081-00 RES, CHIP 22K 5% 1/10W R283 1-216-022-00 RES, CHIP 75 5% 1/10W

R287 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R303 1-216-025-91 RES, CHIP 100 5% 1/10W R341 1-216-017-91 RES, CHIP 47 5% 1/10W R342 1-216-097-91 RES, CHIP 100K 5% 1/10W R343 1-216-073-00 RES, CHIP 10K 5% 1/10W

R344 1-216-061-00 RES, CHIP 3.3K 5% 1/10W R350 1-208-766-11 RES, CHIP 220 0.5% 1/10W R351 1-208-766-11 RES, CHIP 220 0.5% 1/10W R352 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W R354 1-208-794-11 RES, CHIP 3.3K 0.5% 1/10W

R357 1-216-091-00 RES, CHIP 56K 5% 1/10W R358 1-216-043-91 RES, CHIP 560 5% 1/10W R359 1-216-057-00 RES, CHIP 2.2K 5% 1/10W R360 1-163-001-11 CERAMIC CHIP 220pF 10% 50V R361 1-216-049-91 RES, CHIP 1K 5% 1/10W

R362 1-216-043-91 RES, CHIP 560 5% 1/10W R363 1-216-037-00 RES, CHIP 330 5% 1/10W R364 1-216-025-91 RES, CHIP 100 5% 1/10W R365 1-216-295-91 SHORT R366 1-216-053-00 RES, CHIP 1.5K 5% 1/10W

R367 1-216-057-00 RES, CHIP 2.2K 5% 1/10W R368 1-216-025-91 RES, CHIP 100 5% 1/10W R369 1-216-045-00 RES, CHIP 680 5% 1/10W R370 1-216-033-00 RES, CHIP 220 5% 1/10W R372 1-216-035-00 RES, CHIP 270 5% 1/10W

R373 1-216-025-91 RES, CHIP 100 5% 1/10W R374 1-216-025-91 RES, CHIP 100 5% 1/10W R375 1-216-053-00 RES, CHIP 1.5K 5% 1/10W R376 1-216-049-91 RES, CHIP 1K 5% 1/10W R377 1-216-049-91 RES, CHIP 1K 5% 1/10W

R378 1-216-041-00 RES, CHIP 470 5% 1/10W R379 1-216-049-91 RES, CHIP 1K 5% 1/10W

 64 

Note: Note:

The components identified by shading andmark safety. Replace only with part number specified.

are critical for

Les composants identifies per un trame et une marque sont critiques pour la securite. Ne les remplacer quepar une piece portant le numero specifie.

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/

21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C

BOARD VARIANT PARTS LIST PACKAGING LIST & ACCESSORIES

The variant parts on this page belong to the following model(s) only:

KV-21SE82/82C

REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK

A BOARD VARIANT LIST: KV-21SE82/82C

R380 1-208-790-11 RES, CHIP 2.2K 0.5% 1/10W R382 1-216-053-00 RES, CHIP 1.5K 5% 1/10W R387 1-216-025-91 RES, CHIP 100 5% 1/10W R388 1-216-025-91 RES, CHIP 100 5% 1/10W R395 1-216-025-91 RES, CHIP 100 5% 1/10W

R396 1-216-025-91 RES, CHIP 100 5% 1/10W R397 1-216-025-91 RES, CHIP 100 5% 1/10W R400 1-247-863-91 CARBON 22K 5% 1/4W R402 1-216-121-91 RES, CHIP 1M 5% 1/10W R403 1-247-815-91 CARBON 220 5% 1/4W

R404 1-247-815-91 CARBON 220 5% 1/4W R432 1-249-428-11 CARBON 8.2K 5% 1/4W R651 1-247-289-00 CARBON 8.2M 5% 1W R652 1-202-961-11 CEMENTED 1.8 5% 10W R658 1-215-929-11 METAL OXIDE 100K 5% 3W F

R664 1-215-479-00 METAL 270K 1% 1/4W R698 1-215-479-00 METAL 270K 1% 1/4W

TRANSFORMER

T603 1-433-817-11 TRANSFORMER

THERMISTOR

THP601 1-803-540-11 THERMISTOR

PACKAGING LIST AND ACCESSORIES

1-417-182-11 CONVERTER (EAC-25) 1-501-730-41 ANTENNA, TELESCOPIC 3-866-075-41 MANUAL, INSTRUCTION (KV-21SE82/82C) 3-866-072-21 MANUAL, INSTRUCTION (KV-20M42/S42/S43) 3-866-073-41 MANUAL, INSTRUCTION

(KV-21SB42C/42M/MB42C/42M/42P/ME42/42C/ SB42C/42M/21SE42/42C)

1-475-801-11 REMOTE COMMANDER (RM-Y165)

(KV-21SE82/21SE82C)

1-475-757-11 REMOTE COMMANDER (RM-Y156)

(KV-20M42/21MB42P/42C/42M/21ME42/42C)

1-475-635-11 REMOTE COMMANDER (RM-Y155)

(KV-20S42/21SB42M/42C/21SE42/42C)

1-475-631-11 REMOTE COMMANDER (RM-Y156W) (KV-20S43)

9-939-830-11 BATTERY COVER, REMOTE

4-041-254-01 BAG, PROTECTION * 4-061-384-02 CUSHION, (UPPER) (ASSY) (KV-21SE82/82C) * 4-061-392-01 CUSHION, (UPPER) (ASSY)

(KV-21ME42/42C/SE42/42C)

* 4-062-747-01 CUSHION, (UPPER) (ASSY)

(KV-20M42/S42/S43/21MB42C/42M/42P/SB42C/42M)

* 4-061-383-02 CUSHION, (LOWER) (ASSY) (KV-21SE82/82C) * 4-061-391-01 CUSHION, (LOWER) (ASSY)

(KV-21ME42/42C/SE42/42C)

* 4-062-748-01 CUSHION, (LOWER) (ASSY)

(KV-20M42/S42/S43/21MB42C/42M/42P/SB42C/42M)

TUNER

TU101 8-598-431-00 TUNER, FSS BTF-WA411

VARISTOR

VDR601 1-803-587-11 VARISTOR, RZV10D471

* 4-064-000-02 CARTON, INDIVIDUAL (KV-21SE82/82C) * 4-052-651-11 CARTON, INDIVIDUAL (KV-20M42/S42/S43) * 4-061-395-11 CARTON, INDIVIDUAL

(KV-21ME42/42C/21SE42/42C

* 4-062-755-11 CARTON, INDIVIDUAL

(KV-21MB42C/42M/42P/21SB42C/42M)

 65 

KV-20M42/20S42/20S43/21MB42C/21MB42M/21MB42P/21ME42/21ME42C/ 21SB42C/21SB42M/21SE42/21SE42C/21SE82/21SE82C/21XE42C

NOTES:

 66 

Sony Corporation

Sony Technology Center

Product Quality Division

Service Promotion Department9-965-855-01

English

99DS74399-1

Printed in U.S.A.

SONY BA6 Diagram

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS

SAFETY CHECK-OUT

DISASSEMBLY

SET -UP ADJUSTMENTS

SAFETY RELATED ADJUSTMENTS

CIRCUIT ADJUSTMENTS

EXPLODED VIEWS

ELECTRICAL PARTS LIST
