User guide

T715

Thank you for purchasing a Sony Ericsson

T715/T715a. For additional phone content, go to

www.sonyericsson.com/fun. Register now to get free online

storage and special offers at

www.sonyericsson.com/myphone.

For an extended User guide and product support, go to

www.sonyericsson.com/support

Please read the Important information before you use your mobile phone.

Instruction symbols

These symbols may appear in the User guide:

Note

Tip

Warning

> Use a selection or navigation key to scroll and select.

See Navigation on page 10.

Getting started

Assembly

Before you start using your phone, you need to insert a SIM card and the battery.

To insert the SIM card

Remove the battery cover.

Slide the SIM card into its holder with the gold-coloured contacts facing down.

To insert the battery

Insert the battery with the label side up and the connectors facing each other.

Attach the battery cover.

Turning on the phone

To turn on the phone

Press and hold down .

Enter your SIM card PIN (Personal Identification Number), if requested, and select OK.

Select a language.

Follow the instructions that appear.

If you want to correct a mistake when you enter your PIN, press .

Help

In addition to this User guide, an extended User guide, Feature guides and more information are available at

www.sonyericsson.com/support.

Help and information are also available in your phone.

To access the User guide

•

Select Menu > Settings > User help > User guide.

To view tips and tricks

•

Select Menu > Settings > User help > Tips and tricks.

To view information about functions

•

Scroll to a function and select Info, if available. In some cases, Info appears under Options.

To view the phone status

•

Press the volume key. Phone, memory and battery information is shown.

Charging the battery

The phone battery is partly charged when you buy it.

To charge the battery

Connect the charger to the phone. It takes approximately

2.5 hours to fully charge the battery. Press a key to view the screen.

Remove the charger by tilting the plug upwards.

You can use your phone while it is charging. You can charge the battery at any time and for more or less than 2.5 hours. You can interrupt the charging without damaging the battery.

Phone overview

1 Ear speaker

7 8

10 11

2 Screen light

sensor 3 Screen 4 Connector for

charger,

handsfree and

USB cable 5 Selection keys 6 Navigation key 7 Call key 8 Activity menu key 9 C key (Clear) 10 Memory card slot

(under the cover) 11 End key, On/off

key

12 Strap hole

13 Main camera 14 Camera light 15 Volume, digital

zoom keys 16 Camera key 17 Loudspeaker

Navigation

To access the main menu

•

When Menu appears on the screen, press the centre selection key to select Menu.

•

If Menu does not appear on the screen, press , and then press the centre selection key to select Menu.

To navigate the phone menus

•

Press the navigation key

, , or to move through

the menus.

To end a function

•

Press

To return to standby

•

Press .

To delete items

•

Press to delete items such as numbers, letters, pictures and sounds.

Shortcuts

You can use keypad shortcuts to go directly to functions from standby.

To use navigation key shortcuts

•

Press , , or to go directly to a function.

To edit a navigation key shortcut

Select Menu > Settings > General > Shortcuts.

Scroll to an option and select Edit.

Scroll to a menu option and select Shortc..

Activity menu

The activity menu gives you quick access to:

•

New events – missed calls and new messages.

•

Running apps – applications that are running in the

background.

•

My shortcuts – add your favourite functions to access

them quickly.

•

Internet – quick access to the Internet.

To open the activity menu

•

Press .

Memory card

You may have to purchase a memory card separately.

Your phone supports a microSD™ memory card adding more storage space to your phone. It can also be used as a portable memory card with other compatible devices.

You can move content between a memory card and the phone memory. See Handling content in the phone on page 22.

To insert a memory card

•

Remove the battery cover and insert the memory card with the gold-coloured contacts facing down.

Entering text

You can use multitap text input or T9™ Text Input to enter text. The T9 Text Input method uses a built-in dictionary.

To change writing language

•

When you enter text, press and hold down

To change text input method

•

When you enter text, press and hold down .

To shift between capitals and lower-case letters

•

When you enter text, press .

To enter numbers

•

When you enter text, press and hold down –

To enter full stops and commas

•

When you enter text, press

To enter a symbol

When you enter text, select Options > Add symbol.

Scroll to a symbol and select Insert.

To enter text using T9™ Text Input

Select, for example, Menu > Messaging > Write new > Message.

is not displayed, press and hold down to

change to T9 Text Input.

Press each key only once, even if the letter you want is not the first letter on the key. For example, to write the word “Jane”, press

, , , . Write the

whole word before looking at the suggestions.

Use or to view suggestions.

Press to accept a suggestion and add a space.

To enter text using multitap text input

Select, for example, Menu > Messaging > Write new > Message.

If is displayed, press and hold down to change to multitap text input.

Press – repeatedly until the desired letter appears.

When a word is written, press to add a space.

To add words to the built-in dictionary

When you enter text using T9 Text Input, select

Options > Spell word.

Write the word using multitap text input and select Insert.

Calling

Making and receiving calls

You need to turn on your phone and be within range of a network.

To make a call

Enter a phone number (with international country code and area code, if applicable).

Press

You can call numbers from your contacts and call list. See Contacts on page 16, and Call list on page 16.

To end a call

•

Press .

To make international calls

Press and hold down until a “+” sign appears.

Enter the country code, area code (without the first zero) and phone number.

Press .

To answer a call

•

Press .

To reject a call

•

Press

To change the ear speaker volume during a call

•

Press the volume key up or down.

To mute the microphone during a call

Press and hold down

. appears.

Press and hold down again to resume.

To turn on the loudspeaker during a call

•

Select SpkrOn.

appears.

Do not hold the phone to your ear when using the loudspeaker. This could damage your hearing.

Emergency calls

Your phone supports international emergency numbers, for example, 112 or 911. You can normally use these numbers to make emergency calls in any country, with or without the SIM card inserted, if you are within range of a network.

In some countries, other emergency numbers may also be promoted. Your network operator may therefore have saved additional local emergency numbers on the SIM card.

To make an emergency call

•

Enter 112 (the international emergency number) and press .

To view your local emergency numbers

Select Menu > Contacts.

Scroll to New contact and select Options > Special numbers > Emergency nos..

Call list

You can view information about answered , dialled and missed or rejected calls.

To call a number from the call list

Press

and scroll to a tab.

Scroll to a name or a number and press .

Contacts

You can save names, phone numbers and personal information in Contacts. Information can be saved in the phone memory or on the SIM card.

You can synchronise your contacts using the Sony Ericsson PC Suite.

To add a phone contact

Select Menu > Contacts.

Scroll to New contact and select Add.

Enter the name and select OK.

Scroll to New number: and select Add.

Enter the number and select OK.

Select a number option.

Scroll between the tabs and add information to the fields.

Select Save.

Calling contacts

To call with Smart search

Press – to enter a sequence of (at least two) digits. All entries which match the sequence of digits or

corresponding letters are shown in a list.

Scroll to a contact or a phone number and press .

To turn on or off Smart search

Select Menu > Settings > Calls > Smart search.

Select an option.

Imaging

You can take photos and record video clips to view, save or send. You find saved photos and video clips in Media and in File manager.

Using the camera

To activate the camera

•

From standby press and hold down

Viewfinder and camera keys

1 Activate the camera/Take photos/Record video 2 Zoom in or out

To take a photo

Activate the camera and press the navigation key to scroll to

Press to take a photo. The photo is automatically saved.

Press to return to the viewfinder to take another photo.

To record a video clip

Activate the camera and press the navigation key to scroll to

Press

fully down to start recording.

To stop recording, press fully down. The video clip is automatically saved.

Press

to return to the viewfinder to record another

video clip.

To view photos

Activate the camera and press the navigation key to scroll to .

Scroll through the photos.

To view video clips

Activate the camera and press the navigation key to scroll to

Scroll to a video clip and press the centre selection key. Video clips are indicated by in the upper left corner.

To change settings

•

Activate the camera and select .

To view information about settings

•

Scroll to a setting and select .

Music

You can listen to music, audio books and podcasts. Use the Media Go™ application to transfer content to and from

your phone. For more information, see Transferring content to and from a computer on page 25.

Music player

To play music

Select Menu > Media > Music.

Browse by category using the navigation key.

Scroll to a title and select Play.

To stop playing music

•

Press the centre selection key.

To fast forward and rewind

•

Press and hold down or .

To move between tracks

•

Press or .

To change the volume

•

Press the volume key up or down.

PlayNow™

When you select PlayNow™ you enter PlayNow™ arena, where you can download music, games, ringtones, themes and wallpapers. You can preview or listen to content before you purchase and download it to your phone. If you cannot use PlayNow™ and PlayNow™ arena, see I cannot use Internet-based services on page 35.

This service is not available in all countries.

For extended functionality, you can also access the PlayNow™ arena Web shop on a computer from

www.playnow-arena.com. For more information, go to

www.sonyericsson.com/support to read the PlayNow™

arena Feature guide.

To use PlayNow™

Select Menu > PlayNow™.

Scroll through PlayNow™ arena and follow the instructions to preview and purchase content.

TrackID™

TrackID™ is a music recognition service. You can search for title, artist and album name for a track you hear playing through a loudspeaker or on the radio in your phone. If you cannot use TrackID™, see I cannot use Internet-based services on page 35.

To search for track information

•

When you hear a track through a loudspeaker, select

Menu > Entertainment > TrackID™ > Start.

•

When the radio in your phone is playing select Options > TrackID™.

For best results, use TrackID™ in a quiet area.

Radio

Do not use your phone as a radio in places where this is prohibited.

To turn on the radio

Connect a handsfree to the phone.

Select Menu > Radio.

Saving channels

You can save up to 20 preset channels.

To save channels automatically

•

Select Options > Auto save.

To switch between saved channels

•

Press or .

Transferring and handling content

You can transfer and handle content such as pictures and music.

You are not allowed to exchange some copyrightprotected material. identifies a protected item.

Handling content in the phone

You can use File manager to handle content saved in the phone memory or on a memory card. Tabs and icons in File manager show where the content is saved. If the memory is full, delete some content to create space.

To select more than one item in a folder

Select Menu > Organiser > File manager.

Scroll to a folder and select Open.

Select Options > Mark > Mark several.

For each item you want to mark, scroll to the item and select Mark.

To move items between the phone memory and the memory card

Select Menu > Organiser > File manager.

Find an item and select Options > Manage file > Move.

Select Memory card or Phone.

Scroll to a folder and select Open.

Select Paste.

Sending content to another phone

You can send content, for example, in messages or using Bluetooth™ wireless technology.

To send content

Scroll to an item and select Options > Send.

Select a transfer method.

Make sure the receiving device supports the transfer method you select.

Using a USB cable

You can connect your phone to a computer with a USB cable. If you are using a PC, you are asked to install PC Companion the first time you connect.

You may have to purchase a USB cable separately. Only use a USB cable supported by your phone.

PC Companion

PC Companion lets you:

•

Explore content in your phone.

•

Use your phone as a modem.

•

Install PC Software used to synchronise, transfer and back up phone content.

For more information, go to

www.sonyericsson.com/support to read Feature

guides.

To install PC Companion

Connect your phone to a PC with a USB cable supported by your phone.

Computer: Follow the instructions.

To disconnect the USB cable safely

Do not disconnect the USB cable when transferring content as this may corrupt the content.

Computer: Right-click the Safely Remove Hardware icon

in Windows Explorer.

Select the drives you want to disconnect. Select Stop.

Wait for Windows to notify you that it is safe to remove the drive. Disconnect the USB cable.

Required operating systems

You need one of these operating systems to use Sony Ericsson PC software:

•

Microsoft® Windows Vista™

•

Microsoft® Windows XP, Service Pack 2 or higher

Drag and drop content

You can drag and drop content between your phone, a memory card and a computer in Microsoft Windows Explorer.

To drag and drop content

Connect your phone to a computer using a USB cable.

Computer: Wait until the phone memory and memory

card appear as external disks in Windows Explorer.

Drag and drop selected files between the phone and the computer.

Transferring content to and from a computer

You can use Media Go™ to transfer media content between your phone and a computer.

Media Go™ is available for download through PC Companion or from www.sonyericsson.com/support.

To transfer content using Media Go™

Connect the phone to a computer with a USB cable supported by your phone.

Computer: Select Start/Programs/Sony/Media Go™.

Select Transfer to or from Device using Media Go™ and click OK.

Wait until the phone appears in Media Go™.

Move files between your phone and the computer in Media Go™.

Backing up and restoring

You can back up and restore contacts, the calendar, tasks, notes and bookmarks using the Sony Ericsson PC Suite. Before backing up and restoring, you need to install the Sony Ericsson PC Suite which is available through PC Companion or from www.sonyericsson.com/support. You can back up and restore contacts in your phone using a memory card. You can move content between the memory card and the phone memory. See Handling content in the phone on page 22.

Back up your phone content regularly to make sure you do not lose it.

To make a backup using the Sony Ericsson PC Suite

Computer: Start the Sony Ericsson PC Suite from Start/

Programs/Sony Ericsson/Sony Ericsson PC Suite.

Follow the instructions in the Sony Ericsson PC Suite for how to connect.

Go to the backup and restore section in the Sony Ericsson PC Suite and make a backup of your phone content.

Messaging

To view a message from the inbox

Select Menu > Messaging > Messages > Inbox.

Scroll to the message and select View.

Sending messages

You can send messages from your phone. The maximum size of a standard text message is 160 characters including spaces if no other items are added to the message. If you enter more than 160 characters, a second message is created. Your messages are sent as one concatenated message.

To create and send a message

Select Menu > Messaging > Write new > Message.

Enter text. To add items to the message, press

, scroll

and select an item.

Select Continue > Contacts look-up.

Select a recipient and select Send.

If you send a message to a group, you may be charged for each member. Contact your service provider for details.

Conversations

You can choose whether to view your messages in Conversations or Inbox. A messaging conversation shows all messaging communication between you and one of your contacts.

To view messages in Conversations

•

Select Menu > Messaging > Inbox > the Conversations tab.

•

Select Menu > Messaging > Conversations and select a conversation.

To send a message from Conversations

Select Menu > Messaging.

Select Conversations, or select Inbox > the Conversations tab.

Select a conversation.

Write a message and select Send.

You can use standard email functions and your computer email address in your phone.

You can synchronise your email using Microsoft® Exchange ActiveSync® application.

Before using email

You can use the Basic setup to check if settings are available for your email account or you can enter them manually. You can also receive settings at

www.sonyericsson.com/support.

To create an email account for the first time

To start the basic setup, select Menu > Messaging > Email.

Follow the instructions to create the account.

If you enter settings manually, you can contact your email provider for more information. An email provider could be the company that supplied your email address.

To write and send an email message

Select Menu > Messaging > Email > Write new.

Select Add > Enter email address. Enter the email address and select OK.

To add more recipients, scroll to To: and select Edit.

Scroll to an option and select Add > Enter email address. Enter the email address and select OK. When you are ready, select Done.

Select Edit and enter a subject. Select OK.

Select Edit and enter the text. Select OK.

Select Add and choose a file to attach.

Select Continue > Send.

To receive and read an email message

Select Menu > Messaging > Email > Inbox > Options > Check new email.

Scroll to the message and select View.

Internet

If you cannot use the Internet, see I cannot use Internetbased services on page 35.

To start browsing

Select Search.

Enter a Web address, a search phrase or the name of a bookmark.

Scroll to an item in the list and select Go to or Search.

To exit the browser

•

Select Options > Exit browser.

To create a bookmark

When you browse the Internet, select Options > Tools > Add bookmark.

Enter a title and an address. Select Save.

More features

Flight mode

In Flight mode the network and radio transceivers are turned off to prevent disturbance to sensitive equipment. When the flight mode menu is activated you are asked to select a mode the next time you turn on your phone:

•

Normal mode – full functionality

•

Flight mode – limited functionality

To activate the flight mode menu

•

Select Menu > Settings > General > Flight mode > Continue > Show at startup.

To select flight mode

When the flight mode menu is activated, turn off your phone.

Turn on your phone and select Flight mode. appears.

Update Service

Your phone has software which you can update in order to improve performance. You can access Update Service using your phone or a PC with an Internet connection.

Accessing Update Service using your phone is not possible in all countries/regions.

To view the current software in the phone

Select Menu > Settings > General > Update service.

Select Software version.

Update Service using a PC

You can update your phone using a USB cable and an Internet-connected PC.

Make sure all personal data in your phone memory is backed up before you perform an update using a PC. See Backing up and restoring on page 25.

To use Update Service using a PC

•

Go to

www.sonyericsson.com/updateservice

Alarms

You can set a sound or the radio as an alarm signal. The alarm sounds even if the phone is turned off. When the alarm sounds you can silence it or turn it off.

To set the alarm

Select Menu > Alarms.

Scroll to an alarm and select Edit.

Scroll to Time: and select Edit.

Enter a time and select OK > Save.

To set the alarm signal

Select Menu > Alarms.

Scroll to an alarm and select Edit.

Scroll to the tab.

Scroll to Alarm signal: and select Edit.

Find and select an alarm signal. Select Save.

To silence the alarm

•

When the alarm sounds, press any key.

•

To repeat the alarm, select Snooze.

To turn off the alarm

•

When the alarm sounds, press any key, then select Turn off.

Calendar

You can synchronise your calendar with a computer calendar, with a calendar on the web or with a Microsoft® Windows Server® (Outlook®) application.

Appointments

You can add new appointments or reuse existing appointments.

To add an appointment

Select Menu > Organiser > Calendar.

Select a date.

Scroll to New appointment and select Add.

Enter the information and confirm each entry.

Select Save.

To edit an appointment

Select Menu > Organiser > Calendar.

Select a date.

Scroll to an appointment and select View.

Select Options > Edit.

Edit the appointment and confirm each entry.

Select Save.

To set when reminders should sound

Select Menu > Organiser > Calendar.

Select a date.

Select Options > Advanced > Reminders.

Select an option.

A reminders option set in calendar affects a reminders option set in tasks.

Ringtones

To set a ringtone

Select Menu > Settings > Sounds & alerts > Ringtone.

Find and select a ringtone.

To turn off the ringtone

•

Press and hold down

. appears.

The alarm signal is not affected.

Locks

SIM card lock

This lock only protects your subscription. Your phone will work with a new SIM card. If the lock is on, you have to enter a PIN (Personal Identity Number). If you enter your PIN incorrectly three times in a row, the SIM card is blocked and you need to enter your PUK (Personal

Unblocking Key). Your PIN and PUK are supplied by your network operator.

To unblock the SIM card

When PIN blocked appears, enter your PUK and select OK.

Enter a new four-to-eight-digit PIN and select OK.

Re-enter the new PIN and select OK.

To edit the PIN

Select Menu > Settings > General > Security > Locks > SIM protection > Change PIN.

Enter your PIN and select OK.

Enter a new four-to-eight-digit PIN and select OK.

Re-enter the new PIN and select OK.

If Codes do not match appears, you entered the new PIN incorrectly. If Wrong PIN appears, followed by Old PIN:, you entered your old PIN incorrectly.

Troubleshooting

Some problems can be fixed using Update Service. Using Update Service on a regular basis will optimise the phone’s performance. See Update Service on page 30. Some problems will require you to call your network operator. For more support go to www.sonyericsson.com/support.

Common questions

I have problems with memory capacity or the phone is working slowly

Restart your phone every day to free memory or do a

Master reset.

Master reset

If you select Reset settings, the changes that you have made to settings will be deleted. If you select Reset all, your settings and content, such as contacts, messages, pictures, sounds and downloaded games, will be deleted. You may also lose content that was in the phone at purchase.

To reset the phone

Select Menu > Settings > General > Master reset.

Select an option.

Follow the instructions that appear.

I cannot charge the phone or battery capacity is low

The charger is not properly connected or the battery connection is poor. Remove the battery and clean the connectors. The battery is worn out and needs to be replaced. See Charging the battery on page 6.

No battery icon appears when I start charging the phone

It may take a few minutes before the battery icon appears on the screen.

Some menu options appear in grey

A service is not activated. Contact your network operator.

I cannot use Internet-based services

Your subscription does not include data capability. Settings are missing or incorrect. You can download settings using the Settings download or from www.sonyericsson.com/support.

To download settings

Select Menu > Settings > User help > Settings download.

Follow the instructions that appear.

Contact your network operator or service provider for more information.

I cannot send messages from my phone

To send messages, you need to set a service centre number. The number is supplied by your service provider and is usually saved on the SIM card. If the number to your service centre is not saved on your SIM card, you must enter the number yourself. To send most picture messages, you must set an MMS profile and the address of your message server. If no MMS profile or message server exists, you can receive all the settings automatically from your network operator, download settings using the Basic setup or at

www.sonyericsson.com/support.

To enter a service centre number

Select Menu > Settings > Connectivity > Message settings > Text message and scroll to Service centre.

The number is shown if it is saved on the SIM card.

If there is no number shown, select Edit.

Scroll to New ServiceCentre and select Add.

Enter the number, including the international “+” sign and country code.

Select Save.

To select an MMS profile

Select Menu > Settings > Connectivity > Message settings > Picture message.

Select an existing profile or create a new one.

To set the message server address

Select Menu > Settings > Connectivity > Message settings > Picture message.

Scroll to a profile and select Options > Edit.

Scroll to Message server and select Edit.

Enter the address and select OK > Save.

I cannot synchronise or transfer content between my phone and my computer, when using a USB cable.

The cable or software has not been properly installed. Go to www.sonyericsson.com/support to read Feature guides which contain detailed installation instructions and troubleshooting sections.

Error messages

Insert SIM

There is no SIM card in your phone or you may have inserted it incorrectly. See To insert the SIM card on page 3. The SIM card connectors need cleaning. If the card is damaged, contact your network operator.

Insert correct SIM card

Your phone is set to work only with certain SIM cards. Check if you are using the correct operator SIM card.

Wrong PIN/Wrong PIN2

You have entered your PIN or PIN2 incorrectly. Enter the correct PIN or PIN2 and select Yes.

PIN blocked/PIN2 blocked

You have entered your PIN or PIN2 code incorrectly three times in a row. To unblock, see SIM card lock on page 32.

Codes do not match

Codes that you have entered do not match. When you want to change a security code, for example your PIN, you have to confirm the new code. See SIM card lock on page 32.

No netw. coverage

•

Your phone is in flight mode. See Flight mode on page 29.

•

Your phone is not receiving any network signal, or the received signal is too weak. Contact your network operator and make sure that the network has coverage where you are.

•

The SIM card is not working properly. Insert your SIM card in another phone. If this works, it is probably your phone that is causing the problem. Please contact the nearest Sony Ericsson service location.

Emerg. calls only

You are within range of a network, but you are not allowed to use it. However, in an emergency, some network

operators allow you to call the international emergency number 112. See Emergency calls on page 15.

PUK blocked. Contact operator.

You entered your personal unblocking key code (PUK) incorrectly 10 times in a row.

Legal information

Sony Ericsson T715/T715a

This User guide is published by Sony Ericsson Mobile Communications AB or its local affiliated company, without any warranty. Improvements and changes to this User guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/ or equipment, may be made by Sony Ericsson Mobile Communications AB at any time and without notice. Such changes will, however, be incorporated into new editions of this User guide. All rights reserved.

Publication number: 1226-2918.1

Attention: Some of the services and features described in this User guide are not supported by all networks and/or service providers in all areas. Without limitation, this applies to the GSM International Emergency Number 112. Please contact your network operator or service provider to determine availability of any specific service or feature and whether additional access or usage fees apply.

Your mobile phone has the capability to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone. Prior to your use of any additional content, please verify that your intended use is properly licensed or is otherwise authorized. Sony Ericsson does not guarantee the accuracy, integrity or quality of any additional content or any other third party content. Under no circumstances will Sony Ericsson be liable in any way for your improper use of additional content or other third party content.

Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc. and any use of such mark by Sony Ericsson is under license. The Liquid Identity logo and PlayNow, are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB. Sony is a trademark or registered trademark of Sony Corporation. Media Go is a trademark or registered trademark of Sony Media Software and Services. microSD is a trademark or a registered trademark of SanDisk Corporation. Yahoo! Is a trademark or a registered trademark of Yahoo! Inc. Ericsson is a trademark or registered trademark of Telefonaktiebolaget LM Ericsson. Microsoft, Windows, Outlook, Windows Vista, Windows Server and ActiveSync are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. T9™ Text Input is a trademark or a registered trademark of Tegic Communications. T9™ Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057, United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide. This product is protected by certain intellectual property rights of Microsoft. Use or distribution of such technology outside of this product is prohibited without a license from Microsoft. Other product and company names mentioned herein may be the trademarks of their respective owners. Any rights not expressly granted herein are reserved. All illustrations are for illustration only and may not accurately depict the actual phone.

www.sonyericsson.com

Sony Ericsson Mobile Communications AB SE-221 88 Lund, Sweden

1226-2918.1

FCC Statement

Declaration of Conformity

Sony Ericsson T715

UMTS HSPA Band 1 GSM GPRS/EDGE 850/900/1800/1900

English

Radio wave exposure and Specific Absorption Rate (SAR) information

Thi s mob ile phon e mod el T715 has b een d esi gned to co mpl y wit h app lic able safet y r equir ement s for ex posur e to rad io wa ves. The se re qui remen ts ar e b ased on sc ienti fic guid eline s t hat inc lude saf ety m argin s d esign ed to assu re the s afety of all per sons, re gardl ess o f a ge an d hea lth.

The radi o w ave e xposu re guide lines empl oy a uni t of mea surem ent know n as the Spec ific Absor pti on Ra te, o r S AR. Tes ts fo r S AR ar e con duc ted u sing stand ard ized metho ds with the phon e t ransm ittin g a t its high est c ert ified powe r l evel in al l use d fre que ncy b ands.

Whi le th ere may be di ffe rence s bet ween the SAR level s o f var ious pho ne mo dels, th ey ar e all desi gne d to meet the rele vant gui delin es for e xposu re to ra dio w aves.

For more in forma tion on SAR, pleas e ref er to th e saf ety cha pter in the U ser’s Gu ide.

SAR data in forma tion for resi dents in c oun tries that ha ve ado pted the SAR limit re comme nded by th e I ntern ation al Com missi on of No n-Ion izi ng Ra diati on Pr ote ction (ICN IRP ), whi ch is 2 W/kg avera ged over ten (10) gra m of tissu e ( for exa mple Eur opean Unio n, Japan , Bra zil a nd New Z ealan d):

The high est SAR value fo r thi s mod el ph one when test ed by Son y Eri css on fo r use at the ear i s 0. 90 W/kg (10g) .

FCC Statement

Thi s dev ice comp lies wit h Par t 15 of th e F CC ru les. Ope ratio n i s sub ject to the f ollow ing t wo condi tions : ( 1) Thi s dev ice may not c aus e har mful inter fer ence, and (2) Thi s dev ice must acce pt any i nterf erenc e r eceiv ed, i ncl uding int erfer enc e tha t may ca use u ndesi red o per ation .

Any chan ge or mo dific ati on no t exp ressl y a pprov ed by So ny

Eri csson ma y voi d the us er's autho rity to opera te th e e quipm ent.

Thi s equ ipm ent h as be en teste d and foun d t o com ply w ith the lim its f or a Cla ss B dig ital devic e, pu rsu ant t o Par t 1 5 of the F CC Rul es. T hes e lim its a re desig ned t o pro vid e rea sonab le pro tecti on again st ha rmf ul in terfe rence in a re siden tia l ins talla tio n. Th is eq uip ment gener ates, us es an d can ra diate rad io fr equ ency energ y a nd, i f not inst all ed an d use d i n acc ordan ce with the i nst ructi ons, may c aus e har mful int erfer ence to radio co mmuni catio ns. Howe ver, there is no g uaran tee that int erfer enc e wil l not oc cur i n a p artic ula r ins talla tio n.

If this equ ipmen t doe s c ause harmf ul in ter feren ce to ra dio o r tel evisi on recep tion, wh ich c an be dete rmi ned b y tur nin g the equ ipmen t o ff an d on, th e use r is encou rag ed to try to corre ct the inte rfe rence by o ne or mo re of the fol lowin g mea sur es:

•

Reo rient or relo cate the rece iving ante nna .

•

Inc rease th e sep arati on betwe en th e equ ipm ent a nd re cei ver.

•

Con nect the equi pment in to an outl et on a circu it di ffe rent fro m tha t t o whi ch th e r eceiv er is conn ect ed.

•

Con sult the deal er or an expe rienc ed ra dio /TV t echni cia n for hel p.

Industry Canada Statement

Thi s dev ice comp lies wit h RSS -210 of In dus try C anada .

Ope ratio n i s sub ject to the f ollow ing t wo condi tions : ( 1) th is dev ice m ay not c ause int erfer ence, and (2) this devi ce must acc ept a ny inter feren ce, incl uding inte rfe rence that ma y cau se und esire d o perat ion o f t he de vice.

Thi s Cla ss B dig ital app aratu s com plies wi th Ca nadia n ICE S-003 .

Cet appa rei l num ériqu e d e la class e B e st confo rme à la norm e NMB -003 du Canad a.

Declaration of Conformity for T715

We, Sony Er icsso n Mob ile C omm unica tions AB of Nya Vatt ent ornet SE- 221 8 8 L und, Swede n dec lare und er ou r sol e r espon sibil ity t hat our produ ct

Son y Eri css on ty pe AA D-3 88003 9-BV

and in c omb inati on wi th our a ccess ories , t o whi ch th is dec larat ion rela tes i s i n con formi ty wi th the a pprop ria te sta ndard s E N 301 511: V9. 0.2, EN 30 1 908 -1: V3.2. 1, EN 30 1 908 -2:V3 .2. 1, EN 300 328 :V1.7 .1, E N 301 48 9-7:V 1.3.1 , E N 301 489 -17:V 1.3 .2 an d EN 60 950-1 :2006 foll owi ng th e pro vis ions of, Radi o E quipm ent a nd Telec ommun icati on Termi nal Equ ipmen t d irect ive 1999/ 5/EC .

Lun d, Ju ly 2009

Rik ko Sa kag uchi,

Cor porat e V ice P resid ent and Head of Cr eat ion & Deve lop ment

We fulfi l t he re quire men ts of the R&TTE Di recti ve (1 999 /5/EC ).

󰤏󰥩󰥨 󰤯󰤙󰤥󰥨 󰤏󰥵󰥁󰤙󰥙󰥤 󰤏󰥭󰥵󰤠󰥯󰤙󰥠 R&TTE (1999/5/EC).

Biz R&TT E T əlima tları nın tələ bləri ni ye rin ə yet iriri k ( 1999 /5/ EC) .

Ние изп ълня ваме изис кван ията на Дире ктива та R &TTE (19 99 /5/ EC) .

Mi ispun jav amo z ahtje ve R&TTE Dire ktive (199 9/5 /EC). Com plim els requ isits de la d irect iva R &TT E (1999 /5/ EC). Výr obek spl ňuje požad avk y smě rnice R&TT E ( 1999/5/EC) .

Vi opfyl der krav ene i R& TTE-d irekt ivet (1999 /5/ EC). Die Anfo rde runge n der Ri chtli nie f ür Fu nk- und Fernm eld egerä te

(19 99/5/ EG) werd en er füllt .

Πλη ρούμ ε τι ς απ αιτήσ εις της Οδηγ ίας R &TTE (19 99 /5/ ΕΚ) .

Cum plimo s l os re quisi tos de l a Dir ectiv a R &TTE (1999/5/EC ). Vas tab d ire ktiiv i R&T TE Direc tive (1999 /5/EC ) nõu etele . R&T TE (1 999/5 /EC ) art eztar auare n b aldin tzak bet etzen ditu gu.

  R&TTE       )1999/5/EC(

  .

Täy tämme ra dio- ja te lep äätel aited irekt iiv in (199 9/5 /EY) ase ttama t v aatim ukset .

Ce produ it est c onfor me à la direc tive R&T TE (199 9/5 /EC). Son y Eri css on cu mpre cos requ isito s esi xid os po la di rec tiva

R&T TE (1 999/5 /EC ).

Mun cika sh araɗi n bay ani n R&T TE (99/5/E C).

Mi ispun jav amo z ahtje ve R&TTE Dire ktive (199 9/5 /EC). Tel jesít jük az R &TTE irá nyelv (199 9/5/E C) kö vetel mén yeit. Kam i mem enu hi pe rsyar ata n yan g dit etapk an Petun juk R &TT E

(19 99/5/ EC) . Við uppf yll um R& TTE t ils kipun ina (1999/ 5/EB) . Il prodo tto sodd isfa i r equis iti d ella Dir ettiv a R&T TE (1999/5 /EC ).

ונא םידמוע לכב תושירדה תייחנהבש ה-R&TTE )1999/5/EC(.

Mes vykd ome R&TT E dir ekt yvos (1999 /5/EC ) rei kalav imu s. Mēs izpi ldā m R&T TE di rek tīvas (199 9/5/E K) pr asība s.

Ние ги испо лнув аме б арањ ата на R &TTE Dire ctiv e (1 99 9/5 /EC ).

We voldo en aan d e ver eis ten d ie in de R &TT E-ric htlij n ( 1999/5/ EG) word en geste ld.

Vi oppfy lle r kra vene i R &TTE- direk tivet (199 9/5 /EC).

Ate ndemo s a os re quisi tos da D iretr iz R& TTE (1999/ 5/E C). Spe łniam y w ymaga nia d yre ktywy R&TT E (19 99/5/ WE). São cump rid os os requ isi tos d a Dir ectiv a R &TTE (1999/5/EC ). Înd eplin im cerin ţele Dir ectiv ei R& TTE ( 1999/ 5/EC) .

Изд елие удо влет воряе т тр ебов ания м Ди ректи вы R &TTE (19 99 /5/ EC) .

Výr obok spĺ ňa po žiada vky smer nice R&TTE (199 9/5 /EC). Izp olnju jem o zah teve dir ektiv e za radij sko in t eleko mun ikaci jsko

ter minal sko opre mo (1 999/5 /ES). Ne përmb ush im kë rkesa t e dire ktivë s R&T TE (1999/5/EC ). Mi ispun jav amo z ahtev e d irekt ive R &TTE (1999 /5/EC ). Re pheth isa ditl hoko tsa Tael o ya R&TTE (199 9/5 /EC). Vi uppfy lle r kra ven i R& TTE-d irekt ivet (1999 /5/ EC).

เรา ปฏิบัติต ามขอกำห นดของขอ บังคั บ R &TTE (1999 /5/ EC )

R&T TE Ka rar names inin (1999 /5/EC ) gerekl ilikl eri ni ye rine get irmek tey iz.

Цей Вир іб в ідпо відає вим огам Дир екти ви R& TTE (199 9/ 5/E C).

Chú ng tôi đ áp ứng các y êu cầ u c ủa Chỉ thị R&T TE (1999 /5 /EC ).

A t i mu awọ n ibe ere I lan a ti R&TTE ṣẹ ( 99/5/ EC).

我們符合 R&TTE 規程中的要求 (1999/ 5/EC) 。本公司符合 R&TTE Dire cti ve (1999/5 /EC) 中的規定。

我们符合 R&TTE 指令 (1 999/5 /EC ) 的要求。 Siy azife za izidi ngo z eMi yalel o ye- R&TTE (199 9/5 /EC).

+ 21 hidden pages
